Unsupervised Framework for Interactions Modeling between Multiple

Objects

Ali Al-Raziqi and Joachim Denzler

Computer Vision Group, Friedrich Schiller University of Jena, Jena, Germany

Keywords:

Interaction Detection, Multiple Object Tracking, Unsupervised Clustering, Hierarchical Dirichlet Processes.

Abstract:

Extracting compound interactions involving multiple objects is a challenging task in computer vision due to

different issues such as the mutual occlusions between objects, the varying group size and issues raised from

the tracker. Additionally, the single activities are uncommon compared with the activities that are performed

by two or more objects, e.g., gathering, ﬁghting, running, etc. The purpose of this paper is to address the prob-

lem of interaction recognition among multiple objects based on dynamic features in an unsupervised manner.

Our main contribution is twofold. First, a combined framework using a tracking-by-detection framework for

trajectory extraction and HDPs for latent interaction extraction is introduced. Another important contribu-

tion is the introduction of a new dataset, the Cavy dataset. The Cavy dataset contains about six dominant

interactions performed several times by two or three cavies at different locations. The cavies are interacting

in complicated and unexpected ways, which leads to perform many interactions in a short time. This makes

working on this dataset more challenging. The experiments in this study are not only performed on the Cavy

dataset but we also use the benchmark dataset Behave. The experiments on these datasets demonstrate the

effectiveness of the proposed method. Although the our approach is completely unsupervised, we achieved

satisfactory results with a clustering accuracy of up to 68.84% on the Behave dataset and up to 45% on the

Cavy dataset.

1 INTRODUCTION

Activity recognition is a very important task in com-

puter vision and has many applications such as video

surveillance and animal monitoring systems. Com-

puter vision can help the biologists to understand and

recognize the behavior of animals in the videos. Ac-

tivity recognition can be roughly divided into three

categories. The ﬁrst category is single activity, in

which the activity is performed by only a unique

object without interacting with any other objects

(Ohayon et al., 2013; Guha and Ward, 2012; De-

laitre et al., 2011). In many situations, single activ-

ities are uncommon compared with the activities per-

formed by several active objects e.g. gathering, chas-

ing, ﬁghting, running, etc. The second category is

pair activity which includes the interaction between

two objects. Pair-activity methods can be classiﬁed

into two approaches. The ﬁrst approach performs seg-

menting and tracking the body parts (heads, hands,

legs, etc.) of two objects to discover the interactions

between them e.g. high ﬁve, kiss, hand shake, etc

(Patron-Perez et al., 2010; Dong et al., 2011; Kong

and Jia, 2012; Li et al., 2011). This may be un-

feasible for low image resolution and occlusions in

surveillance videos. In the Cavy dataset which is in-

troduced for the ﬁrst time in this study, it is difﬁcult

to segment cavy parts to discover the interactions be-

tween the cavies. The second category is character-

ized by tracking the whole body of objects to extract

the interactions between objects, e.g. gathering, scat-

tering, leaving, etc (Zhou et al., 2011; Sato and Ag-

garwal, 2004; Blunsden et al., 2007). The third cate-

gory is group activity which refers to the interaction

among multiple objects (two or more objects) within

a speciﬁc distance. In group activity methods, the

scene has to be divided into subgroups, interaction in

each group are then analyzed and recognized, e.g. In-

Group, Approach, WalkTogether, Fight, etc, (Bluns-

den and Fisher, 2009; Cheng et al., 2014; Kim et al.,

2014; Ni et al., 2009; Lin et al., 2010; Yin et al., 2012;

unch et al., 2012; Zhang et al., 2012). Generally,

activities involving multiple active objects are consid-

ered as a group activity. As an example, scattering

activity consists of multiple running individuals.

Figure 1 shows some scenarios where various ob-

jects in a scene are interacting with each other in Cavy

Al-Raziqi, A. and Denzler, J.

Unsupervised Framework for Interactions Modeling between Multiple Objects.

DOI: 10.5220/0005680705090516

In Proceedings of the 11th Joint Conference on Computer Vision, Imaging and Computer Graphics Theory and Applications (VISIGRAPP 2016) - Volume 4: VISAPP, pages 509-516

ISBN: 978-989-758-175-5

509

(a) Approach (b) Fight (c) InGroup

Figure 1: Interactions between multiple persons on the

Cavy and the Behave datasets (Blunsden and Fisher, 2010).

