The Effect of Peer Assessment Rubrics on Learners' Satisfaction and

Performance Within a Blended MOOC Environment

Ahmed Mohamed Fahmy Yousef

1,2

, Usman Wahid

, Mohamed Amine Chatti

1,2

Ulrik Schroeder

1,2

and

Marold Wosnitza

Learning Technologies Group (Informatik 9), RWTH Aachen University, Ahornstrasse 55, Aachen, Germany

Center for Innovative Learning Technologies (CiL), RWTH Aachen University, Ahornstrasse 55, Aachen, Germany

School Pedagogy and Educational Research, RWTH Aachen University, Eilfschornsteinstraße 7, Aachen, Germany

Keywords: Massive Open Online Courses, MOOCs, Blended MOOCs, bMOOCs, Peer Assessment, Collaborative

Learning, Rubrics.

Abstract: Massive Open Online Courses (MOOCs) have a remarkable ability to expand access to a large scale of

participants worldwide, beyond the formality of the higher education systems. MOOCs support participants

to be actively involved in collaborative learning and construct their own learning experience in a variety of

domains. However, one of the biggest challenges facing MOOCs is how to assess the learners’ performance

in a massive learning environment beyond traditional automated assessment methods. To address this

challenge, peer assessment has been proposed as an effective assessment method in MOOCs. The problem

is, however, how to ensure the quality of the peer assessment in terms of validity and reliability. Moreover,

assessment in blended MOOCs (bMOOCs) introduces unique challenges regarding the best peer assessment

model in a learning environment that brings together face-to-face interactions and online activities. This

paper presents the details of a study conducted to investigate peer assessment in bMOOCs. The study results

show that flexible rubrics have the potential to make the feedback process more accurate, credible,

transparent, valid, and reliable, thus ensuring the quality of the peer assessment task.

1 INTRODUCTION

Massive Open Online Courses (MOOCs) have

succeeded in offering large amount of university

level courses for a huge number of participants

around the globe without any entry requirements or

tuition fees, regardless of their location, age, income,

ideology, and education background (Yousef et al.,

2014a). Different types of MOOCs have been

introduced in the MOOC literature. Daniel (2012)

and Siemens (2013) classified MOOCs into

connectivist MOOCs (cMOOCs) and extension

MOOCs (xMOOCs). The vision behind cMOOC is

based on the theory of connectivism, which fosters

connections, collaborations, and knowledge sharing

among course participants. The second type,

xMOOCs is following virtue of behaviorism and

cognitivist theories with some social constructivism

aspects. xMOOC platforms were developed by

different elite universities and usually distributed

through a third party provider such as Coursera,

edX, and Udacity.

Despite their popularity and the large scale

participation, a variety of concerns and criticism in

the use of MOOCs have been raised. Yousef et al.

(2014a) in their comprehensive analysis of the

MOOC literature reported that the major limitation

in MOOCs is the lack of human interaction (i.e.

face-to-face communication). Furthermore, the

authors pointed out that the original concept of

MOOCs that aims at breaking down the barriers of

education for anyone, anywhere, and at any time, is

far away from the reality. In fact, most of the

existing (x)MOOC implementations still follow a

centralized and controlled top-down, teacher-

centered learning model. Initiatives to implement

student-centered, open, bottom up, and distributed

forms of MOOCs are the exception rather than the

rule. Other researchers point out concerns about the

limitations of MOOCs. These concerns include

pedagogical problems concerning providing the

participants with timely, accurate, and meaningful

feedback of their assignments tasks (Hill, 2013;

Piech et al., 2013; Luo et al., 2014); lack of

148

Yousef A., Wahid U., Chatti M., Schroeder U. and Wosnitza M..

The Effect of Peer Assessment Rubrics on Learners’ Satisfaction and Performance Within a Blended MOOC Environment.

DOI: 10.5220/0005495501480159

In Proceedings of the 7th International Conference on Computer Supported Education (CSEDU-2015), pages 148-159

ISBN: 978-989-758-108-3

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

interactivity between learners and the video content

(Grünewald et al., 2013); high drop-out rates, on

average 95%, of course participants (Daniel, 2012).

Plausible reason for the latter problem might be the

complexity and diversity of the participants. This

diversity is not only related to cultural and

demographic attributes, but also takes into account

individual motives and perspectives when enrolled

in MOOCs (Yousef et al., 2015b).

In order to address these limitations, a new

design paradigm emerges, called blended MOOCs

(bMOOCs). This paradigm aims to bring together

in-class (i.e. face-to-face) interactions and online

learning components as a blended environment. This

blended model can resolve some of the hurdles

facing standalone MOOCs (Ostashewski & Reid,

2012; Bruff, et al., 2013). The bMOOCs model has

the potential to bring human interactions into the

MOOC environment, foster student-centered

learning, support the interactive design of the video

lectures, provide effective assessment and feedback,

as well as contemplate the diverse perspectives of

the MOOC participants.

However, the ability to evaluate a large scale of

participants in MOOCs is obviously a big challenge

(Yin and Kawachi, 2013). The most widely used

evaluation technique in MOOCs is regular

automated assessment, which is restricted to closed

question formats, e.g. quizzes with multiple choice

questions (Díez et al., 2013; Kaplan & Bornet,

2014). This method of assessment is relatively easy

to apply in science curricula courses, even though

the level of competences to be examined is rather

limited. It seems even more difficult to apply this

assessment method in humanities curricula courses,

mainly due the nature of these courses, which are

based on the creativity and imagination of the

learners (Sandeen, 2013). This provides strong

ground for alternative assessment methods for both

domains that provide effective and constructive

feedback to MOOCs participants about their open-

ended exercises, or essays.

