Challenges in Identification in Future Computer Networks

Libor Polčák

Faculty of Information Technology, Brno University of Technology, Božetěchova 2, 612 66 Brno, Czech Republic

1 OUTLINE OF OBJECTIVES

The knowledge of user identity is a necessity for

many network-related tasks, e.g. network

management (Grégr et al., 2011), security incident

backtracking (Scarfone et al., 2008), authentication

and authorisation (Huang et al., 2012; Sanguanpong

and KohtArsa, 2013), lawful interception

(ATIS/TIA, 2006; ETSI, 2001), and quality of

service (Laiping Zhao et al., 2012). Traditionally,

an IPv4 address was a suitable identifier for the

identification. With the advent of new technologies,

such as IPv6 or carrier grade network address

translation (CGN/NAT444), the methods for user

identification need to be revised (Polčák et al.,

2013a).

In IPv4, a device usually leases an IPv4 address

from a DHCP server in the custody of the network

operator. Then, the device applies this unique IPv4

address for all its communication until the lease

expires. In contrast, IPv6 introduced several new

mechanisms for address assignments. For example,

Stateless Address Autoconfiguration (SLAAC)

(Thomson et al., 2007) allows an end device to

generate as many IPv6 addresses as it needs, e.g. for

privacy concerns (Groat et al., 2010; Narten et al.,

2007), as long as the addresses are not already used

by another device in the network. Note that the

addresses are not handled centrally but generated by

end devices.

Some companies prefer to prioritize specific

traffic, e.g. important video calls of a manager with

high bandwidth demand. Lately, companies allow

their employees to bring their own equipment to

work (bring your own device policy). These devices

are not registered in the network, consequently,

their identity is unknown. Hence, a device of a

manager is indistinguishable from other devices;

and the traffic of such an equipment cannot be

treated according to special rules easily.

This Ph.D. research focuses on user

identification in future computer networks. The aim

is to study the information available in different

parts of the network (e.g. local area networks —

LANs, backbone networks, content provider

networks etc.). The ultimate goal is to propose

mechanisms that identify the user even though the

user changes his or her IP address. Although the

primary aim is at identification of traffic of a

specific user, identification of data of a specific

computer is also considered since it might ease the

primary goal of user identification. In addition, the

research takes into account latest network

technologies: CGN/NAT444, IPv6 and software

defined networking (SDN) are considered during

the research.

The research is divided into the following areas:

• A study and improvements of existing methods

for identification or proposal of new methods.

In addition, the research should evaluate

advantages and disadvantages of the methods.

The aim is at methods that does not require

cooperation from the end user and are

transparent for him or her. These methods are

applicable to all of our use cases.

• Understanding of relations between different

identities detected on different layers of the

TCP/IP architecture. The Ph.D. research should

distinguish between identities of computers and

persons.

• Proposal of mechanisms to link identities of the

same person or a computer.

• Proof-of-concept: results of the Ph.D. research

are expected to be used as a part of the Lawful

Interception System developed at the Brno

University of Technology as a part of the

research focused on criminality mitigation on

the new generation Internet (FIT BUT, 2014).

Additionally, we plan to develop an SDN

application that controls an SDN network and

prioritize traffic according to the identity of the

communicating parties.

This section outlined the objectives of the Ph.D.

research. Section 2 introduces the terminology and

Pol

cák L..

Challenges in Identiﬁcation in Future Computer Networks.

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

explains the research problem in detail. Section 3

overviews the work related to this Ph.D. research.

The methodology to achieve the goals is proposed

in Section 4. Section 5 elaborates on the expected

outcome of the Ph.D. research and portrays the

validation of the research. Current stage of the

research is discussed in Section 6 and the

contribution is summarized in Section 7.

2 RESEARCH PROBLEM

In conformance with (Pfitzmann and Hansen,

2010), we consider an identity to be a set of

attribute values that uniquely identify a subject, i.e.

a person or a computer.

A single identity may comprise (Pfitzmann and

Hansen, 2010) of different partial identities of the

same person or a computer; each of the partial

identity represent the subject in a specific context or

a role. All partial identities co-exist and can

potentially be linked (correlated). If two identities

are linkable, their attributes can be merged as all

belong to the same subject. Consider a user owning

two e-mail addresses — x any y. Both x and y are

partial identities of the subject.

In the network environment, often, one of the

attributes is unique for a specific identity. Such

attribute is called the identifier — usually it exists

in a form of a name or a bit string (Pfitzmann and

Hansen, 2010). Each identifier corresponds to a

specific (partial) identity. For instance, the identity

of an e-mail user owning a mail box of an address x

can be represented directly by the identifier x. This

Ph.D. research should focus on the identifiers and

how common they are.

