Transfer Learning for Bibliographic Information Extraction

Quang-Hong Vuong

and Takasu Atshuhiro

Master Student, Hanoi University of Science and Technology, Dai Co Viet, Hanoi, Vietnam

National Institute of Informatics, Hitotsubashi, Tokyo, Japan

Keywords:

Transfer Learning, Bibliographic Information Extraction, Conditional Random Fields, Page Layout Analysis,

Digital Libraries.

Abstract:

This paper discusses the problems of analyzing title page layouts and extracting bibliographic information

from academic papers. Information extraction is an important task for easily using digital libraries. Sequence

analyzers are usually used to extract information from pages. Because we often receive new layouts and the

layouts also usually change, it is necessary to have a machenism for self-trainning a new analyzer to achieve a

good extraction accuracy. This also makes the management becomes easier. For example, when the new layout

is inputed, There is a problem of how we can learn automatically and efﬁciently to create a new analyzer. This

paper focuses on learning a new sequence analyzer automatically by using transfer learning approach. We

evaluated the efﬁciency by testing three academic journals. The results show that the proposed method is

effective to self-train a new sequence analyer.

1 INTRODUCTION

Recently, the digitization of documents is very pop-

ular. However what we need is not just the digi-

tization of books, we also want to create an infor-

mation archive accessible from everywhere in the

world. Digital libruaries (DLs) is a type of informa-

tion storage. The researchers have built their insti-

tutional repositories that can be accessed from web.

As it is known, bibliographic information about doc-

uments are indispensable for the efﬁcient access to

and ultilization of digital documents. Moreover, bib-

liographic information extraction is a key technology

for realizing such information archives as intellec-

tual legacies because it will enable the extraction of

various kinds of metadata and will provide the users

of such archives with full access to rich information

sources.

For academic documents that we have studied

here, we are interested in title, abstract, author .etc.

These information can be used to identify records

which are stored in different DLs. Many scien-

tists have studied to extract bibliographic information

from papers and documents. (Peng and McCallum,

2004) presented an empirical exploration of several

factors, including variations on Gaussian, exponential

and hyperbolic-L

priors for improved regularization.

(Takasu, 2003) has proposed a method for extracting

bibliographic attributes from reference strings cap-

tured using optical character recognition (OCR) and

an extended hidden Markov model. (I. G. Councill

and Kan, 2008) used conditional random ﬁeld (CRF)

model to label the token sequences in the reference

strings. He also used a heuristic model to identify ref-

erence strings from a plain text ﬁle and to retrieve the

citation contexts. (Takasu and Ohta, 2014) have pro-

posed a method to detect layout changes and how they

learn to use a new sequence analyzer efﬁciently. Al-

though there were many results, it remains an active

research area, with several competitions having been

held

In addition, for accurate information extraction,

the scientists have proposed different rule-based

methods that can exploit both logical structure and

page layout. However, most of them can not learn

automatically when we received a new page layout.

Therefore, we studied and proposed a method, which

can learn automatically a new page layout by using

transfer learning approach.

Transfer learning has been known as an approach

that addresses the problem of how to utilize much of

the labeled data in the source domain to solve related

but different problems in a target domain, even when

the training and testing problems have different dis-

http://www.icdar2013.org/program/competitions

374

Vuong Q. and Atsuhiro T..

Transfer Learning for Bibliographic Information Extraction.

DOI: 10.5220/0005283003740379

In Proceedings of the International Conference on Pattern Recognition Applications and Methods (ICPRAM-2015), pages 374-379

ISBN: 978-989-758-076-5

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

tributions or features (S. J. Pan and Yang, 2013). To

cater for the various situations involving the source

and target domains and tasks, we can identify three

transfer-learning categories, namely inductive trans-

fer learning, transductive transfer learning, and unsu-

pervised transfer learning (Quang-Hong and Takasu,

2014).

In this paper, we focused on how to use transfer

learning for bibliographic information extraction to

train a new analyzer automatically. We evaluated the

efﬁciency and the correctness by testing three journals

data set.

In summary, our main contributions are as fol-

lows.

• We propose a new method that can learn a new

analyzer automatically.

• We implemented to prove the efﬁciency and the

correctness of our method.