The generic aim of most assessment methods is

to provide such kind of feedback usually involve

teaching staff correcting and grading the

assignments. In the MOOCs scenarios, this requires

substantial resources in terms of time, money, and

manpower. To alleviate this problem, we argue that

the most suitable way is to look for assessment

methods that employ the wisdom of the crowd. Such

assessment methods include portfolios, wrappers,

self-assessment, group feedback, and peer

assessment (Chatti et al., 2014; Davis et al., 2014).

Learner’s portfolio is an approach to authentic

assessment that potentially enables large classes to

reflect on their work (McMullan, 2003); wrapping

assessment techniques use a set of reflective

questions to engage participants in self-assessment

and self-directed learning (Yorke, 2007); self-

assessment can be used to prompt learners’

reflection on their own learning outcomes; and peer

assessment refers crowdsourcing grading activities

where learners can take responsibility for rating,

evaluating, and providing feedback on each other’s

work (Topping, 1998).

We considered these different crowdsourcing

assessment activities, and concluded that the most

suitable assessment method in our scenario is to

involve the learners themselves under supervision

and guidance from the teachers. We think that peer

assessment activities that involve learners

themselves in the assessment process can play a

crucial role in supporting an effective MOOC

experience. So far, little research has been carried

out to investigate the effectiveness of using peer

assessment in a bMOOC context (Chatti et al., 2014;

Suen, 2014). In an attempt to handle this assessment

issue, this paper presents in details a study

conducted to investigate the effectiveness of using

peer assessment on learners’ performance and

satisfaction in the bMOOC environment L

P-

bMOOC.

2 L

P-BMOOC:

FIRST DESIGN

As highlighted earlier, current MOOCs suffer from

several critical limitations, among which are the

focus on the traditional teacher-centered model, the

lack of human interaction, as well as the lack of

interaction between learners and the video content

(Grünewald et al., 2013; Yousef et al., 2015b).

P-bMOOC is an extension of the L

P learning

platform of RWTH Aachen University, Germany. It

was designed and implemented to address these

limitations. L

P-bMOOC supports learner-centered

bMOOCs by providing a bMOOC environment

where learners can take an active role in the

management of their learning activities, thus

harnessing the potential of bMOOCs to support self-

organized learning. L

P-bMOOC fosters human

interaction through face to face communication and

scaffolding, driven by blended learning approach.

The platform includes a video annotation tool that

enables learners’ collaboration and interaction

TheEffectofPeerAssessmentRubricsonLearners'SatisfactionandPerformanceWithinaBlendedMOOCEnvironment

149

around a video lecture to engage the learners and

increase interaction between them and the video

content. Thus, L

P-bMOOC changes the traditional

MOOC concept, where learners are limited to

viewing video content towards a collaborative and

dynamic one. Learners are encouraged to organize

their learning, collaborate with each other, create

and share their knowledge with others.

In L

P-bMOOC, video lectures are

collaboratively structured and annotated in a mind-

map representation. Figure 1 shows the workspace

of L

P-bMOOC which consists of a course selection

section, an unbound canvas representing the video

map structure of the lecture, and a sidebar for new

video node addition and editing of video properties.

Possible actions on a video node include video

annotations, video clipping, social bookmarking (i.e.

attaching external web feeds), and collaborative

discussion threads (Yousef et al., 2015c).

Figure 1: L

P-bMOOC Workspace.

As pilot test for this platform the course

“Teaching Methodologies” was delivered as

bMOOC by the Fayoum University, Egypt in

cooperation with RWTH Aachen University. It

started in March 2014 and ran for eight weeks. This

course was offered both formally to students from

Fayoum University and informally with open

enrollment to anybody who was interested in

teaching and learning methodologies. At the end of

the course, there were 128 active participants. 93

were formal participants who took the course to earn

credits from Fayoum University. These participants

were required to complete it and obtain positive

grading of assignments. The rest were informal

participants undertaking the learning activities at

their own pace without receiving any credits. The

teaching staff provided six video lectures and the

course participants have added 27 related videos.

The course was taught in English and the

participants were encouraged to self-organize their

learning environments, to present their own ideas,

collaboratively create video maps of the lectures,

and share their newly-acquired knowledge through

social bookmarking, annotations, forums, and

discussion threads (Yousef et al., 2015c).

To evaluate whether the platform supports and

achieves the goals of “network learning” and “self-

organized learning”, we designed a qualitative study

based on a questionnaire. This questionnaire utilized

a 5-point Likert scale with range from (1) strongly

disagree, to (5) strongly agree. We derived the

results and reported conclusions based on the 50

participants who completed and submitted the

questionnaire by the end of the survey period. The

results obtained from this preliminary analysis are

summarized in the following points:

The collaboration and communication tools (i.e.

group workspaces, discussion forums, live chat,

social bookmarking, and collaborative annotations)

allowed the course participants to discuss, share,

exchange, and collaborate on knowledge

construction, as well as, receive feedback and

support from peers.

The results further show that the majority agreed

that L

P-bMOOC allowed them to be self-organized

in their learning process. In particular, the

participants reported that it helped them to learn

independently from teachers and encouraged them to

work at their own pace to achieve their learning

goals.

The study, however, identified two problems

concerning assessment and feedback. The

participants had some difficulties in tracking and

monitoring their learning activities and those of their

peers. The second issue pointed out was the limited

ability to evaluate and give effective feedback for

their open-ended exercises (Yousef et al., 2015c).

A possible solution for the first problem was the

introduction of learning analytics features. These

features can improve the participants’ learning

experience through e.g. the monitoring of their

progress and supporting (self)-reflection on their

learning activities. To alleviate the second problem,

we opted for peer assessment. As motivated in the

previous section, one possible scenario for peer

assessment is the evaluation of assignment that

cannot be corrected automatically, such as open-

ended exercises and essays.

