A Hybrid Approach to Developing a Cyber Security Ontology
James Geller
1
, Soon Ae Chun
2
and Arwa Wali
1,3
1
New Jersey Institute of Technology, Newark, NJ, U.S.A.
2
City University of New York – College of Staten Island, Staten Island, NY, U.S.A.
3
College of Computing and Information Technology, King Abdulaziz University, Jeddah, Saudi Arabia
Keywords: Cyber Security Ontology; Security Knowledge Acquisition Tool, Security Learning Objects, Textbook,
Index Terms, Augmented Ontology.
Abstract: The process of developing an ontology cannot be fully automated at the current state-of-the-art. However,
leaving the tedious, time-consuming and error-prone task of ontology development entirely to humans has
problems of its own, including limited staff budgets and semantic disagreements between experts. Thus, a
hybrid computer/expert approach is advocated. The research challenge is how to minimize and optimally
organize the task of the expert(s) while maximally leveraging the power of the computer and of existing
computer-readable documents. The purpose of this paper is two-fold. First we present such a hybrid
approach by describing a knowledge acquisition tool that we have developed. This tool makes use of an
existing Bootstrap Ontology and proposes likely locations of concepts and semantic relationships, based on
a text book, to a domain expert who can decide on them. The tool is attempting to minimize the number of
interactions. Secondly we are proposing the notion of an augmented ontology specifically for pedagogical
use. The application domain of this work is cyber-security education, but the ontology development
methods are applicable to any educational topic.
1 INTRODUCTION
Building ontologies is difficult. Two major schools
of thought with various combinations have defined
the state-of-the-art. One school relies entirely on
human experts. This approach works well as long as
the desired ontology is small. However, most useful
ontologies tend to be large. For example, in Medical
Informatics, SNOMED CT (Cornet & de Keizer,
2008) contains about 400,000 concepts. Due to
differing viewpoints, large ontologies cannot be built
in a completely modular fashion. Rather, experts
working on different modules need to communicate
with each other, which increases the amount of time
that is necessary for building the final product.
The alternative approach to ontology building is
to automate the process by letting “a computer read
available material, just like a human would read it.”
Unfortunately, this approach can only become
completely successful after the Turing Test has been
passed. This leads us to a two-pronged approach.
(1) Use any relevant structured or semi-structured
information that is available besides free text. (2)
Implement a software tool that maximizes support
for human experts and minimizes the time they need
to spend on ontology building.
An et al. and Geller et al. (An, Geller, Wu, &
Chun, 2007; Geller, Chun, & An, 2008) have used
the Deep Web as a source of structured information.
However, web site owners are increasingly
unwilling to let robot programs extract backend data,
which makes this approach difficult. Thus, we have
turned to another source of domain knowledge.
The best Knowledge Representation “system”
for over 3000 years has been the book. A major
improvement was achieved by adding a table of
contents with page numbers and a back index to
books. The exact history of the “alphabetic index” is
difficult to trace, but (Cleveland & Cleveland, 2013)
mentions an example from the 5
th
century. The fact
that a back-of-the-book index incorporates “a degree
of intelligence” can be seen from Artificial
Intelligence attempts to automate the process of
building an index (Wu, Li, Mitra, & Giles, 2013).
Our approach is to make use of the intelligence
that went into building an index and of the structure
of the index as it is intertwined with the text in the
body of the book. In this paper, we are describing a
hybrid approach to developing a cyber-security
ontology for education. First a seed ontology is
377
Geller J., Ae Chun S. and Wali A..
A Hybrid Approach to Developing a Cyber Security Ontology.
