Cloud Computing and Technological Lock-In

Literature Review

Robert Viseur

1,2

, Etienne Charlier

and Michael Van de Borne

CETIC, Rue des Frères Wright, 29/3, 6041 Charleroi, Belgium

UMONS Faculty of Engineering, Rue de Houdain, 9, B-7000 Mons, Belgium

Keywords: Cloud Computing, Lock-in, Iaas, Paas, Saas, Big Data, Standardization, Open Source.

Abstract: The increasing use of cloud computing services results in an increased risk of lock-in that is source of

anxiety for users facing the risk of having their data to be hosted online without the possibility of migrating

them on their own IT resources or on competitors' platforms. In this preliminary research, we deal with the

problem of the management of lock-in in case of use of cloud computing services. We aim to answer six

questions: (1) What is the lock-in? (2) Is the lock-in perceived as a major problem? (3) What are the causes

of lock-in? (4) What is the impact of lock-in on the users? (5) How can the users avoid lock-in? and (6) Is

the general public concerned with the problem of lock-in? Our paper is organized in three sections. The first

section presents the methodology used for this study. The second section details the results. This section

identifies in particular six mechanisms to reduce the risk of lock-in. The third section discusses the results

and suggests further work.

1 INTRODUCTION

The cloud computing has its roots in the Application

Service Providers (ASP) model that emerged in the

early 2000s. The phenomenon “represents a

fundamental change in the way information

technology (IT) services are invented, developed,

deployed, scaled, updated, maintained and paid for”

(Marston et al., 2011). Cloud computing can be

defined as “an information technology service model

where computing services (both hardware and

software) are delivered on demand to customers

over a network in a self-service fashion, independent

of device and location” (Marston et al., 2011).

From the point of view of a user, cloud

computing comes in three distinct models (CIGREF,

2013; Marston et al., 2011). The Software as a

Service model (SaaS) provides the user with an

application hosted in the cloud (e.g. Google Mail,

Google Documents). The Platform as a Service

(PaaS) model provides an environment to develop

and deploy applications (e.g. Microsoft Azure,

Google App Engine). The Infrastructure as a Service

(IaaS) model provides storage and computation

capacities (e.g. Amazon S3, Amazon EC2). These

models can be deployed in a corporate network or an

external platform. The first case is known as private

cloud, the second, as public cloud. The latter

benefits on an important marketing from companies

and the growing notoriety of providers such as

Amazon (EC2) and Microsoft (Azure). The cloud

also affects the general public. The latter indeed

faced through online services such as SaaS, for

example, Facebook messaging services, Google

Mail email services or Google Documents online

productivity tool.

Whereas previously the user had its applications

and its data on its own computer (or on a network of

computers under its control), the cloud computing

outsources infrastructure, applications and/or data.

This results in a lock-in that is increased (or

perceived as such). It is a cause of concern for users

facing the risk of having their online data without

the possibility of migrating them on their own IT

resources or on competing service provider.

In this preliminary research, we deal with the

problem of the management of lock-in in case of use

of cloud services. We aim to provide an initial

response to the following six questions: (1) What is

the lock-in? (2) Is the lock-in perceived as a major

problem? (3) What are the causes of lock-in? (4)

What is the impact of lock-in for the users? (5) How

305

Viseur R., Charlier E. and Van de Borne M..

Cloud Computing and Technological Lock-In - Literature Review.

DOI: 10.5220/0005109903050313

In Proceedings of 3rd International Conference on Data Management Technologies and Applications (DATA-2014), pages 305-313

ISBN: 978-989-758-035-2

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

can users avoid lock-in? and (6) Is the general

public concerned with the problem of lock-in? Our

paper is organized into three sections. The first

section presents the methodology used for this study.

The second section develops the results that are

relative to the six research questions. The third

section discusses the results and proposes further

work.

2 METHODOLOGY

Our research consists of a literature review. The

latter is based on two types of sources. On the one

hand we used articles from scientific literature that

substantially address the issue of lock-in. These

papers were found mainly by querying the Google

Scholar search engine (scholar.google.fr). On the

other hand we relied on a set of articles from the

trade press that specifically deal with the issue of

lock-in in the cloud. The Google search engine was

used to identify these items. In practice, the next

four queries were used:

cloud lock-in, (saas OR

paas OR iaas) lock-in

, (amazon OR rackspace

OR azure OR "app engine" OR smartcloud OR

salesforce) lock-in

, and (facebook OR gmail)

lock-in

. The links from the first page of search

results were filtered in order to keep only the

substantive articles (for the third query, the number

of off-topic links were obliged to go on the third

page of results). At the end, twenty-four articles

were identified with this method. They were

complemented by a serie of five articles pointed in

the first series of articles. The articles from the

professional literature can be identified in the

references by the presence of the URL. Note that the

notion of lock-in seems to be used very little for

public services, perhaps because the term is more

familiar to business users.

