Automating Resources Discovery for Multiple Data Stores Cloud

Applications

Rami Sellami, Michel Vedrine, Sami Bhiri and Bruno Defude

Computer Science Departement, Institut Mines-Telecom,

Telecom SudParis, CNRS UMR Samovar, Evry, France

Keywords:

NoSQL Data Stores, Relational Data Stores, Polyglot Persistence, Manifest based Discovery, ODBAPI.

Abstract:

The production of huge amount of data and the emergence of cloud computing have introduced new require-

ments for data management. Many applications need to interact with several heterogeneous data stores de-

pending on the type of data they have to manage: traditional data types, documents, graph data from social

networks, simple key-value data, etc. Interacting with heterogeneous data models via different APIs, multi-

data store applications imposes challenging tasks to their developers. Indeed, programmers have to be familiar

with different APIs. In addition, developers need to master and deal with the complex processes of cloud

discovery, and application deployment and execution. Moreover, the execution of join queries over hetero-

geneous data models cannot, currently, be achieved in a declarative way as it is used to be with mono-data

store application, and therefore requires extra implementation effort. In this paper we propose a declarative

approach enabling to lighten the burden of the tedious and non-standard tasks of discovering relevant cloud

environment and deploying applications on them while letting developers to simply focus on specifying their

storage and computing requirements. A prototype of the proposed solution has been developed and is currently

used to implement use cases from the OpenPaaS project.

1 INTRODUCTION

Cloud computing has recently emerged as a new com-

puting paradigm enabling on-demand and scalable

provision of resources, platforms and software as ser-

vices. Cloud computing is often presented at three

levels (Baun and et al., 2011): the Infrastructure as

a Service (IaaS) giving access to abstracted view on

the hardware, the Platform-as-a-Service (PaaS) pro-

vides to the developers programming and execution

environments, and the Software as a Service (SaaS)

enables end users to run cloud software applications.

Due to its elasticity property cloud computing pro-

vides interesting execution environments for several

emerging applications such as big data management.

According to the National Institute of Standards and

Technology

(NIST), big data is data which exceed

the capacity or capability of current or conventional

methods and systems. It is based on the 3-Vs model

where the three Vs refer to volume, velocity and vari-

ety properties (McAfee and Brynjolfsson, 2012). Vol-

ume means the process of large amounts of informa-

tion. Velocity signiﬁes the increasing rate at which

http://www.nist.gov/

data ﬂows. Finally, variety refers to the diversity of

data sources. Against this background, the challenges

of big data management result from the expansion of

the 3Vs properties. In our work we focus mainly on

the variety property and more precisely on multi-data

store applications in the cloud.

In order to satisfy different storage requirements,

cloud applications usually need to access and inter-

act with different relational and NoSQL data stores

having heterogeneous APIs. The heterogeneity of the

data stores induces several problems when develop-

ing, deploying and migrating multi-data store appli-

cations. Below, we list the main 4 problems which

we are tackling in this paper.

. Heavy workload on the application developer:

Nowadays data stores have different and het-

erogeneous APIs. Developers of multi-data

store applications need to be familiar with all

these APIs when coding their applications.

. No declarative way for executing join queries:

Due to the heterogeneity of the data models,

there is currently no declarative way to deﬁne

and execute complex queries over several data

stores. That means developers have to cope

397

Sellami R., Vedrine M., Bhiri S. and Defude B..

Automating Resources Discovery for Multiple Data Stores Cloud Applications.

DOI: 10.5220/0005446103970405

In Proceedings of the 5th International Conference on Cloud Computing and Services Science (CLOSER-2015), pages 397-405

ISBN: 978-989-758-104-5

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

themselves with the implementation of such

complex queries.

. Code adaptation: When migrating applications

from one cloud environment to another, ap-

plication developers have to re-adapt the ap-

plication source code in order to interact with

new data stores. Developers have potentially to

learn and master new APIs.

. Tedious and non-standard processes of discov-

ery and deployment: Once an application is

developed or migrated, developers have to de-

ploy it into a cloud provider. Discovering the

most suitable cloud environment providing the

required data stores and deploying the applica-

tion on it is a tedious and meticulous provider-

speciﬁc process.

