An Enhanced DNA-based Steganography Technique

with a Higher Hiding Capacity

Samiha Marwan

, Ahmed Shawish

1,2

and Khaled Nagaty

1,2

Department of Computer Science, The British University in Egypt, Cairo, Egypt

Ain Shams University, Cairo, Egypt

Keywords:

Security, DNA-based Steganography, Data Hiding, Encryption, Decryption, Playfair Cipher.

Abstract:

DNA-based Steganography is one of the promising techniques to secure data exchange, where data is hidden

into a real DNA sequence. For the sake of security, some steganography techniques encrypt data before hiding

it which strengthen the technique’s steganalysis. One of the widely used encryption techniques is the DNA-

based playfair cipher. This technique intensively requires a long list of preprocessing steps in addition to

extra bits which must be added to guarantee successful decryption. Nevertheless, the succeeding hiding step

suffers from a limited capacity, which turns this current DNA-based Steganography technique into a complex,

inefﬁcient, and time consuming process. In this paper, we propose a new DNA-based Steganography algorithm

to simplify the current technique as well as achieve higher hiding capacity. In the proposed algorithm, we

enhance the commonly used playfair cipher by deﬁning a novel short sequence of preprocessing steps and

getting rid of the extra overhead bits. We also utilize a more efﬁcient technique to enhance the hiding phase.

The proposed approach is not only simple and fast but also provides a signiﬁcantly higher hiding capacity

with a high security. The conducted extensive experimental studies conﬁrm the outstanding performance of

the proposed algorithm.

1 INTRODUCTION

In the world where information and communication

become indispensable, it becomes a must for research

to ﬁnd out solutions for data protection, integrity and

accuracy. Recently, DNA-based Steganography be-

comes one of the promising techniques to secure data

exchange, where data is hidden into a real DNA se-

quence. The complexity of the DNA structure and

the randomness of its data are the main drivers of its

outperformance in comparison with other traditional

Steganography methods (Smith, 2003),(Alberts and

Johnson, 2008),(Adleman, 1994). For the sake of se-

curity, some DNA-based Steganography approaches

encrypt the data ﬁrst through a ciphering technique

and then hide it into a real DNA sequence. This paper

focuses on such approach as it leads to a more con-

fusion to the attacker and strengthen the technique’s

steganalysis

The 5x5 playfair cipher is one of the well known

and commonly used substitution ciphering techniques

Study of identifying the existence of data and detecting

it.

that uses a 5x5 grid containing the English alphabet in

an ascending order from A to Z, where 24 letters oc-

cupies 24 cells and the remaining 2 letters -usually I

& J- occupy the remaining cell. The sender and the

receiver should agree on a speciﬁed keyword to rear-

range the ordering of its cells to guarantee the unique-

ness of the 5x5 grid each time the key is changed as

shown in Fig1. Recently, this ciphering technique is

used to encode DNA-based data due to its strong en-

crypting capability in comparison with the other en-

cryption techniques (Atito, A. et al., 2012). How-

ever, such technique come up with long list of pre-

processing steps that, in our point of view, do not

decrease the cracking probability but complicate the

implementation process and increase the processing

time. Nevertheless, it also decreases the hiding ca-

pacity as we will prove in the rest of this paper. All

these issues contradicts with the fact of the DNA’s

huge storage capacity.

In the current DNA-based 5x5 playair cipher

implementation (Khalifa and Atito, 2012), the target

message passes through a long sequence of transfor-

mations: from letters to binary, from binary to DNA

150

Marwan S., Shawish A. and Nagaty K..

An Enhanced DNA-based Steganography Technique with a Higher Hiding Capacity.

