A Priori Data and A Posteriori Decision Fusions for Human Action

Recognition

Julien Cumin and Gr

egoire Lefebvre

Orange Labs, R&D, Meylan, France

Keywords:

Action Recognition, Decision Fusion, Voting Methods, Dempster-Shafer Theory, Possibility Theory.

Abstract:

In this paper, we tackle the challenge of human action recognition using multiple data sources by mixing a pri-

ori data fusion and a posteriori decision fusion. Our strategy applied from 3 main classiﬁers (Dynamic Time

Warping, Multi-Layer Perceptron and Siamese Neural Network) using several decision fusion methods (Vot-

ing, Stacking, Dempster-Shafer Theory and Possibility Theory) on two databases (MHAD (Oﬂi et al., 2013)

and ChAirGest (Rufﬁeux et al., 2013)) outperforms state-of-the-art results with respectively 99.85% ± 0.53

and 96.40% ± 3.37 of best average correct classiﬁcation when evaluating a leave-one-subject-out protocol.

1 INTRODUCTION

In the last decades, human action recognition based

on inertial or visual data sources has been an active

area of research due to its success in robotics, video

games, surveillance, etc. Nevertheless, some chal-

lenging difﬁculties still exist, caused by what is called

the “3V” issues (IBM et al., 2011): the action Veloc-

ity, the action Variety and the action Volume.

Action recognition requires instantaneous re-

sponses from the system, moreover if it is an interac-

tive application where actions are used as interaction

controllers. In this regard, the velocity of data gen-

eration is a major problem, imposing constraints of

execution times on algorithms.

Moreover, there is great variability about the way

people produce actions. Dynamic variations occur

when people produce intense or phlegmatic, slow or

fast gestures. Different shapes, orientations and di-

rections may then be captured from body trajectories.

These variations exist between people but also for a

single user producing the same set of actions (e.g. hu-

man ability, left or right-handed, on the move, in dif-

ferent use contexts, etc.).

Finally, volumetric variations are challenging as

well, ranging from one user in a close world paradigm

to multi-users in an open world paradigm.

Consequently, when designing a pattern recogni-

tion system, several steps are needed to deal with

these issues: processing input data in order to reduce

noise and to enhance salient information, clustering

data to reduce the dimensionality of the problem, and

learning a speciﬁc action classiﬁer.

In this paper, we propose a human action clas-

siﬁcation system mixing a priori data fusion and a

posteriori decision-level fusion (i.e. classiﬁer fusion)

methods.

This paper is organized as follows. In Section 2,

we present some main literature methods on action

recognition and decision fusion. In Section 3, we

explain in details our fusion strategy. Then, Section

4 shows our experimental conﬁgurations and results.

Finally, our conclusions are drawn and perspectives

are presented in the last section.

2 STATE OF THE ART

2.1 Action Recognition

Human action recognition has been deeply studied for

the past ten years. Some studies are based on iner-

tial sensors, others on visual skeleton acquisitions, or

sometimes both simultaneously.

Based on inertial data, three main strategies can

be identiﬁed. The ﬁrst action recognition strategy re-

lies on similarity metrics between unknown actions

to be classiﬁed and class reference instances. One

main representative (Akl and Valaee, 2010) is a model

constructed from the Dynamic Time Warping (DTW)

similarity distance and a K Nearest Neighbor (KNN)

classiﬁer. Others studies by (Berlemont et al., 2015)

proposed a non-linear metric learning strategy based

Cumin, J. and Lefebvre, G.

A Priori Data and A Posteriori Decision Fusions for Human Action Recognition.

DOI: 10.5220/0005680204930500

In Proceedings of the 11th Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2016) - Volume 4: VISAPP, pages 493-500

ISBN: 978-989-758-175-5

493

on Siamese Neural Networks (SNN). The second

strategy consists in a statistic modeling approach with

Hidden Markov Models (HMM), as in (Pylv

ainen,

2005) in order to model correlations between tempo-

ral data samples. Finally, the last strategy implies ma-

chine learning methods in order to model class fea-

tures, such as Support Vector Machines (SVM) (Wu

et al., 2009), Bayesian Networks (Cho et al., 2006) or

Recurrent Neural Networks (Lefebvre et al., 2015).

Using visual feature data, these three main strate-

gies are still relevant. Firstly, (Zhou and De la

Torre Frade, 2012) present a Generalized Time Warp-

ing (GTW) algorithm, which is an extension of the

DTW algorithm to temporally align multi-modal se-

quences from multiple subjects performing similar

activities. Secondly, (Xia et al., 2012) present an ap-

proach for human action recognition with histograms

of 3D joints locations. These features are projected

using Linear Discriminant Analysis (LDA) and clus-

tered into several posture visual words. The tempo-

ral evolutions of those visual words are then modeled

by a discrete HMM. Thirdly, a study by (Vemulapalli

et al., 2014) uses a SVM classiﬁer to build an ac-

tion recognition system. Their approach is based on

a skeletal representation modeling the 3D geometric

relationships between body parts using rotations and

translations in 3D space. Since 3D rigid body motions

are members of the Special Euclidean group SE(3),

human actions can be modeled as curves in this Lie

group.