In our work, we are are coping with these prob-

lems in order to support the developer during a mul-

tiple data stores based application life cycle. In a

previous work, we proposed ODBAPI (OPEN-PaaS-

DataBase API) a streamlined and a uniﬁed REST-

based API (Sellami et al., 2014) for executing CRUD

operations on relational and NoSQL data stores. The

highlights of ODBAPI are twofold: (i) decoupling

cloud applications from data stores in order to facil-

itate the migration process, and (ii) easing the de-

velopers task by lightening the burden of managing

different APIs. In contrast, we present in this pa-

per a declarative approach for discovering appropri-

ate cloud environments and deploying applications

on them while letting developers to simply focus on

specifying their storage and computing requirements.

A prototype of the proposed solution has been de-

veloped and is currently used to implement use cases

from the OpenPaaS project.

The remainder of the paper is organized as fol-

lows. In section 2, we introduce the context and

present a motivating example. In section 3, we give an

overview of our approach and we detail in sections 4

the discovery step. In section 5, we present the imple-

mentation and validation of our solution. In Section

6, we discuss the related work. Section 7 concludes

our paper and outlines directions of future work.

2 MOTIVATION

Our work is done in the context of the OpenPaaS

project

aiming at developing a PaaS technology

dedicated to enterprise collaborative applications de-

This work has been partly funded by the French FSN

OpenPaaS grant (https://research.linagora.com/display/

openpaas/Open+PAAS+Overview)

ployed on hybrid clouds (private/public). It is a plat-

form that allows to design and deploy applications

based on proven technologies provided by partners

such as collaborative messaging system, integration

and workﬂow technologies that will be extended in

order to address Cloud Computing requirements. Tar-

get applications of OpenPaaS are applications that use

multiple data stores that corresponds to what is pop-

ularly referred to as the polyglot persistence. For in-

stance, an application can interact with three hetero-

geneous data stores at the same time: a relational data

store, a document data store that is CouchDB, and a

key value data store which is Riak. But, this exam-

ple exposes some limits. Linking an application with

multiple data stores is very complex due to the differ-

ent APIs, data models, query languages and consis-

tency models. If the application needs to query data

coming from different data sources (e.g joining data,

aggregating data, etc.), it can not do it declaratively

unless some kinds of mediation have been done be-

fore. Finally, the different data stores may use differ-

ent transaction and consistency models (for example

classical ACID and eventual consistency). It is not

easy for developers to understand these models and to

maintain its properties while coding their application.

Moreover, it is more complicated when it comes to

execute complex queries and especially join queries.

But ﬁrst, the developer has to discover all data stores

capabilities of the available cloud providers in order

to elect the most suitable cloud provider to his ap-

plication requirements to deploy it. However this in

itself is a tedious and meticulous work. In this paper,

we will tackle these problems and we will propose an

end-to-end solution and we will focus on the step of

the cloud data stores discovery.

3 OVERVIEW OF OUR

APPROACH

The lion’s share of the contribution of our work is

dedicated to application developers. Indeed, we at-

tempt to simplify the developer task during the life

cycle of an application (i.e. development, discovery

and deployment, and execution) using multiple and

heterogeneous data stores in its source code. The de-

veloper has (i) to write the source code of his applica-

tion using various APIs, (ii) to discover data stores of

each cloud provider in order (iii) to deploy his appli-

cation, and (iv) to execute queries.

Hence, for the purpose of simplifying the devel-

opers task and getting them rid of all their onerous

responsibilities, we propose our solution that is based

on three points: (i) using a unique API enabling the

CLOSER2015-5thInternationalConferenceonCloudComputingandServicesScience

398

coding and the execution of multiple data store based

application, (ii) enabling join queries execution over

heterogeneous data stores, and (iii) ensuring a neutral

application deployment in a cloud provider that is al-

ready automatically discovered.

