Anomaly-based Mobile Malware Detection: System Calls as Source for

Features

Dominik Teubert, Fred Grossmann and Ulrike Meyer

Department of Computer Science, RWTH Aachen University, Aachen, Germany

Keywords:

Mobile Malware, Machine Learning, Anomaly Detection, One-class SVMs, Hidden Markov Models.

Abstract:

Mobile malware nowadays poses a serious threat to end users of mobile devices. Machine learning techniques

have a great potential to automate the detection of mobile malware. However, prior work in this area mostly

focused on using classiﬁers that require training with data from both the benign as well as the malicious class.

As a consequence, training these models requires feature extraction from large amounts of mobile malware,

a task that becomes increasingly difﬁcult considering the obfuscation and emulator detection capabilities of

modern mobile malware. In this paper we propose the use of one-class classiﬁers. The advantage of using these

models is that they are exclusively trained with data from the benign class. In particular, we compare generative

as well as discriminative modeling approaches, namely Hidden Markov Models and one-class Support Vector

Machines. We use system calls as source for our features and compare the discriminatory power of binary

feature vectors, frequency vectors, as well as temporally ordered sequences of system calls.

1 INTRODUCTION

In recent years, the popularity of mobile devices

such as smartphones and tablets has continuously in-

creased. According to market research company IDC,

nearly 1.3 billion smartphones were shipped in 2014

(IDC, 2014). Gartner Inc. predicts that by 2018 more

than 50 percent of users will turn to their mobile de-

vices ﬁrst for all online activities (Gartner, 2014).

However, the broad range of capabilities of today’s

mobile devices, as well as their unique suitability for,

e.g., mobile payment or premium rate services, make

mobile devices an attractive target for malware au-

thors. The accumulation of large amounts of poten-

tially sensitive data on the devices also contributes to

the fact that mobile malware recently emerged from

a theoretical danger to a real threat for end users and

mobile operators.

Commercial mobile malware detection systems to

date mainly use a signature-based approach, which

requires the vendors to continuously obtain and an-

alyze new malware samples in order to generate up-

to-date signatures. This signature generation process

is time-consuming and costly—particularly in face of

the rapidly increasing number of new malware sam-

ples. Consistently, the detection rates reported in a

recent evaluation of four of these mobile malware de-

tection systems are rather low, ranging from 20.2% to

79.6% (Zhou and Jiang, 2012). Another disadvantage

of the signature-based approach in the mobile context

is that the scanning process has a negative impact on

battery lifetime and conﬂicts with user demands on

system responsiveness.

Alternative approaches to mobile malware detec-

tion (e.g., (Dini et al., 2012; Burguera et al., 2011;

Shabtai et al., 2012; Bose et al., 2008)) make use

of machine learning techniques in order to automate

malware detection based on monitoring characteris-

tic and measurable properties of a single app or the

operating system and using them as features for clas-

siﬁcation. Most of the prior approaches in this area,

however, make use of multi-class classiﬁers that try

to discriminate between malicious and benign system

behavior. That is, these approaches train a classiﬁer

with correctly annotated feature vectors from the be-

nign as well as the malicious class and thus vitally

depend on ﬁnding and analyzing malware samples for

training purposes. While various features have been

proposed in this context, a particularly promising ap-

proach (also known from host-based intrusion detec-

tion (Forrest et al., 1996; Warrender et al., 1999; Ye-

ung and Ding, 2003; Mutz et al., 2006; Maggi et al.,

2010)) is using system call traces as source of fea-

tures: Since system calls provide the interface be-

tween user-space and kernel-space, all malicious ac-

tions that may harm the system have to pass this inter-

Teubert, D., Grossmann, F. and Meyer, U.

Anomaly-based Mobile Malware Detection: System Calls as Source for Features.

DOI: 10.5220/0005652900260036

In Proceedings of the 2nd International Conference on Information Systems Security and Privacy (ICISSP 2016), pages 26-36

ISBN: 978-989-758-167-0

face. To date two approaches exist that make use of

system call features in the mobile context (Burguera

et al., 2011; Dini et al., 2012). However, these ap-

proaches focus on frequencies of system calls only

and do not consider other options to derive features

from system call traces.

In contrast to prior work, in this paper we pro-

pose the use of one-class classiﬁers, i.e., models that

exclusively rely on data from one class only (in our

case the benign class) in the training phase. Speciﬁ-

cally, we compare generative as well as discriminative

modeling approaches, namely Hidden Markov Mod-

els (HMMs) and one-class Support Vector Machines

(SVMs) as two state-of-the-art models of this type.

The obvious advantage of such models is that they al-

low model training without access to data from the

malicious class. Most importantly, however, they can

be expected to be able to also detect zero-day mal-

ware that heavily differs from known malware as they

deﬁne anomalies as deviations from benign behav-

ior rather than similarity to known malicious patterns.

We concentrate on system calls as source for fea-

tures. However, instead of considering only frequen-

cies of system calls in observed traces as in (Burguera

et al., 2011; Dini et al., 2012), we propose two addi-

tional feature types derived from system call traces,

namely binary vectors indicating the occurrence of

system calls, and (temporally ordered) sequences of

system calls. We comparatively evaluate the two

modeling methods in combination with the different

feature types on pairs of benign apps and their mali-

cious repackaged counter parts. Speciﬁcally, we train

a model with feature vectors derived from system call

traces of a benign app and then test if the model is

able to detect feature vectors derived from traces of

the app’s malicious counterpart.

The remainder of this paper is structured as fol-

lows: Section 2 reviews relevant related work. Sec-

tion 3 describes how features that are used through-

out this paper are derived from monitored system call

data. Section 4 introduces the models used. Section 5

describes our experimental setup. Section 6 presents

the results, and puts them into context.

2 RELATED WORK

The work published so far in the area of mobile mal-

ware detection aims to overcome the shortcomings of

signature-based approaches, namely the great effort

that is necessary to create signatures. Thus, most of

the related work on mobile malware detection focuses

on ﬁnding malicious patterns in an automated fashion

by means of machine learning. These approaches sig-

niﬁcantly vary in the features and models used. In the

learning phase, typically a classiﬁer is trained with

features derived from observed data. In the subse-

quent detection phase, the features are derived from

the data observed while the mobile device is under

regular usage and are tested against the trained model.

