MiDAS: A Model-Driven Approach for Adaptive Software

José Bocanegra, Jaime Pavlich-Mariscal and Angela Carillo-Ramos

Departamento de Ingeniería de Sistemas, Pontiﬁcia Universidad Javeriana, Bogotá, D.C., Colombia

Keywords:

Adaptation, Design, MDE, Requirements, Transformations.

Abstract:

Some of the main problems in software engineering for adaptive software are: the lack of mechanisms to

specify adaptive characteristics in software requirements; the difﬁculty to obtain a functional adaptive system

based on the elicited requirements; and the need of maintaining synchronization and traceability between the

requirements, design and implementation. To address the above problems, this paper proposes MiDAS, a

framework that uses a model-driven approach to develop adaptive software. Speciﬁcally, MiDAS provides: (i)

a new language for requirements engineering process that takes into account uncertainty in adaptive software;

(ii) a method to derive concrete implementations in speciﬁc architectures supporting run-time adaptation; and,

(iii) a mechanism to maintain traceability and synchronization between requirements speciﬁcations, design

models and implementation architectures.

1 INTRODUCTION

An adaptive software system is a system able to

“modify itself at run-time due to changes in the sys-

tem, its requirements, or the environment in which it

is deployed” (Andersson et al., 2009). Adaptive soft-

ware plays an important role in several scenarios. One

of them is when there are frequent changes in the con-

text/goals/requirements during run-time. For exam-

ple, in a slow connection, an adaptive software may

modify its behavior at run-time and change the format

in which information is presented (from graphical to

textual) to give the user a better experience. Another

scenario is when users with different abilities inter-

act with software. For example, an Adaptive Learn-

ing Management System may adjust the contents pre-

sented to the student taking into account his/her skills,

and so, improving the educational process.

However, developing adaptive software is a task

far from trivial. Cheng et al., (2009a), identiﬁed

the main problems in software engineering for adap-

tive software. The ﬁrst issue is the lack of mecha-

nisms to specify adaptive characteristics in software

requirements. In traditional software development

process, software engineers use standard phrases or

statements, called linguistic patterns, which are habit-

ual in requirement speciﬁcations (Durán et al., 1999).

Some traditional linguistic patterns are “The system

shall do this <objective>", or “The system shall store

information about <relevant concept>”.

Linguistic patterns facilitate requirements writing

because “requirements information is structured in

a ﬁxed form, so requirements engineers know what

missing information must be searched, requirements

can easily be treated by a software tool” (Toro et al.,

1999). However, traditional linguistic patterns to

elicit requirements are not suitable to deal with un-

certainty, a key feature in adaptation (Esfahani and

Malek, 2013). According to Cheng et al., (2009a),

traditional linguistic patterns have a notion of manda-

tory behavior versus the optional behavior that could

be used to specify adaptive systems. Adaptive soft-

ware requires a new requirement vocabulary and new

linguistic patterns, such as The system might do this...,

but it may do this... as long as it does this..., or The

system ought to do this... but if it cannot, it shall even-

tually do this... (Cheng et al., 2009a).

The second issue is the difﬁculty to design and

implement a functional adaptive system based on the

elicited requirements. There are two many reasons.

First, in current approaches, the transition between a

set of functional requirements to a design is not direct,

repeatable, or constructive (Dromey, 2003). Second,

the adaptation logic is “typically speciﬁed at the code

level, tightly coupled with the main system function-

ality, making it hard to control and maintain” (Fleurey

and Solberg, 2009).

It is important to provide systematic methods to

automate the transition from requirements speciﬁca-

tions to design and to concrete implementations that

281

Bocanegra J., Pavlich-Mariscal J. and Carrillo-Ramos A..

MiDAS: A Model-Driven Approach for Adaptive Software.

DOI: 10.5220/0005486202810286

In Proceedings of the 11th International Conference on Web Information Systems and Technologies (WEBIST-2015), pages 281-286

ISBN: 978-989-758-106-9

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

support run-time adaptation (Salehie and Tahvildari,

2009). These methods should help to reduce or elim-

inate the need to code an adaptive system manually.