DOI: 10.5220/0005111503770384
In Proceedings of 3rd International Conference on Data Management Technologies and Applications (DATA-2014), pages 377-384
ISBN: 978-989-758-035-2
Copyright
c
 2014 SCITEPRESS (Science and Technology Publications, Lda.)

extended in a semi-automatic fashion, resulting in
the Bootstrap Ontology. The Bootstrap Ontology is
then extended by a domain expert using a
knowledge acquisition tool, called the Security
Knowledge Acquisition Tool (SKAT) that was
developed in this research. The semi-automatic
ontology construction component uses the textbook
index terms as input and classifies each index term
into a seed ontology of concepts. (Note that when
we use the term “classify,” this is not the DL
classification algorithm.) This preliminary work was
reported in (Chun, Geller, & Wali, 2014; Wali,
Chun, & Geller, 2013). However, this semi-
automatic processing left many index terms
unclassified in the security ontology.
The SKAT Tool allows a security domain
expert to manually place the security terms into the
ontology. In order to alleviate the cognitive burden
on the domain expert, the tool parses the textbook to
identify index terms co-occurring with ontology
concepts to make suggestions of candidate concepts
and relationships. Thus, SKAT incorporates a
Concept Recommendation component to identify
occurrences of ontology concepts in the unstructured
text of a textbook that co-occur with the semi-
structured index terms, and it recommends these
index terms as candidate concepts to the SKAT user.
This will minimize the expert’s effort to search in
the ontology structure for concepts that may be
related to a security term from the text book.
In this paper, we present related work in Section
2, and briefly review our automatic concept
classification approach and its results in Section 3.
Section 4 presents our approach to augmenting the
cyber security ontology further through the use of
concept recommendation and the SKAT tool, as
utilized by a human expert. In Section 5, we discuss
the results and experience with the SKAT tool.
Section 6 concludes with a summary and future
research tasks.
2 RELATED WORK
2.1 Security Ontologies
Ontology development approaches can be divided
into the purely manual, the purely automatic, and
various hybrid methods. In the manual approach, a
team of human experts accumulates domain
concepts, organizes them into a subconcept (subclass
or IS-A) hierarchy and then includes additional
information, such as semantic relationships between
pairs of concepts or details about concepts.
LoLaLi is an example of an ontology that was
manually built (Caracciolo, 2006). Building LoLaLi
manually was very time consuming.
The automatic methods attempt to build an
ontology by parsing of English text. There are
several variants for this approach, such as clustering,
linguistic pattern matching, formal concept analysis,
or ontology alignment. Hindle’s work is based on
the clustering approach (Hindle, 1990).
Hearst et al. used a linguistic pattern matching
approach to find semantic relationships between
terms from large corpora (Hearst, 1992). Formal
concept analysis was used for extracting monotonic
inheritance relations from unstructured data
(Cimiano, Hotho, & Staab, 2005; Wiebke, 2004).
Another method for developing a comprehensive
ontology is by ontology alignment. BLOOMS is an
example for building an ontology by alignment or
ontology matching from smaller ontologies (Jain,
Hitzler, Sheth, Verma, & Yeh, 2010).
In previous research, we used a methodology for
automatic construction of a domain ontology, by
combining WordNet (Fellbaum, 1998) concepts with
domain-specific concept information extracted from
the web (An et al., 2007). Methods based on
unstructured data from the web suffer from web
pages that may be changing rapidly. Pattanasri et al.
(Pattanasri, Jatowt, & Tanaka, 2007) developed a
textbook ontology using the index and the table of
contents. The concepts in each ontology are cross-
referenced with page numbers to refer to
corresponding textbook segments or slide page
numbers. To the best of our knowledge, our research
is the first that combines a back of the textbook
index with an existing security ontology as a seed
structure to build a more complete Bootstrap
Ontology of cyber-security terms and then provides
a tool for a human expert to augment the Bootstrap
Ontology. Several preexisting security-related
ontologies have been reported (Bajec, Eder, Souag,
Salinesi, & Comyn-Wattiau, 2012; Fenz & Ekelhart,
2009; Geneiatakis & Lambrinoudakis, 2007;
Herzog, Shahmeri, & Duma, 2007; Meersman, Tari,
Kim, Luo, & Kang, 2005; Vigna et al., 2003). For a
review see (Blanco et al., 2008).