The name of the suppliers that we used in

queries was determined on the basis of the emphasis

in the professional and scientific literature (Crochet-

Damais, 2013; Darrow, 2012; Harsh et al., 2012;

Nachmani, 2012; ZDNet, 2013; Zhang et al., 2013).

In particular, the publication of market shares

enables to objectify this choice. Amazon Web

Services (AWS), Microsoft Azure, Google App

Engine, Rackspace, Salesforce and IBM SmartCloud

for professionals were therefore chosen as the focus

in this paper. Facebook and Gmail were taken into

account for services that are more oriented towards

the general public. Each article from the professional

or scientific literature was processed to identify

items that meet the six research questions. These

elements were then categorized.

3 RESULTS

3.1 What Is the Lock-In?

According to Germain (2013), the lock-in appears

when the cost of changing technology from one

vendor to another is so expensive that the client is

unable to leave the vendor's offers. The lock-in is

not a new concept (Linthicum, 2012). Juengst (2012)

gives also well-known examples including blocked

mobile phones and ink cartridges. Linthicum (2012)

adds that the principle of the use of resources

external to the company is not new. According to

Germain (2013), the vendor lock-in has been part of

life in the IT business for many years. In practice,

the topic of lock-in also implies migration costs.

Chatzakis (2012) examines the issue of lock-in

in AWS, and identifies three levels of lock-in. The

light lock-in corresponds in practice to an absence of

lock-in: for example the platform uses industry

standards. The medium lock-in occurs when the

platform provides non-standard services whose

blocking character may be limited by rules relative

to development and architecture. The hard lock-in

requires parts of the source code to be rewritten but

it is associated with the provision of innovative

features that are sources of opportunities for the

users.

According to Malhotra (2013), “lock-in” is

another way of saying “risk”. There is a trade-off

between the lock-in (risk) and the value (profit).

Less lock-in means less functionality and more

source code to write.

Zhang et al. (2013) combines the concept of

lock-in with three other concepts: interoperability,

compatibility and portability. The interoperability in

the cloud is the ability of multiple vendors working

together. The compatibility in the cloud means that

data and applications can operate in the same

manner regardless of the cloud provider. The

portability in the cloud means that data and

applications can be easily moved and reused

whatever the choice of cloud provider, operating

system, storage format or API. In practice, by

improving the interoperability, the compatibility and

the portability help to reduce the lock-in.

Note that the term “lock-in” is also found in the

literature relevant to Increasing Returns to Adoption

DATA2014-3rdInternationalConferenceonDataManagementTechnologiesandApplications

306

(in french: “Rendements Croissants d'Adoption”,

RCA). Translated as inflexibility (in French:

“inflexibilité”), the lock-in is a locking mechanism

in the adoption process of a technology that

competes with other technologies (Foray, 1989).

3.2 Is the Lock-In Perceived as a Major

Problem?

The perceived importance of lock-in is widely

discussed.

According to Gruman (2007), the issue of lock-

in is one of the concerns for the users of enterprise

management solutions, especially as the sector has

experienced a significant consolidation in 2002. This

concern is reinforced by the exit costs that are

particularly high for management applications

(Messerschmitt and Szyperski, 2001). For Nachmani

(2012), the lock-in has an important impact on the

decision to use or not to use the cloud.

In practice, however, the results are more mixed.

Smets, a French entrepreneur active in free software

edition and SaaS solutions based on free software,

believes that the protection of privacy, commercial

confidentiality and freedom to migrate are irrelevant

differentiators for the vast majority of the market

(Viseur, 2013b). Kash (2013) noted that only 15% of

customers are concerned about the vendor lock-in.

This criterion appears in eighth position, a result to

be compared to security vulnerabilities that appear in

the first position and concern 51% of customers.

