Fast Regularized Least Squares and k-means Clustering Method for

Intrusion Detection Systems

Parisa Movahedi, Paavo Nevalainen, Markus Viljanen and Tapio Pahikkala

Dept. of Information Tech., University of Turku, FI-20014, Turku, Finland

Keywords:

Intrusion Detection, k-means Clustering, Regularized Least Squares, Kernel Approximation.

Abstract:

Intrusion detection systems are intended for reliable, accurate and efﬁcient detection of attacks in a large

networked system. Machine learning methods have shown promising results in terms of accuracy but one dis-

advantage they share is the high computational cost of training and prediction phase when applied to intrusion

detection. Recently some methods have been introduced to increase this efﬁciency. Kernel based methods

are one of the most popular methods in the literature, and extending them with approximation techniques we

describe in this paper has a huge impact on minimizing the computational time of the Intrusion Detection

System (IDS).

This paper proposes using optimized Regularized Least Square (RLS) classiﬁcation combined with k-means

clustering. Standard techniques are used in choosing the optimal RLS predictor parameters. The optimization

leads to fewer basis vectors which improves the prediction speed of the IDS. Our algorithm evaluated on the

KDD99 benchmark IDS dataset demonstrates considerable improvements in the training and prediction times

of the intrusion detection while maintaining the accuracy.

1 INTRODUCTION

In recent years, attack detection has gained tremen-

dous attention. Internet and devices connected to it

have resulted in more network trafﬁc and conﬁdential

information moving around. Utilizing accurate, but

also efﬁcient, detection methods is therefore essential.

Especially, when using Machine Learning classiﬁers,

the prediction step has to be as efﬁcient as possible.

Anomaly detection is one of the most common ma-

chine learning tasks in this respect. It can be viewed

as a classiﬁcation problem distinguishing abnormal

from normal trafﬁc based on the feature characteris-

tics of the trafﬁc ﬂow.

Techniques such as clustering and artiﬁcial neu-

ral networks (ANN) (Portnoy et al., 2001), kernel

based methods (Kim and Kim, 2005b), genetic algo-

rithms (Li, 2004), fuzzy logic (Kaur and Gill, 2013)

and many others have been applied to IDS.

Support vector machine (SVM) (Vapnik, 1995) is

one of the most popular kernel based machine learn-

ing techniques (Sch

olkopf and Smola, 2002) used in

classiﬁcation problems. It has been applied to in-

trusion detection problems (Sung and Mukkamala,

2003; Li et al., 2003) as well. Kernel based methods

enable solving nonlinear problems by mapping the in-

put space to a feature space in which the data is sepa-

rated by a hyperplane. The kernel function implicitly

deﬁnes the feature space by calculating an inner prod-

uct of two given inputs.

In (Kim and Kim, 2005a), SVM is used for attack

classiﬁcation in intrusion detection systems. (Sotiris

et al., 2010) have used one-class SVM technique for

anomaly detection to a normal class and attack class

of data. One drawback of SVM based methods are

that SVM training requires solving a convex quadratic

programming which has a steeply increasing comput-

ing cost as a function of the size of the training data.

One alternative to the quadratic programming

based SVM is the regularized least squares algorithm

(RLS or LS-SVM). In (Rifkin et al., 2003), RLS

binary classiﬁer is used to minimize the regularized

square loss. The advantage over the well established

SVM is that RLS training requires constructing and

solving a single system of linear equations instead of

solving a convex quadratic problem required by SVM.

RLS and SVM both seek a Tikhonov regularized so-

lution from the representing kernel Hilbert space, but

they have different loss functions. The methods have

comparable accuracy (Poggio and Girosi, 1990).

Our efﬁciency focused approach is closely related

to two previous studies. In (Gao and Wang, 2006),

264

Movahedi P., Nevalainen P., Viljanen M. and Pahikkala T..

Fast Regularized Least Squares and k-means Clustering Method for Intrusion Detection Systems.

