Balancing is the Key

Performing Finger Vein Template Protection using Fuzzy Commitment

M´elanie Favre

, Sylvaine Picard

2∗

, Julien Bringer

and Herv´e Chabanne

1,3

Morpho, Issy-les-Moulineaux, France

Safran, Magny-les-Hameaux, France

T´el´ecom ParisTech, Paris, France

Keywords:

Fuzzy Commitment, Finger Vein, Product Codes, Template Protection Scheme.

Abstract:

We propose a novel vein extraction technique adapted to template protection and use it to apply a fuzzy

commitment scheme. We construct dedicated error correcting codes that enable us to maintain a good accuracy

after template protection. In a second application, we offer to overcome the alignment issues when comparing

two vein templates by performing this step outside of the protection scheme. Different implementations are

proposed to explore trade-offs between False Rejection Rate, False Acceptance Rate, comparison time and

security. All approaches are tested on the recent database of University of Twente from ICB 2013. Our

biometric performances are close to state of the art approaches whilst bringing security with the template

protection scheme.

1 INTRODUCTION

Biometrics provide a reliable and convenient way of

individual authentication. The use of physical traits

has the advantage that they cannot be lost or forgot-

ten. However, the storage of biometric templates may

lead to security and privacy issues. In order to thwart

these problems, different solutions for privacy protec-

tion have been proposed (ISO, 2011). A ﬁrst set of

techniques is to protect the template with a template-

level transformation, often denoted by biometric tem-

plate protection. This can offer a ﬁrst layer of security

without impacting too much the system. More robust

security protection will rely on more complex archi-

tectures that work at the system level (not restricted

to the template-level). The underlying idea of the

template-level approach is to derive a protected ver-

sion of the enrolled biometric template and to store it

instead of the ﬁrst one. The transformation mecha-

nism is considered as public and it must be difﬁcult to

reconstruct the template from the protected one with-

out the genuine user’s biometric data. The level of

difﬁculty that one can achieve is very often dependent

on the difﬁculty to reverse the transformation and the

difﬁculty to ﬁnd a matching template. That motivates

us to ﬁnd a good trade-off between false positive rate

∗

Work done during employment at Morpho

and reversibility.

Among the well known biometric template protec-

tion schemes there are the fuzzy commitment scheme

(Juels and Wattenberg, 1999) and the fuzzy vault

scheme (Juels and Sudan, 2006). Both approaches

commit to a secret value under a noise-tolerant key.

The ﬁrst scheme deals with ﬁxed-length binary keys

while the latter is able to deal with unordered sets.

First introduced in (Juels and Wattenberg, 1999), the

fuzzy commitment scheme binds a binary biometric

template to a random codeword. The idea is to over-

come the biometric variance by means of error cor-

rection. The error correction capacity has to coin-

cide with the chosen threshold deliminating intra and

inter-class variance. The fuzzy commitment scheme

has been applied to many different biometric modal-

ities and representations: a survey can be found, for

instance, in (Rathgeb and Uhl, 2011). We propose

in this paper to use it with ﬁnger vein biometrics.

An attempt on backhand vein has been carried out in

(Hartung and Busch, 2009) and fuzzy commitments

has also been applied on ﬁnger vein in (Yang et al.,

2013), but after a ﬁrst bio-hashing step (that relies on

a secret parameter). Our approach deals with non-

hashed ﬁnger vein templates. Note that the security

evaluation of the fuzzy commitment scheme is still

an open problem despite recent proposals (see for in-

stance (Simoens et al., 2012)). However, this work

304

Favre M., Picard S., Bringer J. and Chabanne H..

Balancing is the Key - Performing Finger Vein Template Protection using Fuzzy Commitment.

DOI: 10.5220/0005241403040311

In Proceedings of the 1st International Conference on Information Systems Security and Privacy (ICISSP-2015), pages 304-311

ISBN: 978-989-758-081-9

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

has not the ambition of bringing new elements on its

security, but rather to focus on showing how to ap-

ply efﬁciently the fuzzy commitment scheme to ﬁnger

vein biometrics.

