Computer Annotation of Nucleic Acid Sequences in Bacterial

Genomes Using Phylogenetic Profiles

Mikhail A. Golyshev

and Eugene V. Korotkov

1,2

Bioinfomatics laboratory, Centre of Bioengineering, Russian Academy of Sciences, Prospect 60-letiya Oktyabrya 7/1,

Moscow, 117312 Russian Federation

Department of Applied Mathematics, National Research Nuclear University “MEPhI”, Kashirskoe shosse 31, Moscow,

115409 Russian Federation

Keywords: Genes, Annotation, DNA Similarity, Bacterial Genpmes, Phylagenetic Profile.

Abstract: Over the last years a great number of bacterial genomes were sequenced. Now one of the most important

challenges of computational genomics is the functional annotation of nucleic acid sequences. In this study

we presented the computational method and the annotation system for predicting biological functions using

phylogenetic profiles. The phylogenetic profile of a gene was created by way of searching for similarities

between the nucleotide sequence of the gene and 1204 reference genomes, with further estimation of the

statistical significance of found similarities. The profiles of the genes with known functions were used for

prediction of possible functions and functional groups for the new genes.We conducted the functional

annotation for genes from 104 bacterial genomes and compared the functions predicted by our system with

the already known functions. For the genes that have already been annotated, the known function matched

the function we predicted in 63% of the time, and in 86% of the time the known function was found within

the top five predicted functions. Besides, our system increased the share of annotated genes by 19%. The

developed system may be used as an alternative or complementary system to the current annotation systems.

1 INTRODUCTION

Recent advances in genome sequencing have

provided access to a wide variety of nucleic acid

sequences (Eisenhaber, 2012). Thousands of

complete bacterial genomes, as well as numerous

eukaryotic genomes are now available for use. But

to effectively apply this knowledge, we must

understand the functions of genes in cells, which

makes functional characterization, i. e. annotation of

the already sequenced genes, our top priority (Janitz,

2007). There are two methods to solve this task. The

first one is in vitro – the experimental biological

approach, which allows us to receive the most

reliable information about the functions of genes and

other sequences (Saghatelian and Cravatt 2005).

However, these researches are quite time-consuming

and expensive. In silico approach is the other option:

computer-based annotation is rather low-cost and the

results can be obtained much faster. Yet, the

reliability is not high compared to the experimental

approach. Besides, there are genes which cannot be

annotated with the computer approach, and their

share in bacterial genomes, though varying for

different genomes, averages 45% (Galperin and

Koonin 2010). Our purpose is to develop new

mathematical and computational techniques in order

to increase the share of annotated genomes and

improve the annotation reliability (Richardson and

Watson 2013). The bacterial genes computer

annotation is based on one main principle: if two

sequences are similar, the probability of their

biological functions being similar is very high. This

idea underlies all of the currently used mathematical

annotation methods (Pandit et al., 2004; Friedberg

2006) of which the most widespread are those based

on the heuristic similarity search algorithm, multiple

sequence alignment, hidden Markov model (HMM)

and complex systems combining several methods.

These methods were used to assign functions to

nearly 60% of sequenced bacterial genes, while

around 40% are not yet characterized. Let’s examine

the main computer annotation methods in more

detail.

134

A. Golyshev M. and V. Korotkov E..

Computer Annotation of Nucleic Acid Sequences in Bacterial Genomes Using Phylogenetic Proﬁles.

DOI: 10.5220/0005236201340143

In Proceedings of the International Conference on Bioinformatics Models, Methods and Algorithms (BIOINFORMATICS-2015), pages 134-143

ISBN: 978-989-758-070-3

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

1.1 Dynamic Programming and

Heuristic Algorithms

The main principle behind the annotation is as

follows: if a known sequence in a database is similar

to the one under study, their functions are likely to

be similar too. Methods used to detect similarities

between nucleotide sequences include global and

local alignment, both of which are based on dynamic

programming (Needleman & Wunsch 1970),(Smith

& Waterman 1981). These methods are the most

precise ones, but are not very efficient due to their

extensive computational complexity. Therefore, the

heuristic programming tools for pairwise alignment

such as BLAST (Altschul et al. 1990) and FASTA

(Pearson & Lipman 1988) with various Expect value

thresholds, and others are more widespread. As a

source of sequences with known functions they use

the following databases: RefSeq (Pruitt et al. 2005),

GenBank (Benson et al. 2013), KEGG Genes

(Kanehisa et al. 2004), UniProt (The UniProt

Consortium 2011), Swiss-Prot (Bairoch & Apweiler

1999). Compared to the dynamic programming,

however, the heuristic algorithms discover much

fewer significant alignments. At the same time, this

is the only approach allowing us to analyze all the

gene sequences available so far.