Following the two most important ways to analyze

(mobile) malware, the approaches can be classiﬁed

into those that use static analysis to gather the data

needed to derive features and those that use dynamic

analysis to monitor behavioral features at runtime.

The former line of work includes (Arp et al.,

2014),(Zhang et al., 2014), and (Aafer et al., 2013),

in which API-level features of varying complexity are

derived and used to train classiﬁers with the goal to

distinguish malicious from benign apps. Approaches

of this category are not able to cope well with mal-

ware that uses obfuscation techniques as these render

automated features extraction based on static analysis

infeasible in many cases. Approaches from the latter

category typically monitor system- or user-behavior-

based features. In an early approach, Bose et al. use a

temporal logic to deﬁne behavioral signatures of API

calls (Bose et al., 2008). To be able to also match

partial signatures at run-time, the authors use SVMs

for classiﬁcation. Xie et al. proposed pBMDS, a sys-

tem that correlates user inputs with system call traces

(Xie et al., 2010). The authors use HMMs to model

theses correlations to detect anomalies that indicate

the infection with malware. Shabtai et al. proposed

an anomaly detection framework called Andromaly,

which uses a large set of very different run-time fea-

tures (such as CPU load and number of incoming

SMS messages) and compares six different standard

classiﬁers on this data (Shabtai et al., 2012). Contract-

based approaches that try to infer policies apps have

to meet in a dynamic and collaborative manner also

fall into this category (Dini et al., 2014; Aldini et al.,

2014).

Recently, the idea using system call traces as

source for features, originally proposed in the area

of host-based intrusion detection (Forrest et al., 1996;

Warrender et al., 1999; Eskin et al., 2002; Yeung and

Ding, 2003; Mutz et al., 2006; Maggi et al., 2010),

was adapted to mobile malware detection. With

Crowdroid Burguera et al. proposed a solution that

collects system call traces of Android apps using a

user-space app, i.e., system calls are monitored on

a per-app basis (Burguera et al., 2011). The traces

are further preprocessed locally into feature vectors

representing the frequency of each monitored sys-

tem call. On a remote server, the feature vectors

are then clustered into two classes using the k-means

algorithm. The crucial step is then to label these

Anomaly-based Mobile Malware Detection: System Calls as Source for Features

two classes as benign and malicious. Burguera et

al. propose to solve this problem by applying a crowd-

sourcing approach: for each app, feature vectors are

collected by the crowd and submitted to the server.

After clustering, the larger of the two resulting classes

is labeled as benign, following the assumption that

benign apps are executed more often than their ma-

licious counter parts. This approach has two major

shortcomings: ﬁrst, it always results in two classes,

even if only benign vectors are present and second,

the approaches rely on the participation of a sufﬁcient

number of honest users in order to guarantee that the

assumption holds.

Similar to Burguera et al., Dini et al. use frequen-

cies of system calls as features. However, the sys-

tem calls are not monitored on a per-app basis, but

system-wide. Furthermore, only 11 of the most sensi-

tive system calls are taken into account. The resulting

features are complemented with two additional fea-

tures: (1) whether or not the user is idle and (2) the

count of sent SMS messages. They use the k-nearest

neighbors (KNN) classiﬁer and train it with benign

traces generated with the help of real users as well as

artiﬁcially generated malicious traces. This manual

creation and later interpolation of malicious feature

vectors is a major drawback of the system, since it

requires detailed assumptions on how malicious ac-

tions inﬂuence the system call counts. Another weak-

ness of the system is the combination of the system

call counts and the two additional features into the

same feature vector, since it is not clear to which ex-

tent the system call counts contribute to the discrim-

ination power of the system. So it is very likely that

e.g., for SMS sending malware the classiﬁer learns

over-simplistic rules of the form “malware detected

if the user is idle and SMS messages are sent”. The

heavy reliance on the idleness-indicator allows smart

malware to bypass detection very easily by becoming

active if and only if the user is active as well.

Nearly all of the aforementioned approaches use

benign as well as malicious data to train a multi-class

classiﬁer in the learning phase (with (Xie et al., 2010)

being the only exception). This diminishes the advan-

tages of implementing anomaly detection in its purest

form based on a one-class classiﬁer trained on be-

nign data only. In particular, such one-class classiﬁers

do not require the collection and processing of mal-

ware samples. In addition, they can be expected to

be able to also detect zero-day malware that heavily

differs from known malware as they deﬁne anoma-

lies as deviations from the model of benign behav-

ior rather than similarity to known malicious patterns.

We therefore propose the use of one-class classiﬁers

in this paper and compare two state-of-the-art models

of this type. While so far only the use of frequencies

of system calls as feature was studied (e.g. (Burguera

et al., 2011; Dini et al., 2012)), we compare three

different features derived from system calls. Speciﬁ-

cally, we evaluate the different combinations of one-

class classiﬁers and feature types with respect to their

power to differentiate between a benign app and a

repackaged malicious version of the same app. Note

that as most other recent work in this area we focus on

the market leading Android platform, which is most

targeted by mobile malware authors. Most Android

malware comes as repackaged malicious version of

some benign app (Zhou and Jiang, 2012).

3 FEATURE DERIVATION

While system calls as a source for features were con-

sidered in different approaches in behavior-based mo-

bile malware detection (see Section 2), the ﬁeld to

date lacks a systematic comparison of different fea-

tures derived from sequential system call data. No-

tably, prior work solely focused on the frequency fea-

ture, neglecting to investigate other system call de-

rived features of varying complexity.

In this paper we study the following three types of

increasingly complex features:

• Binary Feature: The binary feature is the most

straightforward way to process system call data.

It indicates whether or not a speciﬁc system call

was invoked. A binary feature vector therefore is a

bitvector of the form x

bin

∈ {0, 1}

, where n is the

number of system calls available on the operating

system.

• Frequency Feature: The frequency feature has

a structure similar to that of the binary feature.

However, instead of a bit indicating the presence

of a system call the vector now consists of integers

indicating the number of occurrences for each

call. This yields a vector of the form x

f rq

∈ N

• Sequence Feature: The most complex feature we

use in this paper is the sequence feature. Unlike

the other two types of feature vectors, sequence

vectors capture the temporal ordering of system

calls. The use of sequence vectors requires some

preprocessing, since models typically require se-

quences to have equal length. We use the standard

sliding window approach to solve this problem: A

window of ﬁxed size is moved over the sequence

with a speciﬁc step-size to generate sequences of

ﬁxed length. Each sequence vector therefore has

the form x

seq

∈ S

, where S denotes the set of sys-

tem calls and k the size of the sliding window.

