Cloud Spreadsheets Supporting Data Processing

in the Encrypted Domain

D. A. Rodríguez-Silva

, L. Adkinson-Orellana

, B. Pedrero-López

and F. J. González-Castaño

Gradiant, Edif. CITEXVI, Campus de Vigo, 36310, Pontevedra, Spain

AtlantTIC, Escuela de Ingeniería de Telecomunicación, Universidade de Vigo, 36310, Pontevedra, Spain

Keywords: Cloud Computing, Security, Privacy, Homomorphic Encryption, Spreadsheet.

Abstract: Security has become one of the main barriers for the adoption of cloud services. A range of legal initiatives

that require support mechanisms such as access control and data encryption have been proposed to ensure

privacy for data moved to the cloud. Although these mechanisms are currently feasible in situations in

which the cloud acts as a mere data storage system, they are insufficient in more complex scenarios

requiring processing in external cloud servers. Several new schemes have been proposed to overcome these

shortcomings. Data Processing in the Encrypted Domain (DPED) permits arithmetic operations over

ciphered data and the generation of encrypted results, without exposure of clear data. In such a set-up, the

servers have no access to the information at any point of the process. In this paper we describe, as a case

study of secure cloud data processing, a cloud spreadsheet that relies on DPED libraries to perform

operations in the encrypted domain. Tests performed on local servers and in the Google cloud through the

Google App Engine platform show that representative real applications can benefit from this technology.

Because the proposed solution is PaaS-oriented, developers can apply the libraries to other applications.

1 INTRODUCTION

Security and privacy are both major concerns for

Cloud Computing users. As reported in the

European CIOs and Cloud Services research study

(2010), around 71% of European companies are

worried about security and privacy, especially when

it comes to storing or processing sensitive data in the

cloud. Security has thus become a significant barrier

to full adoption of cloud services.

Concerns regarding security and privacy have

been addressed in part by different legal initiatives

within the European Union, such as Directive

95/46/EC of the European Parliament and the

Council of October 24 1995 (Data Protection

Directive, 1995), which proposes a set of

recommendations for protecting personal data during

transfer and processing. In Spain there are several

specific laws to protect and regulate the management

of personal and corporate data used by cloud

applications, including the Data Protection

Regulation, of Law 15/1999 on Personal Data

Protection (LOPD, 1999) and the Royal Decree

1720/2007, which approves the development of the

LOPD (RDLOPD, 2007). As an example of the

recommended proposals, the 85

article of the

RDLOPD states that security measures applied to

personal data in communication networks, public or

not, should guarantee at least the same security level

as that offered by local access systems.

Due to their very nature, data processed in the

cloud will presumably be affected by international

data transfers, primarily because many web

applications are hosted on foreign servers.

International data movement is regulated by the data

protection regulation, which forbids international

data transfers between countries that do not offer

sufficient security guarantees according to the

LOPD, although there are some exceptions explicitly

indicated in the reference regulation. In addition, this

regulation sets out several legal requirements, such

as transfer notification to the Spanish Data

Protection Agency.

Because legal procedures are slow, new

technological mechanisms are required until the

situation is completely regulated. Authentication on

the client side and use of security mechanisms such

as data encryption during data transmission are good

solutions for interception attacks and servers that do

not offer sufficient guarantees of reliability. To

increase security, the client can cipher data using a

514

Rodríguez-Silva D., Adkinson-Orellana L., Pedrero-López B. and González-Castaño F..

Cloud Spreadsheets Supporting Data Processing in the Encrypted Domain.

DOI: 10.5220/0005451505140520

In Proceedings of the 5th International Conference on Cloud Computing and Services Science (CLOSER-2015), pages 514-520

ISBN: 978-989-758-104-5

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

private key, thereby hiding the information from the

server. Although this option is valid when the cloud

acts as a mere storage service, there are cases in

which it would be insufficient, for example when

performing certain calculations on the server or

when processing a query to a database with ciphered

data.

To overcome the above shortcomings, new

server-side schemes have been proposed, such as the

use of cryptographic hardware or Data Processing in

the Encrypted Domain (DPED). Cryptographic

hardware can be used to perform cryptographic

operations and to store keys securely, but it is

expensive (specific trusted anti-tampering devices

are required) and it needs to be physically integrated

into the provider’s infrastructure. DPED overcomes

these problems, but at the expense of increased

processing time. It enables operations over ciphered

data that generate encrypted results, thereby

allowing server-side operations without revealing

the original information. This adds an additional

security level to the cloud paradigm by means of

complex homomorphic algorithms. The

computational requirements may not be a problem

thanks to the scalability and flexibility of the cloud

paradigm.