2.2 Project Environment
The work presented in this paper is part of an NSF
funded project for creating an “Ultimate Course
Search” (UCS) tool for students to navigate existing
teaching materials. The UCS tool allows students to
search video recordings of a whole semester of
classes, interlinked with the power point slides used
DATA2014-3rdInternationalConferenceonDataManagementTechnologiesandApplications
378

in the lectures and page images of the text book. The
cyber-security ontology is visible in the UCS tool.
The intended function of the ontology is as
follows. If a search term does not appear anywhere
in the power point presentation but does appear in
the ontology, then the ontology component can
suggest closely related search terms, such as parents
or siblings, to be located in the power point
presentation. The likelihood that a student will
search for a term that is not correct is high, because
a learning student does not know the appropriate
terms of the domain. Thus, the ontology is needed.
3 AUTOMATED SECURITY
ONTOLOGY DEVELOPMENT
Our previous work (Wali et al., 2013) described the
bootstrapping approach to enrich a seed ontology
using an ensemble of different algorithms to classify
book index terms into the seed ontology. The
bootstrapping approach starts with the ontology of
Herzog (Herzog et al., 2007) as seed ontology.
Terms from the book index of Goodrich (Goodrich
& Tamassia, 2010) are extracted and classified
under the existing classes in this seed ontology by
assembling different matching algorithms and
evidence boosting algorithms using different sources.
We started with exact matching, followed by
matching using a stemmer and incorporating
subterms recognizable in the index by indentation.
For example, “vulnerabilities” in the textbook index
matches with the concept “vulnerability” after
applying the stemmer. In the next step we used
substring matching together with Wikipedia
categories to place index terms into the seed
ontology. For instance, “replay attacks” overlaps
with the Wikipedia category “Cryptographic Attacks”
under “attacks,” thus the system concludes that the
index term defines a subcategory of “attacks.”
Subsequently section headings and subsection
headings as well as linguistic heuristics (e.g., in a
noun-noun phrase the second noun often indicates a
superclass), etc. are used. For instance,
“cryptographic compression function” belongs to
“Cryptography” as a section heading and as a
security class name. Next, prefix and postfix
modifier matching is used, e.g., to determine that
“E-mail Worm” potentially belongs to “E-mail” and
“Worm” as super classes (with “Worm” more likely).
In addition, NIST’s security term definitions
were extracted and included in the Bootstrap
Ontology to define its concepts. However, a sizable
number of index terms remained unclassified.
Among 724 index terms, 263 terms were
successfully classified into the seed ontology, which
corresponds to 36.32%.
In this paper, we are approaching the problems
of including concepts and incorporating semantic
relationships between the remaining unclassified
index terms and existing concepts in the Bootstrap
Ontology. It is important to note that by including an
index term in the ontology with an IS-A link, the
term is promoted to a concept. Thus, we can talk
about relationships between pairs of concepts. While
including semantic relationships, we confront the
following problem.
Assuming that there are N concepts in an
ontology, the formula for the number of distinct
pairs of concepts is (N
2
– N)/2. For a moderately
sized ontology of 1000 concepts, that would mean
499,500 possible pairs. If a domain ontology allows
for the use of IS-A relationships and nine other
semantic relationships between pairs of concepts, an
expert would need to consider each one of them for
every pair of concepts. In reality, ten is a gross
underestimate, and the expert needs to also entertain
the possibility that no relationship at all holds.
If an expert could make a decision about each
pair in ten seconds, he would need 173 work days of
8 hours to review all pairs. Resources at this level
are rarely available, as experts are normally busy in
their field of expertise. Thus, the task of assigning
semantic relationships must be minimized as much
as possible by presenting only pairs to the expert that
are highly likely to have a useful relationship.
4 SKAT: EXPERT KNOWLEDGE
ACQUISITION TOOL
4.1 Basic Assumptions
Our work is based on the following four heuristics.
H1. If a word or a multi-word term appears in the
index of a book, then it describes an important
domain concept for the ontology of this domain.
