Robust Face Recognition using Key-point Descriptors

Soeren Klemm, Yasmina Andreu, Pedro Henriquez and Bogdan J. Matuszewski

Robotics and Computer Vision Research Laboratory, School of Computing Engineering and Physical Sciences,

University of Central Lancashire, Preston, U.K.

Keywords:

Face Recognition, SIFT, SURF, ORB, Feature Matching, Face Occlusions.

Abstract:

Key-point based techniques have demonstrated a good performance for recognition of various objects in nu-

merous computer vision applications. This paper investigates the use of some of the most popular key-point

descriptors for face recognition. The emphasis is put on the experimental performance evaluation of the

key-point based face recognition methods against some of the most popular and best performing techniques,

utilising both global (Eigenfaces) and local (LBP, Gabor ﬁlters) information extracted from the whole face

image. Most of the results reported in literature so far, on the use of the key-points descriptors for the face

recognition, concluded that the methods based on processing of the full face image have somewhat better

performances than methods using exclusively key-points. The results reported in this paper suggest that the

performance of the key-point based methods could be at least comparable to the leading “whole face” meth-

ods and are often better suited to handle face recognition in practical applications, as they do not require face

image co-registration, and perform well even with signiﬁcantly occluded faces.

1 INTRODUCTION

Face is one of the most frequently used biometric fea-

tures. It is used for subject recognition and iden-

tity veriﬁcation with the most commonly listed ad-

vantages, including ubiquitous, non-contact and non-

invasive data acquisition. For many years, face recog-

nition and related research have been of great inter-

est to computer vision and image processing com-

munities, with applications exploited in public secu-

rity (Chellappa et al., 1995), fraud prevention (Jafri

and Arabnia, 2009) and crime prevention and detec-

tion (Kong et al., 2005). Although a fair amount

of research has been made on the development of

face recognition systems based on range and 3D face

scans (Zhang and Gao, 2009), the 2D image based

systems are still being investigated due to prevalence

of the relevant acquisition systems as well as simplic-

ity and low cost of such systems. One of the most

popular techniques applied to face recognition uses

a specially designed image transformation model to

represent faces in a more compact and/or discrimi-

native manifold. The typical examples of this class

of techniques include Principal Component Analy-

sis (PCA) (Yang et al., 2004), Linear Discriminant

Analysis (LDA) (Belhumeur et al., 1997) or Inde-

pendent Component Analysis (ICA) (Bartlett et al.,

2002). These techniques are often called global meth-

ods, as the transformation uses the whole face to

ﬁnd the corresponding representation in the target

manifold and the representation in that manifold can

strongly depend on the spatially distant points in the

original face image. In recognition of the difﬁculties

with global methods in dealing with images captured

in real settings, for example with changing illumina-

tion condition, another class of methods have been

proposed, focused on extraction of local discrimina-

tive information. These techniques usually do not

require images to be transformed to a different do-

main, but rather calculate local descriptors for all the

pixels representing the face. These descriptors are

subsequently integrated in a form of localised his-

tograms with the ﬁnal feature vector created through

concatenation of the local histograms. The most pop-

ular techniques in this class include Local Binary

Patterns (LBP) (Ahonen et al., 2006) and Gabor ﬁl-

ters (Xie et al., 2010). Yet another class of methods is

based on calculation of the local descriptors but only

in the image regions associated with anatomically sig-

niﬁcant and predeﬁned facial landmarks, such as eye

or mouth corners. In the realm of processing im-

ages in practical applications all these techniques ex-

hibit some deﬁciencies. In case of global and local

methods based on processing of the whole face im-

ages, the basic requirement is that the database and

the query images are spatially co-registered and accu-

447

Klemm S., Andreu Y., Henriquez P. and Matuszewski B..

Robust Face Recognition using Key-point Descriptors.

DOI: 10.5220/0005314404470454

In Proceedings of the 10th International Conference on Computer Vision Theory and Applications (VISAPP-2015), pages 447-454

ISBN: 978-989-758-090-1

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

rately cropped. This process is prone to errors partic-

ularly when faced with constraints imposed by prac-

tical applications. Similarly the anatomical landmark

based methods require that the landmarks are accu-

rately identiﬁed. The methods investigated in this pa-

per, based on key-point descriptors, do not require im-

age co-registration or accurate image cropping or in-

deed accurate detection of anatomical landmarks as

the selection of the relevant key points is inherently

embedded in the methods’s key point matching. The

main premise of this paper is that the techniques based

on the key points can achieve comparable results with

other techniques, and are more robust when dealing

with images acquired in practical applications. The

paper proposes the testing methodology and presents

the comparative test results between the most popu-

lar methods based on the whole image processing and

popular key-point methods. The performance of these

techniques with respect to facial occlusion is tested in

some detail as an example of the robustness of these

methods to the conditions often met in real applica-

tions.

