Private Eyes: Secure Remote Biometric Authentication
Ewa Syta
1
, Michael J. Fischer
1
, David Wolinsky
1
, Abraham Silberschatz
1
, Gina Gallegos-Garc´ıa
2
and Bryan Ford
1
1
Department of Computer Science, Yale University, New Haven, CT, U.S.A.
2
Department of Computer Science, National Polytechnic Institute of Mexico, Mexico City, Mexico
Keywords:
Authentication, Biometrics, Privacy, Security.
Abstract:
We propose an efficient remote biometric authentication protocol that gives strong protection to the user’s
biometric data in case of two common kinds of security breaches: (1) loss or theft of the user’s token (smart
card, handheld device, etc.), giving the attacker full access to any secrets embedded within it; (2) total penetra-
tion of the server. Only if both client and server are simultaneously compromised is the user’s biometric data
vulnerable to exposure. The protocol works by encrypting the user’s biometric template in a way that allows
it to be used for authentication without being decrypted by either token or server. Further, the encrypted tem-
plate never leaves the token, and only the server has the information that would enable it to be decrypted. We
have implemented our protocol using two iris recognition libraries and evaluated its performance. The overall
efficiency and recognition performance is essentially the same compared to an unprotected biometric system.
1 INTRODUCTION
A major problem facing the Internet is “the re-
liance on passwords to authenticate users” (FIDOa,
2014). The drawbacks of passwords have long been
known (Kessler, 1996). Weak passwords are easily
guessed; strong passwords are difficult for users to re-
member and to supply when required. In addition,
username and password data must be somehow pro-
tected when sent over the network and stored on a
server since once compromised, they are sufficient to
impersonate the legitimate user.
Combining biometrics with cryptographic authen-
tication schemes is an attractive alternative to pass-
word authentication (FIDOb, 2014), an approach sup-
ported by the FIDO (Fast IDentity Online) Alliance,
a non-profit organization formed to promote easier to
use and stronger authentication. FIDO works closely
with dozens of prominent industry partners (e.g.,
Bank of America, Google, Visa, RSA) and strives to
reflect the current needs and expectations of the au-
thentication process, from clients and services alike.
In their approach, a secret key, stored on the user’s lo-
cal device, is used with a challenge-response protocol
to authenticate securely to the server. Biometrics are
used to prevent the local device from being activated
by any but the legitimate user. However, the user’s de-
vice stores secret information, which becomes prob-
lematic when the device is compromised.
Especially sensitive in any biometric scheme is
the user’s biometric data which, if compromised, can
subsequently be used by an attacker to impersonate
the individual to whom it belongs. Unlike passwords,
biometric data cannot be changed, so once compro-
mised, it becomes useless as an authentication factor.
Many techniques exist for extracting data stored
on a device’s internal memory, even from so-called
“tamper-resistant” devices (Anderson and Kuhn,
1996). One must assume that an attacker who steals
or otherwise gains physical possession of the user’s
device also obtains the entire contents of the device’s
internal memory, including any secret keys and bio-
metric data stored therein. Therefore, the user’s bio-
metric data must not be stored on the user’s device in
any form that would allow an attacker to reconstruct
it. Similar considerations apply to the server, which
also must protect the user’s biometric data even in the
face of a total compromise.
2 OUR CONTRIBUTION
We propose an efficient remote biometric authentica-
tion protocol that gives strong protection to the user’s
biometric data in case of two common kinds of secu-
rity breaches: a full client compromise or a full server
compromise. Our scheme also allows the creation
of multiple unlinkable personas in much the same
way as with passwords. (See Section 6.3.) Our two-
factor protocol can be combined with a broad class
243
Syta E., J. Fischer M., Wolinsky D., Silberschatz A., Gallegos-Garcia G. and Ford B..
Private Eyes: Secure Remote Biometric Authentication.
DOI: 10.5220/0005539602430250
In Proceedings of the 12th International Conference on Security and Cryptography (SECRYPT-2015), pages 243-250
ISBN: 978-989-758-117-5
Copyright
c
 2015 SCITEPRESS (Science and Technology Publications, Lda.)

of existing biometric authentication schemes to pro-
tect the privacy of the user’s biometric data and the
template derived from it. It works with any biometric
scheme where the result of feature extraction can be
represented by a binary feature vector, and the match-
ing criterion for two feature vectors is based on their
Hamming distance.
1
The user’s device (or token) stores only an en-
crypted form of the reference biometric template,
which we call the blinded template. This keeps the
biometric data safe even if the token is compromised.
The encryption is performed by computing the XOR
of the biometric template with a random blinding fac-
tor that is stored only on the server. How this is
accomplished is the heart of our protocol and is de-
scribed in Section 4. Since the blinding factor is ran-
dom and carries no information about the actual bio-
metric template, the biometric data is safe even if the
server is compromised. Only if both token and server
are simultaneously compromised is the user’s biomet-
ric data vulnerable to exposure.
