Full Video Processing for Mobile Audio-visual Identity Verification

Alexander Usoltsev, Khemiri Houssemeddine and Dijana Petrovska-Delacrétaz

Télécom SudParis, SAMOVAR CNRS, Université Paris-Saclay, 9 rue Charles Fourier, 91011 Evry Cedex, France

Keywords: Biometrics, Full Video Processing, Face, Speech, Score Fusion.

Abstract: This paper describes a bi-modal biometric verification system based on voice and face modalities, which

takes advantage of the full video processing instead of using still-images. The bi-modal system is evaluated

on the MOBIO corpus and results show a relative improvement of performance by nearly 10% when the

whole video is used. The fusion between face and speaker verification systems, using linear logistic

regression weights, gives a relative improvement of performance that varies between 30% and 60%

comparing to the best uni-modal system. Proof-of-concept iPad application is developed based on the

proposed bi-modal system.

1 INTRODUCTION

Mobile devices (like tablets and smartphones) have

become an important part of our daily lives, and

large amount of personal data is collected and stored

in the device’s memory. Moreover, with the

proliferation of the mobile internet, sensitive

information (such as social network accounts, emails

and bank accounts) became easier to access. Most of

these services require personal authentication. Since

mobile devices incorporate both microphone and

camera, it is possible to apply a bi-modal biometrics

approach based on face and speech modalities to

provide protection against unauthorized access.

Mobile biometric system should be fast and

autonomous in a way that the user provides only

initial media recording (still-image, audio and/or

video), and all the processing steps (for example,

finding face region and detecting eyes position)

should be performed automatically.

However, finding face region and the positions

of the eyes in automatic way could be a tricky task

due to a wide range of recording conditions

(variations of illumination, pose, image quality,

etc.). Because modern mobile devices can capture

not only still image of the face, but record a video, it

is possible to exploit recorded video frames and

improve face verification results in hard mobile

environment conditions.

On the other hand, if we will pass all video

frames to the face verification system on mobile

device, it will take long time and consume too much

energy to perform computationally demanding

biometric verification operations. Therefore, a trade-

off between processing the full video and keeping

the calculations under a reasonable time should be

found.

In this paper, a bi-modal biometric verification

system based on voice and face modalities is

proposed. The speaker verification system is based

on an UBM-GMM (Universal Background Model –

Gaussian Mixture Model) method (Reynolds et al.,

2000), while the face verification system is using

Gabor features and Linear Discriminant Analysis

(LDA) modeling (Petrovska-Delacrétaz et al., 2009).

For video containing face and speech samples, each

modality is first processed separately, and then an

overall verification score is computed using score

fusion.

For our knowledge, previous evaluation of

biometric systems suitable for mobile device used

the hand-labeled eye positions, while biometric

systems might work different if the face and eye

positions are detected automatically rather than

annotated by a human (Khoury et al., 2013).

That is why in proposed system the face

modality is processed in a fully automated way,

including automatic eyes position detection, which

involves a whole video sequence processing while

keeping balance between calculations time and

biometrics system performance.

The proposed system is evaluated on the MOBIO

database (McCool et al., 2012). This database, as

well as results on face, voice and multimodal fusion,

552

Usoltsev, A., Petrovska-Delacrétaz, D. and Houssemeddine, K.

Full Video Processing for Mobile Audio-Visual Identity Veriﬁcation.

DOI: 10.5220/0005667305520557

In Proceedings of the 5th International Conference on Pattern Recognition Applications and Methods (ICPRAM 2016), pages 552-557

ISBN: 978-989-758-173-1

is publicly available. Moreover, MOBIO database

was recorded on mobile devices, which provides a

good estimation of challenges of mobile

environment. For every video, database providers

extract one still image and manual eyes positions are

given only for those still images. This allows us to

compare the performance of face verification system

when face and eyes detection is performed

automatically against using the manual positions of

the eyes.

Using the obtained results we develop an iPad

proof-of-concept bi-modal biometric application.

Despite being early prototype, this application

processes full video and performs bi-modal

biometric verification in a time of 2-3s (with input

video’s length of 10s).

This paper is organized as follows. In Section 2

the face and speaker verification systems are

outlined. In Section 3, full video processing and

score fusion approaches are described. Experimental

database and results are exposed in Section 4.

Conclusions and perspectives are given in Section 5.

2 BI-MODAL VERIFICATION

SYSTEM

In this section, baseline face and speaker verification

systems are summarized. Two versions of the face

verification system are used. In the first version, we

suppose that the positions of the eyes are given. In

the second version, the positions of the eyes are

automatically detected using the Combined Active

Shape Model (CASM) (Zhou et al., 2009).

