Survey on Textual Notations for the Uniﬁed Modeling Language

Stephan Seifermann and Henning Groenda

Software Engineering, FZI Research Center for Information Technology, Haid-und-Neu-Str. 10-14, Karlsruhe, Germany

Keywords:

UML, Textual Notation, Survey, Editing Experience.

Abstract:

The Uniﬁed Modeling Language (UML) has become the lingua franca of software description languages.

Textual notations of UML are also accessible for visually impaired people and allow a more developer-oriented

and compact presentation. There are many textual notations that largely differ in their syntax, coverage of the

UML, user editing experience, and applicability in teams due to the lack of a standardized textual notation.

The available surveys do not cover the academic state of the art, the editing experience and applicability in

teams. This implies heavy effort for evaluating and selecting notations. This survey identiﬁes textual notations

for UML that can be used instead of or in combination with graphical notations, e.g. by collaborating teams

or in different contexts. We identiﬁed and rated the current state of 16 known notations plus 15 notations that

were not covered in previous surveys. 20 categories cover the applicability in engineering teams. No single

editable textual notation has full UML coverage. The mean coverage is 2.7 diagram types and editing support

varies between none and 7 out of 9 categories. The survey facilitates the otherwise unclear notation selection

and can reduce selection effort.

1 INTRODUCTION

The Uniﬁed Modeling Language (UML) has become

the lingua franca of software description languages.

The UML speciﬁcation comes with a graphical no-

tation, which is commonly applied. There is no

standardized textual notation. According to Spinel-

lis (Spinellis, 2003), textual notations provide an al-

ternative representation. It can be more compact or

more intuitive for certain user groups than the graph-

ical representation. An example is the textual repre-

sentation of an UML activity diagram-like speciﬁca-

tion of a service’s behavior (Erb, 2011). The textual

version requires signiﬁcantly less space for the repre-

sentation and is more intuitive to developers.

There are several tailored textual notations tai-

lored for speciﬁc purposes such as creating documen-

tation integrated in the code, having a more com-

pact representation, or increasing accessibility. They

largely differ in their syntax, coverage of the UML,

user editing experience, and applicability in an engi-

neering teams.

The latest surveys covering textual UML notations

were performed by Luque, et al. (Luque et al., 2014a;

Luque et al., 2014b). The former (Luque et al., 2014a)

focuses on the accessibility of UML for blind students

in classrooms and the latter (Luque et al., 2014b) on

tools for use-case and class diagrams used in indus-

try at 20 companies in the state of Sao Paolo (Brazil).

Both surveys target notations used in practice without

regarding the state of the art described in scientiﬁc

publications. (Mazanec and Macek, 2012) focuses on

textual notations in general but is a few years old and

covers few notations. It does not represent the current

development state and available variety of the nota-

tions and modeling environments. The three existing

surveys show that there is a wide range available with

individual advantages and drawbacks. They do not

analyze the user’s editing experience, which is cru-

cial for using a notation in a collaborating engineering

team, and requires heavy analyses effort. The overall

effort reduces the chance for a comprehensive analy-

sis and can endanger the selections’s quality.

The contribution of this survey is the identiﬁca-

tion and classiﬁcation of textual UML notations in-

cluding the user experience. Engineering teams can

use the classiﬁcation for identifying appropriate no-

tations for their usage scenarios. The classiﬁcation

scheme is tailored to support this selection. This sur-

vey examines accessibility of notations with respect to

their syntax, editors, and modeling environment. Us-

ability in realistic scenarios is determined by covered

diagram types, data format exchanges, and synchro-

nization approaches with other notations. It addition-

ally evaluates whether non-necessary parts of the no-

tation can be omitted. This sketch support eases low-

Seifermann, S. and Groenda, H.

Survey on Textual Notations for the Uniﬁed Modeling Language.

DOI: 10.5220/0005644900280039

In Proceedings of the 4th International Conference on Model-Driven Engineering and Software Development (MODELSWARD 2016), pages 28-39

ISBN: 978-989-758-168-7

overhead discussion and brainstorming. For instance,

the UML speciﬁcation allows to omit the types of the

class attributes.

The survey identiﬁed and rated 31 notations of

which 15 were not covered in previous surveys. 20

categories allow ﬁne-grained pre-selection and cover

the applicability in engineering teams.

The remainder of this survey is structured as fol-

lows: Section 2 describes the review method of the

survey by deﬁning the objectives and the review pro-

tocol consisting of three phases. Section 3 describes

the classiﬁcation scheme based on the deﬁned objec-

tives. Section 4 presents the analysis results in terms

of classiﬁed textual notations. Section 5 discusses the

validity of the results and the ﬁndings. Finally, Sec-

tion 6 concludes the paper.

2 REVIEW METHOD

The review process follows the guidelines of Kitchen-

ham and Charters (Kitchenham and Charters, 2007).

They developed guidelines for structured literature re-

views (SLR) in software engineering based on the

guidelines in the ﬁeld of medical research. Their

guidelines cover the planning, conduction, and writ-

ing of reviews. Planning involves deﬁning research

objectives and creating a review protocol describing

the activities in each step during the review conduc-

tion.

The following sections describe our implementa-

tion of the SLR and mapping to the proposed method.

The results of our search activities are documented

and available for reproducibility at http://cooperate-

project.de/modelsward2016.

2.1 Objectives

Our objectives are to determine each notation’s (O1)

coverage of the UML, (O2) user editing experience

and (O3) applicability in an engineering team. The

reasoning requires an analysis of the textual notations

and of the modeling environments. Section 3 presents

the detailed classiﬁcation scheme based on the ob-

jectives and instructions on the according information

extraction procedure from literature.

2.2 Review Protocol

Figure 1 shows an overview of our review protocol.

We distinguish three phases during the conduction:

classic SLR, Quality Assurance and Complement.

The classic SLR follows the guidelines of review

conduction by Kitchenham, et al. (Kitchenham and

ad Quality Assurance

Identification of

Research

Study Selection

Study Quality

Assessment

Data Extraction

Data Synthesis

Identification of

Unpublished

Approaches

Build Reference

Closure

Reasoning

Check Availability

Study Selection

Study Quality

Assessment

Data Extraction

Data Synthesis

ad SLR ad Complement

Data Extraction

Data Synthesis

Figure 1: The three phases of the review conduction process

used in this survey.