The rest of the paper is structured as follows. Sec-
tion 3 summarizes other solutions to biometric au-
thentication. Section 4 presents our protocol, and Sec-
tion 5 analyzes its security properties. Section 6 dis-
cusses deployment issues. Section 7 describes a pro-
totype implementation and a performance evaluation
of our protocol. Section 8 concludes.
3 RELATED WORK
Many biometric authentication protocols offer protec-
tion of biometric data. Unlike our protocol, however,
those protocols frequently protect the biometric data
at the cost of a degraded recognition performance,
higher complexity, or a lack of mechanisms to create
unlinkable personas.
Standard cryptographic solutions for protecting
passwords or other secrets, such as encryption or
hashing, are difficult to use for protecting biometric
templates because evenif two templates are generated
using two samples of the same biometric characteris-
tic, they are never exactly the same. Homomorphic
encryption (Gentry, 2009) and secure two-party com-
putation techniques (Lindell and Pinkas, 2007) offer
good security and privacy guarantees but they nor-
mally come at a high performance cost.
Biometric cryptosystems (BC), such as fuzzy ex-
tractors (Dodis et al., 2008; Dodis et al., 2004), fuzzy
vaults (Juels and Sudan, 2006) and fuzzy commit-
ments (Juels and Wattenberg, 1999), use a template
1
The Hamming distance between two bit vectors is the
number of indices in which the two vectors differ.
as well as helper data to extract a cryptographic key,
with the resulting key validated by verifying its cor-
rectness. While BC offers additional features such as
reliable cryptographic key generation, they come at
the cost of performance and complexity. They heav-
ily rely on error correction codes, which limits their
recognition performance to the error-correcting capa-
bility of the employedcode (Jain et al., 2008; Rathgeb
and Uhl, 2011). Furthermore, to achieve reusabil-
ity and unlinkable personas, BC schemes must be
strengthened by adding auxiliary information, for ex-
ample passwords (Ballard et al., 2008; Nandakumar
et al., 2007). This adds to their complexity, limits
user convenience, and in some cases may still be in-
sufficient (Hong et al., 2008).
Other template protection schemes use a transfor-
mation function, either invertible (BioHashing (Jin
et al., 2004)) or non-invertible (cancelable biomet-
rics (Ratha et al., 2001)), and apply it to biometric
data during the enrollment phase. For the authen-
tication phase, they apply the same transformation
and compare the resulting template against the ref-
erence template. In case of invertible transforma-
tions, users need to supply, and therefore remember
or keep secure, a password or a key, which impacts
their convenience. A compromise of this additional
information can yield further vulnerabilities (Kong
et al., 2006; Lumini and Nanni, 2007). This is in
contrast to our protocol where a compromise of the
user’s token does not expose her biometric data. In the
case of non-invertible transformations, the recogni-
tion performance is affected because the matching is
applied to degraded transformed templates (Rathgeb
and Uhl, 2011). However, unlinkable personas can be
achieved (Jain et al., 2008; Nagar, 2012).
4 PROTOCOL DESCRIPTION
In this section, we give a description of our protocol.
We refer the reader to our technical report (Syta et al.,
2015) for interesting extensions of the protocol.
4.1 Enrollment Phase
The authentication process is performed over a net-
work between an authenticating party (Peggy, the
user) and a verifying party (Victor, the authentication
server), after the user enrolls into the system.
During the enrollment phase, Peggy and Victor
cooperate to create Peggy’s credentials and to estab-
lish the shared authentication information (the choice
of a biometric characteristic, a feature extractor that
produces a biometric template, an appropriate match-
SECRYPT2015-InternationalConferenceonSecurityandCryptography
244

ing metric on templates, and an appropriate pseudo-
random number generator G). Our protocol assumes
the template is described by a Boolean vector, and the
matching metric is a function of the difference be-
tween templates. We assume that G is cryptograph-
ically secure (Goldreich, 2001) and backtracking re-
sistant (Bellare and Yee, 2003).
Since our protocol is a two-factor scheme, Peggy
needs to obtain a token on which to store her blinded
biometric template and the state of the pseudorandom
number generator, as further discussed in Section 6.2.
Peggy and Victor also need to obtain a shared se-
cret z to be used as the seed for G. The seed needs to
be established in a secure manner in order to keep the
sequences of blinding factors secret and the blinded
template secure. This can be done in person for face-
to-face enrollment, using cryptographic techniques
such as a key agreement protocol (Goldreich, 2001)
for remote enrollment, or Victor can send the seed to
Peggy over a secure channel.