The remainder of the paper is organized as fol-

lows. In Section 2, we discuss related work. In

Section 3, we present our proposed method. We de-

scribe our experiments, present our experimental re-

sults, and discuss them in Section 4. Finally, Section

5 concludes the paper and suggests some future work.

2 RELATED WORK

2.1 Semi-supervised Conditional

Random Field

Semi-supervised approach is used as the base learner

of our transfer learning method (F. Jiao and Schu-

urmans, 2006). The main contribution of semi-

supervised approach is ultilization the unlabeled data

to improve the accuracy. It is also a easy approach to

use and discover the latent components of unlabeled

data to train. Therefore, we use semi-supervised CRF

as base learner to train a new analyzer that ﬁts for un-

labeled data. In following, we present more details

about semi-supervise CRF.

Let X be a random variable over data sequences

to be labeled, and Y be a random variable over cor-

responding label sequences. All components, Y

, of

Y are assumed to range over a ﬁnite label alpha-

bet Y . Assume we have a set of labeled samples,



(1)

, y

(1)



, ...,



(N)

, y

(N)



and unlabeled

samples D



(N+1)

, ..., x

(N + M)



. We would like

to build a CRF model

(y|x) =

((x))

exp(

∑

k=1

(x, y))

((x))

exp(< θ, f (x, y) >)

(1)

over sequential input and output data x, y,

where parameter vector θ = (θ

, ..., θ

)

, f (x, y) =

( f

(x, y), ..., f

(x, y))

and

((x)) =

∑

exp(

∑

k=1

(x, y)) (2)

(F. Jiao and Schuurmans, 2006) proposed a semi-

supervised learning algorithm which exploits a form

of entropy regularization on unlabeled data. For semi-

supervised CRF, they proposed to maximize the fol-

lowing objective

RL(θ) =

∑

i=1

log p

(i)

) −U(θ)

+ γ

∑

i=N+1

∑

(y|x

(i)

)log(y|x

(i)

)

(3)

Here, γ is a tradeoff parameter that controls the inﬂu-

ence of the unlabeled data. It determines the impact

of unlabeled data set. Because our target is to learn a

new analyzer that is closest to new data set, we set it

is large enough.

2.2 Unilateral Transfer Adaboost

Method

(Quang-Hong and Takasu, 2014) presented the

UnilateralTrans f erAdaBoost method, which ex-

tends Trans f erAdaBoost (W. Dai and Yu, 2007) in

terms of transfer learning. The algorithm aims to

boost the accuracy of a weak learner by carefully ad-

justing the weights of training instances and learns a

classiﬁer accordingly. The main idea of Unilateral −

TrAdaBoost is that, at each iteration, the effect of

training instances that are misclassiﬁed is reduced by

multiplying its weight by β

)−c(x

, where h

) :

X → Y is the hypothesis that, at the t

iteration,

β ∈ (0, 1]. Therefore, in the next round, those mis-

classiﬁed diff-distribution training instances that are

dissimilar to the same-distribution training instances

will affect the learning process less than in the current

round. The decision function is then

(x) = argmax

∑

t=d

k,t

xlogβ

(4)

where β

1−ε

, ε

is the error for hypothesis h

, u

k,t

is weight vector associated with class k and t

hy-

pothesis, and N is the maximum number of iterations

for the Unilateral − TrAdaBoost algorithm.

TransferLearningforBibliographicInformationExtraction

375

They proposed a new strategy to update the weight

vector. They only updated the weight of misclassi-

ﬁed samples from different distribution. Therefore,

we can use this strategy to semi-supervised methods.

More details present in the next section.

3 PROPOSED METHOD

To enable transfer learning, we use the unlabeled data

set that have the new page layout to run a role in

building the classiﬁcation model. We call these data

target-domain data. Moreover, these target-domain

data do not have label. Therefore, we can not use

them to train a classiﬁer. The labeled training data,

whose distribution may differ from the target-domain

data, perhaps because they are out-dated, are called

source − domaindata. The classiﬁers learned from

these data cannot classify the target-domain data well

due to different domains.