3.3 What are the Causes of Lock-In?

The first cause of lock-in is the pace of innovation

and the search for differentiation between

competitors. The cloud service providers seek to

differentiate themselves by placing innovations on

the market. These innovations take the form of

advanced features to customize the services

provided by the cloud computing suppliers (Kash,

2013). These features increase the risk of lock-in.

They are particularly established in the form of

vendor-specific API (Germain, 2013; Juengst, 2012;

Kash, 2013). These APIs allow the management of

the platform to be automated or customized, or

access to innovative services to be provided, for

example in the field of storage (Harris, 2013; Kash,

2013). The vendor-specific API are currently used

by 23% of customers, a figure expected to increase

(Kash, 2013).

The second cause of lock-in is the search for

Increasing Returns to Adoption. Babcock (2013)

estimates that the lock-in occurs when a company

becomes a dominant seller for a technology and

develops products that make progress with

proprietary elements. This strategy prevents

customers from leaving. The providers keep their

technologies proprietary for as long as possible,

because this blocks the customers in their

environment (McKendrick, 2011). The lock-in is a

good thing for the vendor because it reduces

customer turnover (“churn”) (Harsh et al., 2012).

However, the authors challenge this view because

they believe that brand loyalty must be obtained by

service quality and attractive prices. For Zhang et al.

(2013), the incompatibility between cloud products

and services providers may temporarily protect the

interests of each supplier. However, this strategy

will prove counterproductive in the long term as the

market will become more mature. In addition, this

strategy goes against the new modes of cooperative

definition of open standards that favor a wide

dissemination of the standard rather than control

(Adatto, 2013).

The third cause of lock-in is the use of

proprietary data formats by providers (Chow et al.,

2009). In SaaS, the interoperability problem arises

especially in terms of data (Zhang et al., 2013).

Regardless of any desire to curb the exit of data, the

volume of data can itself hamper migration and

block the user with a service provider. The

outsourced Big Data applications pose specific

problems in the case of migration, given the volume

of data. The contracts do not always specify the

terms of migration of user data when they wish to

change supplier (Kash, 2013).

The fourth cause of lock-in is the PaaS type

cloud platforms. The PaaS services are frequently

highlighted for their significant risk of lock-in

(Harris, 2013; Germain, 2013; Juengst, 2012;

Nachmani, 2012). Zhang et al. (2013) justify this

point by the fact that, from IaaS to SaaS, the

automation increases; therefore, from IaaS to SaaS,

the portability decreases. More portability means

more work for the management and the deployment

of the software. Various factors explain the

importance of lock-in for PaaS (Coté, 2008;

Germain, 2013; Juengst, 2012): the use of a

proprietary programming language, the use of open

source languages extended by proprietary APIs, the

provision of proprietary infrastructure services, the

use of proprietary databases, etc.

CloudComputingandTechnologicalLock-In-LiteratureReview

307

However, even for PaaS, the degree of lock-in is

variable (Nachmani, 2012). For example,

Force.com, the PaaS of Salesforce.com, has a

maximum degree of lock-in, because the Apex

language and the database are proprietary.

Conversely, Heroku, acquired by Salesforce.com,

supports JSON and XML Web services, and widely

used languages such as Java, Ruby or PHP, and open

source databases such as PostgreSQL and MySQL.

3.4 What Is the Impact of Lock-In for

the Users?

The first impact for the users is the blocking of user

data and the longer periods of migration. The user

data can be difficult to process because of the

impossibility of technical means to access, the use of

proprietary formats, or the volume of data to be

fetched (Chatzakis, 2012). The general public also

faces this problem with online services like

Facebook or Flickr (Weinberger, 2012).

The extension of the migration duration that

results is not without potential consequences for the

company. The supplier is not immune to an

acquisition by another company (McKendrick,

2011). The new owner can change its policies, and

cause problems, including legal problems (e.g.

location of data). The customers have no control

over the evolution of a commercial cloud (Chow et

al., 2009). They may therefore find themselves in

trouble due to the closure of a service. The Coghead

users faced this situation due to the closure of the

company and the purchase of assets by SAP.

The issue of lock-in may be related to privacy,

through the issue of life-cycle data, whether for

business users or the general public (Pearson, 2009).

The last phase of the life cycle is the decommission

that provides secure deletion and removal of

personal and sensitive data.

The consequences of lock-in can be masked by

the pricing practices of companies. Thus, the

customers can be attracted by the price war on the

upload of data (Darrow, 2013). It is possible that,

once these data are online, the providers try to be

remunerated otherwise, and therefore hamper the

data exit.

