Social Business Intelligence

OLAP Applied to User Generated Contents

Matteo Golfarelli

DISI, University of Bologna, Via Sacchi, 3, Cesena, Italy

Keywords:

OLAP, User-generated Contents, Data Warehousing, Social Media Monitoring, Sentiment Analysis.

Abstract:

Social BI is an emerging discipline that aims at applying OLAP analysis to textual user-generated content to

let decision-makers analyze their business based on the trends perceived from the environment. Despite the

increasing diffusion of SBI applications, only few works in the academic literature addressed the speciﬁcities

of this applications. In this paper we report some of this distinguishing features and discuss possible solutions.

1 INTRODUCTION

The planetary success of social networks and the

widespread diffusion of portable devices has enabled

simpliﬁed and ubiquitous forms of communication

and has contributed, during the last decade, to a sig-

niﬁcant shift in human communication patterns to-

wards the voluntary sharing of personal information.

Most of us are able to connect to the Internet any-

where, anytime, and continuously send messages to a

virtual community centered around blogs, forums, so-

cial networks, and the like. This has resulted in the ac-

cumulation of enormous amounts of user-generated

content (UGC), that include geolocation, preferences,

opinions, news, etc. This huge wealth of informa-

tion about people’s tastes, thoughts, and actions is ob-

viously raising an increasing interest from decision

makers because it can give them a fresh and timely

perception of the market mood; besides, often the dif-

fusion of UGC is so widespread to directly inﬂuence

in a decisive way the phenomena of business and so-

ciety (Castellanos et al., 2011; Rehman et al., 2012b;

Zhang et al., 2009).

Some commercial tools are available for analyz-

ing the UGC from a few predeﬁned points of view

(e.g., topic discovery, brand reputation, and topics

correlation) and using some ad-hoc KPIs (e.g., topic

presence counting and topic sentiment). These tools

do not rely on any standard data schema; often they

do not even lean on a relational DBMS but rather on

in-memory or non-SQL ones. Currently, they are per-

ceived by companies as self-standing applications, so

UGC-related analyses are run separately from those

strictly related to business, that are carried out based

on corporate data using traditional business intelli-

gence platforms. To give decision makers an unprece-

dentedly comprehensivepicture of the ongoing events

and of their motivation, this gap must be bridged

(Garc´ıa-Moya et al., 2013).

Social Business Intelligence

(SBI) is the emerg-

ing discipline that aims at effectively and efﬁciently

combining corporate data with UGC to let decision-

makers analyze and improve their business based on

the trends and moods perceived from the environ-

ment (Gallinucci et al., 2013). As in traditional busi-

ness intelligence, the goal of SBI is to enable power-

ful and ﬂexible analyses for decision makers (simply

called users from now on) with a limited expertise in

databases and ICT. In other terms we want to apply

OLAP analysis on top of a data warehouse storing a

semantically enriched version of the UGC related to a

speciﬁc matter.

In the context of SBI, the most widely used cate-

gory of UGC is the one coming in the form of textual

clips. Clips can either be messages posted on social

media (such as Twitter, Facebook, blogs, and forums)

or articles taken from on-line newspapers and mag-

azines. Digging information useful for users out of

textual UGC requires to set up an extended ETL pro-

cess that includes (1) crawling the web to extract the

clips related to a subject area; (2) enriching them in

order to let as much information as possible emerge

from the raw text; (3) transforming and modeling the

data in order to store them in a multidimensional fash-

In the literature the term Social BI is also used to de-

ﬁne the collaborative development of post user-generated

analytics among business analysts and data mining profes-

sionals.

Golfarelli M.

Social Business Intelligence - OLAP Applied to User Generated Contents.

DOI: 10.5220/0006807200010001

In Proceedings of the 11th International Conference on e-Business (ICETE 2014), pages 11-19

ISBN: 978-989-758-043-7

ion. The subject area deﬁnes the project scope and

extent, and can be for instance related to a brand or

a speciﬁc market. Enrichment activities may simply

identify the structured parts of a clip, such as its au-

thor, or even use sentiment analysis techniques (Liu

and Zhang, 2012) to interpret each sentence and if

possible assign a sentiment (also called polarity, i.e.,

positive, negative, or neutral) to it. We will call SBI

process the one whose phases range from web crawl-

ing to users’ analyses of the results.

