Multi-factor Authentication Updating System Evaluation Dynamically

for Service Continuity

Hiroya Susuki

, Rie Shigetomi Yamaguchi

and Shizuo Sakamoto

The University of Tokyo, 7-3-1 Hongo, Bunkyo-ku, Tokyo, 113-8656, Japan

NEC Corporation, 7-1 Shiba 5-chome, Minato-ku, Tokyo, 108-8001, Japan

Keywords:

Multi-factor Authentication, Bayesian Model, Probabilistic Model, Security, Usability.

Abstract:

In response to changes in security environments, an authentication framework has an important role for service

continuity, which can evaluate both of security and usability and handle authentication methods. If the service

provider cannot respond to problems such as new attacks immediately, the service must be stopped. In this

paper, we propose a multi-factor authentication framework using a probabilistic evaluation method considering

service continuity. Our framework includes a formal theoretical model, based on Bayesian approach, to be

dynamically updated to use appropriate combinations of authentication factors in response to changes in the

security environment. The model is important because it forms the basis on which the real-world systems is

able to be evaluated security immediately and responded to weak factor.

1 INTRODUCTION

Various services are now available in online environ-

ments. These services require that the user be authen-

ticated its access. On most online service sites, only

password authentication is used. As a result, pass-

words are also a major source of vulnerability(Herley,

2009). There are advantages and disadvantages for

authentication methods, and there is a trade-off be-

tween security and usability. Often, more secure

methods are less convenient. An effective way to re-

solve these problems of single-factor authentication is

to use multi-factor authentication(Shay et al., 2010).

One such method is Google 2-step veriﬁcation, which

is a well-known method that uses multi-factor authen-

tication to prevent spooﬁng(Google, 2015). Although

authentication systems using multi-factors have be-

come increasingly widely used, multi-factor authen-

tication methods are not secure if the combination of

multiple factors itself is not secure.

We also note that new techniques for cracking not

only authentication factors but authentication meth-

ods are continuously being invented. User authentica-

tion systems are unable to rely on frameworks that use

only a single factor or a single authentication method.

When a service provider needs to change the authenti-

cation factor, this cannot be done with a single-factor

system. Similarly, systems that use only a single au-

thentication method cannot be changed to the other

method. Since continuity of service is very impor-

tant, there is a need for authentication frameworks

that can change which factor and which method they

use. However, currently, there are no ways to evalu-

ate these multi-factor systems since service providers

need to evaluate both security and usability formally.

Basic idea has been already proposed in many arti-

cles but these schemes are heuristic and is difﬁcult

to present an overview for security on the system.

Probabilistic models can estimate the evaluation of

systems in an environment without enough statistical

data. In addition, for example, most systems using

password authentication return a binary value (either

accept or deny). On the other hand, in the case of bio-

metric authentications, such as ﬁngerprints, irises, or

faces, the score is not binary but a probability value,

such as the likelihood(Damer et al., 2014). The evalu-

ation using probabilistic model is appropriate for han-

dling mixture of probability scores. Therefore, the

evaluation of the authentication systems requires the

use of probabilistic models.

In summary, the contribution of this work is a

probabilistic framework for multi-factor authentica-

tion with a probabilistic evaluation model; with this

method, authentication factors can be dynamically

changed to correspond with the current security envi-

ronment. Although our formulation is basic, our ap-

proach is important because the service providers be-

come easier to manage the authentication system by

Susuki, H., Yamaguchi, R. and Sakamoto, S.

Multi-factor Authentication Updating System Evaluation Dynamically for Service Continuity.

DOI: 10.5220/0005681802730281

In Proceedings of the 2nd International Conference on Information Systems Security and Privacy (ICISSP 2016), pages 273-281

ISBN: 978-989-758-167-0

273

the formulation of multi-factor authentication frame-

work. In this paper, we show how to use our proposed

framework to select a combination of factors that are

suitable in terms of both security and usability.

This paper is structured as follows. In the next

section, we provide general background about multi-

factor authentication and evaluation methods. In Sec-

tion 3, we describe our proposed probabilistic method

and multi-factor authentication model. In Section 4,

we provide and analyze an application of the proposed

method. Finally, in Section 5, we present our conclu-

sions and discuss areas of future work.

