An Approach in the Design of Common Authentication Solution for a

Multi-Platform Cloud Environment

Primož Cigoj

1,2

Borka Jerman Blažič

and Tomaž Klobučar

Jožef Stefan International Postgraduate School, Jamova cesta 39, 1000 Ljubljana, Slovenia

Jozef Stefan Institute, Laboratory for Open Systems and Networks, Jamova cesta 39, 1000 Ljubljana, Slovenia

Keywords: Single Sign-on, Identity Management, Identity Federation, Cloud Computing, Security, Cloud Management,

Cloud Provisioning, Infrastructure-as-a-Service, IaaS, Multi-platform Cloud, Access Control, Authentication,

Authorization, Cloud Service Provider, Privacy, Software Platform, Centralized Systems, OpenStack,

VMware.

Abstract: The security provision within multi-platform cloud computing environment is still considered not to be

properly solved due to different problems with technical and human-based origin. This paper presents an

attempt to provide an authentication and authorization solution based on the single sign-on (SSO) approach

for cloud service users and administrators in a multi-platform environment. The problem of authentication in

cloud services is briefly introduced and the approach implemented for cloud environment with two different

proprietary (VMware) and open source (OpenStack) platforms is described.

1 INTRODUCTION

Cloud computing has revolutionized the provision of

computing services, transferring them from local to

locally unspecified remote environments, which are

controlled by third party service providers. The main

cloud computing challenge for vendors, providers and

users of clouds remains protection of the cloud

technology, services and users with adequate security

measures. According to the survey conducted by

Microsoft and the National Institute of Standards and

Technology (NIST), security in the cloud computing

model was the ICT executives’ main concern (Jansen

and Grance, 2011; Microsoft, 2010). Consequently,

many business entities are still not very keen on

adopting cloud computing.

In the cloud users alone have no control over their

data and their cloud identity. Installation procedures

are often complex and there is no adequate and

complete security solution that ensures the safe

deployment of the underlying infrastructure and safe

use of the services. Especially in the multi-platform

clouds and inter-clouds, where multiple cloud

systems can be accessed, users and administrators are

faced with different authentication and authorisation

systems, different login dialogs, and each login dialog

is matched with different credentials. In addition to

being difficult implementing strong authentication at

the user level (Tripathi and Mishra, 2011), it is also

complex to manage and create authentication

mechanisms for several services and several

platforms (Fernandes, Soares, Gomes, Freire and

Inácio, 2014). Identity federation and single sign-on

(SSO) techniques address these issues by allowing

exchange of authentication and authorization

information between two parties, such as an Identity

Provider (IdP) and a Service Provider (SP).

While the identity federation and single sign-on

concepts have been well covered in the literature in

the past years, in general as well as in the cloud

context e.g. (Pérez-Méndez, Pereniguez-Garcia,

Marin-Lopez, López-Millán and Howlett, 2014),

(Cruz Zapata, Fernández-Alemán and Toval, 2014),

there are still practical issues that prevent their

straightforward and simple application in the multi-

platform cloud environments. Our attempt described

in this paper was to design and develop a solution that

would provide trustworthy and secure authentication

and authorization service in such environment. The

proposed solution is based on the SSO principle and

was implemented on two different platforms

(OpenStack and VMware). It was tested and

evaluated within a large National Competence Centre

project on cloud-assisted services for different fields

of application.

The paper discusses the problem and related work

first. Then it introduces the selected SSO- based

365

Cigoj P., Jerman Blaži

c B. and Klobu

car T..

An Approach in the Design of Common Authentication Solution for a Multi-Platform Cloud Environment.

DOI: 10.5220/0005351103650372

In Proceedings of the 5th International Conference on Cloud Computing and Services Science (CLOSER-2015), pages 365-372

ISBN: 978-989-758-104-5

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

solution, and describes the development approach and

the implementation course. The presentation ends

with discussion and plans for future work.