Charters, 2007). We extend the SLR with two addi-

tional phases in order to increase the quality of the re-

sults and to take notations into account that are mainly

used in (industrial) practice: The Quality Assurance

phase focuses on incoming and outgoing literature

references as suggested by the Snowballing search

approach (Wohlin, 2014). In contrast to the original

proposal, we use Snowballing only to cross-check our

SLR search strategy. The Complement phase focuses

on textual notations that are available in practice but

are not scientiﬁcally published.

2.3 Phase 1: SLR

The review conduction according to (Kitchenham and

Charters, 2007) consists of the ﬁve activities marked

as SLR in Figure 1.

The Identiﬁcation of Research describes the

search strategy for collecting literature. We chose a

keyword-based search approach using the search en-

gines ACM Digital Library, IEEExplorer, CiteSeer,

ScienceDirect, SpringerLink and Google Scholar.

These search engines cover relevant journals and are

suggested by Kitchenham and Charters for the soft-

ware engineering domain. We did not include EI

Compendex and Inspec as we could not query these

search engines without subscriptions. Their focus is

on high-qualitative entries and metadata and they do

not belong to a not-covered established publishing

authority. We are conﬁdent that the selected search

engines are sufﬁcient and that no relevant paper is

not selected by our keywords because of insufﬁcient

Survey on Textual Notations for the Uniﬁed Modeling Language

Table 1: Keyword groups used in search queries.

Group Keywords

Textual T CTS, textual modeling, textual mod-

elling, text-based modeling, text-

based modelling, textual notation,

text-based notation, textual UML,

text-based UML, textual syntax

UML U UML, uniﬁed modeling language,

uniﬁed modelling language

metadata provided by the selected engines.

We deﬁned a set of keywords T for identifying

textual notations and another one U for identifying the

usage of UML. Both sets are shown in Table 1 and are

variations of our original terms textual notation, and

UML. They are based on commonly used terminology

in the modeling domain. A search query is given by

∨t

∨ . . . ∨t

) ∧ (u

∨ u

) with t

∈ T ∧ u

∈ U.

The query enforces the exact matching of keywords.

It considers abstracts and titles because this restricts

the search to literature that focuses on textual nota-

tions for UML. Google Scholar has API restrictions

that limit queries on abstracts to papers that have been

released at most one year ago. This restriction does

not apply to our title-based search. We restrict Sci-

enceDirect queries to computer science papers. We

implemented a search on the SpringLink results en-

abling keyword identiﬁcation in the abstract. After

collecting the results of all search engines, we merge

them and ﬁlter duplicates.

Study Selection covers a rough screening based on

titles and abstracts to allow spending more time on

relevant literature. We focus on textual notations for

graphical parts of the UML notation, which are given

in the UML speciﬁcation (OMG, 2015a, p. 683). We

exclude all textual notations only extending UML or

its elements rather than expressing UML itself. We

exclude all notations that are not related to UML. We

exclude notations not intended for usage by humans

such as data transfer containers, e.g. XMI serializa-

tion (OMG, 2015b). We include a) primary papers

describing a single textual notation, and b) secondary

survey-like papers including their references as pri-

mary sources.

The Study Quality Assessment considers title, ab-

stract, and the content of the full paper. We decide on

in-/exclusion of the remaining papers in this step.

Data Extraction is the process of determining the

information required to judge about the fulﬁllment of

the objectives. Section 3 shows the analyzed features

of the notations, their hierarchy, and individual deci-

sion basis in detail. We reason on the modeling en-

vironment based on information found directly in lit-

erature, implemented prototypes, prototype websites,

and source code. We identify prototypes, their web-

site, and the source code by: a) following links in the

papers, b) mining the website of the institute or com-

pany of the authors, c) and searching for the name of

the notation (full name and abbreviation if used) via

the Google search engine and on Githuband visit the

ﬁrst one hundred search results. Data extraction takes

place for the declared primary editor. If there is more

than one prototype, we use the declared primary edi-

tor and an IDE-integrated editor. We assume the latter

to proﬁt from advanced accessibility features of the

IDE. If there are editors for several IDEs, we decide

in favor of the Eclipse-based one because Eclipse is

open source, highly extensible, and offers many ac-

cessibility features

Data Synthesis summarizes the information. We

show and summarize the analysis results according to

the classiﬁcation given in Section 3.

2.4 Phase 2: Quality Assurance

The Quality Assurance phase is based on the Snow-

balling approach (Wohlin, 2014) of Wohlin. Wohlin

suggests starting with an initial set of relevant liter-

ature and including relevant forward and backward

references. Afterwards, the resulting set of literature

is processed as described in common SLR processes.

We do not use Snowballing as primary source for rele-

vant literature because its quality heavily depends on

the initial literature set as described by Wohlin. In-

stead, we accept the overhead of a prior SLR phase

with broad search terms and use Snowballing to ver-

ify the quality of our SLR phase as described below.

Build Reference Closure determines the complete-

ness of results from the SLR phase. We collect all

directly referenced and referencing literature for the

analyzed papers. We derive the referenced literature

from the references section of the paper. We use

Google Scholar to determine the literature that cites

the paper under investigation.

The Study Selection and Study Quality Assessment

from phase SLR are applied to identify additional no-

tations.

We perform Data Extraction on selected papers as

in the SLR phase and add the notation to our database.

Data Synthesis summarizes the information as

carried out in the SLR phase.

Reasoning addresses why the newly identiﬁed no-

tations have not been found in the SLR phase. The

results are presented in Section 5. This phase is dif-

ferent from the Snowballing approach of Wohlin and

allows us to verify the quality of our SLR phase.

https://wiki.eclipse.org/Accessibility

MODELSWARD 2016 - 4th International Conference on Model-Driven Engineering and Software Development

2.5 Phase 3: Complement

Identiﬁcation of Unpublished Approaches focuses on

textual notations that are available in practice but are

not scientiﬁcally published. We use the Google search

engine to identify the top 5 pages for ’UML textual

notation’, ’UML textual notations’, ’UML textual no-

tations list’. We mine the resulting websites to iden-

tify new approaches. We follow the links from the

identiﬁed websites looking for notations or compar-

isons of notations.

Additionally, we search for unrecognized scien-

tiﬁc surveys or notation comparisons. We perform a

full-text search via Google Scholar with the names of

the three most popular non-scientiﬁc notations. We

assume that recent surveys including non-scientiﬁc

notations cover them and thereby will be included in

the search results. We determine a notation’s popular-

ity by querying Google with the name of the notation

and comparing the announced results with the amount

of other notations. We only included notations that do

claim to relate to the UML.

In Check Availability, we exclude potential nota-

tions with dead links for all results.

