A Rational Perspective on Software Modeling

Tony Spiteri Staines

University of Malta, Malta MSD 2080, Malta

Keywords: Software Engineering, Requirements Engineering, Modelling, Systems Modeling, Software Development

Methods, Lightweight Methods, Quality Assurance, Best Practice Approaches.

Abstract: This work introduces the concept of rational software modeling from a practical perspective. Valid

arguments about the importance of modeling in modern software engineering and requirements engineering

are presented. The different stakeholder’s perspectives or views on modeling are analysed and a soft

uniform approach is presented. The uniform approach or rational perspective to modeling is based on the

main fundamental concepts of requirements engineering. This approach presents the basic ground for more

elaborate work in the future. The universal approach is based on i) usability, ii) universality, iii) uniqueness

and iv) uniformity. The concepts presented can be combined with any particular approach or method. The

ideas could prove to be useful for quality assurance and best practice approaches in the real world.

1 INTRODUCTION

Modeling is the very act of creating representational

artifacts of a system or its parts, for the specific

purpose of explaining it to different stakeholders. It

is possible to represent the software development

process and the product itself using appropriate

techniques. Modeling is useful for deriving the

fundamental properties of software.

In the modern world the ever increasing

complexities of applications and software systems,

ranging from distributed systems to hybrid

computing, require even more robust forms of

modelling. As a matter of fact, requirements

elicitation, need new ways of expression and

representation. New concepts in system design are

constantly being introduced as is the concept of

design for service presented in (Aleksy, 2012).

In spite of the increasing importance of

modelling, many software development companies

and even students do not seem to comprehend the

importance of this topic. Modeling remains a vague

abstract concept. Another problem lies in the fact

that some notations, like the UML tend to over

model a system, whilst other extreme approaches

like XP tend to focus more on coding rather than

modeling. This work focuses on finding a rational

solution. The idea is to understand the rationality of

modeling and possibly find a middle path solution.

2 WHY MODEL

Modeling exists for various reasons. In theory

modeling, apart from clarifying requirements, is

intended to i) reduce project delivery times ii)

promote reuse and iii) serve as a basis for contracts

between different groups. In the RUP (rational

unified process) business modeling is a core

workflow process. This process is important in all

the stages of the development starting off from the

inception stage to construction and testing stages.

Even in light methods, like Agile ones, modeling

practices cannot be omitted. The fundamental

question to ask is why do we have to model in the

first place. Perhaps some software aspects need

better comprehension or some ideas need to be

communicated to different stakeholders. It could be

simply that the model has to be created for the

persons who will develop the system, test it or

implement it. Some steps, in modeling, are i)

identifying the target audience, ii) develop the model

and iii) check if the model is suitable. One needs to

know the audience of the model. Referring to the

RUP the underlying rationale is to create suitable

models for every stage of the process of application

building. The key concepts and philosophy behind

the RUP are applicable to different types of

problems and enhance one’s own learning

experience.

345

Spiteri Staines T..

A Rational Perspective on Software Modeling.

DOI: 10.5220/0005090103450350

In Proceedings of the 9th International Conference on Software Engineering and Applications (ICSOFT-EA-2014), pages 345-350

ISBN: 978-989-758-036-9

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

3 SOME IDEAS

Traditionally, models were mainly used at the initial

stages of analysis and development. As opposed to

this in modern development strategies and methods

models are not necessarily just developed at a single

stage; but a refactoring process takes place with

modeling, which is seen as a continuous process.

Modern processes are focused on concepts like best

practices, case tool support and the idea of having

several processes, rather than steps or stages as

traditionally presented.

Information modeling deals with presenting real

world views to different stakeholders. Models can be

diagrammatic or formal. Models can represent

conceptual, logical or physical views (Moody,

2009). Many new different modeling notations exist

because of new technologies and distributed systems

(Jeusfeld et al., 1998), (Jeusfeld et al., 2009). As a

case in point, the UML (Collier, O’Hare, and

Rooney, 2004) contains several notations and

hundreds of elements are specified in the

superstructure documentation. But are these really

relevant to proper design?