1.2 HMM-based Systems

PFAM (Finn et al. 2010) and TIGRfam (Haft 2003)

– these are both protein families databases

containing multiple alignments, HMM models, and

related information for automatic classification and

annotation of new proteins. The search for the most

probable models is carried out with HMMER3 (Finn

et al. 2010) or PSI-BLAST (Altschul et al. 1997)

software tools. To annotate genes using HMM, it is

necessary to form the training and validation gene

sets, train the HMM models and conduct cross-

validation. Then the best match between the HMM

and the gene under study is used for functional

annotation. This approach inherits all of the features,

advantages and disadvantages of machine learning:

importance of forming original samples correctly,

avoiding system retraining, etc. At the same time,

the quality of functions prediction with HMM is

much higher than in some machine learning

algorithms (Ali 2004).

1.3 Phylogeny-based Methods

One of these methods uses the COG database

(Tatusov et al. 2000), which contains clusters of

orthologous genes. Three or more genes are grouped

into one cluster if they are found in different

genomes and are more similar to each other than to

other genes in these genomes. Currently there are

about five thousand COG clusters with known

biological functions. The main idea is that

orthologous genes are likely to have the same

biological functions. The method used to define such

functions is similar to the methods described above.

To annotate a gene, initially there is a database

created containing clusters of orthologs of known

genes. Further, the functions of the gene under study

as well as its COG cluster are defined by way of

searching for similarities between this gene and the

known genes from the database. The sequences are

compared by searching for significant alignments

with the BLAST software. One of the disadvantages

of the approach is the need to analyze a significant

number of organisms before a phylogenetic tree and

COG clusters can be created; the other one is that to

conduct the search for significant alignments the

heuristic tools are used, and they cannot guarantee

that all statistically significant alignments are

discovered.

1.4 Pipelines

InterPro (Hunter et al. 2012) is a system that uses the

protein families database with known functions,

signatures and GeneOntology (Ashburner et al.

2000) terms (GO) to determine features of new

proteins. InterPro contains 11 different databases:

Pfam, TIGRfam, SUPERFAMILY, and others. For

search and annotation the InterProScan tool is used

(Quevillon et al. 2005).

IMG(-ER) (Markowitz et al. 2012) is a system

for automatic annotation of new genomes and expert

functions review. It includes native IMG terms

derived from Pfam, TIGRfam, COG, SWISS-PROT,

GO, KEGG, and is used for annotation of

completely new genomes and for complementation

of existing annotations. The database contains more

than four thousand various gene functions; about

20% of all genes are covered by IMG terms.

J.Craig Venter Institute metagenomics analysis

pipeline (Tanenbaum et al. 2010) is a system for

structural and functional annotation of genes.

Functional annotation is based on BLAST, RPS-

BLAST, HMM, and other systems for homology

search between nucleotide sequences. As a result of

annotation, the gene is assigned a name, symbol, GO

terms, EC number, and JCVI functional role

categories.

RAST (Aziz et al. 2008) is a fully automated

ComputerAnnotationofNucleicAcidSequencesinBacterialGenomesUsingPhylogeneticProfiles

135

service for annotating bacterial and archaeal

genomes. It uses manually curated subsystems of

functional roles and protein families (FIGfams)

largely derived from the subsystems. This service is

developed by the SEED project, which also provides

convenient tools for viewing and analyzing results of

the annotations.

GenDB (Meyer et al. 2003) is an open source

project that provides a web interface and API for

gene annotation. For functional annotation it uses

BLAST, HMMER, InterProScan, and other

prediction tools.

Although by using several annotation methods

we can increase the number of genes with predicted

functions, complex systems inherit features and

drawbacks of their subsystems. Besides, it is

sometimes difficult to choose between the results

from different algorithms.

1.5 Phylogenetic Profiles

When the similarity between two nucleic or amino

acid sequences is not strong (usually that means

below 70%), we cannot be sure that these sequences

have the same biological roles notwithstanding the

number of similarities found. However, we shall

consider the fact that not a separate gene, but a

combination of genes involved in a genetic process

is relevant for the viability of bacteria. This means

that genes found in one and the same combination in

different bacterial genomes are most probably

involved in the same genetic process. Hence, the

information about the gene under study being

involved in a group of genes present in genomes of

different bacteria may be critically important for

prediction of its function.

To obtain this information, we form the so called

phylogenetic profiles (Gaasterland and Ragan, 1998;

Weiller 1998). They are created for every gene of

the bacterial genome using the following method.

First, certain genome sequences are selected, which

we will call the reference group. Then a

phylogenetic profile is built for every gene in these

sequences; this profile is a vector of ones and zeros

with the length equaling the size of the reference

group. Thus, every gene from the group matches "0"

or "1" in the corresponding phylogenetic profile: a

zero means the bacterial genome contains no

homolog for the gene under study; if a similar gene

is found, the entry is a one.

After constructing profiles for the reference

group, we build one for the gene under study. Using

a similarity metric we can now compare the profiles.

