Injecting CSP for Fun and Security

Christoph Kerschbaumer

, Sid Stamm

and Stefan Brunthaler

Mozilla Corporation, Mountain View, U.S.A.

Rose-Hulman Institute of Technology, Terre Haute, U.S.A.

SBA Research, Vienna, Austria

Keywords:

Web Browser Security, Content-Security-Policy (CSP), Cross Site Scripting (XSS).

Abstract:

Content Security Policy (CSP) defends against Cross Site Scripting (XSS) by restricting execution of

JavaScript to a set of trusted sources listed in the CSP header. A high percentage (90%) of sites among

the Alexa top 1,000 that deploy CSP use the keyword Unsafe-inline, which permits all inline scripts to run—

including attacker–injected scripts—making CSP ineffective against XSS attacks. We present a system that

constructs a CSP policy for web sites by whitelisting only expected content scripts on a site. When deployed,

this auto-generated CSP policy can effectively protect a site’s visitors from XSS attacks by blocking injected

(non-whitelisted) scripts from being executed. While by no means perfect, our system can provide signiﬁ-

cantly improved resistance to XSS for sites not yet using CSP.

1 MOTIVATION

Modern web pages are complex web applications that

pull scripts from different origins into the same ex-

ecution context (Nikiforakis et al., 2012). While

powerful, this execution scheme also opens the door

for cross-site scripting (XSS) attacks and vulnerabil-

ity studies consistently rank XSS highest in the list

of attacks on web applications (OWASP, 2012; The

MITRE Corporation, 2012; Microsoft, 2012).

As of today, all major web browsers (Chrome,

Firefox, Internet Explorer, Safari) support the

Content-Security-Policy HTTP header. However, a

recent study (Weissbacher et al., 2014) shows that

fewer than one percent of Alexa top 100 sites use CSP.

Challenges in adoption (Weissbacher et al., 2014),

such as lack of framework support, are often barri-

ers to CSP deployment on many Web sites. Addi-

tionally, our own crawl of the Alexa top 1,000 sites

shows that only 20 deploy CSP; and of those, only

two avoid use of the keyword Unsafe-inline. The key-

word Unsafe-inline was originally introduced to sup-

port legacy code while transitioning sites to use CSP.

This keyword whitelists all inline scripts for a site,

but it also allows attacker–injected scripts code to ex-

ecute, making CSP ineffective against most XSS at-

tacks.

We present a system that reduces the burden on

site authors: it does not require manual effort from

site authors to craft, deploy and maintain their own

CSP. Our system shifts the work from the site authors

to the user agents, by having browsers report hashes

of served inline scripts of a web page to a trusted

third-party policy server. This policy server then ac-

cumulates those script hashes from many individual

visitors into a script proﬁle for subject web sites. The

accumulated script proﬁles are then used to automat-

ically generate a CSP header for each site tracked by

the policy server. Subsequent visitors to tracked sites

can query this policy server for its generated CSP,

and then apply it when assembling and rendering the

site content. While all users of our system will con-

tinue reporting scripts appearing on tracked sites, they

can also enjoy protection from a CSP based on what

other visitors expect to appear. This crowdsourced

approach allows inspection deep into web sites, per-

mitting our system to gather information about inline

scripts beyond the initial landing pages.

In this paper, we ﬁrst establish the threat model we

aim to defend against (Section 2) and then contribute

the following:

• We measure current CSP deployment (Section 3)

by visiting the Alexa top 1,000 sites in the world,

show that only two percent of pages deploy CSP,

and note how few of those effectively protect

against XSS attacks.

• We present design and implementation details of

Kerschbaumer, C., Stamm, S. and Brunthaler, S.

Injecting CSP for Fun and Security.

DOI: 10.5220/0005650100150025

In Proceedings of the 2nd International Conference on Information Systems Secur ity and Privacy (ICISSP 2016), pages 15-25

ISBN: 978-989-758-167-0

Table 1: Alexa top 1,000 sites that deploy CSP and are protected against XSS. (AR=Alexa rank, R=report only, IS=Inline

scripts, safe=protected against XSS).

AR Page IS default-src script-src safe

1 2 facebook.com 12 Unsafe-inline

2 12 twitter.com 4 Unsafe-inline

3 25 yandex.ru 15 Unsafe-inline

4 30 pinterest.com 9 Unsafe-inline

5 36 mail.ru 78 Unsafe-inline

6 65 cnn.com 14 Unsafe-inline

7 107 vimeo.com (R) 8 Unsafe-inline

8 126 dropbox.com 17 Unsafe-inline

9 198 github.com 0 X X

10 378 yandex.ua 17 Unsafe-inline

12 436 w3.org 1 Unsafe-inline

12 438 fbcdn.net 12 Unsafe-inline

13 440 zendesk.com 18 Unsafe-inline

14 519 steamcommunity.com 5 Unsafe-inline

15 558 ya.ru 4 Unsafe-inline

16 643 mega.co.nz 0 X X

17 695 yandex.com.tr 9 Unsafe-inline

18 787 behance.net (R) 13

19 801 yandex.kz 15 Unsafe-inline

20 995 chefkoch.de 50

a system (Section 4) based on Firefox (v39.0) that

allows any web page to be deployed with a CSP

header.

