SCUT: Multi-Class Imbalanced Data Classification using SMOTE

and Cluster-based Undersampling

Astha Agrawal

, Herna L. Viktor

and Eric Paquet

1,2

School of Electrical Engineering and Computer Science, University of Ottawa, Ottawa, Ontario, Canada

National Research Council of Canada, Ottawa, Ontario, Canada

Keywords: Multi-Class Imbalance, Undersampling, Oversampling, Classification, Clustering.

Abstract: Class imbalance is a crucial problem in machine learning and occurs in many domains. Specifically, the

two-class problem has received interest from researchers in recent years, leading to solutions for oil spill

detection, tumour discovery and fraudulent credit card detection, amongst others. However, handling class

imbalance in datasets that contains multiple classes, with varying degree of imbalance, has received limited

attention. In such a multi-class imbalanced dataset, the classification model tends to favour the majority

classes and incorrectly classify instances from the minority classes as belonging to the majority classes,

leading to poor predictive accuracies. Further, there is a need to handle both the imbalances between classes

as well as address the selection of examples within a class (i.e. the so-called within class imbalance). In this

paper, we propose the SCUT hybrid sampling method, which is used to balance the number of training

examples in such a multi-class setting. Our SCUT approach oversamples minority class examples through

the generation of synthetic examples and employs cluster analysis in order to undersample majority classes.

In addition, it handles both within-class and between-class imbalance. Our experimental results against a

number of multi-class problems show that, when the SCUT method is used for pre-processing the data

before classification, we obtain highly accurate models that compare favourably to the state-of-the-art.

1 INTRODUCTION

In an imbalanced dataset used for classification, the

sizes of one or more classes are much greater than

the other classes. The classes with the larger number

of instances are called majority classes and the

classes with the smaller number of instances are

referred to as the minority classes. Intuitively, since

there are a large number of majority class examples,

a classification model tends to favour majority

classes while incorrectly classifying the examples

from the minority classes. However, in imbalanced

datasets, we are often more interested in correctly

classifying the minority classes. For instance, in a

two class setting within the medical domain, if we

are classifying patients’ condition, the minority class

(e.g. cancer) is of more interest than the majority

class (e.g. cancer free). In practice, many problems

have more than two classes. For example, in

bioinformatics, protein family classification, where a

protein may belong to very small families within the

large Protein Data Bank repository (Viktor et. al,

2013), as well as protein fold prediction, are

examples of multi-class problems. Typically, in such

a multi-class imbalanced dataset, there are multiple

classes that are underrepresented, that is, there may

be multiple majority classes and multiple minority

classes, resulting in skewed distributions.

A number of research studies have been realized

in order to improve classification performance on

imbalanced binary class datasets, in which there is

one majority class and one minority class. However,

improving the performance on imbalanced multi-

class datasets has not been researched as

extensively. Consequently, most existing techniques

for improving classification performance on

imbalanced datasets are designed to be applied

directly on binary class imbalanced datasets. These

methods cannot be applied directly on multi-class

datasets (Wang and Yao, 2012). Rather, class

decomposition is usually used to convert a multi-

class problem into a binary class problem. For

instance, the One-versus-one (OVO) approach

employs multiple classifiers for each possible pair of

classes, discarding the remaining instances that do

not belong to the pair under consideration. The One-

versus-all (OVA) approach, on the other hand,

226

Agrawal, A., Viktor, H. and Paquet, E..

SCUT: Multi-Class Imbalanced Data Classiﬁcation using SMOTE and Cluster-based Undersampling.

In Proceedings of the 7th International Joint Conference on Knowledge Discovery, Knowledge Engineering and Knowledge Management (IC3K 2015) - Volume 1: KDIR, pages 226-234

ISBN: 978-989-758-158-8

considers one class as the positive class, and merges

the remaining classes to form the negative class. For

‘n’ classes, ‘n’ classifiers are used, and each class

acts as the positive class once (Fernández et al.,

2010). Subsequently, the results from different

classifiers are combined in order to reach a final

decision. Interested readers are referred to (Ramanan

et al., 2007) for detailed discussions of the OVO and

OVA approaches. However, combining results from

classifiers that are trained on different sub-problems

may result in classification errors (Wang and Yao,

2012). In addition, in OVO, each classifier is trained

only on a subset of the dataset, which may lead to

some data regions being left unlearned. In this paper,

we propose a different method to improve

classification performance on multi-class

imbalanced datasets which preserves the structure of

the data, without converting the dataset into a binary

class problem.

