An Aspect-Oriented Extension to the OWL API

Specifying and Composing Views of OWL Ontologies using Ontology Aspects and

Java Annotations

Ralph Sch

afermeier, Lidia Krus and Adrian Paschke

Corporate Semantic Web Group, Institute of Computer Science, Freie Universit

at Berlin, Berlin, Germany

Keywords:

Modular Ontology Development, Aspect-Oriented Programming, Ontology APIs.

Abstract:

Aspect-Oriented Programming (AOP) is a technology for the decomposition of software systems based on

cross-cutting concerns. As shown in our previous work, cross-cutting concerns are also present in ontologies,

and Aspect-Oriented Ontology Development (AOOD) can be used for ﬂexible and dynamic ontology mod-

ularization based on functional and non-functional requirements. When ontologies are used in applications,

application and ontology-related requirements often coincide. In this paper, we show that aspects in ontologies

can be expressed as software aspects and directly referred to from software code using the well-known AspectJ

language and Java annotations. We present an extension of the well-known OWL API with aspect-oriented

means that allow transparent access to and manipulation of ontology modules that are based on requirements.

1 INTRODUCTION

Ontologies provide a formal representation of shared

knowledge for use in information systems. Recent

years have witnessed a signiﬁcant adoption of ontolo-

gies in IT, not least due to the standardization activi-

ties by the W3C leading, among others, to the incep-

tion of the Web Ontology Language OWL, which can

be used to describe ontologies and knowledge bases

using Description Logics (DL).

Still, the authoring of ontologies is a potentially

Source code and documentation are available at https://

github.com/ag-csw/aspect-owlapi

There is a dissent between different communities on the

exact deﬁnition of the term ontology. Some communities

deﬁne an ontology as only the conceptualization of a spe-

ciﬁc discourse domain, i.e., a statemtent of a logical theory

about concepts and their relations. A knowledge base, by

this deﬁnition, is a set of assertions about concrete objects

(instance data), grounded in the conceptualization given

by the ontology. In this paper, we commit to the deﬁni-

tion of ontologies by Guarino and Giaretta (Guarino and

Giaretta, 1995), according to which a knowledge base is a

special kind of ontology. Therefore, whenever we speak

of ontologies, we also include what others would refer to

as knowledge bases. We have made this choice because

in this work, we exclusively talk about OWL 2 ontologies,

and the OWL 2 speciﬁcation does not make this termino-

logical distinction either

http://www.w3.org/TR/2012/REC-owl2-syntax-20121211/

complex and resource intensive process. Therefore,

reusability of existing ontologies is generally desired.

However, reuse of ontologies is often not trivial, as

many of the existing ontologies designed with this

purpose in mind are extremely large, and only small

parts of them are actually relevant in a particular reuse

scenario (Noy and Musen, 2004).

Ontology modularization tackles the problem of

creating meaningful reusable ontology modules or

views of large monolithic ontologies that can be easier

explored or extracted. Beyond reuse, ontology mod-

ularization may serve a number of further goals, such

as the improvement of reasoning and query result re-

trieval performance, scalability for ontology evolution

and maintenance, complexity management, ameliora-

tion of understandability, context-awareness, and per-

sonalization (Parent and Spaccapietra, 2009).

A signiﬁcant number of approaches to the prob-

lem of ontology or knowledge base modularization

therefore exist, each of them tackling one or several

of the above-mentioned problems.

In our previous work (Sch

afermeier and Paschke,

2014), we have presented Aspect-Oriented Ontology

Development (AOOD) as a uniﬁed, goal indepen-

dent approach to deﬁning syntactic ontology modules,

which was inspired by the Aspect-Oriented Program-

ming (AOP) or Aspect-Oriented Software Develop-

ment (AOSD) paradigm. A commonly accepted no-

tion of an ontology module is that deﬁned by the con-

Schäfermeier, R., Krus, L. and Paschke, A..

An Aspect-Oriented Extension to the OWL API - Specifying and Composing Views of OWL Ontologies using Ontology Aspects and Java Annotations.