2 RELATED WORK

In this section, we provide the general background of

multi-factor authentication and evaluation methods.

Various methods for risk assessment and risk con-

trol have been proposed, but not sufﬁcient in ac-

tual operation. In recent years, risk-based authen-

tication methods have become practical. There

have also been theoretical investigations of risk-

based access control models, which consider se-

curity risks when making decisions about access

control(Karabacak and Sogukpinar, 2005)(Chen and

Crampton, 2012)(Cheng et al., 2007). A study has

compared multiple authentication methods to the text-

based password authentication(Bonneau et al., 2012).

Another study assessed the security of the United

States e-government sites to identify opportunities for

and threats to the sites and their users(Zhao and Zhao,

2010). Many of these approaches consider only the

security aspects of authentication systems, whereas

usability is also important. These models evaluate

the security of the authentication system in each situ-

ation and then choose from multiple levels of secu-

rity. The Electronic Authentication Guideline pro-

vided by National Institute of Standards and Tech-

nology (NIST) presents the technical requirements

for each of the levels of assurance for authentica-

tion(Burr et al., 2004). Authentication systems can

balance security and usability at each level, prior to

making a decision (Kim and Hong, 2011)(Hocking

et al., 2010). Existing studies have considered only

the current evaluation of the authentication systems

and have not considered updating the evaluation, al-

though this is important for continuity of service.

Since the result of an authentication method is not

necessarily a binary value, it is important to have an

evaluation measure that can deal with fractional re-

sults. Therefore, evaluation of authentication systems

requires probabilistic models that are based on a fore-

cast and can deal with fractional results. Bayesian

models are a popular type of probabilistic model,

and even if the amount of sample data is small, the

model can estimate the probability by using Bayesian

subjective probability, and thus the probabilities can

be updated continuously. There have been vari-

ous relevant studies using Bayesian models(Pavlovic

and Meadows, 2010)(Nguyen et al., 2011)(Kondakci,

2010). Thus, there have been methods proposed that

use Bayesian models for user authentication. How-

ever, these models considered only security, and it is

also necessary to consider usability of authentication

methods.

Various multi-factor authentication methods have

been proposed for improving the security of authen-

tication systems. These methods consist of various

combinations of factors and various ways in which

they are combined. Two- and three-factor authentica-

tion methods have become popular(Yang et al., 2008).

One typical example is a multi-biometric authentica-

tion method. Multi-biometric methods use multiple

sources of biometric information to enhance perfor-

mance and to overcome the limitations of conven-

tional unimodal biometrics(Damer et al., 2014)(Al-

Assam et al., 2010). With the growth in concern

about security in the mobile environment, various

multi-factor authentication methods have been pro-

posed(Aloul et al., 2009)(Riva et al., 2012)(Sabze-

var and Stavrou, 2008). As discussed above, var-

ious multi-factor authentication methods have been

proposed, but most of them evaluate only the current

security environment and do not consider changing

the authentication factors. In addition, there has been

limited research that considered usability. In the next

section, we propose a probabilistic model for multi-

factor authentication that considers both security and

usability.

3 AUTHENTICATION MODEL

In this section, we begin by deﬁning the multi-factor

authentication method that will be considered in this

paper, and deﬁne the related terms and notation.

3.1 Deﬁnition of Terms and Notation

We deﬁne authentication as the process of establish-

ing conﬁdence in the identity of a user or information

system; multi-factor authentication is based on a com-

bination of two or more factors.

Let u be a user who wishes to be authenticated,

and let U be the set of all users; that is, u ∈ U. In

order to allow a service srvc to be provided to u, an

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

274

online transaction tra is performed to establish conﬁ-

dence with the provider that u has legitimate authority

to access that service. In addition to the request for a

srvc, u provides a clear intention. Note that u must be

authenticated by the service provider for each trans-

actions tra. In this paper, we do not consider about

machine-to-machine authentication. We will assume

that the services are authenticated by the intention of

u. With one-to-one (1:1) authentication, it is possible

to identify the account to which u tried to gain access.

On the other hand, with one-to-many (1:n) authenti-

cation, the account cannot be identiﬁed. In the case of

one-to-many authentication using biometrics, u may

be authenticated as a different user.

3.1.1 Deﬁnition of Function and Scenario

We deﬁne two terms for multi-factor authentication.

