An Approach to Personalized Privacy Policy Recommendations on

Online Social Networks

Ammar Abuelgasim and Anne Kayem

Dept. of Computer Science, University of Cape Town, Rondebosch 7701, Cape Town, South Africa

Keywords:

Privacy Policies, Recommendation Systems, Social Networks.

Abstract:

Most Online Social Networks (OSNs) implement privacy policies that enable users to protect their sensitive

information against privacy violations. However, observations indicate that users ﬁnd these privacy policies

cumbersome and difﬁcult to conﬁgure. Consequently, various approaches have been proposed to assist users

with privacy policy conﬁguration. These approaches are however, limited to either protecting only proﬁle

attributes, or only protecting user-generated content. This is problematic, because both proﬁle attributes and

user-generated content can contain sensitive information. Therefore, protecting one without the other, can still

result in privacy violations. A further drawback of existing approaches is that most require considerable user

input which is time consuming and inefﬁcient in terms of privacy policy conﬁguration. In order to address

these problems, we propose an automated privacy policy recommender system. The system relies on the

expertise of existing OSN users, in addition to the target user’s privacy policy history to provide him/her

with personalized privacy policy suggestions for proﬁle attributes, as well as user-generated content. Results

from our prototype implementation indicate that the proposed recommender system provides accurate privacy

policy suggestions, with minimum user input.

1 INTRODUCTION

Online Social Networks (OSNs) have revolutionized

the way that users interact and communicate online,

by introducing new and innovative ways for self-

expression, information sharing, and relationship for-

mation. Popular OSNs nowadays attract a large num-

ber of users as attested by Facebook which has 1.49

billion monthly active users, of which 968 million

users access Facebook daily (Facebook Inc., 2015).

Likewise, Twitter has drawn about 316 million users

since its creation in 2006 (Twitter, 2015).

Users of OSNs disclose large volumes of informa-

tion during their daily interactions. For instance, ev-

eryday about 350 million photos are shared on Face-

book (Fire et al., 2014), and 500 million tweets are

sent on Twitter (Twitter, 2015). The majority of

this information is sensitive in nature as Gross et al.

(Gross et al., 2013) have pointed out.

The ease with which such sensitive information

can be accessed, and by a large number of people,

exposes OSNs’ users to many privacy and security

risks. Examples of such privacy and security risks

include identity theft, ﬁnancial fraud, cyberstalking,

cyberbullying, insurance and employment discrimi-

nation, embarrassment and losing face with friends

(Fire et al., 2014; Gao et al., 2011; Acquisti et al.,

2007). As a result, in order to protect users against

privacy violations, most OSNs have implemented pri-

vacy policies. Privacy policies are essentially a set

of rules that enable users to control who can access

their disclosed information. For example, OSNs like

Google+ and Facebook have ﬁne grained privacy poli-

cies that allow users to control access to individual

proﬁle attributes such as birthdate, and address, as

well as to user-generated content such as posts, pho-

tos, and videos. However, it has been shown that nu-

merous users fail to conﬁgure their privacy policies

either because they are not aware of the existence of

these policies, or because these policies are complex

and time consuming to understand and conﬁgure cor-

rectly (Madejski et al., 2012; Liu et al., 2011).

Consequently, various automated approaches have

been proposed to assist users with privacy policy con-

ﬁguration. (Fang and LeFevre, 2010; Shehab et al.,

2010; Ghazinour et al., 2013b; Alsalibi and Zakaria,

2013; Sinha et al., 2013; S

anchez and Viejo, 2015).

These approaches are however, limited to either con-

ﬁguring privacy policies for proﬁle attributes, or con-

ﬁguring privacy policies for user-generated content.

126

Abuelgasim, A. and Kayem, A.

An Approach to Personalized Privacy Policy Recommendations on Online Social Networks.

DOI: 10.5220/0005689701260137

In Proceedings of the 2nd International Conference on Information Systems Security and Privacy (ICISSP 2016), pages 126-137

ISBN: 978-989-758-167-0

This is problematic, because both proﬁle attributes

and user-generated content can contain sensitive in-

formation. For instance, users have been documented

to have put their real cellphone numbers on their pro-

ﬁles, and also disclosing their physical whereabouts

in status updates (Gross and Acquisti, 2005; Gun-

decha et al., 2011; Toch et al., 2010; Ghazinour et al.,

2013a). Therefore, protecting proﬁle attributes with-

out user-generated content (and vice-versa), is not a

good privacy protection solution for OSNs. Further-

more, most of the proposed privacy policy conﬁgura-

tion approaches require substantial user input, which

is a time consuming process.

In order to address the aforementioned problems,

in this paper we propose an automated privacy pol-

icy recommender system that enables users to pro-

tect both proﬁle attributes and generated content,

with minimal user input. In summary, the recom-

mender system consists of two main components.

The ﬁrst component, the Proﬁle Attributes Protector

(PAP), utilizes privacy policies that existing experi-

enced OSN users have speciﬁed for their proﬁle at-

tributes, to suggest to new target users

, how to con-

ﬁgure privacy policies for their proﬁle attributes. The

second component, which is the User Content Pro-

tector (UCP), utilizes the target user’s privacy policy

history, to suggest suitable privacy policies for con-

tent that the target user might generate and share in

the future. We designed the recommender system

as ‘server-side’ solution, with the understanding that

this would be maintained by the OSN provider. The

advantage of this solution is twofold, ﬁrst we pro-

tect both proﬁle attributes and user-generated content

which is important in preventing privacy leaks and

second, we alleviate the issue of manual privacy pol-

icy conﬁgurations by providing the users with auto-

mated personalized privacy policy suggestions.

The rest of the paper is structured as follows,

in Section 2 we provide an overview of the related

work on automated privacy policy speciﬁcation in

OSNs. We describe our proposed privacy policy rec-

ommender system in Section 3 and discuss experi-

mental results on our prototype recommender system

implementation in Section 4. Finally, we conclude in

Section 5 with a summary and offer some ideas for

future work.