If the gene under study is part of a combination

involved in one genetic process, its profile will be

similar to one or several profiles in the reference

group. Otherwise no similarities will be found.

This approach was first used by (Gaasterland and

Ragan 1998) and than M.Pellegrini for protein

sequences (Pellegrini et al. 1999) and was

sufficiently developed over the last ten years in

terms of the creation, comparison and analysis of

phylogenetic profiles. Particularly, the concept of

using real vectors or matrices instead of binary

vectors was developed. Also, various approaches to

comparison of phylogenetic profiles were suggested,

such as the mutual information approach, Jaccard

coefficient, Pearson correlation, hypergeometric

distribution and others. The detailed review of the

approaches was given in studies (Pellegrini 2012;

Kensche et al. 2008).

However, the results very much depend on the

similarity search method used. In this study, we used

the phylogeny-based method, though a little

amended. Firstly, with the help of BLAST we

searched for homologs with different values of

reward and penalty, which ensured the reasonable

search speed and allowed us to find a large number

of local alignments. Secondly, we used the dynamic

programming algorithm (Needleman & Wunsch

1970) with the PuPy substitution matrix (Rastogi et

al. 2006) to see if a statistically significant global

alignment could be found where BLAST had

discovered a local one. The reason we looked for

global alignments only was that local alignments

often indicate partial similarities, not the whole gene

homologs. To define statistical significance of a

global alignment, the Monte Carlo method was used

(Raeside 1976). Thirdly, we compared the annotated

gene to the bacterial genomes, not to single genes,

which saved us from mistakes associated with the

structural annotation of bacteria, i. e. with genes

demarcation. Following this analysis, a phylogenetic

profile was built for every gene under study, which

was then compared to the profiles of the reference

group genes. Our study resulted in annotation of an

additional 19% of genes which couldn’t be

annotated with any of the previously used methods.

At the same time, we were unable to assign

statistically valid functions to 9% of the genes.

2 MATERIALS AND METHODS

2.1 Phylogenetic Profiles

Phylogenetic profiles are used to create sets of genes

that are involved in the same genetic process. This

BIOINFORMATICS2015-InternationalConferenceonBioinformaticsModels,MethodsandAlgorithms

136

approach was first applied in 1998 by M. Pellegrini

and his colleagues (Pellegrini et al. 1999). To create

a phylogenetic profile of a gene, it is necessary to

form a binary vector as follows: if a gene has been

detected in the i-th genome, the i-th position of the

vector contains 1; if there is no gene found, it is 0.

We assume that the genes involved in the same

genetic process will have similar phylogenetic

profiles constructed from the same set of reference

genomes. The assumption is derived from the fact

that the gene normally performs its function not

alone, but in conjunction with other genes as part of

one metabolic pathway. In the course of evolution

this process is inherited by different organisms; as a

result, more functional groups emerge containing

genes of similar profiles (Eisen 1998).

In this paper, for the predicted function we take

one of the most probable predicted functions from

the gene’s functional group. As you can see, the

phylogenetic approach does not use direct

comparison of the coding sequences of genes against

each other, but takes into account the co-occurrence

of certain genes in the genomes. So, this approach

can supplement the annotation methods discussed in

the previous section and predict functions for those

genes, for which the best similarity is significantly

lower than 70%.

2.2 The Method Description

Our work in this study had two stages: creation of a

database containing phylogenetic profiles of genes

with known functions and prediction of the functions

for genes using the previously created database

(Figure 1).

Figure 1: Creation of the phylogenetic profiles database

for genes with known functions. Function prediction for a

new gene.

To create a phylogenetic profile of a gene, it is

necessary to determine a set of reference genomes.

As of this writing, there were more than 2,100

bacterial genomes sequenced; however, using close

genomes, for example strains of one organism,

impairs precision of predictions because occurrences

of the gene in such genomes are not independent.

And we also could not use all available genomes, as

the algorithm used for creating profiles for all genes

has O(n

) time complexity. Since we had to find all

genes in all of the selected genomes, the number of

comparisons made was N

, where N is the number of

all genes. So from all bacterial genomes we only

selected 1,204 as reference genomes. To create the

database of phylogenetic profiles, we used all the

genes with known functions from the 1,204

reference genomes: 3.7 million genes in total.

The major task in the database creation process

was to determine the similarity significance for each

pair of genes and genomes. First, we used BLAST

with different options to search for significant local

alignments. After that we extended the found local

alignments to global alignments and for each global

alignment we calculated scores F of dynamic

programming (Needleman-Wunsch algorithm

(Needleman & Wunsch 1970)) using the PuPy

matrix. Using the Monte Carlo method and Equation

1, we calculated statistical significance for each

global alignment on the assumption that the

distribution of the score F was normal (Feller 1968):

()





(1)

where F is the score of alignment, M(F) and

D(F) are the sample mean and sample variance of

the random value F. The sequences sample was

created from the original sequence by randomly

shuffling its symbols. M(F) and D(F) were

calculated on the samples with size 1000.