When a user u ∈ U wishes to be provided a service

srvc

(i ∈ N), u must participate in multi-factor au-

thentication. Any factors in any combination can be

chosen, and it is possible to select different combina-

tions of factors for different services. The particular

combination of factors is called a scenario S ∈ S.

Function. The functions are the processes used in

single-factor authentication; these include such

things as password authentication and ﬁngerprint

authentication. We denote a function as f ∈ F.

Scenario. A scenario is a combination of functions,

which results in a series of authentications. We

denote a scenario as S ∈ S. There are dependen-

cies between some of functions.

Let S be a combination of functions f

, f

, . . .

, (n ∈ N), for which an order is deﬁned, as follows.

S = (( f

, 1), ( f

, 2), . . . ( f

, n))(n ∈ N) (1)

is the set of functions without a deﬁned order.

= (( f

), ( f

), . . . ( f

))(n ∈ N) (2)

Consider a scenario that uses both password au-

thentications with ID and ﬁngerprint authentication. S

is composed of two functions: f

is password authen-

tication with ID, and f

is ﬁngerprint authentication.

Each function f returns a binary value (0, 1) for

the result of a single-factor authentication. A return

of 1 shows that authentication was successful, and 0

shows that it failed.

3.1.2 Service and Scenario

In this paper, we deﬁne that a scenario S is composed

of one or more functions f

, f

, . . . f

(n ∈ N). Fur-

thermore, a scenario S that is composed of only one

function f is a single-factor authentication. It is also

possible to create a scenario that combines scenarios.

As an example, we now consider a scenario in which

a user accesses an online service on a website. A user

u activates his/her mobile device by using function f

(ﬁngerprint authentication). Then, u logs onto a web-

site by using function f

(password authentication).

When a user u is provided a service srvc by a ser-

vice provider SP ∈ SP, u must participate in authen-

tication in accordance with the required scenario. Let

a ∈ A be an adversary who impersonates a legitimate

user u. It is possible that there are multiple scenarios

, S

, . . . S

(k ∈ N) from which the SP can select a

suitable scenario for the given srvc

. Thus, if one sce-

nario is cracked and thus loses security, the provider

can require a different scenario. In this way, there is a

mechanism to ensure that, in a changing environment,

continuous service can be provided and safety can be

maintained.

3.2 Combinations of Functions

In this subsection, we discuss the relations between

functions. There are two types of combinations of

functions: sequential and parallel.

. . . −→ f

−→ f

i+1

−→ f

i+2

−→ . . .

Figure 1: Sequential Functions.

% &

. . . −→ f

i+1

−→ . . .

& %

i+2

Figure 2: Parallel Functions.

3−1

% &

. . . → S

→ S

→ f

3−2

→ S

→

& %

3−3

Figure 3: Combination of Sequential and Parallel.

3.2.1 Sequential Functions

Sequential functions result in step-by-step authenti-

cation. As shown in the Figure 1, each function is

completed before the next is begun. For example, in

the ﬁrst function, f

, u enters an ID and a password.

In the second function, f

i+1

, u enters additional secret

information from a table of random numbers. Further

Multi-factor Authentication Updating System Evaluation Dynamically for Service Continuity

275

functions are processed in order until authentication is

completed. The order of S is important in the sequen-

tial functions. The result of a function determines the

result of later functions.

3.2.2 Parallel Functions

Parallel functions are all performed at the same time,

as shown in Figure 2. For example, two functions ( f

;

password authentication and f

; device ID authenti-

cation) are performed simultaneously. The order of S

does not have any meaning and can be changed. Thus,

S can be written as follows.

= (( f

), ( f

), . . . ( f

))(n ∈ N) (3)

3.2.3 Combinations of Sequential and Parallel

There are also authentication methods that use both

sequential and parallel functions. Figure 3 shows an

example of a combination scenario S

, which is writ-

ten as follows.

= (S

, S

)

= (S

, S

, ( f

3−1

, f

3−2

, f

3−1

), S

) (4)

3.3 Deﬁnition of Probability

We discuss the probability of acceptance authentica-

tion for multi-factor authentication.