Formally, let X

be the target-domain data, X

the source-domain data, X = X

∪ X

be the domain-

data, and Y = {y

} be the set of category labels. The

training data set T contained labeled set T

, and

unlabeled set T

. T

represents the source-domain

data that T

= {(x

, y

)}, where x

∈ X

(i = 1, . . . , N).

represents the target-domain data that T

= {x

where x

∈ X

(i = 1, . . . , M). N and M are the sizes

of T

and T

, respectively. The combined training set

T = {(x

, y

)} is deﬁned as follows

(

, i = 1, . . . , N;

, i = N + 1, . . . , N + M;

Here, T

corresponds to some labeled data from a

source-domain data that we try to reuse as much as we

can; however we do not know which part of T

is use-

ful to us. What we only have is a unlabeled data set

from target-domain data, and then use these data

to ﬁnd out the useful part of T

. The problem that we

are trying to solve is: given an unlabeled data set from

target-domain data T

, a labeled data set from source-

domain data T

, the objective is to train an analyzer to

label each token with its type of bibliographic compo-

nent.

We now present our method, Trans f er − CRF,

which extends Unilateral − TrAdaBoost (Quang-

Hong and Takasu, 2014) for CRF. However,

Unilateral-TrAdaBoost is similar to most traditional

machine learning methods which need a few labeled

data to train. Therefore, it can not be used to

learn a new model automatically. In our extension

to Transfer-CRF, Transfer-CRF applied Unilateral-

TrAdaBoost’s learning strategy to ﬁlter only consis-

tency samples to build a good model. Thus, in our

extension, we use a mechanism to choose useful sam-

ples.

A formal description is presented in Algorithm 1.

we can see that at each iteration, if a training sample

from source-domain data is mistakenly predicted, it

may conﬂict with the target-domain data. Therefore

it will reduce its effect by remove from trainning set

or reduce its weight in training phase (here we remove

it from trainning set). The algorithm stoped when the

number of iteration is larger than a number that is in-

puted by user or we can not remove any sample from

source-domain data. The output of algorithm contain

the labeled data that is consistent with unlabeled data.

Therefore, we can use them to train a better analyzer.

Algorithm 1: Transfer-CRF.

1 . procedure TRANSFER −CRF(T

, T

, N)

2 . Input: Given two data set T

, T

to train, and

number of iteration K

3 . for i ← 1, K do

4 . Call semi-supervised CRF, providing the

combined training set T . Return with a hypothesis

: X → Y.

5 . if h

∈ X

) 6= y

6 . Remove x

from T

7 . end if

8 . if can not remove any sample

9 . break for

10. end if

11. end for

12. Output: a new analyzer h

that is the last hy-

pothesis

4 EXPERIMENTS

This section examines the efﬁciency and the effective-

ness by evaluating the accuracy in labeling the unla-

beled data that have new layout.

4.1 Dataset

For this experiment, we used the same three journals

as in our previous study (M. Ohta and Takasu, 2010),

as follows:

- Journal of Information Processing by the Infor-

mation Processing Society of Japan (IPSJ): We

used papers published in 2003 in this experiment.

This dataset contains 479 papers, most of them

has been written in Japanese.

- English IEICE Transactions by the Institute of

Electronics, Information and Communication En-

gineers in Japan (IEICE-E): We used papers pub-

ICPRAM2015-InternationalConferenceonPatternRecognitionApplicationsandMethods

376

Table 1: Feature templates of CRF for bibliographic component labeling (M. Ohta and Takasu, 2010).

Type Feature Description

Unigram < i(0) > Current line ID

< x(0) > Current line abscissa

< y(0) > Current line ordinate

< w(0) > Current line width

< h(0) > Current line height

< g(0) > Gap between current and preceding lines

< cw(0) > Median of character widths in the current line

< ch(0) > Median of character heights in the current line

< #c(0) > Number of characters in the current line

< ec(0) > Proportion of alphanumerics in the current line

< kc(0) > Proportion of kanji in the current line

< jc(0) > Proportion of hiragana and katakana in the current line

< s(0) > Proportion of symbols in the current line

< kw(0) > Presence of predeﬁned keywords in the current line

Bigram < y(−1), y(0) > Previous and current labels

lished in 2003. This dataset contains 473 papers

written in English.

