The Study on the Identity Verification between the on-Site Face

Image and the ID Photo

Zhiguo Yan, Chun Pan and Zheng Xu

The Centre of Internet of Things, The Third Research Institute of Ministry of Public Security

339 Bisheng Road, Shanghai, China

Keywords: Identity Verification, Super-resolution Reconstruction Deep Learning Face Verification RFID.

Abstract: Nowadays, how to pass the security-check passageway with self-service under high throughput is an

emerging application challenge. The identity verification technique is the key factor to solve this dilemma,

especially in the railway station, bus station and airport etc. The essence of this question is the one vs. one

face verification. It involves two crucial application knot, the real-time super-resolution image

reconstruction and the real-time face detection and recognition in the video stream under the surveillance

scene. To improve the performance of the identity verifications system based on face similarity assessment

we exploited the deep learning mechanism to train the face detection module and the to realize the super-

resolution construction remarkably. The experiment proves its effectiveness.

1 INTRODUCTION

In recent years, with the boosting demand on

security check in railway station, bus station and air-

port, the self-service passenger pass as an important

pre-check mechanism has attract the wide attention.

The general application mode lies on the identity

verification between the passenger on-site face

image and the electronic identification photo. While

passenger approached the security-check gate, they

will swipe the RFID ID-card and the RFID reader

capture the stored electronic photo. At the same

time, their face images are captured and stored by

the on-the-spot surveillance camera mounted on the

security gate. The identity verification system will

automatically judge whether the passenger is

identical with his carried ID-card based on the face

similarity measurement. To those passengers whose

score meet the threshold condition, they are allowed

to pass the security-check gate. Otherwise they will

be blocked.

This procedure involves two key techniques: the

identification photo enhancement and the dynamic

face verification based on the real-time video

stream. As it is well known that the size of the

electronic photo stored in the RFID ID-card is

126*102 pixels. This image quality is too weak and

unsuitable to execute the face verification. As a

premise, the enhancement is a necessary

preprocessing. The advisable preprocessing for

image enhancement will effectively reduce the false

alarm dramaticlly. Considering the low resolution is

the key difficulty which impede the practical

application, we focus our attention on super-

resolution (SR) reconstruction (Dong, 2015) during

the image enhancement stage. Different form the

work, we adopt the online super-resolution

reconstruction for the captured electronic photos.

The reason lies in that we can’t get the electronic

photos prior to the identity verification.

Furthermore, with respect to the on-line super-

resolution construction for the electronic

identification photos, what we can utilized is just

themselves. In other words, no redundant

information derived from other photos will

introduced into the super-construction process.

As the real-time video stream is concerned, the

content analysis focus on the pedestrian detection

and face region segmentation. The frontal face

capture is the crucial step during the dynamic face

verification. As to the frontal face image capture,

our previous work (Yan, 2013) has addressed a kind

of promising methods.

Pedestrian detection in complex scenes is a tough

problem. In the general surveillance scene, the

unsuitable illumination intensity, the body occlusion

and the backlight and shadow exist frequently and

give severe adverse impact on face region

segmentation. To speed up the pedestrian detection,

we execute the down-sampling for those raw frames

130

Pan C., Xu Z. and Yan Z.

The Study on the Identity Veriﬁcation between the on-Site Face Image and the ID Photo.

DOI: 10.5220/0006020401300133

In Proceedings of the Information Science and Management Engineering III (ISME 2015), pages 130-133

ISBN: 978-989-758-163-2

with 1920*1080 pixels and the DPM algorithm is

utilized to find out the pedestrian. In some case,

there exists some pedestrians in one frame image

which give rise to the multi-face detection. To avoid

this phenomena, we tune the focus and the Tele-

Wide button to select the advisable view coverage.

Moreover, the narrow passageway will limit the

occurence of the multi-face in one frame. To the

worst case, there still exists multi-face in one frame,

we adopt the face with maximum face region as the

analyzed target.

The remaining parts of this paper are organized

as follows. Section П gives a simple introduction to

the proposed identity verification procedure, and

describes super-resolution reconstruction, dynamic

face verification. The experimental result is given in

section . Conclusions are figured out in the section

2 THE PROPOSED

ARCHITECTURE

As shown in Fig. 1, the identity verification system

is composed of four parts: the on-site surveillance

camera module, the RFID card reader module, the

online face verification module and the automatic

security gate control module.