In addition to between-class imbalance (i.e. the

imbalance in the number of instances in each

classes), within-class imbalance is also commonly

observed in datasets. Such a situation occurs when a

class is composed of different sub-clusters and these

sub-clusters do not contain the same number of

examples (Japkowicz, 2001). It follows that

between-class and within-class imbalances both

affect classification performance. In an attempt to

address these two problems, and in order to improve

classification performance on imbalanced datasets,

sampling methods are often used for pre-processing

the data prior to using a classifier to build a

classification model.

Sampling methods focus on adapting the class

distribution in order to reduce the between-class

imbalance. Sampling methods may be divided into

two categories, namely undersampling and

oversampling. Undersampling reduces the number

of majority class instances and oversampling

increases the number of minority class instances.

Unfortunately, both random oversampling and

undersampling techniques present some weaknesses.

For instance, random oversampling adds duplicate

minority class instances to the minority class. This

may result in smaller and more specific decision

regions causing the learner to over-fit the data. Also,

oversampling may increase the training time.

Random undersampling randomly takes away some

instances from the majority class. A drawback of

this method is that useful information may be taken

away (Han et al., 2005). Further, when performing

random undersampling, if the dataset has within-

class imbalance and some sub-clusters are

represented by very few instances, the probability

that instances from these sub-clusters be retained is

relatively low. Consequently, these instances may

remain unlearned.

SMOTE represents an improvement over random

oversampling in that the minority class is

oversampled by generating “synthetic” examples

(Chawla et. al., 2002). However, in highly

imbalanced datasets, too much oversampling (i.e.

oversampling using a high sampling percentage)

may result in overfitting. This is especially

important in a multi-class setting where there are a

number of minority classes with very few examples.

Further, in a multi-class setting, there is a need to

find the correct balance, in terms of number of

examples, between multiple classes. In order to

address this issue, we propose an algorithm called

SCUT (SMOTE and Clustered Undersampling

Technique) which combines SMOTE and cluster-

based undersampling in order to handle between-

class and within-class imbalance.

Undersampling is required to balance the dataset

without using excessive oversampling. If majority

class instances are randomly selected, small

disjuncts with less representative data may remain

unlearned. Clustering the majority classes helps

identify sub-concepts, and if at least one instance is

selected from each sub-concept (cluster) while doing

undersampling, this issue might be addressed

(Sobhani et. al, 2014). This implies that the scenario

of having unlearned regions when within-class

imbalance exists, is reduced. In this setting,

combining clustering and undersampling makes

sense as it addresses the disadvantage of random

undersampling. To this end, Yen and Lee proposed

several cluster-based undersampling approaches to

select representative data as training data to improve

the classification accuracy for the minority class

(Yen and Lee, 2009). The main idea behind their

cluster-based undersampling approaches was based

on the assumption that each dataset has different

clusters and each cluster seems to have distinct

characteristics. Subsequently, from each cluster, a

suitable number of majority class samples were

selected (Yen and Lee, 2009). Rahman and Davis

also used a cluster-based undersampling technique

for classifying imbalanced cardiovascular data that

not only balances the data in a dataset, but further

selects good quality training set data for building

classification models (Rahman and Davis, 2013).

Chawla et al. combined random undersampling

with SMOTE, so that the minority class had a larger

presence in the training set. By combining

undersampling and oversampling, the initial bias of

the learner towards the majority class is reversed in

SCUT: Multi-Class Imbalanced Data Classiﬁcation using SMOTE and Cluster-based Undersampling

227

the favour of the minority class (Chawla et al.,

2002). In summary, cluster-based undersampling

ensures that all sub-concepts are adequately

represented. When used in conjunction with

SMOTE, the hybrid sampling method thus aid to

ensure that between-class imbalance is reduced

without excessive use of oversampling and

undersampling.

This paper is organized as follows. Section 2

contains a description of the proposed method. In

Section 3, the experimental setup and results are

presented while Section 4 concludes the paper and

discusses our future plans.

2 SCUT ALGORITHM

Our SCUT algorithm combines both undersampling

and oversampling techniques in order to reduce the

imbalance between classes in a multi-class setting.

The pseudocode for our SCUT method is shown in

Figure 1.