• We evaluate our approach and demonstrate the

ability of our system (Section 5) to protect up to

half of web pages against XSS attacks. Discus-

sion includes the limitations of our approach (Sec-

tion 6).

2 THREAT MODEL

Since attacker–supplied JS executes in the target

page’s context, it can perform many actions as if it

were the user; this could lead to reading a user’s pri-

vate data, stealing their authentication credentials, or

harvesting sensitive user information like keystrokes.

A greedy script may also traverse the Document Ob-

ject Model (DOM) (W3C - World Wide Web Consor-

tium, 2004) and steal any visible data on a compro-

mised web page (Russo et al., 2009). Attackers often

employ these methods of XSS to gain access to con-

ﬁdential user information, or perform actions without

the users consent or knowledge.

In this paper we focus on one goal of web site au-

thors: prevent site visitors from leaking sensitive in-

formation such as cookies or login credentials to an

attacker. Throughout this paper we assume that the

attacker’s capabilities are limited to JavaScript injec-

tion and that attackers can:

1. inject a sequence of bytes into other web pages

2. own and operate their own web sites

3. neither intercept nor control network trafﬁc

4. not exploit any privilege escalation vulnerabilities

in the browser

3 CONTENT SECURITY POLICY

Within a CSP policy, the directive script-src deﬁnes

from which URLs and contexts a document may load

scripts (Stamm et al., 2010; W3C - World Wide Web

Consortium, 2014). More critically, when the script-

src directive appears in combination with the keyword

Unsafe-inline, CSP cannot prevent XSS attacks.

script - s rc * ’ unsafe - inl i ne ’;

A policy like the one deﬁned above provides no

additional security for a web site, since it permits all

script code whether loaded from an external resource

(indicated by the wildcard *), inlined by the site, or

injected by an attacker (both permitted by Unsafe-

inline). In other words, if an attacker manages to

inject script code into a page using this policy, then

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

Start

script-src?

default-srcscript-src

allow

block

load?

Continue

yes no

yes

load script

Figure 1: CSP policy enforcement in the browser.

CSP will not stop the attack code from being executed

within that page.

When used correctly however, CSP can stop script

injection attacks even if an attacker is able to exploit

an XSS vulnerability in the web page. The script-

src directive allows developers to enumerate speciﬁc

inline scripts by specifying the scripts’ hashes as an

allowed source:

script - s rc htt ps : // e x amp l e . com ’ sha512 - XV HzN ...= ’;

A browser enforcing the above policy will per-

mit external scripts loaded from https://example.com

and will additionally allow inline scripts to execute if

the inline script’s hash matches the one sha512-hash

speciﬁed in the policy: XVHzN...=.

It is important to note that JS event handlers are

also considered inline scripts and hence also subject

to the script-src directive (W3C - World Wide Web

Consortium, 2014). For example, if a page makes use

of <a href=’javascript:foo();’>link</a> then the hash

of the scripttext, in that case the hash of foo(); would

have to match any of the hashes deﬁned within the

script-src directive so that CSP would allow the JS

event handler to execute.

In contrast to the ﬁrst policy displayed above, this

second policy does not allow all inline scripts to exe-

cute. By being more restrictive, the second policy can

prevent attempted script injections.

3.1 Browser Enforcement of CSP

A browser handling a CSP policy makes its decision

whether to allow or block any inline script by ﬁrst

consulting the script-src directive (see Figure 1). If

the script-src directive is not deﬁned within a site’s

CSP, then a browser’s CSP implementation consults

the default-src directive before making its decision

whether to allow or block the load. If neither directive

is present, CSP executes the script.

3.2 The State of CSP Deployment

In order to identify CSP headers deployed on the

Web, we implemented a web crawler that automati-

cally visits the Alexa Top 1,000 web sites using Fire-

fox (v39.0). All the data in our paper reﬂect snapshots

of frequently changing web pages, taken on January

16th and March 16th, 2015. The results of our crawl

conﬁrm our assumptions and overlap with the ﬁnd-

ings of Weissbacher et al. (Weissbacher et al., 2014).

As illustrated in Table 1, only 20 out of the

top 1,000 sites in the world use CSP. The two sites

github.com and mega.co.nz employ a ﬁne-grained, se-

cure CSP; neither of these two sites use inline scripts.

Both sites deﬁne a script-src directive, and omit the

keyword Unsafe-inline to prevent execution of inline

scripts. Such a tight and security–enhancing policy

leverages the full potential of CSP: to prevent unau-

thorized script execution.

Unfortunately, the other 18 sites with CSP do not

use its full potential. Those sites use the Unsafe-

inline keyword either in the script-src directive itself,

or they do not specify a script-src directive at all and

instead include Unsafe-inline in the fallback directive,

default-src. For example, the CSP of yandex.ru does

not specify a script-src directive. Hence, before load-

ing any of this site’s 15 inline scripts, a browser’s

CSP implementation consults the default-src direc-

tive, where for the example case of yandex.ru it ﬁnds

the keyword Unsafe-inline and allows all inlined con-

tent scripts—including injected attack scripts—to ex-

ecute.

