Contribution to Automatic Design of a Hierarchical

Fuzzy Rule Classifier

Cristhian Molina

3,2

, Vincent Bombardier

1,2

and Patrick Charpentier

1.2

Université de Lorraine, CRAN, UMR 7039, Campus Sciences, BP 70239, Vandoeuvre-lès-Nancy Cedex, 54506, France

CNRS, CRAN, UMR 7039, Vandoeuvre-lès-Nancy Cedex, France

Universidad de Santiago de Chile, Santiago, Chile

Keywords: Feature Selection, Fuzzy Associative Rules, Pattern Recognition, Fuzzy Rule Classifier.

Abstract: In this paper, two ways for automatically designing a hierarchical classifier is checked. This study deals

with a specific context where is necessary to work with a few number of training samples (and often

unbalanced), to manage the subjectivity of the different output classes and to take into account an

imprecision degree in the input data. The aim is also to create an interpretable classification system by

reducing its dimensionality with the use of Feature Selection and Fuzzy Association Rules generation. The

obtained results over an industrial wood datasets prove their efficacy to select input feature and they are

used to make some conclusions about their performance. Finally, an original methodology to automatically

build a hierarchical classifier is proposed by merging the both previous methods. Each node of the

hierarchical structure corresponds to a Fuzzy Rules Classifier with selected inputs and macro classes for

output. The leaves are the outputs of the classification system.

1 INTRODUCTION

In this paper, we propose a contribution to the

automatic design of a fuzzy hierarchical classifier,

working in a specific industrial wood context.

As presented in many classification reviews

(Gordon, 1987), classification in image processing is

done based on the characteristics of a bunch of

features, arranged as a vector (input features)

extracted from the image of a product in order to

classify it in a certain group (output classes).

In classification systems, many factors are

considered to evaluate their results. In most of cases,

systems are considered efficient because they have a

certain level of accuracy, even if they have some

restrictions like their computational complexity, or if

they present difficulties in order to be applied. This

implies that their profitability will depend on the

application context. Thus, as says the “ugly duckling

theorem”, a classification system depends on the

application context.

In our wood industrial domain (Bombardier

2010), these constraints to be considered principally

are:

 The leak of training data, often unbalanced

regarding the output classes.

 The subjectivity of the classification, which is

done by an operator.

 The fuzziness of the output classes, which are

often not disjointed.

We will also improve the interpretability of the

model given by the classification algorithms.

However, many of them work as a black box, hiding

the actual process from the user, or are so complex

that their comprehensibility is out of limits.

In (Bombardier 2010), is shown that the Fuzzy

Sets Theory seems to be one of the best techniques

to deal with the subjectivity of the system and its

non-disjointed output classes. Additionally, the

recently application of fuzzy rule-based systems in

pattern classification tasks (Nakashima, 2007) and

their ability to work with few learning data sets

(Wang 2008) appears like the best way to deal with

almost all the limitations presented above. Finally,

the desired interpretability of the system can be

achieved either with the creation of a hierarchical

structure of fuzzy rule classifiers (Bombardier

2007).

In (Horng 2009) it has been mentioned that

hierarchical methods are computationally intensive

when both, the size of the data set and the number of

classes are large.

150

Molina, C., Bombardier, V. and Charpentier, P..

Contribution to Automatic Design of a Hierarchical Fuzzy Rule Classiﬁer.

In Proceedings of the 7th International Joint Conference on Computational Intelligence (IJCCI 2015) - Volume 2: FCTA, pages 150-155

ISBN: 978-989-758-157-1

There are in literature, principally three ways to

reduce the complexity of a classification system, as

defined before:

 to reduce the number of features, which

naturally leads to the reduction of the number

of rules in the system;

 to reduce the number of features per rule,

keeping the most “interesting” ones under

certain criterions;

 to create a hierarchical classification system, in

order to simplify each decision level with the

creation of different macro classes.

So, in this paper, we propose to check the first

two ways in order to contribute to the third one.

