Optimizing Dependency Parsing Throughput

Albert Weichselbraun and Norman S¨usstrunk

Department of Information, University of Applied Sciences Chur, Pulverm¨uhlestrasse 57, Chur, Switzerland

Keywords:

Natural Language Processing, Dependency Parsing, Performance Optimization, Throughput.

Abstract:

Dependency parsing is considered a key technology for improving information extraction tasks. Research

indicates that dependency parsers spend more than 95% of their total runtime on feature computations. Based

on this insight, this paper investigates the potential of improving parsing throughput by designing feature

representations which are optimized for combining single features to more complex feature templates and

by optimizing parser constraints. Applying these techniques to MDParser increased its throughput four fold,

yielding Syntactic Parser, a dependency parser that outperforms comparable approaches by factor 25 to 400.

1 INTRODUCTION

Dependency parsing is considered a key technology

for improving natural language processing. Although

information extraction tasks such as named entity

linking, named entity recognition, opinion mining

and coreference resolution would beneﬁt from depen-

dency parsing, throughput has been one of the mayor

obstacles towards its deploymentfor big data and Web

intelligence applications.

Therefore, researchers have put more attention to

parsing throughput in recent years which led to sig-

niﬁcant speed improvements. The latest version of

the Stanford parser (Chen and Manning, 2014), for

instance, is able to process on average more than 900

sentences per second, a number which is even ex-

ceeded by MDParser (Volokh, 2013) with a through-

put of approximately 5200 sentences per second.

In contrast to related work which primarily fo-

cuses on the parsing and feature selection strategy,

this paper puts its emphasis on feature extraction and

the optimization of parsing constraints. The sug-

gested methods, therefore, complement related work,

i.e. they can easily be applied on top of them.

A major motivator for applying dependency pars-

ing is its potential to enable a more sophisticated text

processing for information extraction tasks such as

opinion mining. Qiu et al., for example, deﬁne syn-

tactic rules that draw upon dependencytrees to extract

opinion targets from text documents. Afterwards,

their approach propagates the value from opinion-

bearing words to their targets based on a set of pre-

deﬁned dependency rules, connecting the targets with

further terms within the sentence (Qiu et al., 2011).

Targets can transfer their sentiment to other terms

which can either be new sentiment terms or targets.

While Qiu et al. focused on identifying unknown

sentiment terms, Gindl et al. apply this approach to

the extraction of sentiment aspects and targets (Gindl

et al., 2013). Poria et al. use dependency parsing

for decomposing text into concepts based on the de-

pendency relations between clauses. Their approach

is domain-independent and extracts concepts with an

accuracy of 92%, obtains a precision of 85% for sen-

timent analysis, and a precision of 63% for emo-

tion recognition (anger, sadness, disgust, fear, sur-

prise and joy), therefore, outperforming approaches

which solely relied on N-grams or part-of-speech tag-

ging (Poria et al., 2014).

These improvements and the potential to facili-

tate more advance text understanding for information

extraction and text mining tasks in big data environ-

ments have been major drivers for developing and

evaluating the methods discussed in this paper.

The rest of this paper is organized as follows: Sec-

tion 2 presents an overviewof related work. Section 3

then provides an analysis of the dependency parsing

process, addresses areas for improving the parser’s

throughput, and performs isolated evaluations of how

these improvements impact the parsing speed. We

then present a detailed benchmark and evaluation of

our approach in Section 4 as well as a discussion of

the obtained results. The paper closes with an outlook

and conclusion in Section 5.

Weichselbraun, A. and Süsstrunk, N..

Optimizing Dependency Parsing Throughput.

In Proceedings of the 7th International Joint Conference on Knowledge Discovery, Knowledge Engineering and Knowledge Management (IC3K 2015) - Volume 1: KDIR, pages 511-516

ISBN: 978-989-758-158-8

511

2 RELATED WORK

Most current dependency parsers are either graph-

based or transition-based (Nivre and McDonald,

2008). Graph-based dependency parsers learn a

model for scoring dependency graphs from training

sentences and choose the highest scoring dependency

graph for unknown sentences. This strategy requires

the parser to create and score a large number of de-

pendency graphs which is a time consuming task.