In this paper we describe a cloud spreadsheet

application that uses the DPED concept to perform

operations in the encrypted domain. We have tested

it on our local servers and in the Google cloud

through the Google App Engine (GAE) platform.

Section 2 discusses related work and section 3

explains the implementation details of our

application. Section 4 presents the tests performed,

and finally, section 5 concludes the paper.

2 RELATED WORK

Many office cloud applications allow users to work

with spreadsheets. Some well-known examples are

Microsoft Office 365, Google Drive Spreadsheets,

Thinkfree Calc and Zoho Sheet. Nevertheless, none

of these applications currently offers full protection

mechanisms for user data, meaning that privacy,

when available, is supported by external means.

Indeed, most current solutions are designed for

Google Drive, not for spreadsheets. Furthermore,

although there are solutions that are completely

integrated with the Google Drive interface that

encrypt documents transparently to users (Adkinson-

Orellana et al., 2010), most simply use the cloud to

store the encrypted documents (CryptRoll, 2013;

ZecurePC, 2011; and CloudLock, 2015).

DPED allows certain operations to be performed

over ciphered data without the need to access the

clear version. In particular, arithmetic operations can

be performed efficiently in the encrypted domain

thanks to the concept of additive and multiplicative

privacy homomorphisms (Brickell and Yacobi,

1987). In 2009, Gentry presented the first fully

homomorphic encryption scheme. He described

public key encryption using ideal lattices (Gentry,

2009). In the same year, M. Van Dijk described a

“somewhat homomorphic” encryption scheme based

on elementary modular arithmetic, and used

Gentry’s techniques to convert it to a full

homomorphic scheme (M. Van Dijk et al., 2009)

that implemented addition and multiplication over

integers rather than ideal lattices over a polynomial

ring.

There have been other contributions in this

direction. A. F. Chan formulated a privacy

homomorphism for operating over ciphered data

with two different encryption schemes, where data

could be processed directly in an encrypted form

(Chan, 2009). H. Hacigümüş, in turn, described

different techniques for executing SQL queries over

encrypted data (Hacigümüş et al., 2002). The

strategy involves processing as much of the query as

possible at the service provider site, without

decrypting data. Decryption and the remainder of the

query processing takes place at the client side. They

also explored an algebraic framework to split the

query to minimize computation at the client side.

The innovative idea in this paper is to enable

DPED processing in cloud applications. We are not

aware of any previous DPED-enabled complex

cloud applications, although, in a previous work, we

presented a toy example that demonstrated that

DPED could strengthen the privacy of simple

mathematical operations in the cloud (Rodriguez-

Silva et al., 2011).

3 SECURE CLOUD

SPREADSHEET

3.1 Arithmetic Calculations in the

Encrypted Domain

The spreadsheet application is composed of two

modules: a client module and a server module. The

client module presents the spreadsheet interface,

which is used to enter data, cipher its content, send it

to the server, and decipher and present the results in

the corresponding spreadsheet cell. The server

CloudSpreadsheetsSupportingDataProcessingintheEncryptedDomain

515

module, in turn, executes arithmetic operations on

the encrypted data received from the client by means

of adequate privacy homomorphisms. The supported

encrypted operations are listed in Table 1.

Due to the low efficiency of complete

homomorphisms in the current state-of-the-art, our

implementation uses a variation of the additive

homomorphic encryption described by Paillier

(Paillier, 1999) as the basis of our cryptographic

system. One or more additional rounds of

communication between the client and the server

will also be needed depending on the complexity of

the operation requested.

Table 1: Encrypted operations supported by the

spreadsheet.

Operation Description Example

AVERAGE Average value AVERAGE (A1:A5)

DEGREES Degree conversion DEGREES (A1:A5)

FFT Fast Fourier Transform FFT (A1:A5)

PROD Product PROD (A1:A5)

RADIANS Radian conversion RADIANS (A1:A5)

SPROD Scalar product SPROD(A1:A5;B1:B5)

STDEV Standard deviation STDEV (A1:A5)

SUM Addition SUM (A1:A5)

VADD Vector addition VADD (A1:A5;B1:B5)

VAR Variance VAR (A1:A5)

VPROD Vector product VPROD(A1:A5;B1:B5)

VSUB Vector substraction VSUB (A1:A5;B1:B5)

The encryption methods used are based on

asymmetric key algorithms. The libraries present

different options, such as threads and JNI (Java

Native Interface), thereby increasing efficiency

thanks to the use of C libraries. The encryption

libraries also allow operations with scalars and

vectors, unlike the version in our previous work,

which only offered basic operations for unary

values.