Two sites, behance.net and chefkoch.de, use nei-

ther the script-src nor the default-src directive, which

means that CSP will not protect them against any kind

of script injection attacks. Note that behance.net de-

ploys its CSP in report-only mode, meaning browsers

will not actively block any resource loads or script

executions, but will transmit reports for any detected

CSP violations to a URI identiﬁed in the CSPs report-

uri directive.

4 DESIGN AND

IMPLEMENTATION

We implemented a prototype of our proposed client-

server architecture for equipping every web site with

a CSP using Firefox (v39.0). First, we patched Gecko

(the rendering engine in Firefox) to record hashes of

Injecting CSP for Fun and Security

CSP Databasehttps://www.example.com

...

sha512-YW...=

sha512-XV...=

sha512-SK...=

sha512-NA...=

sha512-BE...=

sha512-CK...=

...

A ∩ B ∩ C ∩ ...

Figure 2: System overview: Various users (A, B, C) visit https://www.example.com and report hashes of executed inline scripts

to a third party policy server which creates an intersection of all the reports and generates a CSP header. Future visitors to

https://www.example.com beneﬁt from the additional layer of security provided by a CSP header delivered to them from the

third party.

inline scripts found on each visited site. Our approach

allows users to record inline scripts as they browse

deeply into complex sites. The advantage of a crowd-

sourced approach like this lies in recording real-world

interactions—including for parts of the site behind

authentication—which a web crawler can not inspect.

4.1 Collecting Hashes

Figure 2 shows various users, each requesting a web

site and viewing it in their browser (illustrated as A,

B, C). Each user’s browser records a sha512-hash of

each inline script found on the page. Once a page

is fully loaded (our prototype implementation listens

to the onload() event handler), our modiﬁed browser

asynchronously reports those hashes to a trusted third

party policy server, which collects and evaluates all

reported hashes. For example, user A navigates to

https://www.example.com and encounters the follow-

ing inline script:

< sc ri pt > al e rt ( ’ He llo , wor l d . ’) ; </ s cr ip t >

In such a case user A would record the hash of that

script. Once the page is fully loaded, user A sends the

gathered hashes of all the encountered inline scripts

to a third party policy server (named CSP Database

in Figure 2).

Later, user B also browses to

https://www.example.com but views a different

subpage and hence loads a different inline script.

Eventually user C and various other users also visit

https://www.example.com. All users record encoun-

tered inline scripts and send the collected hashes of

loaded inline scripts to the third party policy server

that processes all the reported hashes and assembles

a CSP header for the entire web site.

4.2 Assembling a CSP Policy

Lets assume user A and various other users encounter

the same script and report the same hash (sha512-

YWIzO...=) to the policy server. Lets further assume

that user B and various other users report the same

hash (sha512-XVHzN...=) to the policy server. The

CSP policy our system assembles and employs for

that page resembles the following:

Co nt en t - S ecu ri ty - P oli cy : s cr ip t - sr c * ’sha512 -

YW IzO ... = ’ ’sha512 - X V Hz N ... = ’

Please note that our injected CSP always contains

the wildcard (*) within the script-src directive to allow

all external scripts to load (Stamm et al., 2010; W3C

- World Wide Web Consortium, 2014). For a detailed

explanation of how our injection algorithm works, we

defer the reader to Section 4.3.

Start

entry in

CSP-DB?

script-src * 'unsafe-inline'script-src * 'sha512-XVHzN...=' ...

yes no

Continue

Figure 3: Conservative CSP header generation.

When generating CSP headers our system needs

to be conservative: an incorrect header that replaces

Unsafe-inline in the script-src directive that contains

incorrect hashes will impact user experience. As a

result, we implement a conservative CSP header gen-

eration strategy, illustrated in Figure 3.

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

Our system only generates and deploys a CSP

header for a given site when we have collected a

sufﬁciently large number of reports. Algorithm 1

shows our implementation of reporting inline scripts

for each URL. The threshold function T () controls

how many reports we collect until we generate the

CSP header, and is empirically determined (line 5).

A scalar threshold value does not capture real-world

Internet use, since the distribution of users usually

is multimodal: there are pages with many users and

pages with few users. For example, if our system were

to uniformly use a high threshold value, pages with a

recurrent user population of less than the threshold

would never beneﬁt from our system.

We compute our threshold T as follows. First, we

collect user statistics on a per page basis to estimate

its recurrent user population. Then we determine the

sample size such that we have small conﬁdence inter-

vals. Finally, we set T to the high end of the conﬁ-

dence interval.

Our reporting procedure relies on two databases,

the CSP Database and the CSP-Candidate-Database.

The CSP Database holds hashes for URLs that have

crossed the site-speciﬁc threshold value, whereas

the CSP-Candidate-Database only holds reported

hashes. Using two separate databases means that re-

ports for sites that serve dynamic inline scripts will

never cross their site-speciﬁc threshold T , because the

Algorithm 1: Report inline script to CSP Database.

Data: source url, hash h of an inline script or

indicator of no scripts (ε), the reporting

IP-Address, and threshold function T ()

to determine large enough sample size.

