Renewable Energy-aware Data Centre Operations for Smart Cities

The DC4Cities Approach

Sonja Klingert

, Florian Niedermeier

, Corentin Dupont

, Giovanni Giuliani

Thomas Schulze

and Hermann de Meer

Software Engineering Group, University of Mannheim, Mannheim, Germany

Computer Networking and Computer Communications Group, University of Passau, Passau, Germany

Create-Net, Trento, Italy

HP Italy Innovation Center, Milan, Italy

Keywords: Data Center, Energy-aware, Renewable Energy Source, Smart Cities, Workload Scheduling.

Abstract: Data centres are important players in smart cities both as IT service providers and as energy consumers.

Integrating intermittent renewable energy sources into the local power grid is one challenge in future smart

cities aiming at an IT based low carbon economy. The project DC4Cities takes up this challenge by offering

a both technical and business related solution for optimizing the share of local renewable power sources

when operating data centres in smart cities. To this end, power management options between the data centre

and the smart city together with internal adaptation strategies for data centres are introduced. Finally, an

implementation of the suggested approach is presented and evaluated in a simulation.

1 INTRODUCTION

In 1516 Sir Thomas More published his book

“Utopia”, a vision of a perfect society which became

the blueprint of all future visions for an ideal

society. Today, facing the risk of climate change

processes we cannot control, we are again badly in

need of visions.

In this paper we offer a vision with regards to an

eco-friendly data centre (DC) management in smart

cities. The challenge is a society that runs on big

data, especially in smart cities whose organisation is

based on sensor networks along the dimensions of

smart governance, smart economy, smart mobility,

smart environment, smart people, and smart living.

All data created by these sensors need to be

collected, processed and put into effect by DCs,

most of them within the geographical boundaries of

the smart city. However, in order to maintain a level

of CO2 emissions which is in line with the EU’s

emission goals of 2020, 2030, and beyond (EC,

2009), this data management needs to be done with

as little impact on the smart city’s CO2 balance as

possible.

The general setting for such a vision is to enable

a near real-time communication between the smart

city, all DCs participating in this scheme and

specific customers of the DCs. The smart city can be

represented by a so-called Energy Management

Authority of the Smart City (EMA-SC) which acts as

a mediator between the DCs and the energy system.

As such, it overviews and analyses the current state

of the power grid and the availability of renewable

energy resources. From these data and under some

other constraints the DC then computes an ideal

power plan. Depending on how accurately this ideal

power plan is implemented, the DC is either

rewarded or might need to pay a fine.

This paper gives more insight into the DC4Cities

research and associated prototype that implements it.

Section 2 will give a more detailed overview on the

general research idea, section 3 will introduce the

architecture of the DC4Cities implementation, and

section 4 will present first simulation results.

Finally, section 5 will position our approach in

relation to others’ work.

2 GENERAL APPROACH

Operating a DC at a level of 100% of renewable

energy is not a problem if its energy provider is only

Klingert S., Niedermeier F., Dupont C., Giuliani G., Schulze T. and de Meer H..

Renewable Energy-aware Data Centre Operations for Smart Cities - The DC4Cities Approach.

DOI: 10.5220/0005430600260034

In Proceedings of the 4th International Conference on Smart Cities and Green ICT Systems (SMARTGREENS-2015), pages 26-34

ISBN: 978-989-758-105-2

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

using hydro or geothermal sources. To save CO

emissions caused by DCs one might suggest to move

them to places offering corresponding infra-

structures like Norway. Even though large DC

owners like Google are considering this as a solution

for parts of their DCs, it is not practicable in all

scenarios. Some DCs need to be close to users and

inside cities for manifold reasons: Companies often

see security risks in outsourcing data or other IT

services, especially to foreign countries. Network

latency is another aspect that makes moving services

to distant locations unfeasible (e.g. near real-time

stock exchange services). So, if moving DCs to

locations with a high availability of renewable

energy is not an option, DCs need to become more

energy aware, energy efficient, and energy adaptive.

However, running a DC at high levels of renewable

energy sources in the city is a great challenge. A

main reason for this is the lack of availability of

locally produced renewable energy due to space

limitations

Figure 1: DC4Cities Impact on Renewable Energy

Utilization.