SBI has emerged as an application and research

ﬁeld in the last few years. Although a wide literature

is available on the two initial steps of the extended

ETL process sketched so far, namely data crawling,

text mining, semantic enrichment and Natural Lan-

guage Processing, only few papers have focused on

the strictly OLAP-related issues. In (Lee et al., 2000)

the authors propose a cube for analyzing terms oc-

ccurrences in documents belonging to a corpus but

the terms categorization is very simple and do not al-

low to carry out analysis at different levels of abstrac-

tion. In (Ravat et al., 2008) the authors propose tex-

tual measures as a solution to summarize textual in-

formation within a cube. Complete architectures for

SBI have been proposed by (Rehman et al., 2012a)

and by (Garca-Moya et al., 2013) identifying its basic

blocks but still with a limited expressiveness. An im-

portant step in increasing the expressiveness of SBI

queries has been done in (Dayal et al., 2012) where,

a ﬁrst advanced solution for modeling – the so-called

topic hierarchy – has been proposed. In this paper we

discuss three issues that, in our experience, represent

major changes with respect to tradition BI projects:

• SBI Architecture: with reference to standard BI

projects, SBI requires additional modules neces-

sary, for example, for semantic enrichment of un-

structured data. It also requires new technologies

such as document DBMS necessary for storing

and querying the large amount textual UGC.

• Modeling of SBI data: the semi-structured na-

ture of SBI data together with the dynamism of

UGCs make traditional multidimensional models

not enough expressive to support SBI queries.

• Methodology for SBI projects: a distinctive fea-

ture of SBI projects is related to the huge dy-

namism of the UGC and of the pressing need

of immediately perceiving and timely reacting to

changes in the environment.

2 A SBI ARCHITECTURE

The architecture we propose to support our approach

















Figure 1: An architecture for SBI.

to SBI is depicted in Figure 1. Its main highlight is

the integration between sentiment and business data,

which is achieved in a non-invasive way by extracting

some business ﬂows from the enterprise data ware-

house and integrating them with those carrying tex-

tual UGC, in order to provide users with 360

◦

deci-

sional capabilities. In the following we brieﬂy com-

ment each component.

The Crawling component carries out a set of

keyword-based queries aimed at retrieving the clips

(and the available meta-data) that are in the scope

of the subject area. The target of the crawler search

could be either the whole web or a set of user-deﬁned

web sources (e.g., blogs, forums, web sites, social

networks). The semi-structured output of the crawler

is turned into a structured form and loaded onto the

Operational Data Store (ODS), that stores all the rel-

evant data about clips, their authors, and their source

channels; to this end, a relational ODS can be cou-

pled with a document-oriented database that can efﬁ-

ciently store and search the text of the clips. The ODS

also represents all the topics within the subject area

and their relationships. The Semantic Enrichment

component works on the ODS to extract the seman-

tic information hidden in the clip texts. Depending

on the technology adopted (e.g., supervised machine-

learning (Pang et al., 2002) or lexicon-based tech-

niques (Taboada et al., 2011) such information can in-

clude the single sentences in the clip, its topic(s), the

syntactic and semantic relationships between words,

or the sentiment related to a whole sentence or to

each single topic it contains. The ETL component

periodically extracts data about clips and topics from

the ODS, integrates them with the business data ex-

tracted from the Enterprise Data Warehouse (EDW),

and loads them onto the Data Mart (DM). The DM

stores integrated data in the form of a set of multidi-

mensional cubes that, as shown in Section 3, require

ad-hoc modeling solutions; these cubes support the

decision making process in three complemental ways:

1. OLAP & Dashboard: users can explore the UGC

from different perspectives and effectively con-

trol the overall social feeling. Using OLAP tools

for analyzing UGC in a multidimensional fashion

pushes the ﬂexibility of our architecture much fur-

ther than the standard architectures adopted in this

context.

2. Data Mining: users evaluate the actual relation-

ship between the rumors/opinion circulating on

the web and the business events (e.g., to what ex-

tent positive opinions circulating about a product

will have a positive impact on sales?).

3. Simulation: the correlation patterns that connect

the UGC with the business events, extracted from

past data, are used to forecast business events in

the near future given the current UGC.

In our prototypical implementation of this ar-

chitecture, publicly available at http://semantic.csr.

unibo.it, topics and roll-up relationships are manu-

ally deﬁned; we use Brandwatch for keyword-based

crawling, Talend for ETL, SyN Semantic Center by

SyNTHEMA for semantic enrichment (speciﬁcally,

for labeling each clip with its sentiment), Oracle for

storing the ODS and the DM, and MongoDB for stor-

ing the document database. We developed an ad-hoc

OLAP & dashboard interface using JavaScript, while

simulation and data mining components are not cur-

rently implemented.

