Evaluation of the Anonymous I2P Network’s Design Choices Against

Performance and Security

Juan Pablo Timpanaro, Thibault Cholez, Isabelle Chrisment and Olivier Festor

TELECOM Nancy, Universit´e de Lorraine, INRIA/LORIA UMR 7503, Vandœuvre-l`es-Nancy, F-54602, France

Keywords:

Attack Detection, Eclipse Attack, I2P, Anonymous systems, netDB.

Abstract:

Anonymous communications are growing extremely fast because more and more Internet users employ anony-

mous systems, such as the I2P or Tor networks, as a way to hide their online activity. Therefore, these networks

have been more and more studied, mainly from a security point of view. Different studies have shown impor-

tant design ﬂaws in these systems that could break users’ anonymity and how these issues can be overcome,

but the resilience of the underlying information systems has not been much investigated so far. Indeed, these

anonymous systems rely entirely on directories, either centralised or decentralised, to store vital network in-

formation. In this paper, we consider the I2P anonymous system and its decentralised directory, known as the

netDB, where our contributions are twofold. On the one hand, we conduct arguably the ﬁrst churn study of

the I2P network, showing that I2P users are more stable than non-anonymous peer-to-peer users. On the other

hand, we analyse the design of the netDB and compare it against the popular KAD design, demonstrating

that the former is more vulnerable to different attacks, specially to Eclipse attacks, which can be mitigated by

applying design choices of the latter. We lately show the positive impact on performances of including KAD’s

DHT conﬁguration into the netDB in terms of bandwidth, storage and messages overhead.

1 INTRODUCTION

NONYMOUS communications are quickly grow-

ing: the Tor network has tripled its user-base

in the last six months, while the I2P anonymous net-

work has doubled its user-basein the last ten months

These systems allow users to access different ser-

vices while preserving their online anonymity, where

a user’s real identity is decoupled from its assigned

system’s identity. As with the increased use of these

systems, different attacks have been designed and de-

ployed. Regarding the Tor network (Dingledine et al.,

2004), different studies have been carried out, where

the network itself has been attacked (Biryukov et al.,

2013; News, ), or it has been monitored (Mccoy et al.,

2008). The I2P network has been attacked as well, at

an application level (Crenshaw, 2011) and at a net-

work level (Herrmann and Grothoff, 2011).

These systems use a directory to store network

metadata, i.e. the metadata necessary to maintain

the operation of the network, such as the information

of participants or applications and services deployed

within the network. Tor uses a central directory to co-

Statistics from http://metrics.torproject.org and

http://stats.i2p.in/, respectively. Last visited on 09/2014.

ordinate its Tor routers, while the I2P network uses a

distributed directory to coordinate and store all sys-

tem metadata.

Our motivation lies in the fact that if these directo-

ries are attacked and fail, the entire system will not be

able to properly operate and deliver its main service:

anonymous communications. In this paper, we focus

on the security aspects of the anonymous I2P network

and its distributed directory, called the netDB.

Our contributions are:

• We evaluate the security and design of the netDB.

• We carry out the ﬁrst churn study of the netDB.

• We improve netDB’s design based on lessons

learned from the KAD distributed hash table.

The rest of the paper is organised as follows: Sec-

tion 2.4 introduces the I2P anonymous network. Sec-

tion 3 introduces the related work and arguably the

only practical attack against the I2P network. Sec-

tion IV introduces our recommendations to improve

netDB, from a security and performance point of

view. Section V introduces the performance eval-

uation of our proposed mechanisms: extending its

replica set size and extending its user-base. Section

6 considers further options when dealing with Sybil

Timpanaro J., Cholez T., Chrisment I. and Festor O..

Evaluation of the Anonymous I2P Network’s Design Choices Against Performance and Security.

DOI: 10.5220/0005226600460055

In Proceedings of the 1st International Conference on Information Systems Security and Privacy (ICISSP-2015), pages 46-55

ISBN: 978-989-758-081-9

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

attacks within distributed hash tables. Finally, Sec-

tion 7 concludes our work and presents further work

perspectives.

2 THE I2P NETWORK

The I2P network is designed as an anonymous net-

work layer enablingusers to deploy their own applica-

tions on top of the network, and it is mainly designed

for anonymous ﬁle-sharing and anonymousweb host-

ing. On the contrary to the Tor network, where users’

trafﬁc enters the network, gets re-routed and exits to

the normal Internet, in the I2P network the trafﬁc

stays within the network. Thus, the I2P network is

a closed network, on the opposite to the Tor network,

that can be seen as an Internet proxy.

2.1 I2P Architecture

Every node, or I2P user, within the system deploys

an I2P router, thus forming the I2P network overlay.

I2P routers connect among themselves forming tun-

nels: a multi-hop path among different I2P routers,

as depicted in Figure 1. The

I2P router A

sends

messages through a one-hop tunnel employing

I2P

router B

(endpoint) and receives messages employ-

ing as well a one-hop tunnel using

I2P router F

(gateway).

I2P router D

uses as well one-hop tun-

nels, where it sends data through the

I2P router

(endpoint), whilst receives data through the

I2P

router C

(gateway). The number of hops in a I2P

tunnel varies between 0 and 7, where more hops in

a tunnel increases the anonymity but reduces perfor-

mance, being that data needs to traverse more inter-

mediate nodes.

Users deploy I2P applications on top of their I2P

routers, where these applications are able to commu-

nicate to other remote I2P applications in an anony-

mous manner. Figure 1 presents a typical scenario,

where applications

App A

and

App B

communicate

among themselves by means of these I2P tunnels,

avoiding any direct communication among their I2P

routers.