In Proceedings of the 7th International Joint Conference on Knowledge Discovery, Knowledge Engineering and Knowledge Management (IC3K 2015) - Volume 2: KEOD, pages 187-194

ISBN: 978-989-758-158-8

187

cept of conservative extensions as proposed by (Grau

et al., 2008) and (Konev et al., 2009), which guarantee

that a module is self-contained in the sense of being

semantically equivalent to its parent ontology wrt. a

particular signature. A syntactic module, on the other

hand, is deﬁned less rigidly as a set of axioms that is

a subset of all axioms of the parent ontology.

Applications using ontologies come with a set of

requirements. A subset of these requirements are re-

lated to how the ontology is going to be used and what

the application developers expect to get back from the

ontology. These requirements are in fact related to

the ontology itself, still they concern the application’s

mode of operation. As those particular requirements

affect both the application and the ontologies in the

same manner, it appears natural to have them reﬂected

in a uniﬁed way in the application code as opposed to

have them scattered across the application. For this

reason, we have developed a formalism that allows

for a direct mapping of software aspects to ontology

aspects and a system that permits to control the use of

ontology aspects from within the application code in

a declarative fashion.

The contribution of this paper consists of a soft-

ware artifact that makes ontology aspects accessible

to developers of semantic web applications. We have

implemented it in the form of an aspect-oriented ex-

tension to the well-known OWL API

, a Java API for

OWL 2 ontologies, using AspectJ

as a Java aspect

language and Java annotations as a way to declara-

tively control ontology aspects from Java code.

The remainder of this paper is structured as fol-

lows. In section 2, we decribe the formalism of

aspect-oriented ontologies for OWL. In Section 3, we

demonstrate how we make this formalism available

in Java code using Java annotations. In Section 4,

we discuss the results on the basis of a an experi-

mental evaluation using an ontology from the arts do-

main that contains AOOD aspects for temporal attri-

bution, provenance information and reasoning com-

plexity. Section 5 gives an overview of related work.

Section 6 concludes and points out future work.

2 ASPECT-ORIENTED

ONTOLOGY DEVELOPMENT

In (Sch

afermeier and Paschke, 2014), we describe

a formalism for Aspect-Oriented Ontology Devel-

opment (AOOD) which we derived from the basic

principles of Aspect-Oriented Programming (AOP).

http://owlapi.sourceforge.net/

https://eclipse.org/aspectj/

Aspects in software are self-contained modules that

comprise a well-deﬁned fragment of a system’s func-

tionality and instructions on how to combine this

functionality with the main system, the former being

referred to as advice and the latter being referred to as

pointcuts.

Advice is regular software code, in the majority

of cases written in the same programming language

as the main system. A pointcut is a collection of so

called join points, points in the code of the main sys-

tem where the advice of the aspect is supposed to be

executed. A pointcut can be an exhaustive list of join

points or an abstract description thereof by the means

of quantiﬁcation.

Thereby, advice adds a well-deﬁned piece of func-

tionality to an existing system, while the pointcut con-

tains all the necessary information on where exactly

to add it. Each piece of information reﬂects a require-

ment or business concern. As deﬁned by the IEEE

standard 1471 of software architecture (Group, 2000),

“concerns are those interests which pertain to the sys-

tems development, its operation or any other aspects

that are critical or otherwise important to one or more

stakeholders”. The functionality in the advice nor-

mally reﬂects a cross-cutting concern, i.e. the imple-

mentation of a requirement that cross-cuts with other

requirements of the system.

As in software development, cross-cutting con-

cerns are linked to requirements. Requirements can

be functional, i.e., directly related to the business

goals the system or ontology is supposed to accom-

plish. Non-functional requirements, in contrast, are

related to goals concerning the system or ontology

itself. Functional ontology requirements are gener-

ally directly related to the competency questions the

ontology is supposed to answer, while examples for

non-functional requirements include provenance in-

formation, multilinguality and reasoning complexity.

Each of these requirements is mapped to one ore

multiple sets of axioms in an ontology. If there ex-

ists a relationship between an aspect and an axiom, it

means that this axioms belongs to the aspect in ques-

tion. This way, an ontology can be modularized into

(possibly overlapping) modules, each module repre-

senting a requirement, and each module-requirement

pair being encapsulated in an aspect.

