Multi-Algorithmic Approaches to Gene Expression Binarization

Jaime Seguel

Department of Electrical and Computer Engineering, University of Puerto Rico at Mayagüez, Mayagüez, Puerto Rico

Keywords: Gene Expression, Expression Threshold, Algorithm, Binarization, Aggregation.

Abstract: A basic problem in the construction of network representations of gene interactions is deciding whether a

gene is or is not expressed at a time instant. This problem, referred here as the gene expression decision

problem, has been approached with statistical and numerical algorithms. Numerical methods are based on

different intuitions on what signals a gene expression threshold and as a consequence, they often return

different answers. Consequently, the choice of a particular gene expression decision algorithm influences

the gene interaction model. This article proposes an aggregation methodology for numerical gene

expression decision algorithms that is based on voting. The result is thus, the expression decision made by

the majority of the algorithms, provided that that decision is consistent with an underlying logical law

referred as the doctrine. The proposed method is compared with some non-voting aggregation algorithms.

1 INTRODUCTION

Most of the physical and biochemical traits of a

living being can be traced back to its genetic make-

up through mRNA counts. An mRNA concentration

is the result of intricate cascades of stochastic

cellular processes that start with the transcription of

information stored in the genes. For this reason,

mRNA counts are referred as gene expressions.

Although posttranscriptional events may alter the

correlation between mRNA and their related

proteins (Greenbaum et al., 2003) gene expression

data still provide valuable insights on the

transcriptional process in the cell. Transcription

networks models such as Boolean and Probabilistic

Boolean networks, are usually derived from, and

validated with time series of gene expressions

(Bornholdt, 2008); (Kim et al., 2013); (Shmulevich

et al., 2010).

Gene expression data is normally obtained with

DNA microarrays (Tarca et al., 2006), quantitative

polymerase chain reactions (qPCR) (Derveaux et al.,

2010), or next generation sequencing experiments

(Matsumura et al., 2005); (Yamamoto et al., 2001).

DNA microarray methods are based on

hybridization of dyed mRNA samples to probes, and

the measurements of the intensities of a fluorescent

signal. The intensities are, in turn, correlated with

the amount of mRNA in the sample through a

complex protocol that involves a number of ad-hoc

decisions on data analysis methods, background

noise eliminations, and other error pruning

considerations. Just as microarrays, qPCR methods

are based on hybridizations and intensity

measurements of fluorescent signals. But unlike

microarrays, qPCR detection is made in real-time,

with each cycle of amplification. Quantitative PCR

is, in general, faster and more sensitive than

microarrays, and requires lower amounts of material.

Both, microarray and qPCR methods quantify only a

selected number of transcripts. Next generation

sequencing is capable of quantifying all the mRNA

in a cell sample. The expression levels returned by

these methods are basically free of correlation errors

and background noise elimination, as they do not

involve the transformation of signal intensities into

estimations on the number of transcripts.

Gene expression changes with time and

biological context. Thus, capturing meaningful

information requires a sequence of experiments

whose results are reported in a gene expression

array (GEA). A GEA with N experiments on a set of

M genes is a M × N array G = [G(k, j)]. Each row

corresponds to a gene, and each column to a

different experiment or condition. The k-th row in G

is called expression profile of gene k.

The gene expression decision problem (GEDP) is

stated as follows: “For each entry G(k, j) in a GEA,

decide whether gene k is or is not expressed at

condition j”.

It is worth remarking that GEDP is much harder

to solve than the problem of detecting over

109

Seguel J..

Multi-Algorithmic Approaches to Gene Expression Binarization.

DOI: 10.5220/0005203701090115

In Proceedings of the International Conference on Bioinformatics Models, Methods and Algorithms (BIOINFORMATICS-2015), pages 109-115

ISBN: 978-989-758-070-3

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

expressed genes that commonly arises in the search

for disease biomarkers. GEDP answers are

presented, in turn, as a M × N array B = [B(k, j)],

where B(k, j) = 1 if the k-th gene is expressed at

condition j and B(k, j) = 0, otherwise. Because of the

currently limited knowledge of the cell inner

mechanisms and the stochastic nature of the events

that lead to gene expressions, matrix B is more a

hypothesis on the states and transitions of the gene

expressions than a deterministic fact. Nonetheless,

these hypotheses are often formulated with the help

of deterministic data analysis algorithms that mine

each expression profile in G for signals of an

expression threshold t. Once a threshold t is

determined for the expression profile of gene k, the

k-th row of B is produced by assigning 1 to the j-th

entry if G(k, j) > t, and 0, otherwise.