In Fig 1, we showcase an overview of our solution

including the different steps of the application life cy-

cle. Indeed, we depict the following four steps:

• Development Step: The ﬁrst step is the appli-

cation development. For this purpose, we pro-

pose to use a unique API enabling the interac-

tion with relational and NoSQL data stores. In

a previous work (Sellami et al., 2014), we deﬁned

a generic resources model deﬁning the different

concept used in each type of data store. These

resources are managed by ODBAPI a stream-

lined and a uniﬁed REST API enabling to execute

CRUD operations on different NoSQL and rela-

tional databases. ODBAPI decouples cloud appli-

cations from data stores alleviating therefore their

migration. Moreover it relieves developers task by

removing the burden of managing different APIs.

• Discovery Step: The second step consists in dis-

covering data stores capabilities of each cloud

provider. So, we can decide which cloud provider

can support our application requirements. Doing

so, the developer describe his requirements in the

Abstract application manifest and sends it to the

discovery module. The discovery module inter-

acts with the cloud providers in order to discover

the capabilities of each cloud provider in term of

data store services. Then, it obtains as a result

the offer manifest. Based on these two manifests,

the Matching module elects the most appropriate

cloud provider to the application in order to de-

ploy it and edit its deployment manifest.

• Deployment Step: The third step represents the

application deployment. An important part in

this phase consists in generating the application

executable and adding the execution manifest to

it. This manifest contains the endpoint of the

ODBAPI server or/and the data stores endpoints

that the application requires. We propose to de-

ploy an application by any deployment API (e.g.

COAPS API(Sellami and et al., 2013), roboconf

API

, etc.). In our work, we are building on the

COAPS API that is proposed in our team and al-

lows human and/or software agents to provision

and manage PaaS applications. This API provides

a unique layer to interact with any cloud provider

based on manifests. We model the deployment

Roboconf home page: http://roboconf.net/fr/ in-

dex.html

manifest based on the manifest of COAPS API

and we enrich it with information about data

stores to support ODBAPI-based application.

• Execution Step: The fourth step is the application

execution. In this step, an application can exe-

cute two types of queries. On the one hand, it can

execute CRUD queries; hence it interacts directly

with the target data store based on its execution

manifest. In this case, it uses a unique API like

ODBAPI. On the other hand, it can execute join

queries by interacting with virtual data stores. A

virtual data store is created automatically for exe-

cuting join queries. When a virtual data store re-

ceives a join query, it parses this query, rewrites

it into sub-queries written in the ODBAPI syn-

tax, and sends these sub-queries to the target data

stores. Once a virtual data store receives the result

of each sub-query, it forms the ﬁnal result and re-

turns it to the application. It is worth noting that

when the user edits the Abstract application mani-

fest, he has to precise that his application will ma-

nipulate complex queries. Hence, a virtual data

store will be created and its endpoint will be added

to the execution manifest also.

In the following section, we will focus only on the

discovery of the data stores capabilities and the de-

ployment of an ODBAPI-based application.

4 DISCOVERY OF DATA STORES

OF CLOUD PROVIDERS

In this section, we present our logic to discover the

capabilities of data stores of cloud providers meeting

the application requirements (see Figure2). The de-

veloper coded an ODBAPI application and describes

its requirements in the abstract application manifest

in term of data stores and deployment. Then, he gives

it as an input to the matching algorithm. This algo-

rithms interacts with the data stores directory in or-

der to obtain the data stores capabilities of each cloud

provider stored in the offer manifest. This manifest

represents the second input of this algorithm in order

to obtain the deployment manifest. The data stores

directory is automatically updated by interacting with

the cloud providers using their APIs.

In the rest of this section, we introduce UML

diagram classes illustrating the Abstract application

manifest and offer manifest description. In addition,

we introduce our matching algorithm.

AutomatingResourcesDiscoveryforMultipleDataStoresCloudApplications

399

Figure 1: Overview of our solution.

Figure 2: Zoom-in on the discovery module.

4.1 Abstract Application Manifest

This manifest contains two categories of require-

ments. First, we have requirements in term of data

stores. The developer provides ﬁve information about

the required data stores: its type, its name, its version,

it size and the query type to execute. It is worth not-

ing that when the developer ﬁlls this manifest, he has

the freedom to specify one or multiple information.