2 AUTHENTICATION AND

IDENTITY MANAGEMENT

SERVICES IN

MULTI-PLATFORM CLOUD

INFRASTRUCTURE

According to the Cloud Security Alliance (CSA)

(Simmonds, Rezek and Reed, 2011), the leader in the

field of cloud security, the largest identified cloud

security problem is related to the shared technology

issues. Infrastructure resource sharing can potentially

allow one consumer to peek into another consumer’s

data if the system does not provide strong system for

authorization and authentication. Here, the problems

of account hijacking or user credential theft are also

relevant. The traditional identity management (IdM)

approach is more centralized compared to the current

solution used in cloud computing, and usually is

based on user personal data, such as real name, user

name, e-mail address, identification number, access

permissions, etc. The use of a separate IdM system

within an organisation, and its connection with the

cloud is quite complicated, and there is no simple way

to extend its use to the cloud (Lonea, Tianfield and

Popescu, 2013). In order this to become part of the

cloud system the following actions and the

corresponding implementations are required (Cantor,

Kemp, Philpott and Maler, 2005):

 Registration of identities: Verification of a user

account is needed before proceeding with the

registration in accordance with the relevant

security standards. Organizations that transfer

their user accounts to the cloud must make sure

their user account management system is up-to-

date and safe.

 Authentication: Management and

implementation of the user authentication must

be performed in a trustworthy way. The IdM

systems should allow configuration of the

authentication systems. Another important

property of the system should be the cloud-

providers’ identification disclosure to third

party providers and the use of authentication by

both parties.

 Federation of identities: Federation of

identities allows users to use the same set of

credentials to obtain access to different

resources. User`s electronic identity and

attributes are securely shared across multiple

IdM systems. Federation of identities can be

achieved in several ways; e.g., based on SAML

(Cantor, Kemp, Philpott and Maler, 2005) or

the OpenID solution (Ferg, Fitzpatrick and

Howells, 2007). One of the important

properties is the required compatibility of cloud

providers’ IdM systems.

 Authorization: Authorization specifies the

rights of individual user accounts. It is

important for the cloud the account

management procedures to be set up and for the

rights verification from the highest system

authority. Furthermore, the granted right

should be consistent with the policy.

 Access control: Access control requirements

vary widely according to the type of the end-

user (an individual or an organization). In order

to implement an access control system, an

access control policy must be set, and its

implementation should allow the performed

actions to be traceable.

Apart from these recommendations it becomes

obvious that an optimal system for ensuring

authentication and authorization in a multi-platform

cloud system would also benefit from the single sign-

on approach principles. The Open Group defines SSO

as “a mechanism whereby a single action of user

authentication and authorization can permit a user to

access all computers and systems where that user has

access permission, without the need to enter multiple

passwords” (Group TO, 2014). The most important

security property that the SSO principle brings is the

common secure infrastructure, which can be carefully

managed and protected (Andronache and Nisipasiu,

2011). At the same time, when using the SSO

approach, the cloud services do not have to manage

each user account. Account management can be

carried out by a central authentication system.

Although the concepts of identity federation and

single sign-on are well known in the cloud research

literature there are still some practical design and

implementation issues worth discussing, especially in

the multi-platform cloud environments, cloud

federations, and inter clouds. General proposed

solutions for a multi-platform environment often do

not take into account the current implementation

status, functionalities and openness of the available

cloud platforms, as well as not take advantage of their

existing services. The papers also do not give enough

details of the proposed solutions and their integration

into existing platforms.

Panarello et al., for example, analyse

requirements for IaaS cloud federation (Panarello,

CLOSER2015-5thInternationalConferenceonCloudComputingandServicesScience

366

Celesti, Fazio, Villari and Puliafito, 2014). While

they envisage SAML, OpenID and Shibboleth as an

authentication solution, only a standard and general

identity federation model is described without details

and without taking into account the platform

implementation specifics, such as current missing

SAML support in OpenStack and Hyper-V. They also

highlight only one type (OpenQRM) of cloud

platforms.

Different initiatives, projects and libraries on

regulation technologies for the Inter-Cloud

environment are covered in (Grozev and Buyya,

2014), (Toosi, Calheiros and Buyya, 2014). Libraries,

for example JCloud (java library), Apache LibCloud

(python library), or Apache DeltaCloud (ruby

library), and projects such as InterCloud, OPTIMIS,

mOSAIC, STRATOS, Contrail, have been designed

to abstract the programmers from the differences in

the management APIs of clouds and to provide

control over resource provisioning. The EU Contrail

project, for example, provides support for SAML and

oAuth in their latest version. However, this is still not

a practical solution for various cloud platforms, as

they are closed and don't have built-in support for

SAML yet (e.g. Hyper-V).

In (Abdo, Demerjian, Chaouchi, Barbar and

Pujolle, 2013) Abdo et al. discuss the cross-cloud

federation manager and propose a centralised broker-

based approach. A new entity named "broker" is

similar to the centralised solution described in this

paper, but has other goals (change of discovery and

match making).