2 BASELINE METHODS

For years, face recognition methods based on Eigen-

faces and Local Binary Patterns have been widely em-

ployed reporting successful recognition rates under

different scenarios. Over time, this has led to con-

sider these two techniques as standard face recogni-

tion methods. Nevertheless, new face recognition ap-

proaches have continued to be published, such is the

case for Local Gabor XOR Patterns. According to

the latest survey on face recognition (Bereta et al.,

2013), Local Gabor XOR Patterns is a state-of-the-

art method due to the very good recognition rates

reported. In this section these well-established face

recognition techniques are brieﬂy described.

Eigenfaces method is an early technique of de-

scribing images of faces with a relatively low di-

mensional vector. The method was Proposed by

Sirovich and Kirby (Sirovich and Kirby, 1987). The

feature vector of an image is calculated by ﬁrst

subtracting a mean face image and then perform-

ing a Karhunen-Loeve transform/Principal Compo-

nent Analysis (PCA). Eigenfaces relies on well ad-

justed input images that have been normalized with

respect to illumination and contrast and aligned with

major landmarks that, if not perfectly aligned, intro-

duce detection errors, as they will have an inﬂuence

on scale, position and rotation of the image.

Local Binary Patterns (LBP) were originally de-

ﬁned to describe image textures (Ojala et al., 2002).

However, they have been applied to describe face im-

ages achieving high face recognition rates (Ahonen

et al., 2006). LBP based descriptors have become a

state-of-the-art approach in face analysis not only for

their successful results but for the fact that they are not

affected by changes in mean luminance since they are

invariant against greyscale shifts (Ojala et al., 2002).

An LBP number provides information about the dis-

tribution of grey level values of a circularly symmet-

ric set of neighbouring pixels. Given a face image and

its division into equally sized regions, a histogram is

computed for each region. The resulting descriptor

comprises the concatenation of all histograms. LBP

descriptors can be affected by face localisation errors

because they are based on descriptions of local re-

gions of the images.

Local Gabor XOR Patterns (LGXP) (Xie et al.,

2010) are a descriptor based on Gabor ﬁlters and

Local XOR Patterns. This method is one of the

best methods for face recognition according to the

most recent face recognition survey (Bereta et al.,

2013). This descriptor utilises Gabor ﬁlters which

have proved to be a powerful tool for addressing dif-

ferent computer vision tasks including face recogni-

tion (Xie et al., 2010). The idea behind LGXP is to

use the Gabor phase information but alleviating its

sensitivity to the varying positions. With that purpose,

the Gabor phase is quantised to a set of ranges, so if

various phases belong to the same interval they are

treated as a similar descriptor. Then the Local XOR

Pattern operator is applied to quantised phase maps.

As for the previous descriptor, this method also re-

quires the face images to be aligned.

3 FACE RECOGNITION BASED

ON KEY POINTS

In the previous section, the most widely employed

face recognition approaches were introduced. How-

ever, other methods can be applied to address this

problem. A well-known set of techniques for gen-

eral object detection and recognition is investigated

in the following sections. These techniques search for

characteristic points (usually known as key points) in

the image that usually correspond to corners or blobs,

which are regions of the image where some proper-

ties remain constant. Next, information about the sur-

rounding of these key points is extracted and the im-

age is characterised by the set of all extracted descrip-

tors.

VISAPP2015-InternationalConferenceonComputerVisionTheoryandApplications

448

3.1 Key-point Detectors and

Descriptors

One of the most popular techniques of this kind

is Scale Invariant Feature Transform (SIFT) (Lowe,

2004), which has been used for solving face recog-

nition problems achieving competitive results (Luo

et al., 2007; Geng and Jiang, 2009; Dreuw et al.,

2009; Kisku et al., 2010). These works propose modi-

ﬁcations or extensions to SIFT in order to improve the

recognition rates. In this paper a comparison of the

robustness of the different baseline face recognition

methods and key point based techniques is presented.