DOI: 10.5220/0005246501500157

In Proceedings of the International Conference on Bioinformatics Models, Methods and Algorithms (BIOINFORMATICS-2015), pages 150-157

ISBN: 978-989-758-070-3

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

letters

, from DNA letters to protein sequence

presented by English letters

, where ciphering

technique takes place. Then the resulted ciphered

English letters are again transformed to DNA letters

with extra overhead bits, which is generally known as

the ambiguity bits. Finally, the resulted DNA letters

are concealed into a real DNA sequence through a

hiding technique. The whole process is then reversed

again at the receiver’s node to extract the original

message. As we can easily note, the whole process is

a set of complicated long steps that only consume a

lot of the computational effort without a real addvalue

to the security strength.

In this paper, we propose an enhanced DNA-based

Steganography algorithm that is much more efﬁcient

and faster than the current technique with a higher

hiding capacity. In the proposed algorithm, we en-

hance the commonly used playfair cipher by deﬁn-

ing a novel sequence of preprocessing steps and get-

ting rid of the overhead. We also utilize a more efﬁ-

cient technique to enhance the hiding process (Khalifa

and Atito, 2012). The proposed algorithm has rede-

ﬁned the whole process in a much smarter and straight

forward mechanism resulting in a better performance

and low execution time with a higher hiding capacity.

Moreover, The security strength has been carefully

checked and proved through the calculation of the

cracking probability. The outstanding performance of

our proposed algorithm is demonstrated through ex-

tensive experimental studies.

The rest of this paper is organized as follows. Sec-

tion 2 overviews the background and related work

on the current Steganography techniques. Section 3

presents the proposed technique in detail. Section 4

discusses its performance analysis. Finally, the paper

is concluded in Section 5.

2 BACKGROUND

In this section, we provide a brief review on the DNA

and the related work. In addition, we discussed in

detail the main problems of the current DNA-based

Steganography techniques and their problems.

2.1 DNA Overview

DNA is the magic code for life (Smith, 2003), it con-

tains the genetic instructions used in the development

and functioning of all living organisms. Inspired from

The DNA letters are A, G, C, and T.

The protein sequence is composed of amino acids, each

is abbreviated by an English letter.

Key = “PLAY”

A B C D E

F G H I/J K

L M N O P

Q R S T U

V W X Y Z

P L A Y B

C D E F G

H I/J K M N

O Q R S T

U V Q X Z

Figure 1: 5x5 Playfair Cipher Grid before and after using

the Key.

nature, the fact that DNA molecule carries all the ge-

netic information, evolves the idea of using DNA it-

self as a data carrier. The information in DNA is

stored as a code made up of four chemical bases

named as nucleotides: adenine (A), guanine (G), cy-

tosine (C), and thymine (T). The sequence of these

four bases encodes the genetic information (Alberts

and Johnson, 2008). Each of the three nucleotides is

called a codon, therefore in nature there are 64 codons

since there are (4x4x4) letter combinations.

DNA has two main advantages that make it efﬁ-

cient for data hiding and transmission. First of all its

high storage capacity; as proved by(Adleman, 1994).

Secondly, the simplicity of converting data to DNA

sequence makes it a good choice for data encryp-

tion within it. By exploiting the advantages of a

DNA as an efﬁcient data carrier in addition to using

a well-suited encryption technique, researches ended

up by many solutions for secure data communica-

tion and transmission. DNA steganography is one of

these promising solutions(Peterson, 2001), (Catherine

et al., 1999),(Leier et al., 2000),(Shimanovsky et al.,

2002),(SAEB et al., 2007).

2.2 Related Work

In 1999, (Catherine et al., 1999) started DNA

steganography, where data is encrypted in DNA and

hid into microdots. In 2000 (Leier et al., 2000) pro-

posed a hiding technique where data can be encoded

into DNA sequence, however the original data can be

easily recovered once the primer sequence is known.

In 2001 (Peterson, 2001) proposed another new

scheme for secret data hiding but unfortunately it

had some concerns as it can be cracked through a

frequency-based cryptanalysis technique. In 2010

(Shiu et al., 2010) proposed three reversible data hid-

ing schemes based on DNA sequence, the most signif-

icant one was the substitution method, yet its hiding

capacity is not efﬁcient enough.

