Towards Integrity in Diversity-aware Small Set Selection

and Visualisation Tasks

Marcin Sydow

1,2

Institute of Computer Science, Polish Academy of Sciences, Warsaw, Poland

Polish-Japanese Institute of IT, Warsaw, Poland

Keywords:

Diversity, Integrity, Summarisation, Semantic Graphs, Visualisation.

Abstract:

In this short paper, we introduce a novel notion of integrity in diversity-aware selection and visualisation

tasks, present motivation for studying this notion and illustrate it on a case study concerning the visualisation

of semantic entity summaries. In particular, we propose a novel visual integrity measure for this case study

and illustrate it in a preliminary experiment.

1 INTRODUCTION

Diversity is a desired property of results returned to

the user in many applications concerning selecting a

small set of information pieces. It is especially true

in cases when the actual user information need is un-

known or ambiguous and the limit on the amount of

presented information is low. This concerns numer-

ous important practical tasks ranging from result di-

versiﬁcation in Web search (Agrawal et al., 2009),

database querying (Vee et al., 2008), recommender

systems to diversity-aware text summarisation (Car-

bonell and Goldstein, 1998) and recently entity sum-

marisation (Xu et al., 2014) and more speciﬁcally se-

mantic entity summarisation (Xu et al., 2014; Sydow

et al., 2013), to mention some examples. The main

idea in such diversity-aware approaches is to select

and present to the user pieces of information that

are not only potentially maximally relevant to the

user’s information need but also maximally diversi-

ﬁed. This is achieved by various techniques. For ex-

ample, some of them introduce a pair-wise dissimi-

larity measure between the presented items and ap-

proach it as an adaptation of the Maximum Facility

Dispersion Problem (Gollapudi and Sharma, 2009).

Other view the problem as the maximum coverage

(Clarke et al., 2008) or as minimising the probabil-

ity of query abandonment (Chen and Karger, 2006).

The rationale behind such approaches is to avoid re-

dundancy in presented information and the optimal

use of the given low limit on the amount of presented

information i.e. to cover maximally many different

possible aspects/interpretations of the presented infor-

mation to satisfy at least partially an unkown actual

user’s information need.

1.1 The Issue of Information Integrity

The information selection tasks mentioned above can

be roughly divided into two cases.

First Case: Independent Items. In the ﬁrst group,

each separate returned item from the result set repre-

sents rather an independent piece or portion of useful

information to the user itself. This concerns: each re-

turned link to a web document in web search result

set, each returned record in database query result set

or each separate recommended item in the result set

returned by a recommender system.

In such cases, increasing the diversity of re-

sults, without loosing relevance generally improves

the quality of results.

Second Case: Inter-Dependent Items. There is a

second group of tasks, however, that should be treated

in a different way. Here, the returned items can be

more inter-dependent. This concerns especially all

summarisation-like tasks. For example, in extractive

text summarisation, the task is to select a small set of

sentences out of the input text that summarise it. No-

tice that a single piece of useful information can be

spread among two or more sentences that refer to each

other, in such case a single sentence does not neces-

sarily represent a full sense to the user, alone. Similar

situation concerns the entity summarisation task (Xu

et al., 2014; Sydow et al., 2013), where given an input

entity, the output result is expected to be a representa-

tive set of facts or features selected from an underly-

480

Sydow M..

Towards Integrity in Diversity-aware Small Set Selection and Visualisation Tasks.

DOI: 10.5220/0005159904800484

In Proceedings of the International Conference on Knowledge Discovery and Information Retrieval (KDIR-2014), pages 480-484

ISBN: 978-989-758-048-2

 2014 SCITEPRESS (Science and Technology Publications, Lda.)

ing knowledge base and presented to the user. In such

case some facts or features concerning the entity make

more sense to the user only when presented together

in the context of the summarised entity. For exam-

ple, the properties such as “longitude” and “latitude”

in the context of an entity that has some geographi-

cal location (e.g. a city) make a full sense to the user

only when presented together. We will hence refer

to the issue described in such case as to “information

integrity”.