To do so, it is necessary to take a closer look at

the manner vein information is represented and com-

pared. Since Miura et al. publications (Miura et al.,

2004) (Miura et al., 2007), vein feature extraction and

vein recognition problems have generated an increas-

ing interest among the biometrics research commu-

nity. However, ﬁnger vein recognition is still a re-

cent research ﬁeld. Therefore research about a funda-

mental stage for recognition systems like feature ex-

traction is still vivid. Different strategies have been

proposed, for example, local representationwith SIFT

(Ladoux et al., 2009) and minutiae (Yu et al., 2009).

To be well suited for fuzzy commitment scheme, an

interesting characteristic for vein recognition is to al-

low comparison with the Hamming distance. Several

papers are interesting from this point of view. For

example, Lee et al. use in (Lee et al., 2010) a 50 x

20 LBP coded vector to characterize a ﬁnger. Com-

parison is done thanks to a weighted Hamming dis-

tance. In (Zhou and Kumar, 2010), Zhou and Kumar

use different representations for palm vein recogni-

tion: Multi-scale local vesselness based on Hessian

eigenvalues, Localized Radon Transform and Ordi-

nal representation. In this case again, the compari-

son of these representations is based on the Hamming

distance. Finally, Hartung et al. in (Hartung et al.,

2011; Hartung et al., 2012) adapt Spectral Minutiae

(Xu et al., 2009) to backhand vein recognition with

encouraging performances. In this work, we propose

a novel vein extraction technique and novel error cor-

recting code constructions to reach a very good ratio

between accuracy and security.

This article is structured as follows. In section

2 we give a brief overview of vein extraction tech-

niques, we introduce an efﬁcient technique to derive

binary templates that can be compared via Hamming

classiﬁer, and we describe the database we used for

our experiments. Section 3 details the modalities of

the fuzzy commitment as we applied it, and the way

we chose the underlying error correcting codes while

section 4 presents the experiments we carried out. Fi-

nally, section 5 concludes our study.

2 VEIN BIOMETRICS

2.1 Vein Extraction for Template

Protection

In the context of template protection, it is necessary to

adapt data representation to get an effective protection

scheme and minimize information leaks. To do so,

some methods have already been proposed ((Hartung

et al., 2011), (Fuksis et al., 2011), (Hirata and Taka-

hashi, 2009)). With the fuzzy commitment scheme,

one very important point is to provide templates that

can be compared with the Hamming distance. How-

ever, guaranteeing Hamming-wise comparison is not

enough to provide a good data representation. Secu-

rity analysis shows that it is also necessary to be care-

ful in order to make attacks by false acceptance or

brute force difﬁcult.

In general, vein acquisition systems reveal only

main vessels. Therefore, the main part of ﬁnger vein

images is made of background, that means none ves-

sel information. If vein extraction precisely respects

vessels net, then extracted templates will present a

majority of black pixels. In a biometrics recognition

context it is not a problem. In the context of template

protection this bias facilitates attacks. Indeed, fake

templates with a majority of black pixels would take

advantage of this bias reducing the distance between

a protected template and themselves.

To eliminate this problem, we propose a quite

counter-intuitive scheme: do not respect the real

vessel information! We propose to make sure that

vein templates contain as much as possible an equal

number of white and black pixels. This way, we

go a step closer to random data. Our solution can

be applied to different vein extraction methods.

Moreover it does not need to use several templates

as input for balancing the white and black pixels:

the algorithm is made to work with one image to

be compatible with single-image enrollment schemes.

Let I be the vein image, E

(I) the extraction func-

tion. The only requirementon E

is to be a continuous

and smooth function on [0,255]. Then, template T is

constructed as follows:

T(x,y) =



1 if E

(x,y) ≥ thresh

0 if E

(x,y) < thresh

(1)

Where thresh is chosen for each image I in order

to get the number of 1 and the number of 0 as close

as possible in T. That is to say thresh is the median

of E

(x,y). It is clear that some pixels set to one do

not represent ﬁnger vein. This is a consequence of

BalancingistheKey-PerformingFingerVeinTemplateProtectionusingFuzzyCommitment

305

balancing the template. As stated earlier, this rule

can be applied to any continuous E

function, for

example for some 2D adaptation of (Frangi et al.,

1998) or any continuous operator mentioned above.

In this article we use a proprietary function E

based

on a rough modelisation of ﬁnger veins.