3.3.1 Probability of Acceptance for Multi-Factor

Authentication

When a function f ∈ F is accepted, a value of 1 is re-

turned, and when it is denied, 0 is returned. When a

user u participates in a multi-factor authentication us-

ing scenario S = ( f

(u), . . . , f

(u)) (n ∈ N), at func-

tion f , the conditional probability of acceptance into

the user’s own account is P(Acc| f (ID

, u)). If an ad-

versary a impersonates a user u, the probability is

P(Acc| f (ID

, a)). The other probabilities are shown

in Table 1. Similarly, the conditional probability of

acceptance for authentication at scenario S for a user’s

own account I D

is P(Acc|S(ID

, u)).

Note that the notation P(x|y) expresses the condi-

tional probability of x given the value of y, whereas

P(x|y, z) expresses the conditional probability of x

given the values of both y and z. These apply when

two or more events will happen at the same time.

We propose a multi-factor authentication frame-

work based on a Bayesian model. Bayesian updating

of our model is based on fraud detection during au-

thentication. The probability is updated at every login

attempt.

Table 1: Probability of the Authentication Function.

Function Who Accept Probability

/Deny

f (ID

, u) u 1 P(Acc| f (ID

, u))

f (ID

, u) u 0 P(Deny| f (ID

, u))

f (ID

, a) a 1 P(Acc| f (ID

, a))

f (ID

, a) a 0 P(Deny| f (ID

, a))

3.3.2 Probability of Sequential Authentication

When a scenario S consists of a dependent series of

sequential functions, we can deﬁne the case in which

a legitimate user is accepted as follows. Note that, in

the case of sequential authentication, when a function

fails in the middle, the entire authentication is unsuc-

cessful. Also note that when the events are correlated,

their probabilities affect those of the others.

P(Acc|S(ID

, u)) = P(Acc| f

(ID

, u))×

P(Acc| f

(ID

, u, f

(ID

, u))) ×

P(Acc| f

(ID

, u, f

(ID

, u), f

(ID

, u)))

×· ·· × P(Acc| f

(ID

, u, f

(ID

, u),

(ID

, u), . . . , f

(ID

, u)) (5)

When an adversary a tries to impersonate u, we

have

P(Acc|S(ID

, a)) = P(Acc| f

(ID

, a))×

P(Acc| f

(ID

, a, f

(ID

, a))) ×

P(Acc| f

(ID

, a, f

(ID

, a), f

(ID

, a)))

×· ·· × P(Acc| f

(ID

, a, f

(ID

, a),

(ID

, a), . . . , f

(ID

, a)) (6)

3.3.3 Probability of Parallel Authentication

When a scenario S consists of only independent par-

allel functions, the probability that a legitimate user is

accepted is as follows.

P(Acc|S(ID

, u)) = P(Acc| f

(ID

, u))×

P(Acc| f

(ID

, u)) × ··· × P(Acc| f

(ID

, u)) (7)

When an adversary a tries to impersonate u, we

have

P(Acc|S(ID

, a)) = P(Acc| f

(ID

, a))×

P(Acc| f

(ID

, a)) × ··· × P(Acc| f

(ID

, a)) (8)

3.3.4 Probability of Combination

We now consider the probability of a combination

of sequential and parallel authentication, as was dis-

cussed in Section 3.3.2. We will assume that the par-

allel authentication does not have a prior probability.

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

276

The probability of the generalized sequential authen-

tication is as follows.

P(Acc|S(ID

, u)) = P(Acc| f

(ID

, u))×

P(Acc| f

(ID

, u, f

(ID

, u))) ×

P(Acc| f

(ID

, u, f

(ID

, u), f

(ID

, u)))

×· ·· × P(Acc| f

(ID

, u, f

(ID

, u),

(ID

, u), . . . , f

(ID

, u)) (9)

4 AUTHENTICATION

OPERATION

In this section, we discuss authentication opera-

tion using proposed probabilistic model based on a

Bayesian model.

4.1 Service and Scenario

When a user u ∈ U is provided a service srvc

(i ∈ N)

by a service provider SP ∈ SP, u and SP perform

multi-factor authentication. If u and S P are able to

select several types of single factors as a scenario S,

they must decide which types and how many factors

they will use for each types of service.