App A

uses the tunnel with

I2P router F

as gateway to receive data, while

App B

uses the tun-

nel with

I2P router C

as gateway to receive data.

Similarly,

App A

uses the tunnel with

I2P router B

as endpoint to send data, while

App B

uses the tunnel

with

I2P router E

to send data.

Tunnel-based communications is the core of I2P

anonymity, where the identity of an I2P user (repre-

sented by an I2P router, for example I2P

router A

)

is decoupled from the identity of an I2P application

(for instance,

App A

Figure 1: Architecture of the I2P network.

2.2 I2P Anonymity

The information regarding an I2P router is gathered

in a structure known as routerinfo. That data struc-

ture holds all the contact information for that particu-

lar I2P router.

An I2P application is not identiﬁed through the

normal <IP address, port number> tuple, but via a

location-independent identiﬁer, known as I2P desti-

nation. That I2P destination along with a set of en-

cryption keys (to send encrypted data to the applica-

tion), a signing key and the list ofthe gatewaysused to

receive data is gathered in a structure known as leas-

eset. Considering the scenario in Figure 1, the leas-

eset of

App A

contains

I2P router F

as the single

gateway, whilst the leaseset for

App B

contains

I2P

router C

as the single gateway.

Therefore, an I2P router is identiﬁed by a router-

info, whilst an I2P application is identiﬁed by a leas-

eset. Routerinfos and leasesets are the I2P’s network

metadata required for a normal network operation.

I2P uses a distributed directory to store all I2P meta-

data and make it accessible to the entire network.

2.3 Distributed Directory

I2P uses a distributed directory to store its network

metadata that is composed of leasesets and router-

infos. The database is known as the netDB and

is a Kademlia-based (Maymounkov and Mazi`eres,

2002) distributed hash table, composed of ﬂoodﬁll

nodes. Floodﬁll nodes are normal I2P routers with

high bandwidth rates. This means that the netDB is

not formed by the entire network, as in KAD, but only

by a subset of all I2P routers.

The netDB works as any Kademlia-based dis-

tributed hash table when storing and retrieving data.

Figure 2 presents a simpliﬁcation of this procedure,

where a node

stores data with a particular

key

value.

The ﬁrst step is to retrieve those nodes close to the

key value, known as replica set, in this case nodes

and

(considering a replica set of four nodes, as

EvaluationoftheAnonymousI2PNetwork'sDesignChoicesAgainstPerformanceandSecurity

Figure 2: Kademlia storing/retrieving process.

an example). The second and last step is to send the

store message (in the case of searching for data, this

will be a search message) to those nodes, thus storing

the value.

The netDB works in a similar manner, where ev-

ery ﬂoodﬁll node stores a portion of all network meta-

data, either leasesets or routerinfos.

2.4 Keyspace Shifting

As every Kademlia-based DHT, I2P’s netDB uses the

XOR metric to determine in which nodes a value

should be published in or retrieved from by com-

paring a node’s identiﬁer and a value’s identiﬁer. A

node’s identiﬁer is determined during the ﬁrst execu-

tion and normally remains unchanged throughout the

entire life of the node.

Nevertheless, the netDB uses a temporary iden-

tiﬁer instead of a ﬁx identiﬁer to compute the XOR

distance. This temporary identiﬁer, called a routing

identiﬁer as opposed to the node identiﬁer, is obtained

by appending the node identiﬁer with the current date

and hashingthe result, as shown in Equation1. There-

fore, the identiﬁer used in the netDB is the routing

identiﬁer, which changes every day, while the node

identiﬁer remains ﬁx.

routing

id = SHA256(node id||yyyyMMdd) (1)

At midnight, every previously published value

needs to be republished in another DHT location,

since the routing identiﬁer changes. I2P uses this ap-

proach to increase the cost of a localised Sybil attack

(Douceur, 2002). During a Sybil attack, an attacker

creates several fake identities in order to place them

around the DHT. In a localised Sybil attack, all these

fake identities are place close to a particular target, as

to gain control of a particular portion of the DHT.

3 RELATED WORK

The Tor and I2P networks are arguably the most

widely deployed low-latency anonymous systems.

Figure 3: Egger et al. Eclipse attack on the netDB.

Different attacks have been deployed within the

Tor network, aiming at disrupting the network or de-

grading the anonymity of the system (Hopper et al.,

2010; News, ). Monitoring the system has as well

been studied (Loesing et al., 2010; Mccoy et al.,

2008), were different insights about Tor users have

been obtained.

Regarding the I2P network, Herrmann et al.

(Herrmann and Grothoff, 2011) conducted an at-

tack against I2P’s peer selection mechanism (zzz and

Schimmer, 2009), de-anonymising I2P anonymous

web sites, known as eepsites. Crenshaw (Crenshaw,

2011), on the other hand, exploited I2P’s application

layer to link together eepsites and the I2P users run-

ning those eepsites, thus de-anonymising I2P users.

On the contrary to the Tor network, monitoring the

I2P network has not been widely studied.

Despite these previous studies, none of them con-

sidered the network directory. The central directoryof

the Tor network has been, however, questioned about

its centralised nature in (Exchange, ), where a decen-

tralised hash table has been considered as an alter-

native solution. Regarding the I2P network, Egger

et al. (Egger et al., 2013) conducted arguably the

solely practical attack against the I2P network. The

authors deployed an attack against the netDB, aiming

at eclipsing a particular leaseset within the netDB. As

mention in Section 2.4, a leaseset identiﬁes a particu-

lar application, such as a ﬁle-sharing client. The goal

of Egger et al. attack is to render completely inacces-

sible to the rest of the network the leaseset identify-

ing an application. The most similar scenario in the

normal Internet will be to erase the DNS entry of a

particular website.