1 S ← query(CSP-Database, url);

2 if h /∈ S then

3 R ← query(CSP-Candidate-Database, ur l,

h);

4 S ← ω(distinct(R, "IP") − IP-Address);

5 if T(url) < |S| + 1 then

6 delete(CSP-Candidate-Database, url,

h);

7 update(CSP-Database, url, h);

8 else

9 update(CSP-Candidate-Database, url,

h, IP-Address);

10 end

11 else

12 if h = ε then

13 update(CSP-Database, url, ε);

14 end

15 end

reported hashes constantly change. As a result, there

will be many reported entries in the CSP-Candidate-

Database with different hash values.

We count reports for each IP-address only once,

which prevents “spamming” the system with spuri-

ous reports from a single IP-address (see distinct on

line 4). Furthermore, Algorithm 1 also shows how to

weigh reported hashes to prevent tampering with our

system (function ω on line 4). For example, a serious

attacker might attempt to use a botnet to report hashes

of an injected script. In general, there are two strate-

gies to counter tampering attempts. First, ω could use

statistical techniques to measure reports. One could,

for instance, take a random sample of all incoming re-

ports and see whether the sample exceeds our thresh-

old T (). Another statistical procedure would be to

measure all reports to identify and exclude outliers.

Second, we could use third party information sources

to discard spurious reports from the CSP-Candidate-

Database. For example, both Google and Microsoft

maintain databases indicating whether certain sites

are suspicious or not. Our system could take entries

blacklisted by either initiative and sanitize candidate

records.

Algorithm 1 shows on lines 12-14 how our system

handles pages that contain no inline scripts.

Algorithm 2: Generate CSP header.

Data: source url and threshold function T ()

Result: a script-src directive for the speciﬁed

url

1 S ←

0 ;

2 R ← query(CSP-Database, url);

3 R

← query(CSP-Candidate-Database, url);

4 for r ∈ R do

5 S ← S ⊕ r;

6 end

7 if S 6=

0 ∧ |ω(R

)| < T (url) then

8 return "script-src: * "⊕ S;

9 else

10 return "script-src: * ’unsafe-inline’";

11 end

Algorithm 2 shows how we generate a CSP header

for a page. We generate a functional CSP script-

src directive for each reported hash of an inline

script when there are no pending reports in the CSP-

Candidate-Database. This conservative strategy en-

sures that we only generate a CSP header when

the system reaches a stable state, where the CSP-

Candidate-Database contains no signiﬁcant reported

hashes anymore. This stable state indicates that a

Injecting CSP for Fun and Security

page only serves static inline scripts, all of which

have been reported sufﬁciently often and successfully

passed the statistical safeguards implemented in our

weighing function ω.

Generating a CSP header using our system is also

compatible with updates to a page. Whenever a devel-

oper changes his page to serve a new inline script, our

system will trigger new reports to the CSP-Candidate-

Database. While the weighing function ω indicates

that we have seen fewer reports than the threshold

function T () requires, we will continue to generate

the old CSP header (see line 7). Once we cross

the threshold, however, there are two possible cases.

First, Algorithm 1 will add the new hash h to the CSP

Database and delete pending records from the CSP-

Candidate-Database. Second, the new script is dy-

namic and the hashes collected in the CSP-Candidate-

Database will exceed the threshold, causing Algo-

rithm 2 to render the permissive Unsafe-inline key-

word instead. The condition also means that when-

ever an author changes a page, our system requires at

least an amount of threshold function T () reports until

it can make a decision.

4.3 Injecting CSPs

Whenever a user browses to a web site using our mod-

iﬁed CSP enhancing web browser, our system per-

forms one of the following three actions which al-

lows our system to provide the most ﬁne-grained CSP

header possible for that site:

(1) Webpage Does Not Deploy CSP: In case the

web site does not deploy a CSP header, then our

modiﬁed browser simply queries the corresponding

CSP for that webpage from the CSP Database. The

browser applies the CSP as if a CSP header was re-

ceived from the web page itself.

(2) Webpage Deploys CSP with Unsafe-inline: If

the web page deploys a CSP but uses the keyword

Unsafe-inline within the script-src or the default-

src directive, then our system removes the keyword

Unsafe-inline and replaces Unsafe-inline with the

script hashes obtained from the CSP Database. Ad-

ditionally speciﬁed directives within the CSP of the

webpage, such as img-src, style-src, or connect-

src (Stamm et al., 2010; W3C - World Wide Web

Consortium, 2014) remain untouched by our injection

algorithm since such directives provide additional se-

curity for the webpage. We consider crafting a tight

CSP policy as good practice and hence our prototype

always injects the script-hashes within the script-src

directive, even if the original CSP does not contain

a script-src directive and Unsafe-inline was deﬁned

within the fallback directive: default-src.

(3) Webpage Deploys CSP without Unsafe-inline:

If a webpage deploys a CSP, and that policy does

not include Unsafe-inline within the script-src or the

default-src directive, then our system does nothing to

change the user’s interaction with the site. In this rare

case where a webpage crafts its own tight CSP policy,

our modiﬁed browser does not perform any additional

actions other than enforcing the CSP policy like any

other browser that supports CSP. As discussed in Sec-

tion 3.2, we encountered such a tight policy only on

github.com and mega.co.nz.