In August 2014, we conducted a second case

study to evaluate the usability and effectiveness of

the learning analytics module. The focus of this

study was to examine to which extent this module

supported personalization, awareness, self-

reflection, monitoring, and recommendation in

bMOOCs (Yousef et al., 2015a). What still remained

unclear is how to leverage peer assessment in

CSEDU2015-7thInternationalConferenceonComputerSupportedEducation

150

bMOOCs. In this paper, we investigate the

application of peer assessment in bMOOCs. We

address the following research questions:

 Does the peer assessment module improve

learning outcomes?

 Does the peer assessment module provide a

reliable and valid feedback for participants?

 Which peer assessment model fits best in a

bMOOC context?

 What is the learners’ perception of satisfaction

with the usability of the peer assessment module

in L

P-bMOOC?

3 PEER ASSESSMENT IN MOOC

Assessment and feedback are essential part of the

learning process in MOOCs. Collecting valid and

reliable data to grade learners’ assignments;

identifying learning difficulties and taking action

accordingly; and using these results, are just a

portion of the measures to improve the academic

experience (Kulkarni et al., 2013). Many MOOCs

use automated assessments (e.g. quizzes with closed

questions such as multiple-choice/multiple-response)

which strongly focus on the cognitive aspects of

learning. The key challenge of automated grading in

MOOCs is the inability to capture the semantic

meaning of learners’ answers; in particular on open-

ended questions (Kulkarni et al., 2013).

On the other hand, peer assessment is a

promising alternative evaluation strategy in

MOOCs, where learners can be actively involved in

the assessment processes (O’Toole, 2013). This

method of assessment is suitable for activities, like

exercises, assignments, or exams which do not have

clear right or wrong answers especially in

humanities, social sciences, and business studies

(O’Toole, 2013). Several studies have been

conducted to investigate the pedagogical impact of

using peer assessment in traditional classroom

instruction, and acknowledged a number of distinct

advantages. These include: increase in learners’

responsibility and autonomy, new learning

opportunities for both sides (i.e. givers and receivers

of work review), enhanced collaborative learning

experience, and strive for a deeper understanding of

the learning content (Topping, 1998).

Unfortunately, so far, there has been little

discussion about using peer assessment in MOOCs.

In the next section, we will discuss specifically how

MOOCs providers are using peer assessment in their

courses.

3.1 Coursera

Coursera has integrated a peer assessment system in

its learning platform to evaluate and provide

feedback for at least 3 to 4 assignments. Coursera

provides learners with an optional evaluation matrix

to improve peer assessment results. In addition,

learners have the opportunity to self-evaluate

themselves (Piech et al., 2013; Luo et al., 2014). The

peer assessment system in Coursera involves three

main phases: 1) submission phase, 2) evaluation

phase, and 3) publishing results (Coursera, 2015).

Until recently, there has been no reliable evidence

on how peer assessment affects the learning

experience in Coursera.

In several MOOCs offered by the Pennsylvania

State University and hosted online by Coursera,

learners reported that, they mistrusted the peer

assessment results. Moreover, they outlined some

issues of peer assessment, such as the lack of peers’

feedback, accuracy, and credibility (Suen, 2014).

3.2 edX

Peer assessment in edX work similar to the ones in

Coursera. Here, learners are required to review a few

assignments samples that have already been graded

by the professor before evaluating their peers. After

learners proved that they can assign grades similar to

those given by the professor, they are permitted to

evaluate each other’s work and provide feedback,

using the same rubric (edX, 2015).

3.3 Peer Assessment Issues in MOOCs

Peer assessment is a valuable evaluation method for

learners to receive deeper feedback on their

assignments but it is not always as effective as

expected in MOOCs scenarios (Suen, 2014). Jordan

(2013) shows that MOOCs which used peer

assessments tend to have lower course completion

rates compared to the ones that used automated

assessment. In general, there are several possible

factors that can explain the lack of effectiveness of

peer assessment in MOOCs:

 The issue of scale (Suen, 2014).

 The diversity of reviewers’ background and

prior experience (Yousef et al., 2015b).

 The lack of accuracy and credibility of peer

feedback (Suen, 2014).

 The lack of transparency of the review process.

 MOOCs participants do not trust the validity

and reliability of peer assessment results due to

TheEffectofPeerAssessmentRubricsonLearners'SatisfactionandPerformanceWithinaBlendedMOOCEnvironment

151

the absence of a clear evaluation authority (e.g.

teacher)

 The low perceived expertise (McGarr &

Clifford, 2013).

 Peer assessment in MOOCs employs fixed

grading rubrics. Obviously, different exercise

types require different assessment rubrics

(Sánchez-Vera & Prendes-Espinosa, 2015).

4 PEER ASSESSMENT

IN L

P-BMOOC

In this study, we focus on the application of peer

assessment from a learner’s perspective to support

self-organized and network learning in bMOOCs

through peer assessment rubrics. In the following

sections, we discuss the design, implementation, and

evaluation of the new peer assessment module in

P-bMOOC.

4.1 Requirements

In order to enhance L

P-bMOOC with a peer

assessment module, we collected a set of

requirements from recent peer assessment and

MOOCs literature (Gielen et al., 2010; Suen, 2014;

Yousef et al., 2014a). Then, we designed a survey to

collect feedback from different MOOC stakeholders

concerning the importance of the collected

requirements. The demographic profile of this

survey was distinguished into professors and

learners as follows:

 Professors: 98 professors who had taught a

MOOC completed this survey. 41% from

Europe, 42% from the US and 17% from Asia.

 Learners: 107 learners participated in the

survey. A slight majority of these learners were

males (56%). The learners’ ages ranged from 18

to 40+, with almost 65% between the ages of 18

and 39. 12% High school and other levels of

studying, 36% were studying Bachelor, 40%

Master’s, 12% PhD. All of them had taken one

or more online courses, and 92% had

participated in MOOCs. These learners came

from 41 different countries and cultural

backgrounds in Europe, US, Australia, Asia,

and Africa.