Figure 3 illustrates Egger et al.’s attack. The goal

is to place malicious peers around a particular target

key, such as

and

, closer than any other legit-

imate peer, such as

. Thus, these malicious peers

will store that target key and eventually they will stop

answering request, eclipsing the key from the rest of

the network.

In order to deploy this attack, Egger et al. need to

brute-force the position of these malicious peers, due

to the key shifting mechanism used by the netDB. The

number of generated malicious peers or fake keys is

proportional to the size of the replica set used within

the netDB, as later detailed in Section 4.3: a larger

replica set requires a larger set of fake keys to be gen-

erated and inserted. We will consider the attack by

ICISSP2015-1stInternationalConferenceonInformationSystemsSecurityandPrivacy

Egger et al. in our study and analyse how the cost

of this attack can be increased, where we additionally

consider a mechanism to detect whether a leaseset is

under attack.

4 IMPROVING THE RESILIENCE

OF THE netDB

I2P’s reduced replica set has a negative impact from

two points of view: From a reliability point of view, a

low replica set along with a considerable churn value

in the network can produce data loss (Stutzbach and

Rejaie, 2006). From a security point of view, an at-

tacker will need to generate fewer fake routing keys

so as to conduct an attack, specially localised Sybil

attacks, which are the basic attack to deploy further

complex attacks, such as Eclipse attacks. A lower

replica set means that an attacker will have less com-

petition with regular peers, which is translated to a

lower attack cost. So as to increase competition we

can:

• Increase the replica set size.

• Increase the number of nodes supporting netDB.

This section ﬁrst introduces the KAD network.

Later, it introduces two signiﬁcant improvements for

the netDB: extension of its replica set and extension

of its user-base, following KAD’s design.

4.1 The netDB and the KAD Network

The KAD network is a Kademlia-based distributed

hash table used by two ﬁle-sharing clients, aMule and

eMule. It has a double-indexation level, where the

ﬁrst level indexes content, whilst the second indexes

available sources, serving as a fully decentralised

search engine and tracker. The netDB, on the con-

trary, has a single-indexation level, where peers and

application metadata are indexed, similar to KAD’s

second level of indexation.

In both networks, routing is iterative, i.e. a peer

iteratively searches for peers close to a particular key,

before sending a service message, such as a

store

message. The difference, however, is the

size of the replica set. When a peer needs to store

a value within KAD or the netDB, he needs ﬁrst to

locate the closest peers to the key, before issuing the

service message. This set of closest peers is called the

replica set for that particular key. In a network with

no churn, the replica set has ideally a single peer on

it. However, being that churn in an intrinsic property

of P2P networks, both KAD and the netDB have mul-

tiple peers in the replica set. KAD, on the one hand,

uses a replica set of ten peers and therefore every time

a peer needs to store a value, it is replicated in the ten

closest peers. The netDB, on the other hand, onlyuses

the three closest peers to replicate a particular value.

It is important to mention that the replica set size

of the netDB has been decreased, from eight to ﬁve

to ﬁnally three nodes, due to our previous monitor-

ing study (Timpanaro et al., 2012), where we mon-

itored the network based on a distributed architec-

ture to characterise users and anonymous applica-

tions. We considered the distribution of our monitor

nodes, reaching the conclusion that we needed ⌈ N

/ X ⌉ monitor nodes to gather all network metadata

simultaneously, being

the size of the netDB (total

number of ﬂoodﬁll nodes) and

the size of the replica

set. For example, considering

=1000 and

=8 nodes

we needed ⌈ 1000 / 8 ⌉= 125 monitor nodes to have a

complete view of the netDB. However, considering a

lower replica set of three nodes, we needed ⌈ 1000 / 3

⌉= 334 monitor nodes. I2P’s designers considered our

study and decided to reduce the replica set

to tamper

our monitoring efforts.

However, this was clearly a poor design choice for

two reasons. On the one hand, as opposed to the KAD

network where requests are directly addressed and

unencrypted, there is no privacy issues when moni-

toring the I2P network. Requests to the netDB are

tunnelled employing the same tunnels as for anony-

mous communications, as explained in Section 2.1,

and therefore an attacker can not link together an ap-

plication (deﬁned by a leaseset) and the ﬁnal user re-

questing this application. On the other hand, reducing

the replicaset makes the I2P network more vulnerable

to Sybil attacks, and therefore to massive DoS, while

not improving its privacy nor its security.

4.2 Increasing the replica set

We aim at increasing the effort to deploy a Sybil at-

tack, that is to be able to position malicious peers next

to a particular key, closer than any other legitimate

peer. The current netDB design considers a replica set

of three peers, therefore an attacker needs to compute

three fake routing keys closer than any other peer to

achieve a successful attack. The netDB’s design does

not allow to choose a peer’s position within the netDB

space and therefore an attacker needs to compute fake

routing identiﬁers in a brute-force manner to place its

malicious peers.

Considering a netDB with

ﬂoodﬁll nodes and a

random routerinfo (or leaseset) with key

, the aver-

age number of shared bits between the key

and the

closest ﬂoodﬁll

is nb bits = log

N. That is, if we

http://zzz.i2p/topics/1281. Last visited on 09/2014.