Aspects can, in turn, be formal descriptions them-

selves, i.e., just as the ontology module they are

mapped to, they can be ontological statements as well.

For example, a set of facts in an OWL ontology can

be related to a temporal aspect, e.g. Bonn is capital

of West Germany, which was only valid from 1949 to

1990, where the temporal aspect is an OWL individ-

ual that comes with relations and properties formal-

KEOD 2015 - 7th International Conference on Knowledge Engineering and Ontology Development

188

ized using the W3C time ontology and representing

the time interval 1949-1990.

The individual representing the aspect may be di-

rectly referenced by its IRI (if it is a named individ-

ual). Beyond that, it is possible to deﬁne super aspects

by using some sort of query (e.g. all the things that

happened during the 20th century which is equivalent

to all facts in the ontology that are related to temporal

aspects which are valid between 1900 and 1999).

2.1 An Aspect Vocabulary for

Ontologies

We deﬁne a vocabulary that is suitable for a sound and

complete description of aspects in ontologies on an

abstract level. Software aspects apply to lines of code

where the execution ﬂow is diverted due to a call to

a method, function or routine (or whichever callable

units the paradigm of the programming language at

hand deﬁnes), i.e., each call is a candidate for a join

point, and the system can be changed by advising the

join points.

In the case of ontologies, the application of an as-

pect would mean the modiﬁcation of factual (Tbox or

Abox) knowledge. Hence, elements that can be used

as join points in ontologies must be expressions that

represent canonical units of factual knowledge. What

these simple expressions exactly are is deﬁned by the

knowledge representation model of each speciﬁc lan-

guage. In the case of RDF they are triples, while in the

case of OWL, they are axioms. Once the simple ex-

pressions of a language have been identiﬁed, we can

map the relevant concepts from the AOSD domain to

ontologies and come up with an abstract deﬁnition of

ontology aspects:

Pointcut: A pointcut in an ontology is the set of

simple expressions that will be affected by the facts

that are contained in the aspect (and stem from a

cross-cutting requirement).

Advice: An advice in an ontology is a set of facts

that will be applied to the facts in the pointcut and,

depending on their nature, extend or restrict the facts

in the pointcut. A language aspect might, for exam-

ple, add language speciﬁc information (a translation)

to the facts in the pointcut, while a temporal aspect

might impose a temporal restriction on them (with the

consequence that they are only valid during a speci-

ﬁed period in time).

Aspect: An aspect in an ontology is a compound

entity consisting of a pointcut and an advice.

Functional

Aspect

Resoning

Complexity

Access

Restriction

Nonfunctional

Aspect

Compatibility

Provenance

Based

Trust

≡

Provenance

Trust

Customer

Speciﬁc

Feature

rdfs:subPropertyOf

Temporal

Aspect

rdfs:subClassOf

Aspect Advice Pointcut

rdfs:range

rdfs:domain

hasAdvice hasPointcut

rdfs:range

owl:equivalentClass

hasAdvice some Advice

hasPointcut some Pointcut

≡

<<annotation>>

…

Figure 1: The aspect ontology for OWL 2 ontologies con-

ceptualizing the terms Aspect, Pointcut and Advice. The two

annotation properties hasAdvice and hasPointcut can be ap-

plied to axioms (as opposed to only individuals) and are

not part of the OWL semantics. The class hierarchy under

Aspect is preliminary and designed to be extended by users.

The separation of functional and non-functional aspects cor-

responds to functional vs. non-functional concerns.

2.2 Embedding Aspects in OWL

Ontologies

The foundation for aspect-oriented ontologies is an

ontology that formalizes the concept of an aspect as

described in the above Section 2.1. The ontology is

depicted in Figure 1. Given this ontology of aspects,

we deﬁne an aspect-oriented ontology module as fol-

lows:

Deﬁnition 1 (Aspect-oriented Ontology Module).