In section 2, we will provide their definitions,

with advantages and disadvantages, discussing their

theoretical efficiency. In section 3 we will show

some experiments and their results, in order to

present the actual efficacy of feature selection

processes and draw some conclusions about their

behavior.

2 REDUCING THE

COMPLEXITY OF A SYSTEM

2.1 Feature Selection

Feature Selection step is a pre-process that chooses a

subset of the initial features. There exist many

potential benefits in feature selection mentioned in

(Guyon 2003). Among others, it facilitates the

visualization and comprehension of the data, reduces

the training and utilization time of the classification

method, and challenges the dimensionality in order to

improve the accuracy of the classification.

Langley divided the features selection methods,

taking into account the presence or absence of a

classification algorithm in the process. These two

categories are known as “filter” methods and

“wrapper” methods (Langley 1994).

“Filter” methods select a subset of features, from

the dataset in a classification process. In

consequence, their computational cost is low, which

facilitate their application. This type of methods is

independent of the classification algorithm and

hence, the chosen subset can be used in different

classifiers, without influencing the classification

rate. As showed in (Liu 2014), the most used

criterions in this kind of methods, take into account

the data structure and the information that the spatial

distribution contains. (Ferreira 2012), (Guyon 2003)

use the dependence between the features and output

classes (or correlation). (Liu 2014), (Zhang 2002)

and (Zhao 2013) consider both, the interclass

distance and the homogeneity of the elements in the

same class in order to preserve the internal structure

of data. This kind of criterions are well adapted for

treating high dimensional problems, and considering

that it is not our primary objective, we will not focus

our attention on this kind of methods.

“Wrapper” methods use a classification

algorithm to measure the efficacy of the selected

subset, generating a combinatorial problem (NP-

Hard) with a big computational cost (Ferreira 2012).

These characteristics make Wrapper methods less

efficient for working with high dimensional

problems. The utilization of a classification

algorithm in the selecting process creates a subset

with a high discriminative power, but this power can

only be guaranteed for the used classifier (Guyon

2003). The most used criterion in this kind of

methods is the misclassification rate, generating a

big number of tests of every subset in order to

achieve an optimal classification, as in (Li 2004) (De

Lannoy 2011), where SVMs are used as the trained

classifier.

(Pudil 1994) introduces the Sequential Floating

Search Methods (SFSM), probably one of the most

known feature selection techniques, and our primary

reference in feature selection processes. Within

SFSM we can distinguish forward methods (SFFS)

and backward methods (SFBS), as the most known

and used Wrapper methods.

(Kira 1992) presents another reference method,

called Relief. It works in a statistical way, searching

the features which are statistically relevant. This

method acts dividing the entire group of instances

into positive instances and negative instances taking

into account the neighbourhood of each training

sample. After this, it upgrades the weight of each

feature, calculating the relevance based on the

information given by each feature in the before

mentioned process. Finally, a feature will be

considered as important, if its relevance is over a

thresholdτ.

(Chen 2012) also defines an interesting feature

selection method, combined with a fuzzy rule

extraction for classification. In this, the author

creates a modulator, modifying the membership

function of every feature, measuring their influence

in the creation of distance based fuzzy rules. With

this, it attempts to create a fuzzy clustering method,

using only in those features that have the most

relevant influence to the classification rate, forcing

the created modulator to work as a “gate”, which

Contribution to Automatic Design of a Hierarchical Fuzzy Rule Classiﬁer

151

remains closed for every feature until they prove that

their influence is remarkable.

(Schmitt 2008) propose a really interesting

feature selection method which deals with our

context. The Choquet integral is used to select the

more suitable features, according to their capacity

with respect to it. Also, in this method, they measure

the importance of the different decision criterions

according to Shapley indexes, which measure the

contribution of a decision criterion to the final

decision, and Murofushi indexes, which measure the

interaction power between two indexes, discarding

negative feedback. This method works as an

iterative algorithm, discarding weaker features in

order to keep good recognition rates.