H2. If two index terms appear close to each other
in the body of a book, then it is likely that there is a
subclass (IS-A) relationship or a semantic
relationship between them.
H3. If two index terms appear repeatedly close to
each other, then the likelihood of a relationship
between them is higher and/or the importance of the
relationship is higher than for one appearance.
AHybridApproachtoDevelopingaCyberSecurityOntology
379

H4. In a well written textbook, sentences are
semantics-infused units to a higher degree than “k-
word neighborhoods.” Thus, the basic unit of being
“close to each other” will be the sentence, as
opposed to the neighborhood. Of course, other
possible units also exist, such as paragraphs.
4.2 Formal Definition of the SKAT
Knowledge Structure
The knowledge structure that is the backbone of
SKAT will be formally introduced in this section.
Definition 1: A sentence S is a grammatically correct
English sentence terminated by a period.
Definition 2: A book image B of a book is the set of
all sentences derived from the text of a book by
removing front matter, back matter, figures, tables,
captions, page headers, page footers, footnotes and
all levels of chapter and section headers.
An index is an alphabetical list of domain terms used
in a textbook, together with the numbers of pages
where the terms appear, possibly with a multi-level
structure, synonyms, abbreviations, etc. However, an
index will be viewed as a list of terms in this section.
The use of the other elements of an index (page
numbers, etc.) will be explicated later in this paper.
Definition 3: An index I is a flat list of unique index
terms T
i
.
I = <T
1
, T
2
, … T
m
> (1)
As noted before, we assume the existence of a
Bootstrap Ontology created by hand or derived from
a seed ontology, as described in Section 3.
Definition 4: The concept list C of a Bootstrap
Ontology consists of a one-level list of all the
concepts C
i
of the ontology.
C = <C
1
, C
2
, … C
r
> (2)
Furthermore, a concept in C is represented by its
preferred English term, as opposed to an ID, unlike
in the UMLS (Humphreys & Lindberg, 1993).
Definition 5: A term-concept pair TCP
ij
is an ordered
pair that consists of a term T
i
from I (but that is not
in C) and a concept C
j
from C such that there exists
a complete sentence S in B that contains both T
i
and
C
j
. identifiable among the words of the sentence.
TCP
i
j
= <T
i
, C
j
> ∈ S & S ∈ B
(3)
Definition 6: The ranked list RL of term-concept
pairs is the list of all TCPs
RL = <<T
i
, C
j
>…<T
i
, C
k
> …
<T
m
, C
n
>…<T
m
, C
p
>>
(4)
such that if <T
i
, C
j
> appears in RL before <T
m
, C
p
>
then the frequency of T
i
within pairs occurring
within sentences is greater than or equal to the
frequency of T
m
.
Using f() as the function that returns the frequency
of terms or concepts mentioned in RL and the
symbol « to indicate “to the left in the list RL” then
this would be expressed as
<T
i
, C
j
> « <T
m
, C
n
> ↔ f(T
i
) ≥ f(T
m
) (5)
Furthermore, if the frequency of T
i
=T
m
then the
same condition holds for the C
i
. In other words, if
<T
i
, C
j
> appears before <T
i
, C
k
> then the frequency
of C
j
within pairs occurring within sentences is
greater than or equal to the frequency of C
k
. We
reemphasize that f() is based on the frequencies in B,
not on RL, because pairs in RL are unique.
<T
i
, C
j
> « <T
i
, C
k
> ↔ f(C
j
) ≥ f(C
k
) (6)
Definition 7: The projected term list PT consists of
all unique terms in the order imposed by RL.
PT = <T
1
, … T
i
, T
j
, …T
l
> (7)
such that T
i
« T
j
in RL for all i and j.
Definition 8: The projected concept list of a term T,
PC(T), consists of all unique concepts in the order
imposed by RL that appear with T in a term concept
pair.
PC(T) = <C
1
, … C
i
, C
j
, …C
l
> (8)
such that <T, C
i
> « <T, C
j
> for all i and j and all C
x
appearing in pairs <T, C
x
> are included in PC(T).