2.2 Vein Database Description

The lack of public database has been a problem up to

now. Fortunately, some databases are now available

((Kumar and Zhou, 2012), (Ton and Veldhuis, 2013)),

and hopefully some more should be available in the

future. For this experiment, we work with UTFVP

database from University of Twente (Ton and Veld-

huis, 2013). These data represent 60 person’s 6 ﬁn-

gers (index ﬁnger, middle ﬁnger, and annular ﬁnger

of both hands). Data were acquired during two differ-

ent sessions allowing four acquisitions by ﬁnger. In

general, image quality is good.

Image resolution is 126 pixels per centimeter

(ppcm). In order to work with a compact represen-

tation of ﬁnger veins, we downsample the images by

a factor of 5 in each dimension. Finger’s outlines are

easily computed using gradients of the image. Some

ﬁnger orientation correction is done by computingﬁn-

ger principal axis and performing a rotation in order

to get it horizontal. Then, to code reference ﬁnger

images we use a 100 × 30 ﬁnger area centered on

the middle of the image which corresponds roughly

to the middle phalanx. This zone is usually described

as the most stable and the most discriminant area for

ﬁnger vein recognition. Figure 1 shows a ﬁnger from

Twente database and its corresponding balanced en-

coded version.

Figure 1: Finger vein from Twente database and its corre-

sponding balanced coding.

For query images we use a 128 × 44 area centered

on the middle of the image. We use this a priori posi-

tioning because ﬁnger position is quite stable between

two acquisitions. In the case of a bitwise comparison,

different sizes of coding areas for query images and

reference images allow to absorb small translations.

For example, during the comparison stage, it is pos-

sible to move the reference template over the search

template to ﬁnd the highest matching score position.

When relativeﬁnger positions can vary a lot, Yang has

proposed in (Yang and Li, 2010) to detect phalanges

position in order to determine the region of interest for

coding. In our tests, only small translations between

query and reference images can be handled.

To estimate accuracy of our ﬁnger vein coding, we

perform authentication tests without template protec-

tion. That is, we evaluate the amount of different pix-

els in the common area of 100 × 30 between refer-

ence and veriﬁcation templates. We test different po-

sitions and keep the one corresponding to the small-

est distance. For each ﬁnger we use the ﬁrst image

as a reference, and two images, acquired during sec-

ond acquisition session, for the query images. The

results are summarized in table 1, while ﬁgure 2 gives

an overview of the distances we have to deal with.

Table 1: Performances without template protection.

Nb Gen. Nb Imp. EER FRR (%) FRR (%)

Tests Tests (%) @FAR10

−4

@FAR10

−5

720 258480 0.56 2.22 3.89

Figure 2: Hamming distances.

Despite constraints on the coding strategy due to

our motivation to apply fuzzy commitment, our EER

is close to the best EER described in (Ton and Veld-

huis, 2013), that is 0.4%.

ICISSP2015-1stInternationalConferenceonInformationSystemsSecurityandPrivacy

306

h(c)

⊕

enrollment

veriﬁcation

⊕

′

h(c

′

)

decoding

random codeword

Error correcting code C

Figure 3: Fuzzy Commitment scheme.

3 FUZZY COMMITMENT

3.1 Background

Before detailing how the fuzzy commitment works,

we give a brief recall on error-correcting codes. The

goal of these primitives is to transmit a message m

over a noisy channel. To do so, the message is

mapped before transmission to a bigger data string

c - called codeword - containing redundant informa-

tion. This way, if some limited parts of c are corrupted

during transmission, c can be reconstructed through a

decoding algorithm, and therefore also m. More for-

mally, a linear binary error-correcting code C is de-

noted by [n,k,d] where k is the original size of the

message called dimension, n the size of the redun-

dant string called length and d denotes the smallest

Hamming distance between two codewords of C. The

correction capacity of C is bounded by (d − 1)/2.

The fuzzy commitment scheme applied to biomet-

rics demands a binary ﬁxed-length biometric template

b that is masked by a random codeword c to form a

protected template s = b ⊕ c. Meanwhile, the hash

value h(c) is stored together with s. During authenti-

cation, a fresh biometric template b

′

is presented and

XORed with s to get s

′

= b

′

⊕ s = b

′

⊕ b⊕ c. Decod-

ing algorithm is applied on s

′

to get a codeword c

′

. If

b and b

′

are within a certain thresholding in terms of

Hamming distance, then c

′

= c which can be checked

by h(c

′

) = h(c). Figure 3 depicts the whole process.