1.2 Motivation and Contributions

It is important to observe that in most of the diversity-

aware approaches known from literature such a in-

formation link between two or more inter-dependent

items will be ignored (in optimistic scenario) while it

should not as it may lead to separating the pieces of

information. Furthermore, in the diversiﬁcation tech-

niques that are based on redundancy-avoiding such

items will be very likely to be identiﬁed as “similar”

and consequently separated to avoid redundance in

the result. For example, when item “latitude” is se-

lected to be presented in the entity summary, the item

“longitude” will be dropped as being “similar”. As

the result the user would not obtain complete infor-

mation.

The main motivation of this paper is to introduce

the notion of “information integrity” to the research

concerning diversity-aware approaches and to pro-

pose some fundamental observations and concepts in

order to start the discussion on this issue.

1.3 Integrity-awareness in Three Phases

In particular, we identify three basic phases of

a diversity-aware information interaction process,

where the information integrity issue should be prop-

erly addressed:

1. pre-selection phase: automatic detection of the

“information integrity” issue (e.g. computing

some statistics to identify pairs or sets of pieces of

information that should be treated as “integral”)

2. selection phase: enriching the diversity-aware re-

sult selection phase with integrity-awareness (e.g.

to avoid separation of ensembles of items that

have been identiﬁed as “integral” and presented

together)

3. presentation phase: enriching the presentation of

the results with integrity-awareness (e.g. to em-

phasise in the presented results the integrity of

some subsets of presented items)

We realise that each of the above points de-

serves for a separate study and concrete solutions can

strongly depend on the particular application.

We hope that the proposed ideas are to some

extent adaptable in other applications, in particular

in other information visualisation tasks (for example

Google Knowledge Graph or Semantic Knowledge

Graph browsers (e.g. Yago Browser

)

2 CASE STUDY:

INTEGRITY-AWARE

VISUALISATION IN THE

DIVERSUM PROBLEM

In this section we illustrate integrity-awareness prob-

lem on an example. The example is a speciﬁc sum-

marisation problem called DIVERSUM, presented

quite recently in (Sydow et al., 2013). The full name

of the DIVERSUM problem is: diversity-aware en-

tity summarisation on semantic knowlege graphs. The

speciﬁcation of the problem will be given in Sec-

tion 2.2. More precisely, to illustrate the integrity-

awareness issues we focus on the visualisation phase

of the DIVERSUM problem.

2.1 Data: Semantic Knowledge Graph

In this problem, there is given an underlying seman-

tic knowledge graph KG. In short, it consists of a

large collection of so-called subject-predicate-object

triples, where subject and object are some nodes in

KG. The nodes can represent entities – in such case

the predicate represents a “fact” concerning two enti-

ties (e.g. (Woody Allen, acted in, Zelig). One or both

nodes can also represent classes, e.g. (Woody Allen,

has type, Actor) or (Actor, is subclass of, Person), etc.

2.2 DIVERSUM: Problem Speciﬁcation

The problem has the following speciﬁcation:

INPUT:

1. KG – the underlying knowledge base

2. q – a node of KG (entity to be summarised)

3. k ∈ N – an upper limit on the number of facts

(triples) to be presented in the entity summary

OUTPUT: S: summary of entity q – a connected sub-

graph of D containing q and at most k arcs that to-

gether represent a collection of facts being a summary

https://gate.d5.mpi-inf.mpg.de/webyagospotlx/SvgBrowser

For a fuller discussion of the DIVERSUM problem we

refer the reader to (Sydow et al., 2013)

TowardsIntegrityinDiversity-awareSmallSetSelectionandVisualisationTasks

481

Figure 1: Example graphical entity summary of John

Wayne computed on imdb knowledge graph by DIVER-

SUM algorithm with k=7.

of information concerning the entity in the semantic

knowledge graph. In the DIVERSUM problem we

additionally pay attention to make the summary di-

versiﬁed.

An example concerning imdb movie semantic

database

of the resulting summary in the DIVER-

SUM problem is presented on Figure 1. The enti-

ties in this dataset represent movies, actors, prizes,

etc. We will call each particular triple as “fact” (e.g.