If the view of system architectural complexity is

considered, the count of things like entities,

connections and patterns are factors that have to be

considered for modern systems which are obviously

software intensive systems (Booch, 2008). Here the

concept of relative vs absolute complexity is

considered and it is only possible to focus on the

essence, using principles of abstraction. States in the

real world are extremely important and sometimes

unorganized complexity exists (Cao et al., 2009).

The solution proposed by (Booch, 2008) is i) focus

on fundamental problems, ii) define abstractions, iii)

employ good separation of concerns, iv) proper

responsibilities. I.e. it is possible to deduce that the

general idea would be to simplify and focus on the

essence of modeling.

Complexity can obscure or hide the essential

elements of a system. The uniqueness, elegance and

aesthetical value of a solution, imply that simple

architectures have more value than complicated ones

for representation and modeling purposes.

Simplicity is easier to comprehend and measure

rather than complexity.

In fundamental modeling concepts (FMC, 2013)

it is also suggested that diagrammatic notations

should follow certain aesthetic principles. The main

principles behind the FMC idea are i) abstraction, ii)

simplicity, iii) universality, iv) separation of

concerns and v) aesthetics and secondary notation.

The key principles behind FMC have been

successfully applied at SAP in the form of TAM

(technical architectural modeling) (FMC, 2013)

which combines the salient principles of FMC with

those of some UML modeling notations, creating

better diagrammatic notations for analysing and

representing customer requests (Knopfel et al.,

2006).

Even the lines, harmonization and aesthetical

way of drawing artifacts all sum up to a rational way

of modeling systems (Knopfel et al., 2006).

Systems can fail because the systems architect

selects a fundamentally wrong architecture or

something that is too complex to properly

implement. Sometimes systems can fail because of

the continuous adding of parts and little bits. A

system or software development that started off as a

simple task sums up into a cumbersome ordeal that

lacks structure or proper representation. Software

engineering is a discipline that requires the

reasonable combination of dynamic and static

forces.

Architectural refactoring implies the use of

patterns that help manage complex system design.

Patterns help with the observation and classification

in a natural ordered way. I.e. the mental concept that

is observed is easily repeated and represented for

future work and support.

MDE (model driven engineering) has kicked off

research on domain specific languages (OMG,

2013). The idea of MDE rests on the construction of

proper software models that are used to create PIMs

(Platform independent models). MDD (model driven

development) is based on models and architectures

that have to be properly represented for successful

implementation. The idea of PIMs signifies that a

model should be conform to certain rules but

simultaneously express universality for different

platforms.

In light methods such as Agile, Scrum or the UP

(unified process) and even XP (extreme

programming) proper modeling is a must, even

though the models must be kept concise and simple

for quick use.

The principles that can be learned from different

processes, methods and ideas are applicable

independently of the process itself. These can be

easily combined with different methods or

techniques without being limited.

Universality is a form of understanding the

diverse types of modeling notations that can be

confusing and frustrating. Software engineering is a

complex discipline, depending on many different

types of constructs and their proper selection.

ICSOFT-EA2014-9thInternationalConferenceonSoftwareEngineeringandApplications

346

4 DIFFERENT PERSPECTIVES

Given the focus of modern systems that are mainly

directed towards the users and customers of a system

(Aleksy, 2012), it can be observed that software

development is based on a model centric approach.

The perspectives can be classified into the i)

organizational perspective or ii) stakeholder

perspective. Here the stakeholder perspective is

considered. In (FMC, 2013), (Knopfel et al., 2006)

and (Booch, 2008) it is obvious, but not stated

directly that models have certain basic properties

that can be classified here as: i) usability, ii)

universality, iii) uniqueness and iv) uniformity

4.1 Developers

Developers can be satisfied by using proper models

that explain properly what needs to be done. A

balance has to be sought between complexity and

compactness. Developers tend to be unsatisfied if

too many models are used and a lot of consistency

checking has to be done to verify the models. I.e.

consistency checking can become very tedious and

time consuming. These principles are observable

from agile methods or other light methods.

Normally the developers would require to have

refined models and also lower level representations

of the operations of the artefact they have to

develop. These are constructable in conjunction with

the system analysts and customers.