In May 2012 (Khalifa and Atito, 2012) proposed

a Steganography technique, where data is encrypted

using DNA-based playfair cipher, then hid in a real

DNA sequence using a modiﬁed substitution tech-

nique to increase its hiding capacity. Although it

achieved higher hiding capacity than the original sub-

AnEnhancedDNA-basedSteganographyTechniquewithaHigherHidingCapacity

151

Table 1: Example of mapping codons to characters.

Character Codons

F GCT, GCC, GCA

B TAA, TGA, TAG

C TGT, TGC

N AAT, AAC

P CCT, CCC,CCG

O TTA, TTG

R CGT, CGG,CGA, CGC

M ATG

stitution method, yet this hiding capacity was not ef-

ﬁcient enough as a result of the ambiguity problem.

In October of the same year, (Taur et al., 2012)

proposed another modiﬁed substitution technique

achieving a high hiding capacity but without encrypt-

ing data which minimized its security.

2.3 Ambiguity Problem

One of the most critical cons of the current technique

is the ambiguity problem. Hereby, we are providing a

brief description of such problem.

In nature, each codon in a DNA sequence is con-

verted to one of the 20 amino acids forming a pro-

tein sequence that is responsible for a certain func-

tionality. Each amino acid is abbreviated by an En-

glish letter, i.e. ”Alanine” is an amino acid abbrevi-

ated with letter ”A”. Since We have 64 codons and

20 amino acids, each amino acid maps to at most

4 codons leading to the ambiguity problem. (Sabry

et al., 2010) solve this problem by adding two extra

bits next to each amino acid identifying which codon

it represents. (Table 1) is an example showing the

mapping of 8 characters to codons. For clariﬁcation

assume that we have DNA sequence composed of two

codons: ” GCC AAT”. This sequence when converted

to characters using (Table 1), it will be: ” F N ” .

In the decryption process when converting from

characters to DNA sequence, we will not know which

codon does character ”F” represent. This is solved by

adding 2 extra bits that represent a DNA base as clar-

iﬁed in (Table 2), to identify which codon does the

character represent. Assume that base ”A” represents

the 1st codon, ”G” for the 2nd codon, ”C” for the 3rd

and ”T” for the fourth codon. so instead of having ”F

N” we will have ”FG NA” , where ”G” is an ambigu-

ity base refers to second codon and ”A” refers to ﬁrst

codon.

2.4 Hiding using 5x5 Playfair Cipher

Technique

In this subsection we explain the currently used en-

cryption and decryption process using DNA-based

5x5 playfair cipher as well as the recent substitution

process used for DNA hiding mentioned in (Khalifa

and Atito, 2012).

2.4.1 Encryption and Decryption using the

Current DNA-based 5x5 Playfair Cipher

Technique :

The encrypting process works as follows:

1. Convert message text to the binary form where

each character is presented by 8 bits.

2. Transform the binary form into DNA letters using

(Table 2).

3. The DNA form is transferred to the Amino acids

letters representation according to the new al-

phabet distribution with the corresponding new

codons used in (Sabry et al., 2010), taking into

consideration two ambiguity bits for each Amino

acid letter.

4. Separate the ambiguity bits from the amino acids

sequence.

5. Use the key of Upper case letters to generate the

5X5 grid.

6. Apply the traditional Playfair cipher process.

7. Encrypted amino acids letters are transferred back

to DNA sequence form.

8. Concatenate the DNA sequence with the saved

ambiguity bits. Eventually we got an encrypted

DNA sequence.

The decryption process:

Given the key and the encrypted DNA sequence

1. Separate the ambiguity bits from the encrypted

DNA sequence.

2. Convert encrypted DNA sequence to amino acids

letters.

3. Use the key to generate the 5x5 playfair cipher

grid.

4. Perform the inverse of the playfair cipher process.

5. Use the ambiguity bits to get the correct DNA se-

quence.