We perform Data Extraction for new notations,

analyze the information, and add the notation to our

database.

Data Synthesis summarizes the information as

carried out in the SLR phase.

3 CLASSIFICATION

This section presents the classiﬁcation and informa-

tion extraction goals derived from the three objectives

presented in Section 2.1. The objectives cover aspects

of what can be edited based on the textual notation

deﬁnition (O1, O2) as well as how it can be edited

based on modeling environments (O2, O3). We use

feature modeling to represent the evaluation classes,

their hierarchy, and possible values. The resulting

overview is depicted in Figure 2. The features them-

selves and how their values are evaluated for the no-

tations are presented in the following.

Each Textual Notation is deﬁned by a Language

(O1, O2) and an optional Implementation (O2, O3) in

a modeling environment.

The Implementation is optional and covers all as-

pects with respect to a modeling environment for a

notation. It can have Recent Activity (O3), a License

(O3), and can support Change Propagation (O2, O3)

between different notations, data Format Exchange

(O2), and Editor (O2) features.

We divide the classiﬁcation of the implementation

into two parts for a better overview: integration as-

pects, and the editor itself. The former covers the fea-

tures relevant for integrating an implementation into

a tool chain. The latter covers the editing experience

of the editors.

The following subsections will cover the lan-

guage, integration, and the editor in that order.

3.1 Language

The Language deﬁnition is mandatory and describes

the language’s syntax and semantics. It consists of the

UML Support (O1) for diagram types and can have

Sketch Support (O2), integrated Layout Information

(O2), and be Similar to UML Graphics (O2).

UML Support is mandatory and describes the sup-

ported UML diagram types. At least one type has to

be supported. A type is supported if the documenta-

tion states it to be supported or the modeling environ-

ment allows the creation of a corresponding type. The

considered diagram types are based on the UML spec-

iﬁcation (OMG, 2015a, p. 682). The abbreviations

are based on the ofﬁcial abbreviations from (OMG,

2015a, p. 682), or self-made if there is no ofﬁcial

one: Activity Diagram (ACT), Class Diagram (CLS),

Communication Diagram (COM), Component Dia-

gram (CMP), Composite Structure Diagram (COS),

Deployment Diagram (DEP), Interaction Overview

Diagram (INT), Object Diagram (OBJ), Package Di-

agram (PKG), Proﬁle Diagram (PRO), Sequence Dia-

gram (SEQ), State Machine Diagram (STM), Timing

Diagram (TIM), and Use Case Diagram (UC).

Sketch Support is optional and can ease the no-

tation’s usage during discussions. Discussions beneﬁt

from quick interaction and formal full-ﬂedged model-

ing can extend the interaction time. There is support

if only mandatory elements of UML’s abstract syntax

are required.

Layout Information is optional states if the textual

model can contain graphical layout information. This

information allows to improve graphical presentation

of the textual statements. The information is irrele-

vant to describe the model itself. The interpretation

is difﬁcult as graphical coordinates or positions are

only visible in graphic notations. The information can

be either Mixed with model elements or kept Sepa-

rated. It is marked as Mixed if at least one element

has mandatory layout information.

Similar to UML Graphics is optional and denotes

if graphical syntax elements such as arrows are repli-

cated in the textual notation by ASCII art. For in-

stance, the characters <>--> are similar to the UML

graphical representation for an aggregation. This can

Survey on Textual Notations for the Uniﬁed Modeling Language

Textual Notation

Language

Implementation

Sketch Support

Similar to UML

Graphics

Layout

Information

UML Support

Mixed

Separated

CLS

SEQ

… (12 more)

Editor

License

Open Source

Closed Source

Export

Import

UML XMI

Custom

Format Exchange

Textual to

Graphical

Graphical to

Textual

Via Import/Export

Change

Propagation

Textual

Graphical

Editable

Layoutable

Visualization

Navigation

Refactoring

Folding

Syntax

Highlighting

Code Completion

Outline

Goto

Syntax

Element

Optional

Mandatory

Logical ORLogical XOR

Recent Activity

Release Activity

Ticket Activity

Commit Acitivity

Figure 2: Feature model for analyzed characteristics and their hierarchy.

work well for people knowing the graphical represen-

tation but have adverse effects on people using ac-

cessibility tools like Braille displays. A notation is

marked as similar if there is at least one ASCII art

mapping.

3.2 Integration

The integration covers all features that are relevant

for integrating an implementation into a tool chain.

Such a decision is based on the costs, extensibility,

support, maintainability and compatibility to existing

tools. The following features cover these aspects in

more detail.

The Recent Activity is optional and indicates the

support status. In contrast to a maintained project,

a discontinued project will not receive bugﬁxes and

might be incompatible to recent software such as new

versions of an IDE. We determine three activity dates

that allow judging project activity. One of them has to

be identiﬁable: Release Activity relates to the date of

the last release. A release can be a proper release,

snapshot, or nightly build. Ticket Activity is deter-

mined by the date of the most recently closed ticket.

Commit Activity is given if we can determine the most

recent commit.

The License is optional and can be crucial for us-

ing and maintaining the modeling environment. Open

Source licenses allow own bug ﬁxing and the devel-

opment of extensions and adaptations. The individual

requirements for a license depend heavily on the us-

age context of the modeling environment. An expert

review is required to check for a notation of interest if

it applies to the own use case. We therefore differen-

tiate solely between Open Source and Closed Source

licenses. We rely on the list of the Open Source

Initiative (Open Source Initiative, 2015). If the li-

cense is listed on their website, we treat the project as

open source. All other licenses are considered Closed

Source.

Change Propagation can be supported and ad-

dresses transferring changes from one notation into

another. The modiﬁcation in the modeling environ-

ment for a textual notation can therefore result in

an according change in a graphical notation of the

same content. This targets a consistent view of the

content and allows different team members to work

with different notations during discussion. This can

mean updates in real-time for close collaboration or

based on exporting and importing models in differ-

ent environments. We consider the three cases: Tex-

tual to Graphical, Graphical to Textual, and Via Im-

MODELSWARD 2016 - 4th International Conference on Model-Driven Engineering and Software Development

port/Export propagation. Textual to Graphical and

Graphical to Textual apply if the modeling environ-

ment includes a textual and a graphical editor. We

consider it supported if changes in one editor are re-

ﬂected in the other one. Via Import/Export applies if

there is an import or export functionality and nota-

tions can be updated sequentially. It is marked if it

provides import and export function for UML models

in the standardized XMI data format.