3.2 Ciphered Cloud Spreadsheet

Implementation

The spreadsheet allows operations over a range of

cells, with no limitations in terms of the number of

operators involved. The implementation relies on

Java technology, as this is the most common PaaS

language. It uses the Java Runtime Environment

(JRE) classes available to create applets and tables

(JTable, TableModel, etc.), meaning that results can

be easily embedded on a web page. The

development environment used to create the

spreadsheet and the associated technologies are the

same as those used for the encrypted calculator

(Rodriguez-Silva et al., 2011): Java Servlets and

IDE Eclipse 3.5 (Galileo) for the server and Java

applets and Oracle IDE Netbeans 6.8 for the client,

with the corresponding plugin to create graphical

user interfaces. Again, GAE was selected as the

cloud platform to deploy the application. Due to the

restrictions of this PaaS, the encryption libraries had

to be adapted, since the platform has a limited

support for multithreading (a characteristic that the

libraries use to improve efficiency).

By default, some of the applet functionalities

(e.g. reading or writing files on disk) are restricted

through a security policy implemented by the

security controller of the browser Java Virtual

Figure 1: Ciphered cloud spreadsheet interface.

CLOSER2015-5thInternationalConferenceonCloudComputingandServicesScience

516

Machine (JVM) plugin. However, the spreadsheet

applet needs these functionalities to store its content

in a local file and to obtain and save the user keys to

cipher data. For this reason, the user must accept the

applet signature, granting certain restricted

functionalities. All the libraries except

au.com.bytecode.opencsv

(required to save the

content of the spreadsheet in .CSV format) and the

DPED libraries are available on the JRE used by the

browsers. Other libraries are downloaded when the

applet starts.

The client is composed of two modules: one for

the graphic interface and the other for parsing and

communicating with the server. The graphic module

is in charge of the visual interface, intercepting user

events and presenting results. Its design was based

on typical spreadsheet software, such as Google

Spreadsheet, OpenOffice.org and Microsoft Excel

(Figure 1). The client parser analyses formulae

expressions to obtain the data required to perform

the operations. Finally, the communication module

exchanges data with the server using HTTP

tunnelling.

Figure 2: Client module flowchart according to user

interaction.

To perform a spreadsheet operation, the first step

is to start the application (applet) and load the

libraries. The user then introduces his/her login and

password, using his/her Google user account if the

application is deployed in GAE. If access is granted,

the user keys —required to cipher and decipher the

data and perform encrypted operations— are loaded

from binary files. When the process is complete, the

spreadsheet graphic interface is shown. At this point,

the application is ready to process events generated

by user interaction (see Figure 2):

 Finish cell edition. The application checks the

type of data entered in the cell, such as

formulae, a number or other data types. The

formulae are analysed, the type of operation

and the references to the cells are extracted,

and in the case of numbers, these are ciphered.

With this information a new communication

object is created to be sent to the server. In the

case of other data types, the cell content is

directly inserted in the communication object.

Once this object has been created, a new

communication thread is thrown to send the

object to the server. In other words, the

interface thread is released to receive new user

events. The communication thread remains

open until confirmation is received that the

number or object has been correctly received

at the server side or until the operation defined

by the formula has finished. This is indicated

by the communication round. The result is

then decrypted and displayed to the client.

 Save on server. The client creates an object

with the order to save the spreadsheet at the

server side. A new thread is created

specifically to send the petition containing this

object. This thread will receive a response

indicating the success or failure of the request.

 Select a menu option. The selected option is

performed at the client or the server side,

depending on the actions involved, e.g.,

create/load user keys, add/remove rows or

columns, copy/paste cells, etc.

Dependencies between the values of the cells

must be taken into account. When the value of a cell

changes, it can affect other related cells, resulting in

the execution of multiple parallel operations. To

manage this situation, a new thread is thrown for

each dependent operation, creating a new client.

This ensures that the different operations executed

do not interfere with each other, but it requires more

processing load for the application during the

initialization of a new module.