Several algorithms based on different data

mining methodologies and conjectures on the

features in the data that signal an expression

threshold, have been designed. Their results are

often significantly different (Seguel et al., 2013).

In this article, I propose a wisdom-of-crowds

methodology for aggregating these algorithmic

decisions. The methodology is based on a

mathematical structure that I call multi-algorithm

aggregation scheme (MAS). MAS is inspired in the

logic underlying collective decision-making by

voting. MAS is a true alternative to average, median,

and other common aggregation formulas, as it

provides flexibility to select the voting method and a

decision-making rule, referred as doctrine. This

flexibility turns the method into an analytical tool;

capable of testing the data with different decision-

making parameters. As a mathematical structure,

MAS can be used in applications other than gene

expression decisions.

The rest of this article is organized as follows:

Section 2 is a brief description of the algorithms

selected for the proposed multi-algorithmic scheme,

together with some basic time and space complexity

analysis. Section 3 is a mathematical description of

MAS and its implementation for solving the gene

expression decision problem. Section 4 reports the

results of experiments and comparisons between

MAS and other aggregation rules, and Section 5

summarizes some conclusions of this work.

2 SOME GENE EXPRESSION

DECISION ALGORITHMS

The gene expression decision algorithms that are the

basis of the proposed multi-algorithm method can be

classified in three main groups. The first group,

referred as jump-based methods, consists of four

algorithms that determine the threshold on the basis

of a jump in the values of the gene expression

profile. Methods in this group are labelled J1, J2, J3

and J4. The second group consists of three

algorithms that determine a threshold on the basis of

approximations to the gene expression profile by

one-step functions. These algorithms are denoted S1,

S2 and S3 and are called one-step methods. The

threshold returned by one-step methods is the

midpoint of the steps in the one-step approximation

mapping whose values are further apart.

The third group consists of two data clustering

methods, both based on Lloyd’s algorithm. These

methods are labelled C1 and C2. Next are high-level

descriptions of each of these methods.

2.1 Jump-based Methods

Algorithm J1 sorts the input expression profile in

increasing order, and sets as threshold the midpoint

between the smallest and the highest jump in the

data. Algorithm J2 is introduced in (Shmulevich et

al., 2002) The method sorts the expression profile in

increasing order and computes the average of all

data jumps. Then, it sets as threshold the first value

that exceeds the average. Algorithm J3 is a variant

of Algorithm J2 that replaces the first value that

exceeds the average data jump with the mean of all

the values that exceed the average of the data jumps.

The main advantages of algorithms J1, J2 and J3

are conceptual and computational simplicity. In fact,

they all return the M thresholds of a M × N array G

in O(MN) time, using O(N) space. Algorithm J4 is

more complex. This method is an implementation of

the Binarization Across Multiple Scales (BASC)

algorithm (Hopfensitz et al., 2011). BASC

approximates the input expression profile sorted in

increasing order with a sequence of step functions,

each with a different number of steps. It starts with

the step function that fits exactly the input data.

Then, it produces a sequence of step functions, each

with one less step than the previous one. Dynamic

programming is used to ensure that each new step

function minimizes the Euclidian distance to the

sorted expression profile. For each step function in

the sequence, the ratio between the highest step

jump and the Euclidean distance of the step function

to the input data is computed. A high ratio is

declared to be a strong discontinuity and its index is

saved in a vector v. Then, the method computes the

median m of the indices in v and defines the

threshold as the average of the data point indexed by

m and m + 1.

BIOINFORMATICS2015-InternationalConferenceonBioinformaticsModels,MethodsandAlgorithms

110

Algorithm J4 returns the M thresholds of a M ×

N input array G in O(MN

) time, using O(MN

)

space.

2.2 One-Step Approximations

The first method in this group, called Algorithm S1

is inspired on StepMiner (Sahoo et al., 2007).