2.1 Face Verification

For the automatic version, the baseline face

verification system uses Viola-Jones face detector

with Haar cascades. The automatic 2D facial

landmark location is applied to face region to detect

58 facial landmarks, and from those landmarks the

positions of the eyes are extracted.

After geometric and illumination normalization,

global facial descriptors are extracted. It involves

anisotropic smoothing preprocessing, Gabor

features, and LDA face space representation. In this

way the discriminative capabilities of LDA systems,

that maximize the inter-class variability, and

minimize the intra-class distances, are exploited.

Gabor filters are applied and only magnitude values

are kept to create a vector by concatenation. This

vector is projected in the LDA space to reduce its

dimension. The size of reduced vector depends on

the number of subjects used to create the LDA

space. Cosine distance between two reduced

dimension feature vectors is chosen as a score to

decide whether to accept or to reject the claimant.

2.2 Speaker Verification

Well-known GMM-UBM speaker verification

system is proposed as a baseline system. The UBM

(Universal Background Model) is a GMM with 512

Gaussians trained on a large number of speakers to

represent the distribution of the extracted features

for a representative population. The hypothesized (or

target) speaker model is obtained by adapting

parameters of the UBM model using the speaker

training speech and a Maximum A Posteriori (MAP)

adaptation. In the decision making step, a log-

likelihood ratio for a test sequence of feature vectors

X is computed as follows:

LogLR(X,target)=log(p(X|λ

target

))−log(p(X|λ

UBM

)) (1)

where λ

target

and λ

UBM

are respectively the target and

UBM models.

The speaker adaptation step creates a model for

each of the speakers’ voices using samples of their

speech. The speaker model once trained allows

performing the recognition step by scoring the test

speech against the model of the claimed speaker and

the UBM model. This score is used to decide

whether to accept or reject the claimant.

2.3 Score Fusion

One possible way to combine two biometric systems

into a bi-modal identity verification system is the

score fusion. To follow this approach, scores are

first derived using the uni-modal systems. Then, a

min-max normalization is performed to produce

scores between 0 and 1, where the minimum and

maximum score are computed on a development set.

Finally, fusion is performed by a weighted sum of

the two scores. Linear Logistic Regression (LLR) is

exploited to train the optimal weights on a

development set.

Combining face and speaker verification systems

presents a good solution to overcome the problem,

when the face verification system fails to detect

faces. In such a case, the fusion system will assign a

weight of 1 to the speaker verification and 0 to the

face verification instead of a LLR weights. This

could be considered as a fusion with a simple quality

factor.

Full Video Processing for Mobile Audio-Visual Identity Veriﬁcation

553

3 FULLY AUTOMATED SYSTEM

3.1 Full Video Processing

For the proposed fully automated system face region

and eyes position are found automatically without

manual intervention. This system is built on top of

the face and speaker verification baseline biometric

systems. Speech biometric system works with all

audio tracks from videos, however the face

biometric system uses only still-images of face. To

meet challenges of mobile environment, a full video

processing is performed. On the other side, mobile

device performance does not allow passing all video

frames to face biometric system and user interaction

time will be too long. The main idea is to balance

between robustness and speed by applying some fast

operations to all video frames, such as illumination

correction and face region detection, and then

choose subset of frames which passed some basic

quality measures (e.g. face was found, minimal face

dimension is more than 15% of frame dimension).

After that, only this subset of frames is passed to

more computationally demanding face biometric

system.

Steps for the proposed full video processing are:

1) Apply illumination correction filter to all

frames of the video. For fast and robust

results, logarithmic filter is chosen.

2) Detect face regions on all frames of log-

filtered video.

3) Select indexes of only three frames where

face is detected (two strategies to select

frames are discussed below).

4) Apply eye’s positions detector to the three

selected filtered frames.

5) Perform geometric normalization using the

eye’s positions from step (4) on the three

original frames (frame without log filter)

according to the indexes selected in step

(3).

6) Pass these three frames to face verification

system.

Figure 1 shows the scheme of the bi-modal full

video processing system. First, two computationally

fast operations are applied to all frames from the

video: illumination correction with logarithmic filter

and Viola-Jones face detector. Then only the biggest

detected face in each frame is kept (face size is more

than 15% of frame size). After that, computationally

more demanding steps of the face verification

system are applied on three selected frames.

Two different strategies to select that three

frames are evaluated: select three random frames

(“random” frames) or frame from the beginning,

frame in the middle and frame at the end (“thirds”

frames). Influence of selecting “random” or “thirds”

frames is reported in section 4.2.2.