Further, we created binary vectors for each gene

by the following rule: we assigned "1" to the i-th

element of the vector if the statistical significance of

the global alignment between the gene and the i-th

genome exceeded the chosen minimal value, and "0"

if no similarity was found or if its significance did

not exceed the chosen minimal value. Therefore, for

each gene we created a binary vector with length N,

where N is the number of referent genomes. We

chose the minimal value of statistical significance

Z=5.0, so that the probability to find more than one

1 for random sequences was 5%.

Since the names of the same functions may vary

in different annotation systems, we unified them by

using the Gene Ontology terms (GO). As a result,

ComputerAnnotationofNucleicAcidSequencesinBacterialGenomesUsingPhylogeneticProfiles

137

the predicted functions in our system are represented

as GO terms.

To predict a function, we first create a binary

vector for the gene in the same manner as when

creating the database of known functions, after

which we search for similar vectors in this database

using the probability measure that will be described

below. Let N be the size of the reference group and

the vector length, n

be the number of "1" in the

vector (i. e. in the phylogenetic profile) of the first

gene, n

be the number of "1" in the vector of the

second gene, n

be the number of common "1" (i. e.

placed in the same positions) in the first and second

genes. As measure of similarity between two

vectors, we chose the probability P of observing n

or greater co-occurrences between two profiles

purely by chance. As is known, the random variable

of common "1" follows the hypergeometric

distribution (Shuster 2005), hence the probability P

can be calculated by Equation 2:

min( , )

()

nNn

Pn n











(2)

where



knk





– is the number of k-

combinations from the given set of n elements.

Vectors of the genes, the probability P for which

didn’t exceed the chosen threshold, participate in

determining the potential function of the annotated

gene. The result of the prediction is a list of possible

functions, sorted by the probability P. For

phylogenetic profiles filtering, we chose the P

threshold of 10

-7

. The vector pairs with P > P

are

considered different. We tested the selected

threshold on a set of random vectors: the selected P

value provides such level of significance, in which

of 10

comparisons of two random phylogenetic

profiles no more than one has the level of P < P

We tested how many phylogenetic profiles can

be created from "random genes" which have at least

one "1". For this purpose we mixed gene sequences

from referenced genomes and than created

phylogenetic profile for each mixed sequence using

the reference genomes. Only 0.4% sequences

contain at least one "1". The remaining profiles

contain only zeros. After that, we compared the

profiles of “random genes” which have at least one

"1" with profiles of genes from referenced genomes.

Only 39 “random genes” have profiles with P < P

2.3 Comparison of the Current Work

to Previously Conducted

Annotations

To evaluate the quality of the developed method, we

used it to predict possible functions for the genomes

which had already been annotated. Since the system

database already contained genes from these

genomes, for testing purposes we excluded them

from the reference group. The method detects a

functionally linked group of genes rather than the

one most probable function. That is why we

compare the known function not to the single

predicted one, but to the first K of more probable

functions. Below we describe the approach in more

detail.

Of 1204 reference genomes we selected at

random 104 bacterial genomes from various

families. For every genome, we defined the method

it was formerly annotated with and then grouped the

genomes accordingly (Table 1). It was essential so

that we could afterwards compare our results to the

results obtained from the previous annotations based

on different methods.

Table 1: Bacterial genomes grouped by annotation

method.

Annotation

methods

Number of

genomes

Group ID

NCBI, UniProt,

TIGRFam, Pfam,

PRIAM, KEGG,

COG, InterPro,

IMG-ER

38 GRP_1

BLAST,

homology

28 GRP_2

GenDB, BLAST,

COG, COGnitor

7 GRP_3

InterPro(Scan) 5 GRP_4

Total 104 GRP_ALL

The system presents the predicted function as a

set of GeneOntology terms. Let’s see what the GO

terms are in more detail. Each term may belong to

one of the three domains: cellular component (C),

molecular function (F), and biological process (P).

Hence, every function may be presented as a set of

terms from these domains, though not necessarily

from all three of them at once. It is worth noting that

GO terms in each domain are structured as a tree,

where each term is a leaf or an internal vertex.

We were mostly interested in molecular

functions of genes, therefore in this study we will

only cover results for terms of this type (F);

however, similar results were obtained for every

BIOINFORMATICS2015-InternationalConferenceonBioinformaticsModels,MethodsandAlgorithms

138

type (C, F, P) separately and for the combination of

all three together. To compare sets of terms, we used

two approaches: perfect match, when all the terms

should match for the sets to be equal, and fuzzy

match, when the sets are considered equal if at least

one pair of terms match one another.