Data Format Exchange is optional and allows in-

tegrating the modeling results into other tools or ex-

isting tool chains. We only consider fully-automated

exchange procedures provided by the implementation

itself. We do not consider other procedures such as

the error-prone manual translation between notations

or tools that is usually done by assistants. A mod-

eling environment can support the Import or Export

of a different set of data formats. This feature can

have the value UML XMI as standardized UML data

exchange and can list Custom formats supported by

the tools. The values are selected based on the doc-

umentation or ﬁle extensions provided in the editing

environment.

3.3 Editor

Editor categorizes properties related to user input, in-

teraction, and presentation. They can be Textual (O2),

Graphical (O2) or both. An editor is considered tex-

tual if it contains only text and no graphical elements.

Text coloring may be used. This ensures that textual

editors are accessible by accessibility techniques such

as screen readers. Otherwise, it is treated as Graphi-

cal.

Textual editors address several features to increase

user experience and accessibility. A textual editor can

support Visualization (O2), Refactoring (O2) of the

model, and user Navigation (O2) within the model.

Previous surveys did not focus on the editing expe-

rience in detail. Therefore, we selected the features

according to our objectives.

A Visualization is optional and allows focused

presentation of content by means of information hid-

ing. It can support Folding (O2), and Syntax High-

lighting (O2).

Folding (un)hides selected partitions of the model,

eases comprehension for complex models and fo-

cused presentation. It is selected if there is at least

one partition in a model that can be hidden or shown

based on the editor’s UI.

Syntax Highlighting highlights keywords or im-

portant structural parts of the model. It eases compre-

hension and identifying the structure of models. It is

selected if colors or text formatting is used in the edi-

tor to highlight at least one keyword of the language.

Refactoring is optional and addresses batch

changes to the model. For instance, all occurrences

of a model element can be replaced with another one

in one single step instead of using a manual search

and replace approach. This feature exists if there is at

least one supported refactoring.

Navigation is optional and addresses the naviga-

tion to model elements and providing an overview to

users. There can be support for Code Completion

(O2), overviews on model element by Outline (O2),

and direct model element navigation by Goto (O2).

Navigation is selected if there is at least one of its

child features selected.

Code Completion is optional and provides com-

pletion of a language’s syntax or referenced model

elements. It can provide hints on keywords of the

Syntax or model Elements allowed at the current po-

sition. It aids users in specifying correct models and

speeds up changes. We consider two types of values:

Syntax-based and Element-based completion. They

are selected if there is at least one corresponding code

completion feature in the editor.

Outline is optional and provides an overview of

the elements in a model. This can include their hi-

erarchical structure. It is selected if there is at least

a list of all top-level elements in a model depicted in

the editor.

Goto is optional and allows direct navigation or

jumps to speciﬁc model elements. This eases com-

prehension and look-up of elements. It is selected if

there is a navigation or jump support for a least one

type of element in the editor. It is included if it is di-

rectly in the textual notation and excluded if its only

in the Outline.

Graphical editors are optional and allow display-

ing and editing graphical version of the models. There

are many advanced graphical UML editors available

based on the formal UML speciﬁcation. (Kern, 2014)

gives a good overview in his survey of interoperabil-

ity of UML tools. (Wikipedia, 2015) illustrates the

features of various UML tools. There are many com-

parisons between few selected tools such as IBM Ra-

tional Software Architect, MagicDraw, and Papyrus

in (Safdar et al., 2015) or between Rational Rose,

ArgoUML, MagicDraw, and Enterprise Architect in

(Khaled, 2009). This survey focuses on the synchro-

nization aspect with textual languages and their edi-

tors (O3). Our categories show if the editor is mainly

a pure static presentation of the model or allows inter-

actions. We distinguish for Graphical editors if their

content is Editable (O2) and Persistable (O2). This

feature is selected if there is a graphical presentation

of the model in the modeling environment.

Survey on Textual Notations for the Uniﬁed Modeling Language

Editable is optional and denotes if the graphical

content can be modiﬁed, e.g. a user can rename el-

ements. This feature is selected if at least some ele-

ments in the graphical editor can be modiﬁed.

Layoutable is optional and denotes if modiﬁca-

tions to the graphical layout, e.g. the position of

model elements, can be done. Users can structure the

graphical representation in this way. This feature is

selected if elements can be moved.

4 ANALYSIS RESULTS

This chapter presents the analysis results for all no-

tations. Table 2 provides an overview and shows the

determined characteristics for all notations. The fol-

lowing paragraphs provide a short description of the

notations. They point out features or provide com-

ments, which are not already covered by the overview.

Alf (OMG, 2013) has been speciﬁed by the OMG

and is the action language for UML. It is based on

Foundational UML (fUML). There is no ofﬁcial edi-

tor implementation.

Alloy (Jackson, 2002) is a model ﬁnder and solver

based on the Z notation (ISO/IEC 13568:2002, 2002)

instead of UML. The author compares it to UML in

sections 4.1 and 6.4 and states that ”Alloy is similar

to OCL, the Object Constraint Language (OCL) of

UML”

. It provides a graphical and textual notation

but does not support any UML diagrams. It is licensed

under the MIT license and does not provide access to

source code.

AUML (Winikoff, 2005) is an extension to UML

SEQ diagrams. Winikoff deﬁned a textual notation

for AUML that has been included in the Prometheus

Design Tool

. It provides a PNG export but does not

provide a mechanism to import or export a model.

Clafer (Zayan, 2012) is a modeling language for

CLS diagrams and constraints. It can be used for fea-

ture modeling. The online tool

provides no graphical

view but offers a GraphViz export.

DCharts (Feng, 2004) speciﬁes a meta-model in

AToM

3 5

and a graphical and textual notation. The

textual notation is the leading one and the graphical

implemented only partially (Feng, 2004, p. 35). No

tool or ﬁles could be found actually implementing the

theoretical concept. We could not ﬁnd an advanced

textual editor with collaboration features for the self-

deﬁned language. The publication claims that there is

http://alloy.mit.edu/alloy/faq.html

https://sites.google.com/site/rmitagents/software/prometh

eusPDT

http://t3-necsis.cs.uwaterloo.ca:8094

http://atom3.cs.mcgill.ca/

a transformation from the meta-model to UML state

charts.

Earl Grey (Mazanec and Macek, 2012) is a proof

of concept for an accessible textual notation. The

Eclipse implementation creates a model during edit-

ing but there is no export to other notations.