Transition-based parsers, in contrast, only optimize

the transitions between parser states, i.e. the decision

on whether to create a dependency with the label l

between two nodes n

and n

. They derive the de-

pendency graph by performing such transitions for all

words in the sentence using a parsing strategy which

determines the set of possible transitions. Popular

parsing strategies are based on the transition system

by Nivre for projective and non-projective parsing

(Nivre, 2009), or on the Covington algorithm (Cov-

ington, 2001). Parsers which are based on Nivre’s

transition system have a parsing complexity of O(n)

for projective, and O(n

) for non-projective parsing

(Nivre, 2008). Since the fraction of non-projective

dependencies is usually very low even non-projective

dependency parsers that use Nivre’s transition system

have a close to linear time complexity (Nivre, 2009).

The Covington algorithm, in contrast, has a time com-

plexity of O(n

) in the worst case (Volokh and Neu-

mann, 2012).

Clearparser, which is now part of the ClearNLP

project (https://github.com/clearnlp), extends Nivre’s

algorithm (Nivre and McDonald, 2008) with a tran-

sition which determines whether the parser continues

with projective or non-projective parsing, cutting the

average parsing speed by 20% compared to the origi-

nal implementation (Choi and Palmer, 2011).

Although the importance of the parsing strat-

egy for parser throughput is well researched and

undisputed, feature extraction seems to play an even

more important role in optimizing dependency pars-

ing since it has not received much attention yet. Re-

cent research by He et al. suggests that many state of

the art dependency parsers spend most of their time in

the feature extraction step (He et al., 2013). Chen and

Manning observed that more than 95% of the parser’s

runtime is consumed by feature extraction, a number

which is even surpassed by the baseline parser used

by Bohnet (Chen and Manning, 2014; Bohnet, 2010).

The baseline evaluated in his paper uses the archi-

tecture of McDonald and Pereira and spends 99% of

its total runtime on feature extraction (McDonald and

Pereira, 2006).

He et al. address this problem by improving fea-

ture selection. Their parsing framework dynamically

selects features for each edge, achieving average ac-

curacies comparable to parsers which use the full fea-

ture set with less then 30% of the feature templates

(He et al., 2013).

Chen and Manning, in contrast, use dense features

which embed high dimensional sparse indicator fea-

tures into a low-dimensional model (Chen and Man-

ning, 2014). This approach does not only reduce fea-

ture extraction cost but also addresses common prob-

lems of traditional feature templates such as sparsity,

and incompleteness (i.e. the selected feature tem-

plates do not cover every useful feature combination)

(Chen and Manning, 2014).

3 METHOD

3.1 Feature Design

Syntactic Parser mitigates the problem of feature

sparseness by performing a frequency analysis of lex-

ical word forms, replacing words with a very low fre-

quency with the label

unknown

. Optimizing the fea-

ture design by replacing infrequent word forms with

the

unknown

label did not only improve the parser’s

throughput and memory consumption but also posi-

tively affected the parsing accuracy since it enabled

the classiﬁer to learn strategies for handling infre-

quent features.

We also systematically scanned for feature tem-

plates which do not signiﬁcantly improve parsing per-

formance and identiﬁed four combined features used

by MDParser as candidates for removalfrom the pars-

ing process.

3.2 Feature Representation

Parsers tend to spend a signiﬁcant amount of time in

the feature extraction and generation process. MD-

Parser generates new features by combining elemen-

tary string features such as part-of-speech tags, word

forms and dependencies with feature identiﬁers that

indicate the feature type (e.g.

pip1

, etc.).

Depending on the feature type between two (single

feature) and four (ternary feature) string concatena-

tions are required to generate the corresponding fea-

ture. Volokh and Neumann (Volokh and Neumann,

2012) analyzed this problem and came to the con-

clusion that computing these combination requires a

signiﬁcant amount of the total parsing runtime. They

also considered transforming string features into bi-

nary ones but suspected that the transformation might

KDIR 2015 - 7th International Conference on Knowledge Discovery and Information Retrieval

512

be too time intensive to provide an overall beneﬁt

(Volokh and Neumann, 2012).

