Resiliency-aware Data Compression for In-memory Database Systems

Till Kolditz

, Dirk Habich

, Patrick Damme

, Wolfgang Lehner

, Dmitrii Kuvaiskii

Oleksii Oleksenko

and Christof Fetzer

Database Systems Group, Technische Universit

at Dresden, Dresden, Germany

Systems Engineering Group, Technische Universit

at Dresden, Dresden, Germany

Keywords:

In-memory Database Systems, Data Integrity, Lightweight Data Compression, AN Encoding.

Abstract:

Nowadays, database systems pursuit a main memory-centric architecture, where the entire business-related

data is stored and processed in a compressed form in main memory. In this case, the performance gain is

massive because database operations can beneﬁt from its higher bandwidth and lower latency. However,

current main memory-centric database systems utilize general-purpose error detection and correction solutions

to address the emerging problem of increasing dynamic error rate of main memory. The costs of these general-

purpose methods dramatically increases with increasing error rates. To reduce these costs, we have to exploit

context knowledge of database systems for resiliency. Therefore, we introduce our vision of resiliency-aware

data compression in this paper, where we want to exploit the beneﬁts of both ﬁelds in an integrated approach

with low performance and memory overhead. In detail, we present and evaluate a ﬁrst approach using AN

encoding and two different compression schemes to show the potentials and challenges of our vision.

1 MOTIVATION

Increased memory density, decreased transistor fea-

ture sizes and more are major drivers in the area of

hardware development. On the one hand, this leads to

performance improvements in each hardware genera-

tion. On the other hand, the hardware becomes more

and more vulnerable to external inﬂuences. As sev-

eral researches have already stated, especially main

memory becomes a severe cause for hardware based

failures (Hwang et al., 2012; Italiano, 2010). These

errors can be classiﬁed into static or hard errors as

permanently corrupted bits and dynamic or soft er-

rors as transiently corrupted bits. In particular, dy-

namic errors are produced, e.g., by cosmic rays, elec-

tromagnetic radiation, low voltage and increased heat

dissipation.

While the dynamic error rate is still quite low, it

is predicted to increase substantially in the near fu-

ture (Hwang et al., 2012; Italiano, 2010). Moreover,

dynamic errors already have a signiﬁcant impact on

large-scale application on massive data sets. The ﬁeld

of fault tolerance against dynamic memory errors is

not new and several techniques are well-known. A

general applicable approach is executing the same

computation multiple times. In this case, any dy-

namic error can be detected by comparing the ﬁnal

results. The most well-known technique in this class

is Triple Modular Redundancy. Error detection and

error correction codes represent a second class. In

this case, the coding schemes introduce redundancy

to the data (Moon, 2005). Regarding DRAM bit

ﬂips, the most commonly used approach is hardware-

based (72,64)-Hamming ECC (Moon, 2005). It re-

alizes single-error correction and double-error detec-

tion. Many other general coding algorithms are avail-

able, whereas the enhanced coding schemes are more

robust, however their coding results in higher redun-

dancy overhead and higher computational costs. Gen-

erally, the major problem of ensuring a low dynamic

error probability by employing generally applicable

techniques is dramatically increasing costs for mem-

ory and computational power.

Based on the signiﬁcant developments in the hard-

ware sector, database systems have initiated a major

shift from disk-centric to main memory-centric archi-

tectures. Servers with terabytes of main memory are

available for a reasonable price, where the entire data

pool can be kept completely in main memory. As

shown in different papers (Abadi et al., ; Chen et al.,

2001; Lemire and Boytsov, 2012), the performance

gain is massive because database operations beneﬁt

from its higher bandwidth and lower latency (Garcia-

Molina and Salem, 1992). However, current database

326

Kolditz T., Habich D., Damme P., Lehner W., Kuvaiskii D., Oleksenko O. and Fetzer C..

Resiliency-aware Data Compression for In-memory Database Systems.