2 RELATED WORK

Several studies have proposed helping OSNs’ users

In the recommender systems’ literature, the user that

receives the recommendations (i.e. suggestions) is usually

referred to as the ‘target user’.

with privacy policy conﬁguration, by automating the

process of privacy policy conﬁguration. Fang and

LeFevre (Fang and LeFevre, 2010) pioneered this

area with a a mechanism for conﬁguring privacy poli-

cies. Their privacy policy conﬁguration mechanism

follows an active learning approach, whereby for each

proﬁle attribute, the user is prompted to label a subset

of his/her friends by stating whether or not the friends

are allowed to access that proﬁle attribute. Next, the

wizard uses this subset of friends to train a classi-

ﬁer that predicts which of the user’s remaining friends

are allowed (or not allowed) to access that particular

proﬁle attribute. While this approach facilitates set-

ting ﬁne-grained privacy policies, users are required

to provide considerable input to enable the system run

efﬁciently. In fact, for every proﬁle attribute (and one

can have up to 27 attributes) the user is required to

manually label a group of friends, in order to train

the attribute’s classiﬁer. A further caveat of this solu-

tion is that it does not handle privacy policies for user-

generated content, since the classiﬁers are trained to

predict privacy policies for proﬁle attributes only.

Shehab et al. (Shehab et al., 2010) proposed a so-

lution similar to the one of (Fang and LeFevre, 2010),

in which the user is required to label a selected subset

of his/her friends as trusted or not trusted to access

a particular proﬁle object. This subset is then used

to train a classiﬁer that predicts which of the remain-

ing friends are trusted (or not trusted) to access that

particular object. In contrast to (Fang and LeFevre,

2010)’s scheme, the Shehab et al. scheme introduces

an interesting concept, where the resulting classiﬁer

is merged with other neighboring users’ classiﬁers to

enhance the classiﬁer’s performance. However, the

Shehab et al. scheme also requires substantial user

input, because the user has to manually label a group

of his/her friends for every proﬁle object.

Ghazinour et al. (Ghazinour et al., 2013a; Ghazi-

nour et al., 2013b) introduced a tool for recommend-

ing privacy policies called ‘YourPrivacyProtector’.

YourPrivacyProtector uses K-Nearest Neighbours al-

gorithm to ﬁnd the closest 3 proﬁles to the user’s,

and then it uses the privacy policies of the neigh-

bour users to suggest to the user whether to disclose

a particular proﬁle attribute or not. This tool however

only provides coarse-grained privacy policy sugges-

tions. Furthermore, this approach cannot support pri-

vacy policies for user-generated content. Unlike pro-

ﬁle attributes, users might generate different types of

content. For instance, Bob’s status updates are usually

very different form Alice’s status updates. Thus, it is

not feasible to rely on other users content’s policies

for providing suggestions.

On the other hand, Alsalibi and Zakaria (Alsal-

An Approach to Personalized Privacy Policy Recommendations on Online Social Networks

127

ibi and Zakaria, 2013) criticise the approach of (Fang

and LeFevre, 2010), arguing that it incapable of pro-

viding recommendations for user’s who do not have

friends yet. Therefore, Alsalibi and Zakaria proposed

a collaborative ﬁltering privacy recommender system.

In order to recommend privacy policies to a particu-

lar target user; this system ﬁrst identiﬁes a group of

similar users (to the target), and then it uses the most

frequently used privacy policies within this group, to

make privacy policy recommendation to the target

user. However, this system also fails to handle pri-

vacy policies for user-generated content for the same

reason as that of Ghazinour et al.

Sinha et al. (Sinha et al., 2013) were the ﬁrst to

identify that non of the existing approaches, caters for

user-generated content. Therefore, Sinha et al. pro-

pose an automated tool to help users conﬁgure privacy

policies for text-based content. Sinha et al. used the

Maximum Entropy classiﬁcation algorithm (MaxEnt)

to predict and recommend privacy policies for text-

based content. However, despite being able to protect

users’ text-based content, this tool does not provide

any protection for the proﬁle attributes.

Along the same lines, S

anchez and Viejo (S

anchez

and Viejo, 2015) proposed an automated mechanism

to inform OSNs’ users about the privacy risks inher-

ent to their unstructured text-based content, to en-

able users to make more informed privacy policy

choices. The proposed mechanism adopts an infor-

mation theoretic approach, and it works by compar-

ing the text-based content’s ‘sensitivity’ against the

content owner’s ‘privacy requirements’ for all types

of users in the OSN. However, this approach only

warns users about potential privacy conﬂicts within

their generated content, it does not suggest privacy

policies directly to the users.

We note that existing schemes offer automated

tributes or user generated content but not both. This is

problematic, because as mentioned before, protecting

one without the other can lead to privacy violations.

Furthermore, requiring users to provide considerable

content to support privacy policy conﬁguration offers

the advantage of high accuracy, but has the downside

of being cumbersome to use for the average user. In

the following section we discuss the details of our

proposed privacy policy recommender system.

3 PRIVACY POLICY

RECOMMENDER SYSTEM

In order to assist users with privacy policy conﬁgu-

ration we propose a ‘server-side’ privacy policy rec-

ommender system that enables users to protect proﬁle

attributes and generated content, without having to

deal with complex privacy policy conﬁguration pro-

cedures. Our recommender system consists of two

independent components, that work in parallel to pro-

tect the users’ sensitive information. The ﬁrst com-

ponent, which we term the Proﬁle Attributes Pro-

tector (PAP), relies on the privacy policies that exist-

ing users have speciﬁed for their proﬁle attributes to

suggest to presumably na

ıve target users, how to con-

ﬁgure their proﬁle attribute privacy policies. Specif-

ically, the PAP extracts these policies from the pro-

ﬁles of existing experienced users, and uses this data

to build several machine learning classiﬁers, which

in-turn are used to suggest to the target users suit-

able privacy policies for proﬁle attributes. The second

component, which we term the User Content Pro-

tector (UCP). The UCP learns from the target user’s

edge, suggests suitable privacy policies for the target

user’s future content. In other words, the UCP relies

on the targets user’s past privacy policy conﬁgurations

for generated content to train a classiﬁer, that is then

used to suggest suitable privacy policies for the target

user’s future content.

An overview of the recommender is depicted in

Figure 1 below, as shown, in the PAP the training data

is extracted from the proﬁles of experienced users and

used to train several decision tree classiﬁers. The clas-

siﬁers then output privacy policy suggestions for the

target user. The UCP works in a similar fashion, ﬁrst,

the training data is extracted from the target user’s pri-

vacy policy history and used to train a na

ıve bayes

classiﬁer, which outputs privacy policy suggestions

for user generated content.