For better visibility, refer to the web version.

Figure 2: A set of frames taken from different views and

different time with changing the illumination.

and Behave datasets (Blunsden and Fisher, 2010).

It can be observed that most of the previous meth-

ods share two common characteristics. First, at a

high level, most of them implement the same frame-

work according to which motion/appearance features

are extracted. Second, supervised machine learning

method are used to classify the interactions. In many

of the activity recognition categories, the number of

involved objects cannot be determined beforehand.

Furthermore, the exact number of activities is usu-

ally a prerequisite for classiﬁcation, which is often

unavailable especially for new videos to be analyzed.

Hence, using an unsupervised method is a necessity

in such situations to extract the interactions.

Our proposed approach incorporates the capabil-

ities of the Hierarchical Dirichlet Processes (HDP)

with spatio-temporal dynamic features based on the

trajectories to tackle the problem of interactions be-

tween objects. The main contribution of this paper is

twofold:

1. A combined framework using a tracking-by-

detection method for trajectory extraction and

Table 1: The dominant interactions performed by two or

three cavies at different locations on the Cavy dataset.

Interaction Description

Approach

One object approaches to

another(s) object(s)

RunTogether Objects walking together

Split Object(s) split from one another

Ingroup

Several objects are close to each

other and with small moving

Fight Objects ﬁghting each other

Follow Object(s) following other

HDPs for latent interaction extraction is intro-

duced.

2. The introduction of the Cavy dataset

, which con-

tains six dominant interactions performed several

times by two or three cavies at different locations

as shown in Figure 2 and table 1.

The Cavy dataset can be useful in many disciplines, in

addition to computer vision, since the dataset is taken

at various time, it may help the biologists to study and

monitor the cavies behavior in speciﬁc periods.

For unsupervised clustering tasks, HDP has been

widely used in many ﬁelds such as text analysis (Teh

et al., 2006), trafﬁc scene analysis and action recogni-

tion (Kuettel et al., 2010; Krishna and Denzler, 2014;

Krishna et al., 2013) and yielded signiﬁcant results.

In this paper, we apply for the ﬁrst time HDP to the

group activity recognition problem.

The rest of this paper is organized as follows. In

Sect. 2 we provide a brief overview of the existing

literature on interaction recognition. Sect. 3 describes

the interaction modeling. Sect. 4 discusses the applied

HDP model, and the corresponding inference proce-

dure. The experiments conducted on the Cavy and the

Behave datasets are described in Sect. 5 along with re-

sults.

2 RELATED WORK

In this work, we focus on the interaction detection

between multiple objects. The related work can be

divided into two categories, supervised and unsuper-

vised learning methods.

Supervised Learning, In (Yang et al., 2013), the au-

thors used a graph framework to analyze the interac-

tion between parts of an object. The body parts and

objects are represented as nodes of graphs, the parts

are tracked to extract the temporal features and the

Available at http://www.inf-cv.uni-jena.de/Group/

Staff/M Sc ++Ali+M +Al Raziqi.html

VISAPP 2016 - International Conference on Computer Vision Theory and Applications

510

network analysis provide the spatial features. They

then use Support Vector Machine (SVM) and a Hid-

den Markov Model to classify the interactions of the

object’s parts. In (Zhou et al., 2011), the authors

analyzed the interaction between objects based on

Granger Causality Test. The GCT causality mea-

sures the effect of the objects on each other. In (Ni

et al., 2009), the authors divided the individuals into

subgroups and cluster them using k-means algorithm.

The causality is analyzed with respect to individual,

pair, and inter-group activity. Finally, classiﬁers such

as Nearest Neighbor (NN) and SVM are used for

group activity classiﬁcation.

Another relevant approach is introduced in (Kim

et al., 2014), where the authors recognize group ac-

tivities by detecting meaningful groups. This is done

by deﬁning Group Interaction Zone (GIZ). Group ac-

tivities in each GIZ can be illustrated by attraction and

repulsion properties which are represented by the rel-

ative distance during k frames. Furthermore, the study

in (Cheng et al., 2014) presented a new approach in

different semantic layers: individual, pair and group.