EvaluationoftheAnonymousI2PNetwork'sDesignChoicesAgainstPerformanceandSecurity

20000

40000

60000

80000

100000

3 5 8 10 15 20

Cost of Attack (Generated Keys)

Replica set size

Generated keys

Figure 4: Cost of Attack/Replica Set size ratio.

consider the current size of the netDB (∼ 4000 nodes)

and a random routerinfo, or leaseset, we will ﬁnd that

the closest ﬂoodﬁll share 12 bits in common with the

key

associated to that routerinfo or leaseset.

Now, considering the previous relation between

the number of users in the netDB and the number of

shared bits, Equation 2 depicts the number of fake

routing keys an attacker will need to generate based

on the size

of the replica set. Considering netDB’s

current conﬁguration with

= 3 and

∼= 4000 , an

attacker will need to generate in average more than

12K fake routing keys before ﬁnding the number of

appropriate ones to perform the attack.

fake routing keys = K x

⌊log

N⌋+1

(2)

We additionally conducted an experiment consid-

ering the real netDB, so as to complement our ana-

lytic results. In order to correctly measure the effort

to compute these fake routing keys, we conducted the

following experiment, simulating an attack:

• Step 1: we published close to 200 keys in the

netDB and stored the replica set for each publi-

cation.

• Step 2: for each publication we computed the

closest peer, within the replica set, to the pub-

lished key.

• Step 3: ﬁnally we computed, in a brute-force man-

ner,routing keys untilobtainingthree routing keys

closer than the closest legitimate peer computedin

step two. We repeated this step several times (over

a hundred times).

Thus, we can measure how many fake routing

identiﬁers an attacker need to generate before being

able to fully eclipse a particular key in the netDB. In

other words, which is the cost of the attack, mea-

sured in generated fake routing keys. This behaviour

can be observed in Figure 4, where for a replica

set value of three, we need to generate, in average,

13000 fake routing identiﬁers, where with moderate

resources, can be computed in a few minutes. We ob-

tained these values within the netDB containing ap-

proximately 4000 nodes.

We performed the same experiment with different

conﬁgurations of replica set, as observed in Figure 4,

for values 3, 5, 8, 10, 15 and 20 nodes. By increas-

ing the replica set of the netDB, we linearly increase

the effort of the attack. Considering the replica set of

KAD for instance, an attacker will need to generate

up to 60000 fake routing identiﬁers before obtaining

a valid set of malicious peers.

Increasing the replica set within the netDB has

two effects. On the one hand, we are hardening lo-

calised Sybil attacks on the network, a major problem

in I2P’s threat model

. On the other hand, increas-

ing the replica set increases network resilience against

churn, since the probability of all peers in the replica

set going ofﬂine in a particular period of time expo-

nentially decreases when the size of the replica set

increases, as detailed in Section 5.3.

4.3 Increasing netDB’s User-base

The netDB design states that only certain qualiﬁed

peers can join the network, mainly ﬁltering out peers

regarding their bandwidth limits and their uptime in

the system. I2P’s designers states that, in this way,

the netDB is formed by fast and stable peers, the

ﬂoodﬁll nodes. Although a valid approach, we ar-

gue that these limitations need to be removed from

the netDB design, evolving to a more open design,

such as KAD. In KAD, every reachable peer supports

the DHT, without any restriction, leading to a network

size of several millions peers (Cholez et al., 2012).

KAD deals with less stable peers and churn by in-

creasing its replica set and adjusting its republication

window accordingly.

Increasing the number of peers within the netDB

implies that an attacker will need to generate further

fake routing keys, since the netDB space will be more

dense. Table 1 presents our results of the cost of an

Eclipse attack based on a given replica set and netDB

size. With the current values of replica set (three

nodes) and the netDB size (∼ 4000nodes), an attacker

needs to generate approximately 13000 fake routing

keys to achieve a full Eclipse attack, which matched

our previous analytic results. However, if we allow

every node in the I2P network (∼ 55000 nodes) to join

de netDB and maintain the current replica set of three

nodes, the cost of the attack grows almost by a factor

of ten, where an attacker will need to generate over

123000 fake routing keys.

We computed the current number of ﬂoodﬁll

nodes and the estimated number of users in the I2P

https://geti2p.net/en/docs/how/threat-model. Last vis-

ited on 09/2014.

ICISSP2015-1stInternationalConferenceonInformationSystemsSecurityandPrivacy

network based on our distributed architecture (Tim-

panaro et al., 2012).

Table 1: Number of attack keys to generate, based on the

Replica Set and netDB size.

Replica Set NetDB Size

1X (∼ 4K) 2X 4X All (∼ 55K)

Size= 3 13K 27K 52K 123K

Size= 5 23K 65K 110K 224K

Size= 10 60K 125K 250K 730K

We consider the DHT conﬁguration of KAD for

two reasons. On the one hand, the KAD network has

been widely study and improved (Steiner et al., 2007;

Wang et al., 2008; Steiner et al., 2007; Cholez et al.,

2009; Cholez et al., 2012) over the years, yielding

to a mature and robust design. On the other hand, it

has been in use for more than ten years, serving as

the backbone of the widely known eMule and aMule

ﬁle-sharing clients, proving to be an excellent dis-

tributed directory to support a large-scale ﬁle-sharing

network.