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

4 MODELING

In the following we brieﬂy describe the theoretical

foundation of the two state-of-the-art one-class mod-

els we use in the rest of this paper, namely HMMs and

one-class SVMs. While HMMs are generative, prob-

abilistic models, SVMs are discriminative and non-

probabilistic models allowing us to compare the suit-

ability of different algorithm types for the anomaly

detection use case. The former is particularly suited

to model temporally ordered data as needed for the

sequential feature. The one-class SVMs on the other

hand, can be used in connection with all three feature

types introduced in Section 3.

4.1 Hidden Markov Models

HMMs (Rabiner, 1989) are ﬁnite state machines

(FSMs) that describe a doubly embedded stochastic

process. The ﬁrst process is discrete and stationary

and is modeled with a ﬁxed number of states. Since

this process is deﬁned as ﬁrst-order Markov process,

an additional restriction known as the Markov prop-

erty is introduced. This property refers to the con-

straint that the process behavior at any time t depends

only on the current and the directly preceding state.

While this ﬁrst stochastic process is considered not

to be observable (i.e., it is assumed to be hidden), a

second stochastic process exists through which means

the ﬁrst process is observable. At any time t this

second process generates an output O

, which is re-

ferred to as observation. Note that the observation

probability P(O

| q

= S

) only depends on the cur-

rent state q

and not on any preceding states or ob-

servations. Since the internal behavior (in particu-

lar the sequence of visited states during generation)

of the model is hidden, the generated observation se-

quence O = O

. . . O

is the only model behavior

that is visible from the outside. These observation se-

quences, which directly map to the data the model is

trained with, show that HMMs naturally operate on

sequential data.

The complete speciﬁcation of a ﬁrst-order HMM

λ comprises ﬁnding a reasonable value for the num-

ber of hidden states N and specifying the alphabet of

the observation symbols including its size M. In addi-

tion, three probability matrices A, B and π have to be

speciﬁed. Here, A denotes a matrix of state transition

probabilities, B denotes a matrix of observation prob-

abilities and π is a vector of initial state probabilities.

Since the number of hidden states N and the size of

the alphabet M are implicitly deﬁned by the dimen-

sions of the matrices A and B, λ = (A, B, π) represents

a compact notation of the parameter set of an HMM.

In the context of this paper, two basic problems

of HMMs and their efﬁcient algorithmic solutions are

of interest. First, the training problem covers the

question how a model λ can be trained given a set

of training sequences X = {O

, O

, . . . , O

}, so that

P(X | λ), that is the probability of λ generating X, is

maximized. This problem is most commonly solved

using the Baum-Welch algorithm, an iterative proce-

dure for model parameter estimation from the class of

expectation-maximization (EM) algorithms. Second,

the evaluation problem covers the issue how P(O | λ),

i.e., the probability that λ generates O, could efﬁ-

ciently be computed given an HMM λ and an observa-

tion sequence O = O

. . . O

. This latter problem

can be solved using the forward algorithm, an algo-

rithm that, instead of enumerating every possible state

sequence like the na

ıve approach does, splits the ob-

servation sequence into two subsequences, one cov-

ering the range from time 1 to t and the second one

covering the range from t + 1 to T . This idea can be

encoded into the so-called forward variable α and it

leads to a recursive deﬁnition and thus to an efﬁcient

formulation of the calculation.

HMMs are furthermore generative models and

support one-class training, so that they can readily

be applied to anomaly detection. Since HMMs have

their strengths in temporal pattern recognition we use

them solely to model the sequence vectors. For this,

the sequences are preprocessed with a sliding window

of ﬁxed size. The gathered ﬁxed-length sequences

are then used to train an HMM with the help of the

Baum-Welch algorithm. In the detection phase the

monitored sequences are preprocessed in the same

way and tested against the model using the forward

algorithm. Both training and detection phase are de-

scribed in more detail in Section 5.

4.2 One-class SVMs

SVMs have gained great popularity in recent years

due to their outstanding classiﬁcation performance in

a number of application areas. Besides these empir-

ical results, there are theoretical founded arguments

from statistical learning theory for a good generaliza-

tion performance of SVMs. These theoretical guar-

antees on how well SVMs generalize to unseen data

make it a particular interesting modeling approach,

since those predictions are generally rare for learning

algorithms. However, the original application area for

SVMs are multi-class problems. Due to the advances

of Schoelkopf et al. (Sch

olkopf et al., 1999) the ad-

vantages of SVMs can also be used if data for only

one of two classes is available, as it is the case in

anomaly detection where only benign system behav-

Anomaly-based Mobile Malware Detection: System Calls as Source for Features

ior is observed during training. In contrast to HMMs,

SVMs are discriminative and non-probabilistic mod-

els.

A classical two-class SVM places a hyperplane

between two classes of points that make up the train-

ing data. New data points are classiﬁed according to

which side of the hyperplane they lie on. To achieve

a good generalization performance, a SVM maxi-

mizes the margin between the two different classes.

A one-class SVM as described by Schoelkopf et

al. (Sch

olkopf et al., 1999) places a separating hyper-

plane with maximal distance to the origin. This way

the data space is partitioned into two subspaces: one

holds points that are alike to the training points and

the other has points that are very different. If we allow

some slack while deﬁning the hyperplane boundary, a

few training points may be labeled as outliers.

Training a one-class SVM corresponds to solving

a quadratic maximization problem, where the output

is a sparse vector of data points that deﬁne the deci-

sion boundary, the support vectors. The form of this

decision boundary can be adjusted by tuning the pa-

rameters of the SVM. Finding the optimal parame-

ters speciﬁc to the problem at hand is referred to as

model selection. In the one-class SVM formulation

the free parameter that inﬂuences the placement of

the hyperplane is ν. Here, the parameter ν gives an

upper bound on the fraction of data points the one-

class SVM may designate as outliers during training.

Another interpretation for ν is to consider it a lower

bound on the fraction of support vectors. Thus, se-

lecting an appropriate ν is a crucial part of model se-

lection.