These previous strategies focus on one sensor and

one classiﬁer to increase action recognition rates.

This can be viewed as a classiﬁer selection. Few stud-

ies take into account multi-modal sources and several

classiﬁers to build a more robust system. (Chen et al.,

2015) present a two-level fusion approach based on

two modality sensors consisting of a depth camera

and an inertial body sensor. In the feature-level fu-

sion, features generated from the two differing modal-

ity sensors are merged before classiﬁcation. In the

decision-level fusion, outcomes from two classiﬁers

are combined with decision fusion (in their article, us-

ing Dempster-Shafer Theory (DST)).

Inspired by this recent study, we propose to fuse

a posteriori decisions taken by classiﬁers, on the one

hand from individual data, and on the other hand from

a priori combined data.

2.2 Decision Fusion

In the following (see Figure 1), we assume that the ﬁ-

nal classiﬁcation should be made between c

classes,

with i ∈ {1, . . . , I}. We have available C

classi-

ﬁers, with j ∈ {1, . . . , J}, each giving a decision x

i,k

∈

[0, 1] for a class c

about a gesture instance G

, k ∈

{1, . . . , K}. A decision x

i,k

closer to 1 indicates a high

conﬁdence that the instance belongs to the class c

whereas a decision closer to 0 indicates a low conﬁ-

dence. The ﬁnal decision taken by the decision fusion

method is denoted as c

classiﬁer. Others studies by (Berlemont et al., 2015)

proposed a non-linear metric learning strategy based

on Siamese Neural Networks (SNN). The second

strategy consists in a statistic modeling approach with

Hidden Markov Models (HMM), as in (Pylv

ainen,

2005) in order to model correlations between tempo-

ral data samples. Finally, the last strategy implies ma-

chine learning methods in order to model class fea-

tures, such as Support Vector Machines (SVM) (Wu

et al., 2009), Bayesian Networks (Cho et al., 2006) or

Recurrent Neural Networks (Lefebvre et al., 2015).

Using visual feature data, these three main strate-

gies are still relevant. Firstly, (Zhou and De la

Torre Frade, 2012) present a Generalized Time Warp-

ing (GTW) algorithm, which is an extension of the

DTW algorithm to temporally align multi-modal se-

quences from multiple subjects performing similar

activities. Secondly, (Xia et al., 2012) present an ap-

proach for human action recognition with histograms

of 3D joints locations. These features are projected

using Linear Discriminant Analysis (LDA) and clus-

tered into several posture visual words. The tempo-

ral evolutions of those visual words are then modeled

by a discrete HMM. Thirdly, a study by (Vemulapalli

et al., 2014) uses a SVM classiﬁer to build an ac-

tion recognition system. Their approach is based on

a skeletal representation modeling the 3D geometric

relationships between body parts using rotations and

translations in 3D space. Since 3D rigid body motions

are members of the Special Euclidean group SE(3),

human actions can be modeled as curves in this Lie

group.

These previous strategies focus on one sensor and

one classiﬁer to increase action recognition rates.

This can be viewed as a classiﬁer selection. Few stud-

ies take into account multi-modal sources and several

classiﬁers to build a more robust system. (Chen et al.,

2015) present a two-level fusion approach based on

two modality sensors consisting of a depth camera

and an inertial body sensor. In the feature-level fu-

sion, features generated from the two differing modal-

ity sensors are merged before classiﬁcation. In the

decision-level fusion, outcomes from two classiﬁers

are combined with decision fusion (in their article, us-

ing Dempster-Shafer Theory (DST)).

Inspired by this recent study, we propose to fuse

a posteriori decisions taken by classiﬁers, on the one

hand from individual data, and on the other hand from

a priori combined data.

2.2 Decision Fusion

In the following (see Figure 1), we assume that the ﬁ-

nal classiﬁcation should be made between c

classes,

with i 2 {1,...,I}. We have available C

classi-

ﬁers, with j 2 {1,...,J}, each giving a decision x

i,k

[0, 1] for a class c

about a gesture instance G

, k 2

{1,...,K}. A decision x

i,k

closer to 1 indicates a high

conﬁdence that the instance belongs to the class c

whereas a decision closer to 0 indicates a low conﬁ-

dence. The ﬁnal decision taken by the decision fusion

method is denoted as c

1,k

I,k

...

1,k

I,k

...

1,k

I,k

...

Decision

Fusion

Figure 1: The decision fusion process.

2.2.1 Voting Methods

Voting methods are based on the following principle:

each classiﬁer C

adds a vote V

for each class c

. The

class decided by the fuser is then the one that collects

the most votes. In case of a tie, a class at random from

those with the most votes is chosen.

Voting by Majority (VM) C

adds a vote of 1 for

the class it has the most conﬁdence in (i.e. the class

for which x

i,k

is closest to 1), and a vote of 0 for all

other classes.

Voting by Borda Count (VBC) C

adds a vote of

P 2 {1,...,I} for the class it has the most conﬁdence

in, P1 for the second most conﬁdent class, . . . , 1 for

the P

most conﬁdent class, and 0 for all remaining

classes for which it has less conﬁdence. If P = 1, this

VBC method is identical to VM.