Increasing the replica set to ten peers to match

KAD’s DHT conﬁguration and letting every I2P node

to become part of the netDB will increase the cost

of an Eclipse attack by a factor of ﬁfty (from 13K

to 730K), where an attacker will now need to gen-

erate almost a quarter of a million fake routing keys

to achieve the same attack. The cost of the attack

now will remain proportional to the size of the net-

work, which is still constantly growing. Extrapolat-

ing our results from Table 1, we can estimate that an

attacker will need to generate over 15 million fake

routing keys considering a network with one million

users. If we consider that the non-anonymous KAD

network has approximately three million concurrent

online users (Cholez et al., 2012) and the anonymous

Tor network has an user base of over two million users

, we can think in a one-million users I2P network as

a possible scenario.

Increasing the size of the netDB consists in al-

lowing every peer to automatically form part of the

system, as in KAD. The current analysis of band-

width and uptime should be removed from the cur-

rent client, since the load of maintaining the netDB in

terms of bandwidth is negligible when compared with

the bandwidth assigned to I2P routers, as we will see

in Section 5.2. Moreover, the uptime of nodes is no

longer an issue, since a replica set of ten peers reduces

the probability of loosing all nodes in the replica set

to almost zero, as shown in Section 5.1.

Statistics from https://metrics.torproject.org/users.html.

Last visited on 09/14.

5 PERFORMANCE EVALUATION

This section ﬁrst introduces a churn analysis of the

I2P network, which will assist us in our performance

evaluation later in this section. We conduct a perfor-

mance evaluation from two points of view: the cost of

increasing netDB’s user base and the cost of increas-

ing netDB’s replica set.

5.1 Churn in the I2P Network

The I2P network is a peer-to-peer network where I2P

users interconnect among themselves to create multi-

hop paths or tunnels, creating an overlay on top of the

normal Internet. As with every widely-deployed pub-

lic peer-to-peer network, it suffers from variation on

the number of stable users in the system, also known

as churn or dynamics of peer participation as de-

ﬁned by Stutzbach and Rejaie (Stutzbach and Rejaie,

2006), among others.

Stutzbach and Rejaie conducted a comprehensive

study on network churn in P2P systems, yielding to

conclude that most P2P systems, including the KAD

network, can be characterised through a log-normal

distribution function, as shown in Figure 5. Accord-

ing to Stutzbach and Rejaie, the probability of a node

going ofﬂine, let’s call it

off

, after half an hour oscil-

lates around

off

= 1−0.59 = 0.41, meaning that with

a replica set of three peers and the currentI2P republi-

cation windows of thirty minutes, we might have, fol-

lowing Stutzbach and Rejaie results, a probability of

off

= 0.41

= 0.068 that the entire replica set goes of-

ﬂine and therefore the value previously stored within

those peers becomes inaccessible.

However, we consider that churn within the I2P

network might not be fully characterised by non-

anonymous peer-to-peer networks. Even if the I2P

network is mainly used for anonymous ﬁle-sharing

and anonymous web-hosting, we cannot generalise

the dynamics of peer participation of anonymous net-

works based on the dynamics of simple ﬁle-sharing

networks, such as KAD or BitTorrent. Therefore, we

conduct arguably the ﬁrst churn study in anonymous

networks, in our case the I2P network.

We placed a set of eight ﬂoodﬁll nodes, which

gathered routerinfos and leasesets as part of the nor-

mal netDB procedure. We ran our ﬂoodﬁll nodes for

ﬁve days, where we collected, in average, 1424 dis-

tinct routerinfos every 24 hours. As mentioned in

Section 2.3, the netDB’s keyspace switches at mid-

night, meaning that a ﬂoodﬁll will not necessary al-

ways store the same routerinfos. Our ﬂoodﬁll nodes

stored a total of 49563 different routerinfos during the

ﬁve-days test period. We computed the session length

EvaluationoftheAnonymousI2PNetwork'sDesignChoicesAgainstPerformanceandSecurity

0.1

100

1m 2m 5m 12m 30m 1h 2h 5h 12h 1d

CCDF(%)

Session length

Churn I2P Network

Stutzbach and Rejaie

Figure 5: Measured churn in the I2P network.

of every seen I2P user, represented by a single router-

info. Figure 5 depicts our results as well as Stutzbach

and Rejaie past results.

We can observe that

off

is considerable higher,

meaning that I2P users are more stable than in a nor-

mal non-anonymous peer-to-peer network up to ap-

proximately twelve hours, where both curves cross

each other. Afterwards, we detect a considerable low

number of I2P users with session length superior to

twelve hours, as opposed to normal peer-to-peer net-

works, where more users might rest connected for

long periods of a day or more.

In this case we have that the probability

off

of a

node going ofﬂine after half an hour oscillates around

off

= 1− 0.85= 0.15, approximately three times less

than in a normal peer-to-peer network. Moreover,

off

of the entire replica set is now

off

= 0.15

= 0.0033.

Considering our motivation to extend I2P’s replica set

size to ten peers, we will have

off

= 0.15

=∼ 0.

Our results bring forward an important difference

between anonymous users and non-anonymous ones.

Anonymous users, in this case I2P users, are more

stable in the short run, where the probability of the

length of the session exponentially decreases when

we pass the two-hour barrier. On the contrary, non-

anonymous users present, as depicted by Stutzbach

and Rejaie, a log-normal distribution function, where

it is not uncommon to observe users connected for

long periods, well beyond over 24-hours.

5.2 Cost of Increasing netDB’s

User-base

The current design of the I2P network states that in

order for a node to become a ﬂoodﬁll peer, i.e. be-

come part of the netDB, it needs to have a certain

bandwidth available and a certain uptime. Currently,

a node needs to have more than 128 KBps of avail-

able bandwidth and a minimum uptime of 200 min-

utes in order to become a ﬂoodﬁll node. It becomes

logical that a node needs more than three hours of up-

time since the size of the replica set is formed by only

three nodes and considering unstable nodes will lead

to data loss.