4.2 Project Manager

The project manager is more concerned with the

technicalities or overall architecture of the system

rather than the details. This is similar to a coarse

grained approach. From this perspective the models

would represent the architecture or top level

structure of the system. Proper notations are

imperative, but also the models must not be too

complex. Obviously visual modelling should express

ideas in simplicity and an aesthetically pleasant

form. If the system being designed is not

straightforward it might be necessary to use the

experience of an expert systems architect.

4.3 Systems Analyst

For the systems analyst or business analyst, the role

of model creation would be an important part of

their job. It is important that this group is

substantially trained in the use of correct

specification modelling. This implies that their

education would have to go beyond just using some

notations. I.e. the systems analyst must be aware of

the different notations, models and methods and

must have the ability to select the best notation for a

particular task or job. This depends on the

environment in which the systems or business

analyst works. I.e. if future systems will be similar

to those being created now, then in the future similar

modeling notations can be employed.

However, if the nature of the problem changes,

this might imply that better notations have to be

sought. Proper training in modeling can help greatly.

The experienced analyst has to develop his

knowledge gradually after being exposed to the

modeling notations and techniques. There are so

many notations, that selecting the best ones is not a

simple task. A problem will arise if too many or too

few model representations are used. A simple

solution is normally the best, but it does not imply

that important details are ignored. Later work

depends on the initial artefacts, yet still there is the

possibility for refactoring at later stages.

4.4 Tester

The tester or testing team does not normally

construct models. However the testing relies on

previous models for comparison. The development

artefact is compared with the initial proposed model.

For testing, models must not be too complex

otherwise it will be a much more time consuming

process.

4.5 Customers or Users

The customer or users play an important role. The

focus in many types of development is on the end

users of customers. This is evident in SOA’s, CMS

and CRM systems.

Communication with the clients, customers is a

must. Customers are not interested in the detail but

in the essential properties of the system. The models

used should reflect this.

4.6 Other Stakeholders

Obviously system construction is normally not just

limited to the primary stakeholders already

mentioned. Managers, CEOs, CIOs and IT auditors

might be interested in the system. Other roles like

communications engineering or network engineering

need to be give due consideration.

All these different stakeholders can exert

pressure on the system and it is important to

communicate with them using appropriate models

for requirements and design decisions.

ARationalPerspectiveonSoftwareModeling

347

5 A PROPOSED UNIFORM

APPROACH

The approach here is called the four U’s. This can be

included in any type of development method as

required. The four U’s are: i) usability, ii)

universality, iii) uniqueness and iv) uniformity.

These can be used to select the best notations or

models for a particular task or complement a

process.

USABILITY

UNIVERSALITY

UNIQUENESS

UNIFORMITY

5.1 Usability

Preferably diagrammatic notations should be used in

combination with other forms of representation.

Every artefact that is created will require some form

of modification or updating over time. The models

should be simple to update and correct without

considerable effort. This is the Agile philosophy.

Too much detail renders the model unusable for

development teams working in environments that

have a quick turnaround time. But for complex

systems usability might imply a different idea.

Usability also implies the usefulness of the

models from the customer or user viewpoint. In

order to communicate the requirements the

modelling approach being used should use effective

structures that are simple enough for proper

comprehension, but at the same time consider

sufficient detail. From a certain perspective the

concept of usability might be in direct conflict with

complexity. For difficult systems or artefacts it can

be difficult to explain the entire functions at a low

level using simple representations.

Usability requires asking some fundamental

questions about the notations being used. I.e. i) is the

notation simple enough to understand, ii) do case

tools that support the notation exist, iii) does the

notation have a significant learning curve to get to

use it, iv) is the notation suitable for sharing it in a

team.

Depending on different stakeholders there is the

possibility of different interpretations of usability.

What is usable for one stakeholder group is not

necessarily usable by another.

5.2 Universality

Universality implies that the modelling approach

being used is based on effective structures for

communicating the requirements. The quality of a

software engineering method depends on the

accuracy it has for representation. I.e. the method

should focus on empowering and explaining the

facts to the customers or the users of the method.