Motion and appearance features are extracted from

those layers. For the appearance features, Histograms

of Oriented Gradients (HoG) are extracted for each

object in the group and Delaunay triangulation is used

to extract the whole group features.

Unsupervised Learning, In the work presented

in (Al-Raziqi et al., 2014), the authors have devel-

oped an HDP-based interaction extraction approach

in which the optical ﬂow is extracted in the whole

image without object localization or trajectories mo-

tion analysis. Another interesting method which tried

to tackle this problem is described in (Zhu et al.,

2011). The authors extracted features such as ap-

pearance, causality and feedback based on GCT and

leant an extended probabilistic Latent Semantic Anal-

ysis (pLSA). Then, pLSA used to categorize new se-

quences.

Unlike many of the approaches described above,

our approach integrates an unsupervised clustering

method, namely HDP, with optical ﬂow based on mo-

tion trajectories to identify the interactions of multiple

objects without further knowledge.

3 INTERACTIONS MODELING

The interaction is an activity performed by several ob-

jects within a speciﬁc region. Figure 3 shows the main

steps of our approach. In order to perform object in-

teraction modeling, as a preliminary step, a reliable

and accurate tracker is required. Since the objects

in the Cavy dataset are not annotated by bounding

Sequence

Tracking

Flow Words

Extraction

Dictionary

(a) Representation

HDP

Model

Interactions

Bag-of-WordsClips

Flow Word

Count

.....

2540 3

24 12

.....

3568

Flow Word

Count

.....

8560 203

985 102

.....

15840

(b) Clustering

Figure 3: Our framework for interaction detection: (a) Ob-

jects tracking to extract the trajectories, low-level visual fea-

tures inside bounding boxes and build the dictionary with all

possible ﬂow words. (b) Divided the video sequence into

short clips. Local ﬂow motions are computed for each clip.

Each clip is represented by a Bag-of-Words. HDP is used

to extract the interactions between the objects.

boxes (BB), we cannot start with ground truth ob-

ject positions and trajectories, but have to compute

this information from the data itself. This makes the

Cavy data set a very challenging one since the con-

secutive interaction detection step must deal with er-

rors in the previous tracking step. The set of detec-

tions (BB) are generated by background subtraction

method using Gaussian Mixture Model (GMM) pre-

sented in (Zivkovic, 2004).

Due to this simple detection method, errors in the

detection cannot be avoided, such as missing, false,

merging or splitting objects. Examples are shown in

Figure 6. To mitigate the effect of wrong or missing

detections, we apply a two-stage graph method pre-

sented in (Jiang et al., 2012). The result of the track-

ing algorithm are trajectories of all objects, e.g. the

i −th object trajectory is represented from time 1 to k

as: T

= [x

,..., x

], where T

is a sub-trajectory of

the object i

s trajectory in k frames and x

is a center

of mass coordinate (x, y) of a particular object. The

average distance is computed using Euclidean dis-

tance between the sub-trajectories which consists of

the largest value k for which the length of the trajec-

tories of object i equals that of object j.

i, j

||T

− T

|| (1)

Subsequently, optical ﬂow inside the BBs regions

is computed using the TV-L

algorithm (Zach et al.,

2007), if the D

i, j

is below a user deﬁned threshold

Unsupervised Framework for Interactions Modeling between Multiple Objects

511

. This threshold depends on the kind of interactions

to be identiﬁed by the system and is application de-

pended. The video sequence is then divided into short

and equally sized clips without overlap. In each clip,

optical ﬂow is quantized into eight directions (ﬂow

words). The optical ﬂow features can be deﬁned as

X=(x, y, u, v), where (x, y) is the location of a par-

ticular pixel in the image, and (u, v) are the ﬂow val-

ues. Following the approaches are described in (Kuet-

tel et al., 2010; Krishna and Denzler, 2014), all clips

are represented by accumulated ﬂow words over their

frames. Finally, a dictionary is built with all possible

ﬂow words.

4 HIERARCHICAL DIRICHLET

PROCESSES

HDP was ﬁrst presented for clustering words in doc-

uments based on words co-occurrence to infer the la-

tent topics (Teh et al., 2006). Specifying the number

of topics beforehand is impractical. So, in HDP the

number of clusters (topics) is extracted automatically

from the data and a set of hyper-parameters (α, γ and

η). Figure 4 shows the basic HDP model.