Training

Data

Decision Tree

Classifiers

Decision Tree

Classifiers

Privacy policies

For Profile

Attributes

Naive Bayes

Classifier

Naive Bayes

Classifier

Privacy

Policies for

Content

Experienced

users' profiles

Training

suggestions

Training

suggestions

The Target

User

Bob

Profile Attributes Protector (PAP)

User Content Protector (UCP)

The Target

User

Bob's Content

History

Training

Data

Train

Extract

Figure 1: An overview of the proposed privacy policy rec-

ommender system.

In the following subsections we begin by ﬁrst

characterizing the theoretical structure of the OSN

model, and then describe how both the PAP and UCP

work to automate privacy policy conﬁguration.

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

128

3.1 OSN Notations

We model an OSN as an undirected graph G = (V, E),

where V is the set of users represented by nodes in the

graph, and E is the set of social relationships between

the users, represented by edges in the graph. Every

user u ∈ V creates and maintains a proﬁle P

, which

is a personal page (or space) that serves as a digital

representation of the user. The user’s proﬁle consists

of a ﬁxed set of attributes A

= {a

,...,a

} and

a collection of pieces of user-generated content C

,...,c

}. Proﬁle attributes A

describe the

proﬁle owner (i.e. the user). These proﬁle attributes

include demographic information such as: age, gen-

der, political views/interests. User-generated content

is the materials created by users during OSN’s in-

teractions. Examples of user-generated content in-

clude: status updates, notes, posts, photos, and so on.

We assume that users can specify privacy poli-

cies, to control access to their proﬁle attributes and

content. A privacy policy is a user-deﬁned rule in

the form < item,l >, where item can be any pro-

ﬁle attribute a

∈ A

or any piece of content c

∈ C

while l ⊆ V represents the audience, that is, the set

of users allowed to access the item. Users are pro-

vided with a ﬁnite set of audiences L = {l

,...,l

}

to choose from. An example of a privacy policy

is < Photo

,Family >, which means only Family

members can access Photo

3.2 Recommendation System

As mentioned earlier, the recommendation system is

composed of two principal components namely, the

Proﬁle Attributes Protector (PAP) and the User Con-

tent Protector (UCP). The Proﬁle Attributes Protec-

tor (PAP) is the component responsible for suggesting

privacy polices for all the proﬁle attributes in the tar-

get user’s proﬁle. While the User Content Protector

(UCP) handles enforcing privacy on the target user’s

generated content.

3.2.1 Proﬁle Attributes Protector (PAP)

In the PAP, we follow a demographic-based ap-

proach to recommender systems, where the motivat-

ing assumption is that: demographically similar peo-

ple have similar privacy policies for their proﬁle at-

tributes. However, in order to get a deeper under-

standing of how the PAP works, we must ﬁrst under-

stand how it suggests privacy policies for individual

proﬁle attributes. The process by which PAP suggests

privacy policies for an individual proﬁle attribute, say

∈ A consists of three main phases.

The ﬁrst phase is the data collection phase. In this

phase, we collect our training data from the proﬁles

of existing experienced users. Speciﬁcally, since the

recommender is designed to be a server-side solution,

we expect that it will have direct access to users’ pro-

ﬁles’ data. Therefore, from existing user’s proﬁle, we

extract the user’s demographic information, and the

. We

then store the collected information in a dataset D,

in which every record is of the form (

F , l

), where

F = h f

, f

,..., f

i is the user’s demographic infor-

mation, representing the features, and l

is attribute

’s privacy policy, and it represents the class label.

The second phase is the classiﬁer training phase.

we train a classiﬁer that predicts the privacy policies

of the a

attribute. For this task we opted to use the

Decision Tree algorithm, because it is capable of han-

dling classiﬁcation of categorical, noisy, and incom-

plete data (Mitchell, 1997), which are the characteris-

tics of our training data D.

In order to build this classiﬁer, we apply a deci-

sion tree learning algorithm on our dataset D, which

builds the classiﬁer as follows. First, the algorithm

looks at the training dataset D and ﬁnds the feature f

∗

that tells us the most about users’ choice of privacy

policies. It does so by using a statistical measure

called Information Gain (Gain for short), which is

given by the following equation.

Gain(D, f

∗

) = H(D) − H(D| f

∗

)

where H(x) is the entropy of X

and is given by H(x) = −p(x) log(p(x))

(1)

The algorithm then uses the feature with the highest

gain (i.e. f

∗

) to create the root node. Afterwards the

training dataset D is partitioned into several partitions,

such that, each partition contains records that have the

same value for f

∗

. Next, for each partition p, the al-

gorithm looks for the feature f

∗p

that has the high-

est gain in p and uses it (i.e. f

∗p

) to create a child

node. The partition p itself is then re-partitioned and

the process is repeated, until every partition has al-

most the same privacy policy, or the algorithm runs

out of training records.

The ﬁnal classiﬁer will be represented as a deci-

sion tree, where each tree node represents a test for

a speciﬁc feature f

∈

F (i.e. demographical trait),

and each edge branching from the node corresponds

to one of possible values of that feature. The leaves of

the tree correspond to privacy policies (i.e. class la-

bels). This decision tree predicts the privacy policies

of the a

attribute, by testing the target user’s features

at the root node, and moving down the tree to a child

node that corresponds to the value of the tested fea-

An Approach to Personalized Privacy Policy Recommendations on Online Social Networks

129

ture. The target user’s features are then retested at the

child node, and moved down the tree progressively.

The process is repeated until a leaf node is reached.

The privacy policy associated with this leaf is the pre-

dicted privacy policy for the a

attribute.

The third and ﬁnal phase is the suggestion phase.

This phase is triggered by the arrival of a target user.

When a target user registers on the OSN, we extract

demographical information form his/her newly cre-

ated proﬁle, and pass it to attribute a

’s classiﬁer,

which in-turn predicts a privacy policy for the a

at-

tribute. This privacy policy is then simply suggested

to the target user. In Figure 2 below, we depict the

process of suggesting privacy policies for individual

proﬁle attributes, that we have described above.