An upper bound for the security of the fuzzy com-

mitment is given by the dimension k of the error-

correcting code used, as it gives the amount of in-

formation of the key bound to the biometric tem-

plate b. Many more sophisticated security analysis

of the scheme have been carried out, see for instance

(Stoianov et al., 2009; Ignatenko and Willems, 2010;

Smith, 2004; Tuyls and Goseling, 2004). Most weak-

nesses come from the non uniform distribution of er-

rors in the biometric templates. The use of balanced

black and white vein templates limits this point. The

scheme is also subject to false acceptance attacks (see

for instance (Korte and Plaga, 2007)). As soon as

an impostor manages to authenticate, the codeword

bound to the template is retrieved (and consequently

the original template b as well). False acceptance rate

should thus remain low in order to limit this threat.

The use of a soft-decoding algorithm instead of a clas-

sical decoding algorithm may also lead to increased

false acceptances as it enables to decode more errors.

Finally, cross-matching and decodability attacks have

been studied (Simoens et al., 2009; Kelkboom et al.,

2011). Here we focus on the two main issues that are

the dimension of the code and the false acceptance

rate (FAR). In particular, we aim a quite low FAR, that

is set to be approximately between 10

−4

and 10

−5

3.2 Our Construction Choices

The choice of the error-correcting code has to be done

regarding the amount of errors one has to deal within

the biometric setting. Thus, we measured the distance

corresponding to roughly 0.001% of false acceptance

on Twente database. It turned out that we have around

36% of different pixels in this case.

In order to overcome this error rate, we have cho-

sen to use product codes in our scheme. Product

codes are a class of error-correctingcodes constructed

from two or more subcodes. C = C

] ×

] is a [n

] code whose code-

words can be seen as n

×n

matrices whose columns

are codewords from C

and rows codewords from C

When k

and k

are small enough, the min-sum algo-

rithm (Tanner, 1981) can be used to decode product

codes in a very efﬁcient way. It is an iterative process

that associates two scores between 0 and 1 at each ele-

ment of the matrix. These values represent the costs to

put the element to 0 (resp. to 1). Scores are initialized

regarding the word to be decoded and are improved

iteratively. At each iteration, the algorithm looks for

the codeword that costs the least. The error correc-

tion capacity of the min-sum algorithm is assured to

be d

/2 if two iterations are performed but it can

go much further in practice. For our experiments, we

have limited the amount of iterations to ﬁve, as it is a

good compromise between error correction and exe-

cution time. Finally, product codes can be composed

BalancingistheKey-PerformingFingerVeinTemplateProtectionusingFuzzyCommitment

307

of more than two subcodes in a straightforward man-

ner. The decoding process is then a less direct adapta-

tion, details can be found in (Wu et al., 2007), but we

use the most intuitive approach.

Min-sum decoding along with product codes

have been successfully applied in fuzzy commitment

schemes with iris and ﬁngerprint in (Bringer et al.,

2008; Bringer et al., 2007). We follow these exam-

ples by choosing product codes with similar proper-

ties, that is permitting to reach the lowest possible

false rejection rate in the Shannon sense (Shannon,

2001). But we go a step further and use for the ﬁrst

time in this kind of setting product codes of dimen-

sion 3 and 4 in order to achieve a good trade-off be-

tween execution time, code dimension and error cor-

rection capacity. In fact, subcodes with good quali-

ties (weight distribution, correction capacity) are of-

ten codes with n a power of two. The product codes

we tested are composed of repetition codes and of or-

der 1 Reed-Muller codes (Muller, 1954; Reed, 1954)

which are known to have good weight distributions.

As we have 3000 pixels in each template, we have

chosen to use an area of 2048 pixels to perform the

fuzzy commitment scheme. The choice of these pix-

els has been done regarding the areas in pictures less

impacted by errors. As stated in section 2.2, the mid-

dle of the phalanx is more stable, we thus naturally

evinced pixels on the horizontal borders. Our area of

interest is roughly the 68 × 30 central zone of each

picture.

4 EXPERIMENTS

4.1 Fuzzy Commitment with One

Reference Template

Traditionally, vein comparison consists in testing

many translations of one template on the other in or-

der to ﬁnd the best one corresponding to the smallest

amount of different pixels. In our setting, we test up

to 225 translations. To apply a fuzzy commitment in

this case, we need to perform as many decodings as

tested translations (but we can stop if one decoding is

correct).

