WeXpose: Towards on-Line Dynamic Analysis of Web Attack Payloads

using Just-In-Time Binary Modiﬁcation

Jennifer Bellizzi and Mark Vella

PEST Research Group, University of Malta, Msida, Malta

Keywords:

Web Code-injections, Dynamic Binary Instrumentation, JIT Binary Modiﬁcation.

Abstract:

Web applications constitute a prime target for attacks. A subset of these inject code into their targets, posing

a threat to the entire hosting infrastructure rather than just to the compromised application. Existing web in-

trusion detection systems (IDS) are easily evaded when code payloads are obfuscated. Dynamic analysis in

the form of instruction set emulation is a well-known answer to this problem, which however is a solution

for off-line settings rather than the on-line IDS setting and cannot be used for all types of web attacks pay-

loads. Host-based approaches provide an alternative, yet all of them impose runtime overheads. This work

proposes just-in-time (JIT) binary modiﬁcation complemented with payload-based heuristics for the provision

of obfuscation-resistant web IDS at the network level. A number of case studies conducted with WeXpose, a

prototype implementation of the technique, shows that JIT binary modiﬁcation ﬁts the on-line setting due to

native instruction execution, while also isolating harmful attack side-effects that consequentially become of

concern. Avoidance of emulation makes the approach relevant to all types of payloads, while payload-based

heuristics provide practicality.

1 INTRODUCTION

Code injection attacks function by hijacking a tar-

get program’s control ﬂow, redirecting it to a code

payload that would have been smuggled inside its

memory space disguised as input data (Van der Veen

et al., 2012). Exploitation of buffer overﬂow and

dangling pointer bugs in C/C++ applications are tar-

gets for such attacks. This is also the case for web

applications, that although typically associated with

higher level programming/scriptinglanguages, are ul-

timately executed on top of C-written application

servers. Still, web applications add two further levels

in which code injection exploitable ﬂaws can be intro-

duced. These are the script and the (command) shell

levels, where the injected payloads contain server-

side script statements (e.g. PHP) or shell command

sequences (e.g. Bash), rather than machine code (see

section 2.1). The end result of code injections extends

beyond tampering with the vulnerable web applica-

tion and can lead to the entire hosting infrastructure

to be compromised. The situation is further aggra-

vated when one considers how popular web program-

ming languages seem to facilitate the introduction of

security vulnerabilities in application code, and which

is further magniﬁed when the same vulnerable appli-

cation is deployed at multiple sites. One notorious

example is PHP. This is the language in which, for

example, the popular phpBB, Joomla and WordPress

applications are written in. When one considers that

there are million of sites hosting them, the impact of

just a single ﬂaw alone could already be devastating.

On the network level, the state-of-the-art detec-

tion options for web code injection attacks is still

that of signature-based intrusion detection systems

(IDS). Whether web-speciﬁc

or part of a more

generic network IDS having HTTP support

, their

static analysis-based mechanism poses the main lim-

itation. Code payloads, at any of the three injection

levels, can be encoded in ways to express the same

runtime behavior while coming across as completely

different to an IDS, thus evading detection. Com-

plementing static analysis with dynamic analysis is

a well-known answer for addressing this issue, pos-

sibly applied at the host or the network level. At

the host level, program runtime monitoring could be

used in a way to keep track of sequences of system

calls, keeping an eye for ones known to be produced

by attack payloads or malware (Srivastava and Gifﬁn,

www.modsecurity.org

www.snort.org

Bellizzi J. and Vella M..

WeXpose: Towards on-Line Dynamic Analysis of Web Attack Payloads using Just-In-Time Binary Modiﬁcation.

DOI: 10.5220/0005502600050015

In Proceedings of the 12th International Conference on Security and Cryptography (SECRYPT-2015), pages 5-15

ISBN: 978-989-758-117-5

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

2010), or else differing from what the application un-

der normal conditions should produce (Maggi et al.,

2010). Other options could even foil successful in-

jection by blocking control ﬂows that do not abide to

expected program behavior (Wang and Jiang, 2010),

or even change the processor’s instruction set in order

to render the injected payloads useless (Portokalidis

and Keromytis, 2010). Whichever option, host-level

solutions are bound to introduce runtime overheads.

On the network level, the use of instruction set em-

ulators seems, at ﬁrst glance, applicable (Polychron-

akis et al., 2006) (section 2.2). In this approach,

suspect machine code fragments are emulated, rather

than executed, in order to allow for safe examina-

tion of potential malware. An obvious hurdle is that

existing solutions are built with machine code pay-

loads in mind and would therefore require adaptation

to accommodate the other two payload types. A more

fundamental limitation is presented by performance.

Since emulation is essentially software implementa-

tion of hardware instructions, the unavoidable blow-

up in the number of CPU cycles when compared to

native execution render this technique impractical for

an on-line setting. Essentially, the resulting web IDS

would start lagging behind the monitored web server

so much so as to void its purpose.

This work proposes the use of just-in-time (JIT)

binary modiﬁcation as the basis of a solution to en-

hance web IDS with dynamic analysis capabilities,

providing resistance to code obfuscation-based eva-

sion. The essence of JIT binary modiﬁcation lies in

dynamically modifying instruction traces on the ﬂy,

immediately before execution (Bruening et al., 2012)

(section 2.3). Native instruction execution used by

JIT binary modiﬁcation addresses the limitations of

instruction set emulation regarding CPU cycle blow-

up and non-machine code payloads, while dynamic

instrumentation could provide the required isolation.

The use of ’payload starting-point’ heuristics is pro-

posed as a way to economize on dynamic analysis

in order to bring down computational costs (section

3). A prototype implementation, WeXpose, was eval-

uated on attack and benign web trafﬁc generated by a

widely-used penetration testing framework and PHP

applications (section 4). Results show that WeXpose

is resistant to code obfuscation for all three types of

web code injections through secure dynamic analy-

sis. Performance results show that the employment

of payload starting-point heuristics is compulsory for

practicality. Yet, real-time alerting can only be at-

tained at a substantial additional cost in terms of com-

putational power.