DOI: 10.5220/0005246802640269

In Proceedings of the International Conference on Pattern Recognition Applications and Methods (ICPRAM-2015), pages 264-269

ISBN: 978-989-758-077-2

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

LS-SVM based intrusion detection system utilizes

kernel approximation and greedy search. We will

compare our results to their method in terms of accu-

racy and computational complexity. We also compare

to the latest work of (Kabir, 2014), which uses op-

timum allocation based LS-SVM. They have a two-

step approach: ﬁrst phase is an optimum allocation

scheme to determine the sufﬁcient amount of training

data which is representative of the whole data set. The

second phase then applies LS-SVM on this smaller

training set.

Our approach has two steps, those steps are:

1. k-means clustering algorithm on the training

dataset to get optimized base vectors suitable for

classiﬁcation to each attack type.

2. A kernel approximation method to minimize the

kernel space computation and fast parameter se-

lection methods.

Both steps introduce one new parameter for the pre-

diction performance optimization search. New pa-

rameters are k and M, the k-means cluster number and

the size of the approximation base. This arrangement

has a huge impact on training and prediction time of

our the intrusion detection algorithm.

This paper is organized as follows. The RLS al-

gorithm, kernel approximation method and optimized

cross validation method (Pahikkala et al., 2012) are

outlined in Ch. 2. The implementation is built around

RLSCore package

. We also present the intrusion de-

tection system based on RLS and k-means clustering

in Ch. 2. Ch. 3 contains experiments on the KDD99

intrusion detection data set and comparisons to other

IDS systems. The last section presents the conclusion

from the experiments.

2 METHOD

2.1 Regularized Least Squares

Given a training set {(x

, y

), ....., (x

, y

)}, where the

feature vector x

∈ R

and the class labels y

∈ R.

, y

) are independent identically distributed (iid)

samples. The RLS formulation is to ﬁnd c

∗

such that:

∗

= arg min

ky − Kck

+ λc

Kc (1)

where c = {c

}

i∈N

are the weights, y = {y

}

i∈N

are

the labels, λ is the regularization parameter and K =

RLScore, https://github.com/aatapa/RLScore

{K(x

, x

)}

i, j∈N

is the kernel matrix. In this paper we

use a Gaussian kernel function:

K(x

, x) = exp



− xk

2σ



(2)

2.2 Kernel Approximation

RLS approach requires O(n

) memory space for K

matrix and O(n

) time complexity for solving the

corresponding matrix equation. The steeply increas-

ing computational costs can be overcome by using

an approximation of the kernel space where only a

subset of basis vectors are used. This avoids stor-

ing the entire kernel matrix in the memory and de-

creases the time complexity. We use the Nystr

om ker-

nel approximation method used in Regularized Least

Squares Classiﬁcation (Rifkin et al., 2003), (Airola

et al., 2011).

The training set X

= {x

|i ∈ R ⊆ N} is made small

enough to gain computational advantage over the non-

sparse RLS, i.e. | R || N |, while seeking to not give

up too much prediction performance. Denote the full

data set and the new reduced training set by the corre-

sponding index sets N and R. The training points X

are explicit and omitted points X

N\R

will be approx-

imated as a linear combination of the points in X

Nystr

om approximation

K ≈ K of the kernel matrix

is deﬁned as

K = K

)

−1

(3)

where K

= {K

i j

}

i∈N, j∈R

. Similar set indexing

scheme for matrices is employed in the following text.

Now instead of explicitly constructing the approx-

imation kernel

K we are able to calculate its Cholesky

decomposition matrix

C = K

−T

(4)

The cost of calculating C

−1

is O(|R|

) and the mem-

ory complexity is O(n|R|). The cost of the matrix

multiplication equals O(n|R|

) which scales consider-

ably better than straight-forward decomposition of the

kernel matrix. (Airola et al., 2011) uses the Cholesky

decomposition of K

having K

= CC

. For com-

prehensive overview see (Airola et al., 2011). Sim-

ilar advantage carries on to prediction computation,

which can be formulated as:

˜y =

∑

i∈ R

K(x, x

) (5)

where weights b

are solved once for the whole com-

putation (see the actual derivation from (Rifkin et al.,

2003)) leading to O(|R|) complexity.

FastRegularizedLeastSquaresandk-meansClusteringMethodforIntrusionDetectionSystems

265

2.3 k-means Clustering

One of the important tasks in kernel approximation is

the selection of basis vectors i.e. the subset R because

that selection has a direct impact on how well

K ap-

proximates K. There are various methods for choos-

ing the basis vectors such as k-means clustering and

uniform sampling.