HUTN (Vieritz et al., 2014) is an OMG standard

for text-based representation of MOF-based meta-

models, which covers the UML meta-model. Humans

can use it easier than XMI. There is no ofﬁcial refer-

ence implementation of an HUTN-based UML editor.

IOM/T (Doi et al., 2004) allows specifying pro-

tocols for agent communication. It covers AUML

(Winikoff, 2005) sequence diagrams partially, which

we consider as SEQ support. The notation seems to

consist of two papers, the latest in 2007.

MetaUML (Gheorghies, 2015) is a DSL leverag-

ing TeX in the background. It creates graphics in

UML style but no UML models.

modsl

is a text to diagram sketch tool based on

Java code speciﬁcations. The proposed default editing

environment is Eclipse. It creates graphics in UML

style but no UML models.

pgf-umlcd

and pgf-umlsd

are both based on

PGF/TikZ. They leverage T

X interpreters. This has

a major inﬂuence on its syntax and structure. They

create graphics in UML style but no UML models.

PlantUML (Roques, 2015) is a textual notation

to diagram tool. CLS diagrams can be exported as

UML ﬁles for the StarUML and ArgoUML tools. Im-

ports and synchronization mechanisms are not avail-

able. There are various standalone and integrated ed-

itor implementations.

Quick Sequence Diagram Editor

is a text to dia-

gram sketch tool written in Java. It creates graphics

in UML style but no UML models.

TCD (Washizaki et al., 2010) is an ASCII-art con-

verter for CLS diagrams. It provides a conversion

from and to the UML XMI representation. The im-

plementation is not available.

TextUML (Chaves, 2015) exports standard UML

models but does not provide a graphical view. Ser-

vices such as Cloudﬁer

use it as alternative for

graphical modeling tools.

tUML (Jouault and Delatour, 2014) focusses on

modeling for validation and veriﬁcation purposes.

The mentioned prototype is not available.

txtUML (D

evai et al., 2014) uses regular Java syn-

tax for modeling. Java Annotations provide additional

https://code.google.com/p/modsl/

https://github.com/xuyuan/pgf-umlcd

https://code.google.com/p/pgf-umlsd

http://sdedit.sourceforge.net/

http://doc.cloudﬁer.com/creating/language/

MODELSWARD 2016 - 4th International Conference on Model-Driven Engineering and Software Development

information. There is no dedicated textual or graphi-

cal editor but a Papyrus model can be exported.

UML/P (Gr

onniger et al., 2014) is a textual no-

tation claiming to merge programming and modeling

by enriching UML models with Java expressions. The

Eclipse plugin provides textual and graphical editors

but no import or export.

UMLet

(Auer et al., 2003) is a graphical UML

sketch tool. It provides graphical UML shapes. A se-

lected shape is shown in a textual view, which allows

to modify the element. The textual view covers only

the selected element. It create graphics in UML style

but no UML models.

UMLGraph (Spinellis, 2003) uses Java source

ﬁles and customized JavaDoc comments to create di-

agrams. It creates graphics in UML style but no UML

models.

uml-sequence-diagram-dsl-txl

is a command-

line based text to diagram sketch tool written in the

transformation language TXL. The Eclipse IDE plug-

in was not available. The table lists the mentioned

features of the guide

. It creates graphics in UML

style but no UML models.

Umple (Lethbridge, 2014) is a model-to-code gen-

erator with textual notations. UML elements not rel-

evant for code generation such as aggregations are

omitted. The online tool synchronizes the textual and

graphical notation.

USE (Zayan, 2012) aims for specifying systems

with including OCL constraints. The ofﬁcial tool does

not provide an editor but textual and graphical views.

AWMo (Del Nero Grillo and de Mattos Fortes,

2014)

is a Web application targeting the collabora-

tion of blind and sighted users. The Web tool does not

work, there is no included documentation. The char-

acteristics have been determined based on the source

code and available presentations and the paper. They

deﬁne their own simplistic meta-model inspired by

CLS diagrams for their proof of concept. Collabora-

tion is realized via store and load mechanism, which

maps to Import and Export in the table.

blockdiag

has the subprojects seqdiag

and act-

diag

. Both are written in Python and convert tex-

tual diagram descriptions to graphics. The syntax is

Graphviz’s DOT format. The code and release activi-

ties are taken from seqdiag only being representative.

It creates graphics in UML style but no UML models.

www.umlet.com

http://www.macroexpand.org/doku.php

http://www.txl.ca/eclipse/TXLPluginGuide.pdf

http://garapa.intermidia.icmc.usp.br:3000/awmo/

http://blockdiag.com/en/

https://bitbucket.org/blockdiag/seqdiag

http://blockdiag.com/en/actdiag/index.html

Finite State Machine Diagram Editor and Source

Code Generator

has an own XML Schema Deﬁni-

tion, which deﬁnes their textual language called Fs-

mML. Conforming XML documents can be Imported

and Exported. Links to model elements are realized

via String matching.

js-sequence-diagrams

is a text to diagram sketch

tool written in Java Script. It is inspired by the com-

mercial WebSequenceDiagram. It parses plain text

and can report basic parsing errors. Its shared with an

own license title as simpliﬁed BSD. It creates graph-

ics in UML style but no UML models.

nomnoml

is a text to diagram sketch tool written

in Java Script. The syntax is oriented at the graphical

UML shapes. It creates graphics in UML style but no

UML models.

WebSequenceDiagrams

is a text to diagram

sketch tool written in Java Script. It creates graphics

in UML style but no UML models. A free alternative

is js-sequence-diagrams.

yUML (Harris, 2015) is a text to diagram sketch

tool. It creates graphics in UML style but no UML

models.

5 DISCUSSION

This section discusses the presented results of the sur-

vey. Section 5.1 discusses observations based on the

results. Section 5.2 discusses threats to validity.

5.1 Findings

The analyzed notations can be divided into two

groups: 14 notations focuses on generating diagrams

for documentation purposes but do not consider UML

modeling. These notations mainly regard the text

to graph change propagation and focus on graphical

export. 17 notations focus on modeling or further

analysis. The relative share of web tools in the ﬁrst

group (5) is twice as much as in the second group (3).

Most scientiﬁcally published notations mentioned in

(Luque et al., 2014a) are in the ﬁrst group as well.

Only 23% of the remaining notations of (Luque et al.,

2014a) that are also present in our survey do not focus

on graphics generation. This shows that the delivery

method of the editor has no signiﬁcant effect on the

editing experience and applicability.