The second impact for the users is the price

increase for the use of cloud service. Zhang et al.

(2013) argue that there is a risk of ridiculously high

costs due to lock-in. The company can increase its

prices. The user may encounter difficulties to

migrate to new more attractive platforms (Coté,

2008). A PaaS vendor can increase the prices once

customers are blocked (Juengst, 2012). However,

this last statement applies only to PaaS that are not

based on a published full open source

implementation.

The third impact for the users is the slower pace

of innovation. According to Germain (2013), the

lock-in creates monopolies for the seller to the

detriment of customers and limits the pressure on the

supplier to innovate.

The fourth impact for the users is the reduction

of the development life cycle time. Against all

expectations, some authors present the lock-in as a

positive element for the users. This assessment is

associated with the vision of lock-in as a result of an

innovation process that allows the user to benefit

from the service. This view usually comes from

people close to cloud providers.

Coffee (2012) prefers the term “leverage” rather

than “lock-in”. According to the author, the

applications developed on Force.com have a shorter

life cycle. Therefore, they can be quickly adapted to

market realities. This results in a significant

competitive advantage for the users of cloud service

that are able to adapt their applications to rapidly

changing markets, such as mobile applications

market (“time -to-market advantage”).

Magnusson (2013) supports this view: the lock-

in is the price to pay for an innovative platform. The

platform takes on more work and allows the user to

gain time (e.g. Google Datastore). The exit out of

the Google App Engine (GAE) needs 3-4 months of

work for a large application (Magnusson, 2013).

However, the benefits due to GAE are numerous:

management of firewall, protection against DDoS,

protection against viruses, applying patches and

updates, load balancing, etc.

3.5 How can Users Avoid Lock-In?

The first way to avoid lock-in is the use of standards.

The standardization improves the interoperability

between clouds and reduces lock-in (Chow et al.,

2009; Messerschmitt and Szyperski, 2001; Zhang et

al., 2013). The standards are numerous. Pahl et al.

(2013) list a set of standards for the service

modelling (e.g. Open-SCA, USDL/SoaML/

CloudML, EMML), service interfaces (e.g. OCCI,

CMMI, EC2, TOSCA, CDMI) and infrastructure

(OVF).

DATA2014-3rdInternationalConferenceonDataManagementTechnologiesandApplications

308

However, Wolpe (2013) believes that the cloud

industry still suffers from a lack of standardization.

According to this author, the standardization would

happen after an initial innovation phase because it

appears as an obstacle to progress (sic). However,

this vision of standardization contradicts Adatto

(2013). The latter analyzes the emergence of new

modes of cooperative definition of standards,

together with FLOSS implementations, and the

development of strategies of competition between

industrial players. The development of the FLOSS

application concurrent with specification work

brings the standardization in the heart of the

innovation process. Kash (2013) also believes that

the use of open source technologies benefits from a

rapid pace of innovation.

Other authors highlight the current lack of

standardization and interoperability in the cloud.

Kash (2013) regrets the lack of mature standards. If

they consolidate on IaaS services they would,

however, be virtually non-existent for PaaS services.

However, even for IaaS, some technologies are

missing for interoperability (Harsh et al., 2012). In

IaaS, there is a set of technical issues to be resolved

(Zhang et al., 2013). They are partially covered by

standards (e.g. OVF, CDMI and OCCI) that are

offered by organizations such as the Open Grid

Forum (OGF), the Distributed Management Task

Force (DTMF) or the Storage Networking Institute

Association (SNIA). These standards are

progressively implemented in open source solutions

such as OpenStack, OpenNebula and Eucalyptus.

The progress of standardization may however be

variable. For example, network virtualization and

security procedures are important issues currently

processed at a minimum, unlike the issue of

virtualization formats that is well covered by OVF

(Harsh et al., 2012; Zhang et al., 2013). In terms of

IaaS , there is a taxonomy of interoperability in the

IaaS, to point more quickly to the technical problems

to be solved, that distinguishes access mechanisms,

virtualization, storage, networking, security and

service-level agreement (SLAs) (Zhang et al., 2013).

The second way to avoid lock-in is the use of

FLOSS (Free Libre Open Source Software).

According to Weinberger (2012), a solution to the

problem of lock-in is the use of FLOSS

implementations such as Apache CloudStack,

OpenStack and Eucalyptus. The open source

software is increasingly accompanied by

standardization initiatives (Adatto, 2013). They

often appear at the forefront in the field of

standardization. OpenStack is distinguished for

example by its ability to describe network via

software (Zhang et al., 2013).