Note that for privacy reason, we are not

interested in gathering extensive amount of

attributes and their values during this Ph.D.

research. For quality of service, we are primarily

interested in the network identifiers so that it is

possible to distinguish network traffic of different

users. The lawful interception use case has to follow

strict legal rules that prevents pervasive monitoring

of all users. Hence, the goal is to learn the

identifiers, link the partial identities represented by

each of them and identify the traffic of the

discovered subject.

The problem of user or computer identity

detection is useful in several domains, however, its

complexity slightly differs. The basic difference is

the availability of specific attributes in a specific

case: some of the sources of attributes are not

always available, or, some sources cannot be

utilized for a reason, e.g. they are not reliable

enough for that case. For this research, we restricted

the sources of attributes to those that are transparent

for the user to be identified. Although this

restriction limits the methods that are available, it is

a necessary restriction because we are interested in

methods that are compatible with lawful

interception (LI) (ETSI, 2001). However, the

considered method to link partial identities is

general and it does not restrict any method that can

represent an identity by an identifier. Hence the

method is compatible with various techniques that

discover partial identities, including those that are

not transparent to the end user.

The research has to cover several scenarios for

the identification. The goal is to identify the traffic

of end users in the network. We aim to quantify the

usability of the methods that have been already

proposed, on their improvements, and on

development of new methods. Based on the use

cases of an application aware network and the

deployment of a lawful interception system (LIS),

we consider identification in LANs and remote

networks. In addition, we consider modern

technologies, such as IPv6 and software defined

networking.

To achieve this goal of traffic identification, the

research needs to study the attributes, identities,

relations between identities, and linkability of

partial identities. The ultimate goal is to present

methods suitable for various kinds of modern and

future networks, including:

• Network address translation (NAT), carrier

grade NAT (CGN) or multi-layer NAT

(NAT444): As depicted in Figure 1, IPv4

addresses are shared between several

households while one computer can

communicate through different translators that

use different IPv4 addresses.

Figure 1: Multi-layered translation of IPv4 addresses.

ICETE2014-DoctoralConsortium

• IPv6 networks: Short-lived temporary IPv6

addresses (Narten et al., 2007) can be generated

by any computer in IPv6 network at will.

Moreover, a computer can use as many IPv6

addresses on each interface as it can handle.

Furthermore, recent versions of Windows, Mac

OS X, iOS, and several Linux distributions

have temporary addresses enabled by default.

Usually, a new temporary address is generated

at least once per day. However, when a user

authenticates with a different access point in a

Wi-Fi network or reboots his or her computer, it

regenerates its temporary addresses. Figure 2

portrays default behaviour of a Windows

computer.

Figure 2: Multiple IPv6 addresses were used during a

week by a single Windows-based computer

simultaneously. The computer was not shut down during

that week. While it used only one IPv4 address, it

generated new IPv6 address every day.

Hence, IPv6 hosts use several identifiers for the

same interface. Consequently, there needs to be

a mechanism to link all addresses of one

computer together.

• Dual stack networks: Usually, even in

IPv6enabled networks, IPv4 is still present (as

also illustrated in Figure 2). Recent operating

systems and web browsers employ Happy

eyeballs (HE) (Wing and Yourtchenko, 2012)

to dynamically select the protocol with better

performance (sometimes with a slight

preference of IPv6). As a result, one session

(e.g. web session) can be split between both

protocols.

In addition, even without HE, dual-stacked

machines communicate with IPv4-only Internet

using IPv4 while IPv6-enabled servers are

accessed via IPv6. As web pages often contain

external content and DNS is accessed

separately, one session may be split between

IPv4 and IPv6 even without HE.

3 STATE OF THE ART

This Section outlines the related work to this Ph.D.

research. First, the focus is on the terminology and

other approaches to identification. Then, the focus

shifts on detection methods that are not detectable

by an end user of a network. Several methods

suitable for passive user identity detection already

emerged: the characteristics of a subject (attributes)

are enclosed in the data that the subject exchanges

in the network or in the metadata of the

communication.

3.1 Identity Management Systems

FIDIS was an European project that focused on

identification. They considered (Meints and Gasson,

2009) three types of identity management systems

(IMSes):

1. IMSes for account management, authentic-

cation, authorisation, and accounting (AAA).

2. IMSes for profiling of user data by an

organisation, for marketing or providing

personalised services.

3. IMSes for pseudonym management. These

systems are controlled by the end users.

Indeed, this Ph.D. research concerns IMSes. Our

IMS can be characterised as a mix of type 1 and 2.

The aim of our IMS is to link different identities

from computer networks. The ultimate goal is to

provide personalised services for all traffic of a

specific user or a group of users. As the sources of

identities are not limited, it is possible to use any

Type 1 IMS as a source of identities for our IMS.