We considered two possible server deployment

scenarios: a private cloud (local) and a public cloud

(GAE). The private cloud does not have all the

resources and services offered by GAE, such as user

accounts and persistent storage. In this case users are

authenticated through a local mechanism and

persistent storage is simulated by saving the

spreadsheet in a local file, identified by the user

CloudSpreadsheetsSupportingDataProcessingintheEncryptedDomain

517

application, the saved spreadsheet will be retrieved

and deciphered if and only if he/she has the

appropriate private key.

The server is a servlet composed of two

modules: the communication module and the data

processing module. The communication module

performs the same actions as on the client side,

while the data processing module is in charge of

storing or processing the data received in the

encrypted domain and recovering the stored

spreadsheet.

On the server side, the first step is to initialize

the servlet, which will keep listening to incoming

petitions from the clients. When a request is

received, the thread recovers the object and retrieves

the data it contains. The selected action is then

executed, i.e. the data received is saved, the cell

value is deleted, the module is initialized, the

encrypted operation is performed, etc.

The client and server modules must store the

status of each operation requested, indicating the

current execution round. If several operations are

requested at once, several modules for the client and

the server will be instantiated, and those associated

with the same operation will be identified by a

unique identifier. Thus, each time an operation is

requested, it will be possible to execute it in the

corresponding module, avoiding result

inconsistencies when several rounds are being

carried out.

Communication between the client and the

server takes place through a Java object, which is

used to retrieve and store information. This object is

sent through HTTP tunnelling, facilitating data

transmission through different elements (firewalls,

proxies, etc.) that typically limit connection to web

resources. In addition, the object is used to send and

receive different types of data, such as encrypted

data to be stored by the server, information related to

the operation performed and the cells involved,

encrypted results received from the server, etc.

The application also supports the generation of

the keys required to cipher and decipher data. These

keys offer two levels of security: short-term and

medium-term. While short-term security speeds up

encryption and decryption, medium-term security is

stronger, as it would take approximately ten times

longer to break up its keys (e.g., ten years vs 1 year).

4 PERFORMANCE TEST

The test layout comprised a client computer (Intel

Core i3-2120 @ 3.3 GHz, 3870 MB RAM, Ubuntu

10.4) and a local server (with the same

characteristics) to perform the encrypted operations

under Jetty 7.5.4. The cloud application applet was

executed through the Google Chrome 17 browser.

We also used GAE servers equipped with Jetty to

deploy the applications.

The operation selected to evaluate the

performance of the spreadsheet was a Fast Fourier

Transform (FFT), as this is a complex operation that

permits representative performance results. The FFT

was applied to vectors with lengths of 64, 128 and

512 points.

The current version of the spreadsheet encrypts

and sends each data item to the server individually.

When an operation (the FFT in this case) is selected

at the client side, the server simply receives the

operation and the cells involved, since it has already

the ciphered values. Therefore, the total time needed

to perform an operation comprises two times: a data

entry time, including the management of the data in

the cells in the spreadsheet and the time needed to

encrypt and send each operand to the server, and a

running time, which is the time needed to perform

an encrypted operation on the server and present the

result on the client side.

We used four test scenarios:

 Local, with threads and JNI. The encrypted

FFT was executed on the local server. There

were five parallel threads in the server and the

client. JNI was used to improve efficiency.

 Local, without threads or JNI. As in the

previous case, the operation was executed on

the local server. Neither threads for parallel

executions nor C functions were used in this

scenario.

 Local, clear FFT. We executed the FFT using

clear data on the local server. The FFT

algorithm was implemented by a Java

function.

 Remote, deployed on a GAE server. GAE does

not allow the use of threads or JNI, so the

server was subject to these restrictions. At the

client side five threads were used, in addition

to C functions through JNI.

The client was executed on the same machine

and used the same browser in all four scenarios.

In each scenario, 10 FFT operations were

performed for randomly generated vectors for the

three lengths. We used both the short- and medium-

term security levels to perform these tests. Tables 2

and 3 show the corresponding results based on the

following times:

 Entry time (ET). Time from the moment an

CLOSER2015-5thInternationalConferenceonCloudComputingandServicesScience

518

operand is entered in the spreadsheet to the

moment the client receives the response from

the server (indicating that the encrypted data

have been correctly stored).

 Server execution time (SE). Time taken by the

server to perform the encrypted FFT

operation.

 Running time (RT). The sum of

communication time required to exchange

data between the client and the server, the

time needed by the server to perform an

ciphered FFT (SE) and the time needed to

decrypt the result for the client.

Each pair of values represents the average

execution time ( ) and its standard deviation (σ),

both in milliseconds.