A summary of the survey analysis results are

presented in Table 1. The agreeability means of peer

assessment requirements is quite high at above 4. In

particular, indicators 3 and 5 call for specific, albeit

flexible guidelines and rubrics. This is important to

avoid grading without reading the work, or not

following a clear grading scheme, which negatively

impacts the quality of the given feedback (Yousef et

al., 2014b).

Table 1: L

P-bMOOC Peer Assessment Requirements

(N=205).

P-BMOOC Peer Assessment Requirements

Items M SD

Students should receive feedback

and/or correct answers to each

assignment task.

4.57 0.90

Provide formative assessment and

feedback within the learning

process.

4.12 1.05

Design flexible guidelines and

rubrics for each task.

4.53 0.84

Give clear directions and time

limits for in-class peer review

sessions (i.e., face-to-face

interaction) and set defined

deadlines for out-of-class peer

review assignments.

4.36 1.06

Each student doing the peer

review should explain his or her

evaluation.

4.32 0.79

1. Strongly disagree … 5. Strongly agree

Based on the peer assessment literature review

and the survey results, we derived a set of

requirements to support peer assessment in L

P-

bMOOC, as summarized below:

 User Interface: The interface should be simple,

understandable, and easy to use while requiring

minimal user input. The interface design of the

module should take usability principles into

account, and go through a participatory design

process (Nielsen, 1994).

 Rubrics: Provide learners with flexible task-

specific rubrics that include descriptions of each

assessment item to achieve fair and consistent

feedback for all course participants.

 Management: Peer assessment should be easy

to manage. The module ought to be integrated

into the platform with features for activation

and deactivation.

 Scalability: The fundamental difference

between MOOCs and traditional classroom is

the scale of learners. Consequently, scalability

should be considered in the implementations of

peer assessment module in L

P-bMOOC.

 Collaborative Review: Provide mechanisms for

a collaborative review process which involves

the input of more than one individual

participant.

CSEDU2015-7thInternationalConferenceonComputerSupportedEducation

152

 Double Blind Process: Peer assessment module

should support the double blind review process.

Neither the assignment authors know the

reviewers identities, vice versa.

 Deadlines: Peer assessment module should

provide two deadlines for each task: the

submission deadline for learners to submit their

work, and the other for the peer grading phase.

5 IMPLEMENTATION

The peer assessment module in L

P-bMOOC

consists of the six components as shown in Figure 2.

Figure 2: Peer assessment workflow.

These peer assessment components are classified

according to the following methods:

 Teachers need methods to define assignment

tasks and manage the review process.

 Learners need methods to see assignment tasks

and submit solutions, as well as, to provide and

receive peer reviews.

Microsoft SharePoint 2013 has been used as the

underlying technology of the L²P platform.

SharePoint offers a solid base for MOOCs

development, while offering a wide range of other

advantages. These include scalability, security,

customization and collaboration. The internal list

structure of SharePoint makes it easy to implement

fine grained rights on individual list items, which

allow for easy to use rights management in L

P-

bMOOCs peer assessment module. Basically, it is

easy to configure who can see what on a given point

in time. Also, workflows can be used to organize

submission and evaluation processes.

5.1 Teacher Perspective

The peer assessment module in L

P-bMOOC

consists of a centralized place of actions (navigation

ribbon) to help teachers to define, manage, and

navigate the assignment tasks, as shown in Figure 3.

Figure 3: Teacher Navigation Ribbon.

The ribbon actions provide a complete set of

tools to define peer assessment tasks, manage task-

specific rubrics, assign reviewers, give final grades,

and publish the results.

5.1.1 Task Definition with Rubrics

The task definition begins with defining some basic

attributes of the assignments. These attributes

include the name and description, the deadlines, and

the associated materials and resources. Additionally,

there are a number of specific settings to be

configured, which are related to the peer assessment

itself. These specific settings are concerning the start

and end of the review, the review impact on the final

grade, and the task-specific rubrics (see Figure 4).

Figure 4: Task Definition with Rubrics.

There are well researched and documented

methods to enhance the effectiveness of peer

assessment by asking direct questions for the peer to

answer, in order to assess the quality of work by the

author (Gielen et al., 2010). This way, the reviewer

can easily reflect on the quality of work in a goal-

oriented manner. Hence, we implemented a rubric

system that allows tutors to define specific questions

related to each task, and also reuse pre-defined

rubrics. The process for defining rubrics is included

in the task definition itself. A typical rubric has two

Task Definition with

Rubrics

Submit

Solution

Assign

Reviewers

Peer Assessment

Individual / Group

Publish Review

Results

TheEffectofPeerAssessmentRubricsonLearners'SatisfactionandPerformanceWithinaBlendedMOOCEnvironment

153

attributes: name and the actual rubric question.

Further, it contains descriptions that define the

learning outcome and performance levels to provide

enough information to guide learners in doing the

peer assessment review. Teachers can select multiple

rubrics to associate with an assignment definition.

Once the assignment task has been defined, an

automated workflow takes care of publishing the

assignment at the specified time along with

submission deadline. Meanwhile, another workflow

takes care of the review submission after the review

start date.

5.1.2 Assigning Reviewers

Course teachers can assign solutions submitted by

learners to different peers for reviewing by selecting

from a list (see figure 5).

Figure 5: Assigning Reviewers.

Future versions of the system should automate

the distribution process. There are mechanisms to

reverse the process, if there is a problem or a

mistake. After this, the assigned reviews are visible

to the learners according to the specified dates, and

if any review assignment is made after the review

start date, it would be shown to the learners directly.

5.1.3 Publishing Reviews

After grading all the solutions, teachers can publish

the review results to the learners at once using an

action from the ribbon. As a result, the learners are

able to see the reviews submitted by their peers.