- Japanese IEICE Transactions by the Institute of

Electronics, Information and Communication En-

gineers in Japan (IEICE-J): We used papers pub-

lished between 2000 and 2005. This dataset con-

tains 964 papers, most of them has been written in

Japanese.

As in (M. Ohta and Takasu, 2010), we used the fol-

lowing labels for the bibliographic components:

- Title: We used separate labels for Japanese and

English titles because Japanese papers contained

titles in both languages.

- Authors: We used separate labels for author

names in Japanese and English as in the title.

- Abstract: As for the title and authors, we used sep-

arate labels for Japanese and English abstracts.

- Keywords: Only Japanese keywords are marked

up in the IEICE-J.

- Other: Title pages usually contain paragraphs

such as introductory paragraphs that are not clas-

siﬁed into any of the above bibliographic compo-

nents. We assigned the label other to the tokens in

these paragraphs.

Note that different journals have different biblio-

graphic components in their title pages.

Because we used the chain-model CRF, the tokens

must be serialized. We therefore used lines extracted

via OCR as tokens and serialized them according to

the order generated by the OCR system. We labeled

each token for training and evaluation manually.

4.2 Features of the CRF

As in (M. Ohta and Takasu, 2010), the data set has 15

features including 14 unigram features, i.e., the fea-

ture function f

, y

, x) is independently calculated

with the previous label y

. Another feature is bigram

feature, i.e., the feature function f

, y

, x) is depen-

dently calculated with the previous label y

. Table 1

summarizes the set of feature templates. Their val-

ues were calculated automatically from the token and

label sequences.

An example of the bigram feature template <

y(−1), y(0) > is:

, y

, x) =

(

1 i f y

i−1

= titleandy

= author

0 otherwise

An example of the unigram feature is:

, y

, x) =

(

1 i f y

= author

0 otherwise

The bigram features present label structure of

chain-CRF with the corresponding parameter θ

showing how likely a label follows another label.

4.3 Comparison of Methods

Our experiments are implemented in the following

three cases:

- We use an journal to train and the remaining jour-

nals to test.

- For each journal, we use a small number of sam-

ple to train and the rest to test.

TransferLearningforBibliographicInformationExtraction

377

- We use an journal as the labeled data, and another

journal as the unlabeled data to train an analyzer,

then we use the analyzer to label the unlabeled

data.

We measured the accuracy of a learned CRF from

three cases and compare them. The accuracy was

measured by (5) (precision) and F

that is the av-

erage of all F

), where

#number o f correct

#total predicted

(5)

) =

2precision(y

).recall(y

)

precision(y

) +recall(y

)

(6)

where precision(y

) and recall(y

) have been deﬁned

as follows:

precision(y

) =

recall(y

) =

where a

is number of correct y

, N

is number of

in the predicted results, M

is number of y

in the

sample.

4.4 Results and Discussion

In the ﬁrst experiment, we use chain-CRF to learn

a new analyzer. The training corpus is the labeled

datas which comes from the source-domain, and test-

ing corpus is the new unlabeled datas from the target-

domain. The experiment results in the table 2 show

that this approach is inefﬁcient. The accuracy on both

measurement (5) and F

is signiﬁcantly decreased.

From section 4.1, we can see that IEICE-J and

IPSJ have some similar characteristics (such as both

written in Japanese). However, the accuracy is still

small if we compare it with the other chain-CRFs

whose training and testing corpus are drawn from the

same domain. Similarly, we can also see that IEICE-

J and IEICE-E have the same content but they are

presented by other languages, some value of features

such as the proportional(X) of several kinds of char-

acters in the tokens are different. Thus the low accu-

racy is inevitable. In general, this approach can not be

applied to learn a new analyzer automatically.

With the second experiment, we use a small num-

ber of samples to train and the rest to test. Table 3

show the precision and F1-accuracy in this case.

The table shows that chain-CRF is a good method

which can reach a high F1-accuracy and precision.

However, it needs the labeled data from same domain,

and the F1-accuracy is trivial when the number of la-

bel is larger (IEICE-J has 5 labels, the two remain

http://en.wikipedia.org/wiki/F1 score

Table 2: The precision and F1-accuracy of chain-CRF when

target-domain datas have new layout which are disimilar to

source-domain datas.