The third issue is the need to maintain coher-

ence between the requirements, design and imple-

mentation. Beatty and Cheng (2012), explain that a

change request in a requirements speciﬁcation may

affect other parts of a system. A change request may

affect elements such as code, business requirements,

functional requirements, systems requirements, user

requirements, external interface requirements, qual-

ity attributes, architecture, user interface, software de-

sign, and source code. For instance, if there is a

change in a business requirement, this change may af-

fect architecture, user interface, or software design.

A possible solution to these issues is traceabil-

ity. Traceability is the ability to verify the history,

location, or application of an item by means of doc-

umented recorded identiﬁcation. In software engi-

neering traceability provides a clear, bidirectional link

between requirement and design models, between

design and code, and between code and test cases

(Cleland-Huang et al., 2014).

To address all the problems mentioned above,

Model-Driven Engineering is a possible solution.

Model-Driven Engineering (MDE) (Kent, 2002) is

an approach to develop software. MDE uses mod-

els to specify different aspects of a system, from re-

quirements and domain-speciﬁc constructs, to the var-

ious aspects of design descriptions. A key element

in MDE is the use of transformation tools to auto-

matically create the code that realizes those models.

These transformation tools take as input a set of mod-

els representing domain-speciﬁc or design concepts,

and output code in a certain programming language

and platform that realizes those models.

Taking as reference the advantage of MDE, this

paper proposes MiDAS, a framework that uses a

model-driven approach to develop adaptive software.

The expected contributions of MiDAS will be the

following.

First, MiDAS will provide new languages to spec-

ify requirements and design in adaptive software.

These languages are depicted in Section 3.1 and 3.2.

Second, MiDAS will provide a mechanism to both

(i) derive a system implementation from requirements

and design speciﬁcations, and (ii) maintain traceabil-

ity and synchronization between requirements, de-

sign, and implementation models. These mechanisms

will be supported by a language that is detailed in Sec-

tion 3.3.

Third, MiDAS will provide a Case Tool that inte-

grates all of the above elements to support the entire

development process for adaptive software. This tool

is presented in Section 3.4.

Fourth, this paper presents the expected advan-

tages of use MiDAS. These advantages are presented

in Section 4.

This paper concludes with a set of conclusions and

future venues of research.

2 BASELINE AND RELATED

WORK

The requirements speciﬁcation process in adaptive

systems has not been frequently addressed (Whittle

et al., 2010). Some authors indicate that “it is a chal-

lenging task due to the inherent uncertainty associated

with an unknown environment” (Cheng et al., 2009b).

Due to this uncertainty, variability in adaptive sys-

tems is hard to identify and model (Greenwood et al.,

2011).

Although models for adaptive systems are of-

ten constructed in an ad-hoc manner, several authors

((Espada et al., 2011), (Gnaho et al., 2013)) have an-

alyzed the use of well-known languages. Ahmad et

al., (2013) have studied the differences and potential

combinations of 4 different requirements modeling

languages in adaptive systems: KAOS(Lamsweerde,

2009), SysML (OMG, 2015), SysML/KAOS (Laleau

et al., 2010), and RELAX (Whittle et al., 2010). Al-

though all the above approaches address important is-

sues of adaptive systems, they do not address trace-

ability. Moreover, these works only take into account

static aspects of the system, and shelve the dynamic

aspects. In the speciﬁc case of RELAX, this is a tex-

tual language for dealing with uncertainty in adaptive

systems. However, the language “was not integrated

with modeling approaches used in the requirements

engineering community” (Whittle et al., 2010).

Model-Driven Engineering and adaptive software

have been studied, among others, by Vogel and Giese

(2014) . Those authors propose EUREMA, a model-

driven approach to develop adaptive software. How-

ever, EUREMA is only oriented to the speciﬁcation

and execution of adaptation engines, but it does not

cover elements of requirements speciﬁcation.

The above proposals combine adaptation, require-

ments engineering, and MDE. However none of them

provide an integrated approach to address all the chal-

lenges explained in the introduction of this work. Par-

ticularly, there are no approaches that propose a com-

plete process that covers requirements, design, and

implementation of adaptive software. Table 1 pro-

vides the comparison of related work.

WEBIST2015-11thInternationalConferenceonWebInformationSystemsandTechnologies

282

Table 1: Comparison of related work.