In order to tackle this problem, DCs need to try

to adapt better to the availability of renewable

energy, minimize their energy consumption for

specific tasks in general and adhere to constraints of

a higher directive which is managing energy aspects

in a smart city – the afore mentioned EMA-SC.

Figure 1 schematically shows a renewable-energy

optimized and non-optimized DC. On the left hand

side, the energy consumption of a traditional, i.e.

non-optimized DC is shown, which clearly does not

correspond to the generation curve of renewable

energy. The right hand side depicts the energy

profile of the same DC after DC4Cities has been

applied. Here the production and consumption

curves are much more alike, and therefore the

amount of renewable energy used by the DC is much

higher. In order to reach this goal, an active

coordination between EMA-SC and a DC is

mandatory for setting reasonable goals as well as

technique for controlling energy adaptation within

the DC.

The EMA-SC is responsible for the energy

coordination within a smart city and the

communication with DCs. It monitors the energy

consumption and computes the desired energy

consumption both for the smart city as a whole and

individual DCs, and it sets certain targets for DCs

and other large consumers inside the city. In case

some of the targets cannot be reached, it also tries to

resolve such conflicts by facilitating the negotiation

of objectives with the respective consumers’

organizations. In the case of a DC such an escalation

could for example lead to workload relocation

within a federation of DCs having different energy

sources or simply the payment of a fine.

Figure 2: DC4Cities High-Level Architecture.

For the DC internal adaptation, two objectives

are pursued: on the one hand re-organizing workload

(and thus the energy consumption profile) in order to

match the shape of the renewable supply curve, and

on the other hand minimizing energy consumption in

order to meet the current level of renewable supply.

The DC4Cities controller (in the middle of fig 2)

will retrieve forecasts about the energy source mix

directly from the providers or indirectly through

forecasting models. This is done through the

“Renewable Energy Adaptive Interface”. For

example for local solar panels, we start from weather

forecasting data.

This information will be processed periodically

(e.g. every 15 minutes) and merged with the power

objectives of the DC in order to compute the ideal

power plan for the DC (see section 2.1). Inside the

DC, this “energy budget” will then be split onto the

different services; for each service a so-called

“Energy Adaptive Software Controller” (EASC) will

use DC specific monitoring and automation tools to

correctly schedule and tune the SW/HW resource

usage of this service in line with the directives

received by the controller through the “Energy

Adaptive DC Operation Interface”. The expected

RenewableEnergy-awareDataCentreOperationsforSmartCities-TheDC4CitiesApproach

result is that the actual power consumption of the

whole DC will be considerably closer to the

previously computed ideal power plan, thus meeting

the DC power objectives received by the Smart City.

2.1 Coordination between Smart City

and Data Centre

Coordination between the smart city and DCs under

its energy management scheme is managed by

EMA-SC. In our scenario we assume EMA-SC to be

located inside the smart city (a stand-alone solution

is also possible). We also assume that the smart city

has certain goals regarding the share of renewable

energy in the energy mix of its big consumers. These

goals are quite high-level and therefore hardly

immediately technically enforceable. However, by

subdividing these high-level goals into more

concrete objectives, the smart city goals can be

translated into constraints regarding power/energy

usage. Once these constraints are in place and

information on future renewable energy availability

has been obtained, EMA-SC is able to calculate

power budgets for the large consumers inside the

city. To this end, the DC4Cities software includes a

component named Ideal Power Planner (IPP). The

IPP is responsible for transforming renewable

energy forecasts and power/energy usage constraints

imposed by EMA into a power plan for a DC. The

IPP executes the following steps:

1. Calculate the total amount of renewable power

available to the DC from the renewable energy

availability forecast(s)

2. Using information on the minimum

(DCPowerMIN) and maximum

(DCPowerMAX) power demand of the DC,

scale the values obtained in step 1 so that the

difference of the maximum and minimum

corresponds to the difference of

DCPowerMAX and DCPowerMIN

3. Shift the result of step 2 so that the minimum

aligns with DCPowerMIN

4. Apply any constraints from SC side, e.g.,

power and energy constraints

These power plans are then communicated to the

DCs, which will follow them as closely as possible.

While the basic compliance of power/energy

objectives has to be secured via trial runs at the

configuration time of the software system, everyday

changes in energy supply may lead to a non-

compliance regarding objectives from DC side. To

handle this case, DC4Cities includes an escalation

mechanism.

Figure 3: Communication between EMA and DC.