To continue the enrollment, Peggy and Victor ini-
tialize G using seed z. Peggy obtains a biometric sam-
ple using a biometric sensor and generates a reference
template P
ref
. She then blinds P
ref
with the first blind-
ing factor R
0
= r
0
generated using G to produce the
blinded template T
0
= P
ref
⊕ R
0
. This process binds
Peggy’s biometric identity to the secret seed z estab-
lished with Victor. Victor meanwhile uses G to gener-
ate the blinding factor R
0
, which he stores for future
use. Both Peggy and Victor store the next state s
1
of
G. Finally, Peggy securely erases her raw biometric
data, the unprotected template, the secret z, the first
blinding factor r
0
, and the first state s
0
of G. Simi-
larly, Victor securely erases the secret z and the first
state s
0
of G. See Algorithm 1 for details.
4.2 Authentication Phase
Peggy and Victor run the authentication phase each
time Peggy wishes to prove her identity to Victor. At
the start of phase k, Peggy’s token stores T
k−1
= P
ref
⊕
R
k−1
and s
k
while Victor stores R
k−1
= ⊕
k−1
j=0
r
j
and s
k
.
In order to authenticate, Peggy obtains a fresh bio-
metric sample and generates a new template P
k
from
it. She then calculates an authentication message
W
k
= P
k
⊕ T
k−1
= (P
k
⊕ P
ref
) ⊕ R
k−1
.
Peggy sends W
i
to Victor for verification. Without
waiting for a response from Victor, she immediately
updates her token. She uses G to compute r
k
= ρ(s
k
)
and s
k+1
= δ(s
k
). She then computes
T
k
= T
k−1
⊕ r
k
= P
ref
⊕ R
k−1
⊕ r
k
= P
ref
⊕ R
k
.
Finally, she securely replaces T
k−1
with T
k
and s
k
with
s
k+1
, and she securely erases W
k
and all other tempo-
Algorithm 1: Enrollment Phase.
1. Peggy obtains a token. Peggy and Victor agree
on non-secret authentication information: the bio-
metric recognition protocol and the choice of G =
(m, S, ι, δ, ρ, n), where m defines the length of the
seed, S is the finite set of states of the generator,
an initial-state function ι which maps a seed z to
a state s
0
∈ S, δ is the next-state function, ρ is the
output function, which produces n-bit values, and
n is the length of biometric templates.
2. Peggy and Victor securely exchange a random
seed z ∈ {0, 1}
m
.
3. Peggy and Victor both initialize their generator G
to the initial state s
0
= ι(z). They use G to gen-
erate the first random number r
0
= ρ(s
0
) and the
next state s
1
= δ(s
0
) of G.
4. Peggy obtains a biometric template P
ref
, computes
the first blinding factor R
0
= r
0
, and creates a
blinded template T
0
= P
ref
⊕ R
0
, where ⊕ is the
bit-wise exclusive-OR operation. She securely
erases z, P
ref
, R
0
, r
0
, and s
0
. She keeps T
0
and
s
1
on her token.
5. Victor computes the first blinding factor R
0
= r
0
.
He securely erases z, r
0
, and s
0
. He retains R
0
and
s
1
in private storage.
To summarize, after the enrollment phase:
• Peggy’s token stores T
0
= P
ref
⊕ R
0
and s
1
.
• Victor retains R
0
= r
0
and s
1
.
Algorithm 2: Authentication Phase.
1. Peggy obtains a biometric sample and generates a
fresh biometric template P
k
.
2. Peggy calculates W
k
= P
k
⊕ T
k−1
and sends W
i
to
Victor.
3. Peggy uses G to compute r
k
= ρ(s
k
) and s
k+1
=
δ(s
k
). She then computes T
k
= T
k−1
⊕ r
k
. She
securely replaces T
k−1
on her token with T
k
and s
k
with s
k+1
, and she securely erases P
k
, W
k
, r
k
, and
s
k
from her token.
4. Victor, upon receiving W
k
, computes the differ-
ence vector V
k
= W
k
⊕ R
k
. He passes V
k
to the
matching algorithm and accepts Peggy’s authenti-
cation attempt if the match is sufficiently good.
5. If the authentication attempt succeeds, Victor uses
G to computer
k
= ρ(s
k
) and s
k+1
= δ(s
k
). He then
computes R
k
= R
k−1
⊕ r
k
. He securely replaces
R
k−1
with R
k
and s
k
with s
k+1
in memory, and he
securely erases r
k
, and s
k
.
To summarize, at the end of authentication phase k:
• Peggy’s token stores T
k
= P
ref
⊕ R
k
and s
k+1
.
• Victor retains R
k
= ⊕
k
j=0
r
j
and s
k+1
.
rary data from memory. By updating after each au-
thentication, successful or not, she ensures that the
PrivateEyes:SecureRemoteBiometricAuthentication
245

same blinding factor is never used more than once.