One of the widely used and simple ﬂat clustering

algorithms is the k-means algorithm (Hartigan, 1975).

The algorithm divides the input set to k different clus-

ters in an iterative manner. The ﬁrst iteration begins

with k randomly selected cluster center candidates

∈ R

, which form a set M = {m

}, i = 1...k, which

is one parameter of the minimization process. Each

point gets assigned to the closest center candidate, and

at each iteration the center candidates are updated to

the new mean of the assigned points. These iterations

are repeated until the algorithm converges.

The k-means clustering algorithm also minimizes

the following within-cluster sum of squares (WCSS)

with given k:

∗

= argmin

M={m

}

∑

j=1

∑

i∈N



− m



(6)

We seek to extract cluster centroids M to represent

the cluster entities. Therefore, deﬁned by this mea-

sure, the k-means algorithm ﬁnds the best possible

extracted cluster centroids. This makes the algorithm

a safe way to ﬁnd the reduced kernel set R. Reduced

sets of different sizes can be obtained by simply vary-

ing k.

2.4 Proposed Framework

Our proposed framework consist of four main stages,

see Fig. 1:

• Pre-processing of the data. This includes normal-

ization and rejection of invalid entries.

• k-means clustering method Eq. (6) is used to par-

tition the data to k clusters (centroids). The search

Figure 1: The Proposed IDS Framework.

of best k value is completely automated, we have

used the range 20 ≤ k ≤ 100.

• Predictor is constructed based on RLS formu-

lation Eq. (1), using the Gaussian kernel func-

tion (2). The optimal parameters λ and σ (regu-

larization and Gaussian scale) are found using fast

cross-validation (Pahikkala et al., 2012).

• Testing performance with the test data set.

The stage two provides the centroids which serve

as the basis vectors for our approximated kernel func-

tion in the RLS learner. Centroids represent the aver-

age characteristics of the group of data points and the

approximated kernel function is based on them. They

do not co-inside with the data (they do not have la-

bels, for example). The RLS algorithm is modiﬁed to

take this into account.

The fast cross-validation method in stage three has

O(n

) time complexity for the entire leave-one-out

cross-validation scheme. This makes it cheaper to

scan through the RLS parameter space. Basis vec-

tors and the obtained ﬁxed kernel parameters together

form the predictor. The approximated kernel is pre-

sented in Eqs. (3) and (4).

3 EXPERIMENTS

We now present the experiments conducted to eval-

uate the training time and detection accuracy. The

main objective of this study is to enhance the pre-

diction time of the IDS. To be able to compare our

method with other IDS methods we have chosen to

use the KDD99

. benchmark data set which is a data

set derived out of the 1998 DARPA intrusion detec-

tion dataset presented by MIT’s Lincoln Lab.

KDD99 consists of ﬁve million training data in-

stances and about two million test data instances of

network ﬂow trafﬁc. We use the 10% of KDD la-

beled data, totaling 494021 training data points and

311029 test data points. Each instance of data rep-

resents a well established IP connection between two

hosts, containing 41 different categorical or numeri-

cal attributes of that connection. Training data set in-

cludes 24 different attack types which can be further

categorized to 4 main categories.

These main attack categories are: Denial of ser-

vice attack (DoS), Prob attack, User To Root attack

(U2R) and Remote to Local attack types (R2L). In-

cluding the normal state as a category (NORMAL),

this sums up to 5 different categories.

KDD99, http://kdd.ics.uci.edu/databases/kddcup99/

kddcup99.html

ICPRAM2015-InternationalConferenceonPatternRecognitionApplicationsandMethods

266

We compare our method with the method pro-

posed in the work of (Kabir, 2014) and (Gao and

Wang, 2006). For this purpose we had to make two

different subsets of KDD99 to make the environment

comparable to each of their methods.