6. Convert DNA sequence to binary form.

7. Convert the binary form to the original plaintext.

BIOINFORMATICS2015-InternationalConferenceonBioinformaticsModels,MethodsandAlgorithms

152

Table 2: DNA letter representation of binary bits.

DNA letter Binary representation

A 00

G 01

C 10

T 11

Although this 5x5 DNA-based playfair cipher

technique encodes encrypted data efﬁciently it suffers

from two drawbacks. First is the ambiguity problem,

which means that for every codon we are enforced to

add 2 more bits to solve the ambiguity problem i.e.

3/4 of the ciphered DNA is real data while 1/4 is

for solving the ambiguity problem, which minimizes

the hiding capacity. Second, the long list of unneces-

sary complicated iterations consume a lot of compu-

tational resources especially when dealing with large

data sizes.

2.4.2 Implemented Substitution Process

The above mentioned encryption technique uses

a modiﬁed substitution method to achieve the

Steganography goal. This technique is mentioned in

detail in (Khalifa and Atito, 2012), it proved to be

better than the original one mentioned in (Shiu et al.,

2010). It assumes that the length of cover DNA se-

quence is the same as the message itself (S), and ac-

cording to the 5x5 playfair cipher explained above,

only 3/4 of these bases represent the actual message

bits, since the remaining 1/4 are reserved for the am-

biguity bits. The hiding capacity is measured in terms

of the number of hidden bits per neuclotide

(bpn).

Since each DNA base actually represents two bits of

the binary message (M), therefore the hiding capacity

is represented by the following equation:

Capacity =

Sizeo f messageinbits

Sizeo f coverinbases

(1)

∗ |S| ∗ 2

|S|

bpn (2)

From the previous equation we got that the hid-

ing capacity of the current hiding technique using the

DNA-based 5x5 playfair cipher is 3 bits per 2 neu-

clotides.

3 PROPOSED TECHNIQUE

The proposed DNA-based Steganography technique

consists of two phases, First the ciphering phase,

the nucleoide is the same as the DNA-base

•

Construction of 4x4

PFC grid using Key

Msg to binary

conversion

Binary to English

letters conversion

Apply playfair cipher

process on English

letters

English letters to

DNA conversion

Encrypted Data

encoded in a DNA

sequence (Enc)

Construction of 4x4

PFC grid using Key

Binary to original

message

Enc to English letters

conversion

Apply the inverse of

playfair cipher process

on English letters

English letters to

Binary conversion

Encrypted Data

encoded in a DNA

sequence (Enc), Key

Figure 2: Overall Ciphering and Deciphering processes of

the proposed technique.

Table 3: Example of 16 randomly generated English letters

-Playfair cipher grid-.

H C M U

D G Z B

I A X J

Q V W F

where we used 4x4 playfair cipher grid as a mod-

iﬁed version to the current 5x5 playfair cipher grid

(Sabry et al., 2010), (Khalifa and Atito, 2012), (Atito,

A. et al., 2012) to avoid all its drawbacks, Figure 2

shows a short, illustrative diagram to the overall pro-

posed ciphering and deciphering processes. Second,

the hiding phase using the modiﬁed substitution pro-

cess in (Khalifa and Atito, 2012). As a result of mod-

ifying the ciphering process we succeeded in achiev-

ing higher hiding capacity than (Khalifa and Atito,

2012). In the following subsections we discuss in de-

tail the proposed Steganography algorithm from both

the sender and receiver side, followed by a step-by-

step illustrative example.

3.1 Ciphering

In our proposed ciphering algorithm we used 4x4

playfair cipher grid. Since the English alphabet con-

sists of 26 letters, we will use the Key’s ASCII value

as a seed number for generating 16 unique random

English letters to be represented by the 4x4 playfair

Table 4: 4x4 Binary grid.

0000 0001 0010 0011

0100 0101 0110 0111

1000 1001 1010 1011

1100 1101 1110 1111

AnEnhancedDNA-basedSteganographyTechniquewithaHigherHidingCapacity

153

Table 5: 4x4 DNA grid.