StepMiner adjust a one-step or a two-step function

to the data using linear regression with (3, N – 1)

degrees of freedom. The least square errors of the

approximations provide a set of F-statistics, whose

P-value is used for deciding whether the error is

significant. StepMiner is not intended to solve

GEDP. Algorithm S1 adjusts a one-step function to

the expression profile sorted in increasing order,

using StepMiner’s methodology, and a preset

significance of .05. If the subset of one-step

mappings satisfying this constraint is empty, the

method returns Not a Number (NaN). Otherwise, the

method selects the step function whose steps are

further apart, and sets the midpoint between the

function’s steps as the threshold.

Algorithm S2 sorts the input vector in increasing

order. Then, for each j from 1 to N – 1, computes the

median of the data points from 1 to j and that the

data points from j + 1 to N. Then, it finds the index

m where the difference of the medians is maximal,

and sets the threshold as the midpoint between the

data points indexed by m and m + 1. Finally,

Algorithm S3 does the same as algorithm S2 but

using the mean instead of the median. All step

methods return the M thresholds of a M × N input

array G in O(MN

) time, using O(MN) space.

2.3 Clustering Methods

Two methods are in this group. The first classifies a

expression profile in two clusters using Lloyd’s

algorithm, also known k-means clustering. The

algorithmic threshold is implicit, in the sense that the

method splits the expression profile in two clusters,

each centred around a different centroid; without

computing a threshold. Algorithm C1 sets as

threshold the mid-point between the cluster’s

centroids.

Algorithm C2 implements the iterative clustering

variant of Lloyd’s algorithm proposed in

(Berestovsky et al., 2013) as a way to smooth data

oscillations. C2 starts with an application of the 2

means cluster algorithm to the input data. Here d is a

user-defined parameter, whose sole restriction is that

cannot be greater than the length of the expression

profile. After computing the initial 2

clusters, the

algorithm replaces each element in a cluster with the

cluster’s mean, and applies the 2

d–1

–means cluster

algorithm to the resulting data. This process is

repeated until d = 1.

As in Algorithm C1, the threshold returned by

Algorithm C2 is the mid-point between the centroids

of the two clusters at the end of the iterations.

2.4 Threshold Correlations

In order to assess similarities and differences in the

threshold values returned by the above algorithms,

the thresholds of one thousand random 16-point

vectors were computed for each algorithm. It was

observed that the histograms for the threshold values

presented significantly different shapes, and that the

correlations among observed threshold values were

very weak except in the cases of S1 and S3, and C1

and C2 (Seguel et al., 2014). Scatter plots produced

with this data confirmed that the threshold values

returned by the rest of the algorithms do not have

large correlations.

2.5 Threshold Displacements

In time-course data, it is natural to think of the

expression profile as an N-point sample of a

continuous gene expression function that takes

values in a time interval. The size N of the sample

may alter significantly the value of the expression

threshold. This dependence of the threshold on N

can be incorporated in a GEDP method through a

statistical estimation of the threshold displacement

as a function of N.

Table 1: Expected threshold displacements.

Algorithm

Expected

displacement

Variance

J1 0.4609 0.0187

J2 0.7602 0.0516

J3 0.6709 0.0358

J4 0.2474 0.0069

S1 0.1034 0.0122

S2 0.3004 0.0359

S3 0.2777 0.0393

C1 0.1250 0.0001

C2 0.1552 0.0023

I call threshold displacement the maximum

distance between the threshold computed with a

sample of size N = 2

+ 1, n > 2; and the set of all

the thresholds obtained by successively filtering

each other data point until n = 1. The expected value

of the threshold displacement for each of the nine

algorithms was computed with four hundred random

+ 1)-point random vectors, with n = 12 for all

methods except for J4. Because of space and time

Multi-AlgorithmicApproachestoGeneExpressionBinarization

111

limitations, the threshold displacement for algorithm

J4 was computed with (2

+ 1)-point random

vectors, with n = 8. Table 1 reports the results.

Each expected displacement defines a threshold

uncertainty interval. A point in this interval is

declared to be not decidable. More precisely, if d is

the expected displacement of an algorithm, and t is

the threshold returned by the same algorithm on

input V, then a point G(k, j) in V is not decidable if

d  G(k, j )



t  d.

(1)

Algorithms with lower expected threshold

displacement will eventually decide a larger number

of points in the expression profile.