Approaches

Criteria

KAOS SysML

SysML

RELAX EUREMA MiDAS

/KAOS

Traceability

Reqs/Design +

Design/Implem +

Static aspects

Goals + + + + +

User proﬁles + + + +

Context proﬁles + + + +

Dynamic aspects Processes + +

3 MiDAS

The analysis of the previous sections motivates the

proposal of a new approach to develop adaptive sys-

tems, called MiDAS. MiDAS is an acronym for

Model-driven approach for adaptive systems and is

expected to: (i) provide a new language for adaptive

systems; (ii) derive a functional system based on the

speciﬁed requirements; and, (iii) address traceability

and synchronization between requirements, design,

and implementation.

MiDAS comprises three key elements: (i) a Re-

quirements Speciﬁcation Language for Adaptive Sys-

tems (RSLAS); (ii) a Design Modeling Language For

Adaptive Systems (DMLAS); and (iii) a Model Trans-

formation Language for Adaptive Systems (MTLAS).

The remainder of this section explains the features

of each language.

3.1 Requirements Speciﬁcation

Language for Adaptive Systems

(RSLAS)

One of the fundamental objectives in a requirements

speciﬁcation is to clearly deﬁne the problem to be

solved.

Adaptive systems differ from traditional systems,

since they dynamically change their behavior, based

on external inputs. These inputs, called adaptation

parameters, typically include logical conditions based

on user characteristics and context (Brusilovsky,

2001). Since adaptive systems are so dependent on

these inputs, requirements tend to be speciﬁed differ-

ently than traditional systems.

The ﬁrst challenge in adaptive software is the de-

scription of the adaptation parameters in the require-

ments speciﬁcation. However, when software engi-

neers develop adaptive software, they tend to specify

adaptation parameters in the source code and not as

part of the requirements speciﬁcation (Cheng et al.,

2009a). This situation has several drawbacks:

1. The lack of formalism in modeling adaptive sys-

tems. This originates that the development of

adaptive systems are made, generally, on an ad-

hoc manner.

2. The difﬁculty of porting the application across

different architectures and platforms. This situ-

ation may increase the investment in time and re-

sources in the software development process.

3. The complexity to validate the system. This due

to that, for a user, is more complex understand a

source code that a more abstract speciﬁcation.

4. Adaptive parameters are closer to the problem do-

main that the solution domain. The source code is

part of the solution domain, thus including adapta-

tion parameters into the source code would unnec-

essarily tangle them with concerns of the solution

domain.

Therefore, it is necessary that the requirements speci-

ﬁcation take into account adaptive parameters.

RSLAS will provide a new way to include

adaptive parameters in requirements speciﬁcations.

RSLAS will use a special language pattern in which

traditional sentences as “The system shall do this...”,

are replaced by conditional sentences, such as “The

system might do this...”, “But it may do this... as long

as it does this...”, or “The system ought to do this...

but if it cannot, it shall eventually do this...” (Cheng

et al., 2009a).

RSLAS will depict the main elements in a re-

quirements speciﬁcation: goals, functional require-

ments, non-functional requirements, and storage in-

formation requirements. RSLAS also will provide a

set of reusable patterns, taking into account that in

software projects there are requirements that appear

with higher frequency than others (Kopczynska and

Nawrocki, 2014). These patterns may be depicted by

reusable templates that represent repetitive tasks, such

as CRUD operations or login processes.

Context plays an important role in adaptive soft-

ware, since it provides useful information to cus-

MiDAS:AModel-DrivenApproachforAdaptiveSoftware

283

tomize and personalize services. To enable context-

aware adaptation, context proﬁles (e.g., connection,

mobile device, location, etc.) and user proﬁles (e.g.,

personal data, interests, tastes, habits) could be speci-

ﬁed with RSLAS.

Requirements elicitation in RSLAS relies on a

structured requirements model and not on an infor-

mal document written in natural language. This is im-

portant because RSLAS is expected to facilitate trans-

lation, modeling, and relating stakeholder’s expecta-

tions to adaptation requirements. For example, if a

non-technical stakeholder needs to review and vali-

date the requirements, RSLAS may use transforma-

tions to extract information from the structured re-

quirement model and create a document in a language

that the stakeholder understands. Additionally, with a

structured model is easier to derive automatically de-

sign models.