2
Upon receiving W
k
from Peggy, Victor removes
the blinding factor R
k−1
to obtain the difference vec-
tor V
k
= P
k
⊕ P
ref
. He applies the matching metric
of the chosen biometric system to V
k
in order to de-
cide whether or not to accept Peggy’s authentication
attempt. If valid, he updates his stored information.
Using G, he computes r
k
= ρ(s
k
) and s
k+1
= δ(s
k
).
He then computes R
k
= R
k−1
⊕ r
k
. Finally, he se-
curely replaces R
k−1
with R
k
and s
k
with s
k+1
, and
he securely erases all temporary data from memory.
See Algorithm 2 for details.
A legitimate authentication attempt might fail for
many reasons, for example, because Peggy’s message
never reaches Victor, or because of poor feature ex-
traction by Peggy, or because of Victor’s not stor-
ing the updated blinding factor before going offline,
or because of intentional malicious authentication at-
tempts by an adversary. In such cases, Peggy ad-
vances her generator but Victor does not. This will
leave Victor unable to unblind Peggy’s future mes-
sages and require resynchronizing the generators to
continue. Peggy updates her blinded template T
k
af-
ter each authentication attempt (hence, she will never
be behind) and Victor does so only after a successful
authentication (hence, he can always catch up). To do
so, Victor searches forward in the sequence produced
by G for some limited predefined distance looking for
a blinding factor R
k
′
that leads to a successful authen-
tication using Peggy’s current authentication message
W
k
. After finding the correct value of T
k
, both gener-
ators will again be in sync. Such a scheme is called a
rolling code and is widely used in keyless entry sys-
tems (Waraksa et al., 1995).
5 SECURITY PROPERTIES
Our main goal and concern is the security of biomet-
ric data, not only under normal use of the protocol, but
also in case of complete compromise of either Peggy’s
token or Victor’s entire internal state. In addition,
our protocol prevents an attacker who compromises
Peggy’s token from impersonating her to Victor.
We note that if an attacker compromises both
Peggy and Victor, then Peggy’s biometric template is
easily obtained. Peggy’s token contains her blinded
template; Victor has the blinding factor. It is needed
to unblind the difference vector, but it will also un-
2
This prevents an attacker from obtaining useful infor-
mation from differencing two authentication messages W
i
and W
j
. If they both used the same blinding factor T,
the blinding factor would cancel out, and an attacker could
compute W
i
⊕W
j
= (P
i
⊕ T) ⊕(P
j
⊕ T) = P
i
⊕ P
j
.
blind the template stored on the token.
We refer the reader to our technical report (Syta
et al., 2015) for a fuller security analysis, including a
discussion on a leakage of information from template
differences and suggested solutions.
5.1 Assumptions
Peggy and Victor interact over a network, possibly
in the presence of a computationally bounded adver-
sary (Mallory, the malicious adversary). In addition to
eavesdropping on all communication between Peggy
and Victor, we assume that Mallory can talk directly
to Victor in an attempt to impersonate Peggy. In ad-
dition, Mallory might actively attack either Peggy or
Victor but not both.
In an attack on Peggy, Mallory takes possession
of Peggy’s token and obtains access to all of the data
stored on it. Peggy detects the attack since her to-
ken is physically gone. Nevertheless, our protocol
guarantees that Peggy’s biometric data remains secret
and Mallory cannot impersonate Peggy to Victor. In
an attack on Victor, Mallory compromises Victor and
gains access to all of his data. Victor does not nec-
essarily detect the intrusion. He continues processing
authentication requests, and Mallory sees everything
that happens on the server. In this case, Peggy’s bio-
metric data still remains secret, but Mallory can easily
impersonate Peggy to Victor. This can be prevented
by using digital signatures (Syta et al., 2015).
We assume that all communication occurs over
an unsecured channel, so after k authentication at-
tempts, Mallory knows the authentication messages
W
1
, . . . , W
k
, which are blinded differences between
pairs of biometric templates. Thus, Mallory has the
following information.
W
1
= P
1
⊕ T
0
= P
1
⊕ P
ref
⊕ r
0
W
2
= P
2
⊕ T
1
= P
2
⊕ P
ref
⊕ r
0
⊕ r
1
W
3
= P
3
⊕ T
2
= P
3
⊕ P
ref
⊕ r
0
⊕ r
1
⊕ r
2
·· · ·· ·
W
k
= P
k
⊕ T
k−1
= P
k
⊕ P
ref
⊕ r
0
⊕ · ··⊕ r
k−1
Furthermore, we assume that the sensor Peggy
uses to obtain biometric samples does not directly re-
veal her biometric data to Mallory, prior to his pos-
sible compromise of Peggy’s token. We also assume
that Peggy does not use her token after it has been
compromised. Similarly, we assume that the com-
munication channel between the sensor and the to-
ken is trusted. The security of our protocol depends
critically on the pseudorandom number generator G,
which we assume is cryptographically secure (Gol-
dreich, 2001) (the sequence of outputs are compu-
tationally indistinguishable from a similar sequence
SECRYPT2015-InternationalConferenceonSecurityandCryptography
246

of truly random numbers) and backtracking resis-
tant (Bellare and Yee, 2003) (it is not feasible to run
G backwards from a given state to recover previously-
generated values). We also assume that the secret seed
z and the unprotected template P
ref
are securely erased
after enrollment and are not available to Mallory.
5.2 Security of Biometric Templates
Mallory Compromises Victor. We assume that
Mallory can compromise Victor at any time and re-
main undetected. If she compromises him at phase k,
she learns the current blinding factor R
k
and the next
state of the generator s
k+1
. This enables her to com-
pute the future random numbers r
k+1
, r
k+2
, . . . and
the future blinding factors R
k+1
, R
k+2
, . . .. Clearly,
she learns the most by compromising Victor at the
very beginning, in which case she recovers the ex-
act same information that Victor receives from Peggy.
From this, she can learn all of the difference vectors,
V
1
, V
2
, . . .. The usefulness of the difference vectors
depends on the underlying feature extractor. Ideally,
we want a feature extractor that produces templates
on repeated scans of the same biometric that lead to
small false rejection rates. When the match function
is based on the Hamming distance between two tem-
plates, small false rejection rates imply that most dif-
ference vectors approximate the zero vector. Hence,
Mallory only learns vectors in the neighborhood of 0.
In any case, we can say that Mallory has no other in-
formation about the template since Peggy sends noth-
ing else besides the blinded difference vectors.
Mallory Compromises Peggy. When Mallory ob-
tains access to Peggy’s token, she learns the current
blinded reference template
T
k
= P⊕ r
0
⊕ r
1
⊕ · ··⊕ r
k−1
⊕ r
k
and the next state of the generator s
k+1
. This new in-
formation is in addition to all authentication messages
W
1
, . . . , W
k
sent up to that point which we assume she
already knew.
T
k
looks random to Mallory because of the blind-
ing factor r
k
, which she does not know. It was se-
curely erased from the token when T
k
was updated,
and it was never included in any of the messages sent.
Additionally, r
k
cannot be recovered using the stored
state s
k+1
of G and r
0
, . . . , r
k−1
(assuming they are
known) since G is backtracking resistant and crypto-
graphically secure. Thus, Mallory cannot obtain any
information about the blinding factor R
k
, so neither T
k
nor s
k+1
give Mallory any information about P
ref
.
We assume that Peggy’s token is not compromised
at the moment she is using it, since for a brief interval,
the token contains her unprotected biometric template
as well as data from both stage k− 1 and stage k.
5.3 Impersonation
Mallory Compromises Victor. As before, when
Mallory compromises Victor, she gets R
k
and s
k+1
.
R
k
is the blinding factor needed to unblind the next
authentication message. Therefore, Mallory might be
able to prepare a fake message W
′
k
so that verification
will succeed from Victor’s point of view. See (Syta
et al., 2015) for a practical defense against this attack.
Mallory Compromises Peggy. As before, when
Mallory compromises Peggy, she gets T
k
and s
k+1
.
We argued in Section 5.2 that her compromise of
Peggy’s token does not give her any information about
P
ref
or R
k
. Hence, she gets no information that would
allow her to impersonate Peggy.
6 USAGE CONSIDERATIONS
This section discusses biometrics suitable for our pro-
tocol, tokens as well as creating personas.
6.1 Suitable Biometrics
In practice, fingerprints, face geometry, and iris pat-
terns have been popular choices for biometric systems
as they can be obtained easily and non-intrusively us-
ing a simple camera. Fingerprints tend to be prone to
spoofing, however, and the accuracy of facial recog-
nition may be impacted by pose, expression, or light-
ing (Jain et al., 2008). An iris, on the other hand,
exhibits many highly desirable properties. Its pattern
varies greatly among different people, even identical
twins, and persists over a lifetime. Iris-based sys-
tems have been widely deployed by many organiza-
tions including British Telecom, Panasonic, LG and
IBM Schiphol Group (Daugman, 2002).
For these reasons, we chose to use an iris-based
template for our implementation, described in Sec-
tion 7. These templates typically consist of 2048 bits
to represent the iris pattern with any bit equally likely
to be either 1 or 0. On average half of all the bits will
disagree between the templates of two different peo-
ple. A study (Daugman, 2002) based on 9.1 million
comparisons between different pairings of iris images
concludedthat it is extremely improbable that two dif-
ferent irises might disagree in fewer than a third of all
bits, so a difference score less than 0.32 statistically
guarantees a positive match.
PrivateEyes:SecureRemoteBiometricAuthentication
247

Our current protocol assumes binary biometric
templates, which are suitable for all iris-based tem-
plates, however, a binarization technique (Rane et al.,
2010) can convert other types of templates into a bi-
nary vector and make it usable in our protocol but
likely trading off some recognition performance.
6.2 Enrollment Process and Tokens
The main drawback of possession-based authentica-
tion is the need to obtain and manage tokens. Ed-
die, an enrolling agent, can be responsible for issu-
ing tokens and performing the enrollment phase, en-
suring a successful bond between a token and a bio-
metric identity. Depending on the application-specific
security requirements, Eddie can be an independent,
trusted enrollment center, Victor can assume Eddie’s
role, or Eddie’s role can be delegated to users. In the
first scenario, Eddie’s services can be offered by an
organization such as VeriSign (VeriSign, 2012). This
approach would provide a good way to issue and man-
age a variety of tokens. VeriSign already provides
similar services and issues security credentials (VIP
Security Token or Card).
There are two different approaches to utilizing to-
kens depending on the token’s ability to obtain bio-
metric samples. Using a token with a built-in sensor
removes security concerns related to the sensor and
the communicationchannel between the token and the
sensor. Mobile devices are an obvious choice for such
tokens; they are equipped with a high resolution cam-
era capable of capturing images suitable for authen-
tication using several biometric characteristics such
as a fingerprint, facial geometry, or iris pattern (Jain
et al., 2011). A token without a sensor is only used to
store authentication information and to perform com-
putations. It must be paired with an external sensor to
obtain a biometric sample. This implies certain level
of trust that the sensor is not compromised and the
channel between the token and sensor is secure. How-
ever, such tokens are inexpensive and make it possible
to utilize virtually any biometric characteristic. Smart
cards are a good choice for such tokens. They have
been extensively used for authentication as they offer
enough computational power and are relativelycheap,
small, and convenient to use (Smart, 2011).
6.3 Personas
Many biometric authentication protocols create user’s
authentication credentials directly based on a biomet-
ric template. As a result, if a user chooses to enroll
with multiple verifying parties using the same biomet-
rics, then these verifying parties can identify the user
and successfully track his activities performed using
the same biometric credentials or credentials based on
the same biometric features.
In our protocol, credentials are based on a user’s
unprotected biometric template but with respect to the
blinding factors known to the verifying party. Hence,
a user can create multiple, fully independentpersonas.
Each persona is based on the same biometric data but
on a different secret shared with a verifying party so
a persona represents a user’s unique identity as seen
by the verifying party. Users can create different per-
sonas to deal with multiple verifying parties, or use
personas for different transactions with the same ver-
ifying party. This creates a separation and unlinkabil-
ity of biometric identities and transactions performed
using those identities. The user must perform the en-
rollment process once for each persona, choosing a
new secret for each. Policies and procedures con-
trolling the enrollment process would determine how
many and what types of personas a user may acquire.
7 EVALUATION
We evaluated our prototype implementation to ob-
serve the performance characteristics of our protocol
in comparison to using unprotected templates.
7.1 Implementation Details
We have implemented our biometric authentication
system in C++ using the Qt framework and Crypto++
cryptographic libraries. For feature extraction, we
have employed two different iris recognition libraries:
Project Iris (Boyd et al., 2010) and Libor Masek’s
Iris Recognition (Masek and Kovesi, 2003), both of
which utilize John Daugman’s approach (Daugman,
2002) to produce an iris template. In evaluation fig-
ures, we denote the different libraries by their imple-
mentation language: Project Iris as C++ and Masek’s
library as Octave. We used the CASIA Iris Image
Database (Institute of Automation, Chinese Academy
of Sciences CASIA, 2012) as input into our system.
We use a Diffie-Hellman Key Agreement (Goldre-
ich, 2001) to agree on a common key. We then use
the agreed on key to seed a provably secure Blum-
Blum-Shub generator (Blum et al., 1986) (PRBG).
We used a SQLite database to store enrollment infor-
mation. We set a minimal difference score of 0.32
to ensure a low probability of a false match (1 in
26 million) (Daugman, 2002). In their evaluations,
Masek’s scheme uses a modified Hamming distance
scheme that depends on a comparison between two
unencrypted templates. Our system encrypts the tem-
SECRYPT2015-InternationalConferenceonSecurityandCryptography
248

0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1
0 50 100 150 200 250 300 350
CDF
Time in milliseconds
C++ - Server enrollment
C++ - Client enrollment
Octave - Server enrollment
Octave - Client enrollment
Figure 1: CPU time for enrollment.
plates, therefore, the traditional Hamming distance is
more suitable. We analyzed the behavior of these li-
braries to determine their recognition performance,
usefulness and potential overheads in our scheme. We
reported the results in (Syta et al., 2015).
The two feature extractionlibraries we employ use
a technique to further boost the recognition perfor-
mance. A single template may need to be rotated up
to 8
◦
in both directions to achieve better results. In
an unprotected biometric system, the server can ma-
nipulate the template itself because it gets full access
to the client’s biometric template. In our system, we
preprocess templates to produce these rotations and
store the resulting blinded templates on the client’s
side. We do so because the server never gets access to
unprotected biometric data and therefore cannot ma-
nipulate the templates itself. Then, during authenti-
cation, the client uses all of the saved templates as
input to the protocol and forwards the result to the
server. Therefore, our protocol preserves the same
recognition performance as schemes employing this
recognition-enhancing technique.
All CASIA database images have been converted
to gray scale images. CASIA database version 1 con-
tains 108 individuals with 7 images each. Project
Iris only supports version 1 of the CASIA database,
in which images have been preprocessed by replac-
ing the pupils with a black (constant intensity) cir-
cle. Masek’s iris recognition library handles CASIA
database version 2, however, had trouble parsing ap-
proximately 4% of the images, though had no issue
in database version 1. The libraries also differ in the
resolution of their extracted features. While Project
Iris extracts a 2048-bit template like Daugman (Daug-
man, 2002), Masek extracts a 9600-bit template.
0
0.2
0.4
0.6
0.8
1
1 10 100
CDF
Time in milliseconds
C++ - Client invalid authentications
C++ - Traditional template comparison
C++ - Server invalid authentications
Octave - Client invalid authentications
Octave - Server invalid authentications
Octave - Traditional template comparison
C++ - Server valid authentications
C++ - Client valid authentications
Octave - Server valid authentications
Octave - Client valid authentications
Figure 2: CPU time for authentication.
7.2 System Performance
To evaluate the enrollment phase, we created a client
(Peggy) for each image in the CASIA database ver-
sion 1 and used a single server (Victor). Clients, in no
particular order, enrolled one after another. The en-
rollment occurred within the same process, as a result
the evaluation focuses on data processing and mes-
sage serialization, i.e., CPU time. Figure 1 indepen-
dently plots the time for the client and server compo-
nents of enrollment.
The clients enrollment time includes both the ini-
tial enrollment request and the subsequent processing
for a successful enrollment, both represented as a sin-
gle, summed value. Both client and server enrollment
times complete well within 160 ms on average and
within 300 ms together in even the worst-case sce-
nario. The client enrollment time is negligibly larger
than the server enrollment time. The major factor
in performance appears to be the size of the stored
template(s) and the need to generate an appropriate
amount of random blinding factors. While Octave,
Masek’s library, uses 17 9600-bit templates with 17
masks resulting in 40.8 KBs of PRNG work, C++,
Project Iris, uses only 8.7 KBs.
To evaluate authentication time, we had each im-
age in the database tested against every client for a to-
tal of 571,536 authentication attempts or 756 attempts
per client. We separated the results, in Figure 2,
into valid and invalid client and server authentica-
tions, those that our system processed, and compared
them against the time a traditional template compari-
son would take. Authentications complete on the or-
ders of 10s of milliseconds, which we find reason-
able, especially given to the average round trip delay
between machines across the Internet.
PrivateEyes:SecureRemoteBiometricAuthentication
249

8 CONCLUSIONS
Protecting sensitive biometric data is crucially im-
portant for remote biometric authentication, because
once compromised, the biometric data becomes no
longer useful for distinguishing between its legitimate
owner and anyone else who possess a copy.
We present a new method for adding strong bio-
metric data protection to a wide class of existing bio-
metric authentication protocols, making them an at-
tractive alternativeto password authentication. In par-
ticular, biometric data is never stored on the server,
only on the user’s token, and then only in encrypted
form. The token itself requires no secure storage; the
biometric data cannot be recovered even if an attacker
has full and complete access to everything stored on
the token. A lost token also cannot be used to imper-
sonate its owner.
Our method is computationally efficient and has
the same recognition performance as the underlying
feature extraction scheme. It also allows the creation
of independent personas provide enhanced privacy of
users’ actions across different verifying parties.
REFERENCES
Anderson, R. and Kuhn, M. (1996). Tamper resistance-a
cautionary note. In Proceedings of the second Usenix
workshop on electronic commerce, volume 2.
Ballard, L., Kamara, S., Monrose, F., and Reiter, M. K.
(2008). Towards practical biometric key generation
with randomized biometric templates. In Conference
on Computer and Communications Security.
Bellare, M. and Yee, B. (2003). Forward-security in private-
key cryptography. In Topics in Cryptology - CT RSA.
Blum, L., Blum, M., and Shub, M. (1986). A simple un-
predictable pseudo random number generator. SIAM
J. Comput.
Boyd, M., Carmaciu, D., Giannaros, F., Payne, T., and
Snell, W. (2010). Iris recognition (project iris).
http://projectiris.co.uk/.
Daugman, J. (2002). How iris recognition works. IEEE
Trans. on Circuits and Systems for Video Technology.
Dodis, Y., Ostrovsky, R., Reyzin, L., and Smith, A. (2008).
Fuzzy extractors: How to generate strong keys from
biometrics and other noisy data. SIAM J. Comput.
Dodis, Y., Reyzin, L., and Smith, A. (2004). Fuzzy extrac-
tors: How to generate strong keys from biometrics and
other noisy data. In EUROCRYPT.
FIDOa (2014). FIDO alliance: Mission.
http://fidoalliance.org/about.
FIDOb (2014). FIDO alliance: Specifications overview.
http://fidoalliance.org/specifications.
Gentry, C. (2009). A fully homomorphic encryption scheme.
PhD thesis, Stanford University.
Goldreich, O. (2001). Foundations of Cryptography: Vol-
ume 1, Basic Tools. Cambridge University Press.
Hong, S., Jeon, W., Kim, S., Won, D., and Park, C. (2008).
The vulnerabilities analysis of fuzzy vault using pass-
word. In International Conference on Future Genera-
tion Communication and Networking.
Institute of Automation, Chinese Academy of Sci-
ences CASIA (2012). Iris image databases.
http://www.cbsr.ia.ac.cn/english/IrisDatabase.asp.
Jain, A., Ross, A., and Nandakumar, K. (2011). Introduc-
tion to Biometrics. Springer.
Jain, A. K., Nandakumar, K., and Nagar, A. (2008). Bio-
metric template security. EURASIP J. Adv. Signal Pro-
cess.
Jin, A., Ling, D., and Goh, A. (2004). Biohashing: two
factor authentication featuring fingerprint data and to-
kenised random number. Pattern Recognition.
Juels, A. and Sudan, M. (2006). A fuzzy vault scheme.
Designs, Codes and Cryptography.
Juels, A. and Wattenberg, M. (1999). A fuzzy commitment
scheme. In ACM Conference on Computer and Com-
munications Security.
Kessler, G. C. (1996). Passwords
– strengths and weaknesses.
http://www.garykessler.net/library/password.html.
Kong, A., Cheung, K.-H., Zhang, D., Kamel, M., and You,
J. (2006). An analysis of biohashing and its variants.
Pattern Recognition.
Lindell, Y. and Pinkas, B. (2007). An efficient protocol
for secure two-party computation in the presence of
malicious adversaries. In Advances in Cryptology-
EUROCRYPT 2007. Springer.
Lumini, A. and Nanni, L. (2007). An improved biohashing
for human authentication. Pattern Recognition.
Masek, L. and Kovesi, P. (2003). Matlab source code for a
biometric identification system based on iris patterns.
Technical report, University of Western Australia.
Nagar, A. (2012). Biometric Template Security. Disserta-
tion, Michigan State University.
Nandakumar, K., Nagar, A., and Jain, A. K. (2007). Hard-
ening fingerprint fuzzy vault using password. In Inter-
national Conference on Advances in Biometrics.
Rane, S., Nagar, A., and Vetro, A. (2010). Method and
system for binarization of biometric data. US Patent
App. 12/688,089.
Ratha, N. K., Connell, J. H., and Bolle, R. M. (2001). En-
hancing security and privacy in biometrics-based au-
thentication systems. IBM Syst. J.
Rathgeb, C. and Uhl, A. (2011). A survey on biometric
cryptosystems and cancelable biometrics. EURASIP
Journal on Information Security.
Smart (2011). Smart cards and biometrics. A Smart Card
Alliance Physical Access Council White Paper. Pub-
lication Number: PAC-11002.
Syta, E., Fischer, M. J., , Wolinsky, D., Silberschatz, A.,
Garc´ıa, G. G., and Ford, B. (2015). Private Eyes:
Secure Remote Biometric Authentication (Extended
Version). Technical Report TR1510, Yale University.
VeriSign (2012). Symantec Corporation web site.
http://www.verisign.com/.
Waraksa, T. J., Michaels, P. A., Slaughter, S. A., Poirier,
J. A., and Rea, I. B. (1995). Rolling code for a keyless
entry system. US Patent 5,412,379.
SECRYPT2015-InternationalConferenceonSecurityandCryptography
250