Weighted Votes (VW) C

adds a vote of V

j(x

i,k

), with j a weighting function, taking into ac-

count the decision value. As in the Borda Count vot-

ing method, only the P 2 {1,...,I} classes the clas-

siﬁer has the most conﬁdence in can vote, while the

remaining classes receive a vote of 0.

Voting by Kumar and Raj (VK) A weighted vote

approach is also presented by (Kumar and Raj, 2015).

We deﬁne the positive set X

(i.e. instances belong-

ing to a class c

), the negative set X



(i.e. instances

Figure 1: The decision fusion process.

2.2.1 Voting Methods

Voting methods are based on the following principle:

each classiﬁer C

adds a vote V

for each class c

. The

class decided by the fuser is then the one that collects

the most votes. In case of a tie, a class at random from

those with the most votes is chosen.

Voting by Majority (VM) C

adds a vote of 1 for

the class it has the most conﬁdence in (i.e. the class

for which x

i,k

is closest to 1), and a vote of 0 for all

other classes.

Voting by Borda Count (VBC) C

adds a vote of

P ∈ {1, . . . , I} for the class it has the most conﬁdence

in, P −1 for the second most conﬁdent class, . . . , 1 for

the P

most conﬁdent class, and 0 for all remaining

classes for which it has less conﬁdence. If P = 1, this

VBC method is identical to VM.

Weighted Votes (VW) C

adds a vote of V

ϕ(x

i,k

), with ϕ a weighting function, taking into ac-

count the decision value. As in the Borda Count vot-

ing method, only the P ∈ {1, . . . , I} classes the clas-

siﬁer has the most conﬁdence in can vote, while the

remaining classes receive a vote of 0.

Voting by Kumar and Raj (VK) A weighted vote

approach is also presented by (Kumar and Raj, 2015).

We deﬁne the positive set X

(i.e. instances belong-

ing to a class c

), the negative set X

−

(i.e. instances

belonging to all the other classes) and β ∈ R a regu-

larization parameter. x

i,k

is set to 0 if c

is not the best

decided class for C

(meaning only the best class for

VISAPP 2016 - International Conference on Computer Vision Theory and Applications

494

each classiﬁer is voting) and the total number of votes

of a class c

is then:

∑

i=1

i,k

, where (1)

i,k

= argmax

|R(x

i,k

, w)|, with (2)

R(x

i,k

, w) =

−

∑

u∈X

−

1 + e

−βw

i,u

−x

i,k

)

−

∑

u∈X

1 + e

−βw

i,k

−x

i,u

)

. (3)

2.2.2 Stacking Methods

Stacking methods (Wolpert, 1992) are based around

the fact that decision fusion is equivalent to a classiﬁ-

cation task: a fusion classiﬁer has to correctly classify

an instance using the decisions of initial classiﬁers as

inputs. We then build a feature vector to be learnt

by stacking methods as the concatenation of the ﬁrst-

level decisions. The fusion classiﬁer can be trained

on the same data set that was used to train the initial

classiﬁers. A multitude of different classiﬁers can be

used to perform stacking. We use two in this paper:

MultiLayer Perceptron and Support Vector Machine,

respectively referenced by SMLP and SSVM in the

experimental section (see section 4).

2.2.3 Dempster-Shafer Theory (DST)

Dempster-Shafer Theory, also called Evidence The-

ory, models data uncertainty and imprecision with

what is called mass functions.

Let Θ = {c

, c

, . . . , c

} be the set of classes of

the problem, and let 2

= {

0, {c

}, {c

, c

}, {c

, c

}, . . . , Θ} be the power set of Θ. We de-

ﬁne a mass function m

associated to a source C

, as

follows:

: 2

7−→ [0, 1],

∑

A∈2

(A) = 1. (4)

In practice here, we use :

(A) =







i,k

∑

j=1

i,k

if A = {c

}

0 otherwise

. (5)

We can combine the mass functions of all classi-

ﬁers into a single mass function m. Using Smets’

combination rule (Smets, 1990), we have:

∀A ∈ 2

, m(A) =

∑

∩...∩B

∏

j=1

). (6)

The decided class c

is then the one that maxi-

mizes the plausibility function Pl:

= argmax

,i∈{1,...,I}

Pl({c

}) (7)

= argmax

,i∈{1,...,I}





∑

B∈2

,B∩{c

}6=

m(B)





. (8)

2.2.4 Possibility Theory (PT)

Possibility Theory, like DST, is aimed at modeling un-

certainty and imprecision in data, based on the theory

of fuzzy sets.