Train set Test set Precision F

IEICE-J IEICE-E 77.96% 47.68%

IPSJ IEICE-E 71.39% 47.96%

IEICE-J IPJP 76.44% 58.01%

IEICE-E IPJP 63.57% 38.49%

IEICE-E IEICE-J 75.80% 42.50%

IPSJ IEICE-J 88.03% 68.14%

Table 3: The precision and the accuracy of chain-CRF when

target-domain data and source-domain data are drawn from

same domain.

Data set Precision F

IEICE-E 94.17% 91.27%

IEICE-J 93.68% 79.10%

IPSJ 96.33% 90.78%

Table 4: The precision and the accuracy of Transfer-CRF

when target-domain data has new layout and disimilar to

source-domain data.

Train set Test set Precision F

IPSJ IEICE-J 89.37% 73.96%

IEICE-E IPJP 76.23% 50.26%

IEICE-J IPSJ 81.04% 64.37%

jounals have 4 labels). Therefore, chain-CRF can not

be applied to learn a new analyzer automatically.

Finally, we implement with both of labeled datas

from source-domain data and unlabeled datas from

target-domain datas. Table 4 shows the F1-accuracy

and precision of Transfer-CRF with number of iter-

ations is 5. Although the F1-accuracy and precision

of Transfer-CRF is lower than chain-CRF, the corpus

which is used by Transfer-CRF is the unlabeled data.

Therefore, it can be used automatically to learn a new

analyzer. Moreover, this result can be improved by

increasing the number of iterations K or using the la-

beled data which has been already predicted and new

unlabeled data to train a new model to improve the

F1-accuracy.

5 CONCLUSIONS

In this study, we proposed a method that uses an

existing data set to learn a new analyzer to label

the unlabeled data that have new layout. The aim

is to use information from existing data set that is

sufﬁciently consistent with the unlabeled data set.

With this method, we can learn a new analyzer au-

tomatically. Our method is combined Unilateral-

ICPRAM2015-InternationalConferenceonPatternRecognitionApplicationsandMethods

378

TrAdaBoost’s strategy and semi-supervised CRF. In

future work, we plan to investigate a new method that

will detect new labels from new datasets.

REFERENCES

F. Jiao, S. Wang, C. L. R. G. and Schuurmans, D. (2006).

Semi-supervised conditional random ﬁelds for im-

proved sequence segmentation and labeling. In In-

ternational Committee on Computational Linguistics

and the Association for Computational Linguistics,

pages 209–216.

I. G. Councill, C. L. G. and Kan, M. Y. (2008). Parscit:

An open-source crf reference string parsing package.

In Language Resources and Evaluation Conference

(LREC), page 8.

M. Ohta, R. I. and Takasu, A. Empirical evaluation of active

sampling for crf- based analysis of pages. In IEEE

International Conference on Information Reuse and

Integration (IRI 2010), pages 13–18.

Peng, F. and McCallum, A. (2004). Accurate information

extraction from research pa- pers using conditional

random ﬁelds. In Human Language Technologies; An-

nual Conference on the North American Chapter of

the Association for Computational Liguistics (NAACL

HLT), pages 329–336.

Quang-Hong, V. and Takasu, A. (2014). Transfer

learning for emotional polarity classiﬁcation. In

IEEE/WIC/ACM International Joint Conferences on

Web Intelligence (WI2014), pages 94–101.

S. J. Pan, J. K. and Yang, Q. (2013). Transfer learning via

dimensionality reduction. In Proceedings of the con-

ference on artiﬁcial intelligence, pages 677–682.

Takasu, A. (2003). Bibliographic attribute extraction from

erroneous references based on a statistical model. In

Joint Conference on Digital Libraries (JCDL 03),

pages 49–60.

Takasu, A. and Ohta, M. (2014). Utilization of multiple

sequence analyzers for bibliographic information ex-

traction.

W. Dai, Q. Yang, G. X. and Yu, Y. (2007). Boosting for

transfer learning. In Proceedings of the international

conference on machine learning, pages 193–200.

TransferLearningforBibliographicInformationExtraction

379