Given an ontology O that consists of a ﬁnite set

of axioms Ax

, an aspect ontology O

with the set

A ⊆ Sig(O

) of all aspect individuals in O

, A =

{a|∃i ∈ O

: hasAdvice(a, i)} an aspect individual

∈ A and a predicate hasPointcut, then O

⊆

O, consisting of the set of axioms Ax

:= {ax ∈

| hasPointcut(a

, ax)} is an ontology module de-

ﬁned by the aspect a

An Aspect-Oriented Extension to the OWL API - Specifying and Composing Views of OWL Ontologies using Ontology Aspects and Java

Annotations

189

Manual annotation/

selected editing

context in tool

Query based

aspect description

Query

Original ontology Ontology with aspect

meta descriptions

Aspect-based

module selection

Aspect names

or descriptions

Ontology

module

Requirement 1

Requirement 2

Requirement 3

Requirement 4

Requirement 1

Requirement 4

Requirements

Aspects

Modules

Figure 2: The approach of Aspect-Oriented Ontology Development (AOOD): Parts of an ontology are annotated with aspects

by some query (left) or manually (center). Later, parts of the ontology may be extracted by giving a name or specifying a

query (right). The aspect descriptions provide a view on ontology modules (bottom). On a higher level, each aspect represents

a requirement (top).

Aspect individuals can either be named or anony-

mously deﬁned by some query (in, for example,

SPARQL or SPARQL DL), which would then cor-

respond to the quantiﬁcation principle mentioned

above.

The connnection of an aspect individual to an on-

tology axiom is a kind of reiﬁed statement. While

reifcation is deﬁned syntactically on the data ex-

change level (namely for RDF), OWL does not de-

ﬁne semantics for it (and therefore, there exists no di-

rect syntactic category for reiﬁcation in OWL). The

Aspect-Oriented Ontology Development approach

uses reifacation as the infrastructure, with a particu-

lar semantics described above. Technically, instead

of introducing a dedicated syntactic category, for the

sake of backwards compatibility, we use the OWL 2

annotation mechanism for making the connection be-

tween aspects and their advices and pointcuts.

3 OWL ASPECTS

IMPLEMENTED AS GENERIC

ASPECTJ ASPECTS

SUPPLEMENTING THE OWL

API

The most notable APIs for web ontologies are Apache

Jena

and the OWL API

. With both being Java APIs,

Jena’s scope are RDF graphs while the OWL API is

http://jena.apache.org/

http://owlapi.sourceforge.net/

tailored to the OWL language

, providing an object

model for OWL entities and axioms and interfaces for

DL-based reasoning and explanation support. In what

follows, we describe an extension of the OWL API

by programmatic access to OWL aspects as deﬁned

in the previous sections.

3.1 Requirements

We deﬁned the functionality of our approach in terms

of functional requirements, which can be seen in Ta-

ble 1.

We designed an aspect-oriented extension of the

OWL API using the Java aspect language AspectJ

We use Java aspects in order to intercept read/write

access to the OWL API’s Java object model of a

loaded OWL ontology and advice the calls by code

responsible for extracting ontology modules affected

by an OWL aspect.

With regard to requirement 2 we decided to use

Java annotations as a means to convey the selected

aspects from the Java side.

The heart of the extension is a set of pointcut

deﬁnitions that intercept all calls to the OWL API

that either return or manipulate OWL entities or ax-

ioms. Client code using the OWL API can use the

@OWLAspect java annotation type to specify one ore

more aspect IRIs either on the method or class level.

If one or more annotations of that type are encoun-

tered, then all operations on the OWL API within

At the time of the writing of this report, the target language

of the OWL API was OWL 2.

https://eclipse.org/aspectj/

KEOD 2015 - 7th International Conference on Knowledge Engineering and Ontology Development

190

Table 1: Functional requirements for the OWL API extension with ontology aspects.

ID Name Description

F-1 aspects The system should allow for mapping aspects to ontology modules.

F-1.1 aspect declaration The system should permit the mapping of declarative aspect descriptions to OWL aspects

in the set of loaded ontologies.

F-1.1.1 aspect identiﬁcation Aspects should be ontological entities identiﬁed by IRIs, as deﬁned in the AspectOWL

ontology.

F-1.1.2 aspect combination The declarative selection of aspects should allow for a combination of multiple aspects

using logical AND/OR operations.

F-2 ontology change If an aspect declaration is associated with code manipulating an ontology, then the manipu-

lation must only affect this aspect

F-2.1 axiom addition If an axiom is added, then it will be annotated with the aspect(s) present in the declaration.