For undersampling, we employ a cluster-based

undersampling technique, using the Expectation

Maximization (EM) algorithm (Dempster et al.,

1977). The EM algorithm replaces the hard clusters

by a probability distribution formed by a mixture of

Gaussians. Instead of being assigned to a particular

cluster, each member has a certain probability to

belong to a particular Gaussian distribution of the

mixture. The parameters of the mixture, including

the number of Gaussians, are determined with the

Expectation Maximization algorithm. An advantage

of using EM is that the number of clusters does not

have to be specified beforehand. EM clustering may

be used to find both hard and soft clusters. That is,

EM assigns a probability distribution to each

instance relative to each particular cluster (Dempster

et al., 1997).

The SCUT algorithm proceeds as follows. The

dataset is split into n parts, namely D

, D

... D

where n is the number of classes and D

represents a

single class. Subsequently, the mean (m) of the

number of instances of all the classes is calculated.

i) For all classes that have a number of instances

less than the mean m, oversampling is performed in

order to obtain a number of instances equal to the

mean. The sampling percentage used for SMOTE is

calculated such that the number of instances in the

class after oversampling is equal to m.

ii) For all classes that have a number of instances

greater than the mean m, undersampling is

conducted to obtain a number of instances equal to

the mean. Recall that the EM technique is used to

discover the clusters within each class (Dempster et

al., 1977). Subsequently, for each cluster within the

current class, instances are randomly selected such

that the total number of instances from all the

clusters is equal to m. Therefore, instead of fixing

the number of instances selected from each cluster,

we fix the total number of instances. It follows that a

different number of instances may be selected from

the various clusters. However, we aim to select the

instances as uniformly as possible. The selected

instances are combined together in order to obtain m

instances (for each class).

iii) All classes for which the number of instances

is equal to the mean m are left untouched.

Input: Dataset D with n classes

Output: Dataset D' with all classes

having m instances, where m is the mean

number of instances of all classes

Split D into D

, D

, ..., D

where D

is a single class

Calculate m

Undersampling:

For each D

, i=1,2, ... , n where

number of instances >m

Cluster D

using EM algorithm

For each cluster C

, i = 1,2,

... , k

Randomly select instances

from C

Add selected instances to

’

End For

C = Ø

For i=1,2, ... , k

C = C U C

’

End For

’ = C

End For

Oversampling:

For each D

, i=1,2, ... , n where

number of instances <m

Apply SMOTE on D

to get D

’

End For

For each D

, i=1,2, ... , n where

number of instances = m

’

= D

D’ = Ø

For i = 1,2, ... , n

D’ = D’ U D

’

End For

Return D’

Figure 1: SCUT Algorithm.

KDIR 2015 - 7th International Conference on Knowledge Discovery and Information Retrieval

228

Finally, all the classes are merged together in order

to obtain a dataset D’, where all the classes have m

instances. Classification may be performed on D’

using an appropriate classifier.

For instance, one of the datasets used in our work

is the Lymphography dataset, as obtained from the

KEEL repository (Alcalá-Fdez et al., 2011). This

dataset concerns detecting the presence of a

lymphoma, together with its current status, and

contains four (4) classes (normal, metastases,

malignant-lymphoma and fibrosis), with 2, 81, 61

and 4 examples, respectively. That is, the dataset has

a high level of imbalance and contains two majority

and two minority classes. The dataset is split into

four (4) classes and the mean is 37.

i) For class 1, the number of instances is 2, so

SMOTE is applied with a sampling percentage of

1850% in order to obtain 37 instances.

ii) For class 2, the number of examples is 81, so

EM is applied and 3 clusters are obtained, with the

numbers of instances equal to 29, 17 and 35

respectively. In order to obtain a total of 37

instances, 12, 12 and 13 instances are randomly

selected from the clusters.

iii) For class 3, the number of instances is 61.

When EM is applied, only one cluster is obtained.

Next, 37 instances are randomly selected from this

one cluster.

iv) The number of instances of class 4 is equal to

4, so SMOTE is applied with a sampling percentage

of 925% in order to obtain 37 instances.

Lastly, the classes are merged together and a new

dataset of 148 instances (in which each class has 37

examples) is obtained. The next section discusses

our experimental setup and results.