5.2 Learner Perspective

The navigation ribbon contains actions for learners

to submit solutions and perform peer review task.

5.2.1 Submitting Solutions

Once the assignment has been published, the

learners can see the details of the assignment and

work on their solutions until the proposed deadline.

Learners can add a solution by adding a description

and uploading their documents and resources

relevant to the solution. Learners can work

individually, or in groups, depending on the

assignment’s requirements (see Figure 6).

Figure 6: Submitting Solutions.

5.2.2 Peer Assessment

There are a number of peer assessment

methodologies dealing with the anonymity of author

and reviewer, e.g. Single Blind Review (reviewer is

anonymous, author is known), Double Blind Review

(both reviewer and author are anonymous) and lastly

the Open Review (No anonymity). For the purpose

of this implementation we decided to use the Double

Blind Review, as it reduces the chances of biased

marking (Sitthiworachart & Joy, 2004).

Figure 7: Peer Assessment Interface.

CSEDU2015-7thInternationalConferenceonComputerSupportedEducation

154

Once the peer review phase starts, the learners can

see a list of reviews assigned to them by the

teachers. The interface for adding a review can be

seen in Figure 7. It contains two sections, the

submitted solution on the top and the review section

with rubrics at the bottom. The reviewers can see the

documents and resources attached to the solution

and any comments given by the authors. They can

add their comments against the rubric questions in

the review section along with an option to upload

any files and grade the review as well.

6 CASE STUDY

In October 2014, we conducted a third case study to

investigate the usability and effectiveness of the peer

assessment module. We used the enhanced edition

of L

P-bMOOC to offer a bMOOC on “Education

and the Issues of the Age” at Fayoum University,

Egypt in cooperation with RWTH Aachen

University. Again, the course was offered both

formally to students from Fayoum University and

informally with open enrollment to anyone who is

interested in teaching and educations issues. The

teaching staff is composed of one professor and one

assistant researcher from Fayoum University as well

as one assistant researcher from RWTH Aachen

University. A total of 133 participants completed

this course. 92 formal participants took the course to

earn credits from Fayoum University. These

participants were required to complete the course

and obtain positive grading of assignments. The

remaining 41 were informal participants who didn’t

attend the face-to-face sessions. They have

undertaken the learning activities at their own pace

without receiving any type of academic credits. The

teaching staff provided nine short video lectures and

the course participants added another 25 related

videos. Participants in the course were encouraged

to use video maps to organize their lectures, and

collaboratively create and share knowledge through

annotations, comments, discussion threads, and

bookmarks. Participants used the peer assessment

module for the submission of a team project report.

After the submission, every team reviewed other’s

work and provided their feedback based on the

rubric questions provided by the teaching staff.

These reviews were then taken into consideration by

the teaching staff while compiling their own

feedback of the team projects. Once the teacher

reviews were completed the final corrections were

made public to the students who could see both

reviews for their own project namely, the review

from peer and the review from the teacher.

7 EVALUATION

We conducted a thorough evaluation of the peer

assessment module in L

P-bMOOC in order to

answer the main research questions in this work. The

aim was to evaluate the usability and effectiveness

of the module, including the impact on learning

outcome and the quality of feedback. Our endeavor

was also to investigate which peer assessment model

fits best in a bMOOC context. We employed an

evaluation approach based on the ISONORM

9241/110-S as a general usability evaluation as well

as a custom questionnaire to measure the

effectiveness of peer assessment in L

P-bMOOC.

7.1 Usability Evaluation

The purpose of usability evaluation is to measure

learner’s satisfaction with the peer assessment

module as well as to identify the issues for

improvement. The ISONORM 9241/110-S

questionnaire was designed based upon the

International Standard ISO 9241, Part 110 (Prümper,

1997). We used this questionnaire as a general

usability evaluation for the peer assessment module.

It consists of 21 questions classified into seven main

categories. Participants were asked to respond to

each question scaling from (7) a positive

exclamation and its mirroring negative counterpart

(1). The questionnaire comes with an evaluation

framework that computes several aspects of usability

to a single score between 21 and 147. A total of 57

out of 133 participants completed the questionnaire.

A diversity in learner’s age was exhibited by the

evaluators, their ages ranging from 18 to 40+ years

with almost 65% of the evaluators being between the

ages of 18 and 24. Around 70% of the evaluators

were Bachelors students, 17% from Masters courses

and the remaining 12% pursuing a PhD. All of them

had taken one or more online courses. The results

obtained from the ISONORM 9241/110-S usability

evaluations are summarized in Table 2.

The overall score was 99.1 which translates to

“Everything is all right! Currently there is no reason

to make changes to the software in regards of

usability” (Prümper, 1997). This result reflects a

high level of user satisfaction with the usability of

peer assessment module in L

P-bMOOC.

TheEffectofPeerAssessmentRubricsonLearners'SatisfactionandPerformanceWithinaBlendedMOOCEnvironment

155

Table 2: ISONORM 9241/110-S Evaluation Matrix (N=

57).

Factor Aspect M

Suitability for

tasks

Integrity 5.2

Streamlining 5.5

Fitting 4.3

Self-

descriptiveness

Information content 4.9

14.5

Potential support 4.8

Automatic support 4.9

Conformity with

user expectations

Layout conformity 4.7

Transparency 4.7

Operation

conformity

4.6

Suitability for

learning

Learnability 5.4

14.7

Visibility 4.8

Deducibility 4.5

Controllability

Flexibility 4.9

14.2

Changeability 4.5

Continuity 4.8

Error tolerance

Comprehensibility 4.7

13.5

Correct ability 4.6

Correction support 4.2

Suitability for

individualization

Extensibility 4.0

13.2 Personalization 4.3

Flexibility 4.9

ISONORM score 99.1

7.2 Effectiveness Evaluation

In our study, we focused on peer assessment to

support groups or individuals to review, grade and

provide in-depth feedback for their peers, based on

flexible rubrics. The effectiveness evaluation aims at

investigating the impact on learning outcomes and

the quality of feedback. This study included the

design of a questionnaire adapted from (Brindley &

Scoffield, 1998; Wolf & Stevens, 2007; Kulkarni et

al., 2013). The questionnaire consisted of two main

parts. The first part containing 21 items in the two

categories mentioned above as illustrated in Table 3.