For text analysis, the corpus is divided into M sep-

arated documents where each document contains a

set of unordered words N

, denoted as x

m,n

, where

m ∈ [1, M] and n ∈ [1, N

]. Hence, each document is

represented by its words.

In our case, we follow (Krishna and Denzler,

2014; Al-Raziqi et al., 2014; Kuettel et al., 2010),

where the corpus, documents and words correspond

to the video sequence, short equal sized clips, and op-

tical ﬂow respectively. Generally, for a given input

video, optical ﬂow features are extracted from each

pair of successive frames. Then, the video sequence

is divided into short clips. Each clip is represented by

accumulated a Bag-of-Words (see Section 3).

The HDP in this work uses Dirichlet Process (DP)

to infer the interactions at two levels. The global list

of interactions G

is generated in the ﬁrst DP level,

where G

is a prior distribution over the video. In the

second DP, speciﬁc interactions G

are drawn from

the global list G

for each clip. The interactions might

be shared among different G

. Formally, we write the

generative HDP formulation

| γ,H ∼ DP(γ,H)

| α,G

∼ DP(α,G

) for m ∈ [1,M].

(2)

In Eq 2, the hyper-parameters α and γ are called

the concentration parameters and the parameter H is

called the base distribution. Therefore, the observed

words x

m,n

are seen as being sampled from the mix-

ture priors φ

m,n

, which can be interpreted as being

drawn from a DP G

. The values of mixture com-

ponents are drawn from θ

. Consequently, this model

can be written as

∼ P(η) for k ∈ [1, ∞)

m,n

| α,G

∼ G

for m ∈ [i,M],n ∈ [1,N

]

m,n

| φ

m,n

,θ

∼ F(θ

m,n

)

(3)

where M is the number of clips in the video, N

is the

number of words in clip m, P(·) and F(·) are the prior

distribution over topics and words respectively.

Consequently, given the observed ﬂow words,

HDP infers the latent topics (interactions) which is

called Bayesian inference. Following the formulation

of (Krishna et al., 2013), the conditional probability

of the topic-word association for each iteration step is

evaluated as

p(φ

m,n

= k, α,γ,η,θ, H) ∝

¬m,n

m,k

+ αθ

¬m,n

k,t

+ η

¬m,n

+V.η

(4)

where n

m,k

, n

k,t

, and n

represent statistics of the

word-topic, topic-document and the topic-wise word

counts, respectively. The current word x

m,n

must be

excluded from that topic. The size of the dictionary

is represented by V . The probability of assignment

of the current ﬂow word x

m,n

to a particular topic is

relative to the number of words previously associated

with that topic as shown in the ﬁrst term of equation

4. The second term shows the effects of the hyper-

parameters α,γ and η on determining the number of

extracted topics and the possibility of creating a new

topic. In this paper, interactions are interpreted as

ﬂow words which co-occur in the same clip. The

idea is that optical ﬂow measured within the area of

a tracked object represent ﬁne-grained details of the

activity which in combination with the respective ac-

tivity of the other object identiﬁes the interaction.

5 EXPERIMENTS AND RESULTS

For evaluating the performance of our proposed

framework, we performed several experiments on two

different datasets, the Cavy dataset and the bench-

mark dataset Behave (Blunsden and Fisher, 2010) to

illustrate the effectiveness and capability of the HDP

in interaction extraction. Both datasets provide var-

ious challenging interactions of multiple objects as

shown in Figure 1.

As the Cavy dataset does not contain ground truth

in terms of interactions among objects, we marked

VISAPP 2016 - International Conference on Computer Vision Theory and Applications

512

Global interactions

One Interaction

One word

Interactions in clip

Figure 4: HDP model. Dirichlet Processes are used to gen-

erate the global interactions G

and G

which are drawn

from the global G

the semantically meaningful interactions in the scene

(clip-wise annotations). Then, similar to the proce-

dure in (Kuettel et al., 2010; Krishna and Denzler,

2014; Al-Raziqi et al., 2014), the output of our system

is manually mapped to the ground truth labels and the

performance measures are calculated. For the perfor-

mance evaluation, we use the accuracy

Accuracy =

T P + T N

T P + T N + FP + FN

(5)

where TP, FP, FN, and TN are True Positives, False

Positives, False Negatives, and True Negatives re-

spectively.