AA TC CG TG

GC TT TA GT

GG AT CT CC

CA AC AG GA

cipher grid as the example shown in (Table 3).

Another 4x4 grid will be used, called the 4x4 binary

grid where each cell contains one of the 4-bit possible

combinations as shown in (Table 4), where the values

in this grid are ordered in an ascending manner.

Again we will construct another 4x4 grid, called the

4x4 DNA grid that contains the 16 possible 2-DNA

letters combinations, the initial order of these com-

binations is shown in (Table 5). Then the encryption

process done by the sender is implemented as follows:

Preprocessing (Key)

1. Use the Key as a seed value for generating 16

random English letters to form the 4x4 playfair

cipher grid.

2. Use the Key to shufﬂe the 4x4 binary grid and

the 4x4 DNA grid.

Encryption (Msg, 4x4-pfc-grid, ShufﬂedBG, Shuf-

ﬂedDG)

1. Convert Msg to its binary form B.

2. Transform B to English letters E by mapping

each value in ShufﬂedBG to its corresponding

position in 4x4-pfc-grid.

3. Perform playfair cipher technique on E to get a

ciphered text C.

4. Map positions of C in 4x4-pfc-grid to its cor-

responding DNA letters in ShufﬂedDG lying in

the same cell position, to get the ﬁnal encrypted

DNA sequence Enc.

pfc-grid stands for playfair cipher grid, ShufﬂedBG is

the shufﬂed Binary Grid, and ShufﬂedDG is the shufﬂed

DNA grid.

Note that, the values in the 4x4 binary grid and the

4x4 DNA grid are initial values which must be shared

between the sender and the receiver. The sender will

use the Key to shufﬂe these grids, where the resultant

shufﬂed grids will be used for encrypting the binary

data into DNA-based encrypted data.

3.2 Hiding Phase

After encryption, we applied the recent substitution

method (Khalifa and Atito, 2012) for hiding data to

achieve the goal of Steganography. By using equa-

tion(1) with the proposed encryption technique, we

will achieve higher hiding capacity as proved by the

following equation:

|S| ∗ 2

|S|

= 2bpn (3)

From the previous equation, we can see the great im-

pact of our proposed encryption technique on the sub-

stitution method. It has a signiﬁcant higher hiding ca-

pacity, as a result of the ambiguity problem removal.

In other words, the hiding capacity is improved by

25% since in (Khalifa and Atito, 2012) it was 3/2 bits

per nucleotide, while in our proposed technique it is 2

bits per nucleotide.

3.3 Extraction

The extraction process is formed by the receiver, to

extract the hidden encrypted DNA sequence. In our

technique we used the extraction process in (Khalifa

and Atito, 2012).

3.4 Deciphering

The receiver will receive the encrypted DNA se-

quence and the Key through a secure channel. Then

s/he will use the Key to be able to shufﬂe the 4x4

binary grid and the 4x4 DNA grid to decrypt the

extracted encrypted DNA sequence. Ultimately, same

key must be used by the sender and the receiver. The

following is the proposed decryption algorithm which

is the reverse of the aforementioned Encryption algo-

rithm. It will be used by the receiver to retrieve the

original data from the encrypted DNA sequence.

Decryption(Enc, Key)

1. Perform the Preprocessing function mentioned

before the encryption step to obtain the 4x4-pfc-

grid, ShufﬂedBG and the ShufﬂedDG.

2. Map the positions of each 2 letters of the en-

crypted DNA sequence Enc in ShufﬂedDG to its

corresponding positions in 4x4-pfc-grid to get

English text C.

3. Perform the inverse of playfair cipher technique

on C to get E.