To develop this language, RSLAS may be inspired

by current languages that manage uncertainty, such as

RELAX, complemented and integrated to approaches

that provide support to model goals such as Tropos

(Bresciani et al., 2004) or Kaos (Dardenne et al.,

1993).

3.2 Design Modeling Language for

Adaptive Systems (DMLAS)

DMLAS provides support to store information about

static and dynamic components of adaptive software.

Regarding to static elements, DMLAS store informa-

tion about user, context, and additional proﬁles, which

will be tightly related to the adaptation parameters de-

ﬁned by RSLAS.

Regarding behavior, DMLAS may use several ap-

proaches, such as Event-Condition-Action or BPMN,

among others.

DMLAS should provide several design elements

to realize the requirements speciﬁed by RSLAS.

These design elements should abstract different ap-

proaches to provide adaptation, such as if-else state-

ments, rule engines, expert systems, logic program-

ming, constraint programming, etc. With DMLAS

the designer should have the possibility to select and

combine the most convenient elements to create the

solution. DMLAS should also provide a design span-

ning several levels of abstraction (from those closer to

the problem domain to those closer to implementation

domain).

3.3 Model Transformation Language

for Adaptive Systems (MTLAS)

Another challenge in adaptive software is to main-

tain traceability and synchronization between require-

ments, design and implementation, because traceabil-

ity ensures that artifacts of subsequent phases of the

development cycle are consistent.

Although current tools for transformation such

as ATL or ETL provide mechanisms for traceabil-

ity, these tools only provide unidirectional traceabil-

ity(Macedo and Cunha, 2014).

An alternative of solution is to use bidirectional

transformations (Czarnecki et al., 2009). Bidirec-

tional transformations ensure that if some elements in

a model (e.g., in design models) are modiﬁed, other

models (e.g., requirements models) are automatically

and consistently synchronized.

The main problem with current languages for bidi-

rectional transformations (such as the Beanbag lan-

guage (Xiong et al., 2009)) it that some information

about the design may be lost, mainly because of the

mappings from models to code and vice versa are not

1:1.

To ﬁx that issue, MTLAS may provide bidirec-

tional transformations to maintain traceability and

synchronization between requirements, design, and

implementation models.

3.4 Tool Support

Traditionally, CASE tools do not support the devel-

opment process for adaptive software in a whole per-

spective: requirements speciﬁcation, design, and im-

plementation.

MiDAS will provide a CASE tool that supports

the proposed process to develop adaptive software:

requirements speciﬁcation, design, and implementa-

tion. The CASE tool will support the requirements

speciﬁcation process and the design of adaptive ap-

plications. In addition, the tool will perform semi-

automatic generation of adaptive applications from

the models, using a code generator.

This tool depends on several technologies. For

example, a visual workspace is necessary to create

the requirements models. It is important to explore

alternatives such as the Eclipse Graphical Modeling

Project, Eclipse Graphiti, or EuGENia. From these

alternatives, MiDAS may be use one or more, depend-

ing on the application context. Indeed, the deﬁnition

of criteria of use is part of the future work of this

project.

The tool should provide a workspace to customize

and execute semi-automatic transformations to create

WEBIST2015-11thInternationalConferenceonWebInformationSystemsandTechnologies

284

design models from the requirements models. These

transformations will be developed using MTLAS.

The tool also should provide support to transform

the models to an executable platform that supports

adaptation at run-time. For these transformations, the

tool should also use MTLAS.

Finally, the generated code by the case tool may be

complemented with set of predeﬁned libraries. Those

libraries will be represented abstractly in the design

model.

4 ANALYSIS OF ADAPTIVE

SOFTWARE DEVELOPMENT

WITH AND WITHOUT MiDAS

In previous work, the authors of this project have

proposed an adaptive Virtual Learning Environment

named ASHYI-EDU, which assists teachers to create

especially-tailored plans for every student, taking into

account their speciﬁc personalities, learning styles,

competences, and abilities.

The development process in ASHYI-EDU was

made in a traditional way. For example, the models

were used just as a tool to capture ideas in brainstorm-

ing sessions. When the source code was modiﬁed,

models were not updated automatically, i.e., code and

models were not synchronized. Another issue is that

many adaptive design decisions were placed directly

into the code.