Notations that focus on sketching graphics of-

ten disregard formal UML rules and having a UML

http://www.stateforge.com/

https://bramp.github.io/js-sequence-diagrams/

https://github.com/skanaar/nomnoml

https://www.websequencediagrams.com/

Survey on Textual Notations for the Uniﬁed Modeling Language

Table 2: Characteristics of analyzed textual UML notations. Characteristics are: not extractable (-), given (X), or not given

(×). Layout information is: mixed (m) or separated (s). The License is: open (O) or closed (C) source.

Language (mandatory) Implementation

Recent Activity Format Exchange Editor

Textual Graph.

Visuali-

zation

Navigation

Notation

UML Support (mandatory)

Sketch Support

Layout Information

Similar to UML Graphics

Release

Ticket

Commit

License

Change Propagation

Export

Import

Syntax Highlighting

Folding

Refactoring

Code Completion (Syntax)

Code Completion (Element)

Outline

Goto

Editable

Layoutable

Alf CLS,ACT,PKG X × × - - - - - - - - - - - - - - - -

Alloy × × × × 22.02.15 × × O × DOT, XML ALS X × × × × × × × X

AUML SEQ × × × 05.09.14 20.11.14 - - T2G PNG × X × × × × × × - -

AWMo CLS × × × × × 05.11.13 C T2G,

G2T

× × - - - - - - - - -

blockdiag:

seq-,actdiag

SEQ,ACT X m X 01.01.15 10.09.14 22.08.15 O T2G PNG,SVG,PDF × - - - - - - - - -

Clafer CLS,OBJ × × × 28.07.15 11.03.15 28.07.15 O × own,DOT,Z3Py,

ALF,ChocoJS

× X × × × × × × - -

Dcharts STM X × × - - - - - - - - - - - - - - - -

Earl Grey CLS,SEQ,STM × × × 25.05.12 09.04.12 23.05.12 O × × × X X X X X X X - -

Finite State

Machine DE

STM X × × 02.04.15 - - O T2G,

G2T

own own X × × × × × × X ×

HUTN all X × × - - - - - - - - - - - - - - - -

IOM/T SEQ × × × - - - - - - - - - - - - - - - -

js-sequence-

diagrams

SEQ X m X 17.05.15 14.08.15 27.07.15 O T2G SVG × - - - - - - - - -

MetaUML CLS,STM,ACT,

UC,CMP,PKG

X m × 23.06.15 23.08.15 07.08.15 O T2G × × - - - - - - - - -

modsl CLS,COM X × × 11.08.09 09.11.09 11.08.09 O T2G PNG, JPG × X X X X × X X - -

Nomnoml CLS,OBJ,STM,

UC,PKG

X m X × 14.08.15 03.08.15 C T2G PNG × - - - - - - - - -

pgf-umlcd CLS X m × 28.04.14 22.08.15 31.05.15 O T2G × × X × × × × × × - -

pgf-umlsd SEQ X m × 24.02.14 09.02.15 24.02.14 O T2G × × X × × × × × × - -

PlantUML CLS,OBJ,SEQ,

STM,ACT,UC,

CMP,DEP

X m X 05.08.15 23.10.14 05.08.15 O T2G UML,SVG,EPS,

TXT,HTML

× - - - - - - - - -

Quick Se-

quence

Diag. Edit.

SEQ X × × 11.02.13 22.01.15 01.02.15 O × PDF,JPEG,SVG,

SWF,EMF,GIF,

JPEG,(E)PS

× - - - - - - - - -

TCD CLS X × X - - - - IE UML UML - - - - - - - - -

TextUML CLS, STM × × × 20.08.15 02.08.15 20.08.15 O × UML × X × × X × X × - -

tUML CLS, STM, COS × × × - - - - T2G,

UML UML X X × × × X X × ×

txtUML CLS, STM, ACT × × × 14.07.15 - - - T2G UML × X X × × × X X - -

UML/P CLS, OBJ, SEQ,

STM, ACT

X s X - - - C T2G × × X X × X × X X X ×

UMLet CLS, OBJ, UC,

PKG

X m × 19.03.15 13.08.15 12.08.15 O × BMP,EPS,GIF,

JPG,PDF,PNG

UXF X × × × × × × X X

UMLGraph CLS, SEQ X m × 28.10.14 29.10.14 29.10.14 O T2G PNG,ﬁg,PS,GIF

EMF,SVG,JPEG

× - - - - - - - - -

uml-se-

quence-dia-

gram-dsl-txl

SEQ X m X 29.08.09 × × × T2G XML, Code × X X × X × X X - -

Umple CLS, STM, COS X s X 24.02.15 07.02.15 20.08.15 O T2G,

G2T

UML,ALS,USE,

EMF,UXF,Code,

TUML,yUML

× X × × × × × × X X

USE CLS × s × 04.08.15 19.09.14 - O T2G PDF × X × × × × × × X ×

WebSequence-

Diagrams

SEQ X m X - - - × T2G × × - - - - - - - - -

yUML CLS, ACT, UC X × X - - - - T2G PNG,PDF,SVG,

JPEG,JSON

× - - - - - - - - -

MODELSWARD 2016 - 4th International Conference on Model-Driven Engineering and Software Development

model. This leads to some drawbacks: First, the

results of the textual modeling cannot be processed

in tool chains. This is true for all notations that

do not provide export formats other than graphics.

Second, interpreting the generated graphic might be

hard because determining the semantics of the ele-

ments requires spatial thinking. Non-UML graph-

ics such as the conditional node in the PlantUML

activity diagram

make this even harder. Third,

the (semantic) relation of graphic elements is inac-

cessible for machines and visually impaired people.

These drawbacks limit consistency and collaborative

editing. We only identiﬁed ﬁve notations providing

UML-compaptible model export.

19 notations cover less than three UML diagram

types. The most supported diagram type is the CLS

diagram (20) followed by the SEQ (13) and STM di-

agram (12). TIM, PRO, and INT diagrams are only

supported by the HUTN. 15 do not provide editing en-

vironments at all. Based on our results, notations are

specialized and there is no notation that supports col-

laborative editing in textual and graphical notations

of more than ﬁve UML diagrams. MetaUML (6) and

PlantUML (8) come with the highest UML diagram

type coverage and provide an implementation but no

state-of-the-art editing environment. We could not

identify a one-ﬁts-all notation in our survey.

Almost half of the reviewed notations (14) have

recent activity in the year 2015. Therefore, we ex-

pect improvements in the syntax and implementation

of the notations in the near future.

5.2 Threats to Validity

We address four common threats to internal validity:

incomplete selection, inconsistent measurements, bi-

ased experimenter, and incomplete information.