A DC will trigger an escalation in case it cannot

comply with objectives by means of internal

adaptation. In case of such an escalation, EMA-SC

may seek further external solutions such as

suggesting and supporting a federation with other

DCs or updating/adding objectives. As these

escalations are exceptional cases, they can also be

handled in a face-to-face manner between the DC

and EMA-SC. Escalation may be triggered manually

or automatically in case no DC operation compliant

with the IPP can be calculated or if a threshold

agreed on in the contract is violated. Depending on

the time until the occurrence of the predicted non-

compliance, two stages of escalation are envisioned:

A ‘warning’ which marks a possible exceeding of

thresholds in the future (e.g., > 6 hours), and an

‘alarm’ (e.g., < 6 hours). Possible reactions of EMA-

SC depend on the underlying RenEnergy contract

with the DC (see section 2.3). The following de-

escalations are envisioned:

 Tolerate violation of objectives because of.

unforeseen temporary events either at DC side

or originating from energy side

 The RenEnergy contract might allow a certain

number and frequency of violations.

 Incur penalty according to an agreed

reward/penalty scheme

 Change objectives (temporarily/permanent)

 Set temporary objectives in order to prevent

decrease in goal achievement

 Offer federation assistance

Obviously, the occurrence of an escalation

depends on the metrics used by the DC4Cities

system in order to assess the “fitness” of the DC

with respect to its goals. The metrics are for instance

used to measure the distance between the ideal

power plan and the actual power utilization of the

DC. Based on the distance and a threshold value,

escalation events might be determined.

2.2 Energy Adaptation within a Data

Centre

Following the communication with EMA-SC, the

compliance with its goals needs to be implemented

inside the DC.

The novelty of DC4Cities is to propose a multi-

SMARTGREENS2015-4thInternationalConferenceonSmartCitiesandGreenICTSystems

level API able to allow each level of a modern DC to

follow energy directives (see Figure 4). There are

three levels: IaaS, PaaS and individual applications.

Firstly, we need to reschedule some tasks

performed in the DC to match the hours where

renewable energy is available. This scheduling

requires detailed knowledge about the applications

running in the DC and should therefore be tackled at

the level of PaaS, where we have the knowledge of

the applications running. Additionally, the PaaS

layer provides a uniform interface to interact with

the applications, and to scale them up and down.

Figure 4: Components of the DC Subsystem.

The secondary objective of DC4Cities is to save

energy in the DC. Previous projects such as

FIT4Green

showed that it is most efficient to use

the IaaS layer in order to consolidate virtual

machines (VMs) on the most efficient servers, and

then switch off the unused servers.

Thirdly, we need to control specific applications

in the DC, such as maintenance jobs. Applications

such as virus scan or database compression are ideal

candidates because they perform regular tasks that

can be rescheduled if needed.

2.2.1 IaaS Optimization

At IaaS level, we adapt key parameters of an

existing VM scheduler, such as the consolidation

factor and the VM migration frequency. This allows

the VM scheduler to follow energy directives

provided by the EMA, while, of course still

respecting the SLA of each VM. For instance, when

there is little renewable energy available, we

increase the consolidation factor. This will cause the

migration of VMs and in a second step the shutdown

of unused servers. If there is a high level of

renewable energy available, we relax the VM

scheduler constraints, so that VMs will not need to

be migrated to be more consolidated. At this level

http://www.fit4green.eu

the VMs are “anonymous”: we don’t know which

software is running inside them nor at what time

they might be shut down, since this is at the

discretion of the client. A tool such as Plug4Green

(Dupont et al., 2014) or OpenStack Neat

(Beloglazov et al., 2014) can be used.

2.2.2 PaaS Optimization

A PaaS manager allows automating the deployment

of applications in VMs. It is backed up by the IaaS

framework running the VMs. A PaaS manager such

as Cloud Foundry

also provides a certain number of

common services for all applications. The PaaS

optimization in DC4Cities then consists in (1)

consolidating and tuning up and down the

performance of those services, (2) issuing

commands to scale up and down the controlled

applications. This scaling can happen in two

different dimensions: either vertically or

horizontally. Vertical scaling allows, for example, to

allocate more CPUs or more RAM to a particular

VM. Horizontal scaling of an application allows

creating new VMs containing new instances of the

same application. The PaaS layer is then offering us

several opportunities for optimization of applications

according to renewable energy availability. In

particular, the common interface for horizontal

scaling of applications is promising.