The tests were unfeasible for the 512-point FFT

in the remote scenario because the time needed to

generate and return a response in GAE is limited to

30-60 seconds and the 512-point FFT needs longer.

These results are therefore not shown in the tables.

The use of longer keys improves security

considerably, but increases effective operating time.

On comparing Table 2 and Table 3, we can see that

the time required to perform the same operation is

considerably higher for the medium-term security

level. This mainly affects ciphered operation time

(i.e., server execution time). The different level of

security does not have an impact on data entry time,

as this includes the ciphering of data but not the

execution of the encrypted operations.

The use of threads and JNI considerably reduced

the execution time in both cases, primarily due to the

improved efficiency of the execution of the

algorithm on the server and the improved efficiency

of the decoding process. Although this test scenario

cannot be translated to GAE, its results can give us

an idea of how the performance could be improved

with JNI and threads in GAE or other compatible

PaaS.

The running time with GAE was much higher

than in the equivalent local case without threads or

JNI. Besides of the Internet delay, GAE servers took

approximately 10 times longer to execute the same

algorithm, probably because GAE is optimized for

applications with short response times, typically of

hundreds of milliseconds.

The total execution time for the best DPED

scenario (local, threads and JNI) was much longer

than with unencrypted data (local, clear FFT). This

is obviously due to the time spent on encrypting data

and decrypting the result, and the efficiency of the

DPED FFT algorithm, which is over 200 times

slower than the algorithm used to calculate the FFT

with unencrypted data.

Table 2: Data entry time, server execution time and

running time using the short-term security level (ms).

Test scenario 64 128 512

Local, no

threads or

JNI

=524.2

σ=23.5

=897.9

σ =43.3

=6888.4

σ =114.4

=581.4

σ=152.7

=1177.9

σ =137.8

=6013.7

σ =120.1

=1206.6

σ=140.4

=2256.7

σ =135.1

=9918.4

σ =131.5

Local,

threads and

JNI

=565.1

σ =21.9

=936.1

σ =21.3

=8642.9

σ =127.6

=76.9

σ=9.4

=140.9

σ =31.7

=545.8

σ =62.5

=239.1

σ =18.3

=356.3

σ =41.4

=1108.8

σ =103.6

Remote

(GAE)

=16539.3

σ =538.9

=34056.3

σ =1355.2

---

=5595.2

σ=294.3

=13793.8

σ =858.8

---

=6339.3

σ =365.7

=14688.0

σ =881.2

---

Local, clear

FFT

=475.6

σ =23.9

=790.3

σ =41.3

=6250.7

σ =118.3

=0.159

σ=0.086

=0.516

σ =0.307

=1.318

σ =0.422

=6,5

σ =1.5

=6.9

σ =2.5

=10.4

σ =2.0

Table 3: Data entry time, server execution time and

running time using medium-term security level (ms).

Test scenario 64 128 512

Local, no

threads or

JNI

=1132.3

σ=35.1

=1916.8

σ=36.9

=8308.8

σ=192.5

=2382.4

σ=500.8

=4538.1

σ=623.2

=20909.2

σ=742.1

=6127.7

σ=550.3

=11129.8

σ=567.9

=46873.3

σ=1314.3

Local,

threads

and JNI

=589.9

σ=53.6

=995.1

σ=38.3

=6983.7

σ=137.4

=173.6

σ=23.2

=337.0

σ=35.7

=1558.2

σ=287.5

=597.4

σ=46.6

=1031.6

σ=35.1

=4062.7

σ=491.0

Remote

(GAE)

=16733.6

σ=1113.3

=34709.2

σ=2410.8

---

=22045.1

σ=915.4

=52640.6

σ=1033.4

---

=23007.0

σ=926.6

=54172.3

σ=1111.0

---

Local, clear

FFT

=475.6

σ =23.9

=790.3

σ =41.3

=6250.7

σ =118.3

=0.159

σ=0.086

=0.516

σ =0.307

=1.318

σ =0.422

=6,5

σ =1.5

=6.9

σ =2.5

=10.4

σ =2.0

CloudSpreadsheetsSupportingDataProcessingintheEncryptedDomain

519

5 CONCLUSIONS

Cloud computing provides an adequate environment

for deploying applications following a Software-as-

a-Service (SaaS) model. However, security and

privacy are key concerns when sensitive data

managed by applications is moved to cloud

infrastructures for processing or storage.

In this paper we have proposed, as a case study

of a real-life secure cloud application, a spreadsheet

capable of performing DPED operations on cloud

servers. The application was tested on a private

cloud and on GAE, with analysis of the time

required to perform a ciphered FFT operation.