4.1.1 Using an Interleaving

The error repartition inside a ﬁnger vein picture is not

random, there is a correlation between neighboring

pixels. We have thus introduced a random permuta-

tion, as a way to interleavethe pixels, that we apply on

the 2048 bits extracted from the template. This way,

the efﬁciency of the min-sum decoding algorithm is

increased and we were able to decode further than

without the permutation. Note that the permutation is

not a secret, it is just introduced to enhance the decod-

ing capacity of the min-sum algorithm in our setting.

Moreover, the use of a permutation allows to be resis-

tant against cross-matching and decodability attacks.

4.1.2 Tests and Performances

For our tests, we used the ﬁrst image of each ﬁnger

as reference template and used third and fourth im-

ages for veriﬁcation. This leads to 259,200 compar-

isons, among them 720 are genuine. Table 2 sums up

the performances we were able to reach. Execution

timings include the 225 decodings. Our experiments

were run on a computer with a 3.3GHz Intel Core i5

processor and 8GB of RAM. Compared to the bio-

metric performances presented in section 2.2, our re-

sults are degraded. This comes mainly from the fact

that we use only two thirds of the pictures. We can

also remark that the dimension of the error correcting

codes can reach 50 bits.

Table 2: Performances of the fuzzy commitment scheme

with one reference template (2048 bits).

Error correcting code Dim. FAR FRR Exec.

(bits) (%) (%) (ms)

RM(4,1)×RM(5,1)×[4,1,4] 30 0.01 4.31 560

[8,2,4]×RM(4,1)×RM(4,1) 50 0.03 3.05 350

4.2 Using a Second Reference Template

In order to improve the biometric performances, and

especially reduce false acceptance rates, we propose

to enroll a second reference template and impose to

match against both templates to authenticate. To

overcome the alignment problem that would soar the

amount of decodings with two templates, we addi-

tionally introduce a way to perform alignment before

the commitment scheme itself.

Just as Uludag et al. used a helper data to per-

form alignment of ﬁngerprints before a fuzzy vault

scheme in (Uludag and Jain, 2006), we use a part of

the biometric templates to best overlap them. To do

so, we separate each reference template into distinct

areas. We extract a small central zone of 276 pixels

that is stored in clear and used later to evaluate the

optimal translation – but only for that purpose as a

second and distinct part of 2048 pixels is used to per-

form the fuzzy commitment itself. We concatenate

the two 2048-pixel areas of both templates to form a

4096-bit word that we bind to a codeword just as be-

fore. The stored template contains now 2×276 pixels

in clear and a 4096-bit protected string. Again, we

ICISSP2015-1stInternationalConferenceonInformationSystemsSecurityandPrivacy

308

Figure 4: Choice of the areas: in black the alignment area,

in white the code zone (used for the fuzzy commitment) and

in gray unused pixels.

use a random permutation in order to break the corre-

lation between neighboring pixels.

Figure 4 depicts the image dividing as we per-

formed it. We chose a cross form for the alignment

part in order to be able to absorb the different transla-

tions we have to test.

During authentication, we ﬁrst use the two align-

ment areas from the reference templates to ﬁnd the

best translations inside the freshly acquired image.

We then extract the two corresponding areas of 2048

pixels to form a 4096-bit template that is XORed with

the secure template stored in the database. Finally, the

result of this is decoded. Again, we limit the min-sum

algorithm to ﬁve iterations.

4.2.1 Performances

We used the two ﬁrst images of each ﬁnger for en-

rollment and the same two last images as before for

veriﬁcation. The amount and nature of tests stay thus

unchanged.

Table 3 depicts our secure sketch results in term

of biometric accuracy, code dimension and execution

time. We propose two error-correcting codes that per-

mit to achieve low false acceptance rates whilst re-

maining quite accurate. The execution time is also

drastically reduced, as we have only one decoding to

perform. The key size is also improved but is limited

to 64 bits due the amount of errors to correct that is

rather high.

Table 3: Performances of the fuzzy commitment scheme

with two reference templates (4096 bits).

Error correcting code Dim. FAR FRR Exec.