Let π

= {µ

1,k

, . . . , µ

I,k

} be the set of membership

degrees of an instance G

to classes c

with classiﬁer

. The decided class c

is here the one with the max-

imum merged membership degree µ

d,k

, as in Equation

= argmax

i∈{1,...,I}

(µ

i,k

). (9)

As in (Fauvel et al., 2007), µ

i,k

can be evaluated

as:

i,k

∑

j=1

i,k

)

, where (10)

∑

p=0, p6= j

0,5

(π

)

(J − 1)

∑

p=0

0,5

(π

)

, and where (11)

(π

) =

−2α

∑

i=1

(µ

i,k

)

(1 − µ

i,k

)

. (12)

3 OUR STRATEGY

Suppose we have 3 data sources A, B and C to record

an instance we want to classify (in our case, a hu-

man action), and suppose we have 2 classiﬁers C

and

at our disposal. A basic decision fusion approach

to classify one instance would be to naively combine

(e.g. concatenate) the data produced by the 3 sources

into data ABC, and then classify the instance using C

and C

on this new combined data. The 2 sets of de-

cisions X

ABC

and X

ABC

are then combined with any of

the decision fusion methods presented in 2.2 to obtain

the ﬁnal class label of the instance. This is the strategy

we will call a priori fusion in this paper. Rather than

A Priori Data and A Posteriori Decision Fusions for Human Action Recognition

495

naively combining data a priori, we can also directly

use C

and C

on A, B and C independently, resulting

in 6 sets of decisions: X

, X

and X

which we will denote A + B +C. This is the strategy

we will call a posteriori fusion in this paper. We could

have also only combined two data sources (AB or AC

or BC), each resulting in two sets of decisions.

We propose to use all those different approaches

simultaneously in the decision fusion process. Rather

than feeding a decision fusion method with only 2 sets

of decisions on ABC, or 6 sets of decisions on A +

B +C, we can use A + B +C + AB + AC + BC + ABC,

resulting in 14 sets of decisions to combine. This ap-

proach only exploits available data and does not re-

quire to use any additional source.

This strategy is motivated by the idea that some

data sources can be more discriminant for certain

classes than others. For example, for an action con-

sisting of a hand rotation around the axis of the fore-

arm, the skeleton data will probably not describe the

gesture well, because the skeleton is itself the axis of

rotation. A gyrometer or accelerometer sensor placed

on the hand of the user, on the other hand, will pro-

duce data that will feature well the gesture since it

will be subject to the rotation of the hand. Con-

versely, there can be actions that would be easily de-

scribed with skeleton data, while inertial data would

be less useful to classiﬁers. If we combine a pri-

ori both of those data sources, the classiﬁers can use

both information to reach better classiﬁcation perfor-

mances than when using only one of the sources, but

the task of identifying which of the two data is more

helpful to classify this speciﬁc instance relies only on

the classiﬁers. Using decisions taken on data fused a

priori, as well as on each data source independently,

the task of identifying which data is helpful to clas-

sify the instance is shared between the classiﬁers and

the decision fusion method, since it now has access

to decisions taken on each data source independently.

While the use of decisions taken on each data source

independently may worsen the classiﬁcation rates of

the decision fusion method for certain classes that are

well featured by all sources, we believe it can signif-

icantly improve the rates of classiﬁcation of the de-

cision fusion method for classes that are only well-

captured by some sources, and weakly featured by

others.

This process can thus exploit the complementarity

of data sources, which will better discriminate classes

depending on their nature (e.g. accelerations vs joint

trajectories) or their placement (e.g. two accelerome-

ters placed on the hand and on the hip will not equally

discriminate a hand rotation).

4 EXPERIMENTAL RESULTS

4.1 Experiments on MHAD

Figure 2: Snapshots from all the actions available in the

Berkeley MHAD displayed together with the correspond-

ing point clouds obtained from the Kinect depth data. Ac-

tions (from left to right): jumping, jumping jacks, bending,

punching, waving two hands, waving one hand, clapping,

throwing, sit down/stand up, sit down, stand up.

The Berkeley MHAD (Multimodal Human Action

Database (Oﬂi et al., 2013), see Figure 2) contains 11

actions performed by 7 male and 5 female subjects

in the range 23-30 years of age except for one el-

derly subject. All the subjects performed 5 repetitions

of each action, yielding about 660 action sequences

which correspond to about 82 minutes of total record-

ing time.

The speciﬁed set of actions consists of the follow-

ing: (1) actions with movement in both upper and

lower extremities (e.g. Jumping in place, Jumping

jacks, Throwing, etc.), (2) actions with high dynam-

ics in upper extremities (e.g. Waving hands, Clapping

hands, etc.), and (3) actions with high dynamics in

lower extremities (e.g. Sit down, Stand up).

4.1.1 Protocols and Method Conﬁgurations

We use a leave-one-subject-out cross-validation pro-

cess to test our fusion strategy. Thus, for each cross-

validation, all samples from 11 subjects (i.e. 605 in-

stances) are used as a training set, and all samples

from the remaining subject constitute the test set (i.e.

55 instances). A validation set is extracted from 10%

of the training set to optimize β of the VK method

(it can also be used to optimize certain parameters of

other fusion methods, which is not done here for the

datasets presented). Thus the training data for the fu-

sion methods only consist of 90% of the actual total

training set.

After some preliminary studies on the available 6

accelerometers data and 27 joints skeleton data, we

keep 4 main data sources to build our system: the left

hand accelerometer (noted A1) and the right hip ac-

celerometer (A4), as in (Chen et al., 2015), as well

VISAPP 2016 - International Conference on Computer Vision Theory and Applications

496

as the right hand joint trajectory (M20) and the left

hand joint trajectory (M27), which are natural joints

to track in an action recognition system.