The components mentioned above are normally

present, though with different levels of sophistica-

tion, in most current commercial solutions for SBI.

However the roles in charge of designing, tuning, and

maintaining each component may vary from project

to project. In regards to this, SBI projects can be clas-

siﬁed as follows:

• Level 1: Best-of-Breed. In this type of projects,

a best-of-breed policy is followed to acquire tools

specialized in one of the steps necessary to trans-

form raw clips in semantically-rich information.

This approach is often followed by those who run

a medium to long-term project to get full control

of the SBI process by ﬁnely tuning all its criti-

cal parameters, typically aimed at implementing

ad-hoc reports and dashboards to enable sophisti-

cated analyses of the UGC.

• Level 2: End-to-End. Here, an end-to-end soft-

ware/ service is acquired and tuned. Customers

only need to carry out a limited set of tuning

activities that are typically related to the subject

area, while a service provider or a system integra-

tor ensures the effectiveness of the technical (and

domain-independent) phases of the SBI process.

• Level 3: Off-the-Shelf. This type of projects con-

sists in adopting, typically in a as-a-service man-

OCCURRENCE

totalOcc

positiveOcc

negativeOcc

avgSentiment

Date Month Year

Source

Media Type

Clip

Author

Country

Sex

Language

Topic

Figure 2: A DFM representation of an SBI cube reporting

information about the occurrence of a speciﬁc topic in a spe-

ciﬁc text.

ner, an off-the-shelf solution supporting a set of

reports and dashboards that can satisfy the most

frequent user needs in the SBI area (e.g., average

sentiment, top topics, trending topics, and their

breakdown by source/author /sex). With this ap-

proach the customer has a very limited view of the

single activities that constitute the SBI process, so

she has little or no chance of positively impact-

ing on activities that are not directly related to the

analysis of the ﬁnal results.

Moving from level 1 to 3, projects require less techni-

cal capabilities from customers and ensure a shorter

set-up time, but they also allow less control of the

overall effectiveness and less ﬂexibility in analyzing

the results.

3 MODELING SBI DATA

The main goal of SBI is to allow OLAP paradigm to

be applied to social/textual data. As shown in the pre-

vious section some proposals for a multidimensional

modeling of SBI data has been provided but all of

them lacks in providing the required expressiveness.

A key role in the analysis of textual UGC is played by

topics, meant as speciﬁc concepts of interest within

the subject area. Users are interested in knowing how

much people talk about a topic, which words are re-

lated to it, if it has a good or bad reputation, etc. Thus,

topics are obvious candidates to become a dimension

of the cubes for SBI. A simple example of an SBI

cube is reported in Figure 2. Apart from the Topic hi-

erarchy, the meta-data retrieved by the crawling mod-

ule has been modeled thus, for example, the average

sentiment about a speciﬁc group of topics can be ana-

lyzed for different Media Types. Like for any other di-

mension, users are very interested in grouping topics

together in different ways to carry out more general

and effective analyses —which requires the deﬁnition

of a topic hierarchy that speciﬁes inter-topic roll-up

(i.e., grouping) relationships so as to enable aggrega-

tions of topics at different levels.

Example 1. A marketing analyst wants to analyze

people’s feelings about mobile devices and relate

them to the selling trends. A basic cube she will use

to this purpose is the one counting, within the textual

UGC, the number of occurrences of each topic related

to subject area “mobile technologies”, distinguishing

between those expressing positive/negative sentiment

as labeled by an opinion mining algorithm (see Fig-

ure 2). Figure 3-right shows a set of topics for mobile

technologies and their roll-up relationships: when

computing the brand reputation for the topic “Sam-

sung”, decision makers may wish to also include oc-

currences of topics “Galaxy III” and “Galaxy Tab”,

while when analyzing users’ concerns about “Galaxy

III” she want to consider comments about its parts.

However, topic hierarchies are different from tra-

ditional hierarchies (like the temporal and the geo-

graphical one) in several ways:

♯1 Also non-leaf topics can be related to facts (e.g.,

clips may talk of smartphones as well as of the

Galaxy III) (Dayal et al., 2012). This means that

grouping topics at a given level may not determine

a total partitioning of facts (Pedersen et al., 2001).

Besides, topic hierarchies are unbalanced, i.e., hi-

erarchy instances can have different lengths.