In (Grandvalet 2003) an automatic relevance

determination of features in kernelized SVM is

presented. Here, relevance is measured by scale

factors defining the input space metric, and the

features are selected by assigning zero weights to

irrelevant features.

2.2 Reducing the Number of Features

per Rule

Fuzzy association rules can be considered as an

indirect way of reducing the dimensionality of a

problem, showing the existing relationships between

different elements present in a dataset (Han 2006).

Basically, given a number of features, is possible to

create a defined number of rules, combining all

features, and measure the efficacy of each rule

according to certain criterions such as Support and

Confidence Zhang 2002).

FARC-HD is a classification method which uses

fuzzy association rules in its process (Alcala 2011).

Each rule is built in a hierarchical way, combining

all possible features and their fuzzification terms,

considering a restriction in the premise part. After

this process, the Support and the Confidence of each

rule are calculated in order to keep the most relevant

set of rules for the classification process.

FURIA is an algorithm which is used to create a

set of fuzzy rules for classification processes (Huhn

2009). This algorithm has a learning phase, where it

creates the initial set of rules for each class, using a

One Against All (OAA) strategy, in order to learn

how to separate the current class from all the others.

These methods work in a similar way, creating a

bunch of rules in order to cover all the possibilities,

and afterwards they apply a selection process, to

keep the most important ones. As the result, they

create a suitable set of rules for classification

problems.

The above mentioned property is the principal

difference with a classical fuzzy rule set algorithm

such as (Ishibuchi, 1992), where all the possibilities

are covered and the lacking of a selection process

implies the creation of a set of rules that becomes

not understandable.

The structure of a set of Fuzzy Rules can be

described as follow. Given N training patterns, xp=

(x1, x2, …, xm) p= (1, 2, …, n) belonging to S

output classes, where Xpi represents the i-th feature

i= (1, 2, …, m) of the p-th training pattern, each

fuzzy rule will have the following structure:





:















ℎ = 



(1)

Where Rj is the label of the j-th rule, x= (x1, …,

xm) is a feature vector with a dimension m, A

is a

fuzzy label, Cj is a class label j= (1, 2, …, s).

In a classical approach the system will cover all

the possible combination of rules, in order to have

no “empty space” in the classification phase.

Considering that N is the number of features and

Card(Tv) the number of terms in which the feature V

is divided, the number of rules is:

Number of Rules =

∏

(



)





(2)

In fuzzy associative rules for classification, we

appreciate the same structure as any classification

rule but their efficacy is measured as follows:

 → 



=

∑

















∈





(3)

 → 



=

∑

















∈



∑

















∈

(4)

Where |N| is the number of transactions in the

transactions set T, µA(xp) is the matching degree of

the pattern xp with the antecedent part of the fuzzy

rule. With these measures, the methods perform the

mentioned selection process.

3 EXPERIMENTAL ANALYSIS

In this section a series of experiments are proposed,

testing the contribution of feature selection

processes applied in a similar context to which our

work is immersed, to improve the interpretability of

a system. For the classification process, FARC-HD

will be used, which includes the creation of fuzzy

association rules, allowing us to extrapolate the

obtained results, merging the classic feature

FCTA 2015 - 7th International Conference on Fuzzy Computation Theory and Applications

152

selection methods with the dimensionality reduction

propositions given by fuzzy association rules.

3.1 Dataset

It is important to clarify that despite of the

explanations given for the dataset, specifying the

classification purpose and the context in which the

dataset is immersed, for privacy issues, the

considered features will remain with a generic name,

without explaining their significance for the

industrial environment.

The dataset used is from a company which takes

place in the industrial environment of wood. The

associated process to this dataset, named Wood, is in

charge of finding, within a set of defined features,

those that represent in the best possible way the

output classes, which correspond to wood

singularities. The process is performed considering

the aspects of the context, such as non-balanced data

and the complexity of the field, represented by the

imprecision of wood recognition approaches,

depending on the specificity and characterization of

the measures. The aim is to obtain a good accuracy

level using as little features as possible, because of

real time constraints. The obtained model is wished

to be interpretable in order to create a knowledge

model of the system.