Figure 1: Proposed scheme of full video processing for the

bi-modal fully automated biometric system.

4 EXPERIMENTS

In this section, the MOBIO database and protocol

are described. Then the results related to the face

verification system using automatic detection of the

face and to its fusion with the speaker verification

are exposed.

4.1 Database and Experimental Setups

The MOBIO database (McCool et al., 2012) is a

bimodal (face/speaker) database recorded from 152

people. The database has a female-male ratio of

nearly 1:2 (100 males and 52 females) and was

collected from August 2008 to July 2010 in six

different sites from five different countries. In total

12 sessions were captured for each individual. The

database was recorded using two types of mobile

devices: mobile phones (NOKIA N93i) and laptop

computers (standard 2008 MacBook). In this

evaluation, only the mobile phone data are used,

with a sampling rate of 16kHz. Note that a manual

annotation of eyes position for the only one image

per video data is given. More details about the

MOBIO database can be found in (McCool et al.,

2012).

Video

Frames

with

face

(3)

Select

three

frames

(6)

Normalized

faces

(1)Log-filter

(2)face

detector

(4)

Eye’s

position

(5) face normalization

+ +

Speaker

verification

system

Face

verification

system

Audio

Score

Fusion

Fused

score

Threshold

ICPRAM 2016 - International Conference on Pattern Recognition Applications and Methods

554

Table 1: Number of files (original still images and log-

filtered videos) where the automated system fails to detect

face in male and female MOBIO development and

evaluation sets.

Female Male

DEV EVAL DEV EVAL

Enrollment

Still images 0 6 2 17

Full video 0 0 0 0

Test

Still images 38 50 30 0

Full video 2 1 6 0

Table 2: EER and HTER computed on MOBIO still

images from the development and evaluation partition for

the baseline uni-modal systems and their fusion with LLR

weight (using manual positions of the eyes).

Female Male

DEV

(EER)

EVAL

(HTER)

DEV

(ERR)

EVAL

(HTER)

Face verification 8.09 13.55 7.97 8.00

Speaker verification 11.42 11.62 10.18 9.09

Bi-modal system 3.27 6.14 2.73 2.86

Based on gender of the claimant, two different

evaluation protocols for male and female were

generated. In order to have an unbiased evaluation,

the claimants are split up into three different sets:

training, development and evaluation sets:

• Training set: The data of this set is used to learn

the background parameters of the algorithm

(UBM, subspaces, etc.).

• Development set: The data of this set is used to

tune meta-parameters of the algorithm (e.g.

number of Gaussians, dimension of the

subspaces, etc.). For the enrollment of a client

model, five videos of the claimant are provided.

The remaining video files of the claimant serve

as testing files.

• Evaluation set: The data of this set is used for

computing the final evaluation performance. It

has a structure similar to the development set.

For the speaker verification system, the feature

vector is composed of 20 MFCC coefficients (32

Mel filter bank) together with their first derivatives

and the delta energy. This is intended to better

exploit the 16KHz range of the MOBIO database.

Feature warping and energy-based voice activity

detection are performed. The UBM model is trained

with 512 Gaussians. SPro 4.1 (Gravier, 2009) and

ALIZE 2.0 (Bonastre et al., 2008) software are used

to develop the proposed system.

For the face verification baseline system, Gabor

filters are applied with 5 scales and 8 orientations

convoluted with the face images. An anisotropic

smoothing pre-processing is performed and the

distance between the eyes is fixed to 50. The

SudFrog software (Petrovska-Delacrétaz et al.,

2009) is used to develop the system.

4.2 Results

To measure the performance of the proposed

biometric systems, two different criteria are used:

The Half Total Error Rate (HTER) (Khoury et al.,

2013) and the Equal Error Rate (EER). To compute

the HTER, a threshold θ is defined on the

development partition (DEV) at the EER point. This

threshold is applied to the evaluation partition

(EVAL) to obtain the HTER as follows:

HTER = (FAR(θ,EVAL)+FRR(θ,EVAL))/2, (2)

Table 3: EER and HTER computed, respectively on the development and evaluation partition, for the face (if located) from

still-image and whole video MOBIO database (using automatic detection of eyes position) and speaker verification system,

and their fusion using LLR weights (fusion-LLR-quality), and the performance of the fused fully automated system

proposed by mccool-icme-2012 (McCool et al., 2012).