♯2 Trendy topics are heterogeneous (e.g., they could

include names of famous people, products, places,

brands, etc.) and change quickly over time (e.g., if

at some time it were announced that using smart-

phones can cause ﬁnger pathologies, a brand new

set of hot unpredicted topics would emerge during

the following days), so a comprehensive schema

for topics cannot be anticipated at design time and

must be dynamically deﬁned.

♯3 Roll-up relationships between topics can have dif-

ferent semantics: for instance, the relationship se-

mantics in “Galaxy III has brand Samsung” and

“Galaxy III has type smartphone” is quite differ-

ent. In traditional hierarchies this is indirectly

modeled by leaning on the semantics of aggre-

gation levels (“Smartphone” is a member of level

Type, “Samsung” is a member of level Brand).

In light of the above, topic hierarchies in ROLAP

contexts must clearly be modeled with more sophis-

ticated solutions than traditional star schemata. In

(Gallinucci et al., 2013) we proposed meta-star; its

basic idea is to use meta-modeling coupled with nav-

igation tables and with traditional dimension tables.

On the one hand, navigation tables easily support hi-

erarchy instances with different lengths and with non-

leaf facts (requirement ♯1), and allow different roll-

up semantics to be explicitly annotated (requirement

♯3); on the other, meta-modeling enables hierarchy

heterogeneity and dynamics to be accommodated (re-

quirement ♯2). An obvious consequence of the adop-

tion of navigation tables is that the total size of the

solution increases exponentially with the size of the

topic hierarchy. This clearly limits the applicability of

the meta-star approach to topic hierarchies of small-

medium size; however, we argue that this limitation

is not really penalizing because topic hierarchies are

normally created and maintained manually by domain

experts, which suggests that their size can hardly be-

come too large.

In the remainder of this section we provide a for-

mal deﬁnition of the topic hierarchy related concepts.

Deﬁnition 1. A hierarchy schema S is a couple of a

set L of levels and a roll-up partial order ≻ of L. We

will write l

≻l

to emphasize that l

is an immediate

predecessor of l

in ≻.

Example 2. In Example 1 it is L = {Product,

Type, Category, Brand, Component} and

Component

≻Product

≻Type

≻Category,

Product

≻Brand (see Figure 3-left).

The connection between hierarchy schemata (in-

tension) and topic hierarchies (extension) is captured

by Deﬁnition 2, that also annotates roll-up relation-

ships with their semantics.

Deﬁnition 2. A topic hierarchy conformed to hierar-

chy schema S = (L,≻

) is a triple of (i) an acyclic

directed graph H = (T,R), where T is a set of top-

ics and R is a set of inter-topic roll-up relationships;

(ii) a partial function Lev : T → L that associates

some topics to levels of S ; and (iii) a partial func-

tion Sem : R → ρ that associates some roll-up rela-

tionships to their semantics (with ρ being a list of

user-deﬁned roll-up semantics). Graph H must be

such that, for each ordered pair of topics (t

) ∈ R

such that Lev(t

) = l

and Lev(t

) = l

, it is l

≻l

and

∀(t

) ∈ R, Lev(t

) 6= l

The intuition behind the constraints on H is that

inter-topic relationships must not contradict the roll-

up partial order and must have many-to-onemultiplic-

ity. For instance, the arc from “Galaxy III” to “Smart-

phone” is correct because Product

≻Type, but there

could be no other arc from “Galaxy III” to a topic

of level Type. In the same way, no arc from a product

to a category is allowed; the arc from “Galaxy III” to

“Touchscreen” is allowed because the latter does not

belong to any level.

Finally, Deﬁnition 3 provides a compact represen-

tation for the semantics involved in any path of a topic

hierarchy.

Smartphone

Galaxy IIILumia 920

Samsung

Nokia

8MP Camera

4.8in Display

hasBrand

hasType

isPartOf

hasBrand

Mobile Tech

Tablet

hasCategory

hasType

Brand

Category

Type

Product

Component

E5

Galaxy Tab

Touchscreen

Finger Pathologies

causedBy

has

Figure 3: The annotated topic hierarchy for the mobile tech-

nology subject area.

Deﬁnition 3. Given topic t

such that Lev(t

) = l

and given level l

such that l

≻ l

, we denote with

Anc

) the topic t

such that Lev(t

) = l

and t

reached from t

through a directed path P in H. The

roll-up signature of couple (t

) is a binary string

of |ρ| bits, where each bit corresponds to one roll-up

semantics and is set to 1 if at least one roll-up re-

lationship with that semantics is part of P, is set to

0 otherwise. Conventionally, the roll-up signature of

(t,t) is a string of 0’s for each t.