In Section 3, we deﬁned the probability of accep-

tance for our multi-factor model in which the factors

could be changed: P(Acc|S(ID

, u). To take a simple

example, consider the difference between a bank that

requires high security when a user wants to transfer

a large amount of money, and a coffee shop that re-

quires very little security but high speed when a user

wants to buy a cup of coffee. We say that the SP needs

to be able to select many security levels and from

many scenarios, depending on the immediate need.

4.1.1 Deﬁnition of User Authentication

We discuss the relation between scenarios and ser-

vices. Suppose a SP needs to verify whether someone

who is requesting a service srvc is indeed the person

registered to receive it; they do this by exchanging

various information through the Internet. This proce-

dure is called authentication.

The reason that the SP needs to verify the user is

that the service srvc is only open to anyone. The SP

must ensure that u pays the amount required in order

to be provided srvc, that u is a member of a particular

organization, or that for some other reason, u has the

right to receive that service. Note that the SP provides

srvc, and u requests srvc; but SP does not provide the

service if this is not u’s intention.

We assume that srvc is provided through the In-

ternet as an online service, such as entry to an e-

commerce site, a shopping or auction site, a commu-

nication site, or SNS. These kinds of sites do not pro-

vide services continuously, but only when u has an

intention to receive a service. This means that u re-

quests the service on a regular basis, but only once

per visit.

As human, we are not able to connect directly to

the Internet, but only through specialized equipment,

such as a personal computer or a smartphone. We will

assume that this equipment is always able to commu-

nicate with the Internet. The equipment is not able to

form an intention, and so even when services are pro-

vided through such equipment, the user is receiving a

direct service.

4.2 Security and Usability

We now deﬁne parameters for the security and usabil-

ity of a service. For every authentication system, se-

curity is a ﬁrst priority when evaluating the system.

Because we are considering a multi-factor authenti-

cation system, the security evaluation must be based

on a combination of several factors, not just a single-

factor authentication. It is also important to consider

usability, but this must be balanced against security.

4.2.1 Security

In any authentication system, u must be given access,

but an adversary a ∈ A must fail. That is, the prob-

ability that adversaries a

, . . . a

achieve success with

function f should satisfy the following.

P(Acc|S(ID

, a)) = 0 (10)

However, the more secure system, the higher cost

is required. In terms of construction cost of the sys-

tem, the system that the probability of acceptance for

adversaries is zero is not realistic. The cost is required

for the system construction as well as operation. SPs

need to pay attention the cost.

Let k (0 < k < 1) be a security parameter, where

the SP must determine the acceptable level of risk k.

That is, SP should build a system that requires a level

of security that is not more than k.

P(Acc|S(ID

, a)) < k (11)

4.2.2 Usability

If a system denies any of u’s requests, that system is

not serviceable. The SP must choose the probability

that u is denied service. If the SP decides to empha-

size only usability and u is able to be access any fac-

tors, then the probability that access is denied should

Multi-factor Authentication Updating System Evaluation Dynamically for Service Continuity

277

Table 2: Parameters for the Service and the Cost.

Service Cost Security Usability

parameter parameter

srvc

cost

srvc

cost

be as follows.

P(Deny|S(ID

, u)) = 0 (12)

However, the input by u may vary if there is user

error or if u’s biometric measurements ﬂuctuate. It is

not realistic to design a system that is based on the

assumption that u is always able to input the correct

value. Let ub, 0 < ub < 1, be the parameter for the ser-

vice availability, as chosen by the SP. The SP should

build a system that requires availability of not more

than ub, as follows.

P(Deny|S(ID

, u)) < ub (13)

4.2.3 Parameters

Note that neither k nor ub should be unique.

When a person wants to transfer a small amount

to an account to which he or she has previously trans-

ferred money, the value of k should be low. When

a person wants to transfer a large amount to an ac-

count to which he or she has never transferred money,

the value of k should be high. The service provider

should be able to allow for ﬂexible responses.

On the other hand, the SP must change the service

level depending on the value of ub. In general, al-

though the level of security should be high, excessive

security is not always appropriate for a given service.

There is a tradeoff between security and usability, and

it is important that these be balanced when consider-

ing the overall quality of service.

See Table 2 for the parameters that must be set by

the SP. The SP creates the table for cost and parame-

ters before starting the service.