Although the test results demonstrate that

homomorphic encryption is a feasible solution for

secure data processing on cloud infrastructures, the

efficiency of current encrypted domain libraries

needs to be improved to achieve commercial status.

Nevertheless, although the times for encrypted

operations are quite long, they are satisfactory for

applications with a light processing load, such as the

proposed spreadsheet. To apply this model in a

PaaS, cloud providers should support DPED

libraries on their servers.

This solution could be applied to other real-life

applications, such as enterprise resource planning

(ERP) or e-Health SaaS, where confidentiality is

crucial.

ACKNOWLEDGEMENTS

This research was supported by the SAFECLOUD

grant (09TIC014CT), funded by Xunta de Galicia

(Spain), and partially supported by the HIGEA grant

(IPT-2012-1218-300000), funded by the Spanish

Ministry of Economy and Competitiveness, the

PRISMED grant (IPT-2011-1076-900000), funded

by the Spanish Ministry of Science and Innovation.

This research was conducted with the collaboration

of GPSC research group of the University of Vigo,

which provided the DPED libraries, and Fundación

Barrié.

REFERENCES

Adkinson-Orellana, L., Rodríguez-Silva, D. A., Gil-

Castiñeira, F., and Burguillo-Rial, J., 2010. Privacy for

Google Docs: Implementing aTransparent Encryption

Layer. In Proc. of 2nd Cloud Computing International

Conference–CloudViews 2010 (pp. 20-21).

Brickell, E. F., Yacobi, Y., 1987. On Privacy

Homomorphisms. In Advances in Cryptology–

EUROCRYPT 87 (pp. 117-125). Springer Berlin

Heidelberg.

Chan, A. F., 2009. Symmetric-key homomorphic

encryption for encrypted data processing. In

Communications, 2009. ICC'09. IEEE International

Conference on (pp. 1-5). IEEE.

CloudLock. [Online]. [Accessed 6 January 2015].

Available from: http://www.cloudlock.com/

CryptRoll.2013. [Online]. [Accessed 6 January 2015].

Available from: http://cryptroll.android.informer.com/

Data Protection Directive. [Online]. [Accessed 6 January

2015]. Available from: http://ec.europa.eu/justice/data.

protection/index_en.html.

European CIOs and Cloud Services, 2010. [Online].

[Accessed 6 January 2015]. Available from:

http://www.colt.net/cio-research.

Gentry, C., 2009.Fully Homomorphic Encryption Using

Ideal Lattices. In41st ACM Symposium on Theory of

Computing–STOC (Vol. 9, pp. 169-178).

Hacigümüş, H., Iyer, B., Li, C., and Mehrotra, S., 2002.

Executing SQL over encrypted data in the database-

service-provider model. In Proceedings of the 2002

ACM SIGMOD international conference on

Management of data (pp. 216-227). ACM.

LOPD, Ley orgánica 15/1999 de Protección de Datos de

Carácter Personal, Boletín Oficial del Estado (in

Spanish), 1999.[Online].[Accessed 6 January 2015].

Available from: https://www.boe.es/

Paillier, P. (1999). Public-key cryptosystems based on

composite degree residuosity classes. In Advances in

cryptology–EUROCRYPT’99 (pp. 223-238).Springer

Berlin Heidelberg.

RDLOPD, Real Decreto 1720/2007, Reglamento de

Desarrollo de la LOPD, BoletínOficialdel Estado (in

Spanish), 2007.[Online]. [Accessed 6 January 2015].

Availablefrom: https://www.boe.es/

Rodriguez-Silva, D. A., González-Castaño, F. J.,

Adkinson-Orellana, L., Fernández-Cordeiro, A.,

Troncoso-Pastoriza, J. R., and González-Martínez, D.,

2011. Encrypted Domain Processing for Cloud

Privacy. Concept and Practical Experience. In

Proceedings of 1st International Conference on Cloud

Computing and Services Science–CLOSER 2011.

Van Dijk, M., Gentry, C., Halevi, S., and Vaikuntanathan,

V., 2010. Fully homomorphic encryption over the

integers. In Advances in Cryptology–EUROCRYPT

2010 (pp. 24-43). Springer Berlin Heidelberg.

ZecurePC. 2011. [Online]. [Accessed 6 January 2015].

Available from: http://www.zecurex.com/.

CLOSER2015-5thInternationalConferenceonCloudComputingandServicesScience

520