Example 3. In Figure 3 the topic hierar-

chy on the right-hand side is annotated with

levels and roll-up semantics; for instance,

it is Anc

Brand

(8MP Camera) = Samsung,

Anc

Type

(8MP Camera) = Smartphone. Note that

topics “Touchscreen” and “Finger Pathologies” do

not belong to any level. If ρ = (isPartOf, hasType,

hasBrand, hasCategory, has, causedBy), then the

roll-up signature of (8MP Camera, Samsung) is

101000 (because the path from “8MP Camera”

to “Samsung” includes roll-up relationships with

semantics isPartOf and hasBrand), that of (8MP

Camera, Smartphone) is 110000.

Topic hierarchies can be implemented on a RO-

LAP platform combining classical dimension tables

with recursive navigation tables and extends the re-

sult by meta-modeling. Remarkably, the designer can

tune the solution by deciding which levels L

stat

⊆ L

are to be modeled also in a static way, i.e., like in

a classical dimension table. Two different tables are

used:

1. A topic table storing one row for each distinct

topic t ∈ T. The schema of this table includes

a primary surrogate key IdT, a Topic column, a

Level column, and an additional column for each

static level l ∈ L

stat

. The row associated to topic t

has Topic= t and Level= Lev(t). Then, if Lev(t) ∈

stat

, that row has value t in column Lev(t), value

Anc

(t) in each column l such that l ∈ L

stat

and

Lev(t) ≻ l, and NULL elsewhere.

TOPIC

IdT Topic Level Product Type Category

1 8MPCamera Component – – –

2 GalaxyIII Product GalaxyIII Smartph. MobTech

3 GalaxyTab Product GalaxyTab Tablet MobTech

4 Smartphone Type – Smartph. MobTech

5 Tablet Type – Tablet MobTech

6 MobileTech Category – – MobTech

7 Samsung Brand – – –

8 Finger Path. – – – –

9 Touchscreen – – – –

... ... ... ... ... . ..

ROLLUP T

ChildId FatherId RollUpSignature

1 1 000000

2 2 000000

... ... 000000

1 2 100000

2 4 010000

2 7 001000

4 6 000100

8 9 000001

2 9 000010

... ... ...

1 4 110000

1 7 101000

1 9 100010

2 6 010100

3 6 010100

... ... ...

1 6 110100

... ... ...

Figure 4: Meta-star modeling for the mobile technology

subject area.

2. A roll-up table storing one row for each topic in

T and one for each arc in the transitive closure

of H. The row corresponding to topic t has two

foreign keys, ChildId and FatherId, that reference

the topic table and both store the surrogate of topic

t, and a column RollUpSignature that stores the

roll-up signature of (t,t), i.e., a string of 0’s. The

row corresponding to arc (t

) stores in ChildId

and FatherId the two surrogates of topics t

and t

while column RollUpSignature stores the roll-up

signature of (t

Example 4. The topic and the roll-up tables for

the topic hieerarchy in Figure 3 when L

stat

{Product,Type, Category} are reported in Figure 4.

The eleventh row of the roll-up table states that the

roll-up signature of couple (8MP Camera, Smart-

phone) is 110000, i.e., that the path from one topic

to the other includes semantics isPartOf and hasType.

Meta-stars also better support topic hierarchy dy-

namics, through the combined use of meta-modeling

and of the roll-up table. A whole new set of emerging

topics, possibly structured in a hierarchy with differ-

ent levels, can be accommodated —without changing

the schema of meta-stars— by adding new values to

the domain of the Level column, adding rows to the

topic and the roll-up tables to represent the new top-

ics and their relationships, and extending the roll-up

signatures with new bits for the new roll-up seman-

tics. The newly-added levels will immediately be-

come available for querying and aggregation.

Meta-stars yield higher querying expressiveness,

at the cost of a lower time and space efﬁciency.

Surprisingly the tests we carried out in (Gallinucci

et al., 2013) have shown that though, as expected,

in most cases traditional star schemata out-perform

meta-stars, the time execution gap is quite limited and

perfectly acceptable in terms of on-line querying.