Female Male

DEV

(EER)

EVAL

(HTER)

DEV

(EER)

EVAL

(HTER)

Speaker verification 11.42 11.62 10.18 9.09

Face verification, automated

Still images 13.34 15.37 12.83 9.66

Full video, Random frames 11.24 15.03 10.59 8.82

Full video, Thirds frames 11.08 14.58 11.31 9.16

Bi-modal system

Still images 5.69 7.97 5.16 4.82

Full video, Random frames 5.10 7.92 4.62 3.53

Full video, Thirds frames 5.01 8.40 4.86 3.69

mccool-icme-2012 bi-modal system 10.5 13.3 10.9 11.9

Full Video Processing for Mobile Audio-Visual Identity Veriﬁcation

555

where FAR is the False Acceptance Rate and FRR is

the False Rejection Rate.

Using these criteria this section studies:

• the influence of applying log-filter with face

detection on all frames of the video;

• the performance of the face verification system

when the eyes positions are provided manually

or automatically;

• the selection of frame’s subset;

• the fusion between face and speaker verification

systems.

4.2.1 Influence of Illumination Correction

The proposed bi-modal system takes advantage of

fusion between audio and face verification systems,

so it is important to ensure that face can be detected

from video even if the light conditions are

challenging. To estimate the influence of log-

filtering, face detector is applied to still-image

(without any correction) and to full video (with log-

filter illumination correction). Table 1 gives the

number of files (still images and full videos) where

the automated system fails to detect the face. Note

that a video is considered as containing face only

when a face is detected in at least three frames.

Problem with failed face detection in the media

means that all possible trials, which involve this

media, are lost. In that case bi-modal system relies

only on speech data and do not profit from the score

fusion.

Usage of illumination correction with

logarithmic filter reduces number of failed face

detections from 25 files to 0 on enrollment medias,

and for test medias from 118 to 9 files. Therefore

full video processing does not just improve

biometric system performance (section 4.2.3), but in

mobile application it also reduces the number of

situations when the user is asked to re-record video

due to illumination problems.

4.2.2 Manual Bi-Modal System

In this section, the manual positions of the eyes are

used, which means that the face detection and the

automatic 2D facial landmark location modules

described in section 2.1 are not considered. The

projection space for face verification system is

learned on MOBIO training set along with FRGC

database (Phillips et al., 2005). 50 users are used for

each database, where 30 and 20 images per user are

respectively taken from MOBIO and FRGC data. In

a similar way, UBM model for speaker verification

is learned on MOBIO training set and VOXFORGE

data (MacLean, 2012), where 255 female (2h) and

264 male (3h50) files are present.

Table 2 shows the EER and HTER computed

respectively on the development and evaluation

partition for the baseline uni-modal systems, using

the manual positions of the eyes. Fusion of both

systems with LLR weights gives a relative

improvement that varies between 47% and 65%

comparing to best uni-modal system.

4.2.3 Fully Automated Bi-Modal System

In this section we compare performance of the bi-

modal system when it uses still images from

MOBIO dataset against fully processed videos. In

both cases face region and eyes position are found

automatically without any intervention from the user

side. Still images are used “as is” without any

modification, and videos are processed as described

in section 3.1. For full video processing system, two

strategies of subset selection are defined: “random”

frames and “thirds” frames (frames from the

beginning, middle and the end).

The best score of three frames from face

verification system is fused with the score provided

by the speaker verification system according to the

fusion strategy from section 2.3.

The ERR and HTER computed using still-images

and the full videos processing with “random” and

“thirds” strategies selection for the face verification

and the bi-modal systems are shown in Table 3. The

bi-modal system is compared to the fully automated

system proposed by (McCool et al., 2012).

The fusion between face and speaker verification

systems, using LLR weights, gives a relative

improvement of performance that varies between

30% and 60% comparing to the best uni-modal

system. The full video random frames for the fusion

system shows better results on MOBIO evaluation

set comparing to “thirds” frames.

5 CONCLUSIONS AND

PERSPECTIVES

In this paper, we propose a bi-modal biometric

verification system based on voice and face

modalities. The face verification part is based on

LDA modelling while the speaker one is using an

UBM-GMM method. Two versions of the face

verification system are developed. In the first

version, we suppose that only one still-image is

used, while in the second version, system processes

all video frames. The proposed fully automated

ICPRAM 2016 - International Conference on Pattern Recognition Applications and Methods

556

system is evaluated on the MOBIO corpus. The

results show that the full video processing gives a

relative improvement of performance around 10%

for the face system. In addition, the fusion between

face and speaker systems relatively improves the

performance by 30 to 60% comparing to the best

uni-modal system. Additionally, full video

processing decreases number of media where face

could not be found from 25 to 0 files for enrolment

data and from 118 to 9 for test data. Potentially, it

allows using more medias for score fusion and

improves overall system performance.