5.1 Results on Cavy Dataset

The Cavy dataset is a new dataset introduced in this

work. The Cavy dataset contains a variety of con-

ditions that have been taken from a stationary cam-

era. As can be observed in Figure 2, sequences

are recorded from different views with changing il-

lumination and in different periods. It contains

16 sequences with 640 × 480 resolutions recorded

at 7.5 frames per second (fps) with approximately

31621506 frames in total (272 GB). The sequences

are recorded non-synchronously and stored in ppm

format. The Cavy dataset contains six dominant inter-

actions performed several times by two or three cavies

at different locations in the scene. Table 1 shows the

types of the interactions. Some interactions are easy

to distinguish, while others only differ a bit in exe-

cution period, velocity and the number of involved

cavies. In these experiments, we used eight sequences

with a total number of 159358 frames.

Results: As baseline experiments on the Cavy

Table 2: Confusion matrix representing the performance of

the HDP on the Cavy dataset.

A 0.5 0.03 0.05 0.00 0.00 0.00 0.41 61

S 0.01 0.28 0.03 0.00 0.01 0.00 0.67 75

I 0.03 0.01 0.4 0.00 0.02 0.00 0.54 373

FO 0.00 0.25 0.00 0.63 0.00 0.00 0.13 8

F 0.02 0.00 0.1 0.00 0.35 0.00 0.52 48

R 0.00 0.17 0.00 0.00 0.00 0.50 0.33 6

N 0.06 0.01 0.14 0.00 0.05 0.03 0.71 403

A S I FO F R N #

dataset, we ﬁrst extract trajectories of objects and dy-

namic features. As next step, the optical ﬂow is com-

puted inside the bounding boxes. Then, HDP is used

to extract the global interactions in the video. As next

step, the optical ﬂow is computed inside the bounding

boxes.

For qualitative analysis of our method, Figure 5

shows the interactions extracted by the HDP model.

In Figure 5(a), interaction interpreted as one cavy ap-

proaches another one. Figure 5(b) represents one cavy

follows another one. Figure 5(c) shows two objects

are ﬁghting each other. This wrong result is caused by

the detection error (split bounding box). Figure 5(d)

shows two objects close to each other (InGroup). The

interactions are performed by two or three cavies in

k frames and represented by ﬂow words co-occurring

in the same clip.

Also we studied the effect of the hyper-parameters

of HDP (α and η) on the number of the extracted

interactions as depicted in Figure 7 (a). The hyper-

parameters (α and η) values ranging from 0.1 to 2,

and the clip length is 150 frames. As mentioned,

the hyper-parameter values control the number of ob-

tained topics (in our case interactions). As notice

from Figure 7 (a), the number of extracted interac-

tions has ﬂuctuated signiﬁcantly with increasing the

hyper-parameter values especially η. This is due to

the fact that the hyper-parameter η controls the prob-

ability of generating new interactions. It is crucial

mentioning that increasing the values of η does not al-

ways lead to the generation of new interactions. This

is likely due to the randomness in the Bayesian infer-

ence step.

Table 2 shows the quantitatively evaluation for the

selected interactions, Approach (A), Split (S), RunTo-

gether (R), Fight (F), InGroup (I), Follow (FO), No

(N). We add the ﬁeld (No) which represents the false

positive and false negative of the particular interac-

tion, where the ground truth does not contain that in-

teraction. The last column in Table 2 represents the

number of instances of each category in the ground

truth.

In this experiment, the video divided into clips of

150 frames which achieved an average clustering of

up to 45 %. It is clear that there are different factors

Unsupervised Framework for Interactions Modeling between Multiple Objects

513

i-1

Trajectories

(a) Approach

(b) Follow

(d) InGroup

Figure 5: The Cavy dataset. Illustration of different interac-

tions occur in k successive frames. Each row represents one

interaction extracted by HDP. The trajectories correspond

to the interactions. For better visibility, refer to the web

version.

that have an effect on the results, such as errors raised

from detector and tracker (missing, false, merged or

splitted objects) as shown in Figure 6. More precisely,

missing and merged object(s) issues lead to decrease

the TP, whereas the false detection increases the FP.