Therefore, our IMS can be used as Type 1 IMS and

provide authorisation or accounting for related

identities. Such scheme can be deployed on dual

stacked networks (Sanguanpong and Koht-Arsa,

2013) where many network-layer addresses are used

at the same time.

There is an extensive research in identity area.

For example, (Jøsang et al., 2005) list relations

between identifiers, identities and entities. They

explain that one entity has several (partial)

identities, each of them can be identified by several

identifiers. As they focused on a type 3 IMS, they

did not pursued the idea of linking identities as this

research does. Compared to their research, this

research aims to reveal different identities of the

same person.

Compared to definitions of (Clauß and

Köhntopp, 2001), we are not focused on gathering

huge amount of data. Our goal is to identify a

ChallengesinIdentificationinFutureComputerNetworks

person and its network traffic. Their notion of

transaction, situation, and person pseudonyms

might be proven useful during the formal

specification of mechanisms to link identities.

3.2 Identity Detection

The metadata-based approach to reveal identities

can be used for both local and remote monitoring.

One of the possibilities are behaviour models

(Banse et al., 2012; Herrmann et al., 2012;

Kumpošt, 2008). The models are typically

constructed of metadata of past communication, e.g.

accessed IP addresses, amount of exchanged data,

time in a day of communications with specific host,

etc. The disadvantage of the models is the need to

track the user for a long time, e.g. one day (Banse et

al., 2012), and often the models have difficulties

with users regularly changing their IP addresses

(Herrmann et al., 2012). In contrast, common

operating systems use temporary IPv6 addresses by

default; a typical preferred life time of a single IPv6

address is one day.

HTTP headers and information learnt from

JavaScript were originally studied for active

identification (Eckersley, 2010). However, a stable

set of HTTP headers (such as a user agent string and

similar headers) is present in all HTTP requests of a

single browser instance. Consequently, the set can

be treated as additional attributes used for passive

identification. The usability of the method varies

with the amount of information that a browser sends

to the Internet and it needs to be further

investigated. Since browser version is one of the

attributes monitored by the method, the fingerprint

of a browser changes with every update.

Kohno et al. (Kohno et al., 2005) proposed

identification of computers by measuring their clock

skew computed from ICMP and TCP timestamps.

Later, new sources of time information were

proposed (Huang et al., 2012; Murdoch, 2006;

Zander and Murdoch, 2008; Lanze et al., 2012). The

advantage of clock-skew-based identification lays

in its speed (Huang et al., 2012; Sharma et al.,

2012) and the method also works for mobile devices

(Sharma et al., 2012). The possible sources have

some limitations:

• Windows clients does not send TCP

timestamps (Kohno et al., 2005).

• ICMP timestamps are not supported by Apple

(Polčák and Franková, 2014) and this source

is not available in IPv6.

• Timestamps from application protocols have

either low resolution (Zander and Murdoch,

2008) or are not present if not requested by a

server (Huang et al., 2012).

However, the advantage of the clock-skew-

based identification is that the observed clock skew

does not change with an update of the software,

after a change of a user behaviour, after a relocation

to another network, or after a switch between wired

and wireless network.

Several attempts have been made to study IPv6

addresses and their assignments. Static interface IDs

(lower 64-bits of an IPv6 address) were proposed

(Groat et al., 2010; Dunlop et al., 2011) as a mean

to monitor the location of a roaming node. The

downsides of the method are twofold: (1) the

interface ID needs to be known in advance and (2)

ping or tracer-oute probe packets are in the worst

case sent to all networks in the Internet. To limit the

amount of probe packets, the method needs to be

focused on a specific set of usual locations of the

tracked user. This Ph.D. research focuses on passive

monitoring, and therefore, this method is not

applicable.

Grégr et al. (Grégr et al., 2011) poll neighbor

cache of the routers in our University network to

gather information about address assignments.

However, the gathered MAC addresses are not

available outside of the local network, and

consequently, this method is not applicable for the

remote location tracking scenario. Another

downside is that the polling of the routers causes

additional workload on the routers.

Groat et al. (Groat et al., 2011) studied DHCPv6

for monitoring the identity of users in LANs.

However, they focused only on one specific address

assignment method — DHCPv6. In contrast,

SLAAC is a default address assignment method in

IPv6 and DHCPv6 is deployed only rarely.

Moreover, even if it is deployed, end hosts can still

employ SLAAC to generate additional IPv6

addresses.

Asati and Wing (Asati and Wing, 2012) tried to

propagate the information about address

assignments outside of local networks but their

effort did not make it through the IETF

standardisation process.

3.3 Proprietary Solutions

Napatech

summarized their thoughts on problems

in current networking in a series of white papers.

Similarly to our research, (Napatech, 2014a) calls

for a distributed solution with deep packet



http://www.napatech.com

ICETE2014-DoctoralConsortium

inspection capabilities and application detection.

