Cloud Provider Transparency

A View from Cloud Customers

Daniela S.

Cruzes and Martin Gilje Jaatun

SINTEF – ICT, Postboks 4760 Sluppen, 7465 Trondheim, Norway

Keywords: Cloud, Provider, Customer, Security, Privacy, Accountability, Transparency.

Abstract: A major feature of public cloud services is that data are processed remotely in unknown systems that the users

do not own or operate. This context creates a number of challenges related to data privacy and security and

may hinder the adoption of cloud technology. One of these challenges is how to maintain transparency of the

processes and procedures while at the same time providing services that are secure and cost effective. This

paper presents results from an empirical study in which the cloud customers identified a number of

transparency requirements to the adoption of cloud providers. We have compared our results with previous

studies, and have found that in general, customers are in synchrony with research criteria for cloud service

provider transparency, but there are also some extra pieces of information that customers are looking for.

1 INTRODUCTION

Cloud computing, which allows for highly scalable

computing and storage, is increasing in importance

throughout information technology (IT). Cloud

computing providers offer a variety of services to

individuals, companies, and government agencies,

with users employing cloud computing for storing

and sharing information, database management and

mining, and deploying web services, which can range

from processing vast datasets for complicated

scientific problems to using clouds to manage and

provide access to medical records (Paquette, 2010).

Several existing studies emphasize the way

technology plays a role in the adoption of cloud

services, and most of these studies conclude that the

most important challenges are related to security,

privacy and compliance (Kuo, 2011), (Gavrilov and

Trajkovik, 2012), (AbuKhousa et al., 2012),

Rodrigues et al. 2013), (Ahuja et al. 2012). Cloud

service users may hand over valuable and sensitive

information to cloud service providers without an

awareness of what they are committing to or

understanding of the risks, with no control over what

the service does with the data, no knowledge of the

potential consequences, or means for redress in the

event of a problem.

In the European A4Cloud research project

(http://a4cloud.eu), our focus is on accountability as

the most critical prerequisite for effective governance

and control of corporate and private data processed by

cloud-based IT services. We want to make it possible

to hold cloud service providers accountable for how

they manage personal, sensitive and confidential

information in the cloud, and for how they deliver

services. This will be achieved by an orchestrated set

of mechanisms: preventive (mitigating risk),

detective (monitoring and identifying risk and policy

violation) and corrective (managing incidents and

providing redress). Used individually or collectively,

they will make the cloud services in the short- and

longer-term more transparent and trustworthy for:

• users of cloud services who are currently not

convinced by the balance of risk against

opportunity

• their customers, especially end-users who do not

understand the need to control access to

personal information

• suppliers within the cloud eco-system, who need

to be able to differentiate themselves in the

ultimate commodity market.

In this paper we report on the results of an

elicitation activity related to transparency

requirements from the perspective of cloud

customers. A Cloud Customer in our context is an

entity that (a) maintains a business relationship with,

and (b) uses services from a Cloud Provider;

correspondingly, a Cloud Provider is an entity

responsible for making a [cloud] service available to

Cloud Customers.

Transparency is the property of an accountable

system that is capable of ‘giving account’ of, or

Cruzes D. and Jaatun M..

Cloud Provider Transparency - A View from Cloud Customers.

DOI: 10.5220/0005439000300039

In Proceedings of the 5th International Conference on Cloud Computing and Services Science (CLOSER-2015), pages 30-39

ISBN: 978-989-758-104-5

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

providing visibility of, how it conforms to its

governing rules and commitments (Felici et. al,

2013). Transparency involves operating in such a way

as to maximize the amount of and ease-of-access to

information which may be obtained about the

structure and behavior of a system or process. An

accountable organization is transparent in the sense

that it makes the policies on treatment of personal and

confidential data known to relevant stakeholders, can

demonstrate how these are implemented, provides

appropriate notifications in case of policy violation,

and responds adequately to data subject access

requests. In an ideal scenario, the user knows the

information requirements and is able to communicate

that clearly to the provider, and in return, the provider

is transparent and thus willing to address the

regulatory and legislative obligations required with

regard to the assets.

The rest of the paper is organized as follows.

Section 2 presents some background from the

literature. Section 3 explains the methodology that we

used to elicit the views of the stakeholders. In section

4 we present the results, and in section 5 we discuss

our findings compared to related work. We draw our

conclusions in section 6.