The second part aimed at investigating the most

effective peer assessment model in a bMOOC

setting, as presented in Table 4. To ensure the

relevance of these questions, a pre-test was

conducted with 5 learners and 5 learning

technologies experts. Their feedback included a

refinement of some questions and replacing some

others. The revised questionnaire was then given to

the “Education and the Issues of the Age” course

participants.

Table 3: The Effectiveness Evaluation of Peer Assessment

in L

P-bMOOC (N= 57).

Peer Assessment

Evaluation Items M SD

Impact on learning outcome

The peer feedback helped me to see

errors in my own work.

4.5 0.50

Reviewing others' work helped me to

reflect on my own work.

4.4 0.53

The received feedback helped me to

reflect on my own work.

4.2 0.51

The peer assessment helped me to

learn how to give constructive

feedback to peers.

4.2 0.62

The peer feedback helped me to come

up with new ideas.

4.4 0.53

The comments I received from peer

feedback helped to improve the

quality of my work.

4.3 0.48

The received feedback helped me to

get more information about the

learning topic.

4.4 0.53

Reviewing others' work helped me to

expand knowledge about the learning

topic.

4.3 0.51

The peer assessment increased my

ability in organizing ideas and

contents in my work.

4.1 0.50

Impact on learning outcome average 4.3 0.52

Quality of feedback

The scoring grade I received from peer

feedback was valid.

4.2 0.51

The peer feedback I received is

accurate and credible.

4.2 0.50

I am confident that my peers have

enough ability to assess my work.

4.2 0.53

I am confident that I have the ability to

assess peers’ work.

4.3 0.71

I put sufficient effort into grading

peers’ work.

4.5 0.56

The peer assessment rubrics and their

descriptions were sufficiently clear.

4.3 0.57

The peer assessment rubrics supported

in providing peers with detailed

feedback on their assignment work.

4.4 0.62

The peer assessment rubrics assisted

me in focusing on particular details in

the peers work.

4.4 0.53

The description of the rubrics helped

me understand what teachers expected

in the evaluation report.

4.4 0.54

The peer assessment rubrics made the

review task clearer.

4.4 0.56

The peer assessment rubrics made the

review process more transparent.

4.3 0.54

The peer assessment rubrics were

necessary to complete my review task.

4.4 0.53

Quality of feedback average 4.3 0.55

1. Strongly disagree … 5. Strongly agree

CSEDU2015-7thInternationalConferenceonComputerSupportedEducation

156

7.2.1 Impact on Learning Outcome

Respondents were asked to indicate whether the peer

assessment has affected their learning outcome. As

can be seen from Table 3, the overall response to the

evaluation items 1-9 was very positive at 4.3 with

acceptable standard deviation at 0.52. This indicates

that peer assessment is a powerful evaluation

method to detect and correct errors, reflect, and

criticize which are key elements in double-loop

learning. The concept of double-loop learning was

introduced by Argyris and Schön (1978) within an

organizational learning context. According to the

authors, learning is the process of detecting and

correcting errors. Error correction happens through a

continuous process of inquiry, reflection, and (self-)

criticism, which enables learners to test, challenge,

and eventually update their knowledge, and in so

doing improving their learning outcome (Chatti et

al., 2012).

Peer assessment further fosters continuous

knowledge creation, which is a prerequisite for

effective learning (Nonaka and Takeuchi, 1995).

This can be attributed to the fact that in the peer

assessment process, learners can learn from either

negative or positive aspects of peer’s work and make

use of them to get in-depth understanding of the

learning topic and improve their knowledge, which

leads to an enhancement of their learning

performance.

7.2.2 Quality of Feedback

Key challenges in peer assessment include the

diversity of reviewers’ background and prior

experience (Yousef et al., 2015b), the lack of

accuracy and credibility of peer feedback (Suen,

2014) as well as the lack of transparency of the

review process. Moreover, MOOC participants do

not trust the validity and reliability of peer

assessment results due to the absence of a clear

evaluation authority (e.g. teacher) and the low

perceived expertise of students (McGarr & Clifford,

2013).

Rubrics provide a possible solution to overcome

these issues by offering clear guidelines when

assessing peer’s work. Items 10 to 21 in Table 3 are

concerned with the quality of the rubric-based peer

feedback approach employed in L

P-bMOOC. In

general, the respondents agreed that harnessing

rubrics had a positive impact on the quality of the

peer assessment task, in terms of the accuracy and

credibility of peer feedback (item 11), transparency

of the review process (item 20), as well as validity

and reliability of peer assessment results (item 10

and 12). Moreover, the study revealed that

participants are confident in their ability to assess

peers’ work. They confirmed that following clear

rubrics helped them understand the evaluation

criteria and supported them in providing peers with

detailed feedback.

7.3 Peer Assessment Models

An important goal in our study was also to

investigate which peer assessment model fits best in

a bMOOC context, as presented in Table 4.

Table 4: Peer Assessment Models in bMOOCs.