The projected term list and projected concept list
will allow us to precisely describe the information
that is presented by SKAT to a human expert.
The formalism, as explained above, makes the
optimistic assumption that there will be a TCP
available in B for every term taken from I. The
reality is that this is not the case. How can a term
from the index that appears not connected to
“anything” be linked to the ontology? We propose
the use of a transitive linkage mechanism. Thus, we
also allow term-term pairs.
Definition 9: A term-term pair TT is an ordered pair
that consists of two terms T
i
and T
j
, i.e., TT = <T
i
,
T
j
>.
DATA2014-3rdInternationalConferenceonDataManagementTechnologiesandApplications
380

Definition 10: A transitively liked term T
i
is a term
such that
<T
i
, T
j
> ∈ S
1
& S
1
∈ B and also
<T
j
, C
k
> ∈ S
2
& S
2
∈ B
(9)
As a result of discovering a transitively linked term,
a new term concept pair
<T
i
, C
k
> (10)
can be created from <T
i
, T
j
> and <T
j
, C
k
> and
appended to RL. Note that the frequency of T
i
in RL
is by definition equal to 0, because T
i
never occurs
in a sentence of the textbook together with C
k
.
Therefore it is correct to include the new term
concept pair at the end of RL. However, if several
term-concept pairs with the same transitively linked
term exist, they need to be ordered according to the
concept frequency in those pairs.
4.3 Augmented Ontologies
In this section, we will discuss the necessary
background for understanding the “importance,”
“difficulty,” and “prerequisite” mechanisms of the
SKAT tool. According to Noy and McGuiness (Noy
& McGuinness), building an ontology consists of the
following steps, whereby we adapt the description of
the third step and omit the irrelevant fourth step:
 Defining classes in the ontology
 Arranging the classes in an IS-A (subclass–
superclass) hierarchy
 Defining attributes of the classes and
relationships between the classes.
It is surprising, however, that there is no universal
agreement what an ontology actually represents.
Schulz et al. (Schulz, Cornet, & Spackman, 2011) in
a paper on SNOMED CT’s ontological commitment,
point out that it is not entirely clear what is
represented. They suggest three possible
interpretations, which we paraphrase slightly: (1)
Concepts represent real-world objects; (2) Concepts
represent content elements of Electronic Health
Records; (3) Concepts represent patient or clinical
situations. Furthermore, if one uses a post-modernist
approach to knowledge, it becomes questionable
whether any ontology can represent an objective
state of the world (Musen, 2014).
In this paper, we propose that under any
viewpoint of what ontologies represent, the ontology
framework is too limited for pedagogic purposes.
We are introducing the idea of an augmented
ontology that contains additional information related
to the use of knowledge in education, which may be
seen as a kind of meta-knowledge. We will limit
ourselves to the domain of education, leaving open
the possibility that augmented ontologies might be
helpful in other areas. To concretize the notion of an
augmented ontology we note that a “master teacher”
knows more than just the course material.
An outstanding teacher who observes that
students cannot follow an explanation is able to
analyze it for prerequisites that might be unknown to
the students. Standard ontologies do not contain
prerequisite knowledge. Secondly, an outstanding
teacher is also able to prioritize when time is running
out. The teacher knows which concepts are essential
for the success of the student, and which concepts
can be omitted if necessary. Thirdly, an outstanding
teacher knows, from years of experience, which
concepts are difficult to grasp. Thus, s/he will plan
on spending more time concerning difficult
concepts.
To reiterate, an ontology augmented for the
purpose of education needs to contain prerequisite
relationships and difficulty and importance
attributes, even if those cannot be objectively
established. These three notions are interrelated. For
example, a concept with many prerequisites is more
likely to be a difficult concept.
In order to transform a domain ontology into an
augmented ontology for pedagogic use, heuristics
are used, given below. These heuristics are not fail-
safe, as heuristics never are, and the final
determination has to be made by a domain expert.
H5. A domain concept that occurs many times in
a textbook is more important than a concept that
occurs few times, especially if the occurrences are
spread over a wide range of the book.