Intermittently Blocking Valid Content Scripts:

As discussed in Section 4.2, our system is able to

respond site changes (speciﬁcally changes to inline

scripts) very quickly since hashes for inline scripts are

reported by our system’s users at a constant pace. In

turn the CSP generated for tracked sites is regularly

updated with new information. However, there is a

short window of time while the system updates poli-

cies after site changes, and it is possible our system

may block a legitimate (non-attack) inline script. In

this case, the user has the option to manually override

the injected CSP.

5 EVALUATION

We examine the capabilities and limitations of our

system by monitoring the Alexa top 1,000 sites over

a period of two months (January 16th to March 16th,

2015) and record the number of inline scripts per site.

In this section we discuss the feasability of our

approach by inspecting the overall usage of inline

scripts on the Alexa top web sites (Section 5.1) and

discuss tradeoffs of our approach for pages using fre-

quent updates of their inline scripts over pages that

rarely update their inline scripts (Section 5.2). Finally,

we compare the spectrum of effectiveness of our ap-

proach by providing recommendations for web sites

on the lower end and highlight the practicallity of our

approach for web sites on the upper end of that spec-

trum.

A Word About Our Web Crawler: Unfortunately

distribution of our prototype to gather statistical data

for a real world study is not feasible. Hence we set up

a web crawler that visits the front page of the Alexa

Top 1,000 sites and records all inline scripts for those

sites. Even though a web crawler can not inspect the

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

0 50 100 150 200

0 20 40 60 80

Number of scripts (found on Jan. 16th, 2015)

% sites with x scripts

●

0% 20% 40% 60% 80% 100%

Sites with at most x scripts

Figure 4: Number of sites with a given number of scripts

and the CDF (Cumulative distribution function): percent of

all sites with at most a given number of scripts.

deep web hidden behind logins we argue that a web

crawler returns sufﬁcient data to evaluate inline script

usage, record the code change of inline scripts and

therefore allows us to reason about the feasibility of

our approach. Note that a toplevel CSP does not apply

to content in subelement iframes (Stamm et al., 2010;

W3C - World Wide Web Consortium, 2014). Our

crawler supresses the loading of each page’s iframes

to avoid polluting our statistics with incorrectly ac-

counted inline scripts.

5.1 Inline Script Usage

In sum, our web crawler detected 26,743 inline scripts

when visiting the top 1,000 sites on January 16th,

2015. This indicates that every site hosts on average

27 inline scripts, as illustrated in Figure 4.

Unique Scripts: Although our crawler detected

26,743 instances of inline scripts, we found only

16,519 unique scripts. We attribute this phenomenon

to web developers frequently including third-party

functionality such as analytics and/or social media

code to enrich a user’s browsing experience. Quite

commonly such small scripts are copied and pasted,

and inlined directly within a page. For example, we

found the same user agent detection script on 393 out

of the Alexa top 1,000 sites. Once copied and pasted

on a page, these inline scripts do not get updated by

the web site author. This complements our approach

and causes fewer intermittent script blockages as ex-

plained in Section 4.3.

Pages Hosting Many Inline Scripts: We found

two sites that are using more than 200 inline

scripts. The pages repubblica.it and buzzfeed.com

use 278 and 217 inline scripts, respectively. Those

two pages are statistical outliers, but we observed

415 sites that use between 20 and 199 inline scripts.

As a general recommendation for sites with more

than 20 inline scripts: we suggest refactoring such

pages to load most of the scripts from external re-

sources. We understand the performance cost of load-

ing JS from an external resource rather than inlin-

ing the script (Grigorik, 2013), but we argue that us-

ing more than 20 inline scripts will be performance–

hampering for a web page.

Pages Hosting Few Inline Scripts: In contrast to

sites using many inline scripts, we identiﬁed 583 sites

that employ fewer than 20 inline scripts. 43 of those

sites do not use any inline scripts at all. The architec-

ture of such web pages is ideal for our approach, be-

cause our system uses a CSP header of ’script-src *’

for all of those 43 pages, allowing all external scripts

to execute but preventing all inline scripts and thus

most XSS attempts.

5.2 Static vs Dynamic Scripts

In this section we examine inline scripts on web sites

during our monitoring phase and highlight the frac-

tion of inline scripts that we consider static vs. the

fraction of inline scripts we consider dynamic.

Deﬁnition of Static and Dynamic Scripts: We de-

ﬁne an inline script to be static if the script does

not change its contents across time points in our in-

vestigation. We further consider a script to be dy-

namic if the script contents gets updated iteratively

and changes across differently-timed accesses.

Figure 5 illustrates the ratio of static to dynamic

scripts on the Alexa top 1,000 sites. On January 16th,

we detected 26,743 inline scripts. On March 16th,

we detected 27,268 scripts. When doing our second

crawl we compared the hashes of the scripts of the two

runs and noticed that 10,893 scripts did not change

within those two months. In other words, each site in

the Alexa top 1,000 sites hosts on average 27 scripts,

from which we consider 11 to be static and 16 to be

dynamic, or iteratively updated.