By the known function we will mean the

previously annotated function, and by the predicted

function, the one obtained in this study. To define

the system characteristics, we introduced subsets,

which are displayed in Figure 2 and described in

detail in Table 2. Since the annotation results are

presented as a list of possible functions, we consider

the functions equal if the known function is found

within the first N most probable predicted functions.

The list was arranged by probability P (see Equation

2 below); for this study we take N=5.

To evaluate the precision of predictions, we split

the C5 set into two subsets. Let the C6 set be a

subset of genes for which the known function was

found within the top five (N=5) predicted functions.

Therefore, C7=C5−C6 is a subset of those genes

from C5 for which the known function differs from

the predicted function (the known function was not

found within the top five predicted functions).

Figure 2: Subsets of genes under study.

In Table 2, we would like to highlight the two

sets and two subsets of genes which are essential for

estimating the quality characteristics of our

annotation system in comparison with the

annotations that have been made previously. These

are sets C3 and C4, and subsets C6 and C7. The C3

set contains the genes that have predicted functions,

but no known functions. The C4 set contains the

genes that have known functions, but no predicted

functions. The C6 and C7 subsets were defined in

the previous paragraph.

Table 2: Subsets of genes used to compare the current and

previous annotations.

Name Description

С0 All genes under study

С1

The subset of genes from the С0 set that have

known functions

С2

The subset of genes from the С0 set that have

predicted functions

С3

The subset of genes from the C2 set that have

predicted functions, but no known functions. С3

= С2 − С1

С4

The subset of genes from the C1 set that have

known functions, but no predicted functions.

C4= С1 − С2

С5

The subset of genes from the C0 set that have

both known and predicted functions. C5 = C1 ∩

С6

The subset of genes from the C5 set for which

the known function was found within the top

five predicted functions.

С7

The subset of genes from the C5 set for which

the known function was not found within the

top five predicted functions. C7 = С5 – С6

This section contains prediction results grouped

by method of their original annotation and by

method of comparison of their known function with

the predicted ones. In all tables we define the size of

the C

sets as N

. Tables 3 and 4 show the share of

various gene sets in the total number of genes: these

are the set of previously annotated genes, the set of

genes annotated with our system, as well as their

intersections and subsets. The obtained results can

be visualized with the diagram in Figure 3 (the

perfect match method of functions comparison is

used).

It is clear that the share of genes from the C3 set

varies from 16.9% to 21.4% and averages 19%

(Table 3). The share of genes from the C4 set varies

from 6.8% to 11.3% and averages 9%. To determine

the equality of known and predicted functions, we

used the two above-described ways, perfect match

and fuzzy match (Table 4). The share of genes from

the C6 set varies from 37.7% to 44.4% and averages

40% (Table 4). The share of genes from the C7 set

varies from 3.8% to 8.5% and averages 7%. As you

can see from Table 4, these results vary slightly

depending on the comparison approach (perfect

match or fuzzy match). The major difference

between the known and predicted functions (i. e. the

maximum ratio of N7/N6) is observed for the group

of genes defined in Table 1 as GRP_4.

ComputerAnnotationofNucleicAcidSequencesinBacterialGenomesUsingPhylogeneticProfiles

139

Figure 3: Visualization of annotation results.

Table 3: Shares of C1–C5 subsets in the total number of

genes (N0). N1/N0 is the share of genes from the С1 set;

N2/N0 is the share of genes from the С2 set; N3/N0 is the

share of genes from the С3 set; N4/N0 is the share of

genes from the С4 set; N5/N0 is the share of genes from

the С5 set.

Group

(number of

genes)

N1N0 N2/N0 N3/N0 N4/N0N5/N0

С1 С2 С3 С4 С5

GRP_1 144157 0.551 0.613 0.169 0.113 0.444

GRP_2 82170 0.573 0.668 0.186 0.091 0.482

GRP_3 24657 0.568 0.714 0.214 0.068 0.500

GRP_4 20592 0.549 0.663 0.194 0.080 0.469

GRP_

ALL

375151 0.563 0.658 0.186 0.091 0.472

It is also interesting to estimate the precision of

predictions for the top one (N=1) function of the

genes from the C3 set. For this purpose we analyzed

the genes from the C5 set (which consists of the

genes that have both known and predicted functions)

and found for each gene the minimum size of the

predicted functions list so that it contained the

known function. This dependence in terms of

percentage points is presented in Table 5. The size

of the C5 set is designated as 100%; each row shows

the share of each place in the list where the known

function was found. As can be seen from Table 5,

the known function was found on the top of the

predicted functions list in 63% of the time and in

Positions 2 to 5 in 23% of the time; 13% of cases

accrued to Position 6 and higher. These results show

that when we use the most probable predicted

function, the precision to predict the known function

is 63%. Therefore, we can conclude that precision

for genes from the C3 set may be the same.

These results also justify the choice of N=5 for

comparing the biological functions for the C5 set

genes (C6+C7). As you can see from Table 5, the

share of exactly predicted functions stops increasing

notably at N=3 and reaches saturation at N=5.