4 A METHODOLOGY FOR SBI

PROJECTS

SBI has emerged as an application and research ﬁeld

in the last few years and there is no agreement yet

on how to organize the different design activities. In-

deed, in real SBI projects, practitioners typically carry

out a wide set of task but they lack an organic and

structured view of the design process. The speciﬁci-

ties that distinguish a BI project from an SBI one are

listed below:

• SBI projects call for an effective and efﬁcient

support to maintenance iterations, because of the

huge dynamism of the UGC and of the pressing

need of immediately perceiving and timely react-

ing to changes in the environment.

• The schema of the data and the ETL ﬂows are in-

dependent of the project domain and the changes

are mainly related to the meta-data made available

by the crawling and the semantic enrichment en-

gines.

• The complexity of different tasks and the subjects

who are in charge of them are strongly related to

the type of project implemented.

The iterative methodology we have proposed in

(Francia et al., 2014) (see Figure 5) is aimed at letting

harmoniously coexist all the activities involved in an

SBI project. These activities are to be carried out in

tight connection one to each other, always keeping in

mind that each of them heavily affects the overall sys-

tem performance and that a single problem can easily

neutralize all other optimization efforts.

Besides speeding up the initial design of an SBI

process, the methodology is aimed at maximize the

effectiveness of the user analyses by continuously op-

timizing and reﬁning all its phases. These mainte-

semantic track

ETL &

OLAP

Design

Source

Selection

ontology/

dictionary

ETL &

reports

Macro-Analysis

Ontology

Design

Crawling

Design

Execution

Selectio

Crawling

Design

mantic track

ntic t ck

Semantic

Enrichment

Design

Semantic

data track

crawling track

Crawling

sources

domain

ontology

ETL

inquiries

Ontology

Desi

subj. area,

threads, topics

templates,

queries

Execution Execution

Execution

clips

enriched

clips

key

figures

Test

Execution

clips

Execution

enriched

clips

what how

where

Figure 5: Functional view of our methodology for SBI de-

sign.

nance activities are necessary in SBI projects because

of the continuous environment variability which asks

for high responsiveness. This variability impacts ev-

ery single activity, from crawling design to semantic

enrichment design, and leads to constantly having to

cope with changes in requirements.

In the following we brieﬂy describe the main fea-

ture of each activity, for a more detailed description

refer to (Francia et al., 2014).

1. Macro-Analysis: during this activity, users are in-

terviewed to deﬁne the project scope and the set

of inquiries the system will answer to. An inquiry

captures an informative need of a user; from a

conceptual point of view it is speciﬁed by three

components: what, i.e., one or more topic on

which the inquiry is focused (e.g., the Galaxi III);

how, i.e., the type of analysis the user is inter-

ested in (e.g., top related topics); where, i.e., the

data sources to be searched (e.g., the Technology-

related web forums).

Inquiries drive the deﬁnition of subject area,

themes, and topics. As said before, the subject

area of a project is the domain of interest for the

users (e.g., Mobile Technology), meant as the set

of themes about which information is to be col-

lected. A theme (e.g., Tablet reputation) includes

a set of speciﬁc topics (e.g., Touchscreen). Lay-

ing down themes and topics at this early stage is

useful as a foundation for designing a core taxon-

omy of topics during the ﬁrst iteration of ontol-

ogy design; themes can also be used to enforce

an incremental decomposition of the project. In

practice, this activity should also produce a ﬁrst

assessment of which sources cannot be excluded

from the source selection activity since they are

considered as extremely relevant (e.g., the corpo-

rate website and Facebook pages).

2. Ontology Design: during this activity, customers

work on themes and topics to build and reﬁne

the domain ontology that models the subject area.

Noticeably, the domain ontology is not just a list

of keywords; indeed, it can also model relation-

ships (e.g., hasKind, isMemberOf) between top-

ics. Once designed, this ontology becomes a key

input for almost all process phases: semantic en-

richment relies on the domain ontology to better

understand UGC meaning; crawling design ben-

eﬁts from topics in the ontology to develop bet-

ter crawling queries and establish the content rel-

evance; ETL and OLAP design heavily uses the

ontology to develop more expressive, comprehen-

sive, and intuitive dashboards.

3. Source Selection: is aimed at identifying as many

web domains as possible for crawling. The set

of potentially relevant sources can be split in two

families: primary sources and minor sources. The

ﬁrst set includes all the sources mentioned during

the ﬁrst macro-analysis iteration, namely: (1) the

corporate communication channels (e.g. the cor-

porate website, Facebook page, Twitter account);

(2) the generalist sources, such as the online ver-

sion of the major publications. The user-base of

minor sources is smaller but not less relevant to

the project scope. Minor sources include lots of

small platforms which produce valuable informa-

tion with high informative value because of their

major focus on themes related to the subject area.