3 EXPERIMENTATION

We implemented our SCUT algorithm by extending

WEKA, an open source data mining tool that was

developed at the University of Waikato. For

classification, the WEKA implementations of four

classifiers, namely J48 (decision tree), SMO

(support vector machine), Naïve Bayes and IBk

(Nearest Neighbour), were used. For IBk, the

number of nearest neighbours (k) was set to five (5),

by inspection. Default values for the other

parameters were used.

A ten-fold cross validation approach was used

for testing and training. Ten-fold cross validation

has been shown to be an effective testing

methodology when datasets are not too small, since

each fold is a good representation of the entire

dataset (Japkowicz, 2001).

3.1 Benchmarking Datasets

Seven multi-class datasets from the KEEL

repository (Alcalá-Fdez et al., 2011) and the Wine

Quality dataset from the UCI repository (Lichman,

2013) (Cortez et al., 2009) were used in the

experiments. The details of these datasets are

summarized in Table 1. The table shows that the

number of classes in the datasets varies from three

(3) to ten (10) and the number of training examples

range from 148 to 6497. Here, the levels of

imbalance and numbers of classes with majority and

minority instances vary considerably.

The WEKA implementation of the EM cluster

analysis algorithm was used. Recall that the EM

approach employs probabilistic models which imply

that the number of clusters does not have to be

specified in advance. Therefore, a major strength of

EM is that it determines the number of clusters that

must be created by cross validation. In order to

determine the number of clusters, cross validation is

performed as follows:

1. Initially, the number of clusters is set to one (1).

2. The training set is split randomly into ten (10)

folds. The number of folds is set to ten, as long

as the number of instances in the training set is

not smaller ten. If this is the case, the number of

folds is set equal to the number of instances.

3. EM is performed ten (10) times using the ten

(10) folds.

4. The logarithm of the likelihood is averaged over

all ten (10) results. If logarithm of the likelihood

increases, the number of clusters is increased by

one (1) and the algorithm resumes from step 2.

Table 1: Datasets.

Datasets Size # Class Class distribution

Thyroid 720 3 17, 37, 666

Lymphography 148 4 2, 81, 61, 4

Pageblocks 548 5 492, 33, 8, 12, 3

Dermatology 366 6

112, 61, 72, 49,

52, 20

Autos 159 6

3, 20, 48, 46, 29,

Ecoli 336 8

143, 77, 52, 35,

20, 5, 2, 2

Wine Quality 6497 7

30, 216, 2138,

2836, 1079, 193, 5

Yeast 1484 10

244, 429, 463, 44,

51, 163, 35, 30,

20, 5

SCUT: Multi-Class Imbalanced Data Classiﬁcation using SMOTE and Cluster-based Undersampling

229

The G-mean, F-measure and AUC (Area Under

the Curve) measures were used for evaluating the

results. For imbalanced datasets, the G-mean

measure has been found to be highly representative

of an algorithm’s performance (Sobhani et. al.,

2014). We compared our SCUT method with three

other techniques, namely the original SMOTE

algorithm, Random Undersampling (RU) and an

implementation called CUT, which uses SCUT

without using SMOTE. We also consider the

scenario in which no sampling is performed, which

is denoted by Original, in order to determine

whether any form of sampling is actually beneficial

or not.

3.2 Results

In this section, we discuss the results we have

obtained against the eight datasets. Tables 2, 3, 4

and 5 show the G-mean values when the J48, Naïve

Bayes, SMO and IBk classifiers are used,

respectively. Tables 6, 7, 8 and 9 display the results

of the F-measure values, while Tables 10, 11, 12 and

13 depict the AUC values. The tables indicate that

the SCUT and SMOTE algorithms consistently

produced the best results, in terms of the three

measures, when applied to these benchmarking

datasets.

Table 2: G-mean values for J48.

Datasets SCUT SMOTE CUT RU Orig.

Thyroid 0.980

0.989

0.968 0.986 0.984

Lympho.

0.936

0.909 0.817 0.804 0.822

Pageblock

0.975

0.873 0.910 0.859

Derma. 0.977

0.971 0.976

0.980

0.962

Autos 0.763

0.893

0.797 0.818 0.853

Ecoli 0.907

0.921

0.862 0.864 0.899

Wine

0.800

0.762 0.698 0.728 0.682

Yeast

0.828

0.766 0.763 0.749 0.691

Table 3: G-mean values for Naïve Bayes.

Datasets SCUT SMOTE CUT RU Orig.

Thyroid

0.841

0.762 0.696 0.734 0.667

Lympho.