Our fusion method evaluation is based on 3 main

action classiﬁers: DTW, MLP and SNN. The follow-

ing classiﬁers and decision fusion methods use the

corresponding parameters :

• DTW: low-pass ﬁlter of parameter 0.8 on raw data

and KNN using K=1;

• MLP: ﬁxed input vectors of size 100 from the con-

catenation of normalized raw data, 45 hidden neu-

rons with a learning rate of 0.005 and 200 epochs;

• SNN (Berlemont et al., 2015): ﬁxed input vectors

of size 100 from the concatenation of normalized

raw data, 45 hidden neurons with a learning rate

of 0.00005 and 200 epochs;

• VM: V

= 1;

• VBC: P = 11 voting classes;

• VW : V

= 0.15 +

0.85

1+e

−7.68(x−0.68)

and P = 11 voting

classes;

• VK: β is selected in the set {10

−4

, . . . , 10

} to

maximize classiﬁcation rates on the validation set;

• SMLP (Hall et al., 2009): 45 hidden neurons,

learning rate = 0.2, momentum = 0.1, 100 epochs;

• SSVM (Hall et al., 2009): C = 256, γ = 0.001;

• PT: α = 0.5.

Those parameters were experimentally evaluated

(using the same 10% validation set logic) on a purely

symbolic gesture database containing accelerometer

and gyrometer data only, and were not chosen to be

optimal for the MHAD database (or the ChAirGest

database presented after).

4.1.2 Inertial and Vision-based Classiﬁcation

Table 1 presents the average classiﬁcation rates and

standard deviations on isolated data: A1, A4, M20

and M27. It is remarkable to see that for each data

Table 1: Isolated data: average classiﬁcation rates and stan-

dard deviation for standard decision fusion.

A1 A4 M20 M27

DTW 79.01 ± 10.69 56.54 ± 14.45 88.75 ± 7.55 61.24 ± 8.89

MLP 81.75 ± 9.40 61.10 ± 10.29 89.51 ± 9.27 76.44 ± 11.68

SNN 82.05 ± 9.91 62.76 ± 10.46 91.34 ± 6.74 75.22 ± 10.07

VM 85.39 ± 9.46 65.49 ± 10.84 92.55 ± 7.14 75.53 ± 10.56

VBC 87.81 ± 9.18 61.56 ± 15.04 92.10 ± 7.77 76.44 ± 10.75

VW 85.08 ± 7.60 65.20 ± 10.87 90.42 ± 8.61 76.73 ± 11.39

VK 86.59 ± 9.53 64.90 ± 11.09 92.40 ± 5.61 74.76 ± 9.90

SMLP 84.03 ± 8.09 65.35 ± 12.20 90.58 ± 8.28 79.78 ± 10.50

SSVM 83.72 ± 8.24 64.58 ± 10.14 90.42 ± 8.11 78.41 ± 11.30

DST 83.72 ± 7.75 62.31 ± 10.51 90.27 ± 8.48 77.04 ± 11.40

PT 83.42 ± 8.15 62.47 ± 10.71 90.42 ± 8.47 76.43 ± 11.67

Table 2: Concatenated data: average classiﬁcation rates and

standard deviations on a priori decision fusion.

A1A4 M20M27 A1A4M20M27

VM 82.07 ± 8.43 95.13 ± 4.87 96.64 ± 3.96

VBC 83.73 ± 8.95 94.83 ± 5.14 96.04 ± 3.39

VW 85.39 ± 7.90 93.76 ± 6.12 94.97 ± 5.69

VK 80.86 ± 8.93 94.38 ± 5.61 96.95 ± 3.25

SMLP 87.52 ± 7.77 93.91 ± 6.42 94.81 ± 5.74

SSVM 87.97 ± 7.36 93.61 ± 6.58 94.81 ± 5.76

DST 85.85 ± 6.52 93.91 ± 6.45 94.66 ± 6.07

PT 85.40 ± 7.61 94.06 ± 6.37 94.97 ± 5.46

source, multiple strategies of decision fusion give bet-

ter results than the best ﬁrst-level classiﬁer. For in-

stance, VBC achieves the best results on A1, VM on

A4 and M20, and SMLP on M27 data. The best over-

all classiﬁcation rate is achieved by VM on M20 with

92.55% ± 7.14, which is better than the best original

classiﬁer (SNN) with 91.34% ± 6.74 on M20.

4.1.3 A Priori Data Fusion

Table 2 presents, from concatenated data, the aver-

age classiﬁcation rates and standard deviations of de-

cision fusion methods from 3 classiﬁers (DTW, MLP,

SNN) on A1 and A4 concatenated, on M20 and M27

concatenated, and on A1, A4, M20 and M27 con-

catenated. This table shows that most decision fusion

methods beneﬁt from a priori data concatenation. For

example, SSVM achieves 87.97% ± 7.36 from A1A4

data which is better than the results it obtained on

A1 (87.81% ± 9.18) or A4 (65.49% ± 10.84) (see

Table 1). The methods that show worse classiﬁca-

tion rates are actually weakly impacted compared to

the results on A1, which shows that decision fusion

methods are relatively robust to data that contains

non-discriminative parts. The best overall classiﬁca-

tion rate is achieved by VK on all concatenated data

A1A4M20M27 with 96.95% ± 3.25.