H6. A concept that occurs later in a textbook is
likely to have more prerequisites than a concept that
occurs earlier in the textbook.
H7. A concept that occurs earlier in a book is
simpler than a concept that occurs only later.
The above heuristics are supported by an index
that shows by its page numbers how often and where
concepts occur. This information can be extracted
algorithmically. We experimented with additional
heuristics going beyond the book index, based on
concepts appearing in section titles and concepts
appearing in the bodies of those sections, however,
the success of those heuristics was limited.
AHybridApproachtoDevelopingaCyberSecurityOntology
381

4.4 A Tool for Acquiring Knowledge
from a Textbook and from an
Expert
The SKAT (Security Knowledge Acquisition Tool)
was implemented to develop an augmented cyber-
security ontology for pedagogic use. Creating this
ontology starts by developing a Bootstrap Ontology.
Details have been published previously (Wali et al.,
2013). The SKAT tool uses information from the
index and the book image of a cyber-security
textbook to elicit the correct relationships between
pairs of a term and a concept. The book by Goodrich
and Tamassia was chosen to build the security
ontology (Goodrich & Tamassia, 2010). It contains
724 index terms.
We used a glossary of information security
terms from the National Institute of Standards and
Technology (NIST) Interagency Report (NISTIR)
("Glossary of Key Information Security Terms,"
2012) and imported the definitions into the ontology.
Based on the heuristics H1 – H4 from above,
SKAT attempts to minimize the effort that the
domain expert needs to invest into this process.
Furthermore, SKAT suggests the pedagogic
knowledge to transform the ontology into an
augmented ontology for pedagogic purposes, based
on H5 – H7.
Figure 1 shows a screen dump of the
implemented SKAT tool. The screen is subdivided
into several subwindows. The upper left subwindow
presents the projected term list (Definition 7) to the
domain expert, ordered by frequency value or in
alphabetical order, as desired. The idea is that the
user will start with the most commonly co-occurring
terms, which, by the above heuristics, are most
likely to take part in a semantic relationship of the
domain.
Because the IS-A relationship is of paramount
importance in ontologies, the domain expert is
forced to first connect the chosen term from PT with
an IS-A link to a concept in the existing Bootstrap
Ontology. The expert can either drag and drop the
term into the ontology that appears in the lower right
subwindow of the SKAT interface; or s/he can select
one of the concepts in the projected concept list
PC(T) (Definition 8) for that term in the upper right
subwindow.
Figure 1: SKAT Tool Client.
DATA2014-3rdInternationalConferenceonDataManagementTechnologiesandApplications
382

Once the term from PT has been connected by an
IS-A link to the ontology it is considered promoted
to a concept, and the expert may continue with
another term, or may assign one or more semantic
relationships to the newly created concept. For this
purpose s/he may select an already existing
relationship from the menu in the upper middle of
SKAT or add a new relationship.
The relationship menu is initialized with a list of
semantic relationships containing <IS-A, PART-OF,
RELATED-TO, KIND-OF>.
SKAT supports color-coding of the number of
relationships that connect a term from PT to the
ontology. Thus, it is easy to see which terms are still
disconnected and which terms are already singly or
multiply connected to the ontology.
SKAT supports an undo and a redo button.
Changes to the ontology are first saved into a
database table and later reviewed by our project
team before they are made permanent in the
augmented ontology. This allows us to detect and
reject any contaminations of the ontology due to
accidental misuse of the tool by a domain expert.
A look at the SKAT interface also shows that
difficulty and importance are suggested to the
domain expert, which he can accept or change. If a
domain expert is not confident about a decision s/he
may indicate this fact using appropriate buttons.
Domain experts need to log in, in order to have
accountability for the decisions made. SKAT records
the input of each domain expert together with time
stamps, in order to evaluate the time it takes the
expert for every decision. SKAT supports an
Evaluation and a Production mode.