(B) Privacy Policy Suggestion Phase

(A) Data Collection & Model Construction Phases

Users Features

Demographics

Profiles of

Existing Users

Classifier

(Predictive

Model)

Classifier

(Predictive

Model)

The Target User's Profile

Demographics

Privacy

Policy

Training Dataset (D)

Decision Trees

Algorithm

Privacy Policies

Figure 2: The process of suggesting privacy policies for an

individual proﬁle attribute.

So far, we have described how privacy policies are

suggested for one proﬁle attribute. In order to sug-

gest privacy policies for all the attributes in the tar-

get user’s proﬁle, we repeat the previously described

process for each one of the proﬁle attributes. Specif-

ically, we extract demographic information and pri-

vacy policies from the proﬁles of existing users. We

then use this data to build a series of training datasets

,...,D

|A|

}, one for each proﬁle attribute a

∈

A. Next, we apply the decision tree learning algorithm

on these training datasets, to train a series of classi-

ﬁers CL = {cl

,cl

,...,cl

|A|

}. Each classiﬁer cl

∈

CL predicts the privacy policies that the target users

would set for an attribute a

∈ A, ∀i ∈ {1, 2, . . . , |A|}.

Finally, each time a target user registers at the OSN.

We pass his/her demographics to every classiﬁer cl

∈

CL, to predict the privacy policies for each attribute in

the target user’s proﬁle. These predicted policies are

then suggested to the target user.

3.2.2 User Content Protector (UCP)

The UCP is activated after the target user joins the

OSN, and starts generating different types of content

as well as specifying privacy policies for some of the

content he/she has generated.

In the UCP, we follow a content-based approach to

recommender systems, were the motivating assump-

tion is that: similar pieces of user-generated con-

tent have similar privacy policies. Accordingly, the

process by which the UCP suggests privacy policies

for content generated by a particular target user, say

∈ V consists of the following four phases.

The ﬁrst phase is the data collection phase, in this

phase we collect the privacy policy history of the tar-

get user’s content, and arrange it into a dataset Ω,

where every record is in the form (c

), where c

a piece of content generated by the target user u

, and

is the privacy policy that u

has speciﬁed for c

The second phase is the preprocessing phase (i.e.

feature extraction phase), in this phase we transform

every piece of content c

∈ Ω to a vector of fea-

tures that characterize c

, thereby transforming Ω

from a collection of ‘labelled’ user-generated con-

tent, to a dataset of labelled feature vectors

Ω, in

which every record is in the form ( ~c

, l

), where,

= h f

, f

,..., f

i is c

’s feature vector.

The third phase is classiﬁer training phase. Here,

we build the classiﬁer that predicts privacy policies

for the target user’s content. For this task we opted to

use the Na

ıve Bayes algorithm, because it is quick to

test and train, which is a necessity when it comes to

predicting privacy policies for user-generated content.

Speciﬁcally, we apply the Na

ıve Bayes algo-

rithm on our preprocessed dataset

Ω. Na

ıve Bayes

follows a probabilistic model, whereby in order

to predict the privacy policy for a piece of user-

generated content c

. Na

ıve Bayes selects the pri-

vacy policy l

∗

∈ L that maximizes the probability

P(l

| f

, f

,..., f

) ∀l

∈ L, which is the probability

that the privacy policy l

will be observed given that

the features { f

, f

,..., f

} that characterize content

are observed. l

∗

is determined as follows. First,

according to Bayes theorem in equation (2)

P(B|A) =

P(A|B)P(B)

P(A)

(2)

The probability that the privacy policy l

will be ob-

served given that c

’s features (i.e. { f

, f

,..., f

})

are observed, is calculated as follows.

P(l

| f

, f

,..., f

) =

P( f

, f

,..., f

)P(l

)

P( f

, f

,..., f

)

(3)

By assuming that the c

’s features are conditionally

independent, equation (3) can be rewritten as

P(l

| f

, f

,..., f

) =



∏

i=1

P( f

)



P(l

)

P( f

, f

,..., f

)

(4)

Now to ﬁnd l

∗

we select the privacy policy that

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

130

maximizes P(l

| f

, f

,..., f

), which is.

∗

= argmax

∈L





∏

i=1

P( f

)



P(l

)

P( f

, f

,..., f

)



(5)

Since P( f

, f

,..., f

) is constant for all l

∈ L, then

∗

= argmax

∈L



∏

i=1

P( f

)



P(l

)



(6)

Where the probability P(l

) and each of the condi-

tional probabilities P( f

) are estimated from

Ω.

The fourth and the ﬁnal phase is the suggestion

phase, this phase is triggered when the target user u

generates any new piece of content c

new

. We ﬁrst

preprocess c

new

to transform it into a vector of fea-

tures. We then, pass this feature vector to u

’s classi-

ﬁer, which in-turn predicts c

new

’s privacy policy. Then

we simply suggest the predicted policy to u

. In Fig-

ure 3 below, we depict the process of suggesting pri-

vacy policies for user-generated content.

(B) Privacy Policy Suggestion Phase

(A) Data Collection & Preprocessing & Model Construction Phases

New

Content

Content's

Privacy

Policy

History

Preprocessing

Privacy

Policies

Features

Naïve Bayes

Algorithm

Preprocessing

Features

Classifier

(Predictive

Model)

Classifier

(Predictive

Model)

Privacy

Policy

Figure 3: The process of suggesting privacy policies for

user-generated content.

In the next section, we describe the experi-

ments and implementation details of a basic proof-of-

concept prototype of our recommender system.

4 EXPERIMENTS AND RESULTS

In order to implement our proposed privacy policy

recommender system prototype, we carried-out sev-

eral experiments which were primarily focused on

building the classiﬁers that predict privacy policies for

our target users. We generated the training data, us-

ing the Facebook Graph API, and NetLogo which is a

widely used, Agent-Based Modeling and Simulation

(ABMS) environment. We also used Weka, which is

a popular machine learning/data mining package to

train and validate our classiﬁers. Finally, all of our

experiments were conducted on an Intel core i7-4790

3.60 GHz workstation, with 8GB of RAM.

4.1 Implementation and Experiments

with the Proﬁle Attribute Protector

In order to implement the Proﬁle Attributes Protec-

tor (PAP); it’s essential that we obtain rich OSNs

datasets, to build the most important elements of this

component, which are the classiﬁers that predict pri-

vacy policies of proﬁle attributes. However, acquiring

these datasets is difﬁcult, due to the sensitive nature of

OSNs’ data, and the ethical issues associated with it

(Zimmer, 2010). As an alternative, we opted to syn-

thetically generate these datasets through simulating

an OSN, the details of which we describe below.