2 RELATED WORK

Transparency is closely connected to trust (Yang and

Tate, 2012). Onwubiko (2010) affirms that trust is a

major issue with cloud computing irrespective of the

cloud model being deployed. He says that cloud users

must be open-minded and must not whole-heartedly

trust a provider just because of the written-down

service offerings without carrying out appropriate due

diligence on the provider; where certain policies are

not explicit, users should ensure that missing policies

are included in the service contract. By understanding

the different trust boundaries, each cloud computing

model assists users when making decision as to which

cloud model they can adopt or deploy.

Khorshed et al. highlight the gaps between cloud

customers' expectations and the actually delivered

services, as shown in Figure 1 (Khorshed et al., 2012).

They affirm that cloud customers may form their

expectations based on their past experiences and

organizations’ needs. They are likely to conduct some

sort of survey before choosing a cloud service

provider similar to what people do before choosing an

Internet Service Provider (ISP). Customers are

Figure 1: Understanding Cloud Computing Gaps adapted from Khorshed et al. (2012).

Organiza ons’

Needs

Past

Experience

Survey

Cloud

Providers

Expected

Service

Confiden ality

Integrity

Availability

will

trust

you,

you

are

Transparent

Perceived

Service

GAP

You

need

trust

every

level.

company

policy

won’t

allow

100%

Transparent

Trust

Threats

Risks

GAP

Agreement

Cloud

Customer

Cloud

Service

Provider

CloudProviderTransparency-AViewfromCloudCustomers

expected to also establish to what extent providers

satisfy confidentiality, integrity and availability

requirements. On the other hand, cloud service

providers may promise a lot to entice a customer to

sign a deal, but harsh reality is frequently

accompanied by insurmountable barriers to keeping

some of their promises. Many potential cloud

customers are well aware of this, and are

consequentially still sitting on the sidelines. They will

not venture into cloud computing unless they get a

clear indication that all gaps are within acceptable

limits.

Durkee (2010) says that transparency is one of the

first steps to developing trust in a relationship, and

that the end customer must have a quantitative model

of the cloud’s behavior. The cloud provider must

provide details, under NDA if necessary, of the inner

workings of their cloud architecture as part of

developing a closer relationship with the customer.

Durkee also says that this transparency can only be

achieved if the billing models for the cloud clearly

communicate the value (and avoided costs) of using

the service. To achieve such clarity, the cloud vendor

has to be able to measure the true cost of computing

operations that the customer executes and bill for

them.

Pauley (2010) proposed an instrument for

evaluating the transparency of a cloud provider. It is

the only empirical evaluation that we found that

focuses on transparency in the cloud as a subject of

study. The study aims to help businesses assess the

transparency of a cloud provider’s security, privacy,

auditability, and service-level agreements the

Table 1: Pauley’s Cloud Provider Transparency Scorecard.

Aspect

Criteria Mentioned in

Interviews?

Business

factors

1. Length in years in business > 5?

2. Published security or privacy breaches?

3. Published outages?

4. Published data loss?

5. Similar customers?

6. Member of ENISA, CSA, CloudAudit, OCCI, or other

cloud standards groups?

7. Profitable or public?

Yes

Security 8. Portal area for security information?

9. Published security policy?

10. White paper on security standards?

11. Does the policy specifically address multi-

tenancy issues?

12. Email or online chat for questions?

13. ISO/IEC 27000 certified?

14. COBIT, NIST SP800-53 security certified?

15. Offer security professional services (assessment)?

16. Employees CISSP, CISM, or other security certified?

Yes

Partially

Privacy 17. Portal area for privacy information?

18. Published privacy policy?

19. White paper on privacy standards?

20. Email or online chat for questions?

21. Offer privacy professional services (assessment)?

22. Employees CIPP or other privacy certified?

Yes

Partially

External

audits or

certifications

23. SAS 70 Type II

24. PCI-DSS

25. SOX

26. HIPAA

Service-level

agreements

27. Does it offer an SLA?

28. Does the SLA apply to all services

29. ITIL-certified employees?

30. Publish outage and remediation?

Yes

CLOSER2015-5thInternationalConferenceonCloudComputingandServicesScience

the transparency of a cloud provider’s security,

privacy, auditability, and service-level agreements

via self-service Web portals and publications. Pauley

designed a scorecard (Table 1) to cover the

assessment areas frequently raised in his research,

and to begin to establish high-level criteria for

assessing provider transparency. He concludes that

further research is needed to determine the standard

for measuring provider transparency. In our research

we used a different strategy than Pauley; we have

interviewed customers of cloud services to see what

kind of information they would like to get from the

cloud providers.