Hence, any improvement that can be applied to key-

point detectors and descriptors, could be applied to

the described approach as well.

The SURF feature detector and descriptor was

proposed as a faster but at least as powerful alterna-

tive to the SIFT detector/descriptor (Bay et al., 2008).

Both descriptors have been designed with a view to

image matching but are used in many different areas

of computer vision like object detection, video track-

ing and face recognition (Geng and Jiang, 2009; Du

et al., 2009). Both descriptors are invariant to scale

changes and rotation and their performance is com-

parable in many cases. SURF appears to be a more

preferable method as it is faster to compute and pro-

duces smaller feature vectors compared to SIFT.

While SIFT utilises local minima and maxima of a

Difference of Gaussians operator to detect key points,

SURF uses easier to compute Box Filters and inte-

gral images to further speed up the process. It should

be noted that there is also a U-SURF implementation

that interleaves the orientation assignment and leads

to more distinct features and faster computation times

though is no longer providing rotation invariance.

The SURF feature descriptor is created by rotating

the neighbourhood according to the calculated orien-

tation of the feature and then dividing this area into

4×4 square sub-regions. Then box ﬁlter responses

in horizontal and vertical direction at 5×5 equally

spaced sampling points within each of the sub-regions

are calculated. These responses and their absolute

values are summed up separately for each sub-region.

The 4-dimensional descriptor vectors of all 16 sub-

regions are concatenated and form a 64-dimensional

feature vector. The SIFT descriptor comprises of ap-

proximately the same number of features, however it

contains 8-bin histograms of gradient orientation per

sub-region resulting in a descriptor of 128 elements.

Another key point based approach that will

be evaluated is Oriented Fast and Rotated BRIEF

(ORB) (Rublee et al., 2011). This method is com-

posed of the FAST key point detector and BRIEF fea-

ture descriptor. FAST key-point detector counts the

number n of 16 consecutive pixels in a circular pat-

tern around the candidate that are brighter or darker

than the candidate by a certain threshold t. If n ≥ 12

the candidate is treated as a corner. The BRIEF de-

scriptor is a concatenation of the results of 256 bi-

nary tests. Each test is a comparison of the intensity

values of two pixels within a patch surrounding the

key point. To make the descriptor more robust against

noise and small rotations, the compared values are the

average of a 5×5 window around the test pixels.

3.2 Feature Matching

All key point based methods require a measure to

quantify the likeliness of two faces based on the re-

sults of the comparison of their key points. In contrast

to the methods described in Section 2 for key point

based methods there is no pair of equally sized de-

scriptors but two sets, generally containing a different

number of descriptors, to compare.

For the experiments performed the similarity of

the query face to each of the N faces in the database

is calculated as follows.

For every query face a set of I key points

= {K

,...,K

} (1)

is detected and a feature descriptor D

is calculated

for every K

such that the descriptor set

= {D

,...,D

} (2)

can be assumed to describe the face in all necessary

detail.

For every face k in the database a set of key points

and descriptors D

where k = 1. . . N are detected

and calculated using exactly the same methods. Let

= |K

| = |D

| be the number of key points in the

k-th image of the database.

The indices of the key point K

with the closest

match to the query key point Q

are given as:

, j

) = arg min

k, j

− D

k (3)

These key points were determined using the

FLANN (Muja and Lowe, 2009) algorithm for SIFT

and SURF features and a Brute Force nearest neigh-

bour search for ORB. FLANN cannot be used for

ORB, as the Hamming distance has to be applied for

matching BRIEF descriptors.

To exclude randomly matched feature descriptors,

that do not belong to the same part of the face, the

image of the face is divided using a 3×3 grid pattern.

The resulting 9 subsets of pixels are deﬁned as:

r,c

= {(x,y) :c− 1 ≤ x

3/w < c, and

r− 1 ≤ y

3/h < r}

(4)

RobustFaceRecognitionusingKey-pointDescriptors

449

(a) (b)

Figure 1: Matched (green) and un-matched (red) key points

in corresponding faces using the SURF descriptor. Fig-

ure (a) shows false matched key points (diagonals), that are

eliminated by matching only key points that belong to the

same sub-area of the images as can be seen in Figure (b).