We addressed incomplete selection with two addi-

tional phases that check the completeness of search

results. During the survey, we found a total of 31

textual UML notations. We found half of them in

the SLR phase. In the Quality Assurance phase, we

found four new papers and three new notations. The

ﬁrst phase did not reveal three of these papers (Jack-

son, 2002; He, 2006; Doi et al., 2004) because their

main contribution was not about a textual UML no-

tation. Therefore, they did not clearly indicate that

they also cover a textual UML notation in their title

or abstract. The remaining paper (D

evai et al., 2014)

is not indexed by the search engines that we used. The

major new result of the completion phase was the tex-

tual UML tool list (Cabot, 2015) provided by Jordi

http://plantuml.com/activity2.html

Cabot, a professor with research interests in model-

driven software engineering at the ICREA research

institute. We found eleven new notations compared

to the previous phase. We did not ﬁnd ten of them

in earlier phases because those phases are focused on

scientiﬁc notations and the found notations have not

been scientiﬁcally published. The remaining notation

(Del Nero Grillo and de Mattos Fortes, 2014) is not

indexed by the search engines we used. Therefore,

we consider the keywords of the SLR phase and the

whole notation ﬁnding process to be successful and

appropriate.

The Complement phase did not include an exten-

sive search strategy because we focus on scientiﬁ-

cally published notations in this survey. We com-

plement the intensive search strategies of the previ-

ous phases with the most common notations used in

industry. To achieve this, we imitate the common

search strategy that covers the very ﬁrst results only

because they are the most popular ones. We included

all notations of previous surveys in the analysis. In to-

tal, we found 14 new notations compared to previous

surveys: Alf, Alloy, AUML, Clafer, Dcharts, HUTN,

IOM/T, Nomnoml, pgf-umlcd, pgf-umlsd, tUML, tx-

tUML, UML/P, and uml-sequence-diagram-dsl-txl.

We addressed inconsistent measurements and bi-

ased experimenter with a rigorous review protocol

and instructions for the characteristics extraction. The

characteristics for the notations can be determined

in an objective way. Mazanec et al. (Mazanec and

Macek, 2012), however, used subjective characteris-

tics such as readability or simplicity and did not men-

tion how they have been determined.

We addressed incomplete information by using

multiple information sources. We characterized all

31 notations by extracting information from the pa-

pers, and mining websites and source code (if possi-

ble). The former is the standard approach during a

SLR but the two latter allow ﬁlling the gaps left by

the scientiﬁc papers. Especially, the project’s activ-

ity and editor features are most commonly not cov-

ered by publications. Only Alf, Dcharts, HUTN, and

IOM/T did not provide sufﬁcient information to de-

termine these characteristics.

The external validity requires generalizable re-

sults. The survey results are applicable for scenarios

that cover collaborative UML editing with textual no-

tations in general because the characteristics do not

focus on a speciﬁc scenario. This is a beneﬁt over the

previous surveys (Luque et al., 2014a; Luque et al.,

2014a) that focused on teaching UML to visually im-

paired people from industry applying UC and CLS

diagrams. The fuzzy characteristics in (Mazanec and

Macek, 2012) lead to a limited generalization and ap-

Survey on Textual Notations for the Uniﬁed Modeling Language

plicability.

6 CONCLUSIONS

UML is most commonly used for modeling tasks in

various domains. It provides a graphical but no tex-

tual notation. The results show that the lack of a stan-

dard leads to many different and incompatible textual

notations tailored for speciﬁc purposes. They largely

differ in syntax, coverage, editing experience and ap-

plicability in teams. This diversity requires high effort

to evaluate and select a notation for a speciﬁc purpose

and environment.

The contribution of this survey is the identiﬁca-

tion and classiﬁcation of textual UML modeling no-

tations. Teams that plan to incorporate a textual mod-

eling notation can save effort by using our survey be-

cause a) we provide a comprehensive list of available

notations, b) we classiﬁed the notations with respect

to characteristics that are important for their practical

use in teams, and c) are usage scenario independent.

The applied review method ensures reproducible

and reliable results, which is crucial for using our sur-

vey as a foundation for the approach selection. The

review method covered a traditional SLR and two ad-

ditional phases for ensuring the quality and complete-

ness of the review. The SLR phase consisted of a

keyword-based search in search engines relevant for

the software engineering domain. The quality assur-

ance phase applied one iteration of the snowballing

approach as cross-check for the quality of our SLR

phase. The complement phase completed the list of

notations used in practice but without academic back-

ground. The two latter phases identiﬁed about the

same amount of notations as the SLR showing the

strength of our SLR method.

The classiﬁcation is tailored to include the user’s

point of view and support the notation selection in

teams. We presented each of the twenty categories

in detail including objectively checkable conditions

that cover the level of UML support, the editing expe-

rience, and the applicability in an engineering team.

The categories are also a reference for future surveys

in the area.

About half of the identiﬁed notations focus on the

generation of graphics for documentation purposes

based on notations on the code level. Many nota-

tions focus on discussions using purely graphic no-

tations. They provide UML shapes and allow their

arbitrary placement on a canvas. This prevents auto-

mated processing such as checking model validity or

compliance to existing code. This prevents the usage

in many context and can be taken into account during

selection.

The restriction to graphical exports prohibits col-

laborative editing of graphical as well as textual rep-

resentations in engineering teams although both have

their advantages. The majority of notations only

cover less than three UML diagram types. Most of

them do not provide a state-of-the-art editor. This

shows that users have to select notations based on

their own usage scenario and decide on the supported

UML diagram types and the required editor support.

Practitioners can leverage our survey to prioritize

their analysis of notations.

We could not identify a single comprehensive tex-

tual UML notation that comes with a state-of-the-art

editing environment and standard import/export for-

mats. This incompatibility suggests future work for

researchers and practitioners as well: Researchers can

analyze the gap in UML coverage or if there is a best

of breed notation available for all diagrams. Practi-

tioners can compare the available notations more eas-

ily and see which features can help users.

From our perspective, there is a need for notations

that target proper UML modeling and have the abil-

ity to import and export standard UML models. This

allows engineering teams to include the notation in

existing tool chains and enables collaboration.

ACKNOWLEDGEMENTS

This work is funded by the German Federal Min-

istry of Labour and Social Affairs under grant

01KM141108.

REFERENCES

Auer, M., Tschurtschenthaler, T., and Bifﬂ, S. (2003). A

ﬂyweight uml modelling tool for software develop-

ment in heterogeneous environments. In Proceedings

of EUROMICRO’03, pages 267–272. IEEE Computer

Society.