(bits) (%) (%) (ms)

RM(6,1)×RM(6,1) 49 0.0035 2.92 11

[8,2,4]×[8,2,4]×RM(3,1)×RM(3,1) 64 0.0023 3.33 2.1

Compared to the biometric performances pre-

sented in section 2.2, we are able to get the same

performances with two reference templates instead of

one in section 2.2.

4.2.2 Security of the Scheme

Intuitively, the use of the central alignment area in

clear leads to information leakages. Veins have some

predictable patterns, mostly horizontal lines, that

could be exploited in order to guess some pixels of the

code zone knowing the alignment area. We have esti-

mated the leakage coming from the alignment zone by

measuring the correlation between neighboring pixels

in the whole database. Table 4 shows the result of our

measures. As we can see, there is a higher horizontal

correlation than the vertical one. The correlation is

quite high for the pixels at distance one in any direc-

tion and it stays high for the the pixels at distance two

horizontally (thick, blue values in the table). We have

therefore chosen to surround the alignment area by a

security zone (kind of DMZ) of one pixel vertically

and two pixels horizontally (see the gray zone around

the cross in Figure 4). This reduces the possibility

to exploit the information coming from the alignment

area. We remove the most predictable pixels of the

code zone, knowing the helper data, in order to limit

the information leakage. However it is clear that this

approach is a trade-off between execution time and

security.

Table 4: Pixel correlation for different distances in Twente

database.

-3 -2 -1 0 1 2 3

-3 -0.11 -0.10 -0.10 -0.09 -0.11 -0.11 -0.11

-2 -0.02 0.03 0.09 0.11 0.07 0.01 -0.03

-1 0.13 0.27 0.42 0.51 0.41 0.25 0.12

0 0.21 0.41 0.67 1.00 0.67 0.41 0.21

1 0.12 0.25 0.41 0.51 0.42 0.27 0.13

2 -0.03 0.01 0.07 0.11 0.09 0.02 -0.02

3 -0.11 -0.11 -0.11 -0.09 -0.10 -0.10 -0.11

Our scheme, like any fuzzy commitment scheme,

is vulnerable to false acceptance attacks. We man-

age to keep the false acceptance rate low in or-

der to limit the threat. Considering the code

[8,2,4]×[8,2,4]×RM(3,1)×RM(3,1), if an attacker

has access to a protected template, we would need a

database of around 45000 vein templates in order to

statistically decode it by false acceptance.

As stated in sections 4.1 ans 4.2, we limited

our experiments to ﬁve min-sum iterations for the

decoding. But an attacker could try more itera-

tions in order to decode further. We have eval-

uated the potential of this threat by studying the

execution of the fuzzy commitment with the code

[8,2,4]×[8,2,4]×RM(3,1)×RM(3,1). We increased

the number of iterations to 10 and measured the dif-

ference: execution time grows to 3.5ms while FAR

BalancingistheKey-PerformingFingerVeinTemplateProtectionusingFuzzyCommitment

309

stays almost stable with 0.0035%. In fact, more than

20% of impostor comparisons already lead to a suc-

cessful decoding with ﬁve min-sum iterations, but the

codeword found was not the right one (it is the hash

comparison h(c) = h(c

′

) that lead to a reject). Increas-

ing the amount of iterations seems to have a poor im-

pact on the true decoding capacity. We thus expect

the possible gain for an attacker to test more min-sum

iterations to be small.

5 CONCLUSION

In this paper, we apply a fuzzy commitment scheme

with ﬁnger vein biometrics. An adaptation of vein

encoding is proposed making vein template privacy

protection techniques efﬁcient and more secured. The

idea is to get a binary template with an equal number

of black and white pixels. This reduces efﬁciently the

risk of successful attacks. Moreover,it is very general

and can be applied to any continuous vein extraction

function. We also manage to pass over the alignment

problem by performing this step outside of the pro-

tection scheme. Doing so, we limit information leaks

by analyzing their potential and adapting the coding

area. We show how to increase accuracy and code di-

mension using two reference templates. Although the

fuzzy commitment scheme is inherently sensitive to

false acceptance attacks as any template-level protec-

tion technique, our biometric performances are pretty

competitivewith FAR close to 10

−5

and thus ensuring

a ﬁrst layer of security through a template protection

scheme. Finally, but not least, the comparison times

we obtain are compatible with realistic use cases.

ACKNOWLEDGEMENTS

This work has been partially funded by the European

FP7 BEAT project (SEC-284989).