This work makes the following contributions:

• Demonstrates how JIT binary modiﬁcation can be

used to provide web IDS with dynamic analysis

capabilities, as well as to isolate harmful effects

of the analyzed attack payloads.

• The use of ‘payload starting-point’ heuristics as a

way to economize on dynamic analysis.

• WeXpose - a prototype implementation of a web

IDS having dynamic analysis capabilities.

2 BACKGROUND

2.1 Web Code Injection Target Levels

and Obfuscation

Web applications can be targeted at three levels: the

i) the infrastructure, ii) server-side scripting and the

iii) command shell levels. At the infrastructure level

one ﬁnds the execution of, typically, a compiled

C/C++ code-base that makes up the web server pro-

cess as well as the runtime environments supporting

web application level-code. Code injection attacks

exploiting this level use payloads made up of ma-

chine instruction sequences and that can be obfus-

cated, amongst others, by XOR’ing the payload bytes

with a bit-string of the same length (Erickson, 2008).

Listings 1 and 3 show one example. In this exam-

ple the attack payload starts immediately after

var1=

Given that in their majority the attack bytes do not

correspond to printable characters the attack payload

is mostly URL-encoded as per HTTP (

followed by

the hexademical representation of each byte). In any

case, the sequence only makes sense once disassem-

bled as partly shown in listing 2. A typical IDS signa-

ture in this case would focus on the attack string rather

than on the rest of the non-attack exclusive bytes, as

otherwise false alerts would ensue. However the ob-

fuscated version shown in listing 3 is totally different

from the original payload and would therefore evade

detection.

POST / HTTP/ 1 . 1

. . SNIP . . .

Content−Type : a p pl i c a ti o n / x−www−form−urle ncoded

var1=%BD%3C%0As1%DB%C7%D9t%24%F4%5E%2B%C9%B1%0B

%83%C6%041n%0E%03R%04%91%C4%C0%13%0D%BE . . . SNIP

. . .

Listing 1: Original infrastructure-level attack.

0: bd 3c 0a 73 31 mov ebp ,0 x31730a3c

5: db c7 fcmovnb st , st ( 7)

7: d9 74 24 f4 fn ste nv [ esp −0xc ]

. . . SNIP . . .

Listing 2: Attack payload disassembly.

SECRYPT2015-InternationalConferenceonSecurityandCryptography

POST / HTTP/ 1 . 1

. . . SNIP . . .

Content−Type : a p pl i c at i o n / x−www−form−u rlenc oded

var1=%BB%8DA%08%21%DB%C5%D9t%24%F4X3%C9%B1

%26%83%C0%041X%0E%03%D5O%EA%D4%5BM%3E%090%88...

SNIP . . .

Listing 3: Obfuscated infrastructure-level attack using

XOR-encoding.

Web applications hosted on top of compiled in-

frastructure code are typically written in higher-level

languages (e.g. Java, C#) or scripts (e.g. PHP,

Ruby). While avoiding memory corruption vulnera-

bilities this level is still prone to code injections that

target server-side scripting. Due to their interpreted

nature, scripting languages tend to allow the dynamic

creation of script statements and which are then exe-

cuted on the ﬂy, e.g.

eval()

in PHP. Whenever user-

supplied inputs are passed on to these dynamic eval-

uation functions without proper checks, the avenue

for injecting server-side script payloads is created.

Another opportunity for such injections is provided

whenever application code does not check the content

of uploaded ﬁles, that can turn up containing server-

side scripts. Obfuscation techniques in this case could

simply comprise the use of legitimate script obfusca-

tion tools intended for source code protection. One

such example is shown in listings 4 and 5 where a se-

quence of PHP string functions and variable renam-

ings alter the original attack string. Note that contrary

to listings 1 and 3, here the payloads consist of script

statements rather than machine instructions.

POST / upload . php HTTP/1. 1

. . . SNIP . . .

−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−f13a0bf78a1b

Content−D i s po s i t i o n : form−d a ta ; name=” a t t a c h ”

<?php $c =ba se64 dec ode (”

Y2F0IC9ob21lL2plbm5pZmVyL2hvc3QuYyA+

IG15ZmlsZTEudHh0 ”) ; @ s et tim e lim it (0) ;

@i g no re use r a b or t ( 1) ; i n i s e t ( ’

max exec ution time ’ , 0) ; $AtBa= @ini g et ( ’

d i s a b l e f un c t i o n s ’ ) ; i f ( ! empty ( $AtBa ) ) { $AtBa=

p re g r e p l a ce ( ’ / [ , ] + / ’ , ’ , ’ , $AtBa ) ; $AtBa=

explo de ( ’ , ’ , AtBa ) ; $AtBa=array map ( ’ trim ’ , $AtBa

) ; } el s e { $AtBa= a rr ay () ; } i f (FALSE!== s t r p o s (

s t r t o l ow e r ( PHP OS) , ’ win ’ ) ) { $c=$c .” 2>&1\n ”;}

. . . SNIP . . . ?>

−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−f13a0bf78a1b−−

Listing 4: Original server-side script-level attack.

POST / upload . php HTTP/1. 1

. . . SNIP . . .

−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−3 a6 54fbccf08

<?php $ f fc e0=b ase 64 decode ( base 64 deco de ( ’

WTJGMElDOW9iMjFsTDJwbGJtNXBabVZ5TDJodmMzUXVZ

eUErSUcxNVptbHNaVEV1ZEhoMA== ’) ) ; @ s e t tim e l i mi t

(0 ) ; @ ig nor e u s er ab o rt (1 ) ; @ ini s e t ( ba se6 4 decode

( ’ bWF4X2V4ZWN1dGlvbl90aW1l’ ) ,0) ; $vika1 = @ini get (

base64 d ecod e ( ’ZGlzYWJsZV9mdW5jdGlvbnM = ’) ) ; i f (!

empty ( $vika1 ) ) { $vika1= pr e g r e p l a c e ( ba se6 4 decode

( ’ L1ssIF0rLw== ’) , ba se64 decode ( ’LA== ’) , $vika1 ) ;

$vika1 =explo de ( base64 de code ( ’LA== ’) , $vika1 ) ;

$vika1 =array map ( bas e64 dec ode ( ’ dHJpbQ== ’) ,

$vika1 ) ;} e l s e { $vika1 = a rr a y ( ) ;} i f (FALSE !== s t r p o s

( s tr t ol o we r ( PHP OS ) , bas e64 dec ode ( ’ d2lu ’ ) ) ) {

$f fc e 0= $ ff ce 0 . b ase 64 decode ( ’ IDI+JjEK ’ ) ; } . . .