4.3 Advanced Evaluation and Update

We will discuss how to continually and dynamically

evaluate the security and usability of a service.

When the SP provides a service svrc, the SP must

decide which kinds of scenario S

, S

, . . . are suitable

for svrc. Note that there must be many different types

of scenario, and s must be framed by several types of

functions f

, f

, . . . . If srvc is provided by s, which

includes a vulnerable function f

, then another S that

has not yet been included should be selected.

4.3.1 Advanced Evaluation

When SP starts to provide a service at a time t

, it

is impossible to assume that there are no adversaries.

The SP must evaluate the security.

Supposing that the SP chooses values for the se-

curity parameter k and the usability parameter ub, the

SP then chooses a scenario set S = (S

, S

, . . . ) that

satisﬁes the following.

P(Acc|S(ID

, a)) < k, P(Deny|S(ID

, u)) < ub (14)

The SP must pay attention to the usability of S.

The user does not want to be asked to input to key-

board many times. Let ub

be the usability parameter

for S. Note that SP will then require ub

, and so ub

can be regarded as being included in ub.

However, before starting the service, it is impossi-

ble for the SP to have full knowledge of the security

environment. In a multi-factor authentication system,

there are cases that cannot be applied existing evalua-

tion. To determine whether the service should be pro-

vided, it is necessary to evaluate the system based on

some assumption, which can be empirically deduced,

obtained from a similar system, or by updating the se-

curity parameter based evaluation of the need during

the operation.

We suggest that the evaluation method should not

assume that the security level will be constant dur-

ing provision of the service, since prior to initiating

it, it is not possible to obtain an accurate evaluation.

However, before starting the service, it is possible to

estimate the probabilities. As the service continues,

the probabilities continue to be updated to the appro-

priate values, by using the strategy for optimization of

security that we will discuss in Section 4.4.

In the proposed probability model, the evaluation

value of the system is updated by the posterior proba-

bility using a Bayesian update.

4.4 How to Update the Parameter

We now discuss how the SP updates the evaluation

value. We suggest two methods for updating the

value: automatic and manual.

Auto-Update Auto-Update is automatically per-

formed, and the new value is the log of the fre-

quency of successful attacks by an adversary a.

Manual-Update Manual-Update is performed by

the system administrator. This method is for re-

ﬂecting changes in the security environment, such

as the emergence of new technologies or the ap-

pearance of new attacks.

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

278

The continuity of service is important. For small

vulnerabilities in one scenario S, it is not realistic to

re-evaluate the entire system each time a new factor

is added or deleted. Such a system could not con-

tinue until the evaluation had been completed, and this

would result in a lack of continuity of service. Thus,

it is necessary to construct a method that allows the

factor to be updated dynamically in a multi-factor au-

thentication system. However, for the users, the sys-

tem must be ﬂexible and convenient, and it is impor-

tant that the users encounter factors for which they are

prepared, rather than always being forced to adapt to

a new method. We suggest that the actual scenario in

use should be able to be chosen from several different

scenarios by either the SP or u. This would allow the

system to maintain both security and usability, and it

would be a low-load technique for the user.

4.4.1 Auto-Update

The SP can observe the access probabilities from t

to t

i−1

; P(Acc|S(ID

, a)) will continue to change if

the SP provides the srvc with scenario S

(i ∈ N). It

is also possible to estimate the risk of the system by

continuing to update the probabilities of acceptance

of the user and the adversary assuming that there are

attacks to the system.

Let P

(Acc|S(ID

, a)) be P(Acc|S(ID

, a)) at t

so that

(Acc|S(ID

, a)) = δP

(Acc|S(ID

, a))

+(1 − δ)α(δ = 1) (15)

iff

(Acc|S(ID

, a)) = P

(Acc|S(ID

, a)) (16)

where δ is 0 or 1, and α is a ﬁxed value.

These probabilities are based on statistical assess-

ments. The SP observes that the user or adversary

is accepted or denied access to the system and up-

dates P

. Note that if the SP continues to offer the

service based on the scenario S

, the following for-

mula should be satisﬁed: P

(Acc|S(ID

, a)) < k and

(Deny|S(ID

, u

)) < ub.

4.4.2 Manual-Update

When the SP provides the service, a person who can

predict rapid changes in the access probabilities be-

cause they have access to knowledge about new at-

tacks or ongoing attacks controls the system.