The open source implementations may also

provide an answer to the concerns of lock-in for

PaaS-type services. Juengst (2012) recommends the

use of PaaS that offer support for multiple

programming languages, are built on open source

blocks, are open source themselves and do not offer

proprietary APIs. The cases of OpenShift

(www.openshift.com) and Google App Engine

(cloud.google.com/AppEngine) are illustrative.

The Google App Engine has two open source

implementations (Magnusson, 2013). The first is

App Scale (www.appscale.com). Google is working

with Red Hat for the second that is integrated to

OpenShift software via CapeDwarf

(www.jboss.org/capedwarf). Google is also working

to create a Technology Compatibility Kit (TCK) for

Google App Engine (GAE) API (www.appengine-

tck.org) that allows the editors of alternative

implementations to perform compatibility tests. Red

Hat (redhat.com) supports the functionality of the

Datastore storage service via Infinispan

(infinispan.org) open source software.

Red Hat with OpenShift uses in practice the

absence of lock-in as a commercial argument

(Juengst, 2012). The promise is to provide a public

platform (PaaS OpenShift Online) that the

companies can implement in their network, or on a

chosen public IaaS provider (via OpenShift

Enterprise) that is based on a FLOSS

implementation of the OpenShift technology

(OpenShift Origin). In practice, Google Trends

(www.google.com/trends/) shows a strong takeoff of

OpenShift.

The third way to avoid lock-in is the

development of applications based on a generic

functional base. The developments on cloud

platforms can be addressed by requiring the use of

middlewares (or frameworks) to avoid the

dependency to the differences between IaaS or PaaS-

type cloud platforms (Kash, 2013; Zhang et al.,

2013). In terms of IaaS, Zhang et al. (2013) cite the

existence of libraries that facilitate interoperability,

such as Libcloud (libcloud.apache.org) and

Deltacloud (deltacloud.apache.org). These libraries

allow only the common features in the different

supported platforms to be used. In terms of PaaS, the

Simple Cloud API, built by Zend (www.zend.com)

for its PHP framework (framework.zend.com) that

CloudComputingandTechnologicalLock-In-LiteratureReview

309

supports storage services including the Amazon and

Microsoft offers, can be cited.

The lock-in can also be limited by developing

key algorithms in a widely supported development

language, such as Java, and by exploiting the rest the

facilities offered by cloud computing providers

(Coffee, 2012).

The fourth way to avoid lock-in is the use of

specialized technical operators. Some specialized IT

suppliers, called “technical cloud brokers”, can help

agencies avoid lock-in and operate several cloud

services concurrently (Kash, 2013). They are similar

to the “enablers” in Marston et al. (2011).

The fifth way to avoid lock-in is the trust in

“open cloud” labels. The Foundation for a Free

Information Infrastructure (www.ffii.org) proposed a

definition of open cloud. This definition has three

degrees of freedom: TIO (Total Information

Outsourcing) Free / Open / Loyal (Scoffoni et al.,

2012). The TIO Loyal level “provides a framework

to reach the same level of trade secret and

operational transparency as with their own staff”

(tio.ffii.org). The TIO Open level provides freedom

of information and structuring of data in a clearly

specified format. The TIO Libre level provides

freedom of information, freedom of software and

freedom of competition. However, the TIO label has

a limited promotion at this stage (Viseur, 2013b). In

addition, the guidelines for implementing and

ensuring compliance with the conditions remain

difficult to identify. Other similar proposals exist,

such as the Open Cloud Principles of the Open

Cloud Initiative (www.opencloudinitiative.org) or

the Open Cloud Manifesto

(www.opencloudmanifesto.org) (Jean, 2013).

The sixth way to avoid lock-in is the

implementation of an exit strategy (McKendrick,

2011). The cost of the latter must incorporate the

calculation of the costs for implementing the

solution. The data migration should however be

tested, not just discussed with vendors (Kash, 2013).

The support of open standards or their FLOSS

implementations facilitates the implementation of an

exit strategy. The latter may also rely on the

existence of migration tools. Generally, these tools

support the most popular solutions for virtualization

and cloud computing such as VMWare, Amazon and

OpenStack (Kash, 2013). With Amazon, for

example, the importance of lock-in depends on the

existence of conversion softwares (e.g. VM

translations for EC2), the support for standard APIs

(e.g. RDS compatible with Oracle or MySQL),

alternative implementations (e.g. Elastisearch

compatible with Memcache) or the existence of

frameworks that provide a layer of abstraction (e.g.