4.1.1 The OSN Simulation Model

In order to simulate an OSN, we followed an agent-

based approach to modelling and simulation, because

it is suitable for simulating complex systems such as

OSNs (Macal and North, 2011). We implemented our

OSN simulation model using NetLogo.

Our OSN simulation model consists of a set of

agents, representing OSN’s users. For simplicity, we

assigned each agent only eight proﬁle attributes. In

addition, each agent is characterized by three param-

eters namely, a friendship threshold λ ∈ [0,1], which

indicates how friendly an agent is; a maximum nodal

degree δ, which represents the maximum number of

friendships an agent can maintain (Ang and Zaphiris,

2009); and lastly, a privacy concern θ ∈ [0, 1], which

quantiﬁes the agents level of privacy concern (Guo

and Chen, 2012). We assume that λ, δ, and θ are nor-

mally distributed.

We rely on two concepts namely, homophily and

triadic closures to simulate how a user’s friendship

graph is formed. Homophily is the love of the same

(Bakshy et al., 2012), while triadic closures describe

the tendency to make friendships with friends of

friends (Klimek and Thurner, 2013). The idea of us-

ing these concepts is to ensure that our OSN follows

the same pattern of friendship formations as is the

case in typical real-life OSNs. The friendship graph

is formed as follows, each agent u checks whether

its current number of friends has reached its inter-

nal maximum degree δ

. If this is not the case,

then u selects another random agent v, and calcu-

lates the percentage of their identical proﬁle attributes

(u,v)

∈ [0, 1], and percentage of their mutual friends

m f

(u,v)

∈ [0, 1]. Next, if the friendship score, given by

a linear combination of S

(u,v)

and m f

(u,v)

, is greater

than u’s internal friendship threshold λ

. Then a

friendship is formed between u and v. This ‘social-

ization’ process is repeated until all agents reach their

maximum degrees of friendship.

An Approach to Personalized Privacy Policy Recommendations on Online Social Networks

131

The privacy policy conﬁguration process is in-

spired by the work of Guo and Chen (Guo and Chen,

2012), in which proﬁle attributes are classiﬁed by sen-

sitivity (that is privacy weights), and the privacy poli-

cies that are assigned for an attribute, are inﬂuenced

by the user’s level of privacy concern, and the at-

tribute’s privacy weight. Following this heuristic, we

assigned each proﬁle attribute a

∈ A, an arbitrary pri-

vacy weight w

∈ [0,1], that indicates a

’s sensitivity.

In order to set a privacy policy for an attribute, say a

we modelled each agent u to ﬁrst calculate a

’s pri-

vacy score, which is a linear combination of u’s pri-

vacy concern θ

, and a

’s privacy weight w

. We then

map the numerical privacy score to one of four possi-

ble audiences, namely: L = {only me, friends, friends

of friends, public}.

Next, in order to generate our training data, we

used the simulation model to run several simulations

of OSNs of different sizes. By the end of each of

these simulations, we collected every agent’s demo-

graphic information and privacy policies, and stored

it in a dataset. We also generated several control

datasets, where the privacy policies are assigned ran-

domly without going through the simulation model.

4.1.2 Training and Evaluating the Proﬁle

Attributes’ Classiﬁers

For training the proﬁle attributes’ classiﬁers, we used

the J48 algorithm, which is Weka’s implementation

of the C4.5 decision tree learning algorithm. Specif-

ically, we applied the J48 algorithm on each of our

datasets (both simulated and random) to train a clas-

siﬁer for each of our eight proﬁle attributes. Next,

in order to evaluate the performance of these clas-

siﬁers, we performed a 10-fold cross-validation test,

and recorded the accuracy of each model (that is

the percentage of the records for which the classiﬁer

was successful). Cross-validation results show that

the classiﬁers trained on simulated datasets achieved

hight accuracy ranging from 60% to 80%. While

those trained on random datasets were worse, as they

achieved an accuracy ranging from 20% to 30%.

In an effort to further enhance the classiﬁers’ ac-

curacy, we extended the features used in training these

classiﬁers. Particularly, instead of using only demo-

graphics as features, this time we used a combination

of demographics and the privacy policies of other pro-

ﬁle attributes. We then, retrained our classiﬁers on the

new datasets, and measured their accuracy using the

aforementioned methodologies. The results showed

an average of 15% to 25% improvement in the accu-

racy of classiﬁers trained on simulated datasets. On

the other hand, no signiﬁcant improvement was no-

ticed on the accuracy of classiﬁers trained on random

datasets, as illustrated in Figure 4, which shows the

accuracy of two selected proﬁle attribute classiﬁers,

plotted against the size of their training datasets.

100 300 500 1000 2000

100

110

120

●

Performance of Gender Classifier

Dataset size (No. Records)

Classifier's Accuracy (%)

●

Demographics & Privacy Policies As Features

Only Demographics As Features

Random Datasets

(a)

100 300 500 1000 2000

100

110

120

●

Performance of Country Classifier

Dataset size (No. Records)

Classifier's Accuracy (%)

●

Demographics & Privacy Policies As Features

Only Demographics As Features

Random Datasets

(b)

Figure 4: The performance of two proﬁle attribute’s classi-

ﬁers when trained on both random and simulated datasets.

The accuracy of each classiﬁer is plotted against the size of

the dataset used for training it.

At later stages of this work, we obtained a real dataset

used in a similar study. This dataset however, is struc-

turally different than our simulated datasets, as it has

only three demographical features, compared to eight

features in the simulated datasets. Nonetheless, this

dataset can give an insight on how our system will

behave on real OSN data.

Therefore, we applied the J48 algorithm on the

real data, and trained a total of eleven, one for each

proﬁle attribute in the real dataset. Next, we per-

formed a 10-fold cross-validation test, to evaluate

the accuracy of these classiﬁers. The results showed

that, the classiﬁers achieved a relatively high accu-

racy, ranging between 60% to 70%, but is a bit lower

than the classiﬁers trained on the simulated datasets.

Interestingly however, similar to what we observed

with the simulated datasets; the classiﬁers’ accuracy

experienced an average of 17% improvement when

we used a combination of demographics and privacy

policies as features, as illustrated in Figure 5 below.