0.946

0.924 0.859 0.906 0.837

Pageblock 0.920

0.928

0.850 0.898 0.848

Derma.

0.988

0.982 0.980 0.984

Autos

0.814

0.797 0.737 0.687 0.734

Ecoli 0.936

0.941

0.860 0.910 0.907

Wine

0.639

0.591 0.565 0.583 0.574

Yeast

0.753

0.724 0.700 0.711 0.705

Table 4: G-mean values for SMO.

Datasets SCUT SMOTE CUT RU Orig.

Thyroid

0.849

0.740 0.404 0.419 0.292

Lympho.

0.954

0.926 0.872 0.897 0.904

Pageblocks

0.952

0.948 0.737 0.763 0.599

Derma.

0.982

0.970 0.970 0.972

Autos

0.874

0.862 0.803 0.787 0.811

Ecoli 0.904

0.919

0.898 0.909 0.894

Wine

0.675

0.620 0.633 0.632 0.601

Yeast

0.762

0.727 0.710 0.730 0.692

Table 5: G-mean values for IBk.

Datasets SCUT SMOTE CUT RU Orig.

Thyroid 0.876

0.883

0.501 0.512 0.318

Lympho.

0.946

0.929 0.802 0.808 0.844

Pageblocks 0.951

0.969

0.794 0.809 0.750

Derma 0.978

0.979

0.978 0.978 0.974

Autos 0.818

0.824

0.718 0.744 0.766

Ecoli 0.920

0.933

0.860 0.898 0.910

Wine

0.792

0.745 0.657 0.649 0.645

Yeast

0.835

0.774 0.738 0.728 0.667

Table 6: F-measure values for J48.

Datasets SCUT SMOTE CUT RU Orig.

Thyroid 0.974

0.987

0.970 0.977 0.986

Lympho.

0.905

0.875 0.787 0.786 0.804

Pageblocks 0.960

0.967

0.873 0.897 0.947

Derma. 0.962

0.953 0.960

0.967

0.940

Autos 0.792

0.828

0.688 0.722 0.778

Ecoli 0.841

0.870

0.777 0.780 0.836

Wine

0.676

0.640 0.568 0.605 0.586

Yeast

0.708

0.631 0.616 0.595 0.552

Table 7: F-measure values for Naïve Bayes.

Datasets SCUT SMOTE CUT RU Orig.

Thyroid 0.779 0.650 0.765

0.841

0.940

Lympho.

0.918

0.897 0.832 0.898 0.835

Pageblk 0.871

0.919

0.844 0.882 0.930

Derma.

0.981

0.979 0.971 0.968 0.973

Autos

0.692

0.674 0.588 0.523 0.602

Ecoli 0.887

0.902

0.769 0.852 0.854

Wine 0.417 0.383 0.374 0.409

0.439

Yeast

0.595

0.573 0.521 0.542 0.566

KDIR 2015 - 7th International Conference on Knowledge Discovery and Information Retrieval

230

Table 8: F-measure values for SMO.

Datasets SCUT SMOTE CUT RU Orig.

Thyroid

0.781

0.693 0.742 0.746

0.892

Lympho.

0.933

0.903 0.861 0.903

0.905

Pageblocks 0.923

0.938

0.731 0.759

0.897

Derma.

0.970

0.969 0.950 0.950

0.954

Autos

0.801

0.785 0.695 0.671

0.718

Ecoli 0.834

0.863

0.829 0.845

0.823

Wine

0.480

0.403 0.448 0.448

0.461

Yeast

0.606

0.556 0.537 0.571

0.550

Table 9: F-measure values for IBk.

Datasets SCUT SMOTE CUT RU

Orig.

Thyroid 0.831

0.864

0.754 0.777

0.893

Lympho.

0.919

0.907 0.756 0.817

0.827

Pageblocks 0.943

0.959

0.817 0.827

0.931

Derma. 0.964

0.965

0.964 0.964

0.957

Autos 0.702

0.721

0.578 0.605

0.655

Ecoli 0.859

0.885

0.767 0.829

0.853

Wine

0.658

0.612 0.509 0.497

0.543

Yeast

0.713

0.639 0.576 0.568

0.522

Table 10: AUC values for J48.

Datasets SCUT SMOTE CUT RU

Orig.

Thyroid 0.982

0.993

0.968 0.981

0.885

Lympho.