Figure 1: The Schematic Drawing of Identity Verification.

Figure 2: The on-the-spot Deployment of Identity

Verification based on Face Verification Mechanism.

In Fig.1, the on-site surveillance camera module

is designed to capture the corresponding on-site face

image while the passenger is swiping his ID card.

The RFID reader module provide the electronic ID

photo for online face verification module. From

Fig.1 we can figure out that the opening of the

security gate is trigged by the positive verification

result.

Fig.3 shows the configuration of the identity

verification system integrated with luggage X-ray

security check device. While passengers approach

the security check system, their luggage bags will be

transmitted by the transmission belt in the X-ray

scanner and they will pass through the security-

check gate with self-service. The security system

will determine whether allow the passenger to pass

the gate according to the joint judgement of luggage

security check and the identity verification.

Figure 3: The integration of the Identity Verification

Security check gate with the X-ray luggage scanning

device.

In identity verification system, the threshold

value setting for the image similarity is very vital. If

the threshold value is too high, many eligible people

could not pass the identity verification and the false

alarm occurs too frequently. Conversely, if the

threshold value is too low, those unqualified people

will pass the identity verification. In this case, the

system is invalid. So, the setting of threshold value

should keep balance between the rapidness and the

false alarm rate. The trade-off acquisition is

handcrafted and time-consuming. There are no

specific rules or principles to guide the setting, just

depend on the practical experiments in particular

cases. In our further work, we will study the

technique for setting optimum threshold value.

In the following paragraphs, we will introduce

the two core techniques in the image similarity-

based identity verification system. One is the super-

The Study on the Identity Verification between the on-Site Face Image and the ID Photo

131

The Study on the Identity Veriﬁcation between the on-Site Face Image and the ID Photo

131

resolution reconstruction, the other is the deep

learning-based face detection.

Generally speaking, the super resolution

construction are some kinds of restoration

techniques, which consists frequency domain

algorithm and time domain algorithm, for the

original high resolution image based on multi-frame

low resolution images (Zhang, 2010). All the low

resolution images is captured in the same scene with

the original high resolution image and there just

exists slight changes. If there only exists one low

resolution, the ordinary method to get the high

resolution image is interpolation.

In the case of only one low resolution image,

different form the traditional interpolation method,

in (Luo, 2011) the authors proposed the deep

learning-based strategy for single image super-

resolution. With light weighted structure deep

convolution neural network (CNN), this method

directed learns an end-to-end mapping between the

low/high resolution images. They also proved that

the sparse-coding-based SR can be viewed as a

convolutional neural network. This work claimed the

state-of-the-art performance and suitable for the

online usage.

Figure 4: Given a low resolution image Y, the first

convolution layer extracts a set of feature maps. The

second layer maps these feature maps nonlinearly to high

resolution patch representation. The last layer combines

the predictions with a spatial neighbourhood to produce

the final high resolution image F(Y).

In this above-mentioned work, the authors took

the low resolution image as the input and output the

high resolution one. To execute the image quality

enhancement using this deep-learning-based method,

the training stage should be carried out prior to the

output stage. Refer to this method, we utilize over

5000 pairs of LR images and HR images, which

with 126*102 pixels and 441*358 pixels

respectively, as training dataset.

Fig.4 shows the schematic diagram of the deep

learning-based SR.

Face detection in the complex scenes is an

essential but rarely rough task. To the fixed

surveillance camera, the field of view (FOV) is

constant. In this scene, the face region in the frame

image is enough bit to execute the face detection.

But in the ordinary surveillance scenes, to those

peoples far away from the fixed-focus camera, the

face region maybe too small to be detected. In this

case, the pedestrian detection should be utilized to

detect the concerned people and track this people

until his approach makes the face region enough big

to be detected. This strategy was proposed in our

previous work (Yan, 2014) and proved to be

effective and efficient.

Considering the complexity of face detection in

the ordinary surveillance scenes, the researchers

presents a new state-of-the art approach in (Chen,

2014). They observed that the aligned face shapes

provides better features for face classification. To

combine the face alignment and detection more

effectively, they learned this two tasks in the same

cascade. By exploiting the joint learning, the

capability of cascade detection and real time

performance can both achieve the satisfied status.