Table 4: Comparison of original and predicted functions.

N5/N0 is the share of genes from the С5 set (these genes

have both known and predicted functions), N6/N0 is the

share of genes from the С7 set (genes from C5 for which

the known function and the predicted function are equal),

N7/N0 is the share of genes from the С7 set (genes from

C5 for which the known function differs from the

predicted function).

Group ID N5/N0

Perfect match Fuzzy match

С6 С7 С6 С7

GRP_1 0.444 0.377 0.067 0.401 0.043

GRP_2 0.482 0.420 0.062 0.444 0.038

GRP_3 0.500 0.432 0.068 0.460 0.040

GRP_4 0.469 0.384 0.085 0.419 0.050

GRP_ALL 0.472 0.407 0.065 0.432 0.040

Table 5: Distribution of places in the list of predicted

functions where know function was found.

Position

of the

known

function

in the

list

Cumulative

percentage of

genes

Percentage of

genes

Number of

genes

1 63.23 63.23 108806

2 77.12 13.89 23894

3 82.06 4.94 8498

4 84.64 2.58 4446

5 86.23 1.59 2743

6 87.36 1.13 1949

7 88.19 0.83 1433

8 88.84 0.65 1127

9 89.40 0.56 962

10 89.87 0.47 783

The results of annotations for genes under study can

be freely accessed at

http://genefunction.ru/public_results/ .

3 DISCUSSION

First of all, it is interesting to consider the genes for

which functions predicted in our study differ from

the known functions. They fall into the subset of

genes which we defined as C7 in Table 2 and Figure

2. The share of this set is 7% from the total number

of the genes under study (Figure 3). The difference

can be explained by the fixed size of the top

predicted functions for each gene. To compare them

with the known functions we use the top five

BIOINFORMATICS2015-InternationalConferenceonBioinformaticsModels,MethodsandAlgorithms

140

predicted functions sorted by probability P. As you

can see from Table 5, a known function was found

within the top five predicted functions for 86% of

the genes. For 14% the five best predicted

candidates did not contain an already known

function. This may occur in three cases. Firstly, the

genes may be involved in several metabolic

pathways with different functions (i. e. functions of

the gene in these pathways are different). If one of

these metabolic pathways is more widespread in

genomes under study, than the others, the function

of the gene in this pathway may be predicted as

more probable, thus the previously predicted

(known) function may not be found among the top

five predicted functions. Secondly, the gene may

have a mutated copy (paralog), which takes part in a

different genetic process. Such paralog may

participate in a metabolic process that can be found

in a greater number of reference bacterial genomes

than the metabolic process in which the original

gene we study participates. Thirdly, there might be

an mistake made in previous annotations, but the

probability of that to happen is very small, which

may be explained by the high level of similarity

between sequences in the previous annotations.

It is also interesting to consider the C4 set which

contains genes for which no predicted functions

were found in the present work. The share of such

genes is 9% of the total number of analyzed genes.

There are two reasons to explain the absence of

predicted functions for these genes. The first is that

the search for similarities in this work was

performed by comparing the nucleotide sequences

rather than the amino acid sequences. Some

significant similarities of the amino acid sequences

may appear insignificant on the nucleotide level, and

their statistical value will be below the threshold

level. Secondly, this may be explained by the

specific feature of the approach: to create a group of

related genes it is necessary to find similar vectors

with a sufficient number of 1, i. e. the gene must be

found in sufficient number of different genomes. In

most cases when a group cannot be created, it is

because of few "1" in the profile of the gene rather

than due to the absence of similar vectors.

The most successful result of our work is the C3

subset of genes for which there were no previously

predicted functions before our study; the share of

this set is 19% of all genes that have been examined

in the present work. The fact that these functions

have never been predicted before can be explained

by the difference of approaches. The vast majority of

the existing annotation methods identifying

orthologs use amino acid sequences with the

sufficiently high level of similarity only, which

allows to predict the equality of their biological

functions with great probability: the higher the

similarity, the stronger the indication that these

sequences are exact orthologs. When the similarity

level is lower (though still statistically significant),

more potential homologs can be found: the greater

part of them are paralogs (mutated copies with

unrelated functions), but it is entirely possible that

orthologs may also be found among these

similarities. To separate one from another, some

additional information must be used. In this work,

such information is the similarity of phylogenetic

profiles. The similarity between the profiles will be

significant for orthologs and either missing or

statistically less significant for paralogs. Therefore,

this additional filtering by phylogenetic profiles

allows us to sort out paralogs and to predict

biological functions for genes using the similarities

not accounted by the existing annotation methods.