2.2.3 Application Optimization

As a third adaptation strategy, DC4Cities ultimately

controls some key applications and processes of a

DC. This includes virus scanning, database cleaning,

but also physical server scheduled maintenance.

Indeed, server maintenance is a recurring activity in

a DC and it has a significant energetic impact

(Soundararajan et al., 2010).

There are two kinds of applications directly

controlled by DC4Cities: task-oriented and service-

oriented. In the first case tasks are scheduled and

performed by the applications, such as offline video

transcoding or web crawling. In some cases, those

tasks can be post- or pre-poned. We take advantage

of this possibility to schedule tasks at the right

moment (obviously compliant with the underlying

contract). The DC4Cities prototype then monitors

the progress of the task and its KPIs. If it is e.g. too

late, it will modify its schedule to finish faster.

Service-oriented applications, on the other hand,

have a continuous service to perform, such as

serving web pages. In this case, we tune the

http://www.cloudfoundry.org

RenewableEnergy-awareDataCentreOperationsforSmartCities-TheDC4CitiesApproach

performance of the application within an identified

range while respecting the SLA. For example, in the

case of a web server, we augment/reduce the number

of client threads within the boundaries of the SLA.

2.2.4 Coordination Strategies

The optimization in DC4Cities happens at two

stages. First, relatively autonomous application

managers (the EASCs) allow enforcing energy

budgets at IaaS, PaaS and individual application

levels. Indeed, a situation with fully autonomous

energy-aware applications, following the same

energy directives, enables an increased usage of

renewables. Secondly, DC4Cities offers an

additional level of coordination: the prototype

communicates with each EASC to retrieve their

scheduling options and can then arbitrate between

them. This level of coordination is necessary for

better results: the energy directives need to be

adapted for each EASC, because each underlying

application has a different level of flexibility.

Furthermore, the execution patterns provided by

each application need to be consolidated in a central

system in order to make decisions. This would e.g.

avoid the creation of power demand peaks.

The central system should also be able to split

the energy budget granted by the EMA between the

overlapping systems. Indeed, the energy allocation

for the EASC-Apps is overlapping the energy

allocation of the EASC-PaaS, because some

applications might be operated by PaaS managers.

Similarly, the energy allocation for the EASC-PaaS

is overlapping the energy allocation of the EASC-

IaaS, because VMs created by a scaling command

on a PaaS manager are hosted by an IaaS manager.

2.3 Incentives and Monitoring

The previous sections showed that from a technical

point of view it is possible to create a consistent

vision on how to integrate DC energy management

into a smart city relying heavily on renewable

energy. However, in order for this idea to

disseminate and for the vision to become a reality in

future decades, this technical approach must be

viable from a business point of view, both for

participating DCs and the smart city.

As the first goal is not to ‘save’ energy, i.e. to

reduce the amount of energy needed, but rather to

rearrange the power profile of a DC, under today’s

energy tariffs there is no direct power cost reduction.

Here the smart city comes into play as mediator

between energy system and DC – a mediator with

pre-defined goals regarding the share of renewable

energy at the city’s energy mix.

Ignoring the option of a ‘dictator’ smart city, the

EMA-SC needs to incentivize DCs to adhere to the

DC4Cities scheme. Both (real-time) dynamic energy

prices and green tariffs are not applicable: dynamic

prices e.g. formed by the timely interaction on the

energy wholesale market, reflect the scarcity of all

power in the power grid and not the availability of

renewables. On the other hand, green tariffs today

are offered only on certificate basis, i.e. they define

“green” by renewable power being fed into the

power grid anywhere and thus regularly level out the

volatility of – locally produced – renewable power.

Therefore, we propose a so-called ‘RenEnergy’

contract between EMA-SC and the DC that contains

both a model for which behaviour to reward or

penalize and how to monitor this behaviour.

As shown in section 2.1 an ideal power plan IPP

is calculated as reference power profile and power

plan for the DC. The deviation between the IPP and

the realized power profile of the DC is the basis for a

new metric, DCAdapt, whose parameter value needs

to be determined in the RenEnergy contract.

Additionally for monitoring and rewarding the DC’s

effort to adapt to the IPP, the new metric RenPercent

represents the share of renewable energy

consumption of the power profile of a DC. This is

the second pillar of RenEnergy contracts.