We argue that this analysis has become irrelevant

for two reasons: nowadays available bandwidth and

the minimal memory consumptiona node needs when

having a ﬂoodﬁll status are negligible.

Bandwidth Analysis

On the one hand, according to I2P’s designers

the

bandwidth a ﬂoodﬁll node needs (F

BW) to maintain

its ﬂoodﬁll status and to answer remote queries can

be computed as shown in Equation 3, where

is the

average number of users in the I2P network,

is the

average number of client destinations (leasesets),

the tunnel failure percentage,

is the tunnel rebuild

period,

is the average netDB entry size (either a

leaseset or a routerinfo) and

is the tunnel lifetime.

Although these values are proposed by the designers,

they are suitable for an roughly estimate on the re-

quired bandwidth.

F BW= N * (1+

) * (1+

) * S/T

(3)

According to I2P’s designers,

has value of 3,

has a value of 0.05,

has a value of 0.02.

has an

average value of 1 KB and ﬁnally

, the lifetime of a

tunnel, is 10 minutes. Considering the current size of

the I2P network, which is approximately 55000 users,

we can determinate that a ﬂoodﬁll node will need ap-

proximately an extra of 0.38 MBps, according to our

estimations. This ﬂoodﬁll bandwidth will be taken

out from the overall I2P user bandwidth.

According to our previous monitoring study on

the I2P network (Timpanaro et al., 2012), The United

States, Russia, France and Germany are the top four

I2P detected countries, adding up to almost the 60%

of all I2P users. Considering the worldwide band-

width study carried out by Ookla

, these four coun-

tries have an average bandwidth, or line speed, of

3.45 MBps.

I2P guidelines

suggest to set the overall I2P user

bandwidth slightly under the current line speed of the

user. Considering an 80% of the line speed seems

reasonable, resulting in approximately 3.45 MBps *

80% = 2.76 MBps for the I2P user overall bandwidth.

Thus, a ﬂoodﬁll node will barely require 0.38 MBps *

100 / 2.76 MBps = 14% of the overall available band-

width, which is completely affordable.

https://geti2p.net/en/docs/discussions/netdb. Last vis-

ited on 09/14.

http://www.netindex.com/. Last visited on 09/14.

http://echelon.i2p.us/I2Pguide/bandwidth.html. Last

visited on 09/14.

ICISSP2015-1stInternationalConferenceonInformationSystemsSecurityandPrivacy

Memory Consumption Analysis

The extra memory consumption a ﬂoodﬁll node needs

to maintain netDB’s data is also very small. We moni-

tored ourlocal ﬂoodﬁll node to determine the required

storage based on the number of routerinfos and leas-

esets kept. After 48 hours, where the ﬂoodﬁll is well

integrated into the netDB, it keeps a total average of

35 leasesets and 1966 routerinfos. We computed an

average leaseset size of 1068 bytes and an average

routerinfosize of 849 bytes, where give us a total con-

sumption of 35 * 1068 bytes + 1966 * 849 bytes =

1.62 MB. We consider that this cost is completely af-

fordable as well.

Therefore, a ﬂoodﬁll node will need approxi-

mately an extra 0.38 MBps of bandwidth and 1.62

MB of memory, which is, for nowadays computer

conﬁgurations, almost negligible.

5.3 Cost of Increasing Replica Set Size

Increasing the replica set involves replicating a value

to be stored in morenodesand therefore sendingmore

messages. The number of required messages can be

considered as

msgs

= rm+ sm, where the former cor-

respond to routing messages, while the later to service

messages. Routing messages do not depend on the

size of the replica set on Kademlia-based networks,

while service messages are directly proportional to

the size of the replica set. If we consider the republi-

cation time window in the netDB, we can determine

the number of messages to be sent to store a value in

the netDB.

Currently there is a thirty-minutes time window

for the republication of values, which means that ev-

ery half an hour a node needs to send out rm + sm

messages to get a value store in the netDB. If we

consider a replica set of ten peers, that is 10/3 times

bigger than the current replica set, where the same

node will need to send 10/3∗ (rm + sm) messages.

Considering that routing messages are not affected by

the size of the replica set, we actually have a total of

msgs

= rm + (10/3∗ sm) messages sent every thirty

minutes to have a value store in the netDB when em-

ploying a replica set of ten nodes.

However, since a larger replica set decreases the

overall probability of the entire replica set going of-

ﬂine, a node can afford to extend its republication

time window. Figure ?? depicts the probability of the

entire replica set going ofﬂine after a deﬁned amount

of time, for a replica set of three and ten peers. These

results were obtained following our previous results,

as presented in Section 5.1.

As observed in the ﬁgure, for a replica set of three

nodes, the probability of the entire replica set go-

0.1

100

1m 30m 1h 2h 5h 12h

Failure of Replica Set(%)

Republication window

Replica Set = 3

Replica Set=10

0.34%

Figure 6.

ing ofﬂine after half an hour is

off

= (1− 0.85)

0.15

= 0.0033. Considering our new replica set of

ten peers and aiming at maintaining the same

off

probability, i.e. the same service quality, we have

the same probability in a ﬁve hours period, as in

off

= (1 − 0.43)

= 0.57

= 0.0036. Therefore,

we can extend the republication of values within the

netDB to every ﬁve hours, reducing by a factor of

three the amount of messages a node needs to send

to maintain a value stored.