This implies that there is some form of technique or

method that is widely acceptable or can be

comprehended simply by different groups of

persons. Certain block diagrams and representational

notations do not require special learning to

understand. Examples of these are class diagrams,

flow diagrams, DFDs, component and network

diagrams, rich pictures, pictorial models, etc. Hence

the modelling approach used needs to consider a

wide target audience. Obviously the concept of

universality merits more attention and study to

comprehend the perception of different users having

different abilities and learning skills. This is

considered in the CMM (capability maturity model),

where working knowledge is acquired after a

number of years working experience.

From experience it is possible to identify

notations and structures that have more significance

of universality than other structures. This is possible

because of the nature of the structures. I.e.

diagrammatic representations and artefacts being

visual, can have a more universal and wider appeal

than structures that are represented using letters or

sets of equations (Knopfel et al., 2006). Examples of

structures that can communicate universality are i)

use case diagrams, ii) class/object diagrams, iii)

flowcharts, iv) structured block diagrams like

deployment diagrams, network diagrams, etc.

5.3 Uniqueness

Uniqueness has several meanings and implications

in software development which do not necessary

agree with what is presented here. i) The solution or

the artefact developed is unique, ii) the design is

unique, iii) the problem is unique, etc. Here

ICSOFT-EA2014-9thInternationalConferenceonSoftwareEngineeringandApplications

348

uniqueness mainly refers to the modelling approach.

Obviously the model is part of the uniqueness of the

solution. The model should be unique in the sense

that it provides sufficient detail for a proper or

special solution. This means that there is no need to

repeat the obvious or to use several models that

show the same entities or processes in different ways

unless this is really required.

Uniqueness also states that the solution or the

artefact is of a certain standard and quality. The

approach to systems development is not just a hit

and miss approach, but a scientific problem solving

approach that is based on structure and proper

comprehension about the problem domain. Any

solution will not just do, it is required to have a set

of solutions and to select the best possible one.

Uniqueness means that the best proper notations for

the problem domain are to be used. The idea of

uniqueness is not learned in a short span of time but

it can only come when one has acquired proper

problem solving skills after practical work in the

field combined with thinking skills. Group sessions,

discussions, brain storming, teamwork and on the

job training can contribute in this respect.

Uniqueness also implies that the structures have

value or add value. The structures or notations must

add some knowledge, they should not state what is

obvious or already known but explain correctly what

is unclear or obscure about what has to be

developed.

5.4 Uniformity

In object oriented software engineering, uniformity

represents the data integration that is the result of

linking several abstract classes from several systems

or sub systems to produce a shared model.

Uniformity can be used at different levels of

abstraction: i) conceptual, ii) logical and iii)

physical. Uniformity refers to the proper integration

of the modelling notations being used. Linking

together the models and sharing the information

from different models implies that the models

cohesively fit in with each other, i.e. the models

must support each other properly, with no

overlapping. Uniformity becomes a big problem

when too many diagrammatic and other notations

are used to support software development.

Consistency checking between the models becomes

a time consuming complex process that wastes a lot

of resources. The fewer the models the easier it is to

have proper uniformity in place. The more complex

a system is the more difficult is uniformity

mantained. If FMC (fundamental modeling

concepts) and TAM (technical architectural

modeling) used at SAP are examined, the concept of

uniformity becomes clearly visible. The notations

used in FMC for architectural modeling, combine

i)compositional structures, ii) behaviour and iii)

data/value structures. I.e. there is uniformity

between the three types of structures. On the other

hand, if notations from UML are taken and

combined with other notations quite often it is

possible that the concept of uniformity is ignored.

6 BEST PRACTICE APPROACH

The ideas of the four U’s presented can be

implemented as part of a best practice approach, or

in an appropriate framework. The concept of best

practice is based on work related excellence. The

idea is for continuous quality improvement and the

learning process that requires due consideration.

There is the concept that one size does not fit all.

This means that there is no identical solution for

different problems. For modeling this is more of an

issue because it is intrinsically very difficult to

compare system requirements. A certain degree of

flexibility in modeling is a must, but the flexibility

must be properly balanced against complexity. The

experience required for proper modeling cannot be

achieved only by formal training, but requires on the

job training and perhaps a number of years of

practical experience. But obviously formal training

is imperative to get started on the concepts related to

modelling (Stone and Madigan, 2007). Perhaps, in

certain computer courses and training, there is still a

lack or proper problem solving formulation which is

propagated further up. A best practice approach

means that one learns from mistakes and applies

expertise that can only be developed with time.