However, the DC’s options to adapt the

workload - and with it its power profile - to the IPP

are limited due to contracts with its customers laid

down in service level agreements, SLA. Former

work by the authors suggested how to turn these into

GreenSLAs that reward the customers for

collaboration whenever an adaption process in the

DC is necessary. These GreenSLAs are implemented

in the DC4Cities system through ‘green points’ that

are granted to those customers that permit the DC to

shift its workload when required by the IPP.

3 ARCHITECTURE

This section presents the high-level architecture of

the DC4Cities approach and provides details on the

prototype that has been developed to validate it.

The overall technical architecture is in strict

relation with the pattern described in the general

approach (at the beginning of section 2) and is

organized in a set of modules with clear

responsibilities. The following diagram graphically

represents the different modules and the interactions

during the main control loop:

SMARTGREENS2015-4thInternationalConferenceonSmartCitiesandGreenICTSystems

1. DC4cities process controller retrieves the

next 24 hours energy forecasts for each

electricity provider of the DC through the

ERDS handler

2. The Max/Ideal power plan (see section 2.1) is

computed

3. The power plan is split into different plans,

one for each service hosted by the DC (see

section 2.2)

4. Multiple splitting policies can be configured

to better tailor the system to the DC business

needs

5. The controller will request EASC to create

specific power budgets for the next 24 hours

for each service

6. The Option plan collector will receive a set of

possible alternatives by each EASC

7. All Option plans will be consolidated and

globally optimized to achieve the best usage

of renewable energy source

8. If a good solution is found, the different

EASC will receive the confirmation of which

option plan to enact. If no solution is found, an

escalation process is triggered [8x]

9. EASC will use automation tools to control the

SW/HW resources of the service in line with

the received plan (Working Mode).

10. Finally the controller will share the DC power

plan with the energy provider, to enable some

form of demand/response cooperation

Figure 5: DC4Cities Architecture.

Besides the external interfaces described in

section 2, additional internal interfaces connect the

controller to the web presentation of the dashboard

(on the right side of Figure 5) and to the historical

database subsystem (left) used to store all monitored

data as well as to support predictions using on

correlation models based on the collected data.

The prototype of DC4Cities is implemented in

Java and hosted inside a Tomcat Application Server;

the external interfaces are defined and supported

using JSON/Rest technology.

4 TRIALS AND EXPECTATIONS

The EU project DC4Cities includes three trials to

validate the system using different services inside

DCs who have different power providers with

various characteristics:

 CSUC and IMI; Barcelona (Spain), powered

by Gas Natural; CPU intensive video

conversion tasks; federation option

 CN/APSS; Trento (Italy), powered by Italian

grid, located with lots of hydro production;

report generation tasks for health system

 HP; Milan (Italy), powered both by local

photovoltaics (PVs) and the Italian grid; test

lab for a Web E-learning platform offering a

world-wide service (HP LIFE, an HP Living

Progress initiative)

When writing the initial version of this paper a

small model was developed based on preliminary

measures in Trento and HP, to provide first ideas

about expected results. Now, the first phase of the

trial has just been completed, and collected results

are in line with these expectations. The detailed

report of the trial will be published as public project

deliverable D6.2 on DC4Cities project website.

The model considers a batch oriented application

that needs to produce 4320 reports/day (similar to

the Trento trial), initially running with power only

from the Italian grid. On an average day, the

renewable energy percentage varies between 29.21%

and 49.18% (average 37.16%). If the report

generation is spread with uniform distribution over

24 hours, obviously the average RenPercent (see

section 2.3) of the power spent by the HW resources

of this

service is 37.16% as depicted in Figure 6.

Figure 6: Uniform Workload distribution over 24 hours.

If the computing jobs are concentrated on a few

hours (running several reports in parallel) exactly at

the time when the grid has the highest share of

renewable energy, and if unused servers are then

turned off, the RenPercent for the service becomes

42.20%, still producing the same amount of work –

in terms of reports generated (

Figure 7).

Adding 8 solar panels to the previous setting,

RenewableEnergy-awareDataCentreOperationsforSmartCities-TheDC4CitiesApproach

each one generating a maximum of 250Wh, with a

hourly distribution similar to the one measured at

HP solar lab (as shown in Figure 8), and

concentrating the computing when the highest power

is provided by the PVs, without exceeding their

production limits, the expected RenPercent will

reach 79.41% (see Figure 9).