Pages with Most Dynamic Scripts: Figure 6 (left)

shows the ten pages with the most dynamic scripts

encountered on the top 1,000 pages (changed between

the two visits by our web crawler). Our recordings

do not show any static scripts on bloomberg.com as

well as vitaminl.tv and both pages make use of 60

and 90 inline scripts respectively. Our system may

Injecting CSP for Fun and Security

0 50 100 150 200

0.0 0.2 0.4 0.6 0.8 1.0

Number of Scripts

Sites with at most x scripts

●

January

March

Static scripts

Figure 5: CDF for the number of sites with at most a given

number of scripts for January to March 2015.

intermittently block legitimate scripts that are updated

frequently on such pages. Since all of these ten web

pages make extensive use of dynamic scripts, the CSP

Database might not have generated an updated CSP

header for such a site before a subsequent user visits

the page and hence queries and outdated CSP from the

CSP Database. As discussed in Section 4.1, a user of

our modiﬁed web browser can manually override the

injected CSP and allows all inline scripts to run.

To overcome the problem of intermittently

blocked scripts, we recommend that pages hosting

more than 20 inline scripts refactor their pages and

load most (if not all) of their inline scripts from an

external resource. Loading scripts from an exter-

nal resource has the advantage that web site authors

only have to whitelist the URL where scripts are

loaded from once (using the script-src directive) in-

stead of constantly updating script hashes within the

CSP header whenever a script gets updated.

Pages with Most Static Scripts: Figure 6 (right)

shows the ten web pages relying on static inline

scripts and few dynamic inline scripts. For exam-

ple, the page chase.com uses 27 static inline scripts

and the page caixa.gov.br uses 29 static inline scripts.

Both pages use only one dynamic inline script that

changed its hash value between our two visits by

our crawler. Pages like the ten highlighted in Fig-

ure 6 (right) as well as pages that do not include any

inline scripts at all (discussed in Section 5.1) exhibit

ideal conditions where our approach of injecting a

CSP header substantially increases protection against

script injection attacks.

Customized Inline Scripts per Visitor: To evalu-

ate our approach we must also account for webpages

that dynamically generate content on the server and

serve that content in form of inline scripts to the vis-

itor. We performed yet another crawl of the Alexa

top 1,000 on March 16th, 2015, to evaluate how fre-

quently this occurs. We use the same setup as for

the ﬁrst crawl but use a different IP-address to eval-

uate server side inline script customizations on pages.

Overall, we encountered 4,194 scripts generating a

different hash for every visitor. We manually in-

spected scripts that differ and found that such scripts’

functionality is mostly identical but such scripts serve

data in addition to functionality.

For example, the page picmonkey.com serves nine

inline scripts, where eight of them are identical for

two visitors. One script is different for every visitor

because it includes the following code line: ’server-

time: new Date(123456789)’, where 123456789 is

the time speciﬁed by the server before it is shipped

to a client. Inline scripts in this fashion will differ for

every user and so every visitor reports a different hash

for such a script to the policy server. Unfortunately,

pages that serve inline scripts that not only contain

functionality but also data are not very well suited for

our approach. As explained in Section 4.2 our ap-

proach will not generate a CSP header for such pages

because reported hashes will never make its transi-

tion from the CSP-Candidate-Database into the CSP

Database.

Feasibility of CSP Header Injection: We found

that 483 pages serve the same inline scripts for dif-

ferent visitors which makes those 483 pages perfectly

suitable for our approach. Those 483 pages serve only

functionality within their scripts and such scripts’

hash value only changes if indeed an iterative update

of the code within the inline script happens—which

our system recognizes and explicitly supports. Based

on these promising results, we are conﬁdent that our

system scales beyond the Alexa top 1,000 and will

bring about an important improvement in web secu-

rity without requiring extensive manual intervention

from page authors. Given that currently only two per-

cent of pages deploy CSP, any increase enabled by

our system—ideally to the reported 50%—will be a

big win.

6 DISCUSSION

Though the research community has not explored ar-

eas of conﬁguration and software package manage-

ment with CSP, they are vitally important to deploy-

ment. A stable toolchain (compiler, linker, package

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

number of inline scripts

100

urbandictionary.com

seesaa.net

verizon.com

slickdeals.net

mynet.com

bloomberg.com

twitch.tv

vitaminl.tv

cnet.com

cheezburger.com

number of inline scripts

amazonaws.com

cnmo.com

caixa.gov.br

ask.fm

gmw.cn

pchome.net

stockstar.com

chase.com

globo.com

ci123.com

Figure 6: (left) Sites with the most dynamic scripts. (right) Sites with the most static scripts on the Alexa top 1,000.

installer) is key in creating systems that are easy to

deploy.

Today, end users miss out on the increased se-

curity guarantees provided by CSP. As discussed, in

Section 3 we ﬁnd that only two of the Alexa top 1,000

sites deploy CSP that has any XSS prevention beneﬁt.

In this paper we present a system that allows web sites

to be deployed with CSP not relying on web site au-

thors to provide, update and maintain their own CSP

policy.

Approach Limitations: Our system helps prevent

the most common type of XSS, namely non-persistent

(or reﬂected) XSS (Hope and Walther, 2008). Ex-

ploiting a reﬂected XSS vulnerability allows an at-

tacker to inject JS code, most commonly in HTTP

query parameters or in HTML form submissions,

which the web page immediately renders as regular

page content, granting the script access to user sensi-

tive information on that page. As explained in Sec-

tion 4.2, our system only whitelists and adds script

hashes to the CSP Database if hashes are reported by

various users and only once a pre-deﬁned number of

reports for a given script is reached.