Based on this analysis, an efﬁcient feature repre-

sentation would not only need to be more efﬁcient for

combining features but is also required to minimize

the number of transformations.

MDParser transforms String features to integer

values since the used liblinear classiﬁer operates

on numerical values. This step requires a total of

27 transformations for every word, since MDParser

computes 27 different features templates. Syntac-

tic Parser, in contrast, transforms elementary features

to integer values before the features are combined,

requiring only three transformations (part-of-speech,

word form and dependency) for every word in a sen-

tence.

Syntactic Parser represents its numerical features

n as 64-bit integers (Java long type) which consist

of (i) an 8 bit value indicating the feature type, and

(ii) one or more of the following elementary features:

word forms (20 bit), part-of-speech tag (16 bit) or de-

pendency label (16 bit). The feature type is always

stored in the last eight bits, while the position of ele-

mentary features depends on the feature type.

We, therefore, replace the mapping M : F → N of

parser feature strings f

∈ F to integer values n ∈ N

with three mappings that translate word forms w

∈

W (M

word form

: W → {0, ..., 1048575}), part-of-

speech tags pos

∈ P (M

pos

: P → {0, ..., 65535}) and

dependencylabels d

∈ D (M

dep

: D → {0, ...65535} )

to integer values. The numerical feature value n is

then derived by performing bit operations on these el-

ementary features.

Figure 1 illustrate the binary encoding for the fea-

tures wf

, m

, and m

. Combining and encoding fea-

tures is very fast, since it only involves bit operations

on 64 bit values which can be performed directly in

the CPU’s registers. We use hash maps which have

a time complexity of O(1) to translate between the

string features extracted from the input text and their

internal numerical representation. Another potential

optimization is replacing these maps with hash val-

ues obtained by calls to String’s

hashCode()

method

or to high throughput non-cryptographic hash func-

tions such as Murmur3

. Our experiments showed

that Java’s hash maps are very effective and no sig-

niﬁcant speed improvement could be obtained by re-

placing hash maps with the hash functions mentioned

above.

https://code.google.com/p/smhasher/

Figure 1: Binary feature encoding for single (w f

), binary

) and ternary features (m

3.3 Constraint Checking

The dependency parser needs to ensure that the cre-

ated dependency tree does not contain single heads,

reﬂexive nodes, improper roots, or cycles. MD-

Parser and Syntactic Parser perform projective pars-

ing and, therefore, also eliminate non-projective de-

pendencies. The parser tests for every combination

of two nodes, whether one of the above conditions is

met, before it even considers a dependency between

these nodes. This strategy has considerable speed and

accuracy beneﬁts, since these tests are less expensive

than querying the machine learning componentfor the

existence of a dependency.

Considering that (i) the test for cycles and projec-

tiveness traverse the dependency tree

and are, there-

fore, much more expensivethan tests for single heads,

reﬂexive nodes and improper roots, and that (ii) tests

are called

n·(n−1)

times for a sentence with n words,

optimizing the order of these tests has the potential

to considerably improve the performance of the de-

pendency parsing algorithm. This is also reﬂected

in the performance improvement obtained by chang-

ing the original test sequence (single heads, reﬂex-

ive nodes, cycles, improper roots, projectiveness) to

an optimized one (single heads, reﬂexive nodes, im-

proper roots, cycles, projectiveness). We also con-

sider that projectiveness is a symmetric property and,

therefore, compute it only once rather than twice (for

the potential dependency n

→ n

and for the depen-

dency n

→ n

The results summarized in Table 1 show a perfor-

mance boost of factor three for numerical features and

factor four for combining numerical features with op-

timized constraint checking over the original imple-

mentation. The computations required for optimizing

Nivre introduces an algorithm that does not require

traversing the dependency tree but rather performs these

checks in almost linear time (proportional to the inverse of

the Ackermann function) by using suitable data structures

to keep track of the connected components of each node

(Nivre, 2008).