4.1.4 A Posteriori Classiﬁer Fusion

Table 3 presents, from separated data, the average

classiﬁcation rates and standard deviations with clas-

Table 3: Separated data: average classiﬁcation rates and

standard deviations on a posteriori decision fusion.

A1+A4 M20+M27 A1+A4+M20+M27

VM 90.11 ± 6.60 91.35 ± 8.24 98.18 ± 2.01

VBC 89.04 ± 7.62 91.95 ± 7.38 97.71 ± 3.22

VW 92.09 ± 5.63 94.98 ± 5.33 99.39 ± 1.11s

VK 92.54 ± 5.08 95.90 ± 4.32 96.34 ± 3.02

SMLP 91.02 ± 5.79 94.82 ± 5.50 98.32 ± 2.21

SSVM 90.41 ± 5.13 93.45 ± 6.36 98.17 ± 2.32

DST 88.89 ± 8.03 94.08 ± 6.28 96.66 ± 4.35

PT 91.33 ± 5.18 94.68 ± 5.43 98.93 ± 1.67

A Priori Data and A Posteriori Decision Fusions for Human Action Recognition

497

siﬁer fusion methods. A posteriori decision fusion

gives here better average classiﬁcation rates for each

conﬁguration. For instance, when we fuse ﬁrst-level

classiﬁer decisions on separated M20 and M27 data,

we obtain 95.90% ± 4.32 for VK, which is higher

than 95.13% ± 4.87 presented before (see Table 2) on

M20M27 concatenation.

4.1.5 Mixed Fusion Strategies

Table 4 presents our strategy from mixed data us-

ing both a priori data and a posteriori decision fu-

sion. The best average classiﬁcation rate is reached

at 99.85% ± 0.53 by the VW decision fusion method

on separated data (A1+A4+M20+M27), plus partially

concatenated data (A1A4+M20M27), plus all con-

catenated data (A1A4M20M27). These results are

signiﬁcantly better than 99.39% ± 1.11 presented in

Table 3.

Table 4: Mixed data: Average classiﬁcation rates and stan-

dard deviations of decision fusion methods from 3 classi-

ﬁers (DTW, MLP, SNN) on A1, A4, M20 and M27 mixed.

A1+A4+M20+M27

+A1A4+M20M27

A1+A4+M20+M27

+A1A4+M20M27

+A1A4M20M27

VM 98.48 ± 2.43 98.94 ± 2.12

VBC 98.63 ± 2.93 98.78 ± 2.73

VW 99.24 ± 1.20 99.85 ± 0.53

VK 96.80 ± 3.13 97.56 ± 2.85

SMLP 99.24 ± 2.62 99.09 ± 2.63

SSVM 98.78 ± 2.73 99.09 ± 2.63

DST 97.57 ± 4.99 97.87 ± 4.51

PT 98.93 ± 2.74 99.54 ± 1.13

4.1.6 Previous Published Results

(Chen et al., 2015) propose on this database a fu-

sion approach based on two differing modality sen-

sors (depth and inertial data). Their best results for

a leave-one-subject-out evaluation is a classiﬁcation

rate of 99.54% fusing Kinect depth stream and A1

and A4 inertial sensors data with a SRC (Sparse Rep-

resentation Classiﬁer) method. Our strategy is conse-

quently challenging with 99.85% ± 0.53 correct clas-

siﬁcation at best. We then prove on a second dataset

the repeatability of our strategy.

4.2 Experiments on ChAirGest

The ChAirGest Dataset (Rufﬁeux et al., 2013)

contains 6 hours of continuous multi-modal record-

ings. Data have been acquired from a Kinect camera

and 4 Inertial Motion Units (IMUs) attached to the

right arm of the subject (see Figure 3). The dataset

Figure 3: Two sample images captured by the Kinect RGB

stream, where 4 IMUs are ﬁxed on the participant’s arm.

contains 10 different gestures, started from 3 different

resting postures and recorded in two different lighting

conditions by 10 different subjects. The 10 gestures

considered in the corpus are the following: Swipe

left, Swipe right, Push to screen, Take from screen,

Palm-up rotation, Palm-down rotation, Draw a circle

I, Draw a circle II, Wave hello and Shake hand.

4.2.1 Protocols and Method Conﬁgurations

As in the previous experiment, we use a leave-one-

subject-out cross-validation to test our system. Thus,

for each cross-validation, all samples from 9 subjects

(i.e. 450 instances) are used as a training set, and all

samples from the remaining subject constitute the test

set (i.e. 50 instances). Classiﬁers and fusion meth-

ods conﬁgurations are identical to the ones used on

MHAD, described in section 4.1.1. We use here the 4

accelerometers data (A1, A2, A3 and A4) and 3 joint

skeleton data K2, K6, and K10, corresponding respec-

tively to the head, the left hand and the right hand.

4.2.2 Our Results

Table 5: Accelerometer data: Average classiﬁcation rates

and standard deviations.