5 RESULTS
The cyber security ontology is available as a web
application at:
http://cis.csi.cuny.edu:8080/Security_OntologyV4/.
SKAT has been made available to two domain
experts who have taught classes in network security
to evaluate the usability and utility. Their
preliminary feedback includes the following:
1. Provide additional functionality. This includes
the ability to add any concepts to the ontology,
not just those represented as terms in the
projected term list.
2. Making corrections to the ontology on the fly
should be easier. We note that this functionality
was not provided on purpose in order to keep
the ontology clean and free of inconsistencies.
However, in light of the request we will need to
reconsider this design decision.
3. Improve the speed of the implementation. At
this time SKAT is the bottleneck, not the
decision time of the domain expert. This was
surprising for the developers who assumed that
the domain experts would need a long time to
make decisions.
4. The augmented ontology items interrupt the
workflow. It would be better to change SKAT
so that the basic ontology building can be
separated from the augmentation.
5. The prerequisite augmentation item appears in
SKAT in a format that makes it
indistinguishable from semantic relationships of
the domain. This is confusing.
We are currently working on collecting sessions of
the two domain experts and comparing their
decisions about the ontology.
6 CONCLUSIONS AND FUTURE
WORK
Knowledge is too precious to ignore any sources of
it. In this paper we have demonstrated a way of
making use of the semi-structured knowledge of a
book index and of the book text this index is
referring to. However, for many aspects of ontology
building, the domain expert is the final arbiter.
While we already have an operational augmented
cyber-security ontology, we expect that after several
extended sessions of the domain experts the
resulting ontology will reflect the textbook
knowledge to a high degree and will be helpful as a
learning tool in a cyber-security class.
We are currently planning a quantitative and
empirical study of the usefulness of the SKAT tool
for cyber security domain experts. This involves the
evaluation version of SKAT automatically tracking
the number of terms classified into the Bootstrap
Ontology, the relationships they create and how long
each step takes. The security ontology resulting from
the hybrid approach, i.e., automated bootstrapping
and use of the expert tool, will be used in cyber
security education tools e.g., for multimedia course
material search, and will be available for other
useful applications.
ACKNOWLEDGEMENTS
This work is partially funded by NSF grant
DUE1241687. We gratefully acknowledge Pearson
AHybridApproachtoDevelopingaCyberSecurityOntology
383

and Addison-Wesley for making the electronic
textbooks available. We thank Mickel Mansour for
working on and refining the SKAT prototype system.
REFERENCES
An, Y. J., Geller, J., Wu, Y., & Chun, S. A. (2007).
Automatic Generation of Ontology from the Deep
Web. Proceedings Database and Expert Systems
Applications. DEXA '07, Regensburg, Germany.
Bajec, M., Eder, J., Souag, A., Salinesi, C., & Comyn-
Wattiau, I. (2012). Ontologies for Security
Requirements: A Literature Survey and Classification.
Proceedings Advanced Information Systems
Engineering Workshops.
Blanco, C., Lasheras, J., Valencia-Garcia, R., Fernandez-
Medina, E., Toval, A., & Piattini, M. (2008). A
Systematic Review and Comparison of Security
Ontologies. Proceedings Third International
Conference on Availability, Reliability and Security.
Caracciolo, C. (2006). Designing and Implementing an
Ontology for Logic and Linguistics. Literary &
Linguistic Computing, 21, 29-39.
Chun, S. A., Geller, J., & Wali, A. (2014). Developing
Cyber Security Ontology and Linked Data of Security
Knowledge Network. Proceedings Conference of the
Florida Artificial Intelligence Research Society
(Flairs-27), Pensacola, FL.
Cimiano, P., Hotho, A., & Staab, S. (2005). Learning
concept hierarchies from text corpora using formal
concept analysis. J. Artif. Int. Res., 24, 305-339.
Cleveland, D. B., & Cleveland, A. D. (2013). Introduction
to indexing and abstracting (Fourth edition. ed.).