By extending the republication window to ﬁve

hours, we maintain the same service quality of the

current netDB. Additionally, we reduce by a factor

of three the number of messages a node needs to send

to maintain a value stored within the netDB, since the

node will now need to send 10 messages in a ﬁve-

hours period (2 messages per hour) instead of 3 mes-

sages in a thirty-minute period (6 messages per hour

previously).

Finally, we do not consider here the overhead

of the routing table management induced by the in-

creased user’s base. In fact, structured P2P network

have for long been proven very efﬁcient at this regard

and perform routing in log(N) hops.

6 DISCUSSION

Extendingthe size of netDB’s replica set as well as in-

creasing the overall user-base of the netDB certainly

tamper and attacker’s effort to deploy a Sybil attack.

However, these mechanisms are only a partial solu-

tion to this widely know problem. Urdaneta et al.

(Urdaneta et al., 2011) presented a comprehensive

study on mechanisms to deal with Sybil attacks, clas-

sifying them into different groups: centralised certi-

ﬁcation entities, distributed mechanisms, identiﬁca-

tion schemes based on physical network characteris-

tics, social-based approaches, computational puzzles

and game-theory approaches. Game theory-based ap-

proaches (Gatti et al., 2004; Margolin and Levine,

2007) pretend to impose a utility model, which of-

ten needs to use a sort of a currency in the system.

Since the utilisation of a money currency within a

EvaluationoftheAnonymousI2PNetwork'sDesignChoicesAgainstPerformanceandSecurity

distributed environment is highly complex, these ap-

proaches have remained theoretical and have not been

deployed in any large distributed system.

Computational puzzles, also introduced as Re-

source testing by Levine et al. (Levine et al.,

2006), aim at proving network nodes ID with highly-

demanding computational puzzles, assuming that an

attacker has not enough computational resources to

maintain an artiﬁcially high number of Sybil nodes,

since several logical identities are dependent on the

same physical entity. However, the computational

puzzles work best if all identities are proven in a

simultaneous way as stated by Douceur (Douceur,

2002), and it requires that honest nodes continue to

compute these puzzles in a regular basis in order to

remain on the system and avoid the collection of iden-

tities with time. Given the very high amount of IDs

that must be generated to perform a successful eclipse

attack when considering the netDB parameter we rec-

ommend, relying on crypto-puzzle clearly offers the

best collaboration with our work in order to further

improve I2P security against eclipse attacks.

A bullet-proof solution against Sybil attacks can

only be achieved by means of a centralised approach,

as early stated by Douceur (Douceur, 2002), while

non-centralised approaches can partially deal with

this attack. Of course, a distributed approach seems

to better ﬁt a DHT than a central authority but, due to

the lack of mutual trust in a distributed environment

and to the reduced view of the network, as stated by

Urdaneta et al., these defence mechanisms are unable

to fully prevent a Sybil attack, but only mitigate its

effects. Our analysis and recommendations regarding

the I2P’s netDB brings the network a step closer to a

robust system, while maintaining backward compati-

bility.

7 CONCLUSIONS AND FUTURE

WORK

In this paper, we evaluated I2P’s distributed direc-

tory, known as the netDB, from a security and de-

sign points of view. From a security point of view,

we particularly considered the Sybil attack, which en-

ables further complex attacks, such as a full Eclipse

attack, and propose different mechanisms to harden

the netDB based on the design of the KAD network.

An attacker will now need to compute 50 times more

fake identiﬁers than before to deploy the same attack,

considering a replica set of ten peers and the current

I2P network size. However, a resourceful attacker can

still deploy a full Eclipse attack on the netDB. There-

fore, our solution would gain to be associated with

a more resource-consuming way to generate routing

ID, by involving crypto-puzzles in the process rather

than simple hash functions.

We additionally conducted the ﬁrst churn study

the I2P anonymous network, where we detect a

slightly different behaviour of anonymoususers when

compared to normal ﬁle-sharing networks. I2P

anonymous users keep connected longer hours, up to

nine hours, where we found that the session length

curve dramatically drops.

Our solution is favourable in every sense: we have

a more robust network, which as well reduces mes-

sage overhead thus improving network overall per-

formances. Even more, our solution can be locally

implemented allowing a fully backward compatible

I2P client and letting the I2P network to progressively

evolve to a safer state.

Our future work consists in a ﬂexible and itera-

tive approach to overcome this resourceful attacker.

The owner of a leaseset, for instance, will period-

ically search for his published leasesets and if not

found, he will republished it using a bigger replica

set, thus avoiding malicious peers and reaching out

for legitimate peers. This approach enables to auto-

detect an ongoing attack and adjust the publication

procedure accordingly. Another direction that could

directly beneﬁt from our present contribution and bet-

ter mitigate Sybil attacks would be to change the way

DHT’s identiﬁers are computed in order to need more

resources.

REFERENCES

Biryukov, A., Pustogarov, I., and Weinmann, R.-P. (2013).

Trawling for tor hidden services: Detection, measure-

ment, deanonymization. In Proceedings of the 2013

IEEE Symposium on Security and Privacy, SP ’13,

pages 80–94, Washington, DC, USA. IEEE Computer

Society.

Cholez, T., Chrisment, I., and Festor, O. (2009). Evalua-

tion of Sybil Attacks Protection Schemes in KAD. In

Sadre, R. and Pras, A., editors, 3rd International Con-

ference on Autonomous Infrastructure, Management

and Security - AIMS 2009, volume 5637 of Lecture

Notes in Computer Science, pages 70–82, Enschede,

Netherlands. University of Twente, Springer.