A1A2A3A4 A1+A2+A3+A4

VM 76.40 ± 11.23 87.00 ± 6.48

VBC 79.40 ± 9.93 89.00 ± 5.35

VW 75.80 ± 10.26 87.40 ± 4.90

VK 77.20 ± 10.63 82.20 ± 4.85

SMLP 81.40 ± 9.89 83.20 ± 6.74

SSVM 73.20 ± 8.95 78.20 ± 7.20

DST 57.40 ± 9.52 79.00 ± 9.20

PT 64.20 ± 7.97 82.80 ± 5.27

Table 5 shows a comparison between a priori

data and a posteriori decision fusion based on 4 ac-

celerometers. The best average classiﬁcation rate for

the second approach is VBC with 89.00% ± 5.35,

as opposed to the ﬁrst approach where it is SMLP

with 81.40% ± 9.89. We see that each decision fu-

sion method is signiﬁcantly better on A1+A2+A3+A4

compared to A1A2A3A4, which is a trend that was

already existing on the MHAD dataset.

VISAPP 2016 - International Conference on Computer Vision Theory and Applications

498

Figure 4: Average classiﬁcation rates and standard deviations of classiﬁers on individual data and of decision fusion methods

on A1+A2+A3+A4+K2+K6+K10.

Table 6: Kinect data: Average classiﬁcation rates and stan-

dard deviations.

K2K6K10 K2+K6+K10

VM 93.40 ± 3.27 94.80 ± 3.68

VBC 93.60 ± 3.77 93.60 ± 3.97

VW 93.40 ± 3.53 93.20 ± 3.91

VK 93.80 ± 4.05 94.00 ± 5.33

SMLP 90.40 ± 3.75 92.00 ± 3.89

SSVM 89.80 ± 3.94 91.20 ± 3.68

DST 90.40 ± 4.60 90.20 ± 5.37

PT 90.60 ± 3.78 92.20 ± 4.57

Table 6 proposes similar results on Kinect data

with again better classiﬁcation rates for the second ap-

proach (e.g. 94.80% ± 3.68 for VM) compared to the

ﬁrst one (93.80% ± 4.05 for VK). However, standard

deviations are bigger in the second approach; both ap-

proaches are thus quite equivalent for those data.

Table 7: Mixed data: Average classiﬁcation rates and stan-

dard deviations.

A1A2A3A4

K2K6K10

A1+A2+A3+A4

+K2+K6+K10

A1+A2+A3+A4

+K2+K6+K10

+A1A2A3A4

+K2K6K10

+A1A2A3A4K2K6K10

VM 89.60 ± 6.02 95.40 ± 4.15 96.40 ± 3.37

VBC 90.40 ± 4.88 94.60 ± 4.62 96.20 ± 3.58

VW 88.40 ± 7.35 94.20 ± 3.82 96.20 ± 3.46

VK 89.80 ± 6.14 91.80 ± 4.62 93.20 ± 4.02

SMLP 91.00 ± 4.45 93.60 ± 4.30 95.20 ± 4.13

SSVM 90.00 ± 4.11 92.40 ± 4.20 94.40 ± 3.75

DST 81.20 ± 11.04 88.60 ± 6.47 89.60 ± 6.31

PT 83.00 ± 9.39 93.60 ± 3.86 95.60 ± 3.62

Figure 4 presents means and standard deviations

for each method when applying decision fusion on

separated data A1+A2+A3+A4+K2+K6+K10. It is

remarkable to see that all decision fusion methods but

DST outperform a ﬁrst-level classiﬁer selection. For

instance, the DTW classiﬁer achieves a classiﬁcation

rate of 91.00% ± 4.64 on K6, while VM achieves

95.40% ± 4.12 using all separated data sources.

The ﬁnal results are presented in Table 7. The best

overall average classiﬁcation rate is 96.40% ± 3.37

for the VM method, with our strategy mixing both a

priori data and a posteriori decision fusion.

4.2.3 Previous Published Results

(Cao et al., 2015) published results on the ChAirGest

dataset. With the exact same leave-one-subject-out

cross-validation strategy we used in this paper, they

attain at best a classiﬁcation rate of 91.84% ± 5,76.

Our approach performs signiﬁcantly better for all de-

cision fusion methods, bar DST, with results as high

as 96.40% ± 3.37 for the VM fusion method.

(Yin and Davis, 2013) also published previous re-

sults on the ChAirGest dataset. They attain an average

ﬁnal classiﬁcation rate of 91.16%. Here, our evalua-

tion protocol are quite different (we believe that ours

is more challenging), nevertheless our best conﬁgura-

tion performs better (96.40% ± 3.37).

5 CONCLUSIONS AND

PERSPECTIVES

In this paper, we tackle the challenge of human ac-

tion recognition by mixing a priori data fusion and

a posteriori decision fusion. Our strategy applied

from 3 main classiﬁers (DTW, MLP and SNN) on two

databases (MHAD (Oﬂi et al., 2013) and ChAirGest

A Priori Data and A Posteriori Decision Fusions for Human Action Recognition

499

(Rufﬁeux et al., 2013)) matches or even outperforms

state-of-the-art results. Note that the classiﬁcation

rates consistently increased at each step, from stan-

dard decision fusion all the way up to our mixed fu-

sion strategy, for all decision fusion methods we stud-

ied, which highlights the beneﬁts of our approach.

Our perspectives are to extend our solution to dis-

ambiguate some human actions: two gesture classes

where frontiers are fuzzy (e.g. heart and clockwise

symbolic gestures); two gesture classes where one

source is relevant and the other data source gives no

salient information (e.g. limbs rotations, identiﬁable

by inertial systems but not with skeleton based trajec-

tories); or using both strong and weak classiﬁers, in

order to evaluate the impact of extremely low perfor-

mance classiﬁers on our approach of decision fusion.

REFERENCES

Akl, A. and Valaee, S. (2010). Accelerometer-based gesture

recognition via dynamic-time warping, afﬁnity propa-

gation, & compressive sensing. In IEEE International

Conference on Acoustics, Speech and Signal Process-

ing (ICASSP).

Berlemont, S., Lefebvre, G., Duffner, S., and Garcia, C.

(2015). Siamese neural network based similarity met-

ric for inertial gesture classiﬁcation and rejection.

IEEE International Conference on Automatic Face

and Gesture Recognition.

Cao, C., Zhang, Y., and Lu, H. (2015). Multi-modal

learning for gesture recognition. In Multimedia and

Expo (ICME), 2015 IEEE International Conference

on, pages 1–6.

Chen, C., Jafari, R., and Kehtarnavaz, N. (2015). Improv-

ing human action recognition using fusion of depth

camera and inertial sensors. IEEE Transactions on

Human-Machine Systems, 45(1):51–61.

Cho, S.-J., Choi, E., Bang, W.-C., Yang, J., Sohn, J.,

Kim, D. Y., Lee, Y.-B., and Kim, S. (2006). Two-

stage Recognition of Raw Acceleration Signals for 3-

D Gesture-Understanding Cell Phones. In Lorette, G.,

editor, Tenth International Workshop on Frontiers in

Handwriting Recognition.

Fauvel, M., Chanussot, J., and Benediktsson, J. A. (2007).

Decision fusion for hyperspectral classiﬁcation. John

Wiley & Sons, New York, NY, USA.

Hall, M., Frank, E., Holmes, G., Pfahringer, B., Reutemann,

P., and Witten, I. H. (2009). The weka data mining

software: An update. In SIGKDD Explorations, vol-

ume 11.

IBM, Zikopoulos, P., and Eaton, C. (2011). Understanding

Big Data: Analytics for Enterprise Class Hadoop and

Streaming Data. McGraw-Hill Osborne Media.

Kumar, A. and Raj, B. (2015). Unsupervised fusion weight

learning in multiple classiﬁer systems. CoRR arXiv.

Lefebvre, G., Berlemont, S., Mamalet, F., and Garcia, C.

(2015). Inertial gesture recognition with BLSTM-

RNN. In Artiﬁcial Neural Networks, volume 4

of Springer Series in Bio-/Neuro-informatics, pages

393–410. Springer International Publishing.

Oﬂi, F., Chaudhry, R., Kurillo, G., Vidal, R., and Bajcsy,

R. (2013). Berkeley MHAD: A comprehensive Mul-

timodal Human Action Database. In IEEE Workshop

on Applications of Computer Vision, pages 53–60.

Pylv

ainen, T. (2005). Accelerometer Based Gesture

Recognition Using Continuous HMMs Pattern Recog-

nition and Image Analysis. volume 3522 of Lecture

Notes in Computer Science, chapter 77, pages 413–

430. Berlin, Heidelberg.

Rufﬁeux, S., Lalanne, D., and Mugellini, E. (2013).

ChAirGest: A Challenge for Multimodal Mid-air Ges-

ture Recognition for Close HCI. In Proceedings of the

15th ACM International Conference on Multimodal

Interaction, ICMI ’13, pages 483–488.

Smets, P. (1990). The combination of evidence in the trans-

ferable belief model. IEEE Transactions on Pattern

Analysis and Machine Intelligence, 12(5):447–458.

Vemulapalli, R., Arrate, F., and Chellappa, R. (2014). Hu-

man action recognition by representing 3d skeletons

as points in a Lie group. In The IEEE Conference on

Computer Vision and Pattern Recognition (CVPR).

Wolpert, D. H. (1992). Stacked generalization. Neural net-

works, 5(2):241–259.

Wu, J., Pan, G., Zhang, D., Qi, G., and Li, S. (2009). Ges-

ture recognition with a 3-d accelerometer. In Ubiq-

uitous Intelligence and Computing, volume 5585 of

Lecture Notes in Computer Science, pages 25–38.

Springer Berlin Heidelberg.

Xia, L., Chen, C.-C., and Aggarwal, J. (2012). View invari-

ant human action recognition using histograms of 3d

joints. In IEEE Computer Vision and Pattern Recog-

nition Workshops (CVPRW), pages 20–27.

Yin, Y. and Davis, R. (2013). Gesture spotting and recogni-

tion using salience detection and concatenated hidden

markov models. In Proceedings of the 15th ACM on

International Conference on Multimodal Interaction,

ICMI ’13, pages 489–494.

Zhou, F. and De la Torre Frade, F. (2012). Generalized time

warping for multi-modal alignment of human motion.

In IEEE Conference on Computer Vision and Pattern

Recognition (CVPR).

VISAPP 2016 - International Conference on Computer Vision Theory and Applications

500