Within the technical specifications, the Wood

Database has 20 input features, 9 output classes and

around 250 training patterns. These previously

provided specifications make the set of rules created

by the classic classification systems (SVM, KNN,

Neuronal Networks, etc.) too large, and that in

general the rules to be non-interpretable.

3.2 The Used Classifier FARC-HD

FARC-HD is a fuzzy association rule-based

classification method, based on three stages to

obtain an accurate and compact fuzzy rule set

(Alcala, 2011). First, it limits the order of the

associations in the association rule extraction

process, performed by a basic hierarchical decision

tree. Secondly, it considers a subgroup discovery

process, based in a weighted relative accuracy

measure, used to select the most interesting rules

before a genetic postprocessing process for rule

selection and parameter tuning is performed by a

genetic algorithm.

As we mentioned before, the aim of these

experiments, is to merge the effects of traditional

feature selection processes with the ability of

creating a compact fuzzy association rule set,

proposed by FARC-HD.

3.3 Experimental Methodology

The methodology will be divided in two parts,

selection of Features and classification using those

parameters combined with FARC-HD. Within the

used feature selection methods (see section 2.1), we

will find SFFS, SBFS (Pudil, 1994) and RelieF

(Kira, 1992), also we will use our own Fuzzy Rule

Iterative Feature Selection method (FRIFS)

(Schmitt, 2008), the Modulator Gate Method

(MGM) (Chen, 2012) and SVM method

(Grandvalet, 2003).

Feature selection processes performed by each

method were applied separately to the dataset. This

way, each method provides a set of the most

“important” features according to their own

criterion.

As the aim of the entire process lies in to prove

the efficiency of feature selection in the creation of

an interpretable descriptive model, we have focused

our experiments in providing a general idea of the

most useful features in the dataset. So, the results of

feature selection processes have been analyzed

considering the frequency of appearance of each

feature within the different subsets.

For the second part of the experiments, the

application of FARC-HD method leads to different

subsets of preselected features, used separately. It

includes them directly into the classifier and in

combination, to perform the data-crossing process

mentioned before, considering then only the most

frequent, or “important” ones in the classification

process. Within the iterations of the classifier, we

have employed the “leave one out” strategy, in order

to determine empirically the relevance degree of

each selected feature, measuring the obtained

accuracy in each step.

Additionally as a new experiment, we have

tested the efficacy of a possible “feature selection

process” within the rules selection mechanism

performed by FARC-HD when keeping the most

interesting association rules. In order to filter the

most interesting features, we select them regarding

the utilization patterns of each feature in the

different rules created by FARC-HD. We assume

that the most used features are the most important

ones. This way, we will be able to prove or disprove

the following hypothesis: to keep the most important

rules, implies to keep the most important features in

them.

Contribution to Automatic Design of a Hierarchical Fuzzy Rule Classiﬁer

153

3.4 Experimental Results

In Table 1, the different sets of features selected by

the different feature selection methods applied on

Wood are presented.

In Table II the performance and the analysis of

the classifier FARC-HD in the dataset Wood is

shown, where we have the following parameters:

1. #Features stands for the total number of

features used in the process.

2. #UF stands for the number of used features in

the created rules.

3. #R stands for the average number of rules.

4. #C stands for the average number of conditions

(or features) in the premises of the rules.

5. TRA stands for the average classification

percentage obtained over the training data.

6. TST stands for the average classification

percentage obtained over the test data.

The best global result for each one is stressed in

boldface in each case.