Authors would like to thank Raymond Veldhuis

for making the UTFVP database available for their

research work.

REFERENCES

Bringer, J., Chabanne, H., Cohen, G., Kindarji, B., and

Z´emor, G. (2007). Optimal iris fuzzy sketches. In

Biometrics: Theory, Applications, and Systems, 2007.

BTAS 2007. First IEEE International Conference on,

pages 1–6. IEEE.

Bringer, J., Chabanne, H., Cohen, G., Kindarji, B., and

Z´emor, G. (2008). Theoretical and practical bound-

aries of binary secure sketches. Information Forensics

and Security, IEEE Transactions on, 3(4):673–683.

Frangi, A. F., Niessen, W. J., Vincken, K. L., and Viergever,

M. A. (1998). Multiscale vessel enhancement ﬁlter-

ing. In Medical Image Computing and Computer-

Assisted Interventation-MICCAI’98, pages 130–137.

Springer.

Fuksis, R., Kadikis, A., and Greitans, M. (2011). Biohash-

ing and fusion of palmprint and palm vein biometric

data. In Hand-Based Biometrics (ICHB), 2011 Inter-

national Conference on, pages 1–6. IEEE.

Hartung, D., Aastrup Olsen, M., Xu, H., Thanh Nguyen,

H., and Busch, C. (2012). Comprehensive analysis of

spectral minutiae for vein pattern recognition. Biomet-

rics, IET, 1(1):25–36.

Hartung, D. and Busch, C. (2009). Why vein recogni-

tion needs privacy protection. In Intelligent Informa-

tion Hiding and Multimedia Signal Processing, 2009.

IIH-MSP’09. Fifth International Conference on, pages

1090–1095. IEEE.

Hartung, D., Olsen, M. A., Xu, H., and Busch, C. (2011).

Spectral minutiae for vein pattern recognition. In Bio-

metrics (IJCB), 2011 International Joint Conference

on, pages 1–7. IEEE.

Hirata, S. and Takahashi, K. (2009). Cancelable biometrics

with perfect secrecy for correlation-based matching.

In Advances in Biometrics, pages 868–878. Springer.

Ignatenko, T. and Willems, F. M. (2010). Information

leakage in fuzzy commitment schemes. Informa-

tion Forensics and Security, IEEE Transactions on,

5(2):337–348.

ISO (2011). Standard iso/iec 24745:2011. information tech-

nology – security techniques – biometric information

protection.

Juels, A. and Sudan, M. (2006). A fuzzy vault scheme. Des.

Codes Cryptography, 38(2):237–257.

Juels, A. and Wattenberg, M. (1999). A fuzzy commitment

scheme. In Motiwalla, J. and Tsudik, G., editors, ACM

Conference on Computer and Communications Secu-

rity, pages 28–36. ACM.

Kelkboom, E. J., Breebaart, J., Kevenaar, T. A., Buhan, I.,

and Veldhuis, R. N. (2011). Preventing the decod-

ability attack based cross-matching in a fuzzy com-

mitment scheme. Information Forensics and Security,

IEEE Transactions on, 6(1):107–121.

Korte, U. and Plaga, R. (2007). Cryptographic protection

of biometric templates: Chance, challenges and appli-

cations. In Br¨omme, A., Busch, C., and H¨uhnlein, D.,

editors, BIOSIG, volume 108 of LNI, pages 33–46. GI.

Kumar, A. and Zhou, Y. (2012). Human identiﬁcation using

ﬁnger images. Image Processing, IEEE Transactions

on, 21(4):2228–2244.

Ladoux, P.-O., Rosenberger, C., and Dorizzi, B. (2009).

Palm vein veriﬁcation system based on sift match-

ing. In Advances in Biometrics, pages 1290–1298.

Springer.

Lee, H. C., Kang, B. J., Lee, E. C., and Park, K. R. (2010).

Finger vein recognition using weighted local binary

pattern code based on a support vector machine. Jour-

ICISSP2015-1stInternationalConferenceonInformationSystemsSecurityandPrivacy

310

nal of Zhejiang University SCIENCE C, 11(7):514–

524.

Miura, N., Nagasaka, A., and Miyatake, T. (2004). Feature

extraction of ﬁnger-vein patterns based on repeated

line tracking and its application to personal identiﬁ-

cation. Machine Vision and Applications, 15(4):194–

203.

