Semantic Annotation of UMLS using Conditional Random Fields

Shahad Kudama and Rafael Berlanga

Universitat Jaume I, Av. de Vicent Sos Baynat, s/n 12071, Castelló, Spain

Keywords: UMLS, CRF, Semantic Annotation, Biomedical Domain.

Abstract: In this work, we present a first approximation to the semantic annotation of Unified Medical Language

System (UMLS®) concept descriptions based on the extraction of relevant linguistic features and its use in

conditional random fields (CRF) to classify them at the different semantic groups provided by UMLS.

Experiments have been carried out over the whole set of concepts of UMLS (more than 1 million). The

precision scores obtained in the global system evaluation are high, between 70% and 80% approximately,

depending on the percentage of semantic information provided as input. Regarding results by semantic

group, the precision even reaches the 100% in those groups with highest representation in the selected

descriptions of UMLS.

1 INTRODUCTION

As the biomedical literature continuously increases

on the Web, a new important need is growing too:

tools and algorithms to perform effective natural

language processing to assist researchers in

organizing, curating and retrieving all the

information (Settles, 2004). To achieve this goal, the

task of identifying words and phrases in free text

that belong to certain classes of interest, which is

known as named entity recognition (NER), is a

crucial first step for many of these larger

information management goals.

In recent years, much attention has been focused

on the problem of recognizing different mentions in

biomedical abstracts to classify them into different

groups. This paper presents a framework for

recognizing occurrences of different types (anatomic

parts, chemical products, procedures, disorders,

devices, etc.) using Conditional Random Fields with

a variety of features. So, in this paper, we firstly

introduce the concept of conditional random fields

(CRF) and then, apply them to the set of sentences

of the Unified Medical Language System (UMLS) to

obtain the semantic annotation of unclassified words

in one of the predefined semantic groups. As a

result, different terms in the UMLS will be

recognized and classified in groups with a high

precision.

As in this work, we wish to predict a large

number of variables that depend on each other as

well as on other observed variables, we have chosen

CRF as it provides good results in this kind of

problems (Sutton and McCallum, 2012).

As formerly stated in (Kiryakov et al., 2004),

semantic annotation (SA) can be defined as the task

of processing text elements (data description fields,

free texts chunks, and so on) with the purpose of

assigning semantic descriptions from a knowledge

resource (KR) to the mentioned entities and, in this

way, to reduce the ambiguity present in most natural

language expressions. In our case, SA is applied to

give semantics or meaning to words and to validate

and classify them into semantic categories.

Many approximations using Conditional Random

Fields in the biomedical domain have been proposed

so far. In (McDonald and Pereira, 2005), McDonald

and Pereira use Conditional Random Fields for

tagging protein and gene mentions. Proteins and

genes pertain to just one out of the eleven semantic

groups we handle in this work. In (He and Kayaalp,

2008) and (Friedrich et al., 2006) CRF is applied to

the manually tagged GENIA corpus, which has

entities that belong to one of these semantic groups:

protein, DNA, RNA, cell lines and cell types (these

types belong to only two UMLS semantic groups).

In (Friedrich et al., 2006), different experiments

show how the selected features for CRFs directly

affect the precision scores. However, as far as we

know there is no approach in the literature handling

the high heterogeneity of semantic groups present at

UMLS, and for a very large corpus such as the

UMLS Metathesaurus® lexicon.

335

Kudama S. and Berlanga R..

Semantic Annotation of UMLS using Conditional Random Fields.

DOI: 10.5220/0005131003350341

In Proceedings of the International Conference on Knowledge Discovery and Information Retrieval (KDIR-2014), pages 335-341

ISBN: 978-989-758-048-2

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

Although UMLS mainly covers biomedical

concepts, we can also find concepts related to

procedures, devices, time, geography, people,

organizations and so on. These concepts play a

secondary role in UMLS but they are used in

describing biomedical concepts. This fact makes

UMLS a very heterogeneous source of knowledge

and, of course, it also complicates the task of

annotating and classifying the words contained in it.

Another issue that complicates the semantic analysis

is the fact that UMLS has a lot of multi-word

concepts whose components are not described in the

KR itself. Indeed, the results of this work can be

seen as a first approximation to the semantic

decomposition of the complex concepts problem.

In the next section, we present the CRF

algorithm to understand their mathematical basis. In

Section 3, we explain what UMLS is and the

modifications done over it to our experiments. In

Section 4, we present the proposed method to obtain

the seed tagged words that feed the CRF algorithm.