For instance, as can observed from Table 2, the high-

est false positive ratio is detected for the Split interac-

tion, while the interaction is not found in the ground

truth. Consequently, our method showed lower per-

formances for the Split interaction. Additionally, the

optical ﬂow is probably not helpful in case of the ﬁxed

objects which leads to increase the false negative. All

of these factors lead to degraded the performance of

our approach.

5.2 Results on Behave Dataset

Also we used the Behave dataset (Blunsden and

Fisher, 2010). Behave dataset consists of four video

sequences, and 76,800 frames in total and recorded

at 25 frames per second with a resolution of 640 ×

480 pixels. The Behave dataset provides different

challenging interactions include: InGroup, Approach,

WalkTogether, Split, Ignore, Following, Chase , Fight,

RunTogether, and Meet. The number of objects in-

volved in the interaction ranging from two to ﬁve.

Due to the limited number of annotated frames, (Kim

et al., 2014; Yin et al., 2012; Zhang et al., 2012;

unch et al., 2012) used subsets of the categories to

demonstrate the performance of their methods. How-

(a) Split (b) False

Figure 6: Illustration of the main tracking issues. (a) Split

object, which leads to discover interaction interpreted as

following. (b) Non-cavies object detected as cavy (false),

HDP discovers an interaction as gathering or as leaving. (c)

Missing of detecting and (d) Merge objects, in these cases

HDP will not be able to discover the interaction.

0.1

0.5

1.5

(a) Cavy dataset

# of interactions

0.1

0.5

1.5

(b) Behave dataset

# of interactions

Figure 7: Effects hyper-parameters α, η on number of ex-

tracted interactions. In each experiment, we change one of

the hyper-parameters while the other is held constant at 0.5

and vice versa. The clip size is 150 frames.

ever, we use the same subsets to compare our ap-

proach with their methods. In this study, we divided

the sequences into clips with size 150 frames and only

analyze clips for which ground truth are available. It

must be mentioned that Meet and Ignore categories

found just once and twice in the ground truth respec-

tively. Hence, these categories are excluded.

Results: Qualitatively, Figure 8 shows the set of

the probable interactions in one sequence. As ob-

served in Figure 8(a), one object follows another one

from the left corner to the right corner. Figure 8(b)

interpreted as one object approaches from the left cor-

ner to join other objects (converge to center). In Fig-

ure 8(c), the group splitted into two groups each one

VISAPP 2016 - International Conference on Computer Vision Theory and Applications

514

i-1

Trajectories

(a) Follow

(b) Approach

(d) Fight

Figure 8: Illustration of different interactions occur in k suc-

cessive frames.Each row represents one interaction, last col-

umn represents the extracted interaction using HDP.

Table 3: Confusion matrix represents the performance of

the HDP on the BEHAVE dataset.

I 0.54 0.13 0.16 0.03 0.03 0.00 0.10

A 0.11 0.68 0.16 0.05 0.00 0.00 0.00

W 0.03 0.14 0.75 0.06 0.00 0.03 0.00

S 0.13 0.13 0.00 0.67 0.00 0.00 0.07

FO 0.00 0.00 0.00 0.00 1 0.00 0.00

R 0.00 0.00 0.17 0.00 0.00 0.5 0.00

F 0.1 0.00 0.00 0.00 0.00 0.00 0.8

I A W S FO R F

walking into different directions and a set of objects

ﬁghting each other as shown in Figure 8(d). It is worth

mentioning that the interactions a− d in Figure 8 rep-

resented by ﬂow words based on their co-occurrence

in the same clip. The spatial ﬂow patterns is formed

by ﬂow words at different coordinates in the frames.

For the quantitatively evaluation for the selected

categories, Approach (A), Split (S), WalkTogether (W),

RunTogether (R), Fight (F), InGroup (I), Follow (FO).

Table 3 shows the confusion matrix of HDP per-

formance. Our method demonstrated lower perfor-

mances for InGroup and RunTogether interactions.

Most likely due to that the optical ﬂow is not worked

precisely with ﬁxed objects. Addition to the highest

similarity and the spatial overlap between the interac-

tions.

For the comparison with previous work, we used

the same subsets from the Behave dataset and com-

pare directly with their results. We compared our ap-

proach with (Kim et al., 2014; Yin et al., 2012; M

unch

Table 4: Interaction recognition comparison with (Kim

et al., 2014), (M

unch et al., 2012) and (Yin et al., 2012).