These methods might be employed as a source of

identities in our approach. The processing and

correlation of the information gathered in their

white paper is not clear. Napatech calls for better

knowledge of customer needs and behaviour to

avoid death spiral of decreasing revenue. The

mechanism to link (correlate) identities developed

during this research should be capable to help in

this use case as it can derive the identities of the

same user running different applications. In

addition, (Napatech, 2014b) advocates for analysis

of all network layers. This is very similar to our

approach. The downside of the white papers is the

omission of the detailed description due to their

solutions being proprietary.

Cisco Medianet Metadata (Cisco Systems, 2014)

allows to treat flows of specific applications

according to category, their urgency for business,

etc. Similarly, the framework for signaling of flow

characteristics (Eckert et al., 2013) tags flows with

metadata. Both solutions interact with an

application running on an end host and passes

metadata about flows of the application to the

network environment. Hence, both can be used as a

source of partial identities.

4 METHODOLOGY

Since there is not a single method that deals with all

identification-related challenges, several approaches

need to be considered. Typically, sources of

information about identities are scattered in the

network. Moreover, each source has only limited

knowledge about the attributes and consequently, it

operates only with partial identities.

This Section focuses on identities, their

detection and processing. Firstly, it elaborates on

the linkability of identities. Later, it outlines the

possible sources of information that are investigated

during this Ph.D. research.

4.1 Linkability of Identities

We consider a distributed solution to discover the

identities as depicted in the Figure 3. All sources of

identities present a different view on the network.

For example, RADIUS can reveal logins of the users

in the network but IPv6 addresses has to be

discovered from other sources, such as IPv6-SLAAC

or DHCPv6. The holistic view on the identities is

achieved in the central device by correlation of all

information leant from the sources.

Figure 3: Identities can be learnt from different sources in

the network and correlated in the central device.

The sources of discovered identities reveal

network identifiers that can be used in place of the

represented identity. For example, the e-mail

address x can represent the owner of the mail box.

Typically, basic relations between partial identities

can be uncovered from the network sources, such as

the owner of the e-mail address x connected to its

mail box from a computer with the IP address y.

Usually, one or more identifiers are common

between several sources of identities; they can be

used to reveal additional relations between partial

identities. Consider a user authenticating through

RADIUS. He or she authenticates their MAC

addresses when they access a network. Later, their

computer generates IPv6 addresses with SLAAC.

When both mechanisms are monitored, the relation

between IPv6 addresses and the RADIUS login can

be revealed through the mutually discovered MAC

address.

We consider graph representation of the

discovered (partial) identities. The constructed

graph has to be able to express different types of

network identifiers, from all layers of the TCP/IP

architecture. In addition, NAT and its implication

on the graph structure has to be considered. Hence,

the aim of the research should be at better

understanding of network user identities, their

relations and the identifiers that sufficiently

represent the identities.

The graph depicted in Figure 4 represents a

snapshot of identities discovered in a monitored

network of a company. A user is authenticated to

the network and his or her computer is using an

IPv4 and an IPv6 address. The traffic of these IP

addresses can be handled by special rules, e.g. it

should be treated with higher priority since the user

happens to be the manager of the company.

We see benefits in graph representation of the

snapshots of identities detected in a network at a

specific time. Indeed, a graph can model relations

between identities. Moreover, algorithms that are

wellknown from graph theory can be used to infer

additional information from the graph, such as

ChallengesinIdentificationinFutureComputerNetworks

Figure 4: An example of the graph representing relations

between different identities discovered in a network. The

identities are represented by network identifiers depicted

as nodes. The source of the relation between different

partial identities is displayed as a label of each edge.

related partial identities of the same subject.

Another goal is to represent graphs so that identities

related to computers and identities related to

specific persons can be distinguished.

Consequent plans include incorporating time

information into the graphs. Each change in the

network can be considered to be a shift between two

states of the network. Each state of the network can

be represented with the above-mentioned graph.

This is useful for the network monitoring use case.

The rest of this Section focuses on the sources of

identities in the network.

4.2 Local Monitoring

In local monitoring, local knowledge of the network

can be utilised. Often, an application manages the

users in the network, their computers or available

services: for instance a DHCP server or a RADIUS

server. Additionally, consider application layer

services, e.g. instant messaging server, VoIP private

branch exchange or SMTP server, as another

example. All these services are instances of the

Type 1 identity management system (IMSt1)

(Meints and Gasson, 2009).