Where w and h denote width and height of the im-

age in pixels, x = [0, 1,...,w−1] and y = [0,1,...,h−

1] represent the positions of one pixel in the image and

1 ≤ r,c ≤ 3 are the row and column within the grid.

The similarity for the k-th face in the database is now

deﬁned as:

∑

i=1



k,k

∑



r,c

)δ

r,c

)





(5)

Where δ

i, j

denotes the Kronecker delta function

and δ

(A) denotes the Dirac measure. The face with

the highest similarity is chosen as the correct match.

Figure 1 shows the matches before (a) and after (b)

the pruning based on Eq. 4.

4 EXPERIMENTAL STUDY

The aim of this experimental study is to test the de-

scribed face recognition method based on key points

(Section 3) together with the presented baseline face

recognition techniques (Section 2).

First, a set of experiments using non occluded im-

ages is performed in order to have baseline recog-

nition rates. Following, experiments with occluded

faces are carried out considering simulated and real

occlusions.

4.1 Experimental Setup

The experiments can be grouped as follows i) experi-

ments with non-occluded faces, ii) experiments with

simulated occlusions and iii) experiments with real

occlusions. These three groups of experiments are

carried out using each of the previously introduced

face recognition methods: key points, LGXP, LBP

and Eigenfaces. Before carrying out all these experi-

ments, an experiment considering only non-occluded

faces is used to decide what type of key-point detector

and descriptor (SURF, SIFT or ORB) is more suitable

for the task.

For all the face recognition methods, except the

ones based on key points, the faces need to be aligned

so the facial features (eyes, nose and mouth) are ap-

proximately in the same location in all images. In

order to perform such alignment, the manually anno-

tated coordinates of the eyes, nose tip and mouth of

all images are requiered. Given the desired position

of the eyes, nose tip and mouth, a rigid transformation

is applied to the coordinates of those facial features in

each image to obtain the aligned face.

4.2 Face Image Data Sets

Two face image databases are used in the experi-

ments, those are FERET (Phillips et al., 1998; Phillips

et al., 2000) database and the AR (Martinez and Be-

navente, 1998) database.

The FERET database is one of the most widely

used databases for evaluating face recognition perfor-

mance. Different partitions of the database are pro-

vided with it, resulting in different data sets. For our

experiments the fa data set is used as the gallery set,

and the testing data sets are fb, dup1 and dup2.

The AR database consists of images taken from

126 individuals on 2 sessions with a separation of 14

days. As there are not available the same number of

images per subject, a subset of 50 female and 50 male

individuals is used. Out of the 13 images that were

captured per subject and session, only three images

of each session are used in this work: frontal face,

face with sunglasses and face with a scarf. For our

experiments, the non-occluded images of the ﬁrst ses-

sion are used as the gallery set, and the testing datasets

are i) the non-occluded images of the second session,

ii) the images of the subjects wearing sunglasses from

both sessions, and iii) the images of the subjects wear-

ing a scarf from both sessions.

The performance of the different methods is tested

using the originally occluded data sets from the AR

database as well as simulated occlusions applied to

the FERET data sets (see Section 4.4). By perform-

ing the tests on both data sets, the performance with

respect to a controllable amount of simulated occlu-

sion can be tested and the ﬁndings can be supported

with more realistic conditions of the AR images.

4.3 Design Parameters

In this section the parameter settings for each of the

methods used in the experiments are indicated.

Key point based methods use the SURF, SIFT and

ORB implementations provided with the Open

Source Computer Vision library

(OpenCV). It is

OpenCV library is available online at http://opencv.org/

VISAPP2015-InternationalConferenceonComputerVisionTheoryandApplications

450

worth noting that these methods use no aligned

face images, however the location of the face in

the image needs to be detected. The well-known

Viola & Jones face detector (Viola and Jones,

2001) is used, with the implementation provided

with the OpenCV library.

LGXP method is based on the work by (Xie et al.,

2010). Hence, the values of the design parameters

are those given in that work. Although, the results

reported in that publication have not been repli-

cated, the recognition rates achieved with our im-

plementation are useful for comparing the perfor-

mance of this method under different conditions

tested in the experiments.

LBP method is based on regions of 9×9 pixels from

which LBPs are calculated taking 8 sample points

with a radius of 2 pixels. Each of the histograms

extracted from each region has 59 bins, since uni-

form LBPs are used (Ahonen et al., 2006).