Category Our (Kim et al., 2014) (M

unch et al., 2012) (Yin et al., 2012)

Approach 68.42 83.33 60 n/a

Split 66.42 100 70 93.10

WalkTogether 75.00 91.66 45 92.10

InGroup 53.73 100 90 94.3

Fight 80.00 83.33 n/a 95.10

Average 65.95 93.74 66.25 93.65

et al., 2012) with the selected group activities e.g. Ap-

proach, Split, WalkTogether, InGroup,Fight as shown

in Table 4. As can be seen from Table 4, despite the

fact that our approach is completely unsupervised, we

achieved a clustering accuracy close to (M

unch et al.,

2012) of up to 65.95%. Unlike (M

unch et al., 2012),

our approach extracted the interactions without prior

knowledge.

The essential beneﬁts of our approach is that it is

able to extract the interactions automatically for the

new unseen videos without any further knowledge.

5.3 Implementation

The presented tracking framework was implemented

in C++ using the OpenCV library while the optical

ﬂow computation and HDP modeling was realized

in MATLAB using the standard toolboxes. The ex-

periments are performed on a desktop computer In-

tel(R) Core(TM) i7-4770 CPU @ 3.40GHz and 32

GB RAM. The implementation parameters were set

as follows. The threshold distance for equation 1 was

35 pixels, see Sec. 3. For optical ﬂow feature ex-

traction, the trajectories interval k was 10, see Sec.

3. The hyper-parameters (α and η) values in equa-

tion 4 ranging from 0.1 to 2, and the clip length is

150 frames corresponding to approximately 20 sec-

onds, see Sec. 4. The run time for inference process

depends on the video size and number of objects in-

teracting with each other in the scene (BB). The Eu-

clidean distance is computed between sub-trajectories

for every k frames, the time complexity for Euclidean

distance is O(n).

6 CONCLUSIONS AND FUTURE

WORK

The aim of this paper was to address the problem of

interaction among multiple objects. Our proposed ap-

proach incorporates the unsupervised clustering capa-

bilities of the HDP with the spatio-temporal features

to recognize the interactions of multiple objects with-

out prior knowledge. Furthermore, the Cavy dataset

is introduced in this work. The Cavy dataset is created

by capturing the interactions between three cavies.

Unsupervised Framework for Interactions Modeling between Multiple Objects

515

The Cavy dataset contains six dominant interactions

performed several times by two or three cavies at dif-

ferent locations. The challenging aspect of the the

Cavy dataset is that the cavies are behaving and inter-

acting in complicated and unexpected ways. The ex-

periments have been performed on the Cavy dataset

and the Behave dataset. Extensive experiments on

these datasets demonstrate the effectiveness of the

proposed method. Our approach achieved satisfactory

results with a clustering accuracy of up to 68.84% on

the Behave dataset and up to 45% on Cavy dataset.

In the future, robust tracker needs to be developed

to mitigate the tracker effects. Also the appearance-

based and trajectory-based features beside optical

ﬂow could possibly be included.

REFERENCES

Al-Raziqi, A., Krishna, M., and Denzler, J. (2014). Detec-

tion of object interactions in video sequences. OGRW,

pages 156–161.

Blunsden, S., Andrade, E., and Fisher, R. (2007). Non para-

metric classiﬁcation of human interaction. In PRIA,

pages 347–354. Springer.

Blunsden, S. and Fisher, R. (2009). Detection and classi-

ﬁcation of interacting persons. Machine Learning for

Human Motion Analysis: Theory and Practice, page

213.

Blunsden, S. and Fisher, R. (2010). The behave video

dataset: ground truthed video for multi-person behav-

ior classiﬁcation. BMVA, 4:1–12.

Cheng, Z., Qin, L., Huang, Q., Yan, S., and Tian, Q. (2014).

Recognizing human group action by layered model

with multiple cues. Neurocomputing, 136:124–135.

Delaitre, V., Sivic, J., and Laptev, I. (2011). Learning

person-object interactions for action recognition in

still images. In NIPS, pages 1503–1511.

Dong, Z., Kong, Y., Liu, C., Li, H., and Jia, Y. (2011). Rec-

ognizing human interaction by multiple features. In

ACPR, pages 77–81.