Table 2 clearly shows that the efficiency of the

system, in terms of accuracy, increases using less

features than the 20 original features. It also shows

that using “the most important rules” created by the

fuzzy association rules system, some features are

discarded, not being used in the classification

process (it uses only 16 out of 20). Using less

features also improves the number of rules in the

system, from 25 using all features until 15 or 16,

depending on the case, using less features. As we

mentioned before, the reduction of the number of

rules increases the interpretability of the system, but

here we have to consider also the number of

conditions in each rule, to achieve the

understandability of the rule. In fact, Table 2 shows

that using in average, 2.5 conditions per rule, we can

achieve the best accuracy of the system, which is an

acceptable number of conditions in order to draw some

conclusions about the behavior of the system.

In the other hand, with the data-crossing

performed between the different subsets of features,

and the utilization rates given by FARC-HD, we can

also show that the reduction of dimensionality

performed by the feature selection methods, and the

reduction of dimensionality performed by fuzzy

associative rules are from different nature. This

means that if we apply a reduction of the number of

rules via the application of fuzzy association rules, it

does not necessarily mean that the most important

features, according to the state of art feature

selection methods, are going to be considered.

Likewise, the application of feature selection

processes on a dataset, does not assure that the rules

created by the system are going to be interpretable,

given the nature of regular fuzzy rules creation

processes.

Table 1: Selected Features by different Feature Selection Methods applied to Wood Database.

FRAC-HD FRIFS FRIFS-HS1 FRIFS-HS2 SBFS SFFS SVM

C4 SM-Axis SM-Axis Area LR_RE LR_RE SM-Axis

C3 DX/DY DX/DY DX/DY SM_Axis SM_Axis Area

C1+C3 LR LR LR Area Area DX/DY

SM_Axis C1 C1 C1 DX/Dy DX/DY C1

LR C4 C1+C3 C4 C1 C1 C4

Area_Rate C1+C3 C1+C3 C3 C3 C1+C3

Orient C1+C3 C1+C3

Table 2: Results obtained by using different Feature Selection Methods.

Dataset #Feature #UF #R #C TRA TST

Wood 20 16 25 2.68 0.984 0.729

FRIFS 6 6 16 2.25 0.968 0.756

FRIFS HS1 5 5 16 2.25 0.896 0.742

FRIFS HS2 6 6 15 2.6 0.96 0.77

SBFS 8 8 16 2.625 0.968 0.772

SFFS 8 8 16 2.625 0.968 0.772

SVM 6 6 20 2.45 0.964 0.772

MGM 4 4 15 2.533 0.876 0.718

FCTA 2015 - 7th International Conference on Fuzzy Computation Theory and Applications

154

4 CONCLUDING REMARKS

In this paper, we have tested two ways to contribute

to the automatic creation of a hierarchical

classification system: reducing the number of input

variables with feature selection methods and

reducing the number of rules with the use of fuzzy

associative rules. With the execution of some

experiments, we have noticed the power of the

dimensionality reduction in order to improve the

interpretability of a system.

That is why, we think that both ways for

reducing the dimensionality need to be merged or

included simultaneously in a classifier, increasing

the benefits provided in the separated scenario. The

proposed methodology is based on feature selection

process to reduce dimensionality, and fuzzy

association rules creation to have a hierarchical

structure in order to be able to divide the process in

sub processes with different macro classes.

REFERENCES

Alcala-Fernandez, J., Alcala, R., and Herrera, F. (2011). A

Fuzzy Association Rule-Based Classification Model

for High-Dimensional Problems With Genetic Rule

Selection and Lateral Tuning, IEEE Transactions on

Fuzzy Systems, 19 (5), 857–872.

Bombardier, V., and Schmitt, E. Measure (2010). Fuzzy

rule classifier: Capability for generalization in wood

color recognition, Engineering Applications of

Artificial Intelligence, 23 (6), 978–988.

Bombardier V., Mazaud C., Lhoste P. Vogrig R. (2007)

Contribution of Fuzzy Reasoning Method to

knowledge Integration in a wood defect Recognition

System. Computers in Industry Journal 58:355–366

Chen, Y. C., Pal, N. R., and Chung, I.F. (2012). An

Integrated Mechanism for Feature Selection and Fuzzy

Rule Extraction for Classification, IEEE Transactions

on Fuzzy Systems, 20 (4), 683–698.