Next, in order to study and measure the inﬂuence of

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

132

10% 30% 50% 70% 90%

100

●

Performance of Profile Picture Classifier

Dataset size (Pct. Records)

Classifier's Accuracy (%)

●

Demographics & Privacy Policies As Features

Only Demographics As Features

(a)

10% 30% 50% 70% 90%

100

●

Performance of Email Classifier

Dataset size (Pct. Records)

Classifier's Accuracy (%)

●

Demographics & Privacy Policies As Features

Only Demographics As Features

(b)

Figure 5: The performance of two proﬁle attribute’s clas-

siﬁers when trained on the ‘real’ dataset. The accuracy

of each classiﬁer is plotted against the percentage of the

dataset records used for training it.

that each feature have on the classiﬁers accuracy; we

calculated the information Gain of each feature. In-

formation Gain is a statistical measure that quantiﬁes

the reduction of entropy when the value of that par-

ticular feature is known. In other words, it indicates

how much that feature tells us about the target user’s

choice of privacy polices. We then ranked the fea-

tures of each classiﬁer based on the calculated infor-

mation Gain. Initial results showed that demographic

features generally have lower information Gain that

which shows the information Gain of the features of

the Country and Email attribute classiﬁers.

4.2 Implementation and Experiments

with the User Content Protector

In order to implement the User Content Protector; we

focused on building the classiﬁer that predicts privacy

policies for the user-generated content.

Even though users can generate/share different

types of content; however, for the purpose of our ex-

periments we decided to work with text-based con-

tent, because it is availability. However, it is possible

Age−Policy

Language−Policy

Gender−Policy

Interests−Policy

City−Policy

Relationship−Policy

University−Policy

Country

Interest

Language

University

Gender

City

Relationship

Age

Feature Weights − The Country Classifier

Information Gain

0.0

0.2

0.4

0.6

0.8

(a)

Mobile−Policy

DOB−Policy

Name−Policy

ProfilePic−Policy

RelationShip−Policy

Religion

Gender−Policy

Location−Policy

Religion−Policy

Education−Policy

Gender

Location

Language−Policy

Feature Weights − The DoB Classifier

Information Gain

0.0

0.1

0.2

0.3

0.4

0.5

(b)

Figure 6: Shows the features of the Country and Email at-

tribute classiﬁers ranked by their information gain.

to do so with other content types like photos for in-

stance (Squicciarini et al., 2011). Next, we collect the

necessary data for building the classiﬁer.

4.2.1 Data Collection

In order to collect that data necessary for building the

UCP classiﬁer; we used Facebook’s graph Applica-

tion Programming Interface (API) to download posts

(i.e. user-generated content) from one of the author’s

Facebook accounts. Then we manually labelled each

post with a suitable privacy policy. In total we down-

loaded 596 posts, 293 of them were written in En-

glish, and 290 were written in Arabic, while 13 posts

were written in both languages. Next, we discuss how

we transform our raw data into feature vectors.

4.2.2 Preprocessing the Data

In order to transform our recently harvested data Ω,

from a ‘corpus’ of text, to a dataset of labelled fea-

ture vectors

Ω, we used ‘text classiﬁcation’ prepro-

cessing methods. Speciﬁcally, we started the data-

preprocessing with normalising each content (i.e.

post) c

∈ Ω by lower-casing letters and removing di-

acritical marks. Then, we stemmed the data using

An Approach to Personalized Privacy Policy Recommendations on Online Social Networks

133

the lovins stemmer provided by Weka (Arabic con-

tent was left un-stemmed). Next, we used word to-

kenisation to break-down our text corpus Ω into small

units called terms or words (i.e. blocks of consecutive

characters). Then, out of these terms, we only kept

100 terms (per class) to form a term vocabulary V

(which is Weka’s default). Lastly, we vectorized Ω

such that, each content c

∈ Ω is represented as a |v|-

dimensional vector < c

,...,c

>, where c

i j

is a

binary value representing the existence of term j in c

Next, we discuss how we build the UCP classiﬁer.

4.2.3 Building the Classiﬁer

Before we start building the UCP content classiﬁer,

we ﬁrst divided our preprocessed dataset

Ω into: a

training & validation dataset

Ω

(contains 70% of

the records in

Ω); and a test dataset

Ω

(contains the

remaining 30%). As advised by (Sebastiani, 2002).

Next, in order to build the UCP content classiﬁer,

we experimented with applying several algorithms on

our training & validation dataset

Ω

namely: na

ıve

bayes; multinomial na

ıve bayes; complement na

ıve

bayes, in addition to Weka’s SMO algorithm.This

resulted in the construction of multiple classiﬁers.

Since we only need one classiﬁer, we performed a 10-

fold cross-validation test with the intention of select-

ing the best performing classiﬁer. Results showed that

the classiﬁers performed poorly, were the best per-

forming classiﬁer is the one trained using complement

ıve bayes, which achieved 50.11% accuracy.

In an effort to enhance the classiﬁers’ accuracy,

we returned to the data-preprocessing phase. This

time, we increased the size of term vocabulary V to

a maximum of 2000 terms, and removed stop-words

such as a, if, and others. We also changed the vec-

torization such that, each content c

is represented as

|v|-dimensional vector < c

,...,c

>, where c

i j

is a the t f -id f

value. Furthermore, we also cre-

ated another training set (using the same aforemen-

tioned preprocessing steps) but with an additional di-

mensionality reduction step, in which we removed all

terms with information gain less than zero.

After re-training the classiﬁers on the new

datasets, and measuring their accuracy, we noticed an

average of 11.5% performance improvement, where

the accuracy of the best performing classiﬁer (i.e. the

one trained using complement na

ıve bayes) is now

reaching up-to 64%. As evident in Figure 7 below,

which shows the content classiﬁers’ accuracy after

changing the preprocessing phase.

In order to further enhance the classiﬁers accu-

racy, we went back again to the preprocessing phase.

Term frequency-inverse document frequency t f -id f .

Dimensionality Reduction No Dimensionality Reduction

Classifier Performance − Word Tokenization

(10−Fold Cross Validation)

Accuracy (%)

naïve bayes classifier

naïve bayes multinomial classifier

complement naïve bayes classifier

SMO classifier

Figure 7: The accuracy of the UCP content’s classiﬁer when

the training data (i.e.