DOI: 10.5220/0005557303260331

In Proceedings of 4th International Conference on Data Management Technologies and Applications (DATA-2015), pages 326-331

ISBN: 978-989-758-103-8

 2015 SCITEPRESS (Science and Technology Publications, Lda.)

systems do not efﬁciently address the emerging prob-

lem of random dynamic faults.

In order to tackle this issue, we propose to tightly

combine existing techniques form the ﬁeld of error

detecting codes and data compression in an appro-

priate way: resiliency-aware data compression tech-

niques. Data compression techniques play an impor-

tant role in main memory-centric database systems.

These techniques are employed to enable keeping and

processing all business-related data in main memory.

As can be imagined, compressed data is very sensitive

to dynamic errors and an increased dynamic error rate

as described above has a high impact on systems re-

lying on compressed data. Therefore, we focus on the

resilience aspect of compressed data. In our vision,

the beneﬁts of compression should not be completely

neutralized by error detection mechanisms. To reduce

the overall overhead, query processing on resiliency-

aware compressed data should be possible directly

without explicitly decompressing and re-encoding the

data. Finally, error detection should be possible in an

online fashion, so that wrong results can be excluded

to a well-deﬁned degree. To summarize, we want to

replace data compression techniques with resiliency-

aware data compression techniques to retain as many

positive effects of data compression as possible, but

extend it with speciﬁc resiliency aspects to efﬁciently

handle an increasing dynamic error rate.

To show the potentials and challenges of our vi-

sion, we present our ﬁrst research results in this pa-

per. From the ﬁeld of error correcting codes, we

have chosen the family of arithmetic AN codes as

a very promising alternative (or complementary) to

ECC DRAM, since its very nature allows to do arith-

metic operations—including comparisons—without

the need of decoding. Consequently, arithmetic AN

codes are suitable for both transactional and analytical

workloads. From the data compression domain, we

decided to use two prominent lightweight techniques:

Null Suppression (Abadi et al., ; Roth and Van Horn,

1993), and Run Length Compression (Abadi et al., ).

As we are going to show, the combination approach

differs and depends on various factors. Furthermore,

we provide an analysis on how the basic parameter

A of AN encoding can be chosen to detect various

amounts of bit ﬂips with very low performance penal-

ties and low memory overhead.

The remainder of the paper is structured as fol-

lows: In Section 2, we give a detailed insight into

AN encoding. Based on this description, we intro-

duce our AN-encoded extension for Null Suppression

and Run-Length Compression in Section 3. Next,

we present our evaluation in Section 4, where we

discuss the parameterization of AN encoding and

provide throughput comparisons of our AN-encoded

compression schemes. Finally, we conclude the paper

with related work in Section 5 as well as a conclusion

and future work in Section 6.

2 AN-ENCODING TECHNIQUE

To tackle our vision of resiliency-aware data com-

pression techniques, we decided to utilize AN encod-

ing as our resilience technique in a ﬁrst step. AN en-

coding is a technique to detect data corruption caused

by transient (e.g., dynamic bit ﬂips) and permanent

(e.g., stuck-at-1) hardware faults (Schiffel, 2011).

Furthermore, AN encoding offers some features that

we assume beneﬁcial for database system, in particu-

lar for efﬁcient query processing as described later.

Basic Idea of AN Encoding

The underlying idea of AN encoding is simple: multi-

ply each data word n by a predeﬁned constant A, i.e.,

the code word ˆn is computed as:

ˆn = n · A

As a result of this multiplication (encoding), the do-

main of values expands such that only the multiples of

A become valid code words, and all other values are

considered non-code. As an example, if one wants to

encode a set of 2-bit numbers {0, 1,2,3} with A = 11,

then the set of code words is {0, 11,22,33}, while

1,10, 34 are all examples of non-code words.

If a bit ﬂip affects an encoded value, the cor-

rupted value becomes non-code with a probability of

(A − 1)/A. If ˆn = 11 and the least signiﬁcant bit is

ﬂipped, then the new value ˆn

= 10 and is non-code.