If there is a reason that the administrator be con-

sidered as security is reduced, such as an attack will

be widespread, the administrator needs to change the

evaluation of scenarios related to the attack immedi-

ately. We will consider some examples of these kinds

of attacks, which include password list attacks and at-

tacks on biometric authentication, such as by gummy

ﬁnger or wolf attacks.

Attack Forecast. At a time t

∈ T, the administrator

expects a rapid increase in attacks.

At t

, the administrator sets δ = 0. The access

probabilities of all users are changed to

(Acc|S(ID

, a)) = δP

(Acc|S(ID

, a))

+(1 − δ)α(δ = 0, α = α

) (17)

iff

(Acc|S(ID

, a)) = α

. (18)

Note that α

should not be constant before t

, but it

becomes ﬁxed at t

. It is possible to change many

different values to account for the level of attacks.

Update From The Observation of Another User.

The access probability is not only deﬁned for u

but also for many other users, including u

. The

administrator might make the following change:

(Acc|S(ID

, a)) = δP

(Acc|S(ID

, a))

+(1 − δ)α(δ = 0, α = α

) (19)

The service provider will decide α

4.5 Replacement of Factors

If the access probability of S, P

(Acc|S(ID

, a)), is

larger than the security parameter k, then the SP needs

to take measures to ﬁx this, and various options are

available. There are multiple strategies that the sys-

tem administrator can be taken. One of the strict

strategies is service outage; a less drastic strategy is

to change some scenarios, which means changing the

authentication factors; the simplest strategy is to no-

tify the system administrator. The evaluation value

must be effectively utilized as a criterion for the oper-

ation of the system.

4.5.1 Changing Scenarios

If the access probability of P

(Acc|S

(ID

, a)) is

greater than the value of k for scenario S

, the SP de-

cides to stop using S

. The SP selects another scenario

, and the service is provided using S

. Note that S

should satisfy P

(Acc|S

(ID

, a)) < k.

should be selected by considering usability and

the impact on service availability.

4.5.2 Evaluation of a Scenario

After evaluating each scenario, the SP must ﬁnd a new

scenario that has not previously been considered. The

SP should be able to adapt to a new scenario that is

brought about by technical innovations or by a sig-

niﬁcant decrease in the security level of a particular

factor.

Multi-factor Authentication Updating System Evaluation Dynamically for Service Continuity

279

4.6 Stop or Change the Service

For security measures, the SP is able to change of the

quality of service, such as by temporarily lowering

the maximum amount of money transferred or by re-

ducing the amount of credit that can be accessed. To

make the appropriate choice, the SP should use Ta-

bles 2. The SP must stop the service srvc if the ac-

cess probabilities of all scenarios are greater than k:

(Acc|S

(ID

, a)) > k for all S

. Also, the SP must

stop the service srvc if the usability probability of all

scenarios are greater than ub: P

(Acc|S

(ID

, u

)) >

ub for all S

5 CONCLUSIONS

This paper focuses on probabilistic framework for

multi-factor authentication. In recent years, the se-

curity environment has been changing rapidly due

to diversifying cracking methods and the improved

functionality of computers and mobile devices. We

discussed the need for evaluation methods that can

change the authentication factor dynamically, and

we proposed a probabilistic framework based on a

Bayesian model. Our research makes two contribu-

tions. First, we showed a probabilistic framework

for multi-factor authentication considering combina-

tion of authentication factors. Second, we showed a

theoretical model that is able to change authentica-

tion factors dynamically. Moreover, we proposed a

method for selecting a combination of authentication

factors for changing them when the security environ-

ment changes. Our framework can improve the se-

curity and usability of multi-factor authentication. In

the future, it is necessary to evaluate using actual case

studies and data.

ACKNOWLEDGEMENTS

We would like to thank Mitsubishi UFJ NICOS Co.,

Ltd. for a grant that made it possible to complete this

work.

REFERENCES

Al-Assam, H., Sellahewa, H., and Jassim, S. (2010). On

security of multi-factor biometric authentication. In

Internet Technology and Secured Transactions (IC-

ITST), 2010 International Conference for, pages 1–6.

IEEE.