For each information, he gives a constraint expressed

by a constant value, a joker (denoting any values) or

some conditions (expressed as inequalities). Hence,

we will ensure more ﬂexibility in our model. For in-

stance, one developer precises that he wants a data

store having name MongoDB and type document and

another developer precises that he wants a data store

of type document without specifying its name (in this

case any data store of type document fulﬁll the speci-

ﬁcation). Whereas the second category of the require-

ments is dedicated to the application deployment. In-

deed, the developer precises the number of the virtual

machines that he needs to run his application. In ad-

dition, he describes the executable of his application

by giving its name, its type and its location.

We depict in Figure 3 an UML class diagram il-

lustrating the Abstract application manifest model.

The root class of our model is the Abstract applica-

tion manifest class and it is identiﬁed by the attribute

name. This class contains these following classes:

• The User Information Class: This class represents

the required authentication information required

to access the discovery module and consult the

data stores repository. This class contains the user

sents the developer identiﬁers.

• The environment class: This class represents the

environment where an application will be de-

ployed and it is instantiated from an environment

template element that is characterized by a name

attribute and a memory value. Each environment

template contains at least one node class that rep-

resents resources in a cloud provider. A node class

is identiﬁed by an id and a content type attributes.

This latter can be a container or a database to de-

note respectively engine resources to host and run

services and storage resources. This class con-

tains a name class and a version class. When

the content type attribute is equal to database, the

node class contains also a type class, query type

class, and a size class to denote the type of data

storage services, the query type (CRUD queries

or join queries) and its size.

• The application class: This class represents the

constraints that the user requires to deploy his ap-

plication. It is characterized by a unique name at-

tribute and the environment attribute where the ap-

plication will be deployed. It has at least one ver-

sion class that is identiﬁed by a name and a label.

Each version class contains two types of classes:

deployable class and instance class. The deploy-

able class represents the application executable

ﬁle. It is identiﬁed by a unique id attribute, a

content type attribute deﬁning the executable ﬁle

type, a name attribute denoting its name, a loca-

tion attribute containing their URL, and a multi-

tenancy level attribute indicating the application

tenancy degree. Whereas the instance class rep-

resents the running application instances required

by the user. This class is identiﬁed by a unique

id attribute, a name attribute, initial state attribute

CLOSER2015-5thInternationalConferenceonCloudComputingandServicesScience

400

Figure 3: Abstract application manifest model.

deﬁning the state of the application (e.g. running,

stopped, etc) and default instance attribute repre-

senting the running instances by default.

4.2 Offer Manifest

The offer manifest contains information about the

capabilities of data stores of each discovered cloud

provider. In Figure 4, we present a offer manifest

modeling based on a class diagram. Indeed, the

root class is offer manifest and it is identiﬁed by the

name attribute. It contains one or multiple cloud

provider class. This class represents a discovered

cloud provider and it is identiﬁed by a unique id at-

tribute. It contains the name class deﬁning the cloud

provider name and the environment response class

representing the capabilities that a cloud provider ex-

poses according to an abstract application manifest.

The environment response class is composed by one

or multiple offer class that contains one or multiple

node class. This class is similar to the node element

in the abstract application manifest modeling.

Figure 4: Offer manifest model.

4.3 Deployment Manifest

The deployment manifest’s structure is closest to the

abstract application manifest and it is deﬁned based

on the COAPS API’s manifest (Sellami and et al.,

2013) (see Figure 5). Hence, in order to avoid the

repetition, we do not describe this manifest structure

in details. However, we will present we extend the

COAPS API manifest structure. In fact, we add new

attributes about data stores services in the paas node

class. These attributes are the size attribute, the type

attribute and the version attribute.

Figure 5: Deployment manifest model.

4.4 Matching Algorithm

In algorithm 1, we introduce the matching algorithm

that elects the cloud provider that supports the best

the application requirements in terms of data stores.