Then, in Section 5, a complete evaluation of the

process is made and, finally, the conclusion is

presented in the last section.

2 CONDITIONAL RANDOM

FIELDS

As biomedical NER can be thought of as a sequence

segmentation problem where each word is a token in

a sequence to be assigned a label, CRF method was

chosen as a good option to annotate the UMLS

concept descriptions. CRF is a structured prediction

method, which is essentially a combination of

classification and graphical modeling, combining the

ability of graphical models to compactly model

multivariate data with the ability of classification

methods to perform prediction using large sets of

input features (Sutton and McCallum, 2012).

CRFs are undirected statistical graphical models,

a special case of which is a linear chain that

corresponds to a conditionally trained finite-state

machine. As explained in (Settles, 2004), such

models are well suited to sequence analysis, and

CRFs in particular have been shown to be useful in

part-of-speech tagging (Lafferty, McCallum and

Pereira, 2001), shallow parsing (Sha and Pereira,

2003) and named entity recognition for newswire

data (McCallum and Li, 2003). They have also just

recently been applied to the more limited task of

finding gene and protein mentions (McDonald and

Pereira, 2005), with promising early results.

As explained in (Settles, 2004), CRFs are

probabilistic tagging models that give the

conditional probability of a possible tag sequence

given the input token sequence. Let o = {o1, o2...,

on} be a sequence of observed words of length n,

this is the input token sequence. Let S be a set of

states in a finite state machine, each corresponding

to a label l

∈

L. Let s = {s1, s2, ... sn} be the

sequence of states in S that correspond to the labels

assigned to words in the input sequence o. Linear-

chain CRFs define the conditional probability of a

state sequence given an input sequence to be:

  

exp

jj i i

i= j=

Pso=

fs,s,o,i











(1)

Where Zo is a normalization factor of all state

sequences and it is constant for the given input,

i−1

, s

, o , i) is one of m functions that describes a

feature and specifies an association between the

predicates that hold at a position and the state for

that position and λ

is a learnt feature weight for each

feature function, that specifies whether that

association should be favored or disfavored. We

assume that the ith input token is represented by a

set oi

of predicates that hold of the token or its

neighborhood in the input sequence (McDonald and

Pereira, 2005).

The learnt feature weight λ

for each feature f

should be highly positive for features that are

correlated with the target label, highly negative for

features that are anti-correlated with the label and

around zero for relatively uninformative features.

These weights are set to maximize the conditional

log likelihood of labeled sequences in a training set

D = {<o, l>(1)... <o, l>(n)}:









log

2σ

i= j=

LL D = P l 



(2)

When the training state sequences are fully

labeled and unambiguous, the objective function is

convex, thus the model is guaranteed to find the

optimal weight settings in terms of LL(D) (Settles,

2004). Once these settings are found, the most

probable tag sequence for a given input unlabeled

sequence o can be obtained applying a Viterbi-style

algorithm to the maximization (Lafferty, McCallum

and Pereira, 2001).

Typical features considered in the approaches of

the literature are mainly divided in two groups: the

orthographic features (capitalization, affixes,

alphanumerical text, etc.) and semantic features

(using, for example, external lexicons) (Settles,

2004).

KDIR2014-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

336

It is important to point that our goal is different from

those of the literature using CRFs: we aim at

annotating at word-level complex entries of a

biomedical KR, whereas these approaches aim at

predicting the semantic group of a text chunk.

Indeed the existing Gold Standard used in these

approaches cannot be used for evaluating the word-

level annotation problem, as they do not provide the

semantic groups of the words belonging to each

Gold Standard sample.

3 UMLS

In this work, we use the whole lexicon of UMLS

MetaThesaurus® for building the word sequences

dataset. UMLS Metathesaurus (UMLS from now on)

is a compendium of more than 100 controlled

vocabularies in the biomedical sciences. It provides

a mapping structure among these vocabularies and

thus allows one to translate among the various

terminology systems. UMLS further provides

facilities for natural language processing, so it is

intended to be mainly used by developers of systems

in biomedical informatics. As UMLS also provides

relationships between concepts, it can be also

regarded as a big “ontology” that enables physicians

to classify signs, symptoms, and diseases using

medical concepts.

In this work, we deal with the 2012AB version

of UMLS. The latest set of UMLS semantic groups

(SGRs) and UMLS semantic types (STYs) have

been retrieved as well. From the analysis of STYs,

SGRs and vocabularies included in Biotea (Garcia,

McLaughlin and Garcia, 2013), we defined a set of

customized semantic groups.