F-2.2 axiom deletion If an axiom is deleted, and an aspect declaration is present in the Java code, then only

the corresponding aspect associations must be deleted in the ontology (the axiom is only

removed from this aspect, not from the ontology).

F-3 module extraction If an aspect declaration is associated with code reading from an ontology, then only that

part of the ontology is returned, which is associated with the given aspects. The rest of the

ontology is hidden.

Listing 1: Example client code using the OWL API. Note

that aspect references are added transparently and uninva-

sively as method annotations. Client code itself does not

need to be changed.

@OWLAspect ( { ” h t t p : / / www. fu−b e r l i n .

de / csw / o n t o l o g i e s / aood /

o n t o l o g i e s / a s p e c t 1 2 3 ” , ” h t t p : / /

www. f u−b e r l i n . de / csw / o n t o l o g i e s /

aood / o n t o l o g i e s / myAspect456 ” } )

p u b l i c v o id d oSo me thi ng ( ) {

Se t<OWLAxiom> a l l Ax i o ms =

myOntology . get Axi oms ( ) ;

. . . }

the context of the annotation will only be executed

on the subset of the ontology that corresponds to the

aspect(s) speciﬁed by the annotations. For example,

a call to OWLOntology.getAxioms() from a client

method with the annotations from Listing 1 would

only return those axioms that belong to the modules

speciﬁed by the two IRIs used in this example. Ac-

cordingly, write operations would also only be per-

formed on the subset.

3.2 Conjunctive and Disjunctive

Combination of Aspects

In order to fulﬁll requirement F-1.1.2, the annota-

tion type system had to be extended by some kind of

boolean arithmetics that allows for conjunctive and/or

disjunctive combination of multiple aspects. The Java

annotations system does not permit relations between

single annotations in the same place, but nesting of

annotations is possible.

In order to provide a syntax for boolean opera-

tions, we subclassed the OWLAspect annotation type

by OWLAspectAnd and OWLAspectOr.

Unfortunatley, nesting of annotations is restricted

to non-cyclic nesting levels, disallowing arbitrary

nesting (and thereby arbitrary boolean combinations).

However, using the distributivity property of boolean

operations, it is possible to bring every boolean for-

mula into a non-nested form. As a consequence, this

approach is feasible for arbitrary boolean combina-

tions of aspect declarations conveyed using Java an-

notations.

An example of a combination would be:

@OWLAspectOr ( {

@OWLAspectAnd ( {” h t t p : / / . . . # A sp e ct 1 ” ,

” h t t p : / / . . . # A sp ect 2 ” } ) ,

@OWLAspectAnd ( {” h t t p : / / . . . # A sp e ct 2 ” ,

” h t t p : / / . . . # A sp ect 3 ”} )

})

3.3 Syntactic vs. Semantic Modules

The above approach allows for the selection of sub-

sets of axioms, also referrred to syntactic modules as

mentioned in Section 1. Depending on the use case,

this might be sufﬁcient, or it might be necessary to

extend the selected set of axioms to a proper semantic

module, such that the parent ontology is a conserva-

tive extension of the module. The system we present

here may extend the selected subset to a proper mod-

ule by using syntactic locality (Del Vescovo et al.,

2012) as an approximation.

4 CASE STUDY

We conducted an experimental evaluation of our ap-

proach in the for of a case study using an ontology

from the arts domain, containing information about

paintings as well as context information in the form of

An Aspect-Oriented Extension to the OWL API - Specifying and Composing Views of OWL Ontologies using Ontology Aspects and Java

Annotations

191

Table 2: Information encoded in the ontology from the case study: Famous paintings and the paintings’ creators and locations.

OWL aspects comprise (a) time, (b) provenance, and (c) reasoning complexity (not shown in the table).