ASHYI-EDU was built using a Learning Manage-

ment System (LMS), called Sakai. Because of that,

the initial conﬁguration of the development environ-

ment and the integration of adaptation concerns was

a complex task, requiring to invest a considerable

amount of time.

Last, but no least, migrating ASHYI-EDU to dif-

ferent LMS platforms, such as Moodle, would require

a high amount of time and resources, because it would

be necessary to develop the software using a different

programming language and architecture.

Using MiDAS in the development of ASHYY-

EDU models will fulﬁll an important role in the de-

velopment process. The adaptive parameters (e.g.,

personalities, learning styles, competences, and abil-

ities) will be speciﬁed directly in the models and not

in the code; and thanks to the semi-automatic code

transformations development process may be faster.

Switching between platforms can be done in less time

thanks to the abstraction provided by models. Addi-

tionally, the design decisions remain in models and

may be modiﬁed not in code but models.

5 CONCLUSIONS AND FUTURE

WORK

There are some approaches to bridge the gap between

the requirements speciﬁcation, design and implemen-

tation. However, none of them provide an effec-

tive process to generate the design from requirements,

not only for traditional systems but adaptive systems.

This position paper proposes a framework that sup-

ports the entire development process for adaptive soft-

ware, spanning from requirements speciﬁcation to de-

sign to implementation.

Ongoing work is the construction of this frame-

work, which is divided in several activities. The ﬁrst

one is to deﬁne the languages for requirements spec-

iﬁcation and design. The second activity is to cre-

ate parameterizable transformations between require-

ments, design, and implementation. The goal is to an-

alyze and deﬁne the most recurrent scenarios and pa-

rameters in adaptive systems. The third activity is the

construction of the CASE tool. Finally, it is necessary

validate the framework through several case studies to

evaluate the approach and get feedback.

ACKNOWLEDGEMENTS

This paper is part of the project “ASHYI: Plataforma

basada en agentes para la planiﬁcación dinámica, in-

teligente y adaptativa de actividades aplicada a la ed-

ucación personalizada”, executed by the ISTAR re-

search group of the Pontiﬁcia Universidad Javeriana,

coﬁnanced by Colciencias, project 1203-569-33545.

REFERENCES

Ahmad, M., Araújo, J., Belloir, N., Bruel, J.-M., Gnaho,

C., Laleau, R., and Semmak, F. (2013). Self-adaptive

systems requirements modelling: Four related ap-

proaches comparison. In Comparing Requirements

Modeling Approaches Workshop, pages 37–42. IEEE.

Andersson, J., De Lemos, R., Malek, S., and Weyns, D.

(2009). Modeling dimensions of self-adaptive soft-

ware systems. In Software engineering for self-

adaptive systems, pages 27–47. Springer.

Beatty, J. and Chen, A. (2012). Visual Models for Software

Requirements. O’Reilly Media, Inc.

Bresciani, P., Giorgini, P., Giunchiglia, F., Mylopoulos, J.,

and Perini, A. (2004). Tropos: An agent-oriented

software development methodology. Journal of Au-

tonomous Agents and Multi-Agent Systems, 8:203–

236.

Brusilovsky, P. (2001). Adaptive hypermedia. User Model-

ing and User-Adapted Interaction, 11(1-2):87–110.

MiDAS:AModel-DrivenApproachforAdaptiveSoftware

285

Cheng, B. H., De Lemos, R., Giese, H., Inverardi, P.,

Magee, J., Andersson, J., Becker, B., Bencomo, N.,

Brun, Y., Cukic, B., et al. (2009a). Software engineer-

ing for self-adaptive systems: A research roadmap. In

Software engineering for self-adaptive systems, pages

1–26. Springer.

Cheng, B. H., Sawyer, P., Bencomo, N., and Whittle, J.

(2009b). A goal-based modeling approach to develop

requirements of an adaptive system with environmen-

tal uncertainty. In Model Driven Engineering Lan-

guages and Systems, pages 468–483. Springer.

Cleland-Huang, J., Gotel, O. C. Z., Huffman Hayes, J.,

Mäder, P., and Zisman, A. (2014). Software trace-

ability: Trends and future directions. In Proceedings

of the FOSE, pages 55–69. ACM.