Cornet, R., & de Keizer, N. (2008). Forty years of
SNOMED: a literature review. BMC Med Inform
Decis Mak, 8 Suppl 1, S2. doi: 1472-6947-8-S1-S2
[pii] 10.1186/1472-6947-8-S1-S2
Fellbaum, C. (1998). WordNet : an electronic lexical
database. Cambridge, Mass: MIT Press.
Fenz, S., & Ekelhart, A. (2009). Formalizing information
security knowledge. Proceedings 4th International
Symposium on Information, Computer, and
Communications Security, Sydney, Australia.
Geller, J., Chun, S. A., & An, Y. J. (2008). Toward the
Semantic Deep Web. IEEE Computer, 95-97.
Geneiatakis, D., & Lambrinoudakis, C. (2007). An
ontology description for SIP security flaws. Comput.
Commun., 30, 1367-1374.
Glossary of Key Information Security Terms. (2012) NIST
Interagency Report (pp. 222): NIST, US Department
of Commerce.
Goodrich, M. t., & Tamassia, R. (2010). Introduction to
Computer Security: Addison-Wesley.
Hearst, M. A. (1992). Automatic acquisition of hyponyms
from large text corpora. Proceedings 14th conference
on Computational linguistics, Nantes, France.
Herzog, A., Shahmeri, N., & Duma, C. (2007). An
Ontology of Information Security. International
Journal of Information Security and Privacy, 1(4), 1-
23.
Hindle, D. (1990). Noun classification from predicate-
argument structures. Proceedings 28th annual meeting
of the Association for Computational Linguistics,
Pittsburgh, Pennsylvania.
Humphreys, B. L., & Lindberg, D. A. B. (1993). The
UMLS project: making the conceptual connection
between users and the information they need. Bulletin
of the Medical Library Association, 81(2), 170.
Jain, P., Hitzler, P., Sheth, A. P., Verma, K., & Yeh, P. Z.
(2010). Ontology alignment for linked open data.
Proceedings 9th International Semantic Web
Conference, Shanghai, China.
Meersman, R., Tari, Z., Kim, A., Luo, J., & Kang, M.
(2005). Security Ontology for Annotating Resources.
Proceedings On the Move to Meaningful Internet
Systems 2005: CoopIS, DOA, and ODBASE.
Musen, M. (2014) Personal Communication.
Noy, N. F., & McGuinness, D. L. Ontology Development
101: A Guide to Creating Your First Ontology. From
http://protege.stanford.edu/publications/ontology_deve
lopment/ontology101-noy-mcguinness.html
Pattanasri, N., Jatowt, A., & Tanaka, K. (2007). Context-
aware search inside e-learning materials using
textbook ontologies. Proceedings Joint 9th Asia-
Pacific Web and 8th International Conference on web-
age information management conference on advances
in data and web management, Huang Shan, China.
Schulz, S., Cornet, R., & Spackman, K. (2011).
Consolidating SNOMED CT's ontological
commitment. Applied Ontology, 6(1), 1-11.
Vigna, G., Kruegel, C., Jonsson, E., Undercoffer, J., Joshi,
A., & J., P. (2003). Modeling Computer Attacks: An
Ontology for Intrusion Detection Recent Advances in
Intrusion Detection (Vol. 2820, pp. 113-135). Berlin:
Springer Verlag.
Wali, A., Chun, S. A., & Geller, J. (2013). A
Bootstrapping Approach for Developing Cyber
Security Ontology Using Textbook Index Terms.
Proceedings International Conference on Availability,
Reliability and Security (ARES 2013), University of
Regensburg, Germany.
Wiebke, P. (2004). A Set-Theoretical Approach for the
Induction of Inheritance Hierarchies. Electron Notes
Theor Comput Sci, 53, 1-13.
Wu, Z., Li, Z., Mitra, P., & Giles, C. L. (2013). Can Back-
of-the-Book Indexes be Automatically Created?
Proceedings CIKM, pp. 1745-1750, San Francisco,
CA.
DATA2014-3rdInternationalConferenceonDataManagementTechnologiesandApplications
384