Zend Framework and Django for S3) (Chatzakis,

2012). Although migration solutions exist, the

DynamoDB and SimpleDB NoSQL database

services are a source of hard lock-in.

Note that the development of a realistic exit

strategy assumes that the business has not been

affected by the loss of skills that can result from

outsourcing initiatives (Quélin, 2003). This loss can

cause a handicap for a reversal or even the

evaluation of alternative solutions.

3.6 Is the General Public Concerned

with the Problem of Lock-In?

The portability of data encoded by Facebook users is

a well-known problem. Facebook hinders the ability

for users to export the list of friends to Google Plus,

a rival social networks (Asay, 2011). It is possible to

export the personal data in a downloadable archive

(Protalinski, 2011). The latter is especially useful as

a personal backup. Facebook improved its export

system for developers by enriching data with

microformats (hAtom, hmedia and hCard)

(Protalinski, 2011). Exporting contacts is, however,

the subject of numerous articles on the Web, which

is proof, if any was needed, that the interoperability

between social networks is limited.

Weinberger (2012) shows that the difficulty of

data exit also arises for other consumer services.

Flickr, for example, does not offer an officially

supported method for migration. Flickr was further

highlighted in 2006 by blocking the migration of

photos submitted by their users to Zoomr competitor

service. Its API, although functional, was rendered

inoperable for contractual reasons: “We choose not

to support use of the API for sites that are a straight

alternative to Flickr” (Ozerman, 2006).

However, the consumer pressure led to the

emergence of initiatives to facilitate the migration of

data, such as Google Takeout Initiative (Weinberger,

2012). The latter is integrated to the Google Data

Liberation Front (www.dataliberation.org) and

allows the export of data managed by Google

services towards standard data formats (de facto

standards such as DOCX or open standards such as

ODF). For example, a mail box can be exported to

MBOX, one format that is supported by Mozilla

Thunderbird or Microsoft Outlook.

DATA2014-3rdInternationalConferenceonDataManagementTechnologiesandApplications

310

4 DISCUSSIONS AND

PERSPECTIVES

This preliminary research enabled the four different

causes of lock-in to be highlighted, four impacts of

lock-in on the users to be identified and six

mechanisms to reduce the risk of lock-in to be

proposed. Moreover we showed that the problem of

lock-in also had many similarities for professionals

and individuals.

Our research focused on a set of dominant

worldwide providers. It therefore deserves an

extension to niche suppliers (e.g. Ikoula). Their

positioning face to dominant players could be highly

instructive.

The issue of lock-in is as old as the existence of

computers. The issue of data formats in the field of

productivity software is a well-known illustration

(Adatto, 2013). However, the problem has an

additional dimension in the case of cloud computing.

Indeed, the lock-in in the cloud not only causes

difficulties in terms of evolution of the service (for

example, if the pace of innovation offered by the

supplier decreases) but also has an increased risk in

terms of continuity of service. In practice, a software

solution that is installed on a local network by a

publisher in bankruptcy can be used for quite some

time by the company. A bankrupt cloud provider or

a cloud provider that bases its service on a bankrupt

cloud infrastructure provider causes greater

difficulties to its customers due to the inaccessibility

of the service. This point justifies the high visibility

of the topic in the IT press.

This research allowed us to identify a vocabulary

associated with the issue of (vendor) lock-in. This

includes, in particular, the following expressions: (1)

portability, compatibility and especially

interoperability, (2 ) exit strategy (3) increasing

returns to adoption, and (4) outsourcing. Research

about the studies associated with these expressions

could shed additional light on the issue of lock-in in

the cloud services.

The standardization that guarantees the

interoperability between platforms of cloud

computing emerges as a major track to avoid lock-

in. However, the existence of standards does not

solve all problems. The issues of functional

coverage of standards, industrial support of

standards, coverage of standards by implementations

and low success “open cloud” labels remain open

questions.

Table 1: Support of de facto and open standards in open

source projects.