Such IMSt1s are the most precise sources about

the identities connected to the network. Identities

can be learnt either in direct cooperation with an

IMSt1 or from the outputs of these IMSt1s, e.g.

logs.

a) Figure 5 depicts an extension or a plug-in of

an IMSt1. The plug-in is specialized to

advertise the managed identities. When a new

identity is learnt by the IMSt1, the plug-in

immediately passes the information and the

identity can be later correlated with other

identities from other sources. Since this

approach has to be supported by the IMSt1, it

is not applicable in all cases: for instance, a

plug-in system is not available, or, the IMSt1

cannot be accessed by the monitoring entity.

Cisco Medianet Metadata (Cisco Systems,

2014) and the framework for signaling of flow

characteristics (Eckert et al., 2013) are

examples of this scenario whenever the IMSt1

signalise attributes and identifiers of flows

through these channels.

Figure 5: Direct access to an IMSt1 allows immediate

access to all managed identities by the IMSt1.

b) IMSt1s often log changes of the state to

external logs, e.g. stored on a local hard drive.

These logs can be regularly analysed by a

script, which discovers attributes and

consequently identities in the logs (as

displayed in Figure 6). In this case, the

changes are learnt with a slight delay caused

by the polling. The delay can be avoided in

case the file system allows the script to be

notified after the log was changed, e.g.

through inotify (Love, 2005). Alternatively,

SNMP traps or similar mechanisms can be

used when logs are not available.

However, sometimes a special code cannot be

integrated to an IMSt1 of interest, the logs are not

available, or the delay caused be polling of the logs

is not acceptable. For these circumstances, we focus

on traffic parsing during the Ph.D. research.

Figure 6: Logs of IMSt1s typically contain information

about the processed identities, which can be collected by

a script and passed for a further processing.

In the case of centralised services, such as

DHCP or RADIUS, we propose to gather the

information as close to the server as possible;

preferably on the access link of the server. In this

way, all traffic destined for the server can be

analysed with one probe.

However, addresses generated during SLAAC

are not handled centrally but the knowledge about

the assignments is distributed in the network

(Polčák et al., 2013a). For this case, we already

proposed (Polčák et al., 2013a) tracking of IPv6

control traffic (ICMPv6). The approach is passive

and it can learn the assignments of all IPv6

addresses in a LAN.

ICETE2014-DoctoralConsortium

In SDN, a controller or a cluster of controllers

have a detailed knowledge (McKeown et al., 2008)

about the network including its topology and end

hosts. Usually, the controller has a northbound

interface that can be used by a third party

application to learn about the state of the network or

inject rules. Therefore, an SDN controller can be

another source of information about the identities in

a network.

Today, typically all network interfaces are

identifiable by a MAC address. Since the ICMPv6

approach (Polčák et al., 2013a), DHCP logs, and

SDN controllers provide MAC and IP address

pairings, different identities of one computer can be

linked through MAC addresses. However, note that

not all mechanisms can reveal a MAC address, for

instance DHCPv6 (Polčák et al., 2013a) does not

assign IPv6 addresses according to MAC addresses

but instead, it uses DUIDs — special identifiers of

DHCPv6.

In summary, various mechanisms can be used to

detect identities in local networks. A direct

cooperation with IMSt1s provides most precise

information, however, it is not always available.

SDN controllers are another source of reliable

information. However, some identities can be only

learnt from traffic parsing. This research consider

all these means to obtain identities.

4.3 Remote Monitoring

When identities of remote users need to be detected,

e.g. for an Internet access provider monitoring its

network or guaranteeing quality of service, Layer 2

and lower identifiers are not available during

remote identity detection, unless a MAC address

leaks, e.g. through lower part of an IPv6 address

(Dunlop et al., 2011). As such leaks are not

common, a different method to link identities needs

to be employed, instead.

Each computer has internal clock to measure

time. As the manufacturing process is not precise on

atomic level, each clock has its own deficiencies.

Consequently, each computer measures time with

its own in-built inaccuracy, clock skew. Since the

clock skew does not depend on the location of a

computer in the network, or the type of its

connection (copper or WiFi), a computer can be

identified (Kohno et al., 2005) as it moves from

network to network. To evaluate this possibility, a

part of the Ph.D. research focuses on clock skews

and their suitability for remote identification.

HTTP headers also reveal substantial

information (Eckersley, 2010) about user identity.

Besides the headers, Eckersley also considered

JavaScipt and cookies. However, for passive

detection, only HTTP headers from requests are

available.

Additionally, clock skew and the browser

fingerprinting based on HTTP headers can be

combined. Therefore, even computers with very

similar clock skew can be distinguished by

potentially different HTTP headers. Vice versa,

browsers with similar configuration can be running

on computers with different clock skew; thus the

browsers can be differentiated through the clock

skew. In addition, browser updates can be linked

through the detection of a known clock skew.

The behaviour models (Banse et al., 2012;

Herrmann et al., 2012; Kumpošt, 2008) are not

considered during this Ph.D. research. As

mentioned in Section 3, the reported recognition

time of a computer is one day or longer. As users

roam between networks much quicker, the

behaviour models are not suitable for this Ph.D.

research.