Sometimes it might look unpleasant to try to enforce

a culture where design notations and modeling are

given a great amount of importance. Because of

excessive rigor, certain individuals might prefer to

keep concepts and system details in their mind

creating problems. Proper judgement and intuition

provide for proper reasoning to problem solving. In

a best practice approach notations, modeling and

documentation are a must.

Elaborate solutions are not always desirable and

elegant approaches do not mean that elaborate

features and complexities are dealt with. Under-

engineering might be a problem just as over

engineering. Certain challenges implicate that a best

practice culture is developed and instilled in the

ARationalPerspectiveonSoftwareModeling

349

organization that is using modelling techniques, so

that a rational perspective on modeling is taken.

Unfortunately the philosophy of a best practice

approach has to pervade the entire culture of the

organization and this might imply that it will take a

long time to develop it properly.

7 CONCLUSIONS

The importance of proper modelling in the field of

software and systems engineering cannot be over

emphasized. In modern environments where

complex holistic solutions are always increasingly

demanding, models must prevail at every stage of

proper project management. Considering the

difficulties for selecting proper models, a rational

perspective for software modelling has been

presented. The concepts can be applied to any type

of project ranging from small to large size and

independently of whichever method is used.

Obviously users of Agile methods like Scrum

and XP might find these ideas of interest to them.

Even users of the UP (unified process) might

consider implementing the concepts for further

quality improvement in the design of software

products.

It is obvious that commonsense should prevail

when using these ideas and that the concept of one

solution fits all one can never fulfill the complete

needs of different problem domains. Hence the

concept of adaptability that is fundamental in

principle to agile methods must be given due

consideration.

Best practice approaches can only be learned

through acute observation and mistakes that can

happen in time. This is similar to the idea of the

capability maturity model where the experience

gained over a number of years and projects in the

field of software engineering are quantifiable.

Obviously the approach presented here needs to be

validated in future work.

REFERENCES

Aleksy, M., 2012. Coverage of Design for Service

Principles in Software Engineering, 6

Int. Conf. on

Complex, Intelligent, and Software Intensive Systems

(CISIS), 100-105.

Booch, G., 2009. The Defenestration of Superfluous

Architectural Accoutrements, IEEE Software Domain

Specific Languages and Modeling, vo.l 26, no. 4., pp.

7-8.

Cao, L., Ramesh, B., Rossi, M., 2009. Are Domain-

Specific Models Easier to Maintain than UML

Models?, IEEE Software Domain Specific Languages

and Modeling, vo.l 26., no. 4., pp. 19-21.

Collier, R., O’Hare, G., Rooney, C., 2004. A UML-based

Software Engineering Methodology for Agent

Factory, Int. Conf. on Software Eng. And Knowledge

Eng.

FMC., 2013, TAM - The SAP way combining FMC and

UML, Technical report and documentation:

http://www.fmc-modeling.org/fmc-and-tam

Jeusfeld, M.A.., Jarke, M., Mylopoulos, J., 2009.

Metamodeling for Method Engineering, The MIT

press 1

edition.

Jeusfeld, M.A.., Jarke, M., Nissen, H.W., Staudt, M.,

1998. ConceptBase Managing Conceptual Models

about Information Systems, Handbook on

Architectures of Information Systems, Springer, ch.

12, pp. 265-285.

Knopfel. A., Grone, B.,Tabeling, P., 2006. Fundamental

Modeling Concepts, Wiley 1

edition.

Moody, D.L., 2009, “The Physics of Notations: Towards a

Scientific Basis for Constructing Visuals in Software

Engineering”, IEEE trans. On Software Eng.

35(6):756-779.

Stone, J.A., Madigan E., 2007. Inconsistencies and

Disconnects, Communications of the ACM, vol.5.,

no.4., pp. 76-79.

OMG., 2013, MDA - The Architecture of Choice for a

Changing World, OMG Documentation Website:

http://www.omg.org/mda.

ICSOFT-EA2014-9thInternationalConferenceonSoftwareEngineeringandApplications

350