4. Map E to ShufﬂedBG to get its binary form B.

5. Convert B to the original message Msg.

Our proposed algorithm allows the message and

the key to be of any type. The used 4x4 matrix elimi-

nates the ambiguity problem that was presented in the

previous algorithms(Sabry et al., 2010), (Khalifa and

BIOINFORMATICS2015-InternationalConferenceonBioinformaticsModels,MethodsandAlgorithms

154

Table 6: 4x4 Shufﬂed Binary grid.

0111 0010 1100 0011

0110 0001 1000 0000

1001 0101 1010 1110

0100 1111 1011 1101

Atito, 2012). Additionally, it provides more simplic-

ity with no redundancy in the processes, which leads

to higher remarkable performance and lower execu-

tion time.

Moreover, as mentioned in the steps of our algo-

rithm, we use the numeral value of the key to gen-

erate random English letters to construct the playfair

cipher grid, which makes the playfair cipher tech-

nique more confusing to the attacker than the tradi-

tional one; achieving higher security. On the other

hand, any binary message can be encrypted in a DNA

sequence of half its length as will be clariﬁed in the

illustrative example.

3.5 Illustrative Example

Assume the message: Hello and the Key : 2411

The Sender side:

1. Encryption process

(a) Generate 16 random letters using the given key,

(Table 3) will be generated.

(b) Use the key to shufﬂe the initial values in (Table

4) and (Table 5), where (Table 6) and (Table 7)

will be generated respectively.

0100100001100101011011000110110001101111

(Binary sequence)

(d) Get the English letters sequence by mapping

the position of each 4 bits of B in (Table 6) to

their corresponding positions in (Table 3): Q Z

D A D M D M D V (Original English text)

(e) Perform the playfair cipher process on the En-

glish text: W D G I Z H Z H G Q (Ciphered

text)

(f) Convert the ciphered text to a DNA sequence

using (Table 3) and (Table 7), the resulted se-

quence: CCTATCATGGGTGGGTTCGC (En-

crypted DNA sequence)

Note: the Binary message consists of 40 bits,

encrypted in a DNA sequence of 20 bases. i.e.

half its length.

2. Hiding process

(a) Use a suitable Reference DNA sequence from

NCBI database (NCBI database).

Table 7: 4x4 Shufﬂed DNA grid.

GT CG CA TG

TA TC GG AA

AT TT CT AG

GC GA CC AC

(b) Hide the Encrypted DNA sequence ”CCTAT-

CATGGGTGGGTTCGC” in the chosen refer-

ence DNA sequence using the substitution pro-

cess mentioned in (Khalifa and Atito, 2012).

The Receiver side:

Given the fake DNA sequence, the reference DNA se-

quence and the key.

1. Extraction process

(a) Extract the hidden encrypted DNA sequence,

using the reverse of the substitution process

mentioned in (Khalifa and Atito, 2012).

(b) The result is encrypted DNA sequence: ”CC-

TATCATGGGTGGGTTCGC”.

2. Decryption process

(a) Generate 16 random letters using the given key,

(Table 3) will be generated.

(b) Use the key to shufﬂe (Table 4) and (Table 5),

(Table 6) and (Table 7) will be generated.

glish letters by mapping their positions in (Ta-

ble 7) to their corresponding positions in (Table

3): W D G I Z H Z H G Q (Ciphered text)

(d) Perform the inverse of playfair cipher process

Q Z D A D M D M D V (Original English text)

(e) Map the positions of the English letters in (Ta-

ble 3) to a binary form in their corresponding

positions in (Table 6)

0100100001100101011011000110110001101111

(f) Convert the Binary form to the original mes-

sage ”Hello”

4 PERFORMANCE ANALYSIS

In this section we discuss the cracking probability as

well as the experimental results on our algorithm im-

plementation

4.1 Cracking Probability

Despite the fact of simplifying the recent DNA-based

playfair cipher algorithm, the cracking probability of

our proposed algorithm remains high and becomes

AnEnhancedDNA-basedSteganographyTechniquewithaHigherHidingCapacity

155

even more confusing to the attacker. In case of

both the recent technique and the proposed one, the

attacker needs 4 types of information to decrypt a

message, Binary representation, Reference DNA, the

Complementary rule (Khalifa and Atito, 2012) and

the ciphering technique. Probability to get the binary

scheme b is:

P(b) =

(4)

Since we have 4 DNA bases, the number of possible

binary schemes is 4!.