3 MULTI-ALGORITHMIC

SCHEMES

The core concepts in this section are borrowed from

theories developed in the context of economics,

jurisprudence and sociology (List, 2012). I define a

multi algorithmic scheme (MAS) as a quadruple (S,

A, R, D), where S is a finite set of decision

algorithms, A is a finite set of logic statements called

agenda, R is an aggregation rule, and D is a logical

equivalence describing the fact to be determined in

terms of the statements in the agenda. D is referred

as the doctrine. Each algorithm in S decides whether

each of the statements in A is true or false. The set of

these decisions is called algorithmic judgment.

An aggregation rule is a method for determining

a collective judgment from the set of all algorithmic

judgments. Some common aggregation rules are

majority, supermajority, unanimity and dictatorship.

Under majority rule, the truth-value in the collective

judgment is the truth-value of at least one half plus

one of the algorithmic judgments. Under

supermajority, the collective judgment is the truth-

value of a preset number of algorithmic judgments

that is greater than half plus one of the algorithms,

and under unanimity, the truth-value of the

collective judgment is to be shared by all

algorithmic judgments. Dictatorship, in turn,

imposes in the collective judgment the truth-value of

a fixed, preselected algorithm. Thus, dictatorship is a

degenerate or trivial aggregation rule.

A central concept in aggregation theory is

consistency. In its simplest form, consistency refers

to the preservation of the rules of logic when a

doctrine is valuated with the truth-values of the

collective judgments. The theory of aggregation

devotes a significant effort to the search for

conditions in the agenda under which non-trivial

aggregation rules produce consistent judgments. In

this work, however, no consistency requirement is

imposed on the agenda. Instead, MAS interprets

inconsistent collective judgments as instances of the

GEDP that are collectively not decidable.

Not decidable and collectively not decidable

points add a third option in the binary vector B that

is denoted NaN (not a number). From the

perspective of an answer to a GEDP, NaN entries in

B are normally considered to be noisy data points

and as such, are usually filtered out in subsequent

applications of the GEDP solution.

3.1 A MAS for the GEDP

Let S be a subset of {J

, J

, S

, C

the set of gene expression decision algorithms. The

previous discussion partitions the solution space of

the GEDP into decidable and not decidable data

points. Decidable points are further divided into

points that indicate an expressed gene state and

points that indicate that the gene is in unexpressed

state. Let A = {U, N}, where

(2)

and

(3)

Clearly U is true if and only if G(k, j) signals an

unexpressed gene, and N is true if G(k, j) is not

decidable. The doctrine D is set to be

(4)

Thus, E is true if and only if G(k, j) corresponds to

an expressed gene. Finally, R may be majority, a

super majority or the unanimity rule.

Table 2 illustrates a collective judgement that is

inconsistent with doctrine D.

Table 2: Example of inconsistent collective judgment.

Algorithm N U E

A 1 0 0

B 0 0 1

C 0 1 0

Majority 0 0 0

The algorithmic judgments of {N, U} are shown

in rows A, B and C, together with the valuations of

E. The forth row is the simple majority of votes on

each predicate. According with the majority, both

~N and ~U are true while E is false. This is

inconsistent with the doctrine as a true conjunction

is true. a semantic rule of Consequently, the data

point whose algorithmic and collective judgments

are shown in Table 2 is not decidable.



:"G(k, j )  t



| t



G(k, j )|  d"



: "|t



G(k, j )|  d".





BIOINFORMATICS2015-InternationalConferenceonBioinformaticsModels,MethodsandAlgorithms

112

4 SOME EXPERIMENTS

This section compares the resolution capabilities of

MAS against non-voting aggregation formulas. The

resolution is measured with a resolution score (RS),

defined as

RS(V, X)  1



ZN,

(5)

where Z is the number of points in an N-point

expression profile V that are not decided by method

X. The closer RS is to 1, the better the resolution of

X. All algorithms were implemented in Matlab

4.1 MAS-GEDP Pseudo Code

Next is a high-level description of MAS-GEDP.

On input V (an expression profile)

1. For each algorithm in S

Compute the threshold

2. For each data point in V

For each algorithm in S

i. Evaluate N, U and E

ii. Apply majority rule R

iii. Check consistency with D

iv. If inconsistent or N = 1, write NaN

in B

v. Else if E = 1, write 1 in B

vi. Else write 0 in B.