Figure 7: Workload concentrated at Grid max Ren

Percent.

Figure 8: PV hourly power production.

Figure 9: Workload concentrated at max PV production.

The workload parallelism is lower compared to

the previous case, but still 4320 reports/day are

produced. This model is useful to scope the

expectations on the effectiveness of DC4Cities

control mechanisms in the optimization of

renewable energy percent: When using only one

energy source like the grid (or smart grid), the

theoretical maximum RenPercent for the DC is less

than or equal to the max RenPercent of the grid. The

highest value can be obtained only by concentrating

all the load (and therefore consumption) during the

period of highest RenPercent from the grid, and

having zero consumption in other periods. Since this

last case is not applicable in real cases, the

practically achievable optimized value for the DC

will be an intermediate value between the average

and the maximum RenPercent of the grid.

When using additional local PVs, task

shifting/tuning optimizations are needed anyways:

adding PVs without reorganizing the workloads

gives much lower RenPercent improvements.

Optimal conditions can be evaluated also trying to

minimize the number of PVs needed to reach a

certain power objective/goal - thus also reducing the

costs and surface requirements related to PVs.

5 RELATED WORK

Our work is an amalgamation of three different

areas: research about integrating renewable energy

into smart city energy supply and distribution, also

related to the integration of renewables into the

smart grid. The second area is energy-aware

operation of DCs via workload control, and the third

concerns with energy aware contracts of and with

DCs.

(Brenna et al., 2012) look into energy challenges

of smart cities, including how to increase the share

of distributed energy sources at the smart city’s

power consumption; however, the distribution of

available power on consumers is not a topic. The

same applies to (Sioshansi, 2012) who deal with

integrating intermittent energy sources into the smart

grid, using demand response. Also here, the notion

that power is a limited resource and therefore may

require maximum consumption objectives is not

analysed. (Liu et al. 2014) suggest energy budget

optimization for households with shiftable and non-

shiftable loads by scheduling the shiftable load and

buying/selling energy under different information

assumptions. Although the value of this work is high

for DC4Cities as regarding shiftable load the setting

is comparable, the contract option was preferred due

to the high reliability of reaction.

In (Goiri et al., 2013), the authors proposes

GreenSwitch, a model-based approach for sche-

duling dynamically the workload and selecting the

source of energy to use. The authors focus on the

trade-offs involved in powering DCs with solar

and/or wind energy, and propose an implementation

of their solar powered mini DC. With contrast to this

approach, we propose the possibility to schedule the

workload more fine-grained, at application level.

In (Dupont et al., 2015), the authors present

Plug4Green, an energy aware VM manager with a

focus on flexibility and adaptability to new

scenarios. Its main capacity is to migrate VMs and

manage servers on/off state to save energy while

SMARTGREENS2015-4thInternationalConferenceonSmartCitiesandGreenICTSystems

respecting an extensive SLA. Plug4Green is re-used

as a IaaS VM manager in the presented work (see

section 2.2.1). A similar tool is OpenStack Neat.

Finally, the question of how to incentivize DCs

in order to modify their behaviour according to the

availability of renewable energy arises: It relates to

both, to work in the area of SLA induced workload

planning as well as energy aware contracts of DCs

with their power providers. There is some research

of the authors about how to turn SLAs into

GreenSLAs in order to increase the flexibility of the

DC, e.g. (Botero et al., 2013); and we build on this

knowledge base to a high degree. Using SLAs as

constraints to operate DC services like in

(Sakellarriou et al

. 2009) helped a lot understanding

the problem of job scheduling but fell short of the

incentive aspect. Apart from the relation between the

data center and its customers, in order to make DCs

be interested in following renewable power patterns,

they need to have corresponding contracts with their

energy service providers. There is a lot of literature

about different options how to make any type of

customer comply with demand response schema like

in (Aalami et al., 2010, Chao, 2011). But regarding

the specific also technical challenges of integrating

DCs in demand response schemes, again the authors

need to refer to their own work, e.g. (Basmadjian et

al., 2013, Berl et al., 2013).