3 METHODOLOGY

As part of the project, we were responsible for

running a set of stakeholder workshops for eliciting

requirements for accountability tools. In total, our

elicitation effort has involved more than 300

stakeholders, resulting in 149 stakeholder

requirements. The first workshop dealt with eliciting

initial accountability requirements, serving as a

reality-check on the three selected business use cases

we had constructed (Bernsmed et al., 2014). The

second workshop dealt with risk perception. The aim

was to focus on the notion of risk and trust assessment

of cloud services, future Internet services and

dynamic combinations of such services (mashups).

After the first two workshops, we decided to organize

multiple smaller, local workshops on each theme to

ease participation of cloud customers and end users.

The third set of workshops presented stakeholders

with accountability mechanisms to gather their

operational experiences and expectations about

accountability in the cloud.

Of particular importance to this study was the risk

workshop, where 15 tentative requirements related to

transparency where identified. This workshop

comprised 20 international stakeholders from the

manufacturing industry, telecom, service providers,

banking industry and academia, and the tentative

transparency requirements were subsequently

presented to our interviewees as a starting point for

the discussion.

In addition to the stakeholder requirements, we

have devised a set of high-level requirements which,

from an organizational perspective, set out what it

takes to be an accountable cloud provider (Jaatun et

al., 2014). These requirements intend to supplement

the requirements elicitation process by providing a set

of high-level "guiding light" requirements,

formulated as requirements that accountable

organizations should meet. In short, these

requirements state that an accountable organization

that processes personal and/or business confidential

data must 1) demonstrate willingness and capacity to

be responsible and answerable for its data practices 2)

define policies regarding their data practices, 3)

monitor their data practices, 4) correct policy

violations, and 5) demonstrate policy compliance.

From these activities we have created a repository

with requirements from all elicitation workshops, the

guiding lights requirements as well as a number of

more technical requirements that have originating

from the conceptual work and technical packages in

the project. These have been classified in terms of

whether they are functional requirements, which are

directly related to the actors involved in the cloud

service delivery chain, or requirements for

accountability mechanisms, which are related to the

tools and technologies that are being developed in the

project.

For refining and confirming the elicited

requirements of transparency, we have performed an

interview study with eight interviewees, followed by

an in-depth analysis of the collected information.

Invitations were sent to our list of contacts in

Norwegian software companies. Participation was

voluntary. Eight people accepted to participate in the

interviews. The participants were all IT security

experts working with cloud related projects. The

participants represented six different organizations: a

consultancy, 2 cloud service providers (1 public, 1

private), an application service provider, a

distribution service provider, and a tertiary education

institution.

The interviews were performed on Skype and

lasted about one hour. The main questions of the

interview were:

1. What is the most important information you

think should be provided to the cloud customer

when buying services from cloud service

providers?

2. In which parts would you like to be involved

in making the decisions? In which parts would

you like just to be informed of the decisions?

3. What would increase your trust that the data is

secure in this scenario?

4. What do you want to know about how the

provider corrects data security problems?

The eight interviews for this study were

transcribed into text documents based on the audio

recordings. For further analysis of the transcription,

we followed the Thematic Synthesis recommended

steps proposed by Cruzes and Dybå (2011). Thematic

synthesis is a method for identifying, analyzing, and

CloudProviderTransparency-AViewfromCloudCustomers

reporting patterns (themes) within data. It comprises

the identification of the main, recurrent or most

important (based on the specific question being

answered or the theoretical position of the reviewer)

issues or themes arising from a body of evidence. The

level of sophistication achieved by this method can

vary; ranging from simple description of all the

themes identified, through to analyses of how the

different themes relate to one another in a conceptual

map. Five steps were performed in this research:

initial reading of data/text (extraction), identification

of specific segments of text, labeling of segments of

text (coding), translation of codes into themes,

creation of the model and assessment of the

trustworthiness of the model.