SNIP . .. ? >

−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−3a654fbccf08 −−

Listing 5: Obfuscated server-side script-level attack using

string manipulation and variable renaming.

Server-sidescripting environmentstend to support

functions that let programmers call shell commands

from within scripts, e.g. PHP’s

exec()

function,

which can be exploited in a similar manner to server-

side script injections. The only difference is that

attack payloads are made up of shell command se-

quences rather than script statements. Obfuscation

can be applied throughthe use of alternate commands.

For example, in order to overwrite the content of

index.php

as part of a defacement attack, an attacker

could utilize the

echo

command (with redirected stan-

dard output) as per payload in listing 6. However, the

same outcome is achieved if an attacker had to upload

a ﬁle that is copied over

index.php

’s content using

the

cat

command as shown in listing 7.

GET / mainpage . php? a=some%3Becho%20%3E%20in dex .

php HTTP/ 1 . 1

. . . SNIP . . .

Listing 6: Original command shell-level attack.

GET / mainpage . php? a= ot h er%3Bcat%20malupload%20%3

E%20inde x . php HTTP/ 1 . 1

. . . SNIP . . .

Listing 7: Obfuscated shell-level attack that uses an

alternate command.

2.2 Attack Payload Emulation

Attack payload emulation is a malware analysis task

where the use of processor emulators becomes handy

as they can protect from harmful side-effects caused

by payload execution (Egele et al., 2012; Polychron-

akis et al., 2006; Kruegel, 2014). Processor emulators

essentially provide a software implementation for de-

coding and executing machine instructions, with the

consequential slow-down in execution performance.

Emulation is restricted to the instructions making up

the payload being analyzed. In particular, any calls to

external code such as calls to functions inside linked

WeXpose:Towardson-LineDynamicAnalysisofWebAttackPayloadsusingJust-In-TimeBinaryModification

libraries or traps to kernel code, are merely simulated

in order to keep emulation going further in a best ef-

fort attempt. While providing the required isolation

this method would be problematic if it had to be used

for non-machine code payloads. Emulation of script

or shell command-based payloads would require the

execution of their correspondinginterpreter/shell with

the payload as input. However a best effort execution

approach does not sufﬁce for the successful emulation

of interpreter code. Concluding, the use of processor

emulators for web attack payloads seems inadequate

and a more suitable approach is needed.

2.3 Binary (code) Instrumentation

JIT binary modiﬁcation is a way to carry out dy-

namic binary instrumentation, where the object code

of a program is extended or modiﬁed in-memory dur-

ing runtime. Instrumentation granularity varies from

function/system call entry/exit points to the individual

instruction level e.g. DynamoRIO, PIN. At runtime,

instructions making up the execution trace are ﬁrst

copied to a code cache where they can be manipulated

prior to execution. An analysis application using JIT

binary modiﬁcation has total control over the execu-

tion trace given that every instruction is bound to pass

through the code cache and any necessary modiﬁca-

tion can be applied. This may not be the case in other

instrumentation approaches, say in-place re-writing

(e.g. Detours). Say some application that is inter-

ested in instrumenting all calls to

a function()

used

in-place re-rewriting at the start of execution, any dy-

namically generated calls to this function would be

completely missed.

JIT binary modiﬁcation presents an interesting op-

tion for the on-line dynamic analysis of attack pay-

loads required for our solution given that it carries

out native execution. Therefore the slow-down and

script/command payload issues associated with a pro-

cessor emulator approach can be avoided. Further-

more, JIT binary modiﬁcation provides the opportu-

nity to modify the analyzed payloads in a manner so

that harmful side effects can be isolated. Therefore

JIT binary modiﬁcation provides a promising founda-

tion for the dynamic analysis of web attack payloads,

yet not a complete solution per se. In particular, any

form of dynamic analysis is always bound to be more

computationally expensive than plain static analysis

of network packet content, and thus further thought is

required to render the complete solution suitable for

an on-line setting.

3 ON-LINE EXTRACTION AND

SECURE DYNAMIC ANALYSIS

OF WEB CODE INJECTION

PAYLOADS

The proposed JIT binary modiﬁcation-based tech-

nique for providing an obfuscation resistant Web

IDS is embedded inside an HTTP-aware network

level IDS, code-named WeXpose, deployed out-of-

line from the protected web server, as shown in ﬁgure

1, that imposes no runtime overheads. Once network

packets are captured and ﬁltered by the packet ﬁlter-

ing sub-system of the network router, they are passed

through the following processing stages:

Stream Reassembly. The individual network packets

making up an HTTP request must ﬁrst be prop-

erly reassembled according to the TCP protocol.

This is required because a single request could be

split into multiple network packets that arrive out

of order.

Attack Vector Extraction. The strings that belong to

HTTP header or body ﬁelds that could embed at-

tack payloads are extracted for individualprocess-

ing.

Payload Start Position Identiﬁcation. Attack payloads

are not expected to appear at the very start of

an attack vector. Therefore in order to conduct

successful dynamic analysis all possible starting

points of a payload have to be considered. Since

brute-forcing all positions would be wasteful, this

stage makes use of payload starting-point heuris-

tics to reduce the number of dynamic analysis at-

tempts.

JIT Binary Modiﬁcation. Each candidate payload

from the previous step is dynamically analyzed

for the presence of any of three possible types of

injection payloads in a secure manner.