Painter Painting Location Time period Provenance

Raphael Sistine Madonna Italy 1513-1754 Wikipedia

Germany 1754-1945 Wikipedia

since 1955 Wikipedia

Russia 1945-1955 Wikipedia

urer Felsenschloss Germany 1494-1945 Berliner Zeitung

since 2000 Berliner Zeitung

Russia 1945-2000 Berliner Zeitung

Frauenbad Germany 1496-1945 The New York Times

since 2001 Spiegel

Azerbaijan 1993 The New York Times

USA 1997-2001 Spiegel, The New York Times

Johannes der T

aufer Germany 1503-1945 Die Welt

since 2004 Die Welt

Unknown 1945-2003 Die Welt

Estonia 2003-2004 Die Welt

aspects. The particular case stems from a consortium

partner in the realm of digital curation of content from

the arts domain. The ontology we used is an extended

version of the publicly available painting ontology

The ontology was used to model geolocations of con-

temporary artworks.

The additional aspects that were modeled were

• location changes over time (for which period in

time was painting A in location X), using tempo-

ral aspects,

• provenance information about each location/time

statement (which source stated that painting A

was in location X during the time interval T) using

provenance aspects, and

• the belonging of each axiom to one or several

of the OWL 2 proﬁles OWL2-EL, OWL2-RL or

OWL2-QL, using reasoning complexity aspects.

Table 2 provides an example of the information

encoded in the ontology.

For the temporal aspects, the W3C time ontol-

ogy

was used. For the provenance aspects, we used

the W3C PROV ontology

The ontology contains 1,378 axioms. We used the

OWL API in combination with the Pellet reasoner in

order to extract the subsets of the ontology that con-

form to the OWL-EL, QL, and RL proﬁles, respec-

tively, and annotated the axioms with the correspond-

ing reasoning complexity aspect.

In order to test the functional requirements, we

implemented unit tests in which the ontology de-

scribed above is loaded and a variety of read and write

http://spraakbanken.gu.se/rdf/owl/painting.owl

http://www.w3.org/TR/owl-time/

http://www.w3.org/TR/prov-o/

operations is performed, each using different combi-

nations of aspect annotations.

The results show that the relevant use cases can be

captured by the implementation. Competency ques-

tions, such as Where was an artpiece located at a par-

ticular point in time? or a reduced view on the ontol-

ogy with only axioms belonging to a less expressive

but tractable OWL proﬁle for, e.g., only browsing the

class hierachy, could all be represented with ontology

aspects and corresponding java annotations.

Details on the cases and the different combina-

tions thereof we coverered can may be examined in

the github repository.

5 RELATED WORK

Aspect-oriented Ontology Development for ontology

module deﬁnition shares similarities with the work of

Doran et al. (Doran et al., 2008) and d’Aquin et al.

(d’Aquin et al., 2007).(Doran et al., 2008) proposes

SPARQL queries in order to deﬁne ontology modules.

The authors show that a set of specialized approaches,

such as (d’Aquin et al., 2006), (Seidenberg and Rec-

tor, 2006), (Doran et al., 2007) and (Noy and Musen,

2000) may be reformulated in the form of SPARQL

queries. (d’Aquin et al., 2007) proposes a similar

approach using graph transformations and relying on

user-deﬁned graph-based extraction rules.

(Grau et al., 2005) presents a partitioning ap-

proach using E -Connections (Cuenca Grau et al.,

2006). The criterion for the partitioning process is

semantic relatedness. This is determined by check-

ing the E -safe property a structural constraint which

avoids the separation of semantically dependent ax-

KEOD 2015 - 7th International Conference on Knowledge Engineering and Ontology Development

192

before

TemporalAspect

Duerer FelsenschlossObj

Painting Painter

rdf:type

isPointCutOf

"1496-01-01-00:00:00"

^^xsd:dateTime

hasBeginning

createdBy

Germany

Russia

hasLocationCountry

"1945-01-01-00:00:00"

^^xsd:dateTime

hasEnd

TemporalAspect1

isPointCutOf

"2000-01-01-00:00:00"

^^xsd:dateTime

hasBeginning

TemporalAspect3

isPointCutOf

„1945-01-01-00:00:00"

^^xsd:dateTime

hasBeginning

„2000-01-01-00:00:00"

^^xsd:dateTime

hasEnd

TemporalAspect2

rdf:type

TimeInterval1 TimeInterval3 TimeInterval2

hasAdvice

hasAdvicehasAdvice

DateTimeInterval

rdf:type

Figure 3: Example of how a temporal aspect (of locations of D

urer’s paintings Feldschloss) is concretely expressed in the

knowledge base.

ioms in order to achieve semantically consistent mod-

ules. The relatedness of the different modules is re-

tained by the E -Connections. Concept subsumption

or the use of roles across different modules is not

possible. E -Connections apply to ontology entities

(classes, individuals and properties), in contrast, our

approach applies to axioms.