Peer Assessment Models Mean SD

Time

Early feedback

4.6 0.50

Delayed feedback 1.7 0.44

Anonymity

Double blind review

4.6 0.48

Single blind review 2.3 0.61

Open review 1.7 0.88

Delivery

Indirect feedback (i.e., written )

4.6 0.72

Direct feedback (i.e., face-to-face) 2.2 0.68

Peer Grading

Review with grading 3.1 0.86

Review with partly grading

4.4 0.79

Review without grading 1.9 0.41

Peer Grading Weight

Contributing to the final official grade 3.8 0.93

Not contributing to the final official

grade

2.9 1.20

Channel

Single channel feedback (1:1) 2 0.52

Multiple channel feedback (m:n)

4.8 0.34

Review Loop

Single loop 2 0.73

Multiple loop

4.8 0.34

Teacher Role

Substitution 2.1 0.57

Supplementary

4.3 0.58

Monitoring 2.9 0.87

1. Strongly disagree … 5. Strongly agree

We can draw certain conclusions about the most

effective peer assessment practices in bMOOCs as

follows:

Time: Optimal feedback should be provided early in

the assessment process in order to give learners the

opportunity to react and improve their work.

Anonymity: An important aspect of peer assessment

is to ensure the anonymity of the feedback. This

way, reviewers can provide critical feedback and

TheEffectofPeerAssessmentRubricsonLearners'SatisfactionandPerformanceWithinaBlendedMOOCEnvironment

157

grading without considering interpersonal factors

e.g. friendship bias or personal dislikes.

Delivery: Indirect feedback ensures more effective

assessment results as learners feel more comfortable

to give honest feedback without any influence from

peers.

Peer Grading: Peer grading should only be a part of

the final grade in order to ensure the validity of the

assessment results.

Channel: Assessment results can be more accurate

and credible when learners receive feedback from

multiple reviewers rather than from a single one.

This way, learners have the chance to receive a

multifaceted feedback on their work.

Review Loop: Having multiple feedback iteration

achieve a better learning outcome as learners can

reflect on the assignment work multiple times.

Teacher role: The teachers should still take an

active role in the peer assessment process, by

defining evaluation rubrics, providing sample

solutions, and checking the peer review results. They

can also help in developing review skills.

8 CONCLUSIONS

MOOCs have attracted a huge number of

participants around the globe to attend free online

courses in variety of domains. However, one of the

greatest challenges facing MOOCs is how to assess

the learners’ performance in larger class sizes

beyond traditional automated assessment methods.

Peer assessment has been proposed as an effective

assessment method in MOOCs to address this

challenge. The issue is, however, how to ensure the

quality of the peer assessment in terms of validity,

and reliability. Moreover, assessment in blended

MOOCs (bMOOCs) introduces unique challenges

regarding the best peer assessment model in a

bMOOC context.

This paper presents the details of a study

conducted to investigate peer assessment in

bMOOCs. The study results show that flexible

rubrics have the potential to make the feedback

process more accurate, credible, transparent, valid,

and reliable, thus ensuring the quality of the peer

assessment task. Furthermore, early feedback,

anonymity, indirect feedback, peer grading as only a

part of the final grade, multiple channel feedback,

multiple feedback loops, as well as a supplementary

teacher role are the most effective assessment

methods in bMOOCs.

ACKNOWLEDGEMENTS

We are grateful to Dr. Ahmed Ramadan Khatiry,

Fayoum University for providing the course

material. We also thank Vlatko Lukarov, Center for

Innovative Learning Technologies (CiL), RWTH

Aachen University for his valuable comments and

feedback on the first drafts of the paper.

REFERENCES

Argyris, C., & Schon, D. (1978). Organizational learning:

A theory of action approach. Reading, MA: Addision

Wesley.

Brindley, C., & Scoffield, S. (1998). Peer assessment in

undergraduate programmes. Teaching in higher

education, 3(1), 79-90.

Bruff, D. O., Fisher, D. H., McEwen, K. E., & Smith, B.

E. (2013). Wrapping a MOOC: Student perceptions of

an experiment in blended learning. MERLOT Journal

of Online Learning and Teaching, 9(2), 187-199.

Chatti, M. A., Jarke, M., & Schroeder, U. (2012). Double-

loop learning. Encyclopedia of the sciences of

learning, 1035-1037.

Chatti, M. A. (2010) The LaaN Theory. In:

Personalization in Technology Enhanced Learning: A

Social Software Perspective. Aachen, Germany:

Shaker Verlag, pp. 19-42.

Chatti, M. A., Lukarov, V., Thüs, H., Muslim, A., Yousef,

A. M. F., Wahid, U., Greven, C., Chakrabarti, A.,

Schroeder, U. (2014). Learning Analytics: Challenges

and Future Research Directions. eleed, Iss. 10.

Coursera. (2015) How will my grade be determined?

Retrieved on 20

of January, 2015 from,

http://help.coursera.org/customer/portal/articles/11633

04-how-will-my-grade-be-determined-

Daniel, J. (2012). Making sense of MOOCs: Musings in a

maze of myth, paradox and possibility. Journal of

Interactive Media in Education, 3.

Davis, H., Dikens, K., Leon-Urrutia, M., Sanchéz-Vera,

M. M., & White, S. (2014). MOOCs for Universities

and Learners an analysis of motivating factors. In

Proc. CSEDU 2014 conference, pp. 105-116.

INSTICC, 2014.

Díez, J., Luaces, O., Alonso-Betanzos, A., Troncoso, A.,

& Bahamonde, A. (2013, December). Peer assessment

in MOOCs using preference learning via matrix

factorization. In NIPS Workshop on Data Driven

Education.

edX. (2015). Open Response Assessments. Retrieved on

of January, 2015 from, http://edx-guide-for-

students.readthedocs.org/en/latest/SFD_ORA.html.

Gielen, S., Peeters, E., Dochy, F., Onghena, P., &

Struyven, K. (2010). Improving the effectiveness of

peer feedback for learning. Learning and Instruction,

20(4), 304-315.

CSEDU2015-7thInternationalConferenceonComputerSupportedEducation

158

Grünewald, F., Meinel, C., Totschnig, M., & Willems, C.