UMLS concepts are attributed to the STYs; these

are then categorized into SGRs. Currently UMLS

makes use of 15 SGRs that are assigned to 99.5% of

the UMLS concepts (Castro, Berlanga and Garcia,

2014). The SGRs have been defined for

organizational reasons in order to better manage the

conceptual complexity of STYs (McCray, Burgun

and Bodenreider, 2001). The proposed semantic

groups deliver a finer grained grouping in

comparison to those from UMLS. For instance,

proteins or drugs have been separated as specific

groups that are different from more generic

chemicals. These specific groups have been defined

by interpreting the descriptions for the SGRs and the

STYs according to the UMLS Semantic Network.

The SGRs have been modified as follows. We

split the UMLS CHEMicals group into GeNe &

ProTeins (GNPT) for types closely related to either

genes or proteins, DRUG for drugs, and CHEM for

the rest of the chemicals. Our GNPT group also

includes types from the UMLS GENEs group. From

LIVB group (living organisms) we extracted PEOP

group (people) and from CONC group (concepts) we

extracted SPAT group (spatial concepts).

A first step before selecting sequence examples

for CRF consists of identifying those concepts that

are described with a single word. These words will

serve as seed input as they provide semantic

information to the learning process. However, there

are words that are assigned to more than one

semantic group, that is, they are ambiguous. These

words cannot be used as input in CRF as it cannot

handle ambiguous examples. To identify the single-

word concepts, we process the MRCONSO file from

UMLS.

4 METHODOLOGY

In order to illustrate the goal of this work, let us

consider the UMLS Metathesaurus concept entry

“abdominal computed tomography adrenal gland

calcification” for an unambiguous concept tagged as

DISO (disorder). Our goal is to annotate each word

of the entry with one of our predefined semantic

groups. In this case, we would have as a result:

abdominal ANAT, computed INDC, tomography

PROC, adrenal INDC, gland ANAT and

calcification DISO.

In order to achieve this goal, firstly, tagging part

of the UMLS words was necessary in order to

generate a training file for the CRF algorithm.

The first approximation in tagging UMLS single

words consisted in taking the words that only had

one associated semantic group in the UMLS; words

that are unambiguous according to the KR. For

example, if the concept of one word stomach is

tagged as ANAT, anatomical part, then we can

assume that the word stomach belongs to the

semantic group ANAT.

In the second approximation, a simple process of

statistical inference had been added: for each word

that acts as “head” of a multi-word concept, the

semantic group of the concept is associated to it.

After observing all the UMLS, each word has been

associated to its most probable semantic group, as

long as it goes beyond a certain threshold (>0.7 in

the experiments). This threshold has been set

manually observing the results to choose a point

where all words are properly tagged.

Once the words explained before were annotated,

the next step was to create the two necessary files

SemanticAnnotationofUMLSusingConditionalRandomFields

337

Table 1: Semantic groups, percentage of appearance in

training file and description of each one.

Semantic

group

% train Description

LIVB 19.49% Alga, virus, human,

animal, organism, etc.

ANAT 17.86% Body location, cell

component, tissue,

embryonic structure, etc.

DISO 7.90% Anatomical abnormality,

disease or syndrome,

mental or behavioral

dysfunction, etc.

INDC 7.77% Qualitative or

quantitative concept,

classification, idea, etc.

SPAT 7.45% Spatial concept

OBSV 7.45% Finding, sign or

symptom, clinical

attribute, etc.

PROC

4.58% Laboratory or test result,

health care activity,

research activity, etc.

GNPT 3.16% Enzyme, receptor,

molecular or nucleotide

sequence, gene or

genome, etc.

CHEM 2.52% Immunologic factor,

vitamin, biologically

active substance, etc.

DEVI 1.46% Medical, research, or

drug delivery device

PHYS 1.33% Physiological, cell,

genetic or organism

function

for CRF: the training and testing files. The training

file should include as much information as possible

in order to get a good learning model. All the UMLS

entries with all words unambiguously annotated

were used to create the training file. The rest of

UMLS entries constituted the test file. As a result,

the training file contains 183.275 different words,

and the test file has 529.117 different words.

The semantic groups that are being managed are

the most frequent in UMLS and are presented in

Table 1, where the percentage of the occurrences in

the training file and a brief description of each one

are provided.