OpenStack Eucalyptus OpenNebula CloudStack

OVF

Yes N/A Yes N/A

CDMI

Yes N/A Yes N/A

OCCI

Yes Yes Yes Yes

AMI

No Yes N/A N/A

S3 API

Yes Yes No Yes

EC2

API

Yes Yes Yes Yes

Zhang et al. (2013) provide an initial response in the

case of IaaS regarding the functional coverage of

standard and the coverage of the standards by

implementations. A complementary study, based on

Zhang et al. (2013), snia.org, dmtf.org, occi-wg.org,

openstack.org, opennebula.org and cloudstack.

apache.org, is proposed in Table 1. Further work is

necessary, for example, to estimate the actual level

of software compatibility with the listed standards.

Given the subtlety of some causes of lock-in (e.g.

possibility or not to migrate IP addresses, to change

the DNS, etc.), the granularity of the specifications

should also be deepened. More investigation on the

issue of industrial standards support is also needed.

For example, it could be estimated through hit

counts of search engine results (webometrics), as is

already done for the estimation of market shares

(Viseur, 2012; Viseur, 2013a). The thinking should

be extended to PaaS, for which standardization

initiatives have been emerging.

The particularization of the issue of lock-in

based on the model of provision (IaaS, PaaS or

SaaS) seems difficult at this stage. On the one hand,

although the literature demonstrates a tendency to

assign a higher risk of dependence in the case of

PaaS, multiple initiatives for standardization and

availability of FLOSS implementations (e.g.

OpenShift) have been considerably changing the

situation. On the other hand, it became apparent that

the decomposition between IaaS, PaaS and SaaS

providers, if it facilitated the understanding and the

analysis, was sometimes artificial. Indeed, IaaS

labeled platforms like Amazon make services that

are typically associated with PaaS platforms

available (e.g. NoSQL database). In addition, a

platform can be clearly straddling two modes of

provision. For example, Facebook will be

considered a SaaS provider with instant messaging

available to users, or PaaS provider if the developer

who contributes to the application store is taken into

consideration. Idem with Saleforce.com (SaaS) and

its complement Force.com (PaaS).

CloudComputingandTechnologicalLock-In-LiteratureReview

311

REFERENCES

Scientific References

L. Adatto, “Standards ouverts et implémentations FLOSS

(Free Libre Open Source Software) : vers un nouveau

modèle synergique de standardisation promu par

l’industrie du logiciel,” in Terminal : Technologie de

l'Information, Culture, Société, n°113-114, pp. 137-

170, 2013.

R. Chow, P. Golle, M. Jakobsson, et al. , “Controlling data

in the cloud: outsourcing computation without

outsourcing control,” in Proceedings of the 2009 ACM

workshop on Cloud computing security, ACM, pp. 85-

90, 2009.

D. Foray, “Les modèles de compétition technologique.

Une revue de la littérature”, in Revue d'économie

industrielle, Vol. 48, n° 1, 1989, pp. 16-34.

P. Harsh, F. Dudouet, R.G. Cascella, Y. Jegou and C.

Morin, “Using open standards for interoperability:

issues, solutions, and challenges facing cloud

computing,” in 8th International Conference on

Network and Service Management (CNSM), IEEE,

2012, pp. 435-440.

B. Jean, “Impact of cloud computing on FOSS users,” in

Conférence EOLE (European Open source & free

software Law Event), Bruxelles, 6 décembre 2013.

S. Marston, Z. Li, S. Bandyopadhyay, J. Zhang and A.

Ghalsasi, “Cloud computing - The business

perspective”, in Decision Support Systems, 51(1), pp.

176-189, 2011.

D. G. Messerscmitt, C. Szyperski, “Industrial and

Economic Properties of Software: technology,

processes and value,“ in Computer Science Division,

University of California, 2001.

C. Pahl, L. Zhang and F. Fowley, “Interoperability

standards for cloud architecture,” in Closer 2013,

Germany, May 2013.

S. Pearsin, “Taking account of privacy when designing

cloud computing services,” in ICSE Workshop on

Software Engineering Challenges of Cloud Computing

(CLOUD'09), IEEE, pp. 44-52.

B. Quélin, “Externalisation stratégique et partenariat: de la

firme patrimoniale à la firme contractuelle ?,” in

Revue française de gestion, n° 2, 2003, pp. 13-26.

P . Scoffoni, E. Ogez, L. Dubost, “L’open cloud : garder la

maîtrise de son système d’information,” in Méthodes,

techniques et outils, Documentaliste-Sciences de

l'Information, 2012/2 (Vol. 49), pp. 8-15.