Optimizing Dependency Parsing Throughput

513

the feature representation have been performed on an

Intel Core i3-2310M CPU at 2.10 GHz using a single

thread and the OpenJDK virtual machine in version

1.7.0

75 on the Ubuntu 14.04 operating system. The

presented results have been computed as the average

of three runs which have been performed after parsing

of 50,000 sentences to warm up the virtual machine.

In all experiments the standard deviation of the run-

time between the experiments has been below 1.5%.

Table 1: Comparison of the feature encoding speed for

string and numerical feature representations.

feature number of processing

representation sentences time (ms)

string 1,000 16

10,000 161

100,000 1,577

1,000,000 16,827

numerical 1,000 6

10,000 55

100,000 532

1,000,000 5,414

numerical & 1,000 4

optimized 10,000 41

constraints 100,000 405

checking 1,000,000 4,077

3.4 Parser Model

Based on performance evaluations with different

model optimization strategies, we decided to adopt

the strategy deployed by MDParser. MDParser di-

vides the parser model into several smaller mod-

els. For every distinct part-of-speech tag feature (pi-

feature), a separate model is trained. All feature sets

that are generated in one transition are grouped to-

gether according to this pi-feature. Table 2 illustrates

the structure of this composite parser model. This

separation has the following advantages:

• The models are comparably small and more spe-

ciﬁc which leads to faster predictions and better

accuracy.

• Every model can be optimized according to the

pi feature. This is important since the pi-feature

considerably inﬂuences the optimal prediction for

the next parser step.

We also perform a ﬁnal optimization step on the

trained model which eliminates features with a weight

of zero. This step reduces the model size and im-

proves the estimation speed, since only a few percent-

ages of the total feature set gets non-zero weights due

to the high number of sparse features.

Table 2: Composite parser model based on the part-of-

speech tag (pi-feature).

Feature pi Model

pi=VB model1

pi=NN model2

... ...

4 EVALUATION

4.1 Evaluation Setting

The experiments in this section compare Syntactic

Parser’s accuracy and throughput with four publicly

available, well known dependency parsers: (i) Malt-

Parser

, a transition based-parser which supports mul-

tiple transition systems, including arc-standard and

arc-eager (Nivre et al., 2010), (ii) MSTParser

, a two-

stage multilingual dependency parser created by Mc-

Donald et al. (McDonald et al., 2006), (iii) the latest

version of the Stanford dependency parser (Chen and

Manning, 2014), and (iv) MDParser which has been

the target of the optimizations described in this paper.

The evaluations have been performed on a sin-

gle thread of a Ubuntu 14.04 LTS server with two

16 core Intel Xeon E5-2650 CPUs at 2.0 GHz and

128 GB RAM using the 64-bit Java HotSpot in ver-

sion 1.8.0

31 and uses the universal dependency tree-

bank v2.0

, a publicly available collection of tree-

banks with syntactic dependency annotations. The

evaluation framework ran all parsers in their default

conﬁguration using the train ﬁles enclosed in the cor-

pora for training and the test ﬁles for testing accu-

racy and throughput. We did not perform any opti-

mizations such as running MaltOptimizer, optimizing

command line parameters or the feature design for

any of these parsers (including syntactic parser).

4.2 Results

Table 3 compares the parsers’ throughput and accu-

racy for the English universal dependencies corpus.

The experiments report parsing accuracy in terms of

correctly assigned head (unlabeled attachment score;

UAS) and the fraction of heads and types which have

been correctly identiﬁed (labeled attachment score;

LAS). Bold number indicate the best results for a

maltparser.org

www.seas.upenn.edu/ strctlrn/MSTParser

code.google.com/p/uni-dep-tb/

KDIR 2015 - 7th International Conference on Knowledge Discovery and Information Retrieval

514

Table 3: Throughput and accuracy on the universal dependency treebank.