Almost half of the semantic groups are not directly

related to biomedicine field. Words pertaining to one

of the three special groups have been removed,

namely: stop words (a list of English stop words like

“of”, “the”, “in”, “and”, etc.), numbers (a word

formed completely by digits, e.g. 21, 000, 9.2, 2'45,

etc.) and letters (a text with one letter, as “a”, “Z”,

etc.). Non-alphanumerical characters have been also

automatically removed.

As the CRF algorithm needs features of the

words in order to predict the category of each one of

them, we discussed and decided which features are

the most interesting according to the set of words

present in the UMLS. The features should be able to

discriminate the entities correctly, even on new,

unseen examples (Friedrich et al., 2006):

 POS (part-of-speech) tagging. It is the process

of marking up a word in a text as corresponding

to a particular part of speech, based on both its

definition, as well as its context, for example,

relationship with adjacent and related words in a

sentence or a paragraph. POS tagging is used in

the identification of words as nouns, verbs,

adjectives, adverbs, etc. OpenNLP has been

used to obtain POS tag annotations (OpenNLP,

2010).

 Chunking label. A common tagging format,

IOB format, for tagging tokens in a chunking

task in computational linguistics, indicating the

beginning and ending of a chunk. OpenNLP has

been used to obtain the chunking labels

(OpenNLP, 2010).

 Prefix. A prefix is an affix placed before the

stem of a word. A list of English prefixes

related to the biomedicine field has been used to

detect prefixes in words, for example carcino-,

gastro-, immuno-, etc. We assume that words

sharing the same prefix are likely to bring

similar semantics.

 Suffix. A suffix is an affix placed after the stem

of a word. A list of English suffixes related to

the biomedicine field has been used to detect

suffixes in words, for example -kinesis, -lepsia,

-malacia, -derma, etc. Again, words sharing the

same suffix are likely to bring similar

semantics.

 Number. This feature can take two values:

HASNUMBER or NONUMBER, the first one

is set when the word contains a digit and the

second one, if not. Having or not digits in words

gives clues about the category of the word,

which are likely to be CHEM or GNPT, for

example.

KDIR2014-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

338

 Semantic type. One of the subgroups of the

groups that we have presented, which

correspond to the STYs of UMLS. If the first

method had not been able to select one, the

value of this feature will be NOTYPE.

 Semantic group. One of the groups that we

have presented. If the first method had not been

able to select one, the value of this feature will

be NOGROUP.

5 EVALUATION

We have used CRFsuite (Okazaki, 2011), an

implementation of Conditional Random Fields

(Lafferty, McCallum and Pereira, 2001) for labeling

sequential data. The software provides fast training

and tagging, simple data format for training and

tagging, performance evaluation on training, etc.

Once configured both training and test files with

the necessary format for CRFsuite and all the

features explained before, the steps for the

evaluation were the following:

1. Creating manually a Gold Standard with

the most frequent words of the test file with

unknown semantic group. Words like

“protein”, “branch”, “oral”, “lower”,

“cervical”, “receptor”, and so on, are used

in the GS for the evaluation of the system.

The GS includes 300 terms manually

annotated.

2. Training the system and generating the

probabilistic model. The system spends

almost 10 hours training.

3. Tagging the test file using the model

created before. It is very important to

remark that the test file and the train file are

disjoint, as they do not share UMLS entries,

so the test is being done over contexts that

the system had not seen before.

4. Comparing the CRF annotations with the

GS annotations.

In Table 2, the percentages and number of

examples of the most representative semantic groups

in the GS are presented. The representation of each

semantic group follows a similar distribution of the

semantic groups in UMLS.

Once the file test is created with all the concepts

that do not have all the terms annotated, in Table 3,

the percentages of each big group in the file test are

presented: special groups (stop words, numbers and

letters), tagged concepts and no tagged concepts.

Table 2: Percentages of each group in the G.S.

Semantic

group

% in G.S. Number of

examples

GNPT 26.66% 80

CHEM 26.33% 79

ANAT 15.66% 47

INDC 14.00% 42

LIVB 12.33% 37

SPAT 8.33% 25

DEVI 6.33% 19

DISO 3.66% 11

OBSV 3.33% 10

PHYS 3.33% 10

PROC 3.00% 9

Table 3: Statistics in test file.

Group Number of

words

% in test file

Special groups

(STOP,

NUMBER and

LETTER)

838.435 13.23%

Tagged 2.816.149 44.45%

No tagged 2.680.631 42.31%

Table 4: Precision for each coverage percentage.