6 CONCLUSIONS

This paper presented a vision on how to maximize

the share of renewable energy sources when

operating a DC given the conditions of a smart city

aiming at a local low-carbon power supply. It was

shown that this is not only technically feasible but

that there are also design options for the relation

between the DC and the smart city which offer

incentives for the DC to participate in the scheme.

However, the approach is obviously dependent

on the individual technical infrastructure and the real

applications running in the DC as well as on

financial and geographical conditions of the smart

city where it is located. In order to evaluate the

feasibility of the presented approach complementing

trials in a real environment are necessary. These are

planned for the second phase of the project.

ACKNOWLEDGEMENTS

This work was carried out within the European

Project DC4Cities (FP7-ICT-2013.6.2).

REFERENCES

Aalami, H., Moghaddam, M. P., Yousefi, G., 2010.

Demand response modeling considering interruptible

/curtailable loads and capacity market programs. In

Applied Energy 87 (1), Elsevier, 243 – 250.

Basmadjian, R., Niedermeier, F., Lovasz, G., de Meer, H.,

Klingert, S., 2013. GreenSDAs Leveraging Power

Adaption Collaboration between Energy Provider and

Data Centres. In 3rd Conference on Sustainable

Internet and ICT for Sustainability, Proceedings,

IEEE,1-9.

Beloglazov, A., Buyya, R., 2014. OpenStack Neat: A

Framework for Dynamic and Energy-Efficient

Consolidation of Virtual Machines in OpenStack

Clouds. In Concurrency and Computation: Practice

and Experience, Wiley & Sons, (in press).

Berl, A., Klingert, S., Beck, M., de Meer, H., 2013.

Integrating Data Centres into Demand-Response

Management: A Local Case Study. In 39

Conference

of Industrial Electronics Society (IECON), IEEE,

4762-4767.

Botero, J. B., Klingert, S., Hesselbach-Serra,X., Falcone

A., Giuliani, G.,2013. GreenSLAs: Providing Energy

Consumption Flexibility in DCs through Energy-

aware Contracts. In 2nd International Conference on

Smart Grids and Green IT Systems (SMARTGREENS),

SCITEPRESS, 119-122.

Brenna, M., Falvo, M. C., Foiadelli, F., Martirano, L.,

Massaro, F., Poli, D., Vaccaro,A. , 2012. Challenges

in Energy Systems for the Smart-Cities of the Future.

In 2

IEEE EnergyCon Conference, Proceedings,

IEEE,755-762.

Chao, H.,2011. Demand response in wholesale electricity

markets: the choice of customer baseline. In Journal of

Regulatory Economics 39, Springer, 68–88.

Dupont, C., Hermenier, F., Schulze, T., Basmadjian, R.,

Somov, A., Giuliani, G., 2015. Plug4Green: A

Flexible Energy-aware VM Manager to Fit Data

Centre Particu-larities. In Journal AdHoc Networks,

Special Issue on Energy-Aware Data Centres, 2014.

European Commission, 2009. Investing in the

Development of Low Carbon Technologies (SET-

Plan). COM(2009) 519 final.

Goiri, I., Katsak, W., Le, K., Nguyen, Th.D., Bianchini.

R., 2013. Parasol and greenswitch: Managing

datacenters powered by renewable energy. In

SIGARCH Comput. Archit. News, 41(1), 51–64.

Liu, Y., Yuen, C., Ul Hassan, N., Huang, S., Yu, R., Xie,

S., 2014. Electricity Cost Minimization for a

Microgrid with Distributed Energy Resource under

Different Information Availability, IEEE Trans. On

Industrial Electronics, 1-12.

Sakellarriou, R., Yarmolenko, V., 2009. Job Scheduling

on the Grid: Towards SLA-Based Scheduling. In

Lucio Grandinetti (ed), High Performance Comp. and

RenewableEnergy-awareDataCentreOperationsforSmartCities-TheDC4CitiesApproach

Grids in Action, Vol. 16 in Adv. in Parallel

Computing, IOS, 207-222.

Sioshansi, F. P. (ed), 2012. Smart Grid: Integrating

Renewable, Distributed & Efficient Energy, Elsevier.

Soundararajan, V., Anderson, J. M., 2010. The Impact of

Management Operations on the Virtualized

Datacenter. In SIGARCH Comput. Archit. News 38(3).

SMARTGREENS2015-4thInternationalConferenceonSmartCitiesandGreenICTSystems