Ω

) is preprocessed using word to-

kenisation and t f -id f vectorisation.

This time, we used the same preprocessing steps that

we used previously, except for tokenisation, we used

3-gram tokenisation where terms can be sequence

of words instead of individual words. The cross-

validation results showed a small accuracy improve-

ment, while still the highest accuracy is achieved by

the classiﬁer trained using complement na

ıve bayes,

which was around 65.2%. As evident in Figure 8,

which shows the content classiﬁers’ accuracy, after

last changes in the preprocessing phase.

Dimensionality Reduction No Dimensionality Reduction

Classifier Performance − NGram Tokenization

(10−Fold Cross Validation)

Accuracy (%)

naïve bayes classifier

naïve bayes multinomial classifier

complement naïve bayes classifier

SMO classifier

Figure 8: The accuracy of the UCP content’s classiﬁer when

the training data (i.e.

Ω

) is preprocessed using 3-gram

tokenisation and t f -id f vectorisation.

Since, the experimental results showed that the

highest accuracy was achieved by the classiﬁer

trained using complement na

ıve bayes; on a dataset

preprocessed using a combination of normalisation,

stemming, 3-gram tokenisation, stop-words removal,

and t f -id f vectorisation. Therefore, we selected this

classiﬁer to be the UCPs main content classiﬁer. We

then validated this classiﬁer on our ‘untouched’ test-

ing data set

Ω

. The results showed that the classi-

ﬁer’s performance was relatively stable, achieving an

accuracy around 64.2%.

Next, in order to study the affect of the size of the

training corpus on the accuracy of the content classi-

ﬁer; we re-trained the ‘selected’ UCP content classi-

ﬁer several times. Such that, in each time we in in-

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

134

creasing percentage of records from

Ω

to train the

classiﬁer. The results showed that the accuracy of the

UCP content classiﬁer starts to converge when 70%

of the records in

Ω

are used to train the classiﬁer.

As evident in Figure 9.

10% 30% 50% 70% 90%

●

Classifier's Learning Curve

Dataset size (Pct. Records)

Accuracy (%)

●

No Dimensionality Reduction

Dimensionality Reduction

Figure 9: The learning curve of the UCP content classiﬁer

(i.e. the classiﬁer accuracy plotted against the percentage of

records from

Ω

that were used to train the classiﬁer).

4.3 Privacy Analysis - A Discussion

Privacy policies enable users to protect their privacy

by allowing users to specify boundaries, within which

their sensitive information resides. However, since

these boundaries might defer from one user to an-

other; OSN providers tend to provide open (i.e. very

permissive) default privacy policies, thus leaving the

task of conﬁguring (i.e. ﬁne tuning) these policies for

the users. As a result, new users by default have no, or

at best very little privacy, unless they conﬁgure their

privacy policies to suit their privacy needs.

However, for ‘privacy-aware’ users who invest

the time and effort to conﬁgure their privacy poli-

cies, we assume that their policies are correct, and

more privacy-preserving the OSN’s default policies.

By relying on the privacy policies of the existing

OSN’s users, our solution insures that our targets

users’ proﬁle attribute privacy policies, are as privacy-

preserving as the policies of existing ‘privacy-aware’

users, which is better the OSN’s default, and by rely-

ing on the target user’s privacy history, our solution

insures that target user’s content’s privacy policies are

as privacy-preserving as the user’s own privacy his-

tory, which is also better the OSN’s default.

In our experiments with our PAP implementation

we used both simulated and real datasets. Our re-

sults indicate that, when we use simulated datasets,

the PAP was able to suggest privacy policies for pro-

ﬁle attributes with a high accuracy, ranging between

60% - 80%. Furthermore, this accuracy can be im-

proved by up to 25% if we used a combination of de-

mographics and privacy policies as features. When

we used the real dataset however, the accuracy was

slightly lower, ranging between 60% - 70%, but it is

expected given the structural differences between the

simulated and the real dataset. Interestingly however,

we also noticed average of 17% improvement in the

accuracy when we used a combination of demograph-

ics and privacy policies as features. This is indicative

of the fact that the PAP’s accuracy rate can be sig-

niﬁcantly increased, by requiring the user to provide

some privacy policies for a few attributes.

In experiments with UCP implementation, we

used a dataset that we collected from one of the au-

thors Facebook accounts. After experimenting with

several preprocessing techniques, and classiﬁcation

algorithms our results showed that UCP was able to

predict suitable privacy policies for user-generated

content with an accuracy reaching about 65.2%.

5 CONCLUSIONS

In order assist users with privacy policy conﬁguration,

in this paper we proposed an automated privacy policy

recommender system, that caters for proﬁle attributes,

as well as user-generated content. The system con-

sists of two components namely, the Proﬁle Attribute

Protector (PAP), which relies on knowledge and ex-

pertise of existing OSN’s users, to suggest privacy

policies for proﬁle attributes, thus minimizing the in-

put required from the target user; and the User Con-

tent Protector (UCP), which utilizes the target user’s

own privacy policy history, to suggest suitable privacy

policies for his/her future generated content.

We experimented with implementing both of the

recommender system’s components, focusing mainly

on the classiﬁers that predict privacy policies for

users. The experimental results were promising, they

showed that the recommender system was able to

predict (thus suggest) suitable privacy policies with

high accuracy, for both proﬁle attributes and user-

generated content.

For future work we plan to work on improving

the accuracy of the system’s classiﬁers, and conduct

more extensive experiments including implementing

the PAP using real datasets, and studying how the

UCP will ‘generalise’ to other content-types such as

photos for instance. Additionally, the current ‘batch-

learning’ approach that we followed for building the

UCP content classiﬁer, does not handle the scenario

where the target user does not have any generated

content. Therefore, for future work we plan to fol-

low an ‘online learning’ approach, where the content

classiﬁer is built incrementally as new pieces of con-

tent are generated by the target user. We also plan

to work on narrowing down the number of pieces of

An Approach to Personalized Privacy Policy Recommendations on Online Social Networks

135

user-generated contents required for providing accu-

rate privacy policy recommendations.

ACKNOWLEDGEMENTS

Funding for this research was provided by the Na-

tional Research Foundation (NRF) of South Africa

and the Norwegian National Research Council.