Eigenfaces method is implemented using the default

parameters of the FaceRecognizer provided with

the OpenCV library.

Regarding the size of the images, the key point

based method uses the images as they are provided

in the face databases. For the other face recognition

methods the images from the FERET database are re-

sized to 80× 88 pixels following the recommendation

given in (Xie et al., 2010). However, an experiment

using larger image sizes is also perfomed in order to

check if the reduced size affects the recognition re-

sults. For the AR data sets the ready available set

of warped images (Martinez and Kak, 2001) is used,

each image has a size of 120× 165 pixels.

4.4 Simulated Occlusions

In order to have a controlled amount of occlusions

in the images, simulated occlusions were added to

the FERET data sets used for testing. These occlu-

sions were introduced randomly by replacing a square

shaped area of the detected face. To provide a more

realistic scenario the occlusions were not only black

or white masks, but taken from the Colored Brodatz

Texture database. The occluded images were created

by ﬁrst detecting the face in the original FERET im-

age. A square shaped mask of 10% and 25% of the

size of the facial area was created by randomly select-

ing one of the 112 textures in the Brodatz database

and an equally sized area within each of the templates.

This area was then copied to a random position inside

the facial area of the FERET image. The process was

repeated 5 times and the reported results are averaged.

Table 1: Face recognition rates (%) over FERET data sets

achieved by different key-point methods.

SIFT SURF ORB

fb 93.75 97.88 81.15

dup1 52.31 57.61 29.48

dup2 44.30 52.63 21.93

Table 2: Face recognition rates (%) over FERET data sets

without occlusions. Images have been aligned and cropped

to 80× 88 pixels for LGXP, LBP and Eigenfaces methods.

SURF LGXP LBP Eigenfaces

fb 97.88 80.24 92.74 69.56

dup1 57.61 47.01 47.96 23.51

dup2 52.63 39.04 28.51 6.14

5 RESULTS

The evaluation of the tested face recognition meth-

ods is ﬁrst performed using non-occluded data. The

results provide a certain level of conﬁdence in the im-

plemented algorithms as they can be compared to for-

merly reported results. Those results are then com-

pared with the scaled simulated occlusion results and

veriﬁed using the results from real occlusions.

5.1 No Occlusions

Table 1 shows that on non-occluded faces of the

FERET database, the SURF descriptor performs as

expected based on the results formerly reported (Geng

and Jiang, 2009) the same applies to SIFT (Liu et al.,

2011). SURF constantly provides better results than

the other key point based descriptors, especially ORB

does not seem to be suited for face recognition, at

least for the given test environment. For this reason,

the results of SIFT and ORB will no longer be re-

ported for other tests.

Table 2 shows the results for all the described

methods on the same database. In this Table as well

as in Table 3, the SURF results are duplicated (from

Table 1) for reference only. The results for the LBP

algorithm are seconded by previously reported results

on the FERET images (Bereta et al., 2013; Yang and

Chen, 2013). On the used implementation of LGXP,

the performance achieved is worse than previously re-

ported (Xie et al., 2010).

It is worth highlighting at this point that images

of 80 × 88 pixels were used in order to follow the

same experimental setup as in (Xie et al., 2010). To

assess the inﬂuence of the comparatively small size

of the aligned images, a second experiment was per-

formed using larger images of 300 × 330 pixels (see

RobustFaceRecognitionusingKey-pointDescriptors

451

Table 3: Face recognition rates (%) over FERET data sets

without occlusions, but with images aligned and cropped to

300× 330 pixels for LGXP, LBP and Eigenfaces.

SURF LGXP LBP Eigenfaces

fb 97.88 93.65 82.16 69.46

dup1 57.61 52.17 51.22 23.37

dup2 52.63 41.23 48.25 5.70

Figure 2: Example of matched key points in a face with 25%

of simulated occlusion using the SURF descriptor. Despite

a few wrong matches, there is still enough information left

to recognise the subject correctly.

Table 3). While the change in size has no inﬂuence on

the results of the Eigenface descriptor, there is even a

decrease in the performance of the LBP method. It

should be noted, that SURF detection has not been

performed on resized images, therefore the ﬁgures

given in Table 3 are for reference only.

The additional image details due to the increased

resolution do not provide any signiﬁcant changes to

the position of the image vectors in the PCA feature

space. Therefore, the separability of the classes does

not improve when using the Eigenfaces method.