“John Wayne, acted in, True Grit”) and each arc label

as “predicate” (e.g. “acted in”). Using the general ter-

minology as in Section 1 the items to be returned are

the facts concerning the input entity.

In the DIVERSUM problem the result is graph-

ical. Thus, the problem does not consist only in

selecting the items to be shown in the entity sum-

mary(selection phase mentioned in Section 1.3) but

also in a subsequent visualisation of the results (pre-

sentation phase mentioned in Section 1.3). In the re-

maining part of this paper we will illustrate how the

integrity-awareness issue can be naturally observed in

the visualisation phase of the DIVERSUM problem.

2.3 Integrity in Visualisation Phase of

DIVERSUM

When the set of facts to be presented is selected the

remaining task is to decide the layout of the summary.

We will simplify the problem and focus only on the

order of the facts to be presented. Notice that in the

DIVERSUM problem, the presented facts concerning

the summarised entity form a ring of k facts (Fig. 1).

www.imdb.org

2.4 Integrity-aware Visualisation as an

Optimisation Problem

We propose that in the visualisation phase the goal of

the integrity-aware approach can be simply expressed

as follows: similar elements should be shown close to

each other.

We propose to specify this problem as an optimi-

sation one. More precisely, it can be done by deﬁning

integrity measure of a given layout and select the lay-

out that maximises the integrity measure.

2.5 Proposed Visual Integrity Measure

A visual integrity measure should promote layouts in

which similar elements are close to each other. Let

assume that S is the k−set of selected items to be

presented in the summary. Let’s also assume that

there is deﬁned a pair-wise semantic similarity mea-

sure sim : S

→ Q+. We assume that sim is symmetric

(i.e. sim(a, b) = sim(b, a)). The higher the value, the

more similar are the items.

We propose to consider the following visual in-

tegrity measure vim to be maximised based on sim:

vim(L) =

∑

s∈S

sim(s, next

(s))

where L denotes particular layout of the selected

items and next

(s) denotes the element s

∈ S that is

shown next (say, clockwise)

to s in the layout L. The

interpretation of vim is simple: it sums up similarity

measures of neighbouring elements in the layout. By

maximising vim we force the layout to show similar

elements next to each other, in a way.

2.6 Experimental Example

To illustrate the discussed ideas we will use the imdb

movie dataset converted to the format of a semantic

knowledge graph.

In this example, for illustration, we deﬁne the un-

derlying pair-wise similarity sim measure in a sim-

ple way, based on co-occurrence statistics in the imdb

dataset. More precisely, for two facts a, b, the simi-

larity measure value sim(a, b) is deﬁned as the num-

ber of entities in the dataset D in which the predicate

names in a, b co-occur divided by the number of en-

tities in D in which at least one predicate name from

a, b occurs. In other ways it is an adaptation of the

Jaccard co-efﬁcient. To explain: assume that there

are 200 entities incident with predicates a =“actedIn”

This choice is arbitrary, counter-clockwise would result

in the same value in this case

KDIR2014-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

482

Table 1: Jaccard-based, Pair-wise similarity measure for

predicates concerning John Wayne on the imdb dataset.

actedIn directed 0.100

actedIn hasWebsite 0.101

bornOnDate actedIn 0.147

bornOnDate directed 0.055

bornOnDate hasChild 0.026

bornOnDate hasWebsite 0.095

bornOnDate hasWonPrize 0.086

bornOnDate isMarriedTo 0.133

directed hasWebsite 0.025

hasChild actedIn 0.008

hasChild directed 0.005

hasChild hasWebsite 0.013

hasChild hasWonPrize 0.063

hasWonPrize actedIn 0.028

hasWonPrize directed 0.027

hasWonPrize hasWebsite 0.027

isMarriedTo actedIn 0.036

isMarriedTo directed 0.016

isMarriedTo hasChild 0.083

isMarriedTo hasWebsite 0.033

isMarriedTo hasWonPrize 0.135

and b =“directed” (i.e. entities that are both actors

and directors) and that there are 1000 entities in the

dataset that are incident with “actedIn” or “directed”

predicate (actors or directors). The similarity measure

in such case would have value of: sim(a, b) = 0.2.