REFERENCES

Acquisti, A., Carrara, E., Stutzman, F., Callas, J., Schim-

mer, K., Nadjm, M., Gorge, M., Ellison, N., King, P.,

Gross, R., and Golder, S. (2007). Security Issues and

Recommendations for Online Social Networks. Tech-

nical Report 1, European Network and Information

Security Agency.

Alsalibi, B. and Zakaria, N. (2013). CFPRS : Collabora-

tive Filtering Privacy Recommender System for On-

line Social Networks. Journal of Engineering Re-

search and Applications, 3(5):1850–1858.

Ang, C. and Zaphiris, P. (2009). Simulating social networks

of online communities: Simulation as a method for

sociability design. In Human-Computer Interaction,

volume 5727 of Lecture Notes in Computer Science,

pages 443–456. Springer Berlin Heidelberg.

Bakshy, E., Eckles, D., Yan, R., and Rosenn, I. (2012).

Social inﬂuence in social advertising: Evidence from

ﬁeld experiments. In Proceedings of the 13th ACM

Conference on Electronic Commerce, EC ’12, pages

146–161, New York, NY, USA. ACM.

Facebook Inc. (09-2015). Statistics.

https://newsroom.fb.com/company-info/.

Fang, L. and LeFevre, K. (2010). Privacy wizards for social

networking sites. In Proceedings of the 19th Inter-

national Conference on World Wide Web, WWW ’10,

pages 351–360, New York, NY, USA. ACM.

Fire, M., Goldschmidt, R., and Elovici, Y. (2014). Online

social networks: Threats and solutions. Communica-

tions Surveys Tutorials, IEEE, 16(4):2019–2036.

Gao, H., Hu, J., Huang, T., Wang, J., and Chen, Y. (2011).

Security issues in online social networks. Internet

Computing, IEEE, 15(4):56–63.

Ghazinour, K., Matwin, S., and Sokolova, M. (2013a).

Monitoring and recommending privacy settings in

social networks. In Proceedings of the Joint

EDBT/ICDT 2013 Workshops, EDBT ’13, pages 164–

168, New York, NY, USA. ACM.

Ghazinour, K., Matwin, S., and Sokolova, M. (2013b).

YourPrivacyProtector: A Recommender System for

Privacy Settings in Social Networks. International

Journal of Security, 2(4):11–25.

Gross, R. and Acquisti, A. (2005). Information revelation

and privacy in online social networks. In Proceedings

of the 2005 ACM Workshop on Privacy in the Elec-

tronic Society, WPES ’05, pages 71–80, New York,

NY, USA. ACM.

Gross, R., Stutzman, F., and Acquisti, A. (2013). Silent

Listeners: The Evolution of Privacy and Disclosure

on Facebook. Journal of Privacy and Conﬁdentiality,

4(2):7–41.

Gundecha, P., Barbier, G., and Liu, H. (2011). Ex-

ploiting vulnerability to secure user privacy on a so-

cial networking site. In Proceedings of the 17th

ACM SIGKDD International Conference on Knowl-

edge Discovery and Data Mining, KDD ’11, pages

511–519, New York, NY, USA. ACM.

Guo, S. and Chen, K. (2012). Mining privacy settings to

ﬁnd optimal privacy-utility tradeoffs for social net-

work services. In International Confernece on Social

Computing (SocialCom), pages 656–665. IEEE.

Klimek, P. and Thurner, S. (2013). Triadic closure dynamics

drives scaling laws in social multiplex networks. New

Journal of Physics, 15(6):063008.

Liu, Y., Gummadi, K. P., Krishnamurthy, B., and Mislove,

A. (2011). Analyzing facebook privacy settings: User

expectations vs. reality. In Proceedings of the 2011

ACM SIGCOMM Conference on Internet Measure-

ment Conference, IMC ’11, pages 61–70, New York,

NY, USA. ACM.

Macal, C. M. and North, M. J. (2011). Introductory tuto-

rial: Agent-based modeling and simulation. In Pro-

ceedings of the 2011 Winter Simulation Conference

(WSC), pages 1451–1464. IEEE.

Madejski, M., Johnson, M., and Bellovin, S. (2012). A

study of privacy settings errors in an online social net-

work. In Pervasive Computing and Communications

Workshops (PERCOM Workshops), 2012 IEEE Inter-

national Conference on, pages 340–345. IEEE.

Mitchell, T. M. (1997). Decision Tree Learning. In Tucker,

C. L. B., editor, Machine Learning, chapter 3, pages

52–80. McGraw-Hill, Inc., New York, NY, USA, 1

edition.

anchez, D. and Viejo, A. (2015). Privacy risk assessment

of textual publications in social networks. In Proceed-

ings of the International Conference on Agents and

Artiﬁcial Intelligence, pages 236–241.

Sebastiani, F. (2002). Machine learning in automated text

categorization. ACM Comput. Surv., 34(1):1–47.

Shehab, M., Cheek, G., Touati, H., Squicciarini, A. C., and

Cheng, P.-C. (2010). Learning based access control

in online social networks. In Proceedings of the 19th

International Conference on World Wide Web, WWW

’10, pages 1179–1180, New York, NY, USA. ACM.

Sinha, A., Li, Y., and Bauer, L. (2013). What you want

is not what you get: Predicting Sharing Policies for

Text-based Content on Facebook. In Proceedings of

the 2013 ACM workshop on Artiﬁcial intelligence and

security - AISec ’13, pages 13–24, New York, New

York, USA. ACM Press.

Squicciarini, A. C., Sundareswaran, S., Lin, D., and Wede,

J. (2011). A3p: Adaptive policy prediction for shared

images over popular content sharing sites. In Proceed-

ings of the 22Nd ACM Conference on Hypertext and

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

136

Hypermedia, HT ’11, pages 261–270, New York, NY,

USA. ACM.

Toch, E., Sadeh, N. M., and Hong, J. (2010). Generat-

ing default privacy policies for online social networks.

In CHI ’10 Extended Abstracts on Human Factors in

Computing Systems, CHI EA ’10, pages 4243–4248,

New York, NY, USA. ACM.

Twitter (09-2015). Statistics.

https://about.twitter.com/company.

Zimmer, M. (2010). ”but the data is already public”: On the

ethics of research in facebook. Ethics and Information

Technology, 12(4):313–325.

An Approach to Personalized Privacy Policy Recommendations on Online Social Networks

137