We need a ﬂexible matching allowing to elect a cloud

provider which does not fulﬁll all the application’s re-

quirements but it is closed to them (that is the role of

the computed distance). Furthermore, we impose that

the result is a single cloud provider. First, the algo-

rithm constructs the offer manifest using the operation

queryDataStoresRepository by interacting with the

data stores repository (line 4). We introduce this op-

eration in Algorithm2. Second, it calculates for each

cloud provider the number of differences between its

capabilities and the user requirements described in the

abstract application manifest (lines 6-18). Numbers

of differences are stored in the data structure distance.

These values are calculated as follows: for each prop-

erty in the two manifest, if they are not corresponding

then we update the distance by adding the appropri-

ate penalty to the property. The two properties corre-

spond if the actual value of the offer manifest property

fulﬁll the requirement expressed by the abstract appli-

cation manifest property (which is either a constant, a

joker or a condition). These penalties are customized

according to the property importance. By default, all

penalties are ﬁxed at 1; however the user can conﬁg-

ure these penalties according to the importance that he

gives to the properties. Once this step is achieved, we

can now elect a cloud provider and construct the de-

ployment manifest (lines 19-20). This is done through

the operation electCP that takes as inputs the the data

structure distance and the threshold and returns the

identiﬁer of the elected cloud provider if any. This

identiﬁer is the smallest value bounded between 0 and

the threshold.

In algorithm 2, we present in more details the

operation queryDataStoresRepository that returns a

super-set of the result from the data stores repository.

In fact, for each cloud provider it extracts all data

stores corresponding to the data types of the abstract

application manifest. If there are no corresponding

data stores, the cloud provider is rejected (lines 10-

AutomatingResourcesDiscoveryforMultipleDataStoresCloudApplications

401

Algorithm 1: Matching algorithm.

1: input AAM: the abstract application manifest

2: input threshold: the threshold to limit the number of differences

3: output DM: the deployment manifest

4: OM ←queryDataStoresRepository(AAM) # see Algorithm 2#

5: i ← 0

6: while (exist(Cloud Provider CP in OM)) do

7: while (exist(Offer O in OM)) do

8: distance[i] ← 0

9: for each node N in AAM do

10: for each property prop in N do

11: if (!valid(prop, OM.CP.O.node. prop)) then

12: distance[i] ← distance[i]+ updateDistance(prop,

OM.CP.O.node. prop)

13: end if

14: end for

15: end for

16: i ← i + 1

17: end while

18: end while

19: electedCP ←electCP(distance, threshold)

20: return createDM(AAM, OM, electedCP)

Algorithm 2: The queryDataStoresRepository algorithm.

1: input AAM: the abstract application manifest

2: output OM: the offer manifest

3: length ← 0

4: for each node N in AAM do

5: if (content-type == ”database”) then

6: T [length] ← getType(N)

7: length ← length + 1

8: end if

9: end for

10: for each Cloud Provider CP in the data stores directory do

11: for i=0 to length do

12: if (CP contains T[i]) then

13: Add all names of this type to the tree of the current CP

14: else

15: Reject the current CP

16: end if

17: end for

18: end for

19: return the resulted trees as the OM

18). For ease of presentation of this algorithm, we

build ourselves on the Figure 6. Indeed, in the left side

of the ﬁgure, we construct from the abstract applica-

tion manifest a simple graph in which nodes represent

the type elements in the node elements. This graph

is a kind of a sample that will be used to construct

the offer manifest. In the right side of Figure, we il-

lustrate a data stores repository of a cloud provider

having four types of data stores. Based on this repos-

itory and the graph based sample, we extract the list

of the cloud provider’s offers that we represent in the

form of a graph. Once we check all cloud providers,

we collect all the offers in the offer manifest (line 19).

Figure 6: Generating the offer manifest.

5 IMPLEMENTATION AND

VALIDATION

In this section, we present the tool implementing

the matching module. Hence, in order to show the

feasibility of this module, we propose to discover

data stores of cloud foundry and open shift as cloud

providers to deploy an ODBAPI-based application.