5 EXPECTED OUTCOME

This section elaborates on the content of the final

Ph.D. thesis. Firstly, the thesis has to list the

challenges for identification in modern networks.

This list should be based on the challenges solved

during the research and open challenges for future

research.

Additionally, the Ph.D. thesis should provide

formal algorithms and methodology for dealing

with partial identities and their linkability. The

algorithms need to support various sources of

information and they have to consider possible

network operational conditions, including NAT and

multiple addresses of the same computer.

Previously proposed solutions should be

evaluated as the sources of information. Moreover,

the Ph.D. thesis should introduce new mechanisms

for identity detection. All considered mechanisms

should be examined and their advantages and

disadvantages has to be investigated.

In addition, the thesis should reflect possible use

cases related to identity detection. Lawful

interception, network management, and

provisioning of high quality of service are among

the possible applications of this work. As such, the

proposed solution needs to be tested for one of the

above use cases.

As one of the aims of the research carried at the

Brno University of Technology is focused on

ChallengesinIdentificationinFutureComputerNetworks

criminality mitigation on the new generation

Internet (FIT BUT, 2014), incorporation of the

proposed mechanisms to the Lawful Interception

System is an obvious choice.

We also plan development of an SDN-based

management system for traffic shaping and

controlling network accessibility based on

identities. For example, consider an IT company

with a development department, HR, and

accounting. Each of these departments has servers

and services that should not be accessed by

employees of other departments. The IMS designed

during this Ph.D. research can differentiate the

traffic of employees of different departments and

provide separation even if employees of all

departments are in one room during a meeting.

6 STAGE OF THE RESEARCH

This section lists the achievements that were

accomplished during the research. The research

already achieved several milestones both in identity

management and in studying the sources of partial

identities.

In the area of local monitoring, we proposed a

mechanism to detect all IPv6 addresses used in the

network by monitoring messages exchanged during

neighbor discovery. The method takes into account

several differences that we discovered (Polčák and

Holkovič, 2013) in the behaviour of operating

systems. This method was successfully tested at our

University network and it can reveal all IPv6

addresses used by one computer. Later, we

expanded (Polčák et al., 2013b) the detection to

SDN environments.

In remote monitoring, we were interested in the

clock-skew-based identification (Kohno et al.,

2005). The method looked appealing because the

clock skew does not depend on computer interface

or its location. We were interested in using the

method to link different IPv6 addresses of the same

computer. This worked in laboratory environment,

however, our measurements revealed several

obstacles (Polčák et al., 2013c; Polčák and

Franková, 2014) that makes the method hard to use

in real networks. We consider combining the clock-

skew-based identification with other methods, such

as those based on unique content of HTTP headers

(Eckersley, 2010) or amount of traffic sent by

specific users (Megyesi and Molnár, 2013).

We already proposed a formal method to link

identities but it was not published, yet. Currently,

we wait for the results of the peer review for the

submitted paper concerning the approach.

All methods have already been incorporated to

the lawful interception system developed at Brno

University of Technology (FIT BUT, 2014). We

plan to show the application of the method in SDN

with the aim of provisioning desired quality of

service and controlling access to specific parts of

network based on the identity of a user.

7 CONCLUSION

Modern computer networks bring new challenges,

such as network address translation and short-lived

IPv6 addresses. As a result the number of identifiers

related to a single user increases. Consequently, old

methods for identification of the traffic of a specific

user are becoming weak. This research aims to

tackle the challenges by linking partial identities of

a subject together. This way, all traffic of specific

groups of users can be identified and it can be

treated in a personalised manner, e.g. important

calls of a manager can be prioritised.

We consider a distributed system that can link

identities discovered from various sources. As an

example, we investigated both local and remote

identification. This research already resulted in

several accepted papers (Polčák et al., 2013a;

Polčák et al., 2013b; Polčák et al., 2013c; Polčák

and Franková, 2014). Current efforts are in the area

of the proposal of the method to link different

identities, in improvements of the remote

identification techniques, and in designing an SDN-

based control system expanding the proposed IMS

to network control, such as quality of service.

ACKNOWLEDGEMENTS

This research belongs to the project

VG20102015022 (Modern Tools for Detection and

Mitigation of Cyber Criminality on the New

Generation Internet) supported by the Ministry of

the Interior of the Czech Republic. It was also

supported by the project FIT-S-14-2299 (Research

and application of advanced methods in ICT) of

Brno University of Technology.