The two main subsequent tasks involved in this

activity are:

• Template design consists in an analysis of the

code structure of the source website to enable

the crawler to detect and extract only the infor-

mative UGC (e.g., by excluding external links,

advertising, multimedia, and so on).

• Based on the templates designed, query design

develops a set of queries to extract the relevant

clips. Normally, these are complex Boolean

queries that explicitly mention both relevant

keywords to extract on-topic clips and irrele-

vant keywords to exclude off-topic clips.

Note that ﬁltering off-topic clips at crawling time

could be difﬁcult due to the limitations of the

crawling language, and also risky because the in-

topic perimeter could change during the analysis

process. For these reasons, the team can choose to

release some constraints aimed at letting a wider

set of clips “slip through the net”, and only ﬁl-

ter them at a later stage using the search features

of the underlying document DBMS (e.g., Mon-

goDB).

4. Semantic Enrichment Design: involves several

tasks whose purpose is to increase the accuracy

of text analytics so as to maximize the process ef-

fectiveness in terms of extracted entities and sen-

timent assigned to clips; entities are concepts that

emerge from semantic enrichment but are not part

of the domain ontology yet (for instance, they

could be emerging topics). The speciﬁc tasks

to be performed depend on the semantic engine

adopted and on how semantic enrichment is car-

ried out.

In general, two main tasks that enrich and improve

its linguistic resources can be distinguished:

• Dictionary enrichment, that requires including

new entities missing from the dictionary and

changing the sentiment of entities (polariza-

tion) according to the speciﬁc subject area (e.g.,

in “I always eat fried cutlet”, the word “fried”

has a positive sentiment, but in the food mar-

ket area a sentence like “These cutlets taste like

fried” should be tagged with a negative senti-

ment because fried food is not considered to be

healthy).

• Inter-word relation deﬁnition, that establishes

or modiﬁes the existing semantic, and some-

times also syntactic, relations between words.

Relations are linguistically relevant because

they can deeply modify the meaning of a word

or even the sentiment of an entire sentence

determining the difference between right and

wrong interpretation (e.g., “a Pyrrhic victory”

has negative sentiment though “victory” is pos-

itive).

Modiﬁcations in the linguistic resources may pro-

duce undesired side effects; so, after completing

these tasks, a correctness analysis should be ex-

ecuted aimed at measuring the actual improve-

ments introduced and the overall ability of the

process in understanding a text and assigning the

right sentiment to it. This is normally done, using

regressive test techniques, by manually tagging an

incrementally-built sample set of clips with a sen-

timent.

5. ETL & OLAP Design: The main tasks in this ac-

tivity are:

• ETL design and implementation, that strongly

depends on features of the semantic engine, on

the richness of the meta-data retrieved by the

crawler (e.g., URLs, author, source type), and

on the possible presence of speciﬁc data acqui-

sition channels such as CRM.

• KPI design; different kinds of KPIs can be

designed and calculated depending on which

kinds of meta-data the crawler fetches.

• Dashboard design, during which a set of re-

ports is built that captures the user needs ex-

pressed by inquiries during macro-analysis.

6. Execution and Test: has a basic role in the

methodology, as it triggers a new iteration in the

design process. Crawling queries are executed,

the resulting clips are processed, and the reports

are launched over the enriched clips. The speciﬁc

tests related to each single activity, described in

the preceding subsections, can be executed sepa-

rately thoughthey are obviouslyinter-related. The

ﬁrst test executed is normally the one of crawling;

even after a ﬁrst round, the semantic enrichment

tests can be run on the resulting clips. Similarly,

when the ﬁrst enriched clips are available, the test

of ETL and OLAP can be triggered.

The analysis of the outcomes of a set of case stud-

ies (Francia et al., 2014) has shown that the adoption

of a proper methodology strongly impacts on the ca-

pability of keeping under control execution time, re-

quired resources and effectiveness of the results. In

particular the key points of the proposed methodol-

ogy are: (1) a clear organization of goals and tasks

for each activity, (2) the adoption of a protocol and a

set of templates to record and share information be-

tween activities and (3) the implementation of a set of

tests to be applied during the methodology phases.