Probability to get the Reference DNA r:

P(r) =

1.6 ∗ 10

(5)

Since there exists 1.6 ∗ 10

DNA sequences on the

DNA database(NCBI database).

Probability of the complementary rule c is:

P(c) =

(6)

Therefore the overall cracking probability k is:

P(k) = P(b) ∗ P(r) ∗ P(c) =

24 ∗ 1.6 ∗ 10

∗ 16

(7)

In case of the ciphering technique, there are 3 as-

pects that make our proposed DNA-based playfair ci-

pher technique stronger than the traditional one.

1. We are using 4x4 grid instead of the traditional

5x5 playfair cipher grid, which means that the at-

tacker might guess a sequence of English letters

which are not in the grid.

2. We are not ciphering plaintext, but we are cipher-

ing the binary form of the plain text. This means

that we can cipher letters, numbers and even punc-

tuation symbols.

3. The Key used in our modiﬁed playfair cipher tech-

nique is not restricted to characters only, it can be

of any type since we get the numeral of the key

and use it as a seed value for generating any 16

English letters to be presented by the grid.

All the above new aspects of our proposed mod-

iﬁed DNA-based playfair cipher technique makes it

more robust and its cryptanalysis becomes harder to

break.

4.2 Experimental Results

Experimental results of our proposed DNA-based

Steganography technique was compared with the re-

sults in(Khalifa and Atito, 2012) to conﬁrm the supe-

riority of our proposed algorithm regarding the max-

imum size of bits that can be embedded in the cover

145 155 165 175 185 195 205 215 225

Capacity (kb)

Reference DNA sequence Length (bp)

X1000

Current tech.

Proposed tech.

Figure 3: Capacity of the current technique Vs the proposed

one.

media named as the hiding capacity, as well as the

percentage of the maximum hiding capacity needed

to hide the message named as the actual payload and

the execution time. Our algorithm was tested on the

same used 8 benchmarks adopted from the (NCBI

database). As shown in Figure 3, Figure 4 and Figure

5, the x-axis represents DNA sequences with different

sizes used for hiding in terms of base-pairs(bp).

In Figure 3, the y-axis presents the hiding capac-

ity of the 8 reference DNA sequences. Despite the

fact of our proposed technique simplicity, it improved

the hiding capacity by 25% more than the current

technique, since the current technique hides 3/2 bits

per nucleotide, the proposed technique hides 2 bits

per nucleotide; for example a reference DNA of size

149,884 bp can hide a message of length up to 27.44

Kb by using the current technique while the proposed

one can hide up to 36.56 Kb.

The actual payload of the proposed technique is

compared with that of the current one using a message

of size 10 kb. As shown in Figure 4, the less actual

payload percentage, the more data can be hidden. For

example, the 10 Kb message occupies 26.45% in a

reference DNA of length 206,488 bp using the current

technique, while the same message occupies 19.83%

in the same reference DNA using the proposed tech-

nique. In other words, the proposed technique can

efﬁciently hide a larger messages in comparison with

the current one, as illustrated by Figure 4. It is worth

to note, that the hiding capacity of the proposed tech-

nique increases by an average rate of 25% in com-

parison with the current technique, while the actual

payload decreases by almost the same rate.

In Figure 5, the y-axis represents the execution

time. The two illustrated curves represent the perfor-

mance of the current hiding algorithm and our pro-

posed one. It is easily noted that the execution time

of the proposed algorithm is signiﬁcantly less than the

current one as it get rid of the repetitive steps of the

current technique.

BIOINFORMATICS2015-InternationalConferenceonBioinformaticsModels,MethodsandAlgorithms

156

145 155 165 175 185 195 205 215 225

Actual Payload (%)

Reference DNA sequence Length (bp)

X1000

Current tech.