3 THE APPROACH TAKEN IN

THE SOLUTION DESIGN

The multi-platform cloud infrastructure consisted of

the OpenStack and VMware cloud platforms, two of

the most known and widely used platforms for

provision of a cloud infrastructure as a service.

OpenStack is open source software for the

construction of private and public clouds. It uses a

role-based access control (RBAC) mechanism to

manage accesses to its resources (Ferraiolo et al.,

2001). The identity service in OpenStack is named

Keystone. The service authenticates users and

provides them with authorization tokens that can be

used for accessing the OpenStack services. The

current version of Keystone is centralized, and all its

users need to be registered in the Keystone database.

The other platform, VMware is considered as one

of the most feature-completed platforms in the field.

VMware vCloud Director is a cloud platform

software solution that enables enterprises to build

secure, multi-tenant private clouds by pooling

infrastructural resources into the virtual data centres,

and exposing them to users through the web-based

API and REST interfaces as fully automated,

catalogue-based services. The vCloud Director also

supports RBAC. The authentication method used in

vCenter that helps automate VMware vCloud

Director and other virtualization management system

processes is called “Share a unique session”. vCenter

uses a single set of credentials to enable connection

to the vCloud. The latest release 5.5 of the vCenter

application has introduced a new SSO approach

capability, which allows users to log in just once, and

obtain the valuated authentication for all vCloud’s

components. The vCloud API uses basic HTTP

authentication, which enables clients to obtain

authentication tokens.

By considering these characteristic the solution

for enabling a central SSO facility for both platforms

was designed with an aim to provide flexible and

secure authentication and authorization service for

both platforms. The solution is briefly described in

the next section. It was named Common

Authentication Solution for multi-platform cloud or

shortly CAS.

4 COMMON AUTHENTICATION

SOLUTION FOR

MULTI-PLATFORM CLOUD

SERVICE

4.1 Functional Description

The main objective followed during the development

of the CAS solution was to enable the cloud

infrastructure administrators and the other users to

access heterogeneous cloud’s infrastructure services

using just a single credential. The solution takes into

account cloud platforms’ specifics, as well as the

services and APIs already offered by those platforms,

and extends its usage to authorization and user access

rights management. Other objectives that were

followed during the development were to enable:

 better user experience; users should be able to

move between services securely and

uninterrupted,

 one dashboard for interacting with different

cloud SPs,

 reduction of the processing costs, obtained by

reducing the number of calls,

AnApproachintheDesignofCommonAuthenticationSolutionforaMulti-PlatformCloudEnvironment

367

Figure 1: The CAS solution scheme.

 significantly shorter time required for

management of multiple accounts,

 higher level of the information security,

 provision of an audit log of the user operations

and actions.

By following these objectives CAS becomes a

favourable solution that enables administrators,

employees, consumers, and customers to access

clouds and their services with a single credential. In

order to illustrate how CAS works, we are using here

the example of an organisation (e.g. corporation or

university) with several different cloud

infrastructures on site or at a dislocated facility. The

infrastructure consists of different platforms for each

of the cloud, e.g. OpenStack and VMware. CAS is

located on the organisation site, and allows the site

administrator to add multiple cloud platforms, either

inside or outside the organisation. The CAS

application contains a database with the end users of

the organisation enabling the site administrator to

manage the allocation of resources and, the end users

applications in the different system platforms. The

end users need only one login. A user logs into the

CAS system and he finds there virtual machines

assigned to different cloud platforms. Therefore, the

federated approach and SSO in the CAS allows the

successfully authenticated end users to access

additional cloud platforms and services without re-

authenticating, since the relationship of trust had

already been established and was provided by the

CAS system.

The basic operational principles implemented in

the system are shown in Fig. 1. The system is split in

two parts – front end and back end. The first part of

the system is a web interface, built with the help of

the programming languages PHP, HTML, and

JavaScript. This interface enables end users to sign

into a central system with a browser and gain access

to all assigned cloud platforms. An administrator

assigns permissions to end-users, and manages the

access to different cloud platforms through the web

browser. The back end of CAS is responsible for

mapping, synchronizing and removing end users from

the remote cloud platforms. It uses REST access calls

(REST over HTTP protocol) for communication with

a remote terminal. The format of the exchanged data

depends on the end cloud platform accessed (JSON

and XML).