0.943

0.908 0.809 0.815

0.828

Pageblocks 0.977

0.981

0.854 0.923

0.845

Derma 0.984

0.985

0.980

0.985

0.977

Autos 0.903

0.932

0.869 0.872

0.894

Ecoli 0.938

0.941

0.874 0.882

0.920

Wine

0.834

0.803 0.744 0.769

0.722

Yeast

0.881

0.817 0.806 0.779

0.733

Table 11: AUC values for Naïve Bayes.

Datasets SCUT SMOTE CUT RU Orig.

Thyroid 0.916

0.932

0.819 0.830 0.872

Lympho.

0.982

0.961 0.930 0.947 0.920

Pageblocks

0.982

0.981 0.893 0.934 0.916

Derma 0.999

0.999 0.999 0.999 0.999

Autos

0.910

0.899 0.832 0.811 0.828

Ecoli 0.974

0.979

0.928 0.945 0.960

Wine

0.801

0.748 0.684 0.692 0.658

Yeast

0.912

0.874 0.858 0.848 0.816

Tables 14, 15 and 16 show the summaries for the G-

mean, F-measure and AUC values, respectively,

when the results are ranked. For each dataset, the

five methods are ranked from 1 to 5. Here, 1

corresponds to the highest rank (for highest value)

while 5 denotes the lowest rank. If there is a tie, then

Table 12: AUC values for SMO.

Datasets SCUT SMOTE CUT RU Orig.

Thyroid

0.892

0.770 0.522 0.536

0.512

Lympho.

0.971

0.937 0.895 0.904

0.907

Pageblocks

0.973

0.964 0.792 0.818

0.673

Derma.

0.989

0.980 0.980

0.984

Autos

0.927

0.925 0.899 0.866

0.896

Ecoli 0.963

0.970

0.938 0.949

0.944

Wine

0.808

0.759 0.706 0.705

0.678

Yeast

0.887

0.846 0.823 0.828

0.781

Table 13: AUC values for IBk.

Datasets SCUT SMOTE CUT RU Orig.

Thyroid 0.939

0.948

0.631 0.673 0.591

Lympho.

0.986

0.965 0.932 0.957 0.923

Pageblocks 0.981

0.986

0.885 0.933 0.925

Derma.

0.998 0.998

0.997 0.995 0.997

Autos 0.929

0.933

0.873 0.876 0.903

Ecoli 0.958

0.965

0.913 0.939 0.951

Wine

0.898

0.857 0.764 0.769 0.745

Yeast

0.927

0.897 0.843 0.840 0.685

while 5 denotes the lowest rank. If there is a tie, then

the same rank is assigned to both. For each method,

all the ranks are added, and the method with the

smallest rank sum is assigned the highest rank (1)

while the method with the largest rank sum is

attributed the lowest rank (5).

Table 14: Ranks for different methods for G-mean values.

Classifier SCUT SMOTE CUT RU Orig.

J48 2

5 3 4

NaiveBayes

2 4 3 4

SMO

2 4 3 5

IBk 2

4 3 5

Table 15: Ranks for different methods for F-measure.

Classifier SCUT SMOTE CUT RU Orig.

J48 2

4 3 3

NaiveBayes

3 5 4 2

SMO

2 5 4 3

IBk 2

5 4 3

Table 16: Ranks for different methods for AUC values.

Classifier SCUT SMOTE CUT RU Orig.

J48 2

5 3 4

NaiveBayes

2 4 3 4

SMO

2 4 3 5

IBk 2

4 3 4

SCUT: Multi-Class Imbalanced Data Classiﬁcation using SMOTE and Cluster-based Undersampling

231

For the Naïve Bayes and SMO classifiers, our

SCUT method obtains the highest overall rank,

while SMOTE ranks second or third. On the other

hand, when using the J48 and IBk classifiers,

SMOTE achieves the highest rank while SCUT

comes second. The RU technique scores third, in

terms of the G-means and AUC values, while the

Original and CUT methods rank either fourth or

fifth. For the F-measure, the Original dataset

outperforms the undersampling techniques. This

result suggests that the undersampling-only

techniques do not work well in multi-class settings.

The results from Tables 14, 15 and 16 indicate

that our SCUT method is most suitable in scenario

where the Naïve Bayes and SMO classifiers are

employed. When the J48 and IBk classifiers are

used, SMOTE on its own provides the best results

against the datasets under consideration.