LBP seems to beneﬁt from the smaller image sizes

due to the noise reduction resulting from the subsam-

pling as it requires the application of a low-pass ﬁlter.

In contrast to LBP, the Gabor ﬁlter allows one feature

descriptor to cover multiple scales, therefore the re-

sults beneﬁt from the greater detail but still cover an

area large enough to generate distinct features.

Nevertheless, it should be noted, that the SURF

descriptor performs best in all experiments without

occlusions. This does also include the robustness

against appearance changes, that can be observed by

the drop in recognition performance in between the fb

and dup2 data sets.

5.2 Simulated Occlusions

Table 4(a) and Figure 3(a) show the results obtained

on the fb FERET data set with 10% of simulated oc-

clusions. As those results conﬁrm there is only a small

drop in recognition performancefor all methods when

the facial area is occluded. This is due to the high sim-

ilarity of the faces in both sets, that allows for a con-

Table 4: Face recognition rates (%) over FERET data sets

with artiﬁcial occlusions. Images have been aligned and

cropped to 80× 88 pixels for LGXP, LBP and Eigenfaces.

(a) 10% of occlusion

SURF LGXP LBP Eigenfaces

fb 96.31 70.16 86.05 53.31

dup1 51.11 36.11 45.92 16.68

dup2 40.18 29.91 27.98 4.56

(b) 25% of occlusion

SURF LGXP LBP Eigenfaces

fb 92.07 44.98 61.63 27.30

dup1 39.76 17.74 24.62 8.75

dup2 24.65 13.51 15.00 2.19

Table 5: Face recognition rates (%) over AR images without

and with real occlusions.

SURF LGXP LBP Eigenfaces

no occlusion 97.75 89.00 92.00 64.00

sunglasses 94.71 69.00 61.50 33.00

scarf 96.63 46.00 89.00 5.50

stant quality of the single features extracted from the

whole facial area. The experiments using the dup1

and dup2 (see Figure 3(b)) sets show a much larger

drop for all descriptors.

Table 4(b) shows the recognition rates obtained

for each of the methods when the occlusion is 25%

of the facial area. This is a more challenging task and

so the performances drop more signiﬁcantly if com-

pared to the results using non-occluded images. How-

ever, the SURF method seems to be less affected than

the rest which could be due to the quality of the key-

point descriptors. As can be seen in Figure 2, which

depicts the matches of a non-occluded gallery image

against an image with 25% of occlusion, the number

of wrong matches to the occluded area is negligible.

Therefore, it can be assumed that there are enough

remaining matches to allow good results even when

25% of the facial area is occluded.

The performance of LBP in the fb tests shows the

lack of ﬂexibility of the methods based on local de-

scriptors to deal with the loss of information. As the

occlusions are located randomly and the squares may

appear rotated in the aligned images the occlusions

degrade the information of a larger part of the his-

tograms than 25%. The same reasoning applies to the

LGXP descriptor.

As the occluded images are no longer in their ex-

pected subspace in the Eigenfaces feature space, the

projection vectors calculated by both methods do no

longer provide relevant features.

VISAPP2015-InternationalConferenceonComputerVisionTheoryandApplications

452

100

none 10 % 25 %

Correct recognition %

amount of occlusion

(a) FERET fb data set

none 10 % 25 %

Correct recognition %

amount of occlusion

SURF

LGXP

LBPP

Eigenface

(b) FERET dup2 data set

100

none scarf sun glasses

Correct recognition %

Figure 3: Average recognition performance of the tested

6 CONCLUSIONS

Figure 3: Average recognition performance of the tested

methods under different occlusions. The error bars indicate

the minimal and maximal performance achieved for the dif-

ferent versions of the occluded data sets.

5.3 Real Occlusions

The results shown in row 1 of Table 5 deﬁne a base-

line for the experiments with real occlusions. As can

be seen, they are comparable to the results of the fb

test set without any occlusions (Table 2). This is due

to the only 14 days difference in between the ﬁrst and

the second session of the AR data gathering process.

The two types of occlusions in the AR sets appear

to be less challenging than the simulated occlusions.