This application is intended to handle the admin-

istration of relational and NoSQL data stores in a

cloud provider. To do so, we propose to implement

the manifests modeling with XML. We give in this

section the example of the abstract application mani-

fest (see Listing 1). Indeed, the developer provides

user1 as a login and pswd as a password. Then, he

describes the environment that he requires in order

to deploy his ODBAPI based application. Indeed, he

chooses as name for the environment ODBAPIEnv

and for the environment template ODBAPIEnvTemp.

In this template, the user wants tomcat as an ap-

plication container, a document data store without

precising any name by ﬁlling the element name

with the character ∗ and MySQL as a relational data

stores. Regarding the application conﬁguration, the

user names his application ODBAPIApplication. He

precises that the application is a runnable ﬁle and he

requires to have two application instances: one is

running by default and the other is stopped. In this

section we present only the XML based represen-

tation of the abstract application manifest for lack

of space. We wish to emphasize that we provide

our tools and videos demonstration at http://www-

inf.int-evry.fr/∼sellam r/Tools/ODBAPI/index.html

for more details.

1 < a b s t r a c t a p p l i c a t i o n m a n i f e s t name=”AAM”>

2

3 u s e r 1

4 pswd

5 <q u e r y t y p e>com ple x</ q u e r y t y p e>

6

7 <e n vi r o n me n t name = ”ODBAPIEnv”>

8 <t e m p l a t e name=”ODBAPIEnvTemp” memory=” 128 ”>

CLOSER2015-5thInternationalConferenceonCloudComputingandServicesScience

402

9 <node i d =” 1 ” c o n t e n t t y p e =” c o n t a i n e r ”>

10 <name> t o m cat </ name>

11 <v e r s i o n> </ v e r s i o n>

12 </ nod e>

13 <node i d =” 2 ” c o n t e n t t y p e = ” da t a b a s e ”>

14 <name>∗</ name>

15 <v e r s i o n> 1 . 0 </ v e r s i o n>

16 <t y p e> do cum e nt </ t y p e>

17 <s i z e> l a r g e </ s i z e>

18 </ nod e>

19 <node i d =” 3 ” c o n t e n t t y p e = ” da t a b a s e ”>

20 <name> mysq l </ name>

21 <v e r s i o n> ∗ </ v e r s i o n>

22 <t y p e> r e l a t i o n a l </ t y p e>

23 <s i z e> s m a l l </ s i z e>

24 </ nod e>

25 </ t e m p l a t e>

26 </ e nv i r o n m e n t>

27 <a p p l i c a t i o n name=” OD BAP I App lic a tio n ” e nv i r on e m en t =

28 ”ODBAPIEnv”>

29 <v e r s i o n name= ” v e r s i o n 1 . 0 ” l a b e l = ” 1. 0 ”>

30 <d e p l o y a b l e i d = ” 1 ” c o n t e n t t y p e =” a r t i f a c t ”

31 name= ” O DBA PIA p pli c ati o n . war ” l o c a t i o n =” 1444 d7 ”

32 m u l t i t e n a n c y l e v e l =” S h a r e d I n s t a n c e ” />

33 <i n s t a n c e id = ” 1 ” name=” I n s t a n c e 1 ”

34 i n i t i a l s t a t e =” 1 ” d e f a u l t i n s t a n c e =” t r u e ” />

35 <i n s t a n c e id = ” 2 ” name=” I n s t a n c e 2 ”

36 i n i t i a l s t a t e =” 1 ” d e f a u l t i n s t a n c e =” f a l s e ” />

37 </ v e r s i o n>

38 </ a p p l i c a t i o n>

39 </ a b s t r a c t a p p l i c a t i o n m a n i f e s t>

Listing 1: XML based representation of the abstract ap-

plication manifest.

We programmed also a tool ensuring the discov-

ery of cloud providers and the automatic deployment

of an ODBAPI-based application. Indeed, the ap-

plication programmer describes his requirements in

the abstract application manifest and he uploads it

through the interface that we illustrate in Fig. 7. Once

this manifest is uploaded, this tool executes the mani-

fest based matching algorithm to elect the appropriate

cloud provider that supports the ODBAPI client re-

quirements and returns the user the deployment man-

ifest. Based on the deployment manifest, we deploy

the ODBAPI client by the mean of COAPS API.