3. Output B

4.2 Non-voting Aggregation Formulas

I consider three non-voting aggregation formulas.

The first two use the average (AVG), and the

median (MED) of the thresholds, respectively. These

formulas decide all points. The third aggregation

formula decides that a point that is below the lowest

threshold returned by the algorithms in S is

unexpressed; a point that is above the highest

threshold of all algorithms in S is expressed, and a

point in between the lowest and highest thresholds is

not decidable. I refer to this method as below

minimum and above maximum (BMAM). Clearly,

0 ≤ RS(V, X) ≤ 1 whenever X is a MAS-GEDP or

BMAM.

Although BMAM is not a traditional aggregation

rule, it is a natural and simple way to aggregate the

algorithmic decisions.

4.3 Results

In this subsection I report the results returned by

AVG

, MED

, BMAM

, and MAS

, I = 1 or 2. Here

the label 1 indicates that the subset of algorithms is

{ 4, 1, 3, 1, 2}SJSSCC



(6)

These are algorithms whose expected threshold

displacement is less than 0.3. Methods labelled 2 use

the nine gene expression threshold algorithms.

MAS

uses simple majority while MAS

uses a

supermajority of four or more votes. Similarly,

MAS

uses simple majority while MAS

uses a

supermajority of six or more votes.

Table 3: Synthetic expression profile 1.

V 0.080 0.029 0.160 0.960 0.858 0.808

AVG

0 0 0 1 1 1

AVG

0 0 0 1 1 1

MED

0 0 0 1 1 1

MED

0 0 0 1 1 1

BMAM

0 0 0 1 1 1

BMAM

0 0 NaN 1 NaN NaN

MAS

0 0 0 1 1 1

MAS

0 0 0 1 1 1

MAS

0 0 0 1 1 1

MAS

0 0 0 1 1 1

Table 4: Synthetic expression profile 2.

V 0.452 0.402 0.502 0.622 0.770 0.809

AVG

0 0 0 1 1 1

AVG

0 0 0 1 1 1

MED

0 0 0 1 1 1

MED

0 0 0 1 1 1

BMAM

0 0 0 1 1 1

BMAM

0 0 0 NaN NaN 1

MAS

NaN 0 NaN NaN 1 1

MAS

NaN 0 NaN NaN NaN 1

MAS

NaN NaN NaN NaN NaN NaN

MAS

NaN NaN NaN NaN NaN NaN

Table 5: Synthetic expression profile 3.

V 0.143 0.279 0.459 0.654 0.813 0.906

AVG

0 0 0 1 1 1

AVG

0 0 0 1 1 1

MED

0 0 0 1 1 1

MED

0 0 0 1 1 1

BMAM

0 0 0 1 1 1

BMAM

0 0 0 1 1 1

MAS

0 0 NaN NaN 1 1

MAS

0 0 NaN NaN 1 1

MAS

0 NaN NaN NaN NaN 1

MAS

0 NaN NaN NaN NaN 1

The synthetic expression profile 1 approximates

a one-step function with rather distant steps;

synthetic expression profile 2 also approximates a

one-step function but with closer steps. Finally,

synthetic expression profile 3 approximates a

straight line with slope 1.

4.4 Some Statistics

The expected value of the resolution score of

Multi-AlgorithmicApproachestoGeneExpressionBinarization

113

BMAM and MAS methods were computed with 400

randomly generated 16-point expression profiles.

The expected resolution scores (5) and their variance

are shown in Table 6.

Table 6: Expected resolution scores.

Method

Expected RS Variance

BMAM

0.7104 0.0335

BMAM

0.4935 0.0345

MAS

0.7112 0.0160

MAS

0.5334 0.0188

MAS

0.4792 0.0226

MAS

0.2924 0.0204

The percentage of coincident decisions in the

outputs of BMAM

and MAS

, and those of

BMAM

and MAS

were measured in the same

experiment. The results are shown in Table 7.

Table 7: Percentage of coincidences BMAM

– MAS

MAS

(1) MAS

(0) MAS

(NaN)

BMAM

(1) 32.02

BMAM

(0) 32.70

BMAM

(NaN) 20.90

Table 8: Percentage of coincidences BMAM

– MAS

MAS

(1) MAS

(0) MAS

(NaN)

BMAM

(1) 23.34

BMAM

(0) 15.25

BMAM

(NaN) 40.44

According to the tables, BMAM

and MAS

coincide about 86% of times in their decisions, while

BMAM

and MAS

coincide only about 79% of

times.