Cholez, T., Chrisment, I., Festor, O., and Doyen, G. (2012).

Detection and mitigation of localized attacks in a

widely deployed P2P network. Peer-to-Peer Network-

ing and Applications, 6(2):155–174.

Crenshaw, A. (2011). Darknets and hidden servers: Identi-

fying the true IP/network identity of I2P service hosts.

In Black Hat DC 2011, Black Hat ’11, DC.

Dingledine, R., Mathewson, N., and Syverson, P. (2004).

Tor: the second-generation onion router. In Pro-

ceedings of the 13th conference on USENIX Security

ICISSP2015-1stInternationalConferenceonInformationSystemsSecurityandPrivacy

Symposium, SSYM ’04, pages 21–21, Berkeley, CA,

USA. USENIX Association.

Douceur, J. R. (2002). The Sybil Attack. In Revised Papers

from the 1st International Workshop on Peer-to-Peer

Systems, IPTPS ’01, pages 251–260, London, UK.

Springer-Verlag.

Egger, C., Schlumberger, J., Kruegel, C., and Vigna, G.

(2013). Practical attacks against the i2p network. In

Proceedings of the 16th International Symposium on

Research in Attacks, Intrusions and Defenses (RAID

2013).

Exchange, T. S. DDoS attack on Tor directory.

bit.ly/

1iWOrmC

. Last visited on 12/2013.

Gatti, R., Lewis, S., Ozment, A., Rayna, T., and Serjantov,

A. (2004). Sufﬁciently secure peer-to-peer networks.

Workshop on the Economics of Information Security.

Herrmann, M. and Grothoff, C. (2011). Privacy-

implications of performance-based peer selection by

onion-routers: a real-world case study using I2P. In

Proceedings of the 11th International Conference on

Privacy Enhancing Technologies, PETS ’11, pages

155–174, Berlin, Heidelberg. Springer-Verlag.

Hopper, N., Vasserman, E. Y., and Chan-TIN, E. (2010).

How much anonymity does network latency leak?

ACM Trans. Inf. Syst. Secur., 13(2):13:1–13:28.

Levine, B. N., Shields, C., and Margolin, N. B. (2006).

A Survey of Solutions to the Sybil Attack. Tech re-

port 2006-052, University of Massachusetts Amherst,

Amherst, MA.

Loesing, K., Murdoch, S. J., and Dingledine, R. (2010).

A case study on measuring statistical data in the tor

anonymity network. In Proceedings of the 14th In-

ternational Conference on Financial Cryptograpy and

Data Security, FC’10, pages 203–215, Berlin, Heidel-

berg. Springer-Verlag.

Margolin, N. B. and Levine, B. N. (2007). Informant: de-

tecting sybils using incentives. In Proc. of the 11th

International Conference on Financial cryptography

and 1st International conference on Usable Security,

FC ’07/USEC ’07, pages 192–207, Berlin, Heidel-

berg. Springer-Verlag.

Maymounkov, P. and Mazi`eres, D. (2002). Kademlia: A

Peer-to-Peer Information System Based on the XOR

Metric. In Revised Papers from the 1st International

Workshop on Peer-to-Peer Systems, IPTPS ’01, pages

53–65, London, UK. Springer-Verlag.

Mccoy, D., Bauer, K., Grunwald, D., Kohno, T., and Sicker,

D. (2008). Shining Light in Dark Places: Understand-

ing the Tor Network. In Proceedings of the 8th Pri-

vacy Enhancing Technologies Symposium, PETS ’08,

Leuven, Belgium.

News, T. W. Tor and the RELAY EARLY trafﬁc conﬁrma-

tion attack.

Steiner, M., Biersack, E. W., and En Najjary, T. (2007). Ac-

tively monitoring peers in KAD. In Proceedings of the

6th International Workshop on Peer-to-Peer Systems,

February 26-27, 2007, Bellevue, USA, IPTPS 2007,

Bellevue, UNITED STATES.

Steiner, M., En-najjary, T., and Biersack, E. W. (2007). Ex-

ploiting kad: Possible uses and misuses. ACM SIG-

COMM CCR, 37.

Stutzbach, D. and Rejaie, R. (2006). Understanding churn

in peer-to-peer networks. In Proceedings of the 6th

ACM SIGCOMM Conference on Internet Measure-

ment, IMC ’06, pages 189–202, New York, NY, USA.

ACM.

Timpanaro, J. P., Chrisment, I., and Festor, O. (2012). A

Bird’s Eye View on the I2P Anonymous File-sharing

Environment. In Proceedings of the 6th International

Conference on Network and System Security, NSS

’12, Wu Yi Shan, China.

Urdaneta, G., Pierre, G., and Steen, M. V. (2011). A sur-

vey of DHT security techniques. ACM Comput. Surv.,

43(2):8:1–8:49.

Wang, P., Tyra, J., Chan-Tin, E., Malchow, T., Kune, D. F.,

Hopper, N., and Kim, Y. (2008). Attacking the kad

network. In Proceedings of the 4th International Con-

ference on Security and Privacy in Communication

Netowrks, SecureComm ’08, pages 23:1–23:10, New

York, NY, USA. ACM.

zzz and Schimmer, L. (2009). Peer proling and selection in

the I2P anonymous network. In Proceedings of PET-

CON 2009.1.

EvaluationoftheAnonymousI2PNetwork'sDesignChoicesAgainstPerformanceandSecurity