De Lannoy, G., François, D., and Verleysen, M. (2011).

Class-Specific Feature Selection for One-Against-All

Multiclass SVMs, European Symposium on Artificial

Neu. Net., Computacional Intel. and Mach. Learn.

Ferreira, A. J, and Figueiredo, M. A. (2012). Efficient

feature selection filters for high-dimensional data,

Pattern Recognition

Gordon, A. D. (1987). A review of hierarchical

Classification. Journal of the Royal Society. Series A,

150 (2), 119-137.

Grandvalet, Y., and Canu, S. (2003). Adaptive scaling for

feature selection in SVMs, in Neural Information

Processing System. Cambridge, MA: MIT Press.

Guyon, I., and Elisseeff, A. (2003). An introduction to

variable and feature selection, J. Mach. Learn. Res., 3,

1157-1182.

Han, J., Kamber, M., and Pei, J. (2006). Data Mining:

Concepts and Techniques, Second Edition (The

Morgan Kaufmann Series in Data Management

Systems). Morgan Kaufmann.

Horng, S.C., and Hsiao, Y.L. (2009). Fuzzy clustering

decision tree for classifying working wafers of ion

implanter, IEEE International Conference on Industrial

Engineering and Engineering Management, 703–707.

Hühn, J., and Hüllermeier, E. (2009). FURIA: an

algorithm for unordered fuzzy rule induction, Data

Mining and Knowledge Discovery, 19 (3), 293–319.

Ishibuchi, H., Nozaki, K., Tanaka, H., (1992). Distributed

representation of fuzzy rules and its application to

pattern classification. Fuzzy Sets and Systems 52, 21–

32.

Kira, K., and Rendell, L.A. (1992). The feature selection

problem: Traditional methods and a new algorithm,

Proceedings of Ninth National Conference on

Artificial Intelligence, 129-134.

Langley, P. (1994). Selection of relevant features in

machine learning, Proceedings of the AAAI Fall

Symposium on Relevance, 1–5.

Li, G.Z., Yang, J., Liu, G.P., and Xue, L. (2004). Feature

selection for multi-class problems using support vector

machines, Lect. Notes in comp. science, 3157, 292-

300.

Liu, Wang, L., Zhang, J., Yin, J., and Liu, H. (2014).

Global and Local structure Preservation for Feature

Selection, IEEE trans. Neu. net. and learn. Sys., 25 (6).

Nakashima, T., Schaefer, G., Yokota, Y., and Ishibuchi,

H. (2007). A weighted fuzzy classiﬁer and its

application to image processing tasks, Fuzzy Sets and

Systems, 158, 284–294.

Pudil, P., Novovicova, J., and Kittler, J. (1994).Floating

search methods in feature selection, Pattern

recognition letters 15, 1119-1125.

Schmitt, E., Bombardier, V., and Wendling, L. (2008).

Improving Fuzzy Rule Classifier by Extracting

Suitable Features From Capacities With Respect to the

Choquet Integral, IEEE trans. On Systems, mand and

Cybernetics-Part B: Cybernetics, 38 (5), October.

Wang, F., Man, L., Wang, B., Xiao, Y., Pan, W., Lu, X.

(2008) Fuzzy-based algorithm for color recognition of

license plates, Pattern Recognition Letters 29, 1007–

1020.

Zhang, C., and Zhang, S. (2002). Association Rule

Mining: Models and Algorithms. Berlin, Heidelberg:

Springer-Verlag.

Zhao, Z., Wang, L., Liu, H., and Ye, J. (2013). On

Similarity preserving Feature Selection, IEEE Trans.

Knowledge and Data engineering, 25 (3).

Contribution to Automatic Design of a Hierarchical Fuzzy Rule Classiﬁer

155