The data has attack type feature, which has cat-

egorical values: NORMAL, DOS, Probe, U2R and

R2L. To correctly reﬂect the arrangements of (Kabir,

2014), the data was partitioned into four different data

sets D1,..,D4, each containing instances of normal

data and one type of attack data. For example the

D1 data set consists of normal and DoS instances. To

make our data compatible with RLS classiﬁer we have

converted the categorical data into numerical data and

normalized all the samples to have unit norm. Since

the kernel approximation parameters are different for

each combination of the four classes of attacks, in this

paper we have constructed four different predictors,

one for each of these attack classes.

Our Environment consists of Python 2.7, 3.8 G

RAM, Dual Core Dell Processor, CPU 2.26 GHz. We

run the program 10 times with different train subsets

and report average results of the RLS learner. We

give Precision, Recall and F-value results of Fast

k-means RLS algorithm, and the training and testing

times of our method.

3.1 First Experiment

In this Section we will compare our Fast KM-RLS

method to the other two methods of intrusion detec-

tion. First is the Layered approach using Conditional

Random Fields presented by (Gupta et al., 2010) and

second is the OA-LS-SVM IDS frame work presented

by (Kabir, 2014). We chose the training and testing

partitions similar to theirs to make the results compa-

rable. We focus on improving the IDS prediction time

therefore all comparisons are mainly based on predic-

tion time needed for classifying each trafﬁc instance.

3.1.1 D1: DoS Attack vs Normal Trafﬁc

For the training phase we chose 9,000 random nor-

mal trafﬁc instances and 9,000 DoS attack instances

from the KDD99 train data set. We tested the learner

on 5,000 of normal and 6,000 of DoS instances from

KDD99 test data set. Optimal results for our KM-

RLS were obtained by λ = 4 and σ = −5 using k = 30

cluster centroids. Table 1 demonstrates the results of

our algorithm compared to Kabir’s and Guptal’s re-

sults. Test time of Fast KM-RLS for 11,000 instances

is 0.12 seconds and for an instance it is 0.009 millisec-

onds which is much faster prediction rate than the two

methods provide.

Table 1: DoS attack detection, Comparison of KM-RLS,

Kabir’s OA-LS-SVM and Gupta’s CRF method.

Method Precision Recall Fscore

Train Time

(sec)

Test Time

Per Instance

(millisec)

Fast

KM-RLS

99.84 97.67 98.74 169.23 0.009

OA-LS

-SVM

99.86 97.31 98.56 79.36 0.4

Layered

CRF

99.78 97.05 98.10 256.11 0.05

3.1.2 D2: Prob Attack Vs Normal Trafﬁc

For the training phase we chose 9,000 random nor-

mal trafﬁc instances and 2,000 Prob attack instances

from the whole KDD99 train data set. We tested the

learner on 5,000 normal and 3,000 Prob instance of

the KDD99 test data set Table 2. Test time of 8,000

instance of trafﬁc is 0.17 seconds and for one instance

it is 0.01 milliseconds. Optimal detection for Prob at-

tack was obtained by λ = 1 and σ = −3, using 80

cluster centroids. This achieved 99.73 percent accu-

racy on the training set.

Table 2: Prob attack detection.

Method Precision Recall Fscore

Train Time

(sec)

Test Time

Per Instance

(millisec)

Fast

KM-RLS

98.11 95.80 96.94 517.52 0.01

OA-LS

-SVM

97.64 90.89 94.14 22.49 0.2

Layered

CRF

82.53 88.06 85.21 200.6 0.03

3.1.3 D3: R2L Attack Vs Normal Trafﬁc

For the training phase we chose 1,000 random normal

trafﬁc instances and all 1,126 R2L attack instances

from the whole KDD99 train data set. We tested the

learner on 10,000 normal and 8,000 R2L instances of

the KDD99 test data set Table 3. The test time of

18,000 instances of trafﬁc is 0.14 seconds and for one

instance it is 0.008 milliseconds. Optimal detection

for the R2L attack is obtained by λ = 8 and σ = −15,

using 30 cluster centroids for the basis vectors.

Table 3: R2L attack detection.

Method Precision Recall Fscore

Train Time

(sec)

Test Time

Per Instance

(millisec)

Fast

KM-RLS

73.81 97.86 84.15 30.65 0.008

OA-LS

-SVM

83.45 71.48 76.93 3.40 0.1

Layered

CRF

92.35 15.10 25.94 23.40 0.09

FastRegularizedLeastSquaresandk-meansClusteringMethodforIntrusionDetectionSystems

267

3.1.4 D4: U2R Attack Vs Normal Trafﬁc

For the training phase we chose 1000 random normal

trafﬁc instances and 52 U2R attack instances from the

whole KDD99 train data set. We tested the learner on

5,000 normal and all the U2R instances of the KDD99

test data set Table 4. Test time of 5,078 instances

is 0.09 seconds and for one instance it is 0.07 mil-

liseconds. Optimal detection for the U2R attack is

obtained by λ = 2 and σ = −2, using 70 cluster’s cen-

troids for the basis vectors.

Table 4: U2R attack detection.

Method Precision Recall Fscore

Train Time

(sec)

Test Time

Per Instance

(millisec)

Fast

KM-RLS

88.83 22.45 37.09 9.40 0.007

OA-LS

-SVM

95.04 38.24 54.51 11.68 0.2

Layered

CRF

52.16 55.02 53.44 8.35 0.05

Our algorithm shows considerable improvements

in the prediction time of a test point, making the In-

trusion Detection system closer to real time detection.

It maintained the high accuracy in detection of DoS,

Prob and R2L attack, see Table 2. The U2R attack

(Table 4) has also considerably better detection time

but the accuracy is not as good as the other two meth-

ods.

3.2 Second Experiment

Gao presented the kernel approximation method

for LS-SVM (Gao and Wang, 2006), an algorithm

similar to our approach but with a different method

of choosing the basis vectors and kernel parameters.

We will use their choice of data set from KDD99 in

order to compare our prediction time to theirs.

First we combined all the KDD99 training and test

data sets and then chose 2,500 random DoS attacks

and 2,500 normal trafﬁc cases as the set D1, 2,500

Prob attack and 2,500 normal cases as the set D2,

and 2500 instances of both R2L and U2R attacks with

2,500 normal data points as the set D3. We used 40%

of the data for training and 60% for testing the RLS.

The result of using our method and Gao’s method are

presented in Tables 5, 6 and 7.

Our approach is an order of magnitude faster in

both training and testing times of the IDS. The accu-

racy stays comparable to the other IDS methods. We

have come very close to a real time detection system.

Table 5: DoS attack detection, Comparison of KM-RLS,

Gao’s KSA-SVM and LS-SVM.

Method

Basis

Vectors

Accuracy

False

Alarm

Train

Time

(sec)

Test Time

Per Instance

(millisec)

Fast

KM-RLS

30 98.6 0.3 5.01 0.003

KSA-SVM 46 98.5 0.4 8160 0.04

LS-SVM 600 55.02 53.44 1320 5.5

Table 6: Prob attack detection.

Method

Basis

Vectors

Accuracy

False

Alarm

Train

Time

(sec)

Test Time

Per Instance

(millisec)

Fast

KM-RLS

30 96.9 0.4 6.02 0.006

KSA-SVM 58 98.8 0.3 13044 0.05

LS-SVM 600 82.5 3.8 2040 8.21

Table 7: U2R and R2L attack detection.

Method

Basis

Vectors

Accuracy

False

Alarm

Train

Time

(sec)

Test Time

Per Instance

(sec)

Fast

KM-RLS

50 93.3 10.9 8.04 0.006

KSA-SVM 83 94.6 10.5 13044 0.08

LS-SVM 400 90.8 11.3 2040 2.613

4 CONCLUSIONS

To address the problem of efﬁciency in networked

intrusion detection systems caused by the massive

amount of data needed to be processed and classiﬁed,

we have proposed a Fast Regularized Least Squares

algorithm combined with k-means clustering. This

enables us to choose optimized basis vectors to con-

struct an approximated kernel function. We have

combined this with fast cross validation techniques

to select best kernel parameters in a reasonable time.

Having optimized basis vectors result in a smaller

comparison matrix and better detection time of each

instance while maintaining accuracy.

This paper demonstrates that the detection time

can be improved signicantly using existing algorithms

applied already in other Machine Learning ﬁelds.

Benchmarking on the KDD99 network attack data

shows highly signiﬁcant improvements in this regard.

The problem complexity is affected by approximated

kernel and by feature selection, both reduce the size

of the problem independently.

In the future we will experiment with different fea-

ture selection methods to choose best trafﬁc feature

set representing each attack type. The used fast KM-

RLS method allows efﬁcient feature selection. This

will keep the training time competitive while making

the prediction phase even more efﬁcient.

ICPRAM2015-InternationalConferenceonPatternRecognitionApplicationsandMethods

268

ACKNOWLEDGEMENTS

We like to thank for anonymous referees for the in-

sightful comments.

REFERENCES

Airola, A., Pahikkala, T., and Salakoski, T. (2011).

On learning and cross-validation with decomposed

nystr

om approximation of kernel matrix. Neural Pro-

cessing Letters, 33(1):17–30.

Gao, H. and Wang, X. (2006). Ls-svm based intrusion de-

tection using kernel space approximation and kernel-

target alignment. In The Sixth World Congress on

Intelligent Control and Automation, 2006. WCICA

2006., volume 1, pages 4214–4218.

Gupta, K. K., Nath, B., and Kotagiri, R. (2010). Layered

approach using conditional random ﬁelds for intrusion

detection. IEEE Transactions on Dependable and Se-

cure Computing, 7(1):35–49.

Hartigan, J. (1975). Clustering algorithms. New York: John

Wiley & Sons.

Kabir, M. (2014). A statistical framework for intrusion de-

tection system. In Proceedings of the 11th Interna-

tional Conference on Fuzzy Systems and Knowledge

Discovery (FSKD 2014).

Kaur, H. and Gill, N. (2013). Host based anomaly detec-

tion using fuzzy genetic approach (fga). International

Journal of Computer Applications, 74(20):5–9.

Kim, B.-J. and Kim, I. (2005a). Machine learning approach

to realtime intrusion detection system. In Zhang, S.

and Jarvis, R., editors, AI 2005: Advances in Artiﬁcial

Intelligence, volume 3809 of Lecture Notes in Com-

puter Science, pages 153–163. Springer Berlin Hei-

delberg.

Kim, B.-J. and Kim, I.-K. (2005b). Kernel based intrusion

detection system. In Fourth Annual ACIS Interna-

tional Conference on Computer and Information Sci-

ence, 2005., pages 13–18.

Li, H., Guan, X.-H., Zan, X., and Han, C.-Z. (2003). Net-

work intrusion detection based on support vector ma-

chine. Journal of Computer Research and Develop-

ment, 6:799–807.

Li, W. (2004). Using genetic algorithm for network intru-

sion detection. Proceedings of the United States De-

partment of Energy Cyber Security Group, pages 1–8.

Pahikkala, T., Suominen, H., and Boberg, J. (2012). Ef-

ﬁcient cross-validation for kernelized least-squares

regression with sparse basis expansions. Machine

Learning, 87(3):381–407.

Poggio, T. and Girosi, F. (1990). Networks for approx-

imation and learning. Proceedings of the IEEE,

78(9):1481–1497.

Portnoy, L., Eskin, E., and Stolfo, S. (2001). Intrusion de-

tection with unlabeled data using clustering. In Pro-

ceedings of ACM CSS Workshop on Data Mining Ap-

plied to Security. Citeseer.

Rifkin, R., Yeo, G., and Poggio, T. (2003). Regularized

least-squares classiﬁcation. Nato Science Series Sub

Series III Computer and Systems Sciences, 190:131–

154.

Sch

olkopf, B. and Smola, A. J. (2002). Learning with ker-

nels: support vector machines, regularization, opti-

mization, and beyond. MIT press, Cambridge, MA.

Sotiris, V. A., Tse, P. W., and Pecht, M. G. (2010). Anomaly

detection through a bayesian support vector machine.

IEEE Transactions on Reliability, 59(2):277–286.

Sung, A. and Mukkamala, S. (2003). Identifying important

features for intrusion detection using support vector

machines and neural networks. In Symposium on Ap-

plications and the Internet, 2003., pages 209–216.

Vapnik, V. N. (1995). The Nature of Statistical Learning

Theory. Springer-Verlag New York, Inc., New York,

NY, USA.

FastRegularizedLeastSquaresandk-meansClusteringMethodforIntrusionDetectionSystems

269