The overall performance of all the descriptors is con-

ﬁrmed (see Table 5 and Figure 3(c)). However, when

looking at the recognition rates achieved by all the

methods, it seems that the key-point descriptor was

more robust than the rest, as there is no much drop

from the baseline results and those obtained with real

occlusions. In addition, the key-point method had

also an overall better performance. Regarding the

LGXP method, its performance over scarf images is

not as good as the performance over sunglasses oc-

clusions which seem counterintuitive as eyes tend to

provide more discriminant information than other ar-

eas of the face.

6 CONCLUSIONS

The experiments show that, although the recognition

rates of key point based face recognition methods are

slightly lower than reported results for Local Descrip-

tors (Bereta et al., 2013; Xie et al., 2010), they outper-

form the tested implementations when the faces are

partially occluded.

Furthermore, the use of key-point detectors makes

exact alignment redundant, which does not only elim-

inate the need for annotated data sets but also saves

time during the pre-processing stage of the recogni-

tion process.

Out of the tested range of key-point detectors

and descriptors, SURF appears to be the most suc-

cessful one. Not only does it show higher match-

ing speeds (Du et al., 2009) it does also outperform

the well known SIFT on the occluded faces of the

AR database. ORB does, in the described setup, not

achieve results that are comparable to the other meth-

ods. The same applies to the holistic method Eigen-

faces, that was not capable of delivering good perfor-

mance with partially occluded faces.

There are many possible ways to further increase

the performance of key point based face recognition

methods. The described matching method (Section

3.2) is very generic. It seems promising to use more

advanced methods (Geng and Jiang, 2009) or include

a bayesian approach for evaluating the strength of a

matched key point pair.

As face images can, in many cases, be assumed

to be roughly aligned along the vertical axis, the U-

SURF descriptor might deliver even better perfor-

mance than rotation invariant SURF.

In the area of binary descriptors, there are other

methods that show performance comparable to SIFT

when it comes to feature matching. A combination of

FAST detector and BRISK descriptor was reported to

perform very well (Bekele et al., 2013).

Finally, Gabor ﬁlters were able to increase the per-

formance in combination with LBPs (Bereta et al.,

2013; Xie et al., 2010) and have spatial locality, in

contrast to DFT or DCT, it seams reasonable to com-

bine them with key-point descriptor methods as well.

ACKNOWLEDGEMENTS

This work has been supported by the EU FP7 Project

SEMEOTICONS (Grant agreement no: 611516).

Portions of the research in this paper use the FERET

database of facial images collected under the FERET

program, sponsored by the DOD Counterdrug Tech-

nology Development Program Ofﬁce.

RobustFaceRecognitionusingKey-pointDescriptors

453

REFERENCES

Ahonen, T., Hadid, A., and Pietikinen, M. (2006). Face

description with local binary patterns: Application to

face recognition. IEEE Trans. Pattern Anal. Mach.

Intell., 28:2037–2041.

Bartlett, M. S., Movellan, J. R., and Sejnowski, T. J. (2002).

Face recognition by independent component analysis.

IEEE Trans. Neural Networks, pages 1450–1464.

Bay, H., Ess, A., Tuytelaars, T., and van Gool, L. (2008).

Speeded-Up Robust Features (SURF). Computer Vi-

sion and Image Understanding, 110(3):346–359.

Bekele, D., Teutsch, M., and Schuchert, T. (2013). Evalua-

tion of binary keypoint descriptors. In IEEE Int. Conf.

Image Processing (ICIP), pages 3652–3656.

Belhumeur, P. N., Hespanha, J. P., and Kriegman, D. J.

(1997). Eigenfaces vs. Fisherfaces: recognition using

class speciﬁc linear projection. IEEE Trans. Pattern

Anal. Mach. Intell., 19(7):711–720.

Bereta, M., Pedrycz, W., and Reformat, M. (2013). Lo-

cal descriptors and similarity measures for frontal

face recognition: A comparative analysis. Journal

of Visual Communication and Image Representation,

24(8):1213–1231.

Chellappa, R., Wilson, C., and Sirohey, S. (1995). Human

and machine recognition of faces: a survey. Proc.

IEEE, 83(5):705–741.

Dreuw, P., Steingrube, P., Hanselmann, H., and Ney, H.

(2009). SURF-face: Face recognition under viewpoint

consistency constraints. In Proc. British Machine Vi-

sion Conf., pages 1–1.