Our system further relies on web sites perform-

ing standard user input sanitization(Jovanovic et al.,

2006; Balzarotti et al., 2008; Bisht and Venkatakr-

ishnan, 2008) before storing any user data within the

sites internal database. Once malicious user input by-

passes server side sanitization ﬁlters, our system can

not distinguish between legitimate content scripts and

injected scripts. Such a persistent XSS vulnerabil-

ity can not be detected or stopped by our approach

and the hash for the malicious inline script will be

whitelisted and added to the CSP Database once re-

ported by enough users.

Prototype Limitations: A full–scale deployment

of our system should use standard anonymization

techniques so as not to reveal the content and source

of reports sent to the third party policy server. For

example, a production implementation could use a

trafﬁc anonymization system such as TOR (The Tor

Project, 2012), or rely on RAPPOR (Erlingsson et al.,

2014), a technology that allows anonymous crowd-

sourcing statistics from end-user client software.

At the moment our approach focuses on XSS

prevention and to eliminate Unsafe-inline from CSP

headers and does not cover other protections offered

by CSP. Future work would cover more of the CSP

directives not aimed at preventing XSS. For example,

the auto-generated CSP could cover the img-src direc-

tive so that images can only be loaded from expected

resources. Covering more CSP directives and hence

allowing resource loads only from expected origins

could additionally increase security by not allowing

attackers to perform requests to their own servers.

7 RELATED WORK

CSP Analysis: As discussed in Section 3, our

ﬁndings align with the presented results of Weiss-

bacher et al. (Weissbacher et al., 2014). In their paper

they analyze the top one million Alexa sites’ CSP de-

ployment. Their work shows that one percent of web

pages in the Alexa top 100 deploy CSP in enforce-

ment mode and conclude that CSP will not be easily

deployed without substantial framework support.

Security Tools Relying on CSP: In 2013, Doupé et

al. (Doupé et al., 2013) present a system called deDa-

cota. Using static analysis their system automatically

separates code and data of web applications and relies

on CSP to enforce that separation in the browser.

In 2015, Schwenk et al. (Schwenk et al., 2015)

present JSAgents. Even though their approach is

not relying on CSP per se, they use their presented

Injecting CSP for Fun and Security

JSAgents to implement large portions of CSP with the

intent to ﬁne grain CSP so that every element in the

DOM relies on a JSAgent instead of having the full

document rely on one CSP. Similar to our intention,

both of these approaches aim to secure legacy web

applications.

The framework “Conﬁnement with Origin Web

Labels” (COWL (Stefan et al., 2014)) uses CSP as the

foundation and provides a labeling mechanism on top

of CSP and other security features within a browser.

Distributed Analysis: In 2011,

Greathouse et al. (Greathouse and Austin, 2011)

show that a large population, in aggregate, can ana-

lyze larger portions of a program than any single user

individually running the full analysis of a program.

In 2013, Kerschbaumer et al. (Kerschbaumer

et al., 2013) present a crowd sourced based approach

where individuals report security violations to a third

party system which allows to identify malicious web

pages and feed the results to URL blacklisting ser-

vices such as Microsoft’s smartscreen ﬁlter (Mi-

crosoft, 2012) or Google’s safebrowsing (Provos,

2012) initiative.

Third-party Security Systems: In 2011, Thomas

et al. present a system called Monarch (Thomas

et al., 2011) and Canali et al. present a system called

Prophiler (Canali et al., 2011). Both approaches aim

to detect malware on the Web relying on machine

learning techniques. Even though our system does not

try to classify malicious webpages, it ﬁts well within

this theme of letting trusted third party systems pro-

vide security features for the web.

8 CONCLUSION AND OUTLOOK

Today, web sites and their users do not beneﬁt fully

from XSS protection offered by CSP. Even though

most major browsers acknowledge the CSP header,

only 20 out of the Alexa top 1,000 sites deploy CSP,

and only two pages effectively use CSP to protect

their users against code injection attacks and XSS. It

is clear from our ﬁndings that industry requires better

framework support for easy and efﬁcient deployment

of CSP with a web page.

Our proposed system allows deployment of CSP

for web sites without requiring web site authors

to manually update and maintain their CSP header

whenever they perform any kind of update on their

page.

We discussed the limitations of our approach to

account for pages that not only ship functionality but

also data within their inline scripts. Our preliminary

results show that our approach is feasible to deploy a

CSP header for up to half of web sites on the Internet

and thus help protect them from XSS attacks.

ACKNOWLEDGEMENTS

Thanks to the everyone in the Security Engineering

Team of Mozilla for their feedback and insightful

comments.

REFERENCES

Balzarotti, D., Cova, M., Felmetsger, V., Jovanovic, N.,

Kirda, E., Kruegel, C., and Vigna, G. (2008). Saner:

Composing static and dynamic analysis to validate

sanitization in web applications. In Proceedings of

IEEE Symposium on Security and Privacy, pages 387–

401. IEEE.

Bisht, P. and Venkatakrishnan, V. (2008). Xss-guard: pre-

cise dynamic prevention of cross-site scripting at-

tacks. In Detection of Intrusions and Malware, and

Vulnerability Assessment, pages 23–43. Springer.