(2013). Designing MOOCs for the Support of Multiple

Learning Styles. In Scaling up Learning for Sustained

Impact (pp. 371-382). Springer Berlin Heidelberg.

Hill, P. (2013). Some validation of MOOC student

patterns graphic.

From: http://mfeldstein.com/validation-mooc-student-

patterns-graphic/

Jordan, K. (2013). MOOC completion rates: The data.

Retrieved on 20.01.2015, from:

http://www.katyjordan.com/MOOCproject.

Kaplan, F., & Bornet, C. A. M. (2014). A Preparatory

Analysis of Peer-Grading for a Digital Humanities

MOOC. In Digital Humanities 2014: Book of

Abstracts (No. EPFL-CONF-200911, pp. 227-229).

Kulkarni, C., Wei, K. P., Le, H., Chia, D., Papadopoulos,

K., Cheng, J., Koller, D., & Klemmer, S. R. (2013).

Peer and self assessment in massive online classes.

ACM Transactions on Computer-Human Interaction

(TOCHI), 20(6), 33.

Luo, H., Robinson, A. C., & Park, J. Y. (2014). Peer

Grading in a MOOC: Reliability, Validity, and

Perceived Effects. Online Learning: Official Journal

of the Online Learning Consortium, 18(2).

McGarr, O., & Clifford, A. M. (2013). ‘Just enough to

make you take it seriously’: exploring students’

attitudes towards peer assessment. Higher Education,

65(6), 677-693.

McMullan, M., Endacott, R., Gray, M. A., Jasper, M.,

Miller, C. M., Scholes, J., & Webb, C. (2003).

Portfolios and assessment of competence: a review of

the literature. Journal of advanced nursing, 41(3),

283-294.

Nielsen, J. (1994). Usability inspection methods. In

Conference companion on Human factors in

computing systems (pp. 413-414). ACM.

Nonaka, I., & Takeuchi, H. (1995). The knowledge-

creating company: How Japanese companies create

the dynamics of innovation. Oxford university press.

Ostashewski, N., & Reid, D. (2012). Delivering a MOOC

using a social networking site: the SMOOC Design

model. In Proc. IADIS International Conference on

Internet Technologies & Society, (2012), 217-220.

O'Toole, R. (2013) Pedagogical strategies and

technologies for peer assessment in Massively Open

Online Courses (MOOCs). Discussion Paper.

University of Warwick, Coventry, UK: University of

Warwick. Retrieved from:

http://wrap.warwick.ac.uk/54602/

Piech, C., Huang, J., Chen, Z., Do, C., Ng, A., & Koller,

D. (2013). Tuned models of peer assessment in

MOOCs. arXiv preprint arXiv:1307.2579.

Prümper, J. (1997). Der Benutzungsfragebogen

ISONORM 9241/10: Ergebnisse zur Reliabilität und

Validität. In Software-Ergonomie’97 (pp. 253-262).

Vieweg+ Teubner Verlag.

Sánchez-Vera, M. M., & Prendes-Espinosa, M. P. (2015).

Beyond objective testing and peer assessment:

alternative ways of assessment in MOOCs. RUSC.,

12(1). pp. 119-130.

Sandeen, C. (2013). Assessment’s place in the new

MOOC world. Research & Practice in Assessment, 8

(1), 5-12.

Sitthiworachart, J., & Joy, M. (2004). Effective peer

assessment for learning computer programming. In

ACM SIGCSE Bulletin (Vol. 36, No. 3, pp. 122-126).

ACM.

Suen, H. K. (2014). Peer assessment for massive open

online courses (MOOCs). The International Review of

Research in Open and Distance Learning, 15(3).

Topping, K. (1998). Peer assessment between students in

colleges and universities. Review of Educational

Research, 68(3), 249-276.

Wolf, K., & Stevens, E. (2007). The role of rubrics in

advancing and assessing student learning. The Journal

of Effective Teaching, 7(1), 3-14.

Yin, S., & Kawachi, P. (2013). Improving open access

through prior learning assessment. Open Praxis, 5(1),

59-65.

Yorke, M. (2007). Assessment, especially in the first year

of higher education: Old principles in new wrapping.

In REAP International Online Conference on

Assessment Design for Learner Responsibility.

Yousef, A. M. F., Chatti, M. A., Ahmad, I., Schroeder, U.,

& Wosnitza, M. (2015a, accepted). An Evaluation of

Learning Analytics in a Blended MOOC Environment.

The European MOOC Stakeholder Summit 2015.

Yousef, A. M. F., Chatti, M. A., Wosnitza, M., &

Schroeder, U. (2015b). A Cluster Analysis of MOOC

Stakeholder Perspectives. RUSC. Universities and

Knowledge Society Journal, 12(1), 74-90.

Yousef, A. M. F., Chatti, M. A., Schroeder, U. &

Wosnitza, M. (2015c, in press). A Usability

Evaluation of a Blended MOOC Environment: An

Experimental Case Study. The International Review of

Research in Open and Distributed Learning.

Yousef, A. M. F., Chatti, M. A., Schroeder, U., Wosnitza,

M., Jakobs, H. (2014a). MOOCs - A Review of the

State-of-the-Art. In Proc. CSEDU 2014 conference,

Vol. 3, pp. 9-20. INSTICC, 2014.

Yousef, A. M. F., Chatti, M. A., Schroeder, U., Wosnitza,

M. (2014b). What Drives a Successful MOOC? An

Empirical Examination of Criteria to Assure Design

Quality of MOOCs. In Proc. ICALT 2014, 14th IEEE

International Conference on Advanced Learning

Technologies, 44-48.

TheEffectofPeerAssessmentRubricsonLearners'SatisfactionandPerformanceWithinaBlendedMOOCEnvironment

159