CAS provides two ways of end-user registration;

the first option is self-registration, and the second one

is registration through a social network account

(oAuth2). The oAuth2 solution, which has become a

popular open standard for authorization supported by

Google, Facebook, Twitter, and Yahoo was

implemented to enable another simple access to the

end users. It was designed for web applications with

servers that store confidential information, maintain,

state, and provide a secure way for an application like

CAS without requiring usernames and passwords

(Oracle, 2013). In addition to the oAuth and self-

registration, CAS supports also LDAP or AD

integration.

CLOSER2015-5thInternationalConferenceonCloudComputingandServicesScience

368

Before the CAS administrator can manage end-

users, an instance of the remote cloud platform must

be created in the central system. Figure 2 shows the

CAS administrator dashboard, enabling the

administrator to easily add any cloud platform that

becomes part of the CAS. First, the administrator

selects the type of the platform and triggers the

generation of the extra required data fields for the

selected platform type. These fields are needed for

creation of the local instance of the remote platform.

In the case of OpenStack, the fields that belong to the

remote administrator, such as password, token and

tenant, are required to be filled with relevant data.

Once the cloud platform is added, the administrator

can import users from remote cloud platforms or add

them to the remote cloud platform on the CAS

administrator dashboard.

The back end part of the system automatically

adds a new end-user with the help of the REST calls.

In case of OpenStack, the REST calls are used to

insert end-users into the Keystone application. A

more detailed explanation of the end-user mapping by

the central system in the cloud platform can be found

in (Cigoj, 2014).

An end user logs into CAS by providing his CAS

presented with the dashboard of remote platforms that

are accessible to him with a single click on the login

button without a username or a password. The end

user can then create, run and power off virtual

instances.

4.2 Implementation

The implementation of the CAS was based on the

available APIs of the cloud platforms, known

applications, such as CURL, REST, HTTPS, and the

Python programming languages.

For the OpenStack platform PHP scripts with the

support of CURL (a command line tool for

transferring data) were used to ensure the transfer of

end users from CAS into the remote OpenStack and

to automate common end user and administrative

tasks in combination with the CAS. The OpenStack

authentication service provided with the Keystone`s

API interface which is a component that allows the

administrators to manage and map end users into the

remote Keystone database was used for enabling the

end-user authentication process between the CAS and

the remote OpenStack platform. The Keystone

Identity Service enables clients to obtain tokens for

access to the OpenStack cloud services. The

Keystone API is using the RESTful web service

interface where all authentication and operation

requests directed to the Keystone API are performed

with the SSL protocol over the HTTP (HTTPS). Since

Keystone code can be executed by use of the HTTP

sessions, the external authentication methods were

Figure 2: CAS administrative dashboard.

AnApproachintheDesignofCommonAuthenticationSolutionforaMulti-PlatformCloudEnvironment

369

applied. The Keystone SQL identity back end facility

was used together within the CAS for mapping the

end users credentials only once and for login them

into the OpenStack dashboard. Their credentials are

supplied to CAS only once. The Keystone API

supports both JSON and XML data serialization

formats, the response format uses JSON by default.

This feature was used in the CAS and the X-Auth-

Token is accompanied with the URLs of the other

services in the cloud.

The vCloud connection with the CAS is similar to

the solution applied in the OpenStack platform. The

vCloud APIs provide rich functionalities for the

management part of the vCloud platform, the vCloud

Director. Two methods were possible to be used for

the interaction of the vCloud Director cells with the

CAS: through a web browser UI or through the

vCloud API. The vCloud APIs are RESTful- based,

they are highly scalable, and use the HTTP or HTTPS

protocol for communication. As the vCloud directory

contains a set of APIs for vCloud’s provisioning and

management controls the programming of the

necessary extensions was relatively easy. The

returned objects from the API follow the XML

scheme where the properties are represented as

elements, and the object values as element attributes.

The prototype code that works across the

OpenStack and vCloud platforms is offered as an

open source code (https://github.com/primozc/sso).

4.3 User Migration and Federation

During the development of CAS a special attention

was given to the migration of the users from the CAS

to the cloud platform. An end user who is migrated to

the cloud and authenticated at CAS is able to access

the cloud platform assigned to him by an

administrator. As all users are registered and

authenticated in the CAS, the management of the end

users in remote identity service is not necessary

anymore.

API operations are performed to map the end

users in the local CAS database to the OpenStack

Keystone and the vCloud user database. These

operations provided by CAS enable administrators to

obtain and validate access tokens, manage users,

tenants, roles, and service endpoints. The

administrative API calls against services require

authentication; the calls to discover services are the

only ones without authentication.