Throughput in UAS (LAS) per language in %

Parser sent/sec en de fr es

Syntactic 22,448 85.3 (82.3) 78.9 (73.5) 79.3 (75.4) 82.2 (78.6)

MDParser 5,240 83.9 (80.6) 78.6 (72.2) 79.5 (74.9) 82.1 (78.0)

Stanford 909 82.1 (79.6) 76.6 (71.3) 78.8 (74.5) 80.7 (76.8)

Malt (arc-eager) 628 85.0 (82.2) 78.9 (72.8) 79.1 (75.1) 82.4 (78.8)

Malt (arc-standard) 691 84.8 (82.2) 78.2 (72.4) 79.6 (75.2) 83.0 (79.3)

MST 38 84.3 (80.6) 80.7 (73.1) 79.8 (74.4) 82.8 (78.0)

particular experiment. The results show that Syntac-

tic Parser provides a signiﬁcantly higher throughput

than any other parser. The differences between MD-

Parser and Syntactic Parser are particularly interest-

ing since Syntactic Parser is based on MDParser and,

therefore, employs the same parsing algorithm, indi-

cating that a more than four-fold improvement has

been solely achieved by applying the optimizations

discussed in this paper. The evaluation also demon-

strates that these enhancements did not come at the

cost of accuracy, on the contrary, Syntactic Parser out-

performs MDParser in three out of four evaluations

according to the UAS measure and in all experiments

for the LAS metric.

The results presented in Table 3 indicate that Malt-

Parser, MSTParser and Syntactic Parser are very close

in terms of accuracy. Syntactic Parser provides the

best UAS for English, MaltParser outperforms its

competition for Spanish, and MST performs best for

German and French. Syntactic Parser also yields the

best LAS for English, French and German. MDParser

does particularly well for French dependencies, but

provides considerably lower scores for the other lan-

guages. These differences have been caused by the

changes to the feature set and the introduction of a

placeholder label for low frequency terms in Syntac-

tic Parser (Section 3.1).

5 OUTLOOK AND

CONCLUSIONS

Many big data information extraction approaches still

apply lightweight natural language processing tech-

niques since more sophisticated methods do not yet

meet their requirements in terms of throughput and

scalability. The presented research addresses this

problem by optimizing the feature representation and

constraint handling of dependency parsers yielding

signiﬁcant speed improvements.

The main contributions of this work are (i) sug-

gesting a method to address common performance

bottlenecks in dependency parsers (ii) introducing

Syntactic Parser

, a dependency parser which has

been optimized based on the techniques presented in

this paper, and (iii) conducting comprehensive exper-

iments which outline the performance impact of the

proposed techniques, and compare the created parser

to other state of the art approaches.

The presented methodology yielded Syntactic

Parser, a dependency parser which provides state of

the art parsing accuracy and excels in throughput

and performance. Implementing the proposed op-

timizations increased the parsing performance more

than four-fold and also yielded a better overall ac-

curacy when compared to MDParser although both

parsers implement the same parsing strategy. Syn-

tactic Parser clearly outperforms all other parsers in

terms of throughput although it yields a comparable

UAS and LAS at the English, French, German and

Spanish universal dependency treebank.

ACKNOWLEDGEMENTS

The research presented in this paper has been con-

ducted as part of the COMET project (www.htw-

chur.ch/comet), funded by the Swiss Commission

for Technology and Innovation (CTI), and the Radar

Media Criticism Switzerland project (medienkri-

tik.semanticlab.net/about) funded by the Swiss Na-

tional Science Foundation (SNSF).

REFERENCES

Bohnet, B. (2010). Very High Accuracy and Fast Depen-

dency Parsing is Not a Contradiction. In Proceed-

ings of the 23rd International Conference on Com-

putational Linguistics, COLING ’10, pages 89–97,

A Web demo of Syntactic Parser is available at

demo.semanticlab.net/syntactic-parser. A runnable version

of the parser may be obtained from the authors for scientiﬁc

purposes.

Optimizing Dependency Parsing Throughput

515

Stroudsburg, PA, USA. Association for Computa-

tional Linguistics.