Czarnecki, K., Foster, J. N., Hu, Z., Lämmel, R., Schürr,

A., and Terwilliger, J. F. (2009). Bidirectional trans-

formations: A cross-discipline perspective. In Theory

and Practice of Model Transformations, pages 260–

283. Springer.

Dardenne, A., Van Lamsweerde, A., and Fickas, S. (1993).

Goal-directed requirements acquisition. Science of

computer programming, 20(1):3–50.

Dromey, R. G. (2003). From requirements to design: For-

malizing the key steps. In Conference on Software

Engineering and Formal Methods, pages 2–11. IEEE.

Durán, A., Bernárdez, B., Toro, M., Corchuelo, R., Ruiz,

A., and Pérez, J. (1999). Expressing customer require-

ments using natural language, requirements templates

and patterns. In Proceedings of IMACS/IEEE CSCC.

Esfahani, N. and Malek, S. (2013). Uncertainty in self-

adaptive software systems. In Software Engineering

for Self-Adaptive Systems II, volume 7475, pages 214–

238. Springer.

Espada, P., Goulão, M., and Araújo, J. (2011). Measuring

complexity and completeness of kaos goal models. In

Empirical Requirements Engineering (EmpiRE), 2011

First International Workshop on, pages 29–32. IEEE.

Fleurey, F. and Solberg, A. (2009). A domain speciﬁc

modeling language supporting speciﬁcation, simula-

tion and execution of dynamic adaptive systems. In

Model Driven Engineering Languages and Systems,

pages 606–621. Springer.

Gnaho, C., Semmak, F., and Laleau, R. (2013). An

overview of a sysml extension for goal-oriented nfr

modelling: Poster paper. In Conference on Research

Challenges in Information Science, pages 1–2. IEEE.

Greenwood, P., Chitchyan, R., Rashid, A., Noppen, J.,

Fleurey, F., and Solberg, A. (2011). Modelling

adaptability and variability in requirements. In Re-

quirements Engineering Conference, pages 343–344.

IEEE.

Kent, S. (2002). Model-driven engineering. Lecture Notes

in Computer Science, 2335:286–298.

Kopczynska, S. and Nawrocki, J. (2014). Using non-

functional requirements templates for elicitation: A

case study. In Requirements Patterns (RePa), 2014

IEEE 4th International Workshop on, pages 47–54.

Laleau, R., Semmak, F., Matoussi, A., Petit, D., Hammad,

A., and Tatibouet, B. (2010). A ﬁrst attempt to com-

bine sysml requirements diagrams and b. Innovations

in Systems and Software Engineering, 6(1-2):47–54.

Lamsweerde, A. V. (2009). Requirements engineering:

from system goals to UML models to software spec-

iﬁcations. Wiley.

Macedo, N. and Cunha, A. (2014). Least-change bidirec-

tional model transformation with qvt-r and atl. Soft-

ware & Systems Modeling, pages 1–28.

OMG (2015). Sysml speciﬁcation.

http://www.sysml.org/docs/specs/OMGSysML-

v1.3-12-06-02.pdf. Last accessed: January/2015.

Salehie, M. and Tahvildari, L. (2009). Self-adaptive soft-

ware: Landscape and research challenges. ACM

Transactions on Autonomous and Adaptive Systems

(TAAS), 4(2):14.

Toro, A. D., Jiménez, B. B., Cortés, A. R., and Bonilla,

M. T. (1999). A requirements elicitation approach

based in templates and patterns. In WER, pages 17–

29.

Vogel, T. and Giese, H. (2014). Model-driven engineering

of self-adaptive software with eurema. ACM Transac-

tions on Autonomous and Adaptive Systems (TAAS),

8(4):18.

Whittle, J., Sawyer, P., Bencomo, N., Cheng, B. H., and

Bruel, J.-M. (2010). Relax: a language to address

uncertainty in self-adaptive systems requirement. Re-

quirements Engineering, 15(2):177–196.

Xiong, Y., Hu, Z., Zhao, H., Song, H., Takeichi, M., and

Mei, H. (2009). Supporting automatic model incon-

sistency ﬁxing. In Symposium on The foundations of

software engineering, pages 315–324. ACM.

WEBIST2015-11thInternationalConferenceonWebInformationSystemsandTechnologies

286