Cabot, J. (2015). Modeling languages – Uml Tools. https://

modeling-languages.com/uml-tools. accessed 04.Au-

gust 2015

Chaves, R. (2015). Textuml toolkit. http://abstratt.github

.io/textuml/readme.html. accessed 14. August 2015

Del Nero Grillo, F. and de Mattos Fortes, R. (2014). Tests

with blind programmers using awmo: An accessible

web modeling tool. In UAHCI’14, pages 104–113.

evai, G., Kov

acs, G. F., and An,

A. (2014). Textual, exe-

cutable, translatable UML. In Proceedings of the 14th

International Workshop on OCL and Textual Mod-

elling, pages 3–12.

MODELSWARD 2016 - 4th International Conference on Model-Driven Engineering and Software Development

Doi, T., Yoshioka, N., Tahara, Y., and Honiden, S. (2004).

Bridging the gap between AUML and implementation

using IOM/T. In Proceedings of ProMAS’04, pages

147–162.

Erb, S. (2011). Textual modeling of service effect speci-

ﬁcations. http://stephanerb.eu/ﬁles/erb2011a Textual

Modeling of Service Effect Speciﬁcations.pdf. Ac-

cessed 04. August 2015.

Feng, H. (2004). DCharts, a formalism for modeling and

simulation based design of reactive software systems.

Master’s thesis, School of Computer Science, McGill

University, Montreal, Canada.

Gheorghies, O. (2015). Metauml - github. https://github

.com/ogheorghies/MetaUML. accessed 14. August

2015.

onniger, H., Krahn, H., Rumpe, B., Schindler, M., and

olkel, S. (2014). Text-based modeling. CoRR,

abs/1409.6623.

Harris, T. (2015). Create uml diagrams online in seconds,

no special tools needed. http://yuml.me. accessed 14.

August 2015.

He, Y. (2006). Comparison of the modeling languages alloy

and UML. In Proceedings of SERP’06,pages 671–677

ISO/IEC 13568:2002 (2002). Information technology – z

formal speciﬁcation notation – syntax, type system

and semantics. Standard, International Organization

for Standardization.

Jackson, D. (2002). Alloy: a lightweight object mod-

elling notation. ACM Trans. Softw. Eng. Methodol.,

11(2):256–290.

Jouault, F. and Delatour, J. (2014). Towards ﬁxing sketchy

UML models by leveraging textual notations: Appli-

cation to real-time embedded systems. In Proceedings

of the 14th International Workshop on OCL and Tex-

tual Modelling, pages 73–82.

Kern, H. (2014). Study of interoperability between meta-

modeling tools. In Computer Science and Informa-

tion Systems (FedCSIS), 2014 Federated Conference

on, pages 1629–1637.

Khaled, L. (2009). A comparison between uml tools. In

ICECS’09, pages 111–114.

Kitchenham, B. and Charters, S. (2007). Guidelines for

performing systematic literature reviews in software

engineering (version 2.3). EBSE technical report,

EBSE-2007-01, Keele University.

Lethbridge, T. (2014). Umple: An open-source tool for

easy-to-use modeling, analysis, and code generation.

In Proceedings of the Demonstrations Track of MoD-

ELS’14.

Luque, L., Brand

ao, L. O., Tori, R., and Brand

ao, A. A. F.

(2014a). Are you seeing this? what is available

and how can we include blind students in virtual uml

learning activities. In Proceedings of SBIE’14.

Luque, L., Veriscimo, E., Pereira, G., and Filgueiras, L.

(2014b). Can we work together? on the inclusion

of blind people in uml model-based tasks. In Inclu-

sive Designing, pages 223–233. Springer International

Publishing.

Mazanec, M. and Macek, O. (2012). On general-purpose

textual modeling languages. In Proceedings of

Dateso’12, pages 1–12.

OMG (2013). Action language for foundational uml (alf).

http://www.omg.org/spec/ALF/1.0.1/PDF.

OMG (2015a). Uniﬁed Modeling Language (UML) – Ver-

sion 2.5. http://www.omg.org/spec/UML/2.5/PDF.

OMG (2015b). XML Metadata Interchange (XMI) – Ver-

sion 2.5.1. http://www.omg.org/spec/XMI/2.5.1/PDF.

Open Source Initiative (2015). Licenses by name.

http://opensource.org/licenses/alphabetical. accessed

04. August 2015.

Roques, A. (2015). Plantuml: Open-source tool that uses

simple textual descriptions to draw uml diagrams.

http://plantuml.com/. accessed 14. August 2015.

Safdar, S. A., Iqbal, M. Z., and Khan, M. U. (2015). Em-

pirical evaluation of uml modeling toolsa controlled

experiment. In Modelling Foundations and Applica-

tions, volume 9153 of Lecture Notes in Computer Sci-

ence, pages 33–44. Springer International Publishing.

Spinellis, D. (2003). On the declarative speciﬁcation of

models. IEEE Software, 20(2):94–96.

Vieritz, H., Schilberg, D., and Jeschke, S. (2014). Access

to uml diagrams with the hutn. In Automation, Com-

munication and Cybernetics in Science and Engineer-

ing 2013/2014, pages 751–755. Springer International

Publishing.

Washizaki, H., Akimoto, M., Hasebe, A., Kubo, A., and

Fukazawa, Y. (2010). Tcd: A text-based uml class di-

agram notation and its model converters. In Advances

in Software Engineering, volume 117 of Communi-

cations in Computer and Information Science, pages

296–302. Springer Berlin Heidelberg.

Wikipedia (2015). List of uniﬁed modeling language tools.

https://en.wikipedia.org/wiki/List of Uniﬁed Modeli

ng Language tools. accessed 04. August 2015.

Winikoff, M. (2005). Towards making agent UML practi-

cal: A textual notation and a tool. In 2005 NASA /

DoD Conference on Evolvable Hardware (EH 2005),

pages 401–412.

Wohlin, C. (2014). Guidelines for snowballing in system-

atic literature studies and a replication in software en-

gineering. In Proceedings of EASE’14, pages 38:1–

38:10. ACM.

Zayan, D. O. (2012). Model Evolution: Comparative study

between clafer and Textual Uml. http://gsd.uwaterloo

.ca/sites/default/ﬁles/Model%20Evolution;%20Clafer

%20versus%20Textual%20UML.pdf. Project Report.

Survey on Textual Notations for the Uniﬁed Modeling Language