Kernels. The biggest advantage of (one-class)

SVMs, especially when dealing with structured data,

is the support of kernels. The main idea of kernels is

to map non-linearly separable data into a higher di-

mensional feature space where the data points are lin-

early separable with the help of a hyperplane. In our

context this allows us to model all three features de-

scribed in Section 3 with a single modeling approach

and to compare them against each other and against

HMMs.

The simplest kernel is the linear kernel. It com-

putes the similarity metric between two points simply

as the standard dot product. Another frequently used

kernel is the Gaussian Radial Basis Function (RBF)

kernel. The corresponding kernel function is of the

form: k(x, x

) = e

−

||x−x

. Because of the additional

parameter τ, which can be interpreted as the kernel’s

width, we have to evaluate an extra dimension in the

model selection process if we use the RBF kernel.

Besides these two standard kernels which we use

for the binary and frequency vectors, the spectrum

kernel introduced by Leslie et al. (Leslie et al., 2002)

is used in the context of sequence vectors. In con-

trast to HMMs, the monitored trace is not split into

ﬁxed-length sequences in a preprocessing step, but

implicitly by the spectrum kernel. Given a trace of

system calls, the spectrum kernel extracts all k-mers

(sequences of length k) and compares the number of

occurrences of these k-mers in the traces via the dot

product.

5 EXPERIMENTAL SETUP

In this section we provide details on how we evaluate

the different combinations of modeling approaches

and features. We start by explaining how we obtain

the benign apps used to train our models and the mal-

ware samples used for the assessment of the detection

performance of the trained models. Note that we train

models on a per app basis; i.e. each benign app is

used to train an individual model for this one app and

the detection performance of this model is then tested

with features derived from the benign app as well as

its malicious counterpart. I.e., while our models do

not require any malicious data for training purposes,

determining their detection quality naturally requires

malicious data. We then describe how we monitor

system call traces of benign and malicious apps. This

is followed by the deﬁnition of the metrics used to

quantify the detection quality of our models. Finally,

we describe the evaluation steps for the two modeling

approaches in detail.

5.1 Malware Samples and Benign Apps

Throughout the evaluation we will study repackaged

malware, i.e., legitimate Android apps that were tro-

janized with a malicious payload. Speciﬁcally, we

train a model with features derived from the system

call traces of a benign app and then evaluate how well

the model is able to differentiate between features de-

rived from traces of the benign app in question and

features derived from traces of its malicious coun-

terpart. The decision for this scenario follows two

crucial insights: On the one hand repackaged mal-

ware has a massive prevalence. According to Zhou

and Jiang (Zhou and Jiang, 2012) 86% of the An-

droid malware available at that time were repackaged

variants of legitimate applications. Considering only

repackaged malware, therefore, does not constitute

a major restriction. On the other hand, the case of

repackaged malware meets the strengths of anomaly

detection, since one can learn a clean model from the

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

Table 1: Overview over the repackaged apps.

Package Name MD5 Type Shortcut

com.appspot.swisscodemonkeys.steam 5895bcd066abf6100a37a25c0c1290a5 fun app steam

com.bwx.bequick 8b540b320359cc1b842dd800a9e49628 utility bequick

com.camelgames.mxmotor e5b7b76bd7154dea167f108daa0488fc game mxmotor

com.camelgames.shootu ffc735a75a6135a282ff4172fff2f371 game shootu

com.creativem.overkill 5c8c0433e7f0c5f8c686a92b9eb462ca game overkill

com.estrongs.android.pop 82f5bf4509e35c3ae7172a0dd7c3ecf4 utility estrongs

com.forthblue.pool 042177a7d144d5e3264a85341f539cb5 game forthblue

com.gamelio.DrawSlasher b87f2f3a927bf967736ed43ca2dbfb60 game drawslasher

com.googlecode.netsentry 17a2b038d1d9080b42ca8e497dddafb8 utility netsentry

org.zwanoo.android.speedtest.Speedtest b18e9a2ab55ec87b2fcac0227e61d20e utility speedtest

tencent.qqgame.lord 1bcda430eda6f2606d50f917d485500a game qqgame

Table 2: Details on the repackaged apps according to

virustotal.com.

App Malware Fam. Ratio First Sub.

steam Adrd 42 / 55 2011-03-01

bequick RootSmart 34 / 54 2013-10-28

mxmotor BaseBridge 38 / 56 2012-06-11

shootu Dowgin 24 / 54 2014-08-01

overkill BaseBridge 39 / 54 2012-10-08

estrongs PjApps 40 / 56 2011-10-23

forthblue Voxv 27 / 54 2013-03-10

drawslasher GoldDream 41 / 55 2011-07-06

netsentry Geinimi 40 / 55 2012-01-04

speedtest Mseg 28 / 50 2014-03-26

qqgame BaseBridge 47 / 56 2011-06-05

benign version and can evaluate this model by test-

ing the trace of the malicious version against it. Con-

versely, this means that a generalization to more com-

plex cases is needless, if the models fail to achieve

sufﬁcient detection performance in the simple case

of discriminating between benign apps and malware

repackaged with the same app.

Note that the effort required to ﬁnd pairs of a legit-

imate app and its trojanized counterpart is very high

and therefore the overall number of evaluated apps is

limited. The difﬁculty here resides not in ﬁnding ma-

licious apps (which we obtained through a coopera-

tion with virustotal.com), but rather in ﬁnding the

exact benign counterpart for such a trojanized app,

i.e., the benign app with with identical version tag.

As there is no central repository for benign apps that

also lists former versions additional effort is required

to ﬁnd and obtain these apps. Fortunately, since we

train our classiﬁers on a per-app basis, the classiﬁca-

tion performance would not proﬁt from a higher num-

ber of apps. To make the evaluation as meaningful as

possible despite the limited number of samples, we

focused on ﬁnding a set of apps that cover a broad

range of expected behavior. Overall, we found 11

pairs using this approach, including 9 different mal-

ware families and covering a 3 year time span be-

tween 03/2011 and 03/2014. In Table 1, we provide

an overview of the malware samples, stating the Pack-

age Name of the sample, its MD5 hash, the Type, and

a Shortcut introduced for further reference in this pa-

per. Table 2 gives further details about the evaluated

samples, where App identiﬁes the app with its short-

cut, Malware Family denotes the malware family the

majority of the search engines at virustotal stated,

the Detection Ratio gives the ratio of search engines at

virustotal that detected the sample, and First Sub-

mission gives the date when the sample was uploaded

to virustotal for the ﬁrst time.