Schlicht et al. propose a semi-automated ap-

proach to ontology partitioning based on application-

imposed requirements (Schlicht and Stuckenschmidt,

2008). The method constructs a dependency graph of

strongly interrelated ontology features, such as sub/-

super concept hierarchy, concepts using the same re-

lations, or similarly labeled concepts. Then, the on-

tology is partitioned retaining strongly related groups

in the same module. The method is parametrizable

by specifying the features taken into account for con-

structing the dependency graph and the size a module

should have in terms of the number of axioms.

While the latter approaches work with a posteriori

modularization of existing ontologies, a third arising

class of methodological approaches aim at modular

construction of ontologies in an a priori manner.

Related work in this area has been accomplished

by (Thakker et al., 2011), proposing a methodolog-

ical framework for constructing modular ontologies

driven by knowledge granularity. The proposed ap-

proach involves a separation into three levels: an

upper ontology, modeling the theoretical framework,

domain ontologies for reusable domain knowledge,

and domain ontologies for application speciﬁc knowl-

edge.

6 CONCLUSION AND OUTLOOK

This paper describes an approach to declarative syn-

tactic or semantic ontology module selection for de-

velopers of semantic web applications, based on our

approach to aspect-oriented ontology modularization.

We presented a demo implementation based on the

OWL API, which we extended with AspectJ aspects

and an annotation system, which is used to spec-

ify ontology aspects (referenced by IRIs), which are

mapped to ontology modules. In this fashion, opera-

tions performed using the OWL API are restricted to

the submodule(s) of the ontology speciﬁed using the

annotations.

The approach is transparent in that developers

need not change their application code. As mentioned

An Aspect-Oriented Extension to the OWL API - Specifying and Composing Views of OWL Ontologies using Ontology Aspects and Java

Annotations

193

in section 4, a weakness of the approach is that the

pointcut deﬁnitions need to be exhaustive in order to

capture all relevant method calls in the OWL API.

Furthermore, they may potentially break in case of

future changes of the OWL API.

Future work comprises the integration of the dec-

laration of aspects using SPARQL or DL based

queries from our previous work into the API ex-

tension for more dynamic module selection. Cur-

rently, an extension to the well-known ontology ed-

itor is developed, which allows focused work on on-

tology modules based on aspects by hiding parts of

the ontology that do not belong to a selected aspect.

WebProt

e was built on top of the OWL API, and the

aspect-oriented extension to the OWL API described

in this paper, allows the implementation of this fea-

ture in an uninvasive fashion, i.e., without changing

any WebProt

e or OWL API source code.

REFERENCES

Cuenca Grau, B., Parsia, B., and Sirin, E. (2006). Com-

bining OWL ontologies using E -Connections. Web

Semantics: Science, Services and Agents on the World

Wide Web, 4(1):40–59.

d’Aquin, M., Doran, P., Motta, E., and Tamma, V. A. M.

(2007). Towards a parametric ontology modulariza-

tion framework based on graph transformation. In

Grau, B. C., Honavar, V., Schlicht, A., and Wolter,

F., editors, WoMO, volume 315 of CEUR Workshop

Proceedings. CEUR-WS.org.

d’Aquin, M., Sabou, M., and Motta, E. (2006). Modular-

ization: a key for the dynamic selection of relevant

knowledge components. In Haase, P., Honavar, V.,

Kutz, O., Sure, Y., and Tamilin, A., editors, WoMO,

volume 232 of CEUR Workshop Proceedings. CEUR-

WS.org.

Del Vescovo, C., Klinov, P., Parsia, B., Sattler, U., Schnei-

der, T., and Tsarkov, D. (2012). Syntactic vs. Semantic

Locality: How Good Is a Cheap Approximation? In

Schneider, T. and Walther, D., editors, Workshop on

Modular Ontologies (WoMO) 2012, pages 40–50.