Figure 7: Screenshot of the interface allowing to select the

user manifest in order to get the deployment manifest.

In our work, we deploy an ODBAPI-based client

intended to handle the administration of relational and

NoSQL data stores in a cloud provider. In Fig. 8,

we show an overview of the databases created in

each data store in the Cloud Foundry. Indeed, there

is a MySQL database called world and it contains

Figure 8: Screenshot of all databases overview.

three entity sets: city, country, and countrylanguage.

Added to that, we have the MongoDB database that is

named person and it is composed by two entity sets:

Student and Teacher. We show also an overview of

the entities of the city entity set.

6 RELATED WORK

In our previous work (Sellami and Defude, 2013),

we focused on existing solutions of the state-of-the-

art supporting multiple data stores based applications

in the cloud environment. More precisely, (i) we de-

scribed different scenarios related to the way applica-

tions use data stores, (ii) we deﬁned the data require-

ments of applications in cloud environment, and (iii)

we analyzed and classiﬁed existing works on cloud

data management, focusing on multiple data stores

requirements. As a result, we pointed out six require-

ments of using multiple data stores in a cloud environ-

ment. One of these requirements consists in choos-

ing a data store based on a data requirements. We

present three sub-requirements: deﬁning application

needs and requirements towards data, deﬁning data

store capabilities, and deﬁning application needs and

data stores capabilities matching.

Against this background, we ﬁnd several worksq

(Truong and et al., 2012),(Truong and et al.,

2011),(Vu and et al., 2012), (Ghosh and Ghosh,

2012), (Ruiz-Alvarez and Humphrey, 2011), (Ruiz-

Alvarez and Humphrey, 2012) enabling an appli-

cation to negotiate its Data Management Contract

(DMC), often referred to as data agreement or data li-

cense, with various clouds and to bind to the speciﬁc

DBMSs according to its DMC. Truong et al. (Truong

and et al., 2012), (Truong and et al., 2011), (Vu and

et al., 2012) propose to model and specify data con-

cerns in data contracts to support concern-aware data

selection and utilization. For this purpose, they de-

ﬁne an abstract model to specify a data contract and

the main data contract terms. Moreover, they propose

some algorithms and techniques in order to enforce

the data contract usage. In fact, they present a data

AutomatingResourcesDiscoveryforMultipleDataStoresCloudApplications

403

contracts compatibility evaluation algorithm and they

deﬁne how to construct, compose and exchange a data

contract. In (Truong and et al., 2011), they intro-

duce their model for exchanging data agreements in

the Data-as-a-Service (DaaS) based on a new type of

services which is called Data Agreement Exchange as

a Service (DAES). This model is called DEscription

MOdel for DaaS (DEMODS) (Vu and et al., 2012).

However, Truong et al. propose this data contract for

data and not to store data or to help the developer to

choose the appropriate data stores for his application.

In (Ghosh and Ghosh, 2012), Ghosh et al. identify

non-trivial parameters of the Service Level Agree-

ment (SLA) for Storage-as-a-Service cloud which are

not offered by the present day cloud vendors. More-

over, they propose a novel SLA monitoring frame-

work to facilitate compliance checking of Service

Level Objectives by a trusted third part. Although

Ghosh et al. try to enrich the SLA parameters to

support the Storage-as-a-Service, this is still inade-

quate for our purpose in this paper. In (Ruiz-Alvarez

and Humphrey, 2011), (Ruiz-Alvarez and Humphrey,

2012), Ruiz-Alvarez et al. propose an automated ap-

proach to selecting the PaaS storage service according

an application requirements. For this purpose, they

deﬁne a XML schema based on a machine readable

description of the capabilities of each storage system.

The goal of this XML schema is twofold: (i) express-

ing the storage needs of consumers using high-level

concepts, and (ii) enabling the matching between con-

sumers requirements and data storage systems offer-

ings. Nevertheless, they consider in their work that an

application may interact with only one data store and

they did not invoke the polyglot persistence aspect.

7 CONCLUSIONS AND FUTURE

WORK

In this paper, we proposed a manifest-based solution

for data stores discovery and automatic application

deployment. Indeed, once the developer has com-

pleted the development of his application, we pro-

vided him the possibility to express his application

requirements in terms of data stores in the abstract

application manifest. Then, he sends it to the dis-

covery module. This module interacts with the data

stores directory to discover the capabilities of data

stores of each cloud provider and constructs the of-

fer manifest. Based on that, this module implements

the matching algorithm in order to elect the adequate

cloud provider to the application requirements. This

algorithm takes as input the abstract application man-

ifest and offer manifest, and returns the deployment

manifest of the application. Once it is done, we de-

ploy the application using the COAPS API that takes

as input the deployment manifest.

Currently, we are working on applying our solu-

tion to other qualitatively and quantitatively various

scenarios in the OpenPaaS project. This allows us

to identify possible discrepancies and make our work

more reliable for real use. Our second perspective is

to implement virtual data stores in order to execute

join queries across NoSQL and relational data stores

and to introduce more elaborate query processing op-

timization techniques.

REFERENCES

Baun, C. and et al. (2011). Cloud Computing - Web-Based

Dynamic IT Services. Springer.

Ghosh, N. and Ghosh, S. K. (2012). An approach to

identify and monitor sla parameters for storage-as-

a-service cloud delivery model. In Workshops Pro-

ceedings of the Global Communications Conference,

GLOBECOM 2012, 3-7 December, Anaheim, Califor-

nia, USA, pages 724–729.

McAfee, A. and Brynjolfsson, E. (2012). Big data: The

management revolution. (cover story). Harvard Busi-

ness Review, 90(10):60–68.

Ruiz-Alvarez, A. and Humphrey, M. (2011). An automated

approach to cloud storage service selection. In Pro-

ceedings of the 2Nd International Workshop on Scien-

tiﬁc Cloud Computing, ScienceCloud ’11, pages 39–

48.

Ruiz-Alvarez, A. and Humphrey, M. (2012). A model and

decision procedure for data storage in cloud comput-

ing. In 12th IEEE/ACM International Symposium on

Cluster, Cloud and Grid Computing, CCGrid 2012,

Ottawa, Canada, May 13-16, pages 572–579.

Sellami, M. and et al. (2013). Paas-independent provision-

ing and management of applications in the cloud. In

2013 IEEE Sixth International Conference on Cloud

Computing, Santa Clara, CA, USA, June 28 - July 3,

2013, pages 693–700.

Sellami, R., Bhiri, S., and Defude, B. (2014). ODBAPI:

a uniﬁed REST API for relational and NoSQL data

stores. In The IEEE 3rd International Congress on Big

Data (BigData’14), Anchorage, Alaska, USA, June 27

- July 2, 2014.

Sellami, R. and Defude, B. (2013). Using multiple data

stores in the cloud: Challenges and solutions. In Data

Management in Cloud, Grid and P2P Systems - 6th

International Conference, Globe 2013, Prague, Czech

Republic, August 28-29, 2013. Proceedings, pages

87–98.

Truong, H. L. and et al. (2011). Exchanging data agree-

ments in the daas model. In 2011 IEEE Asia-Paciﬁc

Services Computing Conference, APSCC 2011, Jeju,

Korea (South), December 12-15, pages 153–160.

CLOSER2015-5thInternationalConferenceonCloudComputingandServicesScience

404

Truong, H. L. and et al. (2012). Data contracts for cloud-

based data marketplaces. IJCSE, 7(4):280–295.

Vu, Q. H. and et al. (2012). Demods: A description model

for data-as-a-service. In IEEE 26th International Con-

ference on Advanced Information Networking and Ap-

plications, AINA, 2012 , Fukuoka, Japan, March 26-

29, pages 605–612.

AutomatingResourcesDiscoveryforMultipleDataStoresCloudApplications

405