Figure 5: The key point annotation on face shape.

As shown in Fig.5, we use 38 key points to

describe the face shape, 10 points for face contour, 6

points for eyebrows, 10 points for eyes, 7 points for

nose and 5 points for lip respectively.

We bought a face image dataset consisted of

about 20, 000 face images and 20, 000 natural scene

images without faces from web. All face images are

transferred into grayscale images. After all the face

images are labelled, the dataset is utilized to train the

classification/regression tree.

3 EXPERIMENT AND

CONCLUSION

We utilized the combination of the on-site

surveillance camera and RFID reader to realize the

self-service passenger pass. The key techniques

focus in the on-site face detection effectively and the

online SR reconstruction for the low resolution ID

electronic photos. As a comparison, we also directly

ISME 2015 - Information Science and Management Engineering III

132

ISME 2015 - International Conference on Information System and Management Engineering

132

adopted the electronic ID photos without the SR

construction.

The subject consists of 131 peoples. In the

experiments, 5 people face can’t be detected

successfully. Among the other 126 peoples, 102

peoples can pass the security check with the online

SR construction, nearly 80.9% hit rate. At the same

scene, without the SR construction, only 46 peoples

among the 126 peoples can pass the security check

gate with self-service, nearly 36.5% hit rate. The

interface of the identity verification system is shown

in fig. 6.

Figure 6: The interface of the Identity Verification

System.

As mentioned before, some face image can’t be

successfully detected in the surveillance vision. This

default is partly due to the limited FOV of the focus-

fixed camera. In our future work, we will adopt the

dual-camera configuration consists of a static

camera and an active camera to replace the single

focus-fixed camera, see fig.7.

In fig.7, the static camera is a fixed-focus camera

with wide view range and in charge of the pedestrian

detection and transmit the corresponding position

information to the active camera which has the

variable focus. The active camera and track the

pedestrian and grab the clear HR face image for

identity verification system.

Figure 7: The dual-camera configuration in Identity

verification system.

The proposed identity verification system is

based on the image similarity measurement, and the

practical experiments show its effective in practice.

On the other hand, frankly speaking, the

performance without the SR construction is inferior

to the expectation, i.e., the electronic ID photo is

unsuitable to be used directly for identity

verification.

ACKNOWLEDGEMENTS

Our research was supported by the Innovation plan

for practical application of the Ministry of Public

Security (No. 2012YYCXGASS125), National

Science and Technology Support Projects of China

(No. 2012BAH07B01), the Project of Shanghai

Municipal Commission Of Economy and

Information (No. 12DZ0512100) Major program

of Science and Technology Commission of

Shanghai Municipality (No.12510701900), National

High-tech R&D Program of China 863 Program

(No. 2013AA01A603).

REFERENCES

Dong, C., et al., Image Super-Resolution Using Deep

Convolution Networks. arXiv preprint

arXiv:1501.00092, 2014: p. 12.

Yan, Z., F. Yang, and J. Wang, Face Orientation

Detection in Video Stream based on Haar-Like

Feature and LQV Classifier for Civil Video

Surveillance, in 2013 IET Second International

Conference on Smart and Sustainable City2013:

Zhangjiajie, Hunan. p. 5.

Zhang, L., H. Zhang, and H. Shen, A super-resolution

reconstruction algorithm for surveillance images.

Singal Processing, 2010(90): p. 12.

Yan, Z. and K. Gu, The Study on the Techniques on Gun-

Dome Camera Cooperative Human-Tracing. The 10th

International conference on Semantic, Knowledge and

Grid, 2014: p. 6.

Chen, D., S. Ren, and Y. Wei, Joint Cascade Face

Detection and Alignment. European Conference on

Computer Vision (ECCV),, 2014: p. 14.

Luo, X., Xu, Z., Yu, J., and Chen, X. 2011. Building

Association Link Network for Semantic Link on Web

Resources. IEEE transactions on automation science

and engineering, 8(3):482-494.

The Study on the Identity Verification between the on-Site Face Image and the ID Photo

133

The Study on the Identity Veriﬁcation between the on-Site Face Image and the ID Photo

133