Du, G., Su, F., Cai, A., Ding, M., Bhanu, B., Wahl, F. M.,

and Roberts, J. (2009). Face recognition using SURF

features. In SPIE Proc. Int. Symp. Multispectral Image

Proc. and Pattern Recog., pages 749628–1 – 7.

Geng, C. and Jiang, X. (2009). Face recognition using sift

features. In Image Processing (ICIP), 2009 16th IEEE

International Conference on, pages 3313–3316.

Jafri, R. and Arabnia, H. R. (2009). A Survey of Face

Recognition Techniques. Journal of Information Pro-

cessing Systems, 5(2):41–68.

Kisku, D. R., Gupta, P., and Sing, J. K. (2010). Face recog-

nition using sift descriptor under multiple paradigms

of graph similarity constraints. In Int. J. Multimedia

and Ubiquitous Engineering, volume 5, pages 1–18.

Kong, S. G., Heo, J., Abidi, B. R., Paik, J., and Abidi, M. A.

(2005). Recent advances in visual and infrared face

recognitiona review. Computer Vision and Image Un-

derstanding, 97(1):103 – 135.

Liu, N., Lai, J., and Qiu, H. (2011). Robust Face Recog-

nition by Sparse Local Features from a Single Image

under Occlusion. In Graphics (ICIG), pages 500–505.

Lowe, D. G. (2004). Distinctive Image Features from Scale-

Invariant Keypoints. International Journal of Com-

puter Vision, 60(2):91–110.

Luo, J., Ma, Y., Takikawa, E., Lao, S., Kawade, M., and

Lu, B.-L. (2007). Person-speciﬁc sift features for face

recognition. In Int. Conf. Acoustics, Speech and Sig-

nal Processing, volume 2, pages II–593–II–596.

Martinez, A. and Benavente, R. (1998). The AR Face

Database: CVC Technical Report #24.

Martinez, A. M. and Kak, A. C. (2001). PCA versus LDA.

IEEE Trans. Pattern Anal. Mach. Intell., 23(2):228–

233.

Muja, M. and Lowe, D. G. (2009). Fast approximate near-

est neighbors with automatic algorithm conﬁguration.

In In VISAPP International Conference on Computer

Vision Theory and Applications, pages 331–340.

Ojala, T., Pietikainen, M., and Maenpaa, T. (2002). Mul-

tiresolution grayscale and rotation invariant texture

classiﬁcation with local binary patterns. IEEE Trans.

Pattern Anal. Mach. Intell., pages 971–987.

Phillips, P. J., Hyeonjoon Moon, Rizvi, S. A., and Rauss,

P. J. (2000). The FERET evaluation methodology

for face-recognition algorithms. IEEE Trans. Pattern

Anal. Mach. Intell., 22(10):1090–1104.

Phillips, P. J., Wechsler, H., Huang, J., and Rauss, P. J.

(1998). The FERET database and evaluation proce-

dure for face-recognition algorithms. Image and Vi-

sion Computing, 16(5):295–306.

Rublee, E., Rabaud, V., Konolige, K., and Bradski, G.

(2011). ORB: An efﬁcient alternative to SIFT or

SURF. In Int. Conf. Computer Vision, pages 2564–

2571.

Sirovich, L. and Kirby, M. (1987). Low-dimensional proce-

dure for the characterization of human faces. Journal

of the Optical Society of America A, 4(3):519.

Viola, P. and Jones, M. (2001). Rapid object detection using

a boosted cascade of simple features. In Computer

Vision and Pattern Recognition., pages I–511–I–518.

Xie, S., Shan, S., Chen, X., and Chen, J. (2010). Fus-

ing Local Patterns of Gabor Magnitude and Phase for

Face Recognition. IEEE Trans. Image Processing,

19(5):1349–1361.

Yang, B. and Chen, S. (2013). A comparative study on

local binary pattern (LBP) based face recognition:

LBP histogram versus LBP image. Neurocomputing,

120:365–379.

Yang, J., Zhang, D., Frangi, A. F., and Yang, J. (2004). Two-

dimensional PCA: A new approach to appearance-

based face representation and recognition. IEEE

Trans. Pattern Anal. Mach. Intell., 26(1):131–137.

Zhang, X. and Gao, Y. (2009). Face recognition across pose:

A review. Pattern Recognition, 42(11):2876 – 2896.

VISAPP2015-InternationalConferenceonComputerVisionTheoryandApplications

454