To detect this fault, we have to check if the value is

still a multiple of A:

ˆn mod A = 0

Finally, to decode the value, we have to divide the

code word ˆn by A:

n = ˆn/A

Beneﬁcial Features of AN Encoding

One of the features of AN encoding is the ability to

directly process encoded data, i.e., there is no need

to decode values before working on them. Most

database-related operations can be performed on en-

coded values; these operations include addition, sub-

traction, negation, comparisons, etc. For example, the

addition of two valid code words 11 + 22 = 33 pro-

duces an expected code word, and 11 is less than 22

Resiliency-awareDataCompressionforIn-memoryDatabaseSystems

327

just like their original counterparts. Encoded multipli-

cation and division are also possible, but require some

adjustments.

This “encoded processing” feature is beneﬁcial

for in-memory database systems. AN-encoded data

words can be read from main memory, processed us-

ing complex queries and stored back without the need

for intermediate decoding, which reduces the over-

head for resiliency mechanism. Examples of database

operations on encoded data include scans, projec-

tions, aggregate computations, joins, etc.

Application Challenge

AN encoding is an arithmetic encoding scheme, al-

lowing certain arithmetic operations directly on en-

coded data with relatively little overhead as well

as multiplication and division with higher overhead.

However, AN encoding does not pose any restrictions

on a value of A. This constant must be carefully

chosen to suit the needs of a particular application.

The choice of A affects three parameters: fault cov-

erage, memory footprint, and encoding/decoding per-

formance. As a rule of thumb, greater values of A re-

sult in higher fault coverage, higher memory footprint

and worse performance. The challenge is to ﬁnd an A

providing sufﬁciently high fault detection rate at a low

cost of memory blow-up and performance slowdown.

In general, some “good” A’s with the best trade-

offs can be found. In terms of fault coverage, there

is no known formula to ﬁnd the best A, so the re-

searchers resort to experimental results (Hoffmann

et al., 2014). Memory blow-up depends on the size

of A in bits; for example, encoding one 22-bit inte-

ger with a 10-bit A requires 22 + 10 = 32 bits, i.e.,

an increase of 45%. Finally, performance slowdown

is negligible during encoding (since multiplication re-

quires only 2 − 3 CPU cycles), but can be a bottleneck

during checks and decoding (since division is an ex-

pensive CPU instruction). To alleviate this decoding

impact, A must be chosen such that the division oper-

ation is substituted by a sequence of shifts, adds, and

multiplies (Warren, 2002).

3 RESILIENCY-AWARE DATA

COMPRESSION

Lightweight data compression techniques like dictio-

nary or run-length compression play an important role

in main memory database systems. These techniques

are employed to enable holding and processing all

business-related data in main memory, whereas all

compression techniques in database systems are loss-

less. The general approach of data compression is

to encode data using fewer bits than the original rep-

resentation. In contrast to heavyweight compression

techniques like Huffmann, lightweight techniques are

less compute-intensive, whereas they utilize context

knowledge to achieve a good compression rate.

To best of our knowledge, nowadays no additional

information is added to detect bit ﬂip corruption of

compressed data in main memory database systems.

In order to tackle an increasing bit ﬂip error rate, in

particular for dynamic errors, we want to tightly com-

bine techniques from both ﬁelds of lightweight data

compression and resilience techniques like AN en-

coding. One the one hand, lightweight data compres-

sion eliminate data redundancy to represent data using

fewer bits. On the other hand, resilience techniques

introduces data redundancy to detect bit ﬂips. There-

fore, both ﬁelds have opposed aims and the combina-

tion approach have to carefully designed, so that the

beneﬁts of both ﬁelds remains. As we are going to

show later, based on a well-deﬁned and speciﬁc ap-

proach, the overhead of resiliency-aware data com-

pression is less compared to uncompressed data, so

that the approach is beneﬁcial for database systems.