An administration token (token for API calls) is

used for various administrative operations, such as

the integration of the OpenStack with the CAS or user

mapping. The Keystone Identity API verifies the

issued administration token and defines the

administration role. Administration tokens are stored

in the local CAS database system in the process of

adding a new cloud platform. A set of identity

attributes, such as email, username and tenant, are

additionally inserted into the OpenStack Keystone

API when the migration of the users into a cloud

platform is performed

The connection between the vCloud component

of vCloud platform and CAS is similar to the one

described above. CAS connects a user to vCloud on

the user’s request by an API call where user

credentials are passed as parameters. Since vCloud

supports SAML, the open source SimpleSAMLphp

library, which implements the SAML 2.0 standard,

was used for exchange of user messages between

CAS and the remote vCloud platform. In CAS an IdP

was defined according to the vCloud Organization

Federation Settings. End users, user groups’ data and

their roles in vCloud are required to be mapped from

the organization’s database and from the

organization’s SAML provider. This restriction

required additional functionality in CAS to be

developed for provision of the data mapping stored in

the vCloud Director database. As SimpleSAMLphp

application does not support dynamic generation of

metadata in an SP’s remote configuration file, an

additional upgrading code was developed. The

generated XML metadata file from the CAS IdP

contains several certificates and information (e.g.,

SingleLogoutService or AssertionConsumerService)

which are necessary by the vCloud Director to be able

to communicate with the CAS IdP and to validate if

it is sufficiently trustworthy. The generated XML

metadata file from the CAS IdP needs to be uploaded

into the vCloud federation metadata XML form

(VMware, 2012). Since SAML users and groups

cannot be found by use of a search function, user’s

data have to be mapped into vCloud with an

automated API call. Adding this feature to the SSO

the vCloud Director integration became complete.

5 DISCUSION AND

CONCLUDING REMARKS

The security threats in cloud computing can be

removed to a big extent with the system protection

capable to resist the attacks. When business entity

networks are migrated to the cloud, their data and

systems are no longer isolated, they share resources

with many other organizations, and this new status is

becoming much more attractive for malicious

CLOSER2015-5thInternationalConferenceonCloudComputingandServicesScience

370

attackers. In the cloud computing core technologies

identified vulnerabilities are mainly related to the

virtual machine escape, poor password protection,

poor authentication and authorization systems,

session hijacking, and insecure cryptographic

algorithms. The presented work in this paper can be

considered as an attempt to remove some of these

vulnerabilities that are related to the user

authentication and authorization.

Authentication and authorization of the

OpenStack and VMware platforms were carefully

studied before a solution enabling a federated IdM

approach to be applied in cloud computing

environment emerged. The developed solution, the

Common Authentication Solution connects both

platforms and enables secure authentication service

and friendly remote user management. CAS has been

implemented for integrating the user authentication of

the addressed platforms, but it is sufficiently general

to be used for other environment as well. The

Microsoft cloud solution already offers some options.

A SOAP library (Ruby library), for example, can be

used to use the functionality in Windows Remote

Management (WinRM) to call native object in

Windows. This includes, but is not limited to, running

batch scripts, powershell scripts and fetching WMI

variables. This way, we can communicate and map

users between CAS and the Hyper-V cloud. Another

popular open source cloud platform OpenNebula

contains a patch in the authentication system, and two

standard SimpleSAMLphp modules that can be used

to establish connection between CAS and

OpenNebula. Furthermore, Eucalyptus and

CloudStack are still missing the SAML support in

their authentication system, but their aim is to

integrate the SSO SAML support. Despite the lack of

SAML support there can be a patch developed to

support this feature. It is necessary to reiterate at this

point that our aim was to provide a unified interface

for many other well-known cloud providers and

provide simple integration of our platform with other

IaaS platforms.

Acting as a kind of a broker, CAS introduces only

a slight overhead (login to CAS) to the multi-platform

cloud operation from the user point of view when

only one platform is accessed. On the other hand CAS

relieves the user from frustration of having to

remember multiple passwords and enables him easier

access to multiple cloud platforms. CAS functionality

improves administration performance by providing

one interface to manage multiple cloud platforms.

The amount of time spent for logging on to different

cloud platforms is reduced and it provides faster

access to the resources.