Doran, P., Palmisano, I., and Tamma, V. A. M. (2008).

Somet: Algorithm and tool for sparql based ontology

module extraction. In Sattler, U. and Tamilin, A., ed-

itors, WoMO, volume 348 of CEUR Workshop Pro-

ceedings. CEUR-WS.org.

Doran, P., Tamma, V., and Iannone, L. (2007). Ontology

Module Extraction for Ontology Reuse: An Ontology

Engineering Perspective. In Proceedings of the Six-

teenth ACM Conference on Conference on Informa-

tion and Knowledge Management, CIKM ’07, pages

61–70, New York, NY, USA. ACM.

Grau, B. C., Horrocks, I., Kazakov, Y., and Sattler, U.

(2008). Modular Reuse of Ontologies: Theory and

Practice. Journal of Artiﬁcial Intelligence Research,

31:273–318.

Grau, B. C., Parsia, B., Sirin, E., and Kalyanpur, A. (2005).

Automatic Partitioning of OWL Ontologies Using E -

Connections.

Group, I. A. W. (2000). IEEE standard 1471-2000, Rec-

ommended Practice for Architectural Description of

Software-Intensive Systems. IEEE.

Guarino, N. and Giaretta, P. (1995). Ontologies and Knowl-

edge Bases Towards a Terminological Clariﬁcation.

Towards Very Large Knowledge Bases: Knowledge

Building and Knowledge Sharing, 25:32.

Konev, B., Lutz, C., Walther, D., and Wolter, F. (2009). For-

mal Properties of Modularisation. In (Stuckenschmidt

et al., 2009), pages 25–66.

Noy, N. and Musen, M. (2004). Specifying ontology views

by traversal. In McIlraith, S., Plexousakis, D., and

van Harmelen, F., editors, The Semantic Web – ISWC

2004, volume 3298 of Lecture Notes in Computer Sci-

ence, pages 713–725. Springer Berlin Heidelberg.

Noy, N. F. and Musen, M. A. (2000). PROMPT: Algorithm

and Tool for Automated Ontology Merging and Align-

ment. In Proceedings of the Seventeenth National

Conference on Artiﬁcial Intelligence and Twelfth Con-

ference on Innovative Applications of Artiﬁcial Intel-

ligence, pages 450–455. AAAI Press.

Parent, C. and Spaccapietra, S. (2009). An Overview of

Modularity. In (Stuckenschmidt et al., 2009), pages

5–23.

Sch

afermeier, R. and Paschke, A. (2014). Aspect-Oriented

Ontologies: Dynamic Modularization Using Ontolog-

ical Metamodeling. In Proceedings of the 8th Interna-

tional Conference on Formal Ontology in Information

Systems (FOIS 2014), pages 199 – 212. IOS Press.

Schlicht, A. and Stuckenschmidt, H. (2008). A Flexible Par-

titioning Tool for Large Ontologies. In Proceedings

of the 2008 IEEE/WIC/ACM International Conference

on Web Intelligence and Intelligent Agent Technology

- Volume 01, WI-IAT ’08, pages 482—488, Washing-

ton, DC, USA. IEEE Computer Society.

Seidenberg, J. and Rector, A. (2006). Web Ontology

Segmentation: Analysis, Classiﬁcation and Use. In

Proceedings of the 15th International Conference on

World Wide Web, WWW ’06, pages 13–22, New York,

NY, USA. ACM.

Stuckenschmidt, H., Parent, C., and Spaccapietra, S., ed-

itors (2009). Modular Ontologies: Concepts, Theo-

ries and Techniques for Knowledge Modularization.

Lecture Notes in Computer Science. Springer Berlin /

Heidelberg.

Thakker, D., Dimitrova, V., Lau, L., Denaux, R., Karana-

sios, S., and Yang-Turner, F. (2011). A priori ontology

modularisation in ill-deﬁned domains. In Proceed-

ings of the 7th International Conference on Semantic

Systems, I-Semantics ’11, pages 167–170, New York,

NY, USA. ACM.

KEOD 2015 - 7th International Conference on Knowledge Engineering and Ontology Development

194