Aloul, F., Zahidi, S., and El-Hajj, W. (2009). Multi fac-

tor authentication using mobile phones. Interna-

tional Journal of Mathematics and Computer Science,

4(2):65–80.

Bonneau, J., Herley, C., Van Oorschot, P. C., and Stajano,

F. (2012). The quest to replace passwords: A frame-

work for comparative evaluation of web authentica-

tion schemes. In Security and Privacy (SP), 2012

IEEE Symposium on, pages 553–567. IEEE.

Burr, W. E., Dodson, D. F., and Polk, W. T. (2004). Elec-

tronic authentication guideline. Citeseer.

Chen, L. and Crampton, J. (2012). Risk-aware role-based

access control. In Security and Trust Management,

pages 140–156. Springer.

Cheng, P. C., Rohatgi, P., Keser, C., Karger, P. A., Wagner,

G. M., and Reninger, A. S. (2007). Fuzzy multi-level

security: An experiment on quantiﬁed risk-adaptive

access control. In Security and Privacy, 2007. SP’07.

IEEE Symposium on, pages 222–230. IEEE.

Damer, N., Opel, A., and Nouak, A. (2014). Cmc curve

properties and biometric source weighting in multi-

biometric score-level fusion. In Information Fusion

(FUSION), 2014 17th International Conference on,

pages 1–6. IEEE.

Google (2015). Google 2-step veriﬁcation [retrieved 18 sep.

2015]. https://www.google.com/landing/2step/.

Herley, C. (2009). So long, and no thanks for the externali-

ties: the rational rejection of security advice by users.

In Proceedings of the 2009 workshop on New security

paradigms workshop, pages 133–144. ACM.

Hocking, C. G., Furnell, S. M., Clarke, N. L., and Reynolds,

P. L. (2010). A distributed and cooperative user au-

thentication framework. In Information Assurance

and Security (IAS), 2010 Sixth International Confer-

ence on, pages 304–310. IEEE.

Karabacak, B. and Sogukpinar, I. (2005). Isram: informa-

tion security risk analysis method. Computers & Se-

curity, 24(2):147–159.

Kim, J.-J. and Hong, S.-P. (2011). A method of risk assess-

ment for multi-factor authentication. JIPS, 7(1):187–

198.

Kondakci, S. (2010). Network security risk assessment us-

ing bayesian belief networks. In Social Computing

(SocialCom), 2010 IEEE Second International Con-

ference on, pages 952–960. IEEE.

Nguyen, N. T., Zheng, G., Han, Z., and Zheng, R. (2011).

Device ﬁngerprinting to enhance wireless security us-

ing nonparametric bayesian method. In INFOCOM,

2011 Proceedings IEEE, pages 1404–1412. IEEE.

Pavlovic, D. and Meadows, C. (2010). Bayesian authenti-

cation: Quantifying security of the hancke-kuhn pro-

tocol. Electronic Notes in Theoretical Computer Sci-

ence, 265:97–122.

Riva, O., Qin, C., Strauss, K., and Lymberopoulos, D.

(2012). Progressive authentication: Deciding when to

authenticate on mobile phones. In USENIX Security

Symposium, pages 301–316.

Sabzevar, A. P. and Stavrou, A. (2008). Universal multi-

factor authentication using graphical passwords. In

Signal Image Technology and Internet Based Systems,

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

280

2008. SITIS’08. IEEE International Conference on,

pages 625–632. IEEE.

Shay, R., Komanduri, S., Kelley, P. G., Leon, P. G.,

Mazurek, M. L., Bauer, L., Christin, N., and Cranor,

L. F. (2010). Encountering stronger password require-

ments: User attitudes and behaviors. In Proceedings

of the Sixth Symposium on Usable Privacy and Se-

curity, SOUPS ’10, pages 2:1–2:20, New York, NY,

USA. ACM.

Yang, G., Wong, D. S., Wang, H., and Deng, X. (2008).

Two-factor mutual authentication based on smart

cards and passwords. Journal of Computer and Sys-

tem Sciences, 74(7):1160–1172.

Zhao, J. J. and Zhao, S. Y. (2010). Opportunities

and threats: A security assessment of state e-

government websites. Government Information Quar-

terly, 27(1):49–56.

Multi-factor Authentication Updating System Evaluation Dynamically for Service Continuity

281