We also increased the number of significant

similarities by using several cycles of local

alignments search with different parameters,

including the purine-pyrimidine weight matrix for

global alignment. Besides, we compared each gene

with whole bacterial genomes rather than with sets

of previously selected genes from these genomes. It

allowed us to avoid errors during structural

annotations, i. e. when identifying the gene

sequences in the bacterial genomes. To sum it all up,

our success in annotating new genes is based on the

phylogenetic profiles comparison method, which

allowed us to find additional orthologs among a

great number of paralogs.

Let us also estimate the precision of biological

function predictions for genes from the C3 set. For

this estimation, we use as the prediction result the

first function in the list sorted by probability P. As

you can see in Table 5, the predicted biological

functions of 63% of all genes examined in the

present work coincide with known functions. It can

be expected that the precision of predictions for the

C3 genes will be the same (about 63%). The

obtained results looks reasonably better in

comparison to the similar studies; for instance, in a

previous study for the E.coli genome the known

function was found on the top of the predicted

functions list in 43% of the time and within the top

ten in 60% of the time; and for the S.cerevisiae

genome the known function was found within the

top fifty predicted functions in 60% of the time

(Kharchenko et al. 2006). However, in our study the

known function was on average found within the top

five predicted functions in 86% of the time.

ComputerAnnotationofNucleicAcidSequencesinBacterialGenomesUsingPhylogeneticProfiles

141

Although the developed system doesn’t make

exact predictions of gene functions (the precision is

about 63%, see Table 5), it may be used as an

alternative or complementation to the existing

annotation systems: the existing systems predict

functions for genes from sets C4 and C5, and our

system covers functions for genes from sets C3 and

C5. Therefore, the use of our system can increase the

share of annotated bacterial genes by 19% (by the

size of the C3 set).

63% predictions of gene functions was received

for P

=10

-7

and Z=5.0 (see 2.1). P

and Z

was chosen

with a large margin. It is possible to define an upper

limit for the number of false positives in C2 set. For

this purpose we can use the number of profiles

which have at least one "1" received for mixed genes

(see 2.1). The number of these profiles was 0.4 %

and other profiles contain only zeros. Profiles with

zeros have P>P

and automatically eliminated from

our consideration. But 39 “random genes” which

have at least one "1" received profiles with P < P

. It

means that less than 0.01% is upper limit of false

positives for N2 (C2 set). Thus, false positives have

a small effect on our results.

REFERENCES

Ali, H., 2004. A hidden markov model for gene function

prediction from sequential expression data.

Proceedings. 2004 IEEE Computational Systems

Bioinformatics Conference, 2004. CSB 2004., (Csb),

pp.639–640.

Altschul, S. F. et al., 1990. Basic local alignment search

tool. Journal of molecular biology, 215(3), pp.403–

410.

Altschul, S. F. et al., 1997. Gapped BLAST and PSI-

BLAST: a new generation of protein database search

programs. Nucleic Acids Research, 25(17), pp.3389–

3402. Available at: http://

www.pubmedcentral.nih.gov/articlerender.fcgi?artid=

146917&tool=pmcentrez&rendertype=abstract.

Ashburner, M. et al., 2000. Gene ontology: tool for the

unification of biology. The Gene Ontology

Consortium. Nature genetics, 25(1), pp.25–9.

Aziz, R. K. et al., 2008. The RAST Server: rapid

annotations using subsystems technology. BMC

genomics, 9, p.75.

Bairoch, A. & Apweiler, R., 1999. The SWISS-PROT

protein sequence data bank and its supplement

TrEMBL in 1999. Nucleic Acids Research, 27(1),

pp.49–54.

Benson, D. A. et al., 2013. GenBank. Nucleic acids

research, 41(Database issue), pp.D36–42.

Date, S. V & Marcotte, E. M., 2003. Discovery of

uncharacterized cellular systems by genome-wide

analysis of functional linkages. Nature biotechnology,

21(9), pp.1055–62.

Eisen, J. A., 1998. Phylogenomics: Improving Functional

Predictions for Uncharacterized Genes by

Evolutionary Analysis. Genome Research, 8(3),

pp.163–167.

Eisenhaber, F., 2012. A decade after the first full human

genome sequencing: when will we understand our own

genome? Journal of bioinformatics and computational

biology, 10(5), p.1271001.

Feller, W., 1968. An Introduction to Probability Theory

and Its Applications,

Finn, R. D. et al., 2010. The Pfam protein families

database. Nucleic Acids Research, 38, pp.D211–D222.

Friedberg, I., 2006. Automated protein function

prediction--the genomic challenge. Briefings in

bioinformatics, 7(3), pp.225–42.

Galperin, M. Y. & Koonin, E. V, 2010. From complete

genome sequence to “complete” understanding?

Trends in biotechnology, 28, pp.398–406.

Gaasterland, T. & Ragan, M. A., 1998. Constructing the

multigenome viewes of whole microbial genomes.

Microbial & Comparative Genomics 3, pp. 177-192.