Guha, T. and Ward, R. K. (2012). Learning sparse represen-

tations for human action recognition. IEEE Transac-

tions on, Pattern Analysis and Machine Intelligence,

34(8):1576–1588.

Jiang, X., Rodner, E., and Denzler, J. (2012). Multi-

person tracking-by-detection based on calibrated

multi-camera systems. In Computer Vision and

Graphics, pages 743–751. Springer.

Kim, Y.-J., Cho, N.-G., and Lee, S.-W. (2014). Group activ-

ity recognition with group interaction zone. In ICPR,

pages 3517–3521.

Kong, Y. and Jia, Y. (2012). A hierarchical model for human

interaction recognition. In ICME, pages 1–6.

Krishna, M. and Denzler, J. (2014). A combination of

generative and discriminative models for fast unsuper-

vised activity recognition from trafﬁc scene videos. In

Proceedings of the IEEE (WACV), pages 640–645.

Krishna, M., K

orner, M., and Denzler, J. (2013). Hierarchi-

cal dirichlet processes for unsupervised online multi-

view action perception using temporal self-similarity

features. In ICDSC, pages 1–6.

Kuettel, D., Breitenstein, M. D., Van Gool, L., and Fer-

rari, V. (2010). What’s going on? discovering spatio-

temporal dependencies in dynamic scenes. In CVPR,

pages 1951–1958.

Li, B., Ayazoglu, M., Mao, T., Camps, O., Sznaier, M., et al.

(2011). Activity recognition using dynamic subspace

angles. In CVPR, pages 3193–3200.

Lin, W., Sun, M.-T., Poovendran, R., and Zhang, Z. (2010).

Group event detection with a varying number of group

members for video surveillance. IEEE Transactions

on CSVT, 20(8):1057–1067.

unch, D., Michaelsen, E., and Arens, M. (2012). Support-

ing fuzzy metric temporal logic based situation recog-

nition by mean shift clustering. In KI 2012: Advances

in Artiﬁcial Intelligence, pages 233–236. Springer.

Ni, B., Yan, S., and Kassim, A. (2009). Recognizing human

group activities with localized causalities. In CVPR,

pages 1470–1477.

Ohayon, S., Avni, O., Taylor, A. L., Perona, P., and Egnor,

S. R. (2013). Automated multi-day tracking of marked

mice for the analysis of social behaviour. Journal of

neuroscience methods, 219(1):10–19.

Patron-Perez, A., Marszalek, M., Zisserman, A., and Reid,

I. (2010). High ﬁve: Recognising human interactions

in tv shows.

Sato, K. and Aggarwal, J. K. (2004). Temporal spatio-

velocity transform and its application to tracking and

interaction. Computer Vision and Image Understand-

ing, 96(2):100–128.

Teh, Y. W., Jordan, M. I., Beal, M. J., and Blei, D. M.

(2006). Hierarchical dirichlet processes. Journal of

the american statistical association, 101(476).

Yang, G., Yin, Y., and Man, H. (2013). Human object inter-

actions recognition based on social network analysis.

In AIPR, pages 1–4.

Yin, Y., Yang, G., Xu, J., and Man, H. (2012). Small group

human activity recognition. In ICIP, pages 2709–

2712.

Zach, C., Pock, T., and Bischof, H. (2007). A duality based

approach for realtime tv-l 1 optical ﬂow. In Pattern

Recognition, pages 214–223. Springer.

Zhang, C., Yang, X., Lin, W., and Zhu, J. (2012). Recogniz-

ing human group behaviors with multi-group causali-

ties. In WI-IAT, volume 3, pages 44–48.

Zhou, Y., Ni, B., Yan, S., and Huang, T. S. (2011). Recog-

nizing pair-activities by causality analysis. ACM TIST,

2(1):5.

Zhu, G., Yan, S., Han, T. X., and Xu, C. (2011). Gener-

ative group activity analysis with quaternion descrip-

tor. In Advances in Multimedia Modeling, pages 1–11.

Springer.

Zivkovic, Z. (2004). Improved adaptive gaussian mixture

model for background subtraction. In ICPR, volume 2,

pages 28–31.

VISAPP 2016 - International Conference on Computer Vision Theory and Applications

516