5 CONCLUSIONS

Because of the stochastic nature of gene expression,

formulating a hypothesis on the state of a gene at a

particular time instant is not a deterministic problem.

Nonetheless, deterministic algorithms based on

intuitive models and different data mining

methodologies provide insights on the gene

expression state. Aggregating their solutions is a

way around determinism. In this article I introduce

MAS, an aggregation method that regards each

deterministic answer as a vote and makes a decision

on the basis of a majority rule. Points whose

aggregated decision contradicts the doctrine, and

points that fall within a threshold uncertainty

interval, are declared to be not decidable and

discarded as noisy data.

There is not a significant agreement between

BMAM

and MAS

in the identification of noisy

points. In general, as shown in Table 6, methods

BMAM

and MAS

, i = 1, 2; have comparable scores

of resolution when simple majority is used.

ACKNOWLEDGEMENTS

This research was supported in part by grant NIH-

MARC 5T36GM095335-02I.

REFERENCES

Greenbaum D, Colangelo C, Williams K, Gerstein M.,

2003. Comparing protein abundance and mRNA

expression levels on a genomic scale. In Genome

Biology 4 (9): 117. doi:10.1186/gb-2003-4-9-117.

PMC 193646. PMID 12952525.

Bornholdt. S., 2008. Boolean network models of cellular

regulations: prospects and limitations. J. R. Soc.

Interface, 5. Suppl. 1. 85–94.

Kim, Y., Han, S., Choi, S. and Hwang, D., 2013. Inference

of dynamic networks using time-course data. Briefings

in Bioinformatics. doi:10.1093/bib/bbt028.

Shmulevich, I., and E. Dougherty, E. Probabilistic

Boolean networks: the modeling and control of gene

regulatory networks. 2010. SIAM.

Tarca, A. L., Romero, R., and Draghici, S., 2006. Analysis

of microarray experiments of gene expression

profiling. American Journal of Obstetrics and

Gynaecology.195(2), 373-388.

Derveaux, S., Vandesompele, J., and Hellemans, J., 2010.

How to do successful gene expression analysis using

real-time PCR. Methods, Vol 50, 227-230.

Matsumura H, Ito A, Saitoh H, Winter P, Kahl G, Reuter

M, Krüger DH, Terauchi R., 2005. SuperSAGE. Cell

Microbiol 7(1):11-18.

Yamamoto, M., Wakatsuki, T., Hada, A. and Ryo, A.,

2001. Use of serial analysis of gene expressions

(SAGE) technology. Journal of Immunological

Methods 250:45-66.

Seguel, J., Lluberes, M., 2013., Semantics and accuracy of

gene expression threshold algorithms: A case study.

Proc. ADVCOMP 2013, Oporto, Portugal.

Shmulevich, I., Zhang, W., 2002. Binary analysis and

optimization-based normalization of gene expression

data. Bioinformatics. Vol. 18-4, 555–565.

Hopfensitz, M. et al., 2011., Multiscale binarization of

gene expression data for reconstructing Boolean

networks. IEEE/ACM transactions on computational

biology and bioinformatics. Vol. 9, no. 2, 487–498.

Sahoo, D., Dill, D. L., Tibshirani, R., and Plevritis, S. K .

2007. Extracting binary signals from microarray time-

course data.. Nucleic Acids Research Advance Access.

doi:10.1093/nar/gkm284.

Berestovsky, N., Nakhleh. N., 2013. An evaluation of

methods for inferring Boolean networks from time-

BIOINFORMATICS2015-InternationalConferenceonBioinformaticsModels,MethodsandAlgorithms

114

series data. Plos One, doi: 10.1371 /journal .pone.

0066031.

List, C., 2012. The theory of judgment aggregation: An

introductory review. Synthese 187 (1), 209-221.

Seguel, J. Macchiavelli, R. 2014. Mathematical and

statistical characterizations of expression threshold

methods. Unpublished manuscript.

Multi-AlgorithmicApproachestoGeneExpressionBinarization

115