Haft, D. H., 2003. The TIGRFAMs database of protein

families. Nucleic Acids Research, 31(1), pp.371–373.

Hunter, S. et al., 2012. InterPro in 2011: new

developments in the family and domain prediction

database. Nucleic acids research, 40, pp.D306–12.

Janitz, M., 2007. Assigning functions to genes — the main

challenge of the post-genomics era. Biochemical

Pharmacology, 159, pp.115 –129.

Jothi, R., Przytycka, T. M. & Aravind, L., 2007.

Discovering functional linkages and uncharacterized

cellular pathways using phylogenetic profile

comparisons: a comprehensive assessment. BMC

bioinformatics, 8, p.173.

Kanehisa, M. et al., 2004. The KEGG resource for

deciphering the genome. Nucleic acids research,

32(Database issue), pp.D277–80.

Kensche, P. R. et al., 2008. Practical and theoretical

advances in predicting the function of a protein by its

phylogenetic distribution. Journal of the Royal

Society, Interface / the Royal Society, 5(19), pp.151–

70.

Kharchenko, P. et al., 2006. Identifying metabolic

enzymes with multiple types of association evidence.

BMC bioinformatics, 7, p.177.

Markowitz, V. M. et al., 2012. IMG: the Integrated

Microbial Genomes database and comparative analysis

system. Nucleic acids research, 40(Database issue),

pp.D115–22.

Meyer, F. et al., 2003. GenDB--an open source genome

annotation system for prokaryote genomes. Nucleic

acids research, 31(8), pp.2187–95.

Needleman, S. B. & Wunsch, C. D., 1970. A general

method applicable to the search for similarities in the

amino acid sequence of two proteins. Journal of

Molecular Biology, 48, pp.443–453.

Pandit, S. B., Balaji, S. & Srinivasan, N., 2004. Structural

and functional characterization of gene products

BIOINFORMATICS2015-InternationalConferenceonBioinformaticsModels,MethodsandAlgorithms

142

encoded in the human genome by homology detection.

IUBMB life, 56(6), pp.317–31.

Pearson, W. R. & Lipman, D. J., 1988. Improved tools for

biological sequence comparison. Proceedings of the

National Academy of Sciences of the United States of

America, 85(8), pp.2444–8.

Pellegrini, M. et al., 1999. Assigning protein functions by

comparative genome analysis: protein phylogenetic

profiles. Proceedings of the National Academy of

Sciences of the United States of America, 96(8),

pp.4285–8.

Pellegrini, M., 2012. Using phylogenetic proﬁles to

predict functional relationships J. Helden, A.

Toussaint, & D. Thieffry, eds. Methods in Molecular

Biology, 804, pp.167–177.

Pruitt, K. D., Tatusova, T. & Maglott, D. R., 2005. NCBI

Reference Sequence (RefSeq): a curated non-

redundant sequence database of genomes, transcripts

and proteins. Nucleic acids research, 33(Database

issue), pp.D501–4.

Quevillon, E. et al., 2005. InterProScan: protein domains

identifier. Nucleic Acids Research, 33, pp.W116–

W120.

Raeside, D. E., 1976. Monte Carlo principles and

applications. Physics in Medicine and Biology, 21,

pp.181–197.

Rastogi, S. C., Mendiratta, N. & Rastogi, P., 2006.

Bioinformatics Methods and Applications: Genomics,

Proteomics and Drug Discovery, PHI Learning Pvt.

Ltd.

Richardson, E. J. & Watson, M., 2013. The automatic

annotation of bacterial genomes. Briefings in

bioinformatics, 14(1), pp.1–12.

Saghatelian, A. & Cravatt, B. F., 2005. Assignment of

protein function in the postgenomic era. Nature

chemical biology, 1(3), pp.130–42.

Shuster, J. J., 2005. Hypergeometric Distribution. In

Encyclopedia of Biostatistics.

Smith, T. F. & Waterman, M. S., 1981. Identification of

common molecular subsequences. Journal of

Molecular Biology, 147, pp.195–197.

Tanenbaum, D. M. et al., 2010. The JCVI standard

operating procedure for annotating prokaryotic

metagenomic shotgun sequencing data. Standards in

genomic sciences, 2(2), pp.229–37.

Tatusov, R. L. et al., 2000. The COG database: a tool for

genome-scale analysis of protein functions and

evolution. Nucleic acids research, 28, pp.33–36.

The UniProt Consortium, 2011. Ongoing and future

developments at the Universal Protein Resource.

Nucleic acids research, 39(Database issue), pp.D214–

Weiller, G. F., 1998. Phylogenetic Profiles : A Graphical

Method for Detecting Genetic Recombinations in

Homologous Sequences. Molecular Biology and

Evolution, 15, pp.326–335.

ComputerAnnotationofNucleicAcidSequencesinBacterialGenomesUsingPhylogeneticProfiles

143