5 CONCLUSIONS

In this paper we discussed some of the key issues

related to the emerging area of SBI. Although some

commercial solutions is already available, this types

of applications deserve further investigations. SBI

is at the crossroad between different disciplines, this

makes researches more challenging but it potentially

opens to more interesting results.

REFERENCES

Castellanos, M., Dayal, U., Hsu, M., Ghosh, R., Dekhil, M.,

Lu, Y., Zhang, L., and Schreiman, M. (2011). LCI:

a social channel analysis platform for live customer

intelligence. In Proc. SIGMOD, pages 1049–1058.

Dayal, U., Gupta, C., Castellanos, M., Wang, S., and

Garc´ıa-Solaco, M. (2012). Of cubes, DAGs and hi-

erarchical correlations: A novel conceptual model for

analyzing social media data. In Proc. ER, pages 30–

49.

Francia, M., Golfarelli, M., and Rizzi, S. (2014). A method-

ology for social bi. In Proc. IDEAS.

Gallinucci, E., Golfarelli, M., and Rizzi, S. (2013). Meta-

stars: multidimensional modeling for social business

intelligence. In Proc. DOLAP, pages 11–18.

Garca-Moya, L., Kudama, S., Aramburu, M., and Berlanga,

R. (2013). Storing and analysing voice of the mar-

ket data in the corporate data warehouse. Information

Systems Frontiers, 15(3):331–349.

Garc´ıa-Moya, L., Kudama, S., Aramburu, M. J., and Lla-

vori, R. B. (2013). Storing and analysing voice of the

market data in the corporate data warehouse. Informa-

tion Systems Frontiers, 15(3):331–349.

Lee, J., Grossman, D. A., Frieder, O., and McCabe, M. C.

(2000). Integrating structured data and text: A multi-

dimensional approach. In Proc. ITCC, pages 264–271.

Liu, B. and Zhang, L. (2012). A survey of opinion mining

and sentiment analysis. In Mining Text Data, pages

415–463. Springer.

Pang, B., Lee, L., and Vaithyanathan, S. (2002). Thumbs

up? sentiment classiﬁcation using machine learning

techniques. In Proc. EMNLP, volume 10, pages 79–

86.

Pedersen, T. B., Jensen, C. S., and Dyreson, C. E. (2001). A

foundation for capturing and querying complex multi-

dimensional data. Inf. Syst., 26(5):383–423.

Ravat, F., Teste, O., Tournier, R., and Zurﬂuh, G. (2008).

Top keyword: An aggregation function for textual

document OLAP. In Proc. DaWaK, pages 55–64.

Rehman, N., Mansmann, S., Weiler, A., and Scholl, M.

(2012a). Building a data warehouse for twitter stream

exploration. In Advances in Social Networks Analy-

sis and Mining (ASONAM), 2012 IEEE/ACM Interna-

tional Conference on, pages 1341–1348.

Rehman, N. U., Mansmann, S., Weiler, A., and Scholl,

M. H. (2012b). Building a data warehouse for Twitter

stream exploration. In Proc. ASONAM, pages 1341–

1348.

Taboada, M., Brooke, J., Toﬁloski, M., Voll, K. D., and

Stede, M. (2011). Lexicon-based methods for senti-

ment analysis. Computational Linguistics, 37(2):267–

307.

Zhang, D., Zhai, C., and Han, J. (2009). Topic Cube:

Topic modeling for OLAP on multidimensional text

databases. In Proc. SDM, pages 1123–1134.

BRIEF BIOGRAPHY

Matteo Golfarelli received the Ph.D. degree for his

work on autonomous agents in 1998 from the Uni-

versity of Bologna. Since 2005, he is an associate

professor in the same University, teaching informa-

tion systems, database systems, and data mining. He

has published more than 90 papers in refereed jour-

nals and international conferences in the ﬁelds of pat-

tern recognition, mobile robotics, multi-agent sys-

tems, and business intelligence that is now his main

research ﬁeld. Within this area, in the last 15 years he

explored many relevant topics such as collaborative

and pervasive BI, temporal Data Warehouses, phys-

ical and conceptual Data Warehouse design. In par-

ticular he proposed the Dimensional Fact Model a

conceptual model for Data Warehouse systems that is

widely used in both academic and industrial contexts.

His current research interests include distributed and

semantic data warehouse systems, and social business

intelligence and open data warehouses. He joined

several research projects on the above areas and has

been involved in the PANDA thematic network of

the European Union concerning pattern-base manage-

ment systems.