Chen, D. and Manning, C. (2014). A Fast and Accurate De-

pendency Parser using Neural Networks. In Proceed-

ings of the 2014 Conference on Empirical Methods in

Natural Language Processing (EMNLP 2014), pages

740–750, Doha, Qatar. Association for Computational

Linguistics.

Choi, J. D. and Palmer, M. (2011). Getting the Most

out of Transition-based Dependency Parsing. In Pro-

ceedings of the 49th Annual Meeting of the Associa-

tion for Computational Linguistics: Human Language

Technologies: Short Papers - Volume 2, HLT ’11,

pages 687–692, Stroudsburg, PA, USA. Association

for Computational Linguistics.

Covington, M. A. (2001). A fundamental algorithm for de-

pendency parsing. In In Proceedings of the 39th An-

nual ACM Southeast Conference, pages 95–102.

Gindl, S., Weichselbraun, A., and Scharl, A. (2013). Rule-

based opinion target and aspect extraction to ac-

quire affective knowledge. In First WWW Workshop

on Multidisciplinary Approaches to Big Social Data

Analysis (MABSDA 2013), Rio de Janeiro, Brazil.

He, H., III, H. D., and Eisner, J. (2013). Dynamic Fea-

ture Selection for Dependency Parsing. In Empirical

Methods in Natural Language Processing (EMNLP

2013).

McDonald, R., Lerman, K., and Pereira, F. (2006). Multilin-

gual Dependency Parsing with a Two-Stage Discrimi-

native Parser. In Tenth Conference on Computational

Natural Language Learning (CoNLL-X).

McDonald, R. and Pereira, F. (2006). Online learning of

approximate dependency parsing algorithms. In Pro-

ceedings of 11th Conference of the European Chap-

ter of the Association for Computational Linguistics

(EACL-2006)), volume 6, pages 81–88.

Nivre, J. (2008). Algorithms for Deterministic Incre-

mental Dependency Parsing. Computer Linguistics,

34(4):513–553.

Nivre, J. (2009). Non-projective Dependency Parsing in

Expected Linear Time. In Proceedings of the Joint

Conference of the 47th Annual Meeting of the ACL

and the 4th International Joint Conference on Natu-

ral Language Processing of the AFNLP: Volume 1 -

Volume 1, ACL ’09, pages 351–359, Stroudsburg, PA,

USA. Association for Computational Linguistics.

Nivre, J. and McDonald, R. (2008). Integrating Graph-

Based and Transition-Based Dependency Parsers.

In Proceedings of ACL-08: HLT, pages 950–958,

Columbus, Ohio. Association for Computational Lin-

guistics.

Nivre, J., Rimell, L., McDonald, R., and G´omez-Rodr´ıguez,

C. (2010). Evaluation of Dependency Parsers on Un-

bounded Dependencies. In Proceedings of the 23rd

International Conference on Computational Linguis-

tics, COLING ’10, pages 833–841, Stroudsburg, PA,

USA. Association for Computational Linguistics.

Poria, S., Agarwal, B., Gelbukh, A., Hussain, A., and

Howard, N. (2014). Dependency-based semantic pars-

ing for concept-level text analysis. In Gelbukh, A.,

editor, Computational Linguistics and Intelligent Text

Processing, number 8403 in Lecture Notes in Com-

puter Science, pages 113–127. Springer Berlin Hei-

delberg.

Qiu, G., Liu, B., Bu, J., and Chen, C. (2011). Opinion

Word Expansion and Target Extraction through Dou-

ble Propagation. Computational Linguistics, 37(1):9–

27.

Volokh, A. (2013). Performance-oriented dependency pars-

ing. PhD Thesis, Saarland University.

Volokh, A. and Neumann, G. (2012). Dependency Parsing

with Efﬁcient Feature Extraction. In Glimm, B. and

Kr¨uger, A., editors, KI 2012: Advances in Artiﬁcial

Intelligence, number 7526 in Lecture Notes in Com-

puter Science, pages 253–256. Springer Berlin Hei-

delberg.

KDIR 2015 - 7th International Conference on Knowledge Discovery and Information Retrieval

516