Furthermore, when the datasets are highly

imbalanced with some classes having very few

instances, CUT and RU consistently perform poorly.

This observation is also true for the Original dataset

in which sampling is absent. This confirms our

initial hypothesis that oversampling is required in

order to improve the performance in such a multi-

class scenario.

Subsequently, the Friedman statistical test was

used in order to assert the statistical significance of

the results. The Friedman test is a non-parametric

statistical test. Since it ranks the values in each row,

it is not affected by factors that equally affect all the

values in a row. In addition, unlike other tests such

as ANOVA and paired t-test, it does not make any

assumptions about the data distribution. The results

for each classifier (J48, Naïve Bayes, SMO and IBk)

on each evaluation metric (G-mean, F-measure and

AUC) are depicted in Tables 2 to 13. The resultant

p-values are shown in Table 17.

Table 17: Summary of p-values for classifiers and

evaluation metrics.

Evaluation

metric

Classifiers

J48

Naïve

Bayes

SMO IBk

G-mean 0.01460 0.00038 0.00060 0.00010

F-measure 0.00221

0.00470 0.00642 0.00029

AUC 0.00011

0.00024 0.00004 0.00005

Assuming that the results are statistically

significant if p < 0.05, it may be concluded that all

our results are valid and statistically significant.

3.3 Discussion

Our experimental results, based on the

benchmarking multi-class imbalanced datasets, show

that when the SCUT method is used, improved

results for the Naïve Bayes and Support Vector

Machine classifiers are obtained. This suggests that

undersampling makes these two classifiers more

sensitive to the minority classes, and aids them to

correctly classify minority class instances. On the

other hand, the SMOTE technique produces the

highest measured values for the J48 and K-Nearest

Neighbour classifiers. Thus, undersampling does not

improve the results for these two algorithms. Rather,

relying solely on oversampling the minority classes

is sufficient in this particular case. In general, our

results indicate that oversampling the majority

instances is crucial in order to address multi-class

problems. Undersampling approaches, such as RU

and CUT, do not perform well in these conditions.

As a matter of fact, using the Original dataset

without any form of undersampling sometimes

outperforms these two techniques.

The reader should notice that the SCUT

algorithm produced the best overall results in the

Yeast dataset, which contains the highest number of

classes with a wide range or cardinality. It also

produced the best results for the Wine Quality

dataset (in all cases except Table 7). Recall that this

is the largest dataset with a high degree of

imbalance. In addition, SCUT produced the most

accurate models against the Lymphography dataset,

where the levels of imbalance are quite high. This

seems to indicate that our SCUT method is

particularly suitable in such cases, since

undersampling is required. That is, this scenario

implies that a classifier may benefit from increased

sensitivity to the minority classes. Indeed, consider a

dataset in which there are majority classes that

contain very large numbers of instances. In this

context, solely relying on the oversampling of the

minority classes may result in overfitting and noise.

Once more, the SCUT method provides a remedy to

such a situation. We plan to further investigate this

aspect in the near future.

4 CONCLUSIONS

In this paper, we have proposed a hybrid sampling

method called SCUT which combines SMOTE and

cluster-based undersampling to improve the

classification performance on multi-class

imbalanced datasets. Cluster-based undersampling

KDIR 2015 - 7th International Conference on Knowledge Discovery and Information Retrieval

232

handles within-class imbalance. Further, the

combination of cluster-based undersampling and

SMOTE aids to reduce between-class imbalance,

without excessive use of sampling.

We were not able to establish a clear superiority

of one oversampling method over the other.

However, we were able to determine that the SCUT

method is a promising candidate for further

experimentation. Our results suggest that our SCUT

algorithm is suitable for domains where the number

of classes is high and the levels of examples vary

considerably. We intend to further investigate this

issue. We also intend extending our approach to very

large datasets with extreme levels of imbalances,

since our early results indicate that our SCUT

approach would potentially outperform

undersampling-only techniques in such a setting. In

our paper, the number of instances for each class

was set to the mean value. Exploring the optimal

strategy for fixing the number of instances will be

further explored, e.g. by sampling the instances

directly from the distribution associated with the

mixture of Gaussians as obtained from the EM

algorithm.