I would like to thank my supervisors Miroslav

Švéda and Petr Matoušek for their help during the

research and for their input. In addition, I would

like to highlight the contribution of Tomáš Martínek

who helped me with this research during our

ICETE2014-DoctoralConsortium

discussions held on our regular meetings. His ideas

and comments improved this work. I would also

like to thank my students, especially Stanislav

Bárta, Barbora Franková, Martin Holkovič, Radek

Hranický, Jakub Jirásek, and Petr Kramoliš: both

for their input and for their help during the

development of the tools required in this research.

Last but not least, I want to thank Cisco Systems

Switzerland, in particular Davide Cuda and Amine

Choukir, for giving me the possibility of seeing the

research problem from a different angle.

REFERENCES

Asati, R. and Wing, D. (2012). Internet Draft version 00

(Work in progress): Tracking of Static/

Autoconfigured IPv6 addresses. Internet Engineering

Task Force.

ATIS/TIA (2006). Lawfully Authorized Electronic

Surveillance. J-STD-025-B. Alliance for Telecom-

munications Industry Solutions/ Telecommunications

Industry Association Joint Standard.

Banse, C., Herrmann, D., and Federrath, H. (2012).

Tracking users on the internet with behavioral

patterns: Evaluation of its practical feasibility. In

Gritzalis, D., Furnell, S., and Theoharidou, M.,

editors, Information Security and Privacy Research,

volume 376 of IFIP Advances in Information and

Communication Technology, pages 235–248. Springer

Berlin Heidelberg, DE.

Cisco Systems (2014). Cisco medianet architecture. http://

www.cisco.com/web/solutions/trends/medianet.

Clauß, S. and Köhntopp, M. (2001). Identity management

and its support of multilateral security. Computer

Networks, 37(2):205–219. Electronic Business

Systems.

Dunlop, M., Groat, S., Marchany, R., and Tront, J.

(2011). The Good, the Bad, the IPv6. In

Communication Networks and Services Research

Conference, pages 77–84, Ottawa, Canada.

Eckersley, P. (2010). How unique is your web browser?

In Atallah, M. and Hopper, N., editors, Privacy

Enhancing Technologies, volume 6205 of Lecture

Notes in Computer Science, pages 1–18. Springer

Berlin Heidelberg, DE.

Eckert, T., Penno, R., Choukir, A., and Eckel, C. (2013).

A Framework for Signaling Flow Characteristics

between Applications and the Network. IETF.

InternetDraft (work in progress), intended status:

Informational.

ETSI (2001). ETSI TR 101 944: Telecommunications

security; Lawful Interception (LI); Issues on IP

Interception. European Telecommunications

Standards Institute. Version 1.1.2.

FIT BUT (2010–2014). Modern tools for detection and

mitigation of cyber criminality on the new generation

internet. Brno University of Technology, Faculty of

Information Technology, CZ.

http://www.fit.vutbr.cz/~ipolcak/ grants.php?id=517.

Groat, S., Dunlop, M., Marchany, R., and Tront, J.

(2010). The privacy implications of stateless IPv6

addressing. In Cyber Security and Information

Intelligence Research, pages 52:1–52:4, New York,

NY, USA. ACM.

Groat, S., Dunlop, M., Marchany, R., and Tront, J.

(2011). What DHCPv6 says about you. In 2011

World Congress on Internet Security, pages 146–151,

London, UK.

Grégr, M., Matoušek, P., Podermański, T., and Švéda, M.

(2011). Practical IPv6 Monitoring Challenges and

Techniques. In Symposium on Integrated Network

Management, pages 660–663, Dublin, Ireland. IEEE

CS.

Herrmann, D., Gerber, C., Banse, C., and Federrath, H.

(2012). Analyzing characteristic host access patterns

for re-identification of web user sessions. In Aura, T.,

Järvinen, K., and Nyberg, K., editors, Information

Security Technology for Applications, volume 7127 of

Lecture Notes in Computer Science, pages 136–154.

Springer Berlin Heidelberg, DE.

Huang, D.-J., Yang, K.-T., Ni, C.-C., Teng, W.-C.,

Hsiang, T.-R., and Lee, Y.-J. (2012). Clock skew

based client device identification in cloud

environments. In Advanced Information Networking

and Applications, pages 526–533.

Jøsang, A., Fabre, J., Hay, B., Dalziel, J., and Pope, S.

(2005). Trust requirements in identity management.

In Proceedings of the 2005 Australasian Workshop on

Grid Computing and e-Research Volume 44, ACSW

Frontiers ’05, pages 99–108, Darlinghurst, Australia,

Australia. Australian Computer Society, Inc.

Kohno, T., Broido, A., and Claffy, K. (2005). Remote

physical device fingerprinting. IEEE Transactions on

Dependable and Secure Computing, 2(2):93–108.

Kumpošt, M. (2008). Context Information and User

Profiling. PhD thesis, Masaryk University, CZ.