5.2 Data Acquisition

To generate extensive data sets from the found app

pairs, we utilized an automated approach using the

Android emulator that ships with the Android SDK.

The actual system call monitoring is done by an An-

droid app that in turn uses the Linux user-land tool

strace to attach to all running processes. Since user

interaction has to be mocked in our automated ap-

proach, we used the monkeyrunner—an SDK tool

that is often used to stress test apps in the develop-

ment process—to inject random touch and keystroke

events. With help of this automated setup 50 indi-

vidual runs of each (benign or malicious) app were

monitored. However, due to crashes during monitor-

ing some very short traces had to be excluded from

the data set. The resulting strace log ﬁles were then

preprocessed to extract the features described in Sec-

tion 3 and to format the data for the different modeling

approaches.

5.3 Metrics

To quantify the performance of the different modeling

approaches and features we utilize the common met-

rics true positive rate (TPR), false positive rate (FPR),

and (balanced) accuracy (ACC). For both of our mod-

els the assessment of the TPR, i.e., the proportion of

correctly classiﬁed malware, is straightforward, since

it involves simply the test of all malicious traces of an

app against the model trained with all benign traces

of an app. We also refer to the TPR as detection rate.

The calculation is as follows:

T PR =

# true positives

# true positives + # f alse negatives

Evaluating the FPR requires a validation set that is

not included in the training set. We use k-fold cross-

validation with k = 5 to assess the FPR, i.e., our orig-

inal data set of benign traces is partitioned into 5 ran-

Anomaly-based Mobile Malware Detection: System Calls as Source for Features

domly chosen subsets. In every of 5 iterations 4 sub-

sets constitute the training set and one subset is used

as validation set, so that every subset is used as valida-

tion set exactly once. The FPR can then be calculated

as follows:

FPR =

# f alse positives

# f alse positives + # true negatives

To summarize the overall performance of our models

we use the balanced accuracy, which is deﬁned as the

arithmetic mean of the true results, i.e., true positive

rate and true negative rate:

ACC =

T PR + T NR

5.4 Modeling Approaches

While there are differences between the modeling

approaches regarding the preprocessing and the ac-

tual training, the scope of the models stays the same.

Since we use repackaged apps for evaluation, we are

able to create models on a per-app basis, using the be-

nign versions as a base line to detect anomalies. An

individual model therefore represents the benign be-

havior of a single app. Building the evaluation setup

on a per-app basis also means that the overall percent-

age of detectable apps will not signiﬁcantly change

when including more apps, since a broad range of dif-

ferent malware families is included in our test set.

HMM Modeling. The HMM modeling initially

uses a sliding window preprocessing to obtain se-

quences of length 8 from all of the monitored traces.

This preprocessing step therefore is the actual deriva-

tion of the sequence vectors described in Section 3.

The obtained sequence vectors from the benign traces

are then taken as input for the Baum-Welch algorithm.

A crucial issue when training HMMs is that of hidden

space cardinality, i.e., the absolute number of hidden

states of the model. Since there is no general rule to

determine the optimal number of hidden states ((Ye-

ung and Ding, 2003) recommends a number close to

the number of used system calls in the traces, what we

used as a hint), we optimized this parameter across

our 11 repackaged apps which resulted in the use of

76 states.

After the training of an HMM representing the be-

nign behavior of a repackaged app, we are able to test

traces against this model. The forward-algorithm is

used to calculate the so called production probability,

i.e., the probability that the sequence was generated

by the model. To ﬁnally decide whether a monitored

app can be classiﬁed as malware or not, two different

thresholds are applied. The ﬁrst threshold determines

if a single sequence is suspicious. This threshold is

determined by testing a single validation trace, i.e., a

benign trace not included in the training set, against

the model. The obtained probabilities are then sorted

and the minimum of these values is used as the thresh-

old. Note that this ﬁrst threshold is determined on

a per-app basis. The second threshold, however, is

static for all apps and is used to ultimately decide if

an app is considered malware. For this second thresh-

old we select and evaluate two different static values.

The ﬁrst one optimizes the overall average accuracy

and is set to 0.0001, stating that if 1 or more anoma-

lies are found in 10,000 sequences the app is classiﬁed

as malware. The second one is set to 0.01 and opti-

mizes the overall false positive rate (see Table 6 (b)).

Since the determination of the second threshold de-

pends on the availability of malicious traces, it is set

static across all apps. The rationale behind this ap-

proach is to ﬁnd a value that is as generic as possible,

so that it also can be applied on new apps for which

no malicious counterpart is available. In Section 6 we

also brieﬂy describe the results that can be achieved

when optimizing the second level threshold on a per-

app basis (see Table 7).

One-class SVM Modeling. The preprocessing re-

quired for the one-class SVM modeling varies de-

pending on the chosen feature representation and the

selected kernel. Binary vectors can be used as input

for the linear and the RBF kernel directly, whereas

frequency vectors have to be normalized ﬁrst. Nor-

malizing the frequencies to the interval [0, 1] elimi-

nates the overweighting of common system calls that

occur in benign traces. We divide each system call

frequency by the maximal value that was recorded

during a benign trace, if this value is different from

zero. System calls that do not occur in the benign

traces are not normalized. For the spectrum kernel,

we map each system call trace to a string, with each

character representing one system call. To this end,

we reduced the number of system calls that are taken

into account to those that occur at least once during

monitoring.

After preprocessing, we train the one-class SVM

with the data of the benign applications. To conduct

the model selection with one-class SVMs, we have

to determine the parameter ν. Additional parameters

that are used within the speciﬁc kernel have to be se-

lected as well. In case of the linear or the sequence

kernel we conduct a one-dimensional grid search for

ν, whereas for the RBF kernel a two-dimensional grid

search is performed to ﬁnd the additional kernel pa-

rameter τ. We sample the search space exponentially,

testing the values 0.9

, . . . , 0.9

249

for ν for all kernels

except when using the RBF kernel. Sampling a two-

dimensional grid for training with the RBF kernel re-

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

Table 3: Repackaged apps evaluated with one-class SVM on the binary feature.