Cost-sensitive learning is another common

approach for dealing with the class-imbalance

problem. Most of the existing solutions are

applicable to binary-class problems, and cannot be

applied directly to multi-class imbalanced datasets

(Sun et al., 2006). Rescaling, which is a popular

cost-sensitive learning approach for binary class

problems can be applied directly on multi-class

datasets to obtain good performance only when the

costs are consistent (Zhou and Liu, 2010). In

addition, rescaling classes based on cost information

may not be suitable for highly imbalanced datasets.

Designing a multi-class cost-sensitive learning

approach for inconsistent costs without transforming

the problem into a binary-class problem will be the

focus of our future work.

REFERENCES

Chawla, N., Bowyer, K., Hall, L., Kegelmeyer, W., 2002.

SMOTE: Synthetic minority over-sampling technique.

In Journal of Artificial Intelligence Research, Volume

16, pages 321-357.

Alcalá-Fdez, J., Fernandez, A., Luengo, J., Derrac, J.,

García, S., Sánchez, L., Herrera, F., 2011. KEEL data-

mining software tool: data set repository, integration

of algorithms and experimental analysis framework. In

Journal of Multiple-Valued Logic and Soft Computing,

pages 255-287.

Cortez, P., Cerdeira, A., Almeida, F., Matos, T., Reis, J,

2009. Modelling wine preferences by data mining

from physicochemical properties. In Decision Support

Systems, Elsevier, Volume 47, number 4, pages 547-

553.

Dempster, A. P., Laird, N.M., Rubin, D.B., 1977.

Maximum likelihood from incomplete data via the EM

algorithm. In Journal of the Royal Statistical Society,

Volume 39, Number 1, pages 1-38.

Fernández, A., Jesus, M., Herrera, F., 2010. Multi-class

imbalanced data-sets with linguistic fuzzy rule based

classification systems based on pairwise learning. In

Computational Intelligence for Knowledge-Based

System Design, Volume 6178, Number 20, pages 89-

98.

Han, H., Wang, W., Mao, B., 2005. Borderline-SMOTE:

A new over-sampling method in imbalanced data sets

learning. In Proceedings of International Conference

on Advances in Intelligent Computing, Springer,

Volume Part I, pages 878-887.

Japkowicz, N., 2001. Concept-learning in the presence of

between-class and within-class imbalances. In AI

2001: Lecture Notes in Artificial Intelligence, Volume

2056, Springer, pages 67-77.

Lichman, M., 2013. UCI Machine Learning Repository

[http://archive.ics.uci.edu/ml]. Irvine, CA: University

of California, School of Information and Computer

Science.

Rahman, M. M., Davis, D. N., 2013. Addressing the class

imbalance problem in medical datasets, In

International Journal of Machine Learning and

Computing, Volume 3, Number 2, pages 224-228.

Ramanan, A., Suppharangsan, S., Niranjan, M., 2007.

Unbalanced decision trees for multi-class

classification. In ICIIS 2007: IEEE International

Conference on Industrial and Information Systems,

IEEE Press, pages 291-294.

Sobhani, P., Viktor, H., Matwin, S., 2014. Learning from

imbalanced data using ensemble methods and cluster-

based undersampling. In PKDD nfMCD 2013: Lecture

Notes in Computer Science, Volume 8983, Springer,

pages 38-49.

Sun, Y., Kamel, M., Wang, Y., 2006. Boosting for

learning multiple classes with imbalanced class

distribution. In IEEE ICDM ’06: Proceedings of the

Sixth International Conference on Data Mining, IEEE

Press, pages 592-602.

Viktor, H.L., Paquet, E. and Zhao, J., 2013. Artificial

neural networks for predicting 3D protein structures

from amino acid sequences, In IEEE IJCNN:

International Joint Conference on Neural Networks,

IEEE Press, pages 1790-1797.

Wang, S., Yao, X., 2012. Multi-class imbalance problems:

analysis and potential solutions. In IEEE Transactions

on Systems, Man, and Cybernetics, Part B, Number 4,

pages 1119-1130.

Yen, S. J., Lee, Y. S., 2009. Cluster-based under-sampling

approaches for imbalanced data distributions. In

Expert Systems with Applications, Volume 36,

Number 3, pages 5718-5727.

SCUT: Multi-Class Imbalanced Data Classiﬁcation using SMOTE and Cluster-based Undersampling

233

Zhou, Z., Liu, X., 2010. On multi-class cost sensitive

learning. In Computational Intelligence, Volume 26,

No 3, pages. 232-257.

KDIR 2015 - 7th International Conference on Knowledge Discovery and Information Retrieval

234