% coverage (over the

44.45% of the test file)

% precision

0% 68.98%

10% 69.16%

20% 70.64%

30% 70.90%

40% 72.64%

50% 74.04%

60% 75.08%

70% 76.13%

80% 76.48%

90% 77.52%

100% 80%

SemanticAnnotationofUMLSusingConditionalRandomFields

339

Having the tags of the 44.45% of the test file, we

decided to study the behavior of the CRF depending

on the quantity of annotated words that it is being

provided to it. So finally, 11 executions were made

including different percentages of the tagged words

(44.45% of the test file). As shown in Table 4,

precision increases as the algorithm receives more

information of tagged words, starting in 68.98%,

when no semantic information is provided, to 80%,

when the 44.45% of the test file is tagged.

As words tagged in the test file are randomly

selected, we performed 5 different executions for

each coverage point and calculate the average

precision of these executions (see Tables 4 and 5).

Really interesting results have been found in the

annotated terms that can show us the capability of

the learnt model:

 Words as “second”, “cervical”, “middle”,

“forth”, “central, “external” and “nasal” are

tagged as SPAT (anatomic spatial concept).

 “Body”, “fasciculus”, radius”, “thyroid” are

tagged as ANAT (anatomical concept).

 “eiphosoma”, “petiolaris” and “reptans” are

associated to LIVB (living organisms).

 Words like “methylenetetrahydrofolate” and

“adenosyltransferase” are in CHEM (chemical

product).

 “neurolysis”, “peristalsis” and “venereal” are

tagged as DISO (disorder).

All plural words were wrongly tagged. We

noticed that a word presented in singular was tagged

with the expected semantic group, but in plural it

was not. Probably, this is happening because plural

words do not appear frequently in the training file,

so the CRF method cannot make a good model to

predict their semantic group. We are working to

handle this problem with different strategies in order

to raise the precision of the system: adding a feature

with the singular form of the word, preprocess the

test file to change all plurals into singulars, etc. If

these approaches do not solve the problem, we will

add a new feature with the root of the word using

more advanced stemming approaches.

Table 5 presents the precision scores by

semantic group and coverage points. For each group

in the rows and for each percentage of coverage

inthe execution, the precision obtained is presented.

As we can see in Tables 4 and 5, the system is

able to recognize different terms and assign them to

a correct group among the semantic groups we are

dealing with high precision.

As expected, the worst results are obtained in

groups with little representation in the training file.

As they almost do not appear, the system cannot

make a good model to predict them. Conversely,

well represented groups like DEVI, OBSV, LIVB

and SPAT, obtain very good results: 100%, 100%,

97.29% and 92%.

6 CONCLUSIONS

We have presented a framework to use CRFs for

tagging concepts in UMLS and then classifying

them into very different and heterogeneous

predefined categories. The obtained results in the

evaluation are encouraging: the global precision

goes from 68.98% to 80% depending on the

percentage of information included in the test file

(from 0% to 100% of tagged words, which are the

44.45% of the test file). The precision of each

semantic group depends on its representation in the

training file. As many times the group appears in the

train file, its results improve, achieving the 100% of

precision in groups like OBSV and DEVI.

We think that results are promising but no

complete comparison with other methods has been

made, so in future work, this kind of study will be

made using, for example, Inductive Logic

Programming or Statistical Relational Learning.

Furthermore, there are many options to try to

improve the results. Another KR, like Babelnet,

could be used to the semantic groups poorly defined

in UMLS. Semantically decomposing and studying

the coherence of the semantic annotations in

concepts semantically related in the KR would be

another interesting task to do.

Regarding the features, our future work will be

concentrated on making a bigger set of features and

automatically studying the results depending on the

features selected. It would give us information about

which features better discriminate between the

semantic groups in the UMLS.

Once we have all the words annotated with their

semantic groups in the UMLS concepts, we will be

able to present the next step: try to infer the semantic

group of the whole concept. We are working on a

Bayesian model that uses the co-occurrence

probabilities of each pair of semantic groups and we

are expecting to obtain interesting results soon.

ACKNOWLEDGEMENTS

This work has been partially funded by the

KDIR2014-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

340

Table 5: Precision by semantic group at different coverage points.