Cloud computing still needs much more

development and deployment for provision of secure

and trustworthy services. The future development is

planned to be oriented towards provision of a unified

access point for many other well-known cloud

providers such as Amazon, DigitalOcean, Slicehost,

or Rackspace. For this reason, our future work is

oriented to the extension of the functionality of the

CAS system in order to support other features that are

common to different cloud providers and platforms,

such as management of a cloud network, virtual

machine, image and storage.

REFERENCES

Abdo, J. B., Demerjian, J., Chaouchi, H., Barbar, K., &

Pujolle, G. (2013). Broker-Based Cross-Cloud

Federation Manager. In Internet Technology and

Secured Transactions (ICITST), 2013 8th International

Conference for (pp. 244-251). IEEE.

Andronache I., Nisipasiu C., 2011. Web single sign-on

implementation using the simpleSAMLphp

application. Journal of Mobile, Embedded and

Distributed Systems. 3(1):21-9.

Cantor S., Kemp I.J., Philpott N.R., Maler E., 2005.

Assertions and protocols for the oasis security assertion

markup language. OASIS Standard.

Cigoj P., 2014. Cloud computing security and identity

management in the OpenStack platform. Ljubljana:

Jožef Stefan International Postgraduate School.

Cruz Zapata, B., Fernández-Alemán, J.L., & Toval, A.

(2014). Security in Cloud Computing: a Mapping

Study. Computer Science and Information Systems

12(1):161–184.

Ferg B., Fitzpatrick B., Howells C., Recordon D., Hardt D.,

Reed D., et al. 2007. OpenID authentication 2.0.

Fernandes, D.A.B., Soares, L.F.B, Gomes, J.V., Freire,

M.M., & Inácio, P.R.M., 2014. Security issues in cloud

environments: a survey. International Journal of

Information Security, vol. 13, iss. 2, pp. 113-170.

Ferraiolo D.F., Sandhu R., Gavrila S., Kuhn D.R.,

Chandramouli R., 2001. Proposed NIST standard for

role-based access control. ACM Transactions on

Information and System Security (TISSEC). 4(3):224-

74.

Group TO, 2014. Single Sign On. Available from:

http://www.opengroup.org/security/sso/.

Grozev, N., & Buyya, R. (2014). InterCloud architectures

and application brokering: taxonomy and survey.

Software: Practice and Experience, 44(3), 369-390.

Jansen, W., Grance, T., 2011. Guidelines on security and

privacy in public cloud computing. NIST special

publication. 800:144.

Lonea A.M., Tianfield H., Popescu D.E., 2003. Identity

management for cloud computing. New Concepts and

Applications in Soft Computing: Springer. 175-99.

AnApproachintheDesignofCommonAuthenticationSolutionforaMulti-PlatformCloudEnvironment

371

Microsoft. Microsoft Urges Government and Industry to

Work Together to Build Confidence in the Cloud 2010.

Available from: http://www.microsoft.com/en-

us/news/press/2010/jan10/1-20brookingspr.aspx.

Oracle, 2013. Oracle Access Management OAuth Service

2013. Available from: http://www.oracle.com/tech

network/middleware/id-mgmt/overview/oauthservice

white paper-2110557.pdf.

Panarello, A., Celesti, A., Fazio, M., Villari, M., &

Puliafito, A. (2014). A Requirements Analysis for IaaS

Cloud Federation. In 4th International Conference on

Cloud Computing and Services Science, Barcelona,

Spain.

Pérez-Méndez, A., Pereniguez-Garcia, F., Marin-Lopez,

R., López-Millán, G., & Howlett, J. (2014). Identity

Federations Beyond the Web: A survey. IEEE

Communications Surveys & Tutorials, Vol. 16, No. 4.

Simmonds, P., Rezek, C., Reed, A., 2011. Security

guidance for critical areas of focus in cloud computing

v3.0. Cloud Security Alliance. 176 pages.

Tripathi, A., Mishra, A. (2011). Cloud computing security

considerations. In: IEEE International Conference on

Signal Processing, Communications and Computing,

pp. 1–5.

Toosi, A. N., Calheiros, R. N., & Buyya, R. (2014).

Interconnected cloud computing environments:

Challenges, taxonomy, and survey. ACM Computing

Surveys (CSUR), 47(1), 7.

VMware, 2012. vCloud director user's guide, 2012.

Available from: http://pubs.vmware.com/vcd-

51/topic/com.vmware.ICbase/PDF/vcd_51_users_guid

e.pdf.

CLOSER2015-5thInternationalConferenceonCloudComputingandServicesScience

372