Proposed tech.

Figure 4: Actual payload of the current technique Vs the

proposed one.

100

120

145 155 165 175 185 195 205 215 225

Time (sec)

Reference DNA sequence Length (bp)

X1000

Current tech.

Proposed tech.

Figure 5: Execution time of the current technique Vs the

proposed one.

5 CONCLUSIONS AND FUTURE

WORKS

This paper proposed a new DNA-based Steganog-

raphy algorithm to achieve a high hiding capacity.

It’s composed of two steps, ﬁrstly data encryption

using enhanced DNA-base playfair cipher, Secondly

utilizing the recent substitution technique for hid-

ing. The proposed algorithm enhanced the commonly

used playfair cipher and got rid of the overhead ambi-

guity bits. It proved that a message can be encrypted

in a DNA sequence in half of its length. Moreover,

the hiding capacity of the cover DNA sequence is im-

proved by 25% where each 2 bits are hidden in one

DNA base as a result of the playfair cipher modiﬁ-

cation. Additionally, we enhanced the security and

achieved lower execution time as well. The conducted

experimental studies proved the superiority of our

proposed approach in terms of higher hiding capac-

ity and better time performance in comparison with

the current DNA-based Steganography algorithms.

Using DNA as a medium for Steganography is very

promising, due to the fact of its huge storage capac-

ity. As a future work, we should focus on imitating

the DNA nature by developing algorithms with higher

data hiding capacity.

REFERENCES

Adleman, L. (1994). Molecular computation of solutions to

combinatorial problems. Science 11, 266:1021–1024.

Alberts, B. and Johnson, A. (2008). Molecular Biology of

The Cell. The publishing company, US, 5th edition.

Atito, A., Khalifa, A., and Rida, S.Z. (2012). DNA-Based

Data Encryption and Hiding Using Playfair and In-

sertion Techniques. Journal of Communications and

Computer Engineering, 2:44–49.

Catherine, C., Risca, V., and Bancroft, C. (1999). Hiding

messages in dna microdots. Nature Magazine, 399.

Khalifa, A. and Atito, A. (2012). High-capacity dna-based

steganography. The 8th Int. Conf. on INFOrmatics

and Systems.

Leier, A., Richter, C., Banzhaf, W., and Rauhe, H. (2000).

Cryptography with dna binary strands. BioSystems

57.

NCBI data base. http://www.ncbi.nlm.nih.gov/

Peterson, I. (2001). Hiding in dna. Muse.

Sabry, M., Hashem, M., Nazmy, T., and Khalifa, M. E.

(2010). A dna and amino acids-based implementation

of playfair cipher. Int. Journal of Computer Science

and Information Security, 8.

SAEB, M., EL-ABD, E., and EL-ZANATY, M. E. (2007).

On covert data communication channels employ-

ing dna recombinant and mutagenesis-based stegano-

graphic techniques. pages 200–206. CEA’07 Proceed-

ings of the 2007 annual Conference on Int. Conf. on

Computer Engineering and Applications.

Shimanovsky, B., Feng, J., and Potkonjak, M. (2002). Hid-

ing data in dna. The 5th Int. Workshop on Information

Hiding, 2578:373–386.

Shiu, H., Ng, K., Fang, J., Lee, R., and Huang, C. (2010).

Data hiding methods based upon dna sequences. EL-

SEVIER, 180:2196–2208.

Smith, W. M. and Group, T. T. (2003). Dna based steganog-

raphy for security marking. XIX International Secu-

rity Printers Conference.

Taur, J.-S., Lin, H.-Y., Lee, H.-L., and Tao, C.-W. (2012).

Data hiding in dna sequences based on table look up

substitution. Int. Journal of Innovative Computing, In-

formation and Control, 8:6585–6598.

AnEnhancedDNA-basedSteganographyTechniquewithaHigherHidingCapacity

157