After verifying our bi-modal system on the

publically available mobile data corpus (MOBIO),

we develop an iPad prototype bi-modal biometric

application (demo video is available at

https://vid.me/wPJk). This application performs bi-

modal biometric user verification in a time of

around 3s.

Future works will be dedicated to conduct more

experiments with bi-modal verification with full

video processing on a mobile device using existing

iPad prototype application. Moreover, different

quality measures to select frame subset (such as

“mouth close” and “eyes open”,) will be tested to

improve the verification results.

ACKNOWLEDGEMENTS

This work is partially supported by the FUI 15

Equip’Age and H2020-DS-02-2014 SpeechXRays

projects.

REFERENCES

Bonastre, J., Scheffer, N., Matrouf, D., Fredouille, C.,

Larcher, A., Preti, A., Pouchoulin, G., Evans, N.,

Fauve, B., and Mason, J. (2008). Alize/spkdet: a state

of-the-art open source software for speaker

recognition. In The Speaker and Language

Recognition Workshop, Odyssey.

Cootes, T. F., Taylor, C. J., Cooper, D. H., and Graham, J.

(1995). Active shape models their training and

application. In Computer Vision and Image

Understanding, pages 38–59.

Gravier, G. (2009). Spro: Speech signal processing toolkit,

release 4.1.

Khoury, E., Vesnicer, B., Franco-Pedroso, J., Violato, RP.,

Boulkenafet, Z., Mazaira Fernandez, L.M., Diez, M.,

Kosmala, J., Khemiri, H., Cipr, T., Saedi, R., Gunther,

M., Zganec-Gros, J., Zazo Candil R., Simoes F.,

Bengherabi, M., Alvarez Marquina, A., Penagarikano,

M., Abad, A., Boulaymen, M., Schwarz, P., van

Leeuwen, D., Gonzalez-Dominguez, J., Uliani Neto,

M., Boutellaa, E., Gomez Vilda, P., Varona, A.,

Petrovska-Delacrétaz, D., Matejka, P., Gonzalez-

Rodriguez, J., De Freitas Pereira, T., Harizi, F.,

Rodriguez-Fuentes, L.J., El Shafey, L., Angeloni, M.,

Bordel, G., Chollet, G., and Marcel, S., (2013). The

2013 speaker recognition evaluation in mobile

environment, In ICB '13 : The 6th IAPR International

Conference on Biometrics.

Lowe, D. G. (2000). Distinctive image features from

scale-invariant keypoints. International Journal of

Computer Vision, 60:91–110.

McCool, C., Marcel, S., Hadid, A., Pietikainen, M.,

Matejka, P., Cernocky, J., Poh, N., Kittler, J., Larcher,

A., Levy, C., Matrouf, D., Bonastre, J.-F., Tresadern,

P., and Cootes, T. (2012). Bi-modal person

recognition on a mobile phone: Using mobile phone

data. In Multimedia and Expo Workshops (ICMEW),

2012 IEEE International Conference on, pages 635–

640.

Petrovska-Delacrétaz, D., Chollet, G., and Dorizzi, B.

(2009). Guide to Biometric Reference Systems and

Performance Evaluation. Springer Verlag.

Reynolds, D., Quatieri, T., and Dunn, R. (2000). Speaker

verification using adapted gaussian mixture models.

Digital Signal Processing, 10(13):19 – 41.

Stegmann, M. B., Ersbll, B. K., and Larsen, R. (2003).

Fame a flexible appearance modelling environment.

IEEE Trans. On Medical Imaging, 22(10):1319–

1331–110.

Zhou, D., Petrovska-Delacrétaz, D., and Dorizzi, B.

(2009). Automatic landmark location with a combined

active shape model. In International Conference on

Biometrics: Theory, Applications, and Systems, pages

1–7.

MacLean, K., VoxForge (2012). Ken MacLean. [Online].

Available: http://www.voxforge.org/home.

Phillips, P. J., Flynn, P. J., Scruggs, T., Bowyer, K. W.,

Chang, J., Hoffman, K., ... & Worek, W. (2005, June).

Overview of the face recognition grand challenge. In

Computer vision and pattern recognition, 2005. CVPR

2005. IEEE computer society conference on (Vol. 1,

pp. 947-954). IEEE.

Full Video Processing for Mobile Audio-Visual Identity Veriﬁcation

557