4 RESULTS

For the question "What is the most important

information you think should be provided to the cloud

customer in this scenario?" the participants talked

mostly about nine themes (Figure 2):

1. clear statements of what is possible to do

with the data,

2. conformance to data agreements,

3. how the provider handles data,

4. location,

5. who else other than the provider is

participant of the value chain,

6. multi-tenant situations,

7. what the provider does with the data,

8. procedures to leave the service

9. assurance that the user still owns the right to

the data.

One respondent commented that even though he

would like to have clear statements of what is possible

to do with the data: “100 pages document could be

written about this, but for some non-technical people

it would not help at all”. Another one said: “I would

like to have a [web] page where they could tell me

about security mechanisms, for example, firewalls,

backup etc.”

On the conformance to data agreements, the

respondents agree that having Data Agreements

helps, but it is mainly for technicians, not for non-

technical people. On how the provider handles data,

the respondents said that they would like to have

functional, technical and security related information

about how the providers handle the data. On location,

the respondents are concerned about where the data is

physically stored, and the legal jurisdiction of the

services. Another important piece of information is

about sub-providers, if there are any; where they are

located and whether they meet legal requirements of

the customer's location. Multi-tenant situations are a

concern of the customers, and they would like to have

this information transparent. Also, information on

how the providers ensure that data from one customer

will not be accessed by another customer.

It is also important for transparency to know what

the provider does to protect customers’ data. One

respondent said that he would like to have

information on: “How to protect the information or

how the information is protected; not much in detail

for the end-user, but only for enterprises.” It was also

highlighted that they would like to have the

procedures to leave the service and on how to move

data from one service to another transparent. Besides,

they would like to have the assurance that they still

own the rights to their data.

On the question "What would increase your trust

that the data is secure in this scenario?" the

participants mentioned eight different themes: 1)

upfront transparency; 2) community discussions, 3)

customer awareness; 4) way out; 5) reputation; 6)

encryption; 7) data processor agreements; and 8)

location.

Some answers were overlapping towards the

answers from the first question: upfront transparency,

location and conformance to data processor

agreement. Interesting answers for this question were

related to community discussions, customer

awareness and reputation. The respondents said that

it increases their trust in a cloud provider if they know

that the provider has an active security research team,

or participates in security communities. The

respondents also said that for security: “Customers

should be proactive and make sure that all the

documentation is there”. And another one commented

on the importance of having webpages telling what

customers could do to keep the data safe. Two

participants also mentioned “Way out”, meaning that

they would like to have webpages telling them what

to do to remove the data from the service provider.

On the questions: "In which parts would you like

to be involved in making the decisions? In which

parts would you like just to be informed of the

decisions?" it was surprising that the participants

mostly answered that they would like to be informed

but not really taking part of every decision (Figure 4);

the exceptions were when the provider was moving

data to another country, other parties are introduced

in the service provider value chain, or there are

significant changes in the initial terms of contract.

One participant said: “Some customers sometimes

have some requests, but in general they do not care

about taking part in the decisions”, and another one

CLOSER2015-5thInternationalConferenceonCloudComputingandServicesScience

said: “there are some decisions that we don't need to

explicitly know about, but it has to be regulated by

some other agreement about the responsibility of each

one towards the data”. One respondent also said: “I

would like to be involved in decisions on moving my

data to another country in most situations. Unless for

example a disaster and there is the need to move to

another country.” Some respondents said that they

would like to be informed when the data is transferred

from one actor to the next, one of them added: “For

example if calling to the call center your data will be

transferred to another country then the customers has

Figure 2: Important Upfront Information for Transparent Services.

What is the most important

information you think should

be provided to the cloud

customer in this scenario?

Clear statements

of what is possible

to do with the data

The providers should have some kind of standard certification level of description or standard language that they

have to make the situation easier to the buyer to evaluate which security level do we need, what is required from

us and what is the provider offering.

I would like to have a page that they could tell me about security mechanisms, for example, firewalls, backup etc

That I can choose what is possible to do with my data

100 pages document could be written about this but for some non-technical people it would not help.

Conformance to

Data Agreements

Data Agreement helps. How data is handled, how it is stored, the procedures. And having this documentation

available it helps. But mainly for technicians not for non technical people

For example, your data is encrypted in transferred and stored. In a safe harbor, And

also behave adhered to the norwegian data act or norwegian protection framework

Legal contracts sometimes are too big and overkilling. Something in between too high level information and the big contracts.

Show that follows the data handling agreement to the type of data that is in question.

How the Provider

handles data

What the provider does with the data. Of course, problems are the same as with old HOST

systems. You don't really know what the software provider does with your data.

Functional, technical and security wise information about how they handle the data.

If sensitive information is stored on the cloud, they should provide very good

information of how the data is stored and who has access to it.

How the providers will handle data. What is the responsibilities of the parts involved in the agreement

How do the providers manage their systems

All the security aspects of the data are important to be evidenced, before they get a contract with the provider

How many employees have access to the data.

Location

Geographically where my data is stored

Which country it is stored? We are very concerned that it is outside of Norway.

Location. Geographical and Legal location

Locations of the providers

It is important to know where it is located. It might be ok if its in Norway or

not, but it depends on the data the consumers will put on the cloud.

Who else other than the

provider is participant of

the value chain

Which provider is actually stored at.

Information about sub providers if there are. Where they are

located and whether they meet legal requirements of Norway.

What does the whole data

privacy stack looks like.

but providers are quite reluctant to comply to this.

Can other parties get access to your data? For example call centers?

That are located in another country for cost saving purposes?

Who are the participants of the cloud side. Which parties are involved. Are

there others involved? Is this a sole company providing the service?

I would like to know how the service is set up. Who is involved

with who. And that people can see how things are set up.

Multi Tenant Situations

If they are combining my data with other data about me in their servers.

How the customers are separated from each other, in case of multi-tenant services

How the providers assure that data from one customer will not be accessed by another customer.

How they protect the data privacy part.

What the provider

does to protect my

data

How to protect the information or how the information is protected not much in detail for the end-user, but only for enterprises.

That there are mechanisms that secure data not only for data loss but also for data privacy vulnerabilities.

A document that cover some kind of standard level of mechanisms for preventing intrusion.

The default should be maximum security as default and the user decides if they change to

another level of security. But it can also be that the enterprise decides which level they want to do.

The agreement go to the level of saying for example, we need two data centers.

I take for granted that secure rooms, security systems and backup are in place. but of course I would like to hear about it

Encryption

What are the procedures to leave the service?

How do I move data from one service to another?

It is needed good standardization of APIs.

5OL

What is the exit strategy? How can we be out of the service if we want?

Assurance that you still owns the

right to your data

Do you retain full rights to your data or you lose some of them?

What they can do with the data

Who actually have control of your data and what they can do with it?

Things that you can regulate in contract. Ensuring that the provider

can't sell your data, that the consumer has the rights to the data

Others

CloudProviderTransparency-AViewfromCloudCustomers

Figure 3: Transparency on Correction of Data Security Problems.

Figure 4: Involvement on making Decisions.

to be involved in the decision about that. So he can

take an informed decision.” On changes in the initial

terms of Contract, one respondent said: "the providers

should be very aware of what they changed since the

contract with the customer [was signed], and inform

them about the changes that happen. Never leave the

customer in the dark.”

When asked on what they would want to know

about how the provider corrects data security

problems, it was again surprising to learn that the

participants have not thought much on what they

could expect from the providers if some security issue

happens. Most of the respondents needed further

elaboration of the question before they would start

saying something. Then, the participants stated that

they would like to know what is planned before

something happens; when something happens they

want to know how the providers are handling the

situation, why the problem happened, and when will

the services be back online. Interesting was also the

fact that the participants wanted to know how the

providers are improving their services after

something happens, based on lessons learned. These

responses are collated in the taxonomy shown in

Figure 3.

5 DISCUSSION

After analyzing all the collected information we

compiled a list of requirements elicited in the

interviews, as shown in Table 2. The main “topics”

What do you want to

know about how the

provider corrects data

security problems?

Before Something Happens, what is planned

When Something Happens

what happened

why did it happened

what are the procedures that

they are taking to correct .

when will services be

back working normally.

After Something Happened,what are the lessons learned

In which parts would you like to be

involved in making the decisions?

In which parts would you like just to

be informed of the decisions?

Informed YES, taking part of decisions NO

Taking part of Decisions

Moving data to

another country

I would like to be involved in decisions on moving my data to

another country in most situations. Unless for example a disaster

and there is the need to move to another country.

I would like to be part of the decision if the service provider

move the location of the data, for example Ireland or US.

Country is important to know. The level of

trust is different from country to country.

Other Parties

will be involved

I want to be updated when other parties are

involved than the ones I have the contract with.

If they move the data, so someone else will handle the data on

behalf of them. For example, changes of sub providers.

Informed when

the data is trans-

ferred from one

actor to the next

For example if calling to the call centre your

data will be transferred to another country then

the consumer has to be involved in the decision

about that. So he can take an informed decision.

Is there any change in the value chain.

The service provider is merging with another company.

Changes in the

initial terms of

Contract

There should not be any changes on the initial information

that they gave to the customer at the contract time. And if

changes happen, the customer should be informed.

The providers should be very aware of what they changed since

the contract with the customer. And inform them about the

changes that happens. Never leave the customer in the dark.

Anything that changes the initial agreement that you

have with the provider

Anything that is outside of the initial agreement should be informed.

CLOSER2015-5thInternationalConferenceonCloudComputingandServicesScience

Table 2: List of Requirements from Transparency interviews.

List of Elicited Requirements

What is possible to

do with the data

The provider should show clear statements of what is possible to do with the data

The provider should allow the cloud customer to choose what is possible to do with

his/data data

The provider should have a page that they could tell the cloud customer about security

mechanisms, e.g., firewalls, backup etc.

The provider should have some kind of standard certification level of description or

standard language that they have to make the situation easier to the buyer to evaluate

which security level do we need, what is required from us and what is the provider

offering.

The provider should have a document explaining what are the procedures to leave the

service and take the data out of their servers.

The provider should have a document in which they describe the ownership of the data.

Conformance to

Data Agreement

The provider should make available the technical documentation on how data is handled,

how it is stored, and the procedures.

There should be documentation of procedures in different levels of abstraction, for

example for technical staff or for cloud subjects

The provider should show that they follow the data handling agreement to the type of

data that is in question.

The provider should provide geographical information of where the data is stored.

Data Handling

The provider should provide functional, technical and security wise information about

how they handle the data.

The provider should provide very good information of how the data is stored and who

has access to it.

Value chain

In case of using services from other parties, the provider should inform cloud customers

on what are the responsibilities of the parts involved in the agreement.

In case of using services from other parties, the provider should inform about the

existence of sub providers, where they are located and whether they meet legal

requirements of the country of the cloud customer.

Multi-Tenant

Services

The provider should inform the cloud customers on cases of multi-tenant services.

In case of multi-tenant services, the provider should inform how the customers are

separated from each other.

In case of multi-tenant services, the provider should inform how they assure that data

from one customer will not be accessed by another customer.

Protection of the

data

The provider should inform the cloud customer on how to protect the information or how

the information is protected not much in detail for the end-user, but only for enterprises.

The provider should have a document describing the mechanisms that secure data not

only for data loss but also for data privacy vulnerabilities.

Decisions

The cloud providers should get the consent of the cloud customer before moving the data

to another country, in cases where new parties will be involved in the value chain and

on changes on the initial terms of contract.

Correction of the

data

The cloud provider should have a document stating what are the procedures and

mechanisms planned for cases of security breaches on customers' data.

In case of security breaches, the cloud provider should inform the cloud customers on

what happened, why did it happen, what are the procedures they are taking to correct

the problem and when will services be normalized.

CloudProviderTransparency-AViewfromCloudCustomers

mentioned by the respondents were related to what is

possible to do with the data, conformance to data

agreements, data handling, value chain, multi-tenant

situations, protection of the data, decisions and

corrections of the data.

Pauley (2010) designed a scorecard reproduced in

Table 1 to cover the assessment areas frequently

raised in the research, and to begin to establish high-

level criteria for assessing provider transparency.

When comparing our list of elicited requirements to

Pauley’s scorecard (Table 2), we can see some slight

differences in the criteria that Pauley described as

information that should be provided by the cloud

providers and the information that the customers are

looking for (Table 2). In the criteria about the

business factors, the customers did not mention being

concerned about the number of years in business, nor

about membership of CSA, CloudAudit, OCCI, or

other cloud standards groups, or if the providers are

profitable or public. There is a possibility that the

respondents did not mention these criteria because (a)

companies in Norway are usually stable, and (b)

membership of a group or association does not in

itself guarantee good performance or compliance,

even if the group or association promotes a certain

standard.

On the security and privacy aspects, the customers

mentioned all the criteria, but they did not mention

directly the standards/certifying bodies, such as

ISO/IEC 27000, COBIT and NIST, but they

mentioned that it would be nice to know if the

provider was certified somehow, based on some

criteria. The customers also did not mention the need

to know about “external” audits. One of the reasons

for not mentioning security standards and

certification bodies may be that companies that we

have investigated are predominantly private

companies in Norway, where there are not strong

requirements from the certification bodies yet.

One important aspect not very much explored in

Pauley’s scorecard is that customers would like

providers to be transparent about what is possible to

do with the data. In addition, customers were quite

concerned about transparency on exit procedures

(“way out”) and ownership of the data. The concern

over data ownership is interesting seen in the light of

Hon et al. (2012), who found no evidence of cloud

contracts leading to loss of Intellectual Property

Rights.

Another aspect further mentioned by the

customers is on the decisions made on “ongoing”

services, where the customers would like that: “The

cloud providers should get the consent of the cloud

customer before moving the data to another country,

in cases where new parties will be involved in the

value chain and on changes on the initial terms of

contract.”

Physical location and legal jurisdiction, as well as

specific information on the value chain was a very

important aspect to be transparent about for the cloud

customers, and it was not explicitly mentioned in

Pauley’s scorecard.

The interviewees did not show a desire for the

kind of detailed information Durkee (2010) deems

necessary (the inner workings of their cloud

architecture as part of developing a closer relationship

with the customer), and as also pointed out by

Durkee, some respondents were also aware that the

costs of such clarity may be prohibitive, and we might

add that this level of disclosure seems highly unlikely

for ordinary customers of commodity cloud services.

Many of the transparency mechanisms that

customers expressed a desire for are actually being

developed by the A4Cloud project (Jaatun et al.,

2014). For end-users, the Data Track tool (Fischer-

Hübner et al., 2014) enhances transparency by

tracking which personal data has been released to

whom. Furthermore, a central theme of A4Cloud is

the development of the Accountability PrimeLife

Policy Language (A-PPL), which allows end users to

specify a privacy policy that also covers

accountability requirements, including transparency

(Azraoui et al., 2014). A4Cloud is developing an A-

PPL Engine which will serve as a Policy Decision

Point for the associated policies at each cloud

provider. Other tools developed by A4Cloud include

the Cloud Offerings Advisory Tool (COAT), which

allow cloud customers to select an appropriate cloud

provider based on relevant accountability

requirements, including transparency (Alnemr et al.,

2014). This will eventually allow transparency

requirements to be built into standard cloud service

level agreements (SLAs), where transparency is just

one of several security attributes (Jaatun et al., 2012).

6 CONCLUSIONS

Cloud computing has been receiving a great deal of

attention, not only in the academic field, but also

amongst the users and providers of IT services,

regulators and government agencies. The results from

our study focus on an important aspect of

accountability of the cloud services to customers:

transparency.

The customers made explicit all the information

that they would like the providers to be transparent

about. Much of this information can be easily

CLOSER2015-5thInternationalConferenceonCloudComputingandServicesScience

provided at a provider's website. Our contention is

that being transparent can be a business advantage,

and that cloud customers who are concerned with,

e.g., privacy of the data they put into the cloud, will

choose providers who can demonstrate transparency

over providers who cannot.

Our study increases the body of knowledge on the

criteria needed for more accountable and transparent

cloud services, and confirms the results from previous

studies on these criteria. The list of requirements in

Table 2 complements, in part, the existing criteria.

An area for future research is to further evaluate

how cloud providers currently make the information

required by cloud customers available. In addition,

what are the effects of having transparent services in

terms of costs and benefits to cloud customers and

providers. Besides, we plan to increase the number of

participants responding to our interview guide and

adding strength to the evidence provided in this paper.

Another aspect we would like to investigate, is if the

results will be different for users of the different types

of services (e.g., SaaS vs IaaS).

ACKNOWLEDGEMENTS

This paper is based on joint research in the EU FP7

A4CLOUD project, grant agreement no: 317550.

REFERENCES

AbuKhousa, E., Mohamed, N., and Al-Jaroodi, J., “e-health

cloud: Opportunities and challenges,” Future Internet,

vol. 4, no. 3, pp. 621–645, 2012.

Ahuja, S. P., Mani, S. and Zambrano, J., “A Survey of the

State of Cloud Computing in Healthcare,” Network and

Communication Technologies, vol. 1, no. 2, p. 12,

2012.

Alnemr, R., Pearson, S., Leenes, R., and Mhungu, R.,

“COAT: Cloud Offerings Advisory Tool”. Proc. of the

2014 IEEE International Conference on Cloud

Computing Technology and Science (CloudCom 2014)

95-100, 2014.

Azraoui, M., Elkhiyaoui, K., Önen, M., Bernsmed, K.,

Sendor, J., and Santana de Oliveira, A., “A-PPL: An

accountability policy language”, in DPM, 9th

International Workshop on Data Privacy Management,

10 September 2014.

Bernsmed, K., Tountopoulos, V., Brigden, P., Rübsamen,

T., Felici, M., Wainwright, N., Santana De Oliveira, A.,

Sendor, J., Sellami, M., and Royer, J.-C., “Consolidated

use case report”, A4Cloud Deliverable D23.2, October

2014 http://www.a4cloud.eu/sites/default/files/D23.2%

20Consolidated%20use%20case%20report.pdf.

Cruzes, D. S. and Dybå, T., Recommended Steps for

Thematic Synthesis in Software Engineering. ESEM

2011: 275-284, 2011.

Durkee, D., Why cloud computing will never be free.

Commun. ACM 53(5): 62-69 , 2010.

Felici, M., Koulouris, T. and Pearson, S., “Accountability

for Data Governance in Cloud Ecosystems”, Proc. of

the 2013 IEEE International Conference on Cloud

Computing Technology and Science (CloudCom

2013), 2013.

Fischer-Hübner, S., Angulo, J., and Pulls, T., “How can

Cloud Users be Supported in Deciding on, Tracking and

Controlling How their Data are Used?”, Privacy and

Identity Management for Emerging Services and

Technologies, IFIP Advances in Information and

Communication Technology Vol. 421, 2014, pp 77-92.

Gavrilov, G. and Trajkovik V., “Security and privacy issues

and requirements for healthcare cloud computing,” in

Proceedings of ICT Innovations, 2012.

Hon, W.K., Millard, C. and Walden, I., “Negotiating Cloud

Contracts - Looking at Clouds from Both Sides Now”

(May 9, 2012). 16 STAN. TECH. L. REV. 81 (2012);

Queen Mary School of Law Legal Studies Research

Paper No. 117/2012.

Jaatun, M.G., Bernsmed, K., and Undheim, A.: "Security

SLAs – an idea whose time has come?", Proc. CD-

ARES, Prague, LNCS Volume 7465, pp 123-130, 2012.

Jaatun, M.G., Pearson, S., Gittler, F., and Leenes, R.,

“Towards Strong Accountability for Cloud Service

Providers”, Proc. of the 2014 IEEE International

Conference on Cloud Computing Technology and

Science (CloudCom 2014), 2014.

Khorshed, M. T., Ali, A.S. and Wasimi, S.A.: A survey on

gaps, threat remediation challenges and some thoughts

for proactive attack detection in cloud computing.

Future Gener. Comput. Syst. 28(6), 833–851 (2012).

Kuo, A. M.-H., “Opportunities and challenges of cloud

computing to improve health care services,” J. Med.

Internet Res., vol. 13, no. 3, p. e67, 2011.

Onwubiko, C., (2010) "Security Issues to Cloud

Computing", in Cloud Computing: Principles, Systems

& Applications, (Eds) Nick Antonopoulos and Lee

Gillam, Springer-Verlag, August, 2010.

Paquette S., Jaegar, P. T. and Wilson, S. C. Identifying the

security risks associated with governmental use of

cloud computing, Journal of Government Information

Quarterly 27, pages 245-253, April, 2010.

Pauley, W.A., “Cloud Provider Transparency: An

Empirical Evaluation,” IEEE Security & Privacy (8)6,

pp. 32– 39, 2010.

Rodrigues, J. J., Torre, I. de la, Fernandez, G., and Lopez-

Coronado, M., “Analysis of the security and privacy

requirements of cloud-based electronic health records

systems,” J. Med. Internet Res., vol. 15, no. 8, p. e186,

2013.

Yang, H. and Tate, M., "A Descriptive Literature Review

and Classification of Cloud Computing Research,"

Communications of the Association for Information

Systems: Vol. 31, Article 2, 2012.

CloudProviderTransparency-AViewfromCloudCustomers