Table 1 presents the values of similarity measure

computed in this way on the imdb dataset for all pairs

of predicates incident with the entity JohnWayne. For

this example, the optimal layout computed by max-

imising the vim measure and using the sim measure

as described is presented on Figure 2. This example

is given only as an illustration of the discussed con-

cepts and deﬁnitely leaves a lot of room for improve-

ments. For example, we observed that the proposed

simple sim similarity measure gives un-intuitive val-

ues for some pairs (e.g. “isMarriedTo”, “hasWon-

Prize”), however is generally very promising, consid-

ering its simplicity. Also the proposed variant of the

vim visual integrity measure should be treated only as

a basis for further improvements.

3 CONCLUSIONS

We introduced a novel notion of integrity in the con-

text of diversity-aware information selection and vi-

sualisation tasks and illustrated it on an example of

semantic entity summarisation problem. As diversity-

awareness has proved to be an important approach in

many applications we argue that integrity-awareness

is a necessary next step to improve this approaches.

Figure 2: Optimal layout of graphical entity summary of

John Wayne computed on imdb knowledge graph with k=7.

Integrity measure for this layout L: V IM(L) = 0.62.

ACKNOWLEDGEMENTS

The work is supported by Polish National Science

Centre 2012/07/B/ST6/01239 ”DISQUSS” grant.

Thanks are due to M.Andruch

ow for computing the

example in Table 1 and Figure 2.

REFERENCES

Agrawal, R., Gollapudi, S., Halverson, A., and Ieong, S.

(2009). Diversifying search results. In Proceedings

of the Second ACM International Conference on Web

Search and Data Mining, WSDM ’09, pages 5–14,

New York, NY, USA. ACM.

Carbonell, J. and Goldstein, J. (1998). The use of mmr,

diversity-based reranking for reordering documents

and producing summaries. In Proceedings of the 21st

annual international ACM SIGIR conference on Re-

search and development in information retrieval, SI-

GIR ’98, pages 335–336, New York, NY, USA. ACM.

Chen, H. and Karger, D. R. (2006). Less is more: prob-

abilistic models for retrieving fewer relevant docu-

ments. In Proceedings of the 29th annual interna-

tional ACM SIGIR conference on Research and de-

velopment in information retrieval, SIGIR ’06, pages

429–436, New York, NY, USA. ACM.

Clarke, C. L., Kolla, M., Cormack, G. V., Vechtomova, O.,

Ashkan, A., B

uttcher, S., and MacKinnon, I. (2008).

Novelty and diversity in information retrieval evalua-

tion. In Proceedings of the 31st annual international

ACM SIGIR conference on Research and development

in information retrieval, SIGIR ’08, pages 659–666,

New York, NY, USA. ACM.

Gollapudi, S. and Sharma, A. (2009). An axiomatic ap-

proach for result diversiﬁcation. In Proceedings of

the 18th international conference on World wide web,

WWW ’09, pages 381–390, New York, USA. ACM.

Sydow, M., Pikula, M., and Schenkel, R. (2013). The no-

tion of diversity in graphical entity summarisation on

TowardsIntegrityinDiversity-awareSmallSetSelectionandVisualisationTasks

483

semantic knowledge graphs. Journal of Intelligent In-

formation Systems, 41:109–149.

Vee, E., Srivastava, U., Shanmugasundaram, J., Bhat, P.,

and Yahia, S. A. (2008). Efﬁcient computation of di-

verse query results. In Proceedings of the 2008 IEEE

24th International Conference on Data Engineering,

ICDE ’08, pages 228–236, Washington, DC, USA.

IEEE Computer Society.

Xu, D., Cheng, G., and Qu, Y. (2014). Preferences in

wikipedia abstracts: Empirical ﬁndings and implica-

tions for automatic entity summarization. Information

Processing and Management, 50(2):284 – 296.

KDIR2014-InternationalConferenceonKnowledgeDiscoveryandInformationRetrieval

484