Canali, D., Cova, M., Vigna, G., and Kruegel, C. (2011).

Prophiler: a fast ﬁlter for the large-scale detection of

malicious web pages. In Proceedings of the interna-

tional conference on World wide web, pages 197–206.

ACM.

Doupé, A., Cui, W., Jakubowski, M. H., Peinado, M.,

Kruegel, C., and Vigna, G. (2013). dedacota: toward

preventing server-side xss via automatic code and data

separation. In CCS, pages 1205–1216. ACM.

Erlingsson, Ú., Pihur, V., and Korolova, A. (2014). RAP-

POR: Randomized aggregatable privacy-preserving

ordinal response. In Proceedings of the ACM Con-

ference on Computer and Communications Security,

pages 1054–1067. ACM.

Greathouse, J. L. and Austin, T. (2011). The potential

of sampling for dynamic analysis. In Proceedings

of the ACM SIGPLAN Workshop on Programming

Languages and Analysis for Security, pages 3:1–3:6.

ACM.

Grigorik, I. (2013). High Performance Browser Network-

ing. O’Reilly.

Hope, P. and Walther, B. (2008). Web Security Testing

Cookbook. O’Reilly.

Jovanovic, N., Kruegel, C., and Kirda, E. (2006). Pixy: A

static analysis tool for detecting web application vul-

nerabilities. In Proceedings of IEEE Symposium on

Security and Privacy, pages 6–pp. IEEE.

Kerschbaumer, C., Hennigan, E., Larsen, P., Brunthaler, S.,

and Franz, M. (2013). CrowdFlow: Efﬁcient informa-

tion ﬂow security. ISC, Springer.

Microsoft (2012). Microsoft secu-

rity intelligence report, volume 13.

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

http://www.microsoft.com/security/sir/default.aspx.

(checked: August, 2015).

Microsoft (2012). SmartScreen Filter.

http://windows.microsoft.com/en-US/internet-

explorer/products/ie-9/features/smartscreen-ﬁlter.

(checked: August, 2015).

Nikiforakis, N., Invernizzi, L., Kapravelos, A., Van Acker,

S., Joosen, W., Kruegel, C., Piessens, F., and Vigna, G.

(2012). You are what you include: Large-scale evalu-

ation of remote javascript inclusions. In Proceedings

of the ACM Conference on Computer and Communi-

cations Security. ACM.

OWASP (2012). The open web application security project.

https://www.owasp.org/. (checked: August, 2015).

Provos, N. (2012). Safe browsing - protect-

ing web users for 5 years and counting.

http://googleonlinesecurity.blogspot.com/2012/06/safe-

browsing-protecting-web-users-for.html. (checked:

August, 2015).

Russo, A., Sabelfeld, A., and Chudnov, A. (2009). Tracking

information ﬂow in dynamic tree structures. In Pro-

ceedings of the European Symposium on Research in

Computer Security, pages 86–103. Springer.

Schwenk, J., Heiderich, M., and Niemietz, M. (2015). Wait-

ing for CSP: Securing Legacy Web Applications with

JSAgents. In Proceedings of the European Sympo-

sium on Research in Computer Security, page TBA.

Springer.

Stamm, S., Sterne, B., and Markham, G. (2010). Reining in

the web with content security policy. In Proceedings

of the ACM International Conference on World Wide

Web, pages 921–930, New York, NY, USA. ACM.

Stefan, D., Yang, E. Z., Marchenko, P., Russo, A., Herman,

D., Karp, B., and Mazieres, D. (2014). Protecting

users by conﬁning javascript with cowl. In Proceed-

ings of the USENIX Symposium on Operating Systems

Design and Implementation.

The MITRE Corporation (2012). Common weakness enu-

meration: A community-developed dictionary of soft-

ware weakness types. http://cwe.mitre.org/top25/.

(checked: August, 2015).

The Tor Project (2012). Tor (anonymity network).

https://www.torproject.org/. (checked: August, 2015).

Thomas, K., Grier, C., Ma, J., Paxson, V., and Song, D.

(2011). Design and evaluation of a real-time url spam

ﬁltering service. In Proceedings of IEEE Symposium

on Security and Privacy, pages 447–462.

W3C - World Wide Web Consortium (2004). Docu-

ment object model (DOM) level 3 core speciﬁca-

tion. http://www.w3.org/TR/2004/REC-DOM-Level-

3-Core-20040407/DOM3-Core.pdf. (checked: Au-

gust, 2015).

W3C - World Wide Web Consortium (2014). Content Se-

curity Policy Level 2. http://www.w3.org/TR/CSP2/.

(checked: August, 2015).

Weissbacher, M., Lauinger, T., and Robertson, W. (2014).

Why Is CSP Failing? Trends and Challenges in CSP

Adoption. In Research in Attacks, Intrusions and De-

fenses, volume 8688, pages 212–233. Springer Inter-

national Publishing.

Injecting CSP for Fun and Security
