substrate slopes, but it was reasonable to assume that
the guidance relied on extra-cellular cues, which
triggered some reorganization mechanisms in the
cytoskeleton. The actin cytoskeleton in cells
(fibroblasts, endothelia, and macrophages) reacting
to topography is organized in a way which we
believe to be appropriate for movement. Some
proteins, like semaphorines and ephrins, can inhibit
axons to grow the wrong way while other proteins
can attract axons to grow on the right way (Cook,
Tannahill et al. 1998). Compared with flat surface,
growth cones of the growing neurites on the slope
would get larger mechanical stress which can affect
the strength of the integrin–cytoskeleton links and
the integrin receptor distribution and conformation,
thus activating intracellular pathways active in cell
development and behaviour.
In future, we aim to make more experiments to
study the mechanism of slope modulation. For
example, we will put DRG explants on different
slope substrates to measure the growth rate of
neurites and observe the cytoskeleton morphology.
Even we will use quantitative real-time polymerase
chain reaction (qRT-PCR) to measure the magnitude
of changes in the expression of gene compliment
which regulates the neuron cell growth on different
topologies of substrates. Moreover, neurons are
usually not very likely to be the first cells to
encounter an implant as any topography may be
covered and obscured by glia cells (Franze 2013).
Therefore, we also need to study how slope affect
the glial cells.
ACKNOWLEDGEMENTS
This study was supported by the Natural Science
Foundation of China (grant number 61233015), the
National Basic Research Program of China (973
Program) (grant number SQ2012CB037202) and in
part by independent innovation fund of Huazhong
University of Science and Technology, Wuhan, P. R.
China (grant number 2013YGYL004). The authors
would like to thank Dr. Jun Ma and Dr. Jianfeng Xu
for their instruction in the experiments.
REFERENCES
Al-Majed, A. A., C. M. Neumann, et al. (2000). "Brief
electrical stimulation promotes the speed and accuracy
of motor axonal regeneration." The Journal of
neuroscience 20(7): 2602-2608.
Alaerts, J., V. De Cupere, et al. (2001). "Surface
characterization of poly (methyl methacrylate)
microgrooved for contact guidance of mammalian
cells." Biomaterials 22(12): 1635-1642.
Chaban, V., E. Mayer, et al. (2003). "Estradiol inhibits
ATP-induced intracellular calcium concentration
increase in dorsal root ganglia neurons." Neuroscience
118(4): 941-948.
Clark, P., P. Connolly, et al. (1990). "Topographical
control of cell behaviour: II. Multiple grooved
substrata." Development 108(4): 635-644.
Cook, G., D. Tannahill, et al. (1998). "Axon guidance to
and from choice points." Current opinion in
neurobiology 8(1): 64-72.
Curtis, A. (2004). "Small is beautiful but smaller is the
aim: review of a life of research." Eur Cell Mater 8:
27-36.
Dalby, M. J., M. O. Riehle, et al. (2003). "Nucleus
alignment and cell signaling in fibroblasts: response to
a micro-grooved topography." Experimental cell
research 284(2): 272-280.
Franze, K. (2013). "The mechanical control of nervous
system development." Development 140(15): 3069-
3077.
Fricke, R., P. D. Zentis, et al. (2011). "Axon guidance of
rat cortical neurons by microcontact printed
gradients." Biomaterials 32(8): 2070-2076.
Goldner, J. S., J. M. Bruder, et al. (2006). "Neurite
bridging across micropatterned grooves." Biomaterials
27(3): 460-472.
Harrison, R. G. (1911). "On the stereotropism of
embryonic cells." Science 34: 279-281.
Horner, P. J. and F. H. Gage (2000). "Regenerating the
damaged central nervous system." Nature 407(6807):
963-970.
Johansson, F., P. Carlberg, et al. (2006). "Axonal
outgrowth on nano-imprinted patterns." Biomaterials
27(8): 1251-1258.
Oakley, C. and D. Brunette (1993). "The sequence of
alignment of microtubules, focal contacts and actin
filaments in fibroblasts spreading on smooth and
grooved titanium substrata." Journal of Cell Science
106(1): 343-354.
Rajnicek, A., S. Britland, et al. (1997). "Contact guidance
of CNS neurites on grooved quartz: influence of
groove dimensions, neuronal age and cell type."
Journal of Cell Science 110(23): 2905-2913.
Smith, D. H., J. A. Wolf, et al. (2001). "A new strategy to
produce sustained growth of central nervous system
axons: continuous mechanical tension." Tissue
engineering 7(2): 131-139.
Stepien, E., J. Stanisz, et al. (1999). "Contact guidance of
chick embryo neurons on single scratches in glass and
on underlying aligned human skin fibroblasts." Cell
biology international 23: 105-116.
Vincent, A. M. and E. L. Feldman (2002). "Control of cell
survival by IGF signaling pathways." Growth hormone
& IGF research 12(4): 193-197.
Wilkinson, C., M. Riehle, et al. (2002). "The use of
materials patterned on a nano-and micro-metric scale
in cellular engineering." Materials Science and
Engineering: C 19(1): 263-269.