0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100%

LIVB

94.44% 94.44% 94.59% 94.59% 95.13% 97.29% 97.29% 97.29% 97.29% 97.29% 97.29%

ANAT

63.82% 65.95% 70.21% 71.27% 72.34% 72.34% 72.34% 74.46% 74.46% 74.46% 74.46%

DISO

36.36% 38.63% 45.45% 45.45% 54.54% 63.63% 63.63% 63.63% 63.63% 72.72% 72.72%

INDC

64.28% 64.28% 64.28% 66.66% 66.66% 69.04% 69.04% 69.04% 69.04% 69.04% 69.04%

SPAT

84% 84% 88% 88% 92% 92% 92% 92% 92% 92% 92%

OBSV

20% 20% 20% 20% 40% 40% 50% 60% 80% 80% 100%

PROC

22.22% 22.22% 22.22% 44.44% 33.33% 33.33% 33.33% 44.44% 44.44% 55.55% 66.66%

GNPT

83.75% 82.5% 83.75% 85% 85% 86.25% 86.25% 86.25% 87.5% 90% 88.75%

CHEM

85.89% 84.21% 86.07% 87.34% 87.34% 88.60% 88.60% 88.60% 89.87% 92.40% 91.13%

DEVI

50% 50% 50% 50% 50% 50% 50% 100% 100% 100% 100%

PHYS

66.66% 66.66% 66.66% 66.66% 66.66% 66.66% 66.66% 66.66% 66.66% 66.66% 66.66%

“Ministerio de Economía y Competitividad” with

contract number TIN2011-24147, and the Fundació

Caixa Castelló project P1-1B2010-49. Shahad

Kudama has been supported by Universitat Jaume I

predoctoral grant PREDOC/2011/61.

REFERENCES

Burr Settles. Biomedical Named Entity Recognition Using

Conditional Random Fields and Rich Feature Sets.

Proceedings of the COLING 2004 International Joint

Workshop on Natural Language Processing in

Biomedicine and its Applications (NLPBA). Geneva,

Switzerland. 2004. Pages 104-107.

Atanas Kiryakov, Borislav Popov, Ivan Terziev, Dimitar

Manov, and Damyan Ognyanoff. Semantic annotation,

indexing, and retrieval. Web Semantics: Science,

Services and Agents on the World Wide Web 2 (2004).

Pages 49-79.

Ryan McDonald and Fernando Pereira. Identifying gene

and protein mentions in text using conditional random

fields. BMC Bioinformatics 2005,6:S6.

Ying He and Mehmet Kayaalp. Biological Entity

Recognition with Conditional Random Fields. AMIA

Annual Symposium Proceedings. 2008: 293–297.

Christoph M. Friedrich, Thomas Revillion, Martin

Hofmann and Juliane Fluck. Biomedical and Chemical

Named Entity Recognition with Conditional Random

Fields: The Advantage of Dictionary Features.

Proceedings of the International Symposium of

Semantic Mining in Biomedicine (SMBM). 2006.

Pages 85-89.

John Lafferty, Andrew McCallum, and Fernando Pereira.

Conditional random fields: Probabilistic models for

segmenting and labeling sequence data. In

Proceedings of the 18th International Conference on

Machine Learning. 2001, pages 282-289.

Fei Sha and Fernando Pereira. Shallow parsing with

conditional random fields. In Proceedings of the

Human Language Technology and North American

Association for Computational Linguistics

Conference. 2003. Pages 134-141.

Andrew McCallum and Wei Li. Early results for named

entity recognition with conditional random fields,

feature induction and web-enhanced lexicons. In

Proceedings of the Conference on Natural Language

Learning. 2003. Pages 188–191.

Leyla Jael Garcia Castro, Rafael Berlanga and Alexander

Garcia. Biolinks, a semantic similarity score based on

UMLS groups for identifying relevant related full-text

articles in PubMed Central. To appear.

Garcia Castro, L.J., McLaughlin, C. and Garcia, A. Biotea:

RDFizing PubMed Central in Support for the Paper as

an Interface to the Web of Data. Biomedical

semantics, 2003. 15;4 Suppl 1:S5.

McCray, A.T., Burgun, A. and Bodenreider, O.

Aggregating UMLS semantic types for reducing

conceptual complexity, Proceedings of Medinfo, 2001.

10, 216-220.

Charles Sutton and Andrew McCallum. An introduction to

Conditional Random Fields, Foundations and Trends

in Machine Learning, 4 2012.

NaoakiOkazaki. CRFSsuite Software 2011.

http://www.chokkan.org/software/crfsuite/ (18 April

2014)

Apache OpenNLP 2010. http://opennlp.apache.org/ (18

June 2014)

SemanticAnnotationofUMLSusingConditionalRandomFields

341