R. Viseur, “Les moteurs de recherche commerciaux sont-

ils des outils de webométrie fiables ?,”, in 30ème

congrès InforSID, Montpellier (France), 29-31 mai

2012.

R. Viseur, “Estimate the Market Share from the Search

Engine Hit Counts,” in Proceedings of International

Conference on Data Technologies and Applications

2013, Iceland, July 29-31, 2013.

R. Viseur, “Evolution des stratégies et modèles d’affaires

des éditeurs Open Source face au Cloud computing,”

in Terminal : Technologie de l'Information, Culture,

Société, n°113-114, 2013, pp. 173-193.

Professional References

M. Asay, “Facebook, Google, and the war to lock you in,”

in The Register, 5 juillet 2011 [Online]. Available:

http://www.theregister.co.uk

C. Babcock, “10 Tools To Prevent Cloud Vendor Lock-

in”, in InformationWeek, 14 février 2013 [Online].

Available: http://www.informationweek.com/

A. Chatzakis, “How I Learned not to fear Amazon Cloud

Lock-in,” in Newvem, 28 mai 2012 [Online].

Available: http://www.newvem.com

CIGREF (2013), “Fondamentaux du cloud computing,”

Cigref, 2013 [Online]. Available: http://www.cigref.fr

P. Coffee, “Refuting Cloud 'Lock-In': Zero, One, Too,” in

Blog Network Salesforce.com, 18 janvier 2012

[Online]. Available: http://cloudblog.salesforce.com

M. Coté, “SalesForce-to-Google and the Force.com PaaS

Lock-in Question,” in Coté's People Over Process /

RedMonk, 24 juin 2008 [Online]. Available:

http://redmonk.com/

A. Crochet-Damais, “Marché du CRM : Salesforce passe

devant SAP,” in JDN, 29 avril 2013 [Online].

Available: http://www.journaldunet.com/

B. Darrow, “Fear of lock-in dampens cloud adoption,” in

GigaOM, 26 février 2013 [Online]. Available:

http://gigaom.com

J.M. Germain, “How to Avoid Cloud Vendor Lock-In,” in

LinuxInsider, 13 novembre 2013 [Online]. Available:

http://www.linuxinsider.com

G. Gruman, “Is Open Source the Answer to ERP ?,” in

CIO, February, 2007, Vol. 20, pp.23-28.

D. Harris, “Google defends, quantifies App Engine lock-in

concerns,” in GigaOM, 9 juillet 2013 [Online].

Available: http://gigaom.com

D. Juengst, “How to Avoid Cloud Vendor Lock-In when

Evaluating a PaaS,”, in OpenShift, 3 août 2012

[Online]. Available: https://www.openshift.com

W. Kash, “Avoiding Cloud Lock-in,” in Information

Week Government, Novembre 2013 [Online].

Available: http://www.informationweek.com

D. Linthicum, “2 more cloud myths busted: Lock-in and

locked up.,” in InfoWorld, 27 avril 2012 [Online].

Available: http://www.infoworld.com

P. Magnusson, “Google App Engine: Lock in, what lock

in ?,” in VB VentureBeat, 25 juillet 2013 [Online].

Available: http://venturebeat.com

R. Malhotra, “The Truth About Lock In,” in CloudAve, 13

février 2013 [Online]. Available:

http://www.cloudave.com

J. Mckendrick, “Cloud Computing's Vendor Lock-In

Problem: Why the Industry is Taking a Step

Backward,” in Forbes, 20 novembre 2011 [Online].

Available: http://www.forbes.com

O. Nachmani, “The Great PaaS Lock-In,” in DZone, 29

mai 2012 [Online]. Available: http://cloud.dzone.com

DATA2014-3rdInternationalConferenceonDataManagementTechnologiesandApplications

312

R. Ozerman , “Why is Flickr afraid of Zooomr?,” in

Techcrunch, 16 juin 2006, [Online]. Available:

http://techcrunch.com

E. Protalinski, “Facebook finally makes your exported

data useful,” in ZDNet, 8 septembre 2011 [Online].

Available: http://www.zdnet.com

M. Szynaka, “Ask the Expert: Is PaaS vendor lock-in

unavoidable ?,” in SearchCloudComputing, 04 avril

2013 [Online]. Available: http://searchcloud

computing.techtarget.com

CloudComputingandTechnologicalLock-In-LiteratureReview

313