App ACC TPR FPR

steam 83.67 95.74 27.45

bequick 95.62 99.55 22.00

mxmotor 90.22 100.00 18.37

shootu 90.34 96.51 15.56

overkill 84.85 98.00 28.57

estrongs 66.32 100.00 69.57

forthblue 74.32 100.00 54.29

drawslasher 82.47 91.49 26.00

netsentry 94.38 97.22 6.34

speedtest 71.43 90.00 47.92

qqgame 72.90 100.00 54.72

Avg. 82.41 97.14 33.71

App ACC TPR FPR

steam 98.98 100.00 1.96

bequick 85.40 87.50 24.00

mxmotor 100.00 100.00 0.00

shootu 53.41 5.81 1.11

overkill 88.89 80.00 2.04

estrongs 70.53 61.22 19.57

forthblue 63.51 43.59 14.29

drawslasher 68.04 93.62 56.00

netsentry 99.44 97.22 0.00

speedtest 58.16 22.00 4.17

qqgame 73.83 100.00 52.83

Avg. 78.20 71.91 16.00

(a) RBF kernel (b) Linear kernel

Table 4: Repackaged apps evaluated with one-class SVM on the frequency feature.

App ACC TPR FPR

steam 62.24 68.09 43.14

bequick 95.26 100.00 26.00

mxmotor 63.04 67.44 40.82

shootu 91.48 96.51 13.33

overkill 54.55 88.00 79.59

estrongs 51.58 100.00 100.00

forthblue 59.46 79.49 62.86

drawslasher 59.79 70.21 50.00

netsentry 92.70 97.22 8.45

speedtest 56.12 80.00 68.75

qqgame 53.27 96.30 90.57

Avg. 67.23 85.75 53.05

App ACC TPR FPR

steam 55.10 72.34 60.78

bequick 98.54 99.55 6.00

mxmotor 54.35 11.63 8.16

shootu 52.27 5.81 3.33

overkill 59.60 34.00 14.29

estrongs 51.58 79.59 78.26

forthblue 56.76 43.59 28.57

drawslasher 56.70 14.89 4.00

netsentry 97.75 97.22 2.11

speedtest 54.08 56.00 47.92

qqgame 74.77 100.00 50.94

Avg. 64.68 55.88 27.67

(a) RBF kernel (b) Linear kernel

quires much more work, so we limit the search space

to 0.9

, . . . , 0.9

for ν and 2

, . . . , 2

−13

for τ. Since

we decrement the exponent by 2 each turn for τ, we

search 450 parameter combinations when using the

RBF kernel while only evaluating 250 parameters on

other kernels.

Linear and RBF kernel do not need any prepro-

cessing, we just have to provide the feature vectors.

The spectrum kernel on the other hand works on

strings. Internally, it breaks down the string into se-

quences of length 8 using the sliding window tech-

nique. Since each system call is represented by a char

after the preprocessing, we can concatenate 8 system

calls to make up a 64-bit word. These 64-bit words

are in turn interpreted as unsigned integers to build up

a sparse vector. This vector has a dimensionality of

, however, due to the sparse representation it suf-

ﬁces to save the actually occurring sequences.

6 EVALUATION RESULTS

In this section we present and compare the results

of our evaluation of HMMs and one-class SVMs

(see Section 4) in the context of distinguishing ma-

licious from benign Android apps based on features

extracted from system calls (see Section 3). We evalu-

ate HMMs on the sequence feature only (see Table 6),

as HMMs reasonably work on sequential data only.

One-class SVMs are tested on different combinations

of kernels and features. Speciﬁcally, the binary fea-

ture and the frequency feature are evaluated in combi-

nation with the linear kernel and the RBF kernel (see

Table 3 and Table 4), while the sequence feature is

evaluated with the spectrum kernel, which naturally

works on sequences (see Table 5). In the following

we ﬁrst compare the performance of the individual

features in combination with different modeling ap-

proaches averaged over all apps. We start with the bi-

nary feature, continue with the frequency feature and

ﬁnally discuss the sequence feature. Then we take

a closer look at the results on a per-app basis. Fi-

nally, we discuss and compare the overall discrimi-

natory power of the three different feature types pro-

posed.

In Table 3 we summarize the one-class SVM re-

sults for the binary feature. Here the RBF kernel

shows superior results regarding the accuracy, while

the linear kernel has a lower detection rate, but also

a much lower false positive rate. The comparison of

both kernels using the frequency feature presented in

Table 4 shows a very low average accuracy for both

kernels, with only individual apps achieving an ac-

ceptable ratio of detection rate and false positive rate.

While the RBF kernel shows slightly better aver-

age accuracy than the linear kernel on both the binary

and the frequency feature, it also shows much higher

false positive rates in both cases. We reckon that this

behavior is due to an overﬁtting of the RBF kernel to

the training data, which is underpinned by the signif-

icantly higher support vector ratio of the RBF kernel

compared with the linear kernel. Since the RBF ker-

nel also needs more time for training, the linear kernel

Anomaly-based Mobile Malware Detection: System Calls as Source for Features

Table 5: Repackaged apps evaluated with one-class SVM with spectrum kernel on the sequence feature.

App ACC TPR FPR

steam 56.12 89.36 74.51

bequick 97.81 99.55 10.00

mxmotor 61.96 41.86 20.41

shootu 77.27 87.21 32.22

overkill 55.56 42.00 30.61

estrongs 51.58 100.00 100.00

forthblue 79.73 92.31 34.29

drawslasher 74.23 70.21 22.00

netsentry 96.07 97.22 4.23

speedtest 60.20 34.00 12.50

qqgame 65.42 96.30 66.04

Avg. 70.54 77.27 36.98

App ACC TPR FPR

steam 58.16 65.96 49.02

bequick 98.54 99.55 6.00

mxmotor 63.04 39.53 16.33

shootu 78.98 90.70 32.22

overkill 56.57 52.00 38.78

estrongs 55.79 85.71 76.09

forthblue 79.73 92.31 34.29

drawslasher 74.23 70.21 22.00

netsentry 97.19 97.22 2.82

speedtest 63.27 34.00 6.25

qqgame 65.42 96.30 66.04

Avg. 71.90 74.86 31.80

(a) Constant window size 8 (b) Varying window size optimized on per-app basis

Table 6: HMM evaluated on repackaged apps.