As next, we are going to present two speciﬁc AN-

encoded compression scheme extensions: (i) AN-

encoded Null Suppression in Section 4.1 and (ii) AN-

encoded Run-Length Compression in Section 4.2.

3.1 AN-encoded Null Suppression

Null Suppression (NS) is the most well-studied kind

of lightweight compression. Its basic idea to the omis-

sion of leading zeros in small integers. This technique

further distinguishes between bit-wise and byte-wise

null suppression where either all leading zero bits

or leading zero bytes containing only zero bits are

stripped of. Usually, some kind of compression mask

denotes how many bits or bytes were omitted from

the original value. Decompression works by adding

the leading zeros back.

In recent years, research in the ﬁeld of lightweight

data compression has mainly focussed on the efﬁcient

implementation of the techniques on modern hard-

ware e.g., using vectorization capabilities of mod-

ern CPUs (SSE or AVX extensions). Schlegel et al.

(Schlegel et al., 2010) presented 4-Wise Null Sup-

pression as vectorized version. 4-Wise NS eliminates

leading zeros at byte level and processes blocks of

four integer values at a time. During compression the

number of leading zero bytes of each of the four val-

ues is determined. This yields four 2-bit descriptors,

which are combined to an 8-bit compression mask.

DATA2015-4thInternationalConferenceonDataManagementTechnologiesandApplications

328

The compression of the values is done by a SIMD

byte permutation bringing the required lower bytes

of the values together. This requires a permutation

mask, which is looked up in an ofﬂine-created table

using the compression mask as a key. After the per-

mutation, the code words have a horizontal layout, i.e.

code words of subsequent values are stored in subse-

quent memory locations. The compressed data is thus

a sequence of compressed blocks. The decompression

simply reads the compression mask, looks up the ap-

propriate permutation mask which reinserts the lead-

ing zeros bytes and applies the permutation.

Based on that principle, we are able to introduce

our resiliency-aware extension of 4-Wise NS. For bit-

wise or byte-wise NS, the only reasonable way to

tightly combine NS and AN encoding is to encode

the original value ﬁrst and to compress afterwards.

Since the information about eliminated bits or bytes

is stored in the compression mask, we would compute

the leading zero bits/bytes twice in any other combi-

nation approach. This incurs unnecessary additional

computational overhead, which we avoid in our ap-

proach.

3.1.1 Encoding and Compression

Encoded compression for NS works as follows. List-

ing 1 shows the pseudo code for a 4-Wise encoded NS

scheme (processing four 32-bit integers at once in a

vectorized version). There are input and output arrays

to function compress, where elements stores original

data and buffer receives the compressed and encoded

data. Four data items are processed in each loop itera-

tion (line 3). First, each item is multiplied by A (lines

5-7) and afterwards the leading zero bytes are counted

(lines 8-10). This can be done by counting the leading

zero bits using compiler intrinsics (__builtin_clz()

for g++) and then dividing by 8. The bit compres-

sion mask contains the number of leading zeros. It is

computed by ORing the lower 2 bits of the zero byte

counts together (lines 11 and 12). Finally, the mask

and the compressed encoded words are stored in the

output buffer (lines 13-16). Assuming a little endian

system, the leading zero bytes of a compressed value

are inherently overwritten by the next appended data

item, by advancing the write pointer by the number of

non-zero bytes of the item just written.

3.1.2 Decompression and Decoding

Decompression and decoding is also straightforward.

In this case, a loop iterates over the input buffer of

AN-encoded and compressed data. First, the com-

pression mask is loaded. Then, the number of non-

zero bytes – denoted by the mask’s lowest 2 bits – of

1 c ompres s ( i n e l e m e n ts [ ] , o u t b u f f e r [ ] )

2 {

3 f o r ( i = 0 ; i < | e l e m e n t s | ; i = i + 4 )

4 {

5 n1 = e l e m e n t s [ i ] ∗ A;

6 .. .