Laiping Zhao, Yizhi Ren, Mingchu Li, and Kouichi

Sakurai (2012). Flexible service selection with user-

specific QoS support in service-oriented architecture.

Journal of Network and Computer Applications,

35(3):962–973. Special Issue on Trusted Computing

and Communications.

Lanze, F., Panchenko, A., Braatz, B., and Zinnen, A.

(2012). Clock skew based remote device

fingerprinting demystified. In Global

Communications Conference, pages 813–819.

Love, R. (2005). Kernel korner: Intro to inotify. Linux

Journal, 2005(139).

McKeown, N., Anderson, T., Balakrishnan, H., Parulkar,

G., Peterson, L., Rexford, J., Shenker, S., and Turner,

J. (2008). OpenFlow: enabling innovation in campus

networks. SIGCOMM Computer Communication

Review, 38(2):69–74.

Megyesi, P. and Molnár, S. (2013). Analysis of elephant

users in broadband network traffic. In Bauschert, T.,

editor, Advances in Communication Networking,

ChallengesinIdentificationinFutureComputerNetworks

Lecture Notes in Computer Science, pages 37–45.

Springer Berlin Heidelberg. LNCS 8115.

Meints, M. and Gasson, M. (2009). High-Tech ID and

Emerging Technologies, pages 130–189. Springer

Berlin Heidelberg.

Murdoch, S. J. (2006). Hot or not: Revealing hidden

services by their clock skew. In Computer and

Communications Security, pages 27–36, New York,

NY, USA. ACM.

Napatech (2014a). Time to ReThink Mobile Network

Analysis. White paper, version 6, available online at

http://www.napatech.com/sites/default/files/

dn-0720_ttrt_mobile_network_analysis_v06_us_a4_

online.pdf.

Napatech (2014b). Time to ReThink Performance Moni-

toring. White paper, version 6, available online at

http://www.napatech.com/sites/default/files/dn-0645_

ttrt_performance_monitoring_ v6_us_a4_online.pdf.

Narten, T., Draves, R., and Krishnan, S. (2007). Privacy

Extensions for Stateless Address Autoconfiguration in

IPv6. IETF. RFC 4941 (Draft Standard).

Pfitzmann, A. and Hansen, M. (2010). A terminology for

talking about privacy by data minimization:

Anonymity, unlinkability, undetectability,

unobservability, pseudonymity, and identity

management. Technical report. Version 0.34,

Available online at https://dud.inf.tu-dresden.de/

literatur/Anon_Terminology_v0.34.pdf.

Polčák, L. and Franková, B. (2014). On reliability of

clockskew-based remote computer identification. In

International Conference on Security and

Cryptography. SciTePress Science and Technology

Publications.

Polčák, L. and Holkovič, M. (2013). Behaviour of various

operating systems during SLAAC, DAD, and ND.

http://6lab.cz/?p=1691.

Polčák, L., Holkovič, M., and Matoušek, P. (2013a). A

New Approach for Detection of Host Identity in IPv6

Networks. In Data Communication Networking,

pages 57–63. SciTePress Science and Technology

Publications.

Polčák, L., Holkovič, M., and Matoušek, P. (Accepted,

2013b). Host Identity Detection in IPv6 Networks. In

Communications in Computer and Information

Science. Springer Berlin Heidelberg, DE.

Polčák, L., Jirásek, J., and Matoušek, P. (2013c).

Comments on ”Remote physical device

fingerprinting”. IEEE Transactions on Dependable

and Secure Computing. Accepted, PrePrint available.

Sanguanpong, S. and Koht-Arsa, K. (2013). A design and

implementation of dual-stack aware authentication

system for enterprise captive portal. In 9th

International Conference on Network and Service

Management (CNSM), pages 118–121, Zürich,

Switzerland.

Scarfone, K. A., Grance, T., and Masone, K. (2008).

Computer security incident handling guide. Technical

Report SP 800-61 Rev. 1., National Institute of

Standards & Technology, Gaithersburg, MD, United

States.

Sharma, S., Hussain, A., and Saran, H. (2012).

Experience with heterogenous clock-skew based

device fingerprinting. In Workshop on Learning from

Authoritative Security Experiment Results, pages 9–

18. ACM.

Thomson, S., Narten, T., and Jinmei, T. (2007). RFC

4862 IPv6 Stateless Address Autoconfiguration.

Internet Engineering Task Force.

Wing, D. and Yourtchenko, A. (2012). Happy Eyeballs:

Success with Dual-Stack Hosts. IETF. RFC 6555

(Proposed Standard).

Zander, S. and Murdoch, S. J. (2008). An improved

clockskew measurement technique for revealing

hidden services. In Proceedings of the 17th

Conference on Security Symposium, pages 211–225,

Berkeley, CA, USA. USENIX Association.

ICETE2014-DoctoralConsortium