Miura, N., Nagasaka, A., and Miyatake, T. (2007). Extrac-

tion of ﬁnger-vein patterns using maximum curvature

points in image proﬁles. IEICE TRANSACTIONS on

Information and Systems, 90(8):1185–1194.

Muller, D. E. (1954). Application of boolean algebra to

switching circuit design and to error detection. Elec-

tronic Computers, Transactions of the IRE Profes-

sional Group on, (3):6–12.

Rathgeb, C. and Uhl, A. (2011). A survey on biometric

cryptosystems and cancelable biometrics. EURASIP

Journal on Information Security, 2011(1):1–25.

Reed, I. (1954). A class of multiple-error-correcting codes

and the decoding scheme. Information Theory, Trans-

actions of the IRE Professional Group on, 4(4):38–49.

Shannon, C. E. (2001). A mathematical theory of commu-

nication. ACM SIGMOBILE Mobile Computing and

Communications Review, 5(1):3–55.

Simoens, K., Tuyls, P., and Preneel, B. (2009). Privacy

weaknesses in biometric sketches. In IEEE Sympo-

sium on Security and Privacy, pages 188–203. IEEE

Computer Society.

Simoens, K., Yang, B., Zhou, X., Beato, F., Busch, C.,

Newton, E. M., and Preneel, B. (2012). Criteria to-

wards metrics for benchmarking template protection

algorithms. In Jain, A. K., Ross, A., Prabhakar, S.,

and Kim, J., editors, ICB, pages 498–505. IEEE.

Smith, A. D. (2004). Maintaining secrecy when information

leakage is unavoidable. PhD thesis, Citeseer.

Stoianov, A., Kevenaar, T., and Van der Veen, M. (2009).

Security issues of biometric encryption. In Sci-

ence and Technology for Humanity (TIC-STH), 2009

IEEE Toronto International Conference, pages 34–39.

IEEE.

Tanner, R. M. (1981). A recursive approach to low com-

plexity codes. Information Theory, IEEE Transactions

on, 27(5):533–547.

Ton, B. and Veldhuis, R. (2013). A high quality ﬁnger

vascular pattern dataset collected using a custom de-

signed capturing device. In Biometrics (ICB), 2013

International Conference on, pages 1–5. IEEE.

Tuyls, P. and Goseling, J. (2004). Capacity and examples

of template-protecting biometric authentication sys-

tems. In Biometric Authentication, pages 158–170.

Springer.

Uludag, U. and Jain, A. (2006). Securing ﬁngerprint

template: Fuzzy vault with helper data. In Com-

puter Vision and Pattern Recognition Workshop, 2006.

CVPRW’06. Conference on, pages 163–163. IEEE.

Wu, X., He, Y., and Zhu, G. (2007). Performance of im-

proved three-dimensional turbo product code decoder.

In Integration Technology, 2007. ICIT’07. IEEE Inter-

national Conference on, pages 563–567. IEEE.

Xu, H., Veldhuis, R., Bazen, A. M., Kevenaar, T. A., Akker-

mans, T. A., and Gokberk, B. (2009). Fingerprint ver-

iﬁcation using spectral minutiae representations. In-

formation Forensics and Security, IEEE Transactions

on, 4(3):397–409.

Yang, J. and Li, X. (2010). Efﬁcient ﬁnger vein localization

and recognition. In Pattern Recognition (ICPR), 2010

20th International Conference on, pages 1148–1151.

IEEE.

Yang, W., Hu, J., and Wang, S. (2013). A ﬁnger-vein based

cancellable bio-cryptosystem. In Network and System

Security, pages 784–790. Springer.

Yu, C.-B., Qin, H.-F., Cui, Y.-Z., and Hu, X.-Q. (2009).

Finger-vein image recognition combining modiﬁed

hausdorff distance with minutiae feature matching.

Interdisciplinary Sciences: Computational Life Sci-

ences, 1(4):280–289.

Zhou, Y. and Kumar, A. (2010). Contactless palm vein iden-

tiﬁcation using multiple representations. In Biomet-

rics: Theory Applications and Systems (BTAS), 2010

Fourth IEEE International Conference on, pages 1–6.

IEEE.

BalancingistheKey-PerformingFingerVeinTemplateProtectionusingFuzzyCommitment

311