App ACC TPR FPR

steam 99.34 100.00 1.32

bequick 78.33 100.00 43.34

mxmotor 65.78 43.90 12.35

shootu 92.75 95.06 9.57

overkill 82.21 73.47 9.05

estrongs 71.12 51.02 8.78

forthblue 60.06 33.33 13.21

drawslasher 64.44 30.00 1.11

netsentry 89.24 86.21 7.73

speedtest 83.70 78.43 11.03

qqgame 78.59 98.15 40.97

Avg. 78.69 71.78 14.40

App ACC TPR FPR

steam 100.00 100.00 0.00

bequick 88.58 77.16 0.00

mxmotor 50.89 2.44 0.67

shootu 96.55 95.06 1.96

overkill 57.14 14.29 0.00

estrongs 50.00 0.00 0.00

forthblue 49.85 2.56 2.86

drawslasher 53.75 7.50 0.00

netsentry 91.38 82.76 0.00

speedtest 50.00 0.00 0.00

qqgame 50.00 0.00 0.00

Avg. 67.10 34.71 0.50

(a) Threshold 0.0001, optimizing accuracy (b) Threshold 0.01, optimizing false positive rate

has a superior balance between accuracy, false posi-

tive rate, and training performance.

Table 5 shows the evaluation of the sequence fea-

ture in the one-class SVM case with a ﬁxed window

size of 8 in (a) and a varying window size between 2

and 8 that optimizes the accuracy in (b). Overall, the

one-class SVMs with spectrum kernel rank behind the

one-class SVMs on the binary feature and the HMMs

with respect to the accuracy. In Table 6 (a) the results

for the HMMs on the sequence feature are summa-

rized, showing an average accuracy on one level with

one-class SVMs with linear kernel on the binary fea-

ture. Note that HMMs show the lowest false positive

rate of all models and that this value can further be

optimized as shown in Table 6 (b). This optimization

that brings the FPR to a real-world applicable level of

below 1%, however, comes to the price of only de-

tecting 36% of the apps fairly reliably. For the sake of

completeness we also included the detection perfor-

mance for a per-app optimized second level threshold

in Table 7, showing only a slight improvement com-

pared to the static threshold applied in Table 6 (a).

Turning to the results for individual apps, our

evaluation shows that there are apps that show good

detection performance across model boundaries (in

particular netsentry, followed by bequick) and that

there are apps that show the opposite result, i.e.,

bad performance across model boundaries (estrongs,

drawslasher, forthblue, and qqgame). Figure 1 gives

an overview over the achieved accuracy for all tested

apps and models, where frq, bin, and seq denote

Table 7: HMM evaluated on repackaged apps with per-app

optimized second level threshold.

App ACC TPR FPR Thres.

steam 100.00 100.00 0.00 0.01

bequick 92.97 99.49 13.56 0.0008

mxmotor 65.78 43.90 12.35 0.0005

shootu 96.55 95.06 1.96 0.01

overkill 82.21 73.47 9.05 0.0001

estrongs 71.12 51.02 8.78 0.0001

forthblue 60.06 33.33 13.21 0.0001

drawslasher 64.44 30.00 1.11 0.0001

netsentry 93.10 86.21 0.00 0.004

speedtest 83.70 78.43 11.03 0.0001

qqgame 78.83 98.15 40.49 0.0002

Avg. 80.80 71.73 10.1

the frequency feature, the binary feature, and the se-

quence feature, followed by the used kernel. For the

two apps that are well detectable, all but one model

achieve an accuracy above 85%. In particular, netsen-

100

steam

bequick

mxmotor

shootu

overkill

estrongs

forthblue

drawslasher

netsentry

speedtest

qqgame

ACC in %

frq RBF

frq linear

bin RBF

bin linear

seq spectrum

HMM

Figure 1: Overview of the accuracy of all evaluated models

and features.

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

100

steam

bequick

mxmotor

shootu

overkill

estrongs

forthblue

drawslasher

netsentry

speedtest

qqgame

TPR in %

frq RBF

frq linear

bin RBF

bin linear

seq spectrum

HMM

(a) True positve rate

100

steam

bequick

mxmotor

shootu

overkill

estrongs

forthblue

drawslasher

netsentry

speedtest

qqgame

FPR in %

frq RBF

frq linear

bin RBF

bin linear

seq spectrum

HMM

(b) False positive rate

Figure 2: Overview of all evaluated models and features.

try also shows prominent peaks in Figure 2 (a) that

indicate a high detection rate and in Figure 2 (b) that

indicate a low FPR across models. In the case of the

poorly detectable apps, only two models achieve an

accuracy above 80%, the vast majority of the models

perform clearly below 80%. An explanation for this

is that both apps with good detection performance are

fairly simple utility or fun apps, while the latter apps

are a feature-rich ﬁle browser (estrongs) and games

(drawslasher, forthblue, and qqgame), and thus much

more complex.

Therefore, it is to assume that the additional mali-

cious payload is much easier to discriminate from the

simple apps than from the complex apps. Our results

also show, however, that a number of apps show no

clear trend across different models and that sufﬁcient

accuracy for these apps can only be achieved in few

of our models.

Taking a step back to the overall picture, our

evaluation shows that one-class SVM-based modeling

achieves the best performance with the binary feature,

i.e., with the simplest of the three features, outper-

forming the frequency feature and the sequence fea-

ture considerably. Using the accuracy as basis for

these comparisons, the sequence feature processed

by the spectrum kernel performs second best, while

the frequency feature lags far behind. The bad per-

formance of the frequency feature is especially sur-

prising, since this feature shows good performance

in prior work (see (Dini et al., 2012; Burguera et al.,

2011)). In the case of MADAM by Dini et al. an ex-

planation could be found in the enrichment of the fea-

ture vectors (see Section 2), leaving it unclear how

much the additional features contribute to the detec-

tion performance. The fact that the best performance

with one-class SVMs can be achieved with the binary

feature suggests that the introduction of system calls

by the malicious payload that are not present in the

benign traces is most discriminative in the context of

this model. The strong performance of the binary fea-

ture compared to the more complex features indicates,

that the variations of the system call frequencies and

the additional information encoded in the temporal or-

dering is not distinctive enough that it can be reliably

learned by our one-class SVM-based classiﬁer. The

inferior result regarding the sequence feature in the

one-class SVM case, however, is contrasted by the

strong performance of this feature in the HMM-based

approach. This, in turn, suggests that the used spec-

trum kernel does not capture the temporal structure of

the underlying data nearly as well as the HMM does.