7 n4 = e l e m e n t s [ i +3 ] ∗ A;

8 z1 = c o u n t z e r o b y t e s ( n1 ) ;

9 .. .

10 z4 = c o u n t z e r o b y t e s ( n4 ) ;

11 mask = ( z4 << 6) | ( z3 << 4 ) ←-

12 | ( z2 << 2) | z 1 ;

13 b u f f e r ← mask ;

14 b u f f e r ← n1 ;

15 .. .

16 b u f f e r ← n4 ;

17 }

18 }

Listing 1: Pseudo code for AN encoded 4-wise Null

Suppression. elements is the input array while buffer is

the output array. | elements | denotes the array’s number

of elements.

the ﬁrst data item is stored and the according bytes are

stored. The restored item is checked against A and er-

rors may be handled. Then, the decoded data item is

stored in the output array and the read position of the

input buffer is advanced by the number of non-zero

bytes. Finally, the mask is shifted right, so that the

same steps can be repeated for the next three items,

since always 4 items are represented by a single-byte

compression mask.

3.2 AN-encoded Run-Length

Compression

The basic idea of Run-Length Compression (RLE) is

to compress consecutive sequences of a same value –

the runs. For compression, the distinct original value

is stored together with the number of uninterrupted

appearances – the run length. For decompression,

these values are rolled out again.

In contrast to our AN-encoded Null Suppression

compression scheme, our AN-encoded RLE approach

compresses ﬁrst and encodes afterwards, since runs

are condensed to the value and its run length, there-

fore encoding only 2 values instead of long runs of

values. That means, we reduce the necessary work for

encoding using compression. In detail, AN-encoded

RLE compression works as follows: Consecutive ap-

pearances of values are counted – the run lengths.

Whenever a new value is encountered, the previous

value and its run length are encoded and written to

the output buffer. Decompression is done by read-

ing in pairs of encoded values and their encoded run

lengths. After checking both of them against A the de-

coded value is written “run length” times to the output

buffer. The SIMD variant works analogously by com-

Resiliency-awareDataCompressionforIn-memoryDatabaseSystems

329

Table 1: Choice of constant A with its number of effective bits |A|. p

... p

are the respective probabilities of not detecting

1.. . 6 bit ﬂips, cyc – CPU cycles for 4-wise SIMD decoding on Ivy Bridge architecture (taken from Intel Intrinsics Guide:

https://software.intel.com/sites/landingpage/IntrinsicsGuide/), comp. rate – NS compression rate for 16-bit random integers –

memory overhead of AN-encoded compression.

A |A| p

cyc Null Sup.

comp. rate

AN-encoded

mem. overhead

compr. - - - - - - - - 0.561 -

3 4 0.0 14.2 3.74 2.73 1.124 0.567 8 0.729 29.94%

26 5 0.0 2.2 1.72 0.93 0.515 0.282 8 0.803 43.14%

118 7 0.0 0.0 0.51 0.34 0.210 0.130 8 0.810 44.39%

250 8 0.0 0.0 0.25 0.19 0.133 0.088 8 0.811 44.56%

507 9 0.0 0.0 0.08 0.07 0.046 0.040 8 0.936 66.84%

641 10 0.0 0.0 0.08 0.06 0.040 0.030 3 0.962 71.48%

7567 13 0.0 0.0 0.00 0.00 0.007 0.007 8 1.054 87.88%

58659 16 0.0 0.0 0.00 0.00 0.000 0.001 8 1.061 89,13%

paring against and writing out multiple values at once

for compression and decompression, respectively.

4 EVALUATION

In this section, we discuss ﬁrst the choice of the con-

stant A and what trade-offs it introduces. Then, we

show experimental results of our AN-encoded exten-

sions of Null Suppression and Run-Length Compres-

sion. Our evaluation is based on a set of 100 mil-

lion 32-bit random integers with only 16 effective bits

to guarantee compressibility and to have no overﬂow

when encoding. The experiments were run on a ma-

chine with an ASUS P9X79 Pro mainboard running

a 12-core Intel i7-3960X CPU and 8x4 GiB (32GiB)

DRAM. The compression speed results are averages

of 10 runs; the relative standard error does not exceed

0.05%. Due to space constraints, we only report our

evaluation results of our AN-encoded Null suppres-

sion technique.

Parameterization of AN Encoding

As mentioned earlier, the choice of the constant A af-

fects fault detection rate, memory blow-up, and en-

coding/decoding performance. Table 1 shows some

“good” A’s that range in their fault coverage, bit size,

and decoding performance

. For example, A = 3 has

a size of 2 bits, can detect all single bit ﬂips but only

86% of double bit ﬂips, and requires 4 CPU cycles

for decoding. On the other extreme, A = 58,659 can

detect up to 5 bit ﬂips, but is 16 bits wide, leading to

2x memory increase. The “golden” A is equal to 641,

The probabilities for the table are taken from the

experimental results of (Hoffmann et al., 2014); they

can be found on https://www4.cs.fau.de/Research/CoRed/

experiments.

with sufﬁciently high fault coverage, limited memory

increase, and very fast decoding of only 3 cycles.

AN-encoded Null Suppression

The second last column of Table 1 shows the com-

pression rates for our AN-encoded Null Suppression,

whereas the last column reports the memory over-

head. Notice that the original compression rate with-

out AN-encoding is 0.561 as depicted in the ﬁrst row.

As we can see, our AN-encoded extension introduces

a memory overhead of 30-90%. This overhead re-

duces with smaller value ranges. For our golden

A = 641, our AN-encoded compressed data requires

less space than uncompressed data. That means, we

are able to compress and to protect our data with less

space as uncompressed, which is a very good results

from our point of view.

To evaluate the performance, we implemented our

presented AN-encoded schemes in a sequential and

a vectorized (SIMD - SSE 4.1) version, whereas we

used A = 641 in our evaluation. As expected, AN-

coding causes slowdowns of 20-25% in case of the

sequential implementation, and 5-10% for the SIMD

implementation. The difference between the sequen-

tial and SIMD slowdowns stems from the signiﬁ-

cantly different sequences of generated instructions;

in a nutshell, the sequential version introduces four

additional instructions while the SIMD version adds

only one. Nevertheless, the performance slowdown

is low, so that the combination of AN-encoding and

compression is very promising to efﬁciently tackle an

increasing dynamic bit ﬂip rate.

5 RELATED WORK

Several techniques have been presented to deal with

certain error classes in the past. To our best knowl-

DATA2015-4thInternationalConferenceonDataManagementTechnologiesandApplications

330

edge, no research was done in the ﬁeld of databases

to protect in-memory data against arbitrary dynamic

bit ﬂips, except our own investigations on error de-

tecting B-Trees (Kolditz et al., 2014). In the ﬁeld

of databases, other work mainly concentrates on han-

dling errors during I/O operations, or regards situa-

tions where the system inadvertently writes to wrong

memory regions, e.g. due to software bugs like buffer

overﬂows or broken pointers.

For instance, (Graefe and Stonecipher, 2009;

Graefe et al., 2012) harden the well-known B-Tree

and variants against errors during I/O-operations or

against certain other tree corruptions, whereas the

techniques are not suited for online error detection.

Dynamic bit ﬂips may lead to false positives and false

negatives when querying such trees between there

maintenance checks.

(Sullivan and Stonebraker, 1991) deal with cor-

ruptions due to arbitrary writes by employing hard-

ware memory protection for individual pages. Mem-

ory pages are protected using hardware directives and

the protection is removed only when accessing the

pages through a special interface. The routines for

protecting and unprotecting require kernel calls which

leads to high performance penalties. Additionally,

while a page is unprotected other threads may still

corrupt data.

6 CONCLUSION

Low-cost, high-density main memory lead to a

change in the database ecosystem towards in-memory

designs, whereas data compression plays an impor-

tant role, too. However, due to the constant increase

of memory density, main memory becomes more and

more unreliable. This results in dynamic random

errors and in future hardware generations the error

rates are likely to escalate. General purpose ECC

mechanisms are not the appropriate solution from a

cost perspective. Therefore, we propose to exploit

database context knowledge by a tightly combination

of compression and resilience techniques. As pre-

sented, AN-encoding is a code family which allows

arithmetic operations on code words and, by that, is

suitable for transactional and analytical workloads.

We showed that by using AN-encoded extensions of

compression schemes, much higher bit ﬂip detection

capabilities are achievable than with SECDED ECC.

Our preliminary evaluation shows that data compres-

sion schemes augmented with AN-encoding become

resilient at a low memory and performance cost. Nev-

ertheless, more research in this direction is necessary

from a conceptual as well as implementation perspec-

tive.

ACKNOWLEDGEMENTS

This work is partly supported by the German Re-

search Foundation (DFG) within the Cluster of Ex-

cellence “Center for Advanced Electronics Dresden”

(cfAED) and by the DFG-grant LE-1416/26-1.

REFERENCES

Abadi, D., Madden, S., and Ferreira, M. Integrating com-

pression and execution in column-oriented database

systems. In SIGMOD, pages 671–682.

Chen, Z., Gehrke, J., and Korn, F. (2001). Query optimiza-

tion in compressed database systems. SIGMOD Rec.,

30(2):271–282.

Garcia-Molina, H. and Salem, K. (1992). Main Memory

Database Systems: An Overview. Knowledge and

Data Engineering, 4(6).

Graefe, G., Kuno, H., and Seeger, B. (2012). Self-

diagnosing and self-healing indexes. In DBTest, pages

8:1–8:8.

Graefe, G. and Stonecipher, R. (2009). Efﬁcient veriﬁcation

of b-tree integrity. In BTW, pages 27–46.

Hoffmann, M., Ulbrich, P., Dietrich, C., Schirmeier, H.,

Lohmann, D., and Schr

oder-Preikschat, W. (2014).

A Practitioner’s Guide to Software-based Soft-Error

Mitigation Using AN-Codes. In HASE ’14, pages 33–

40.

Hwang, A. A., Stefanovici, I. A., and Schroeder, B. (2012).

Cosmic Rays Don’t Strike Twice: Understanding the

Nature of DRAM Errors and the Implications for Sys-

tem Design. SIGARCH Comput. Archit. News, 40(1).

Italiano, G. F. (2010). Resilient algorithms and data struc-

tures. In CIAC 2010, pages 13–24.

Kolditz, T., Kissinger, T., Schlegel, B., Habich, D., and

Lehner, W. (2014). Online bit ﬂip detection for in-

memory b-trees on unreliable hardware. In DaMoN,

pages 5:1–5:9.

Lemire, D. and Boytsov, L. (2012). Decoding billions

of integers per second through vectorization. CoRR,

abs/1209.2137.

Moon, T. K. (2005). Error Correction Coding: Mathemati-

cal Methods and Algorithms. Wiley.

Roth, M. A. and Van Horn, S. J. (1993). Database compres-

sion. SIGMOD Rec., 22(3):31–39.

Schiffel, U. (2011). Hardware Error Detection Using AN-

Codes. PhD thesis, Technische Universit

at Dresden.

Schlegel, B., Gemulla, R., and Lehner, W. (2010). Fast inte-

ger compression using simd instructions. In DaMoN,

pages 34–40.

Sullivan, M. and Stonebraker, M. (1991). Using write pro-

tected data structures to improve software fault tol-

erance in highly available database management sys-

tems. In VLDB, pages 171–180.

Warren, H. S. (2002). Hacker’s Delight. Addison-Wesley

Longman Publishing Co., Inc., Boston, MA, USA.

Resiliency-awareDataCompressionforIn-memoryDatabaseSystems

331