Behavior-based Detection and Recovery Guidance.

System call traces are expected to be produced

only by actual payloads rather than by content

that happens to coincide with a decode-able

instruction sequence. This reasoning derives from

the fact that data content wrongly interpreted as

machine instructions, scripts statements or shell

commands, very improbably results in setting

up system calls. Therefore the presence of such

traces can be used as the basis for detection

besides containing valuable information to trigger

recovery. Static analysis-based signatures could

also be generated for the detected payloads to

promptly detect re-occurrences.

SECRYPT2015-InternationalConferenceonSecurityandCryptography

 













 !

" 













 #

$

%!





&%!







Figure 1: WeXpose’s deployment and web trafﬁc analysis

stages.

This setup assumes that WeXpose has access to

an unencrypted web trafﬁc stream, which is a re-

quirement shared by all network-level IDS, and there-

fore encryption proxies must be used. The remaining

part of this section presents the details for individ-

ual stages. Design decisions are scoped in terms of

the common Internet-facing platform: x86

64/Linux

(with Bash) and an Apache/PHP-based web applica-

tion server. Given that TCP stream re-assembly is a

well-known procedure that is implemented in readily-

available tools (e.g. tcpﬂow), explanation proceeds

immediately to the second step.

3.1 Attack Vector Identiﬁcation

Attack vectors are chosen on the basis of how HTTP

GET and POST requests are expected to be processed

by web and application server processes. For exam-

ple in the case of a GET request (see ﬁgure 2), the

entire ﬁrst line is expected to be loaded in a buffer to

be parsed in its entirety by web server code. Once

parsed, the URL sub-string could be parsed on its

own and thus copied to a separate buffer to assist in

fetching the required resource, while the query string

in its entirety or as separate query string argument/-

value pairs could be required by application server

scripts. Finally, a query string value could also in-

clude URL (percent) encoding for control characters

requiring escaping. However, both the encoded and

decoded strings are expected to be processed at one

stage or another when processing a request. There-

fore multiple vectors can be produced from a single

string.

The list of all vectors and encodings that are taken

into consideration are the following:

HTTP GET Requests:

• GET request ﬁeld: Full request line, URL, query

string, individual query string argument/value

0,12345642647&727

&-

Figure 2: Attack vector identiﬁcation - a single request ﬁeld

generates multiple attack vectors (as per delineation).

pairs, individual values. Applicable encoding:

URL encoding.

• Cookie ﬁeld: Full string, individual value pairs,

individual values.

• All other request ﬁelds: Full strings.

HTTP POST Requests:

• All vectors applicable to HTTP GET requests.

•

application/x-www-form-urlencoded

payload

: Full payload string, individual ar-

gument/value pairs, individual values. Applicable

encoding: URL encoding.

•

multipart/form-data payload

: Full payload,

name/values of each individual part, content

of each individual part. Applicable encoding:

base64.

3.2 Payload Start Position Identiﬁcation

Payload start position identiﬁcation is carried out us-

ing payload starting-point heuristics, deﬁned on the

basis of content that has to be present within payloads

even when obfuscated. For machine code payloads,

heuristics focus on instructions that enable position-

independent execution. This condition holds particu-

larly for obfuscated payloads where a perpended de-

coder is required to reference the encoded payload ir-

respective of its absolute position in memory (Siko-

rski and Honig, 2012). In the case of 32-bit pay-

loads, sequences of instructions referred to as Get

PC instructions are typically used to get the program

counter. They operate the same overall 3-step strat-

egy: 1- Call an instruction that places the value of the

program counter in memory; 2 - Retrieve the value

and load in some register; 3 - Reference a ﬁxed off-

set from its current value where the encoded payload

is expected to be found. The are two classes of such

sequences: those that leverage the call instruction and

those that leverage instructions that save the FPU state

fsave

fnsave

fxsave

fstenv

fnstenv

. 64-bit

payloads have the luxury of utilizing RIP-relative ad-

dressing, meaning that the operands of data ﬂow in-

structions can be deﬁned in terms of ﬁxed offsetsfrom

the program counter. Thus, no Get PC instruction se-

quences are required even if it is possible that these

are utilized just the same.

WeXpose:Towardson-LineDynamicAnalysisofWebAttackPayloadsusingJust-In-TimeBinaryModification

A third way to write position independent attack

payloads in both 32 and 64-bit modes is when any

other user-level accessible register other than the pro-

gram counter can be utilized in the same manner. In

such cases no special provisions must be taken by at-

tack authors other than making sure not to write to

such registers before reading them. In this case the

identiﬁcation of possible position-independent code

is more difﬁcult. Therefore an alternate strategy is

taken based on the presence of a decoder, expected to

require a loop construct implemented with some con-

trol transfer instruction -

loop

call

jmp

jxx

. Given

these observations, the payload starting-point heuris-

tics for the infrastructure level are:

• Get PC instruction opcode,

• Instruction with a RIP-relative addressing bit se-

quence,

• Control transfer instruction opcode.

input : av (the attack vector),

lst = [start

, start

, ..., start

]

begin

for i=0 to n-1 do

next av = substring(av, lst[i],

length(av)-lst[i])

JIT

binary modify(next av);

end

Algorithm 1: Send attack vectors to the JIT binary modiﬁ-

cation step.

This same procedure is repeated for the remain-

ing two injection levels: the script and shell command

levels. In these two cases heuristics are based on the

requirement that certain control characters must be

present so that the target application server or com-

mand shell gets confused and starts considering input

data following these special characters as script state-

ments or shell commands. Thus, any characters im-

mediately following these characters provide suitable

start positions for payloads. In the case of script-level

(PHP) injection the heuristic is:

• Character following a semi-colon (

;

For the command shell-level (Bash) these are:

• Character following a semi-colon (

;

• Character following a pipe (

• Character following a back-tick (

‘

3.3 JIT Binary Modiﬁcation

Figure 3 shows the process for dynamic analyzing

candidate attack payloads based on JIT binary modi-

ﬁcation. The ﬁrst step prepares the execution environ-

ment that replaces the exploited process (step 1). This

host process is created from a simple binary contain-

ing just dummy instructions required to kick-start the

JIT binary modiﬁcation process, the operating sys-

tem’s runtime (e.g. libc), and the mapped JIT binary

modiﬁcation engine. WeXpose makes use of the Dy-

namoRIO runtime code manipulation framework to

implement this part.

 

'

(

push …

call …

mov …



 

)

push …

mov …

call …

mov …





 

*

+



,!



-.#/.  









Figure 3: The dynamic analysis host process and steps.

For each identiﬁed starting position inside an at-

tack vector the candidate payload is mapped into the

host process (step 2). In the case of machine code

payloads these are read from an input stream and

placed in an executable location on the heap (set up

using

mmap()

and

mprotect()

). In the case of script

and shell command-level payloads the host processes

actually consist of the entire interpreter/shell pro-

cesses executed with the candidate payloads as input.

Once mapped, the candidate payload is transferred to

the code cache (step 3). In the case of machine code

payloads the JIT binary modiﬁcation engine prepends

an unconditional jump (

jmp

) to the dummy instruc-

tion trace, with the destination address being that of

the loaded payload. This modiﬁcation causes the pay-

load instructions to be loaded in the code cache next.

In the case of script and shell command payloads the

machine code instructions triggered as a result of the

parsed script/commandseventually also get loaded in-

side the code cache.

Once loaded, the machine code instructions of

these candidate payloads are modiﬁed (step 4) for

three purposes: a) insertion of dynamic analysis in-

strumentation, b) favoring successful analysis, and

c) isolation of harmful side-effects. Instrumentation

SECRYPT2015-InternationalConferenceonSecurityandCryptography

consists of instruction sequences prior to all system

call instructions -

sysenter

syscall

int x80

that dump the system call number along any argu-

ments of interest into a log ﬁle. The current version

of WeXpose dumps full paths of opened ﬁles and ex-

ecuted commands, as well as IP addresses/port num-

bers of all attempted network connections.

While code injection payloads are expected to

be much more compact and less dependent on

environment-based triggers as compared to stand-

alone malware, inﬁnitely running payloads and ones

that put the host process in a blocked state could

still thwart analysis - say a payload that inﬁnitely at-

tempts to establish a connection to a remote server

from where to download a backdoor malware, or

one that establishes a listening socket and blocks

on accepting incoming connections. Therefore JIT

binary modiﬁcation also keeps an execution count

for each instruction. When the execution count of

some instruction exceeds a conﬁgurable threshold,

dynamic analysis is terminated through the addition

of an

exit()

library call. The same mitigation is

followed when an

accept()

blocking system call is

encountered. Handling of

read(socket,...)

and

recv

recvfrom

recvmsg()

system calls is not nec-

essary given further modiﬁcations applied to ﬁle and

networking operations which are explained next.

The last set of binary modiﬁcations isolate mali-

cious behavior. They are thought out in a way to ren-

der the payloads harmless while at the same time not

compromising analysis. Speciﬁcally:

• Re-direction of ﬁle output - File writing opera-

tions have their ﬁle descriptors substituted with

one associated with an open dummy ﬁle, pur-

posely created so that no application/system ﬁle

gets compromised. Re-direction is chosen over

out-right blocking given that such ﬁle operations

could occur very early during payload execution,

compromising analysis.

• Blocking of network connection attempts - Net-

work connection establishment is considered to be

such a security-critical operation that is actually

stopped right away. Given the detection/identiﬁ-

cation approaches we take (see section 3.4), at this

point of execution the payload’s behavior would

already have been substantially uncovered.

• Deleting system calls that modify permis-

sions/privilege levels - In the case that a

chmod()

chown()

seteuid()

setegid()

setfs

uid()

setreuid()

setregid()

system call is

encountered, the respective instruction is deleted

from the instruction trace. Execution resumes in

a best effort approach without compromising the

security of the machine hosting WeXpose.

The ﬁnal step (step 5) consists of native execu-

tion. Importantly, the JIT binary modiﬁcation engine

is also mapped in any child processes spawned by the

payload so that the full system call trace is generated.

3.4 Behavior-based Detection and

Recovery Guidance

Instrumentation instructions prior to system calls cre-

ate log ﬁle entries that in case of attack payloads pro-

duce a system call trace. Listing 8 shows a fragment

of an example log ﬁle produced for the attack previ-

ously introduced in listing 4. An alert is raised every

time that such a log ﬁle is produced. Additionally an

alert is also raised for every dynamic analysis attempt

that is terminated prematurely due to the aforemen-

tioned inﬁnite execution/blocking and isolation mea-

sures. This trace by itself already contains valuable

information to guide recovery from an attack, e.g. the

potential compromise of passwords whose hashes are

stored in

/etc/passwd

in the case of listing 8. A pos-

sible recovery procedure therefore consists in reset-

ting all of them.

Executable C onte nt Found in : <?php $c =

base64 d ecod e (”

Y2F0IC9ob21lL2plbm5pZmVyL2hvc3QuYyA +

IG15ZmlsZTEudHh0 ”) ; . . . SNIP . . .

. . . SNIP . . .

System C a ll : f cn t l 6 4

System C a ll : s e t r o b u s t l i s t

System C a ll : c l os e

System C a ll : dup2

System C a ll : c l os e

System C a ll : execve , Executing F i l e : / bin / sh ,

Command : c at / et c / passwd > myfile1 . t xt

System C a ll : read , F i l e D e sc r ip to r used : 6

System C a ll : c l os e

System C a ll : w ai tpi d

. . . SNIP . . .

Type : S c r i p t I n j e ct i o n , Found in F i l e :

127. 000. 000. 001. 39306 −127.000.000.001.01575

Listing 8: A (fragment of a) suspicious system call trace

generated by the execution of an attack vector containing

a code injection payload.

PASSWD ATTACK:− System C a ll : c lo s e \nSystem C a ll :

dup2 ( . ∗ ? ) System C a ll : execve , ( . ∗ ? ) / etc / passwd

( . ∗ ? ) \ nSystem Ca ll : read , ( . ∗ ? )

Listing 9: Behavior signature.

System call traces can also form the basis for

behavior signatures so that any re-occurrence of the

same attack that is disguised with obfuscation would

still be identiﬁed as a re-occurrence of a known at-

tack. In this manner the same recovery procedure

WeXpose:Towardson-LineDynamicAnalysisofWebAttackPayloadsusingJust-In-TimeBinaryModification

could be applied without the need of having to re-

examine the log ﬁle. Listing 9 shows an example be-

havior signature (

PASSWD ATTACK

) made up of a reg-

ular expression deﬁned over the trace in listing 8, and

that matches the obfuscated version previously pre-

sented in listing 5. Its trace log ﬁle is shown in listing

10. It is noteworthy that despite the different payload

content the same system call trace is still produced

by dynamic analysis, and which therefore matches

the predeﬁned signature. Furthermore all detection

logs include the attack vector in which the payload

was found, providing the basis for generating a static

analysis-based IDS signature enabling the fast detec-

tion of re-occurrences of the exact same attack.

Executable Content Found in : <?php $ ff ce 0=

base64 d ecod e ( base 64 dec ode ( ’

WTJGMElDOW9iMjFsTDJwbGJtNXBabVZ5TDJodmMzUXVZeUEr

SUcxNVptbHNaVEV1ZEhoMA== ’) ) . . . SNIP . . .

. . . SNIP . . .

System C a ll : c l os e

System C a ll : dup2

System C a ll : c l os e

System C a ll : execve , Executing F i l e : / bin / sh ,

Command : ca t / e tc / passwd > my file1 . t x t

System C a ll : read , F i l e D e sc r ip to r used : 6

. . . SNIP . . .

Type : S c r i p t I nje ct i o n , Found in F i l e :

127. 000. 000. 001. 55528 −127.000.000.001.01575

Match : PASSWD ATTACK

Listing 10: Behavior signature match.

4 EVALUATION

WeXpose’s capabilities of conducting secure dynamic

analysis in an on-line setting, and therefore its capa-

bility of detecting evasive attacks, was evaluated us-

ing attack trafﬁc generated by the Metasploit Frame-

work (MSF). MSF is a widely used penetration test-

ing framework that incorporates exploits for various

vulnerabilities as well as realistic payloads and en-

coders for their obfuscation. Benign trafﬁc is made

of up HTTP requests derived from browsing sessions

of phpBB and Joomla, two widely deployed PHP ap-

plications and so deemed representative. A number

of case studies based on a combination of this trafﬁc

were used to qualitatively evaluate the approach, pro-

viding the opportunity to closely observe how it re-

sponds to scenarios that are representativeof expected

deployments.

4.1 Obfuscation Resistance with Secure

Dynamic Analysis

The ﬁrst set of case studies veriﬁed the expected ben-

eﬁt of obfuscation resistance stemming from the em-

ployment of dynamic analysis. Tables 1 and 2 show

the utilized exploits and payloads for the attacks. All

three levels of code injection are covered.

Table 1: Exploits.

Exploited vulnerability Injection

level

PeerCast Remote Buffer Overﬂow Machine

code

Bugtraq: 1704

Mitel Audio and Web Conferencing

Command Injection

Shell

OSVDB: 69934

WeBid Multiple Remote PHP Code In-

jection

Script

Bugtraq: 48554

Wordpress Asset Manager Plugin ‘up-

load.php’ Arbitrary File Upload

Script (ﬁle

upload)

Bugtraq: 53809

Table 2: Attack payloads and obfuscation.

Injection Payload Obfuscation

Binary

Shell

XOR encoding

(shikata

ga nai)

Shell Defacement (ﬁle-

overwriting in web-path)

Alternate

commands

Script Information leakage

(/etc/passwd copy to

web-path)

Base64

In all cases the obfuscated attacks were detected

successfully whilst dynamic analysis was conducted

securely. Listing 11 shows the detection of the shell

payload where dynamic analysis is terminated prior

to the

accept()

system call. Listing 12 shows the

detection of the defacement payload. Here, the ﬁle

descriptor intended for output (0) was replaced by

one (7) associated with a dummy ﬁle opened by the

JIT binary modiﬁcation engine. The same isolation

technique is also triggered for the information leakage

payload as shown in listing 13. Furthermore, the call

setreuid()

was logged but subsequently deleted

from the instruction trace.

Executable C onte nt Found in : 1\DB\ F7\ E3SCSj#\89\

E1\ B 0 f [ ˆ Rh#\00#\ j #QP\89\ E 1 j f X \89A#\B3#\

B 0 f C \ B 0 f \93 Yj? X I y \ F8h / / shh / b in \89\E3PS\89\

E1\B0# \00

System C a ll : s ys s o c k e t

System C a ll : sys b ind , Socket Number : 5 , Po rt

Number : 4444 , IP Address : 0 . 0 .0 . 0

System C a ll : s y s l i st e n

System C a ll : s ys a c c e p t

Dynamic a n al y s is STOPPED

Type : Sh ellc ode I n j e c t i o n , Found in Fi l e :

127. 000. 000. 001. 55669 −127.000.000.001.01575

Match : ACCEPT ATTACK

Listing 11: Isolation of the shell payload.

SECRYPT2015-InternationalConferenceonSecurityandCryptography

Executable Content Found in : c at > index . php

System C a ll : execve , Executing F i l e : / bin / c at

. . . SNIP . . .

System C a ll : fa d vi s e64 6 4

System C a ll : read , F i l e D e sc r ip to r used : 0

System C a ll : write , F i l e D esc rip to r att em pt : 1

used : 7

System C a ll : read , F i l e D e sc r ip to r used : 0

Type : Command I n j e c t i o n , Found i n Fi l e :

127. 000. 000. 001. 55541 −127.000.000.001.01575 NO

MATCH

Listing 12: Isolation of the defacement payload.

4.2 Performance

A further case study was carried out to measure

WeXpose’s performance in terms of analysis times

and false positives. Measurements were taken

for browsing sessions from phpBB and Joomla.

Both sessions included a run-through of the main

functionality of each application using authenticated

crawling. Results are shown in table 3. The third

column shows the analysis time taken by WeXpose

using the starting-point heuristics as compared to

brute-forcing. The times for the brute-force approach

shown in brackets indicate that despite native execu-

tion WeXpose would have never been ﬁt for on-line

usage without the inclusion of the starting-point

heuristics. Their employment drastically bring down

analysis time considerably. Yet when comparing

to the time taken by the web server to process the

web requests (second column) the difference is still

signiﬁcant. In phpBB’s case analysis time is x24.25

while in the case of Joomla it is x31.24 the time taken

by web server request processing. These measure-

ments show that analysis time is application-speciﬁc.

The number and size of attack vectors are in fact

expected to vary between applications and as a

Executable Content Found in : mode= A /4<91>=J

,<93><90> F 7 ˆCP ˆLˆV1 ˆ ˆ ˆ A <85>

u 2 <99><80>;ˆ v ˆ ˆ5 / ˆ C

<88>< 5 − ł )<95> K ˆ x <91>‘ $ N ˆ

U J <8f >; > <82> $ ˆL= <89>Y& |

v ˜ L Q ˆV<94> ˆ H a ˆ? @ ˆM. ”ˆ XˆU<89>ˆW] ˆ ?(

<93>ˆ@∗ ˆA ˆ@

System C a ll : s e tr e ui d

System C a ll : open , F i l e Opened : / et c / / passwd

. . . SNIP . . .

System C a ll : write , F i l e D esc rip to r att em pt : 5

used : 7

System C a ll : e x i t

Type : Sh ellc ode I n j e c t i o n , Found in F i l e :

127. 000. 000. 001. 55747 −127.000.000.001.01575 NO

MATCH

Listing 13: Isolation of the information leakage payload.

Table 3: Analysis time and false positives for benign trafﬁc.

Application Web server

processing (s)

Analysis for

heuristics/

brute-force (s)

phpBB 2.16 52.6/≈3,600 0

Joomla 4.29 56.8/≈32,700 0

consequence they affect analysis time. The conse-

quence here is that detection alerts are delayed, or

conversely, alerts are not raised in real-time.

While performance results beg for improvement

before real-time detection can be provided, WeX-

pose’s implementation could be trivially parallelized

since each HTTP request could be analyzed by differ-

ent processing cores. An analysis/server processing

time difference of say x31, as in phpBB’s case, could

be brought down to a minimum if 31 cores had to used

for every web request-serving core. Furthermore, de-

tection response times that are inferior to real-time

could still be practical in deployments where web ap-

plication usage is not uniform, giving space for WeX-

pose to catch-up during phases of low usage. Overall,

given the substantial impact of the heuristics on analy-

sis times we can conclude that these provide sufﬁcient

conﬁdence that further work in this direction could

bring down the costs for real-time detection. Oppor-

tunities for smarter heuristics lie for example in terms

of ﬁltering out duplicate attack vectors. Beyond this

low-hanging fruit, mining for payload starting posi-

tions within exploit databases could potentially pro-

vide valuable feedback in this regard.

4.3 Limitations

The current version of WeXpose only considers self-

contained attack payloads, however there is a class

of attacks, typically referred to as code reuse attacks,

whose payloads do not contain the code to be injected

but rather pointers to existing code. This class of at-

tacks includes Return-Oriented-Programming (ROP)

exploits that reuse already mapped application ma-

chine code, and Remote-File-Inclusion (RFI) attacks

that force the target application to retrieve server-side

scripts from external attacker-controlled sites. The

JIT binary modiﬁcation approach sets the basis for

extending the current design with analysis host pro-

cesses that completely replicate the web application

server processes. The toughest overall limitation for

WeXpose constitutes split code-injection attacks (Ab-

basi et al., 2014).

WeXpose:Towardson-LineDynamicAnalysisofWebAttackPayloadsusingJust-In-TimeBinaryModification

5 RELATED WORK

Malware and attack payload analysis options are

available at multiple levels. The use of instruction

set emulation is suitable for shellcode emulation due

to their typical self-contained nature (Polychronakis

et al., 2006). However, this same assumption presents

this approach with its weakest point (Shimamura and

Kono, 2009). Standalone malware requires the use

of full system emulators to examine given that this

type of malware typically manipulates kernel-level

data structures in order to attain stealth and persis-

tence (e.g. rootkits) (Yin et al., 2010). An interesting

alternative to full system emulation was proposed in

terms of extending hypervisors that make use of hard-

ware virtualization extensions. Its beneﬁt lies in the

speed-up over the notoriously slow full system emu-

lation method (Snow et al., 2011). The advent of web-

based and mobile applications brought with it a breed

of malware that executes at the level of web brow-

ers, ﬁle format parsers, interpreters and process vir-

tual machines. This type of malware is best analyzed

by instrumenting/emulating their corresponding run-

time environments (Cova et al., 2010; Schreck et al.,

2013; Weichselbaum et al., 2014).

Web IDS efforts mainly focus on detecting SQLi

and XSS attacks due to the frequent occurrences of

the software ﬂaws they exploit as well as the ease with

which they can be created. Dynamic taint tracking is a

program information ﬂow technique that has attracted

the most attention in this regard (Xu et al., 2006; Vogt

et al., 2007; Sekar, 2009; Tripp et al., 2009). In the-

ory this technique could also be suitable to detect web

code injections at the shell and script levels due to

the similar exploitation techniques shared with SQLi

and XSS attacks. Yet, these host-level methods in-

evitably impose runtime overheads. Furthermore, re-

cent ﬁndings exposed a number of severe limitations

(Afooshteh, 2014).

6 CONCLUSIONS AND FUTURE

WORK

This work set out tackling the problem of providing a

complementary dynamic analysis mechanism to static

analysis-based web IDS for the effective detection of

code injection attacks. The mainstream approach of

using processor emulators could not be used given

that the payloads in question may contain scripts or

shell commands other than machine instructions. Be-

sides, such emulators are not suitable for on-line set-

tings. The proposed solution was implemented in

WeXpose, that uses JIT binary modiﬁcation in order

to avoid the limitations associated with processor em-

ulation. The use of heuristics that identify the possi-

ble start positions of payloads further bring down the

computational cost of dynamic analysis that results

in delaying of alerts. Case studies show that WeX-

pose can detect obfuscated attacks, however real-time

alerting can only be attained at considerable addi-

tional costs in terms of the required computational

power.

Future work has to focus primarily on this prob-

lem, potentially by using smarter heuristics. As for at-

tack obfuscation resistance WeXpose can be extended

to also cover code reuse attacks, such as ROP and

RFI attacks. The JIT binary modiﬁcation approach

provides the ideal basis for further extension in this

direction given that it can provide WeXpose with ac-

cess to the replicated program image of the target web

server. With these enhancements in place WeXpose

will be subjected to a quantitative study.

REFERENCES

Abbasi, A., Wetzels, J., Bokslag, W., Zambon, E., and

Etalle, S. (2014). On emulation-based network intru-

sion detection systems. In Research in Attacks, Intru-

sions and Defenses, pages 384–404. Springer.

Afooshteh, A. N. (2014). Taintless. In Blackhat Arsenal.

Blackhat.

Bruening, D., Zhao, Q., and Amarasinghe, S. (2012). Trans-

parent dynamic instrumentation. In ACM SIGPLAN

Notices, volume 47, pages 133–144. ACM.

Cova, M., Kruegel, C., and Vigna, G. (2010). Detection and

analysis of drive-by-download attacks and malicious

javascript code. In Proceedings of the 19th interna-

tional conference on World wide web, pages 281–290.

ACM.

Egele, M., Scholte, T., Kirda, E., and Kruegel, C. (2012). A

survey on automated dynamic malware-analysis tech-

niques and tools. volume 44, page 6. ACM.

Erickson, J. (2008). Hacking: The art of exploitation. No

Starch Press.

Kruegel, C. (2014). Full system emulation: Achieving suc-

cessful automated dynamic analysis of evasive mal-

ware. In Proc. BlackHat USA Security Conference.

Maggi, F., Matteucci, M., and Zanero, S. (2010). Detecting

intrusions through system call sequence and argument

analysis. volume 7, pages 381–395. IEEE.

Polychronakis, M., Anagnostakis, K. G., and Markatos,

E. P. (2006). Network–level polymorphic shellcode

detection using emulation. In Detection of Intrusions

and Malware & Vulnerability Assessment, pages 54–

73. Springer.

Portokalidis, G. and Keromytis, A. D. (2010). Fast and

practical instruction-set randomization for commod-

ity systems. In Proceedings of the 26th Annual Com-

SECRYPT2015-InternationalConferenceonSecurityandCryptography

puter Security Applications Conference, pages 41–48.

ACM.

Schreck, T., Berger, S., and G¨obel, J. (2013). Bissam: Auto-

matic vulnerability identiﬁcation of ofﬁce documents.

In Detection of Intrusions and Malware, and Vulnera-

bility Assessment, pages 204–213. Springer.

Sekar, R. (2009). An efﬁcient black-box technique for de-

feating web application attacks. In NDSS.

Shimamura, M. and Kono, K. (2009). Yataglass: Network-

level code emulation for analyzing memory-scanning

attacks. In Detection of Intrusions and Malware, and

Vulnerability Assessment, pages 68–87. Springer.

Sikorski, M. and Honig, A. (2012). Practical Malware

Analysis: The Hands-on Guide to Dissecting Mali-

cious Software. No Starch Press.

Snow, K. Z., Krishnan, S., Monrose, F., and Provos, N.

(2011). Shellos: Enabling fast detection and forensic

analysis of code injection attacks. In USENIX Security

Symposium.

Srivastava, A. and Gifﬁn, J. (2010). Automatic discovery

of parasitic malware. In Recent Advances in Intrusion

Detection, pages 97–117. Springer.

Tripp, O., Pistoia, M., Fink, S. J., Sridharan, M., and Weis-

man, O. (2009). Taj: effective taint analysis of web

applications. volume 44, pages 87–97. ACM.

Van der Veen, V., Cavallaro, L., Bos, H., etal. (2012). Mem-

ory errors: the past, the present, and the future. In

Research in Attacks, Intrusions, and Defenses, pages

86–106. Springer.

Vogt, P., Nentwich, F., Jovanovic, N., Kirda, E., Kruegel,

C., and Vigna, G. (2007). Cross site scripting preven-

tion with dynamic data tainting and static analysis. In

NDSS.

Wang, Z. and Jiang, X. (2010). Hypersafe: A lightweight

approach to provide lifetime hypervisor control-ﬂow

integrity. In Security and Privacy (SP), 2010 IEEE

Symposium on, pages 380–395. IEEE.

Weichselbaum, L., Neugschwandtner, M., Lindorfer, M.,

Fratantonio, Y., van der Veen, V., and Platzer, C.

(2014). Andrubis: Android malware under the mag-

nifying glass. Vienna University of Technology.

Xu, W., Bhatkar, S., and Sekar, R. (2006). Taint-enhanced

policy enforcement: A practical approach to defeat a

wide range of attacks. In Usenix Security, pages 121–

136. USENIX.

Yin, H., Poosankam, P., Hanna, S., and Song, D. (2010).

Hookscout: Proactive binary-centric hook detection.

In Detection of Intrusions and Malware, and Vulnera-

bility Assessment, pages 1–20. Springer.

WeXpose:Towardson-LineDynamicAnalysisofWebAttackPayloadsusingJust-In-TimeBinaryModification