The most pronounced result of our evaluation is,

that the structure and complexity of the feature has

to be taken into consideration when choosing the ac-

tual modeling approach. Taking the most important

values—accuracy, detection rate and false positive

rate—into account, it is remarkable that both one-

class SVMs with linear kernel on the binary feature

and HMMs on the sequence feature achieve the best

results with almost identical average values. Simpli-

ﬁed one can state that there is not one best modeling

approach for anomaly-based mobile malware detec-

tion on system calls, but that there are best modeling

approaches for each particular derived feature.

7 CONCLUSION

In this paper, we proposed the use of one-class clas-

siﬁers in the context of mobile malware detection.

These classiﬁers have the advantage that they are

trained with data from the benign class only, do thus

not require access to malware samples during train-

ing, and have a great potential to detect new malware

Anomaly-based Mobile Malware Detection: System Calls as Source for Features

that signiﬁcantly differs from known malware. We

systematically compared HMMs (a generative prob-

abilistic model) and one-class SVMs with different

kernels (discriminative, non-probabilistic model) in

combination with three different feature types derived

from system call traces. We showed that HMMs in

combination with the sequence feature slightly out-

perform the other modeling approaches. The most

discriminative feature type, however, strongly de-

pends on the model chosen. In particular, despite

of the good performance of the sequence feature in

the HMM case, the binary feature outperformed both

the frequency feature and the sequence feature in the

one-class SVM case. Overall, our evaluation shows

that the discriminatory power of the features derived

from system call traces varies greatly on a per-app

basis which indicates that not all malicious behav-

ior is appropriately covered with system call traces.

We identiﬁed the heavy use of inter-process commu-

nication (IPC) on the Android platform as a main rea-

son. In future work we plan to study low-level fea-

tures that provide superior discrimination power than

system calls and to evaluate them with state-of-the art

models from the ﬁeld of one-class classiﬁcation.

REFERENCES

Aafer, Y., Du, W., and Yin, H. (2013). Droidapiminer: Min-

ing api-level features for robust malware detection in

android. In SecureComm, volume 127 of LNICST,

pages 86–103. Springer.

Aldini, A., Martinelli, F., Saracino, A., and Sgandurra, D.

(2014). Detection of repackaged mobile applications

through a collaborative approach. Concurrency and

Computation: Practice and Experience.

Arp, D., Spreitzenbarth, M., H

ubner, M., Gascon, H.,

Rieck, K., and Siemens, C. (2014). Drebin: Effec-

tive and explainable detection of android malware in

your pocket. In Proceedings of NDSS.

Bose, A., Hu, X., Shin, K. G., and Park, T. (2008). Be-

havioral detection of malware on mobile handsets. In

Proceedings of ACM MobiSys, pages 225–238.

Burguera, I., Zurutuza, U., and Nadjm-Tehrani, S. (2011).

Crowdroid: behavior-based malware detection system

for android. In Proceedings of ACM SPSM.

Dini, G., Martinelli, F., Matteucci, I., Saracino, A., and

Sgandurra, D. (2014). Introducing probabilities in

contract-based approaches for mobile application se-

curity. In Data Privacy Management and Autonomous

Spontaneous Security, pages 284–299. Springer.

Dini, G., Martinelli, F., Saracino, A., and Sgandurra, D.

(2012). Madam: A multi-level anomaly detector for

android malware. In MMM-ACNS, volume 7531 of

LNCS, pages 240–253. Springer.

Eskin, E., Arnold, A., Prerau, M., Portnoy, L., and Stolfo,

S. (2002). A geometric framework for unsupervised

anomaly detection: Detecting intrusions in unlabeled

data. In Applications of Data Mining in Computer

Security, pages 77–101. Springer.

Forrest, S., Hofmeyr, S. A., Somayaji, A., and Longstaff,

T. A. (1996). A sense of self for unix processes. In

Proceedings of IEEE S&P.

Gartner (2014). Gartner says by 2018, more than 50 percent

of users will use a tablet or smartphone ﬁrst for all

online activities. http://www.gartner.com/newsroom/

id/2939217.

IDC (2014). Worldwide smartphone growth forecast. http://

www.idc.com/getdoc.jsp?containerId=prUS25282214.

Leslie, C. S., Eskin, E., and Noble, W. S. (2002). The spec-

trum kernel: A string kernel for SVM protein clas-

siﬁcation. In Proceedings of Paciﬁc Symposium on

Biocomputing, pages 566–575.

Maggi, F., Matteucci, M., and Zanero, S. (2010). Detecting

intrusions through system call sequence and argument

analysis. IEEE TDSC, 7(4):381–395.

Mutz, D., Valeur, F., Vigna, G., and Kruegel, C. (2006).

Anomalous system call detection. ACM TISSEC,

9(1):61–93.

Rabiner, L. R. (1989). A tutorial on hidden Markov models

and selected applications in speech recognition. Pro-

ceedings of the IEEE, 77(2):257–286.

Sch

olkopf, B., Williamson, R. C., Smola, A. J., Shawe-

Taylor, J., and Platt, J. C. (1999). Support vector

method for novelty detection. NIPS, 12:582–588.

Shabtai, A., Kanonov, U., Elovici, Y., Glezer, C., and Weiss,

Y. (2012). “Andromaly”: a behavioral malware detec-

tion framework for android devices. JIIS, 38(1):161–

190.

Warrender, C., Forrest, S., and Pearlmutter, B. (1999). De-

tecting intrusions using system calls: alternative data

models. In Proceedings of IEEE S&P.

Xie, L., Zhang, X., Seifert, J., and Zhu, S. (2010). pBMDS:

a behavior-based malware detection system for cell-

phone devices. In Proceedings of ACM WiSec.

Yeung, D. and Ding, Y. (2003). Host-based intrusion de-

tection using dynamic and static behavioral models.

Pattern Recognition, 36(1):229–243.

Zhang, M., Duan, Y., Yin, H., and Zhao, Z. (2014).

Semantics-aware android malware classiﬁcation using

weighted contextual api dependency graphs. In Pro-

ceedings of ACM CCS.

Zhou, Y. and Jiang, X. (2012). Dissecting Android Mal-

ware: Characterization and Evolution. In Proceedings

of IEEE S&P.

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy
