Harnessing Supervised Learning Techniques for the Task Planning of

Ambulance Rescue Agents

Fadwa Sakr and Slim Abdennadher

Faculty of Media Engineering and Technology, German University in Cairo, Cairo, Egypt

Keywords:

Multi-agent Planning, Learning, Supervised Learning Algorithms, Classiﬁcation, RoboCup, Recsue,

RoboCup Rescue Simulation, Task Planning.

Abstract:

One of the challenging problems in Artiﬁcial Intelligence and Multi-Agent systems is the RoboCup Rescue

project that was established in 2001. The Rescue Simulation provides a broad test bench for many algorithms

and approaches in the ﬁeld of AI. The Simulation presents three types of agents: police agents, ﬁrebrigade

agents and ambulance agents. Each of them has a crucial role in the rescuing problem. The work presented

in this paper focuses on the task planning of the ambulance team whose main role is rescuing the maximum

number of civilians. It is obvious that this target is a complicated one due to the number of problems that the

agent is faced with. One of the problems is estimating the time each civilian takes to die; the Estimated Time

of Death (ETD). Realistic estimations of the ETD will lead to a better performance of the ambulance agents

by planning their tasks accordingly. Supervised learning is our approach to learn and predict the ETD civilians

leading to an optimized planning of the agents tasks.

1 INTRODUCTION

The RoboCup Rescue project was initially triggered

after the Hanshi-Awaji hit Kobe City on the 17th of

January in 1995 causing enormous number of casu-

alties and damage. The aim behind the project was

to use an environment for research and development.

The main target would involve multi-agent planning

and team coordination, physical robotic agents for

search and rescue, information infrastructures, per-

sonal digital assistants, a standard simulator and de-

cision support systems, evaluation benchmarks for

rescue strategies and robotic systems that are all to

be integrated into a comprehensive systems in future

(Kitano and Tadokoro, 2001). Teams from all over

the world participate each year to compete through

proposing new solutions and tactics for overcoming

these disastrous scenarios with minimal losses.

The RoboCup Rescue simulation is a league

driven from the Rescue project. The simulation mod-

els an earthquake in an urban centre presented in the

form of a map. The simulated earthquake causes

building to collapse, roads to be blocked, ﬁres igni-

tions, and civilians to be trapped and buried inside

collapsed buildings. Typically, specialized rescuing

forces would be needed for damage control. In the

simulation world, there are three teams that are re-

sponsible for all rescuing purposes; the ambulance

team, ﬁre-brigade and police forces. The role of the

ambulance team is to rescue and save buried civil-

ians and safely get them to refuges. As for the ﬁre-

brigades, their task is to extinguish building that catch

ﬁres. Finally, the police forces’ main concern is to

clear all roads from rubble and other debris. Thus,

clearing the way for the other agents to move freely.

The research question and motive for all participat-

ing teams in the league is to ﬁnd a utilized plan for

each team to reach the maximum possible damage

control. Moreover, the plan has to be a generic one,

that would efﬁciently deal with all possible scenar-

ios. Furthermore, we need to have a dynamic plan

that would ﬁt all possible scenarios enabling the am-

bulance team to save the maximum number of civil-

ians, the ﬁre-brigades to extinguish the maximum

number of ﬁres, and the police forces to clear the

maximum number of roads. Such aim can only be

achieved through agent coordination and team work.

A wide bench of research and application of different

techniques and strategies would be needed to solve

a multi-agent planning optimization problem such as

the rescue problem.As described in (Hussein et al.,

2012), the rescue problem can be divided into three

main tasks: extinguishing buildings on ﬁre, saving

civilians, and clearing blocked roads. In the scope of

Sakr, F. and Abdennadher, S.

Harnessing Supervised Lear ning Techniques for the Task Planning of Ambulance Rescue Agents.

DOI: 10.5220/0005692001570164

In Proceedings of the 8th International Conference on Agents and Artiﬁcial Intelligence (ICAART 2016) - Volume 1, pages 157-164

ISBN: 978-989-758-172-4

157

this paper, we are mainly focused on the tasks of the

ambulance team, which consists of saving the maxi-

mum number of civilians.

The ambulance team is faced with a large num-

ber of obstacles and challenges in order to achieve the

above mentioned goal, thus, increasing the need for

optimized planning and coordination. Predictions of

the ETD of civilians is one of the steps for achieving

this goal. Harnessing supervised learning techniques

for task planning has been the new approach for tack-

ling planning problems such as the problem of the

ambulance team. Consequently, many of the teams

participating in the competition have been working in

similar scenarios and techniques, along with multiple

participation for the team motivated us for exploring

such options.

In (Guan et al., 2010) ZJU team used particle ﬁl-

ters to tackle the problem of implicit parameters pro-

vided by the simulator, thus predicting the ETD of the

civilians. They ﬁrst generate a set of particles, where

each particle in a triple of (Hp, Damage, Rate). Hp

and Damage are obtained by observations of the civil-

ians behavior, while Rate is a value randing from 0 to

1 indicating the growth rate of damage. After each

time step particles are updated using a given dam-

age model. Moreover, they introduced a quantization

range used for classifying new observations and de-

ciding whether or not the values of old particles re-

mained legal or not.

In 2013, team Poseidon modeled the ambulance

problem using the Knapsack algorithm (Afzal et al.,

2013). The Knapsack problem is deﬁned using a set

of items each with a given value and cost. The aim is

to choose the item of the minimum cost and maximum

value, while not exceeding some given cost, capacity

and ensuring that the total value is as large as possible.

With regards to the ambulance problem maximizing

the value means maximizing the number of rescued

civilians. Moreover, each civilian has a value and a

cost that is determined based on multiple values, one

of which is the estimated death time of the civilian.

For the ETD they used the learning model presented

by ZJU team (Guan et al., 2010).

In previous years, the S.O.S team depended on

particle ﬁlters for estimating the death time of the

civilians. However, after evaluating the approach dur-

ing the competition, some mistakes were discovered

and the team switched to decision trees for predict-

ing the ETD (Hesam et al., 2015). The team used a

state space that consisted of 15 states. Moreover, the

team decided to not only depend on the ETD for task

allocation, but also include the health points of the

civilians to do so.

Even though learning has been used previously for

tackling multi-agent planning problems, to our best of

knowledge supervised learning has never been used

for this particular problem so far. The motivation be-

hind the choice is that given the simulation environ-

ment, it is convenient to have a training phase based

on observations of the environment to have an accu-

rate outcome. The outcome would be later used for

learning and future predictions.

The paper is organized as follows. In Section 2,

the supervised learning approach is discussed thor-

oughly. An evaluation of the work is presented in 3.

Finally, in Section 4 we conclude and give some di-

rections for future work.

2 OUR APPROACH

The main target for the ambulance team is to save

the maximum number of civilians possible. This im-

plies the maximum utilization of the time ahead of

each agent, along with using all possible resources

available such as the communication channels and the

help of other agents throughout a coordination and co-

operation plan. First to tackle the problem of time

we needed to make sure that no time will be wasted

on targets that will die either during or after rescu-

ing. That was a problem in previous implementa-

tion in which civilians were prioritized according to

the shortest distance from each agent. Our approach

introduces a new solution for the problem through

learning the ETD of each civilian; using which we

were able to utilize the planning of each agent dur-

ing rescuing. This was achieved using a supervised

learning algorithm.

2.1 Learning

In each time step of the simulation, the state of any

given civilian changes according to a set of parame-

ters determined and rapidly changed by the simulator.

This set consists of the following parameters:

• HP : Health points of a civilian stating how

healthy the civilian is. It starts with an initial

value, when it reaches zero it means the civilian

is dead.

• Damage: The points that will be deducted from

the civilian HP each time step.

• Buriedness: The level of buriedness of a civilian

within a building.

Typically having these parameters through arith-

metic calculations, we could know when exactly will

the civilian die i.e. the ETD. Unfortunately, the dam-

age value provided by the simulator is not accurate

ICAART 2016 - 8th International Conference on Agents and Artiﬁcial Intelligence

158

but rounded to the nearest 10 and the HP value is

rounded to the nearest 1000. Moreover, the growth

rate of damage also differs a lot from one civilian to

the other even if their original damage values were

the same. In order to overcome these implicit val-

ues and tackle our problem a learning approach had

to be introduced. Supervised learning is used when

some correct input-output pairs are known. That was

the case here since the simulator environment already

provides some parameters indicating whether or not

a civilian is alive, i.e.the HP through each time step

along with other multiple parameters. In other words,

the feedback available from the server or the simula-

tor was our motivation towards a supervised learning

approach.

2.1.1 Training Dataset

A training dataset was to be obtained for a further

learning phase. This set was the result of exhaus-

tive runs of multiple maps, where the behavior of the

agents changed to fulﬁll this purpose. Instead of res-

cuing the civilians the agents were to observe and

log their state during each time step. Some further

changes were done to the simulator for the training

phase. All obstacles that normally would face the

agents were disabled. For example, maps were run

with no blockades, both the ﬁre simulator and the

ignition simulator were disabled as well, which led

to ﬁre-less scenarios for all the maps we ran. This

training dataset represented the history of each civil-

ian ever since the simulation started till the civilian is

dead. That would be the base of the learning model

that agents use to learn the ETD of a civilian when

planning their actions.

The training dataset could also be modeled as a

decision tree in which given the values of some at-

tributes a certain goal predicate is evaluated to either

true or false. The goal predicate deﬁned in our tree

model is the health state of the civilian. The pred-

icate outcomes true if the civilian is dead and false

otherwise. A is a set of attributes A

, A

, . . . , A

of the

decision tree. A set of arity 4 was used in our model.

The four parameters of the set are the following:

• Unique ID of the civilian

• HP of the civilian

• Damage rate

• Buriedness level

Each pair of the dataset is called an example. An ex-

ample is a pair ((v

, v

), f (v

, v

)) where

is the value of A

. A positive example is an ex-

ample where f (v

, v

) is true. Otherwise it is

a negative example. In our decision tree a positive

example means the civilian is dead. In that case, an

extra attribute is added to this example and that is the

time when this civilian died. This additional attribute

will be used later on for labelling the training dataset.

Certainly this decision tree model of the dataset is not

sufﬁcient enough for a supervised learning classiﬁca-

tion. Since not all examples are of the same input and

output format needed for a supervised learning clas-

siﬁer, only positive ones have the ETD of the civilian

added. This enforced some further preprocessing of

the training dataset.

2.1.2 Data Preprocessing and Labelling

For a supervised learning algorithm to be applied on a

training dataset, each example of that set has to have

an output attribute, which is the output value of the

classiﬁcation. In the proposed model this attribute is

the death time of the civilian. This desired formatting

of the dataset is not yet present, due to the fact that

the only labeled or positive pairs are the ones that be-

long to a dead civilian leaving all negative examples

unlabeled.

The preporcessing of the data focused mainly on

matching every positive labelled example with all the

negative unlabelled examples that belong together, in

the sense of belonging to the same civilian. The

unique identiﬁer that each civilian has and which was

previously included in the set of attributes of the de-

cision tree was used for the matching. For each neg-

ative example, if it has a matching positive example,

then it will be labelled with the same value of ETD.

If no match was found, it means that the civilian was

alive till the end of the simulation. In this case, the

pair will be given the value of the time the simulation

ends. After the matching of all pairs the identiﬁers

of the civilian shall be removed from the training set

since there will be no use for it anymore.

So far what we have is a training dataset that con-

tains pairs of values for each attribute in the set and a

value for the time where this civilian will die even if

it is not dead yet. This dataset will be used as an input

for a learning classiﬁer, that will be applied later to

classify the time of death of each civilian according

to the given training set.

2.1.3 Learning Classiﬁers

Given the training dataset, we would like to learn the

relation between the input pairs (HP, Damage, buried-

ness) and the output (ETD). This relation was ob-

tained ﬁrst by training the dataset and then using the

output learning model for future predictions. Thus, a

classiﬁer is needed to achieve both goals. The output

being a numeric one discarded some classiﬁers from

Harnessing Supervised Learning Techniques for the Task Planning of Ambulance Rescue Agents

159

the large pool of classiﬁers now present. After fur-

ther ﬁltration enforced by restrictions of our problem,

we chose linear regression as our classiﬁer here. The

Weka tool

was used for all learning purposes.

In our model the output variable often referred to

as the target is the ETD, while there might be none

in case the civilian is alive till the end of the simula-

tion. The ETD still has a large number of possibilities

and that was the main reason for choosing linear re-

gression. In linear regression the output variable or

the target can have a value from an inﬁnite number of

possible values (Lane, 2015). A learning model can

be used for predictions of the ETD of any given input.

This prediction is done using the following equation:

y(x

n+1

) = θ

+ x

n+1

∗ θ

(1)

Where y is a function used for evaluating the line at

point x

n+1

and ﬁnding a label for it, θ

is the slope

of the linear line and θ

is the intercept of y. Now

for the prediction to work we need to learn both θ

and θ

(Murphy, 2012). Applying the classiﬁer on the

previously obtained training dataset we were able to

do so resulting in the following model:

ETD = −0.009 ∗ hp − 0.9197 ∗ damage

+ 0.2056 ∗ burridness + 328.291 (2)

When using machine learning classiﬁers some testing

need to be done to ensure smallest range of error pos-

sible. There are various methods to do so. However,

here we chose cross validation for testing. The idea

of cross validation is to estimate how well the current

dataset can predict an output value for any given in-

put instance. This is done by using a fraction of the

dataset and testing the prediction of it using the rest of

the dataset. The same process can be repeated using

different subsets of the data. A 10 fold cross valida-

tion was applied to the training dataset leading to the

following results:

-Correlation coefficient 0.5189

-Mean absolute error 32.9997

-Root mean squared error 39.6019

-Relative absolute error 85.2929%

-Root relative squared error 85.4812%

After the learning of the training dataset, we were

able to do some predictions of the ETD of any given

instance provided by the agent. Moreover, we were

able to learn more about the direct relation between

each of the model attributes and the ETD of the civil-

ians. This relation was a bit unclear before due to

the implicit attributes provided by the simulator. Pre-

sented in Figure 1 a plot for the damage rate as y-

axis against health points as x-axis, in which civil-

ians having the same health points are classiﬁed into

http://www.cs.waikato.ac.nz/ml/weka/

different classes mainly depending on the damage.

Similarly, civilians of high damage tend to belong to

classes of low ETD (blue instances), while the ones

with low damage belongs to classes of high ETD (or-

ange instances). Moreover, there are instances of the

same HP and damage, however, belong to different

classes. Thus, showing that depending on only the

health points or the damage to determine the prior-

ity for saving civilians would be highly inaccurate

and unreliable. Which was the strategy followed

in previous approach before using the new learning

model(Abouraya et al., 2014). After ﬁnalizing the

learning model, the next phase was to integrate this

model with the task planning of the agents.

Figure 1: Damage vs health points.

2.2 Planning

Rescue agents need to plan their decisions to reach

their restricted goal that is saving the maximum num-

ber of civilians possible. The main source of infor-

mation for the agent is the world model maintained

from the simulator each time step. The world model

is based on the change set of the agent; what the agent

sees and hears formulate the world model of the agent.

In addition to a communication model based on a de-

centralized plan, an approach used for multi-agent

planning (Abouraya et al., 2014), where all agents

communicate together through communication chan-

nels. The communication model helps the agent re-

ceive information about parts of the map outside the

agent’s world model. A third source of information

now added to the agent’s decision making process is

the learning model previously obtained. As shown in

Figure 2 the three models are the input to the plan-

ner according to which the agent gain an extra set of

information namely the ETD about the target. Subse-

quently, a decision making process to evaluate all pos-

sible actions and chose one to perform had to follow.

ICAART 2016 - 8th International Conference on Agents and Artiﬁcial Intelligence

160

Analogously, ambulance agents plan their actions and

start acting accordingly.

Figure 2: Model of the implemented approach.

2.2.1 Decision Making

Ambulance agents have a set of actions to perform:

load/unload a target, rescue a target or move towards

a target. In the scope of this section we are mainly

concerned with the last two actions. Based on the

three models that provide information to the agent, the

agent decides upon which action to perform at each

time step. Previously, the world model was the most

important one of them all. Accordingly, the agent

based all decisions regarding which civilian to save

ﬁrst, either on the shortest distance or the HP of the

civilians. In addition, agents only decided to move

towards the target only if it is still in line of sight.

Meaning that if a target is reachable but not in the

agent’s line of sight, this target would have less pri-

ority than the one who is currently seen by the agent

regardless if which is in more danger. As discussed in

Section 2.1.3 that was not the most accurate or reli-

able decision. Then the communication model is next

in the order of priority, through which agents receive

information about buried civilians outside the world

model. If the agent has no reachable targets within

the world model, then it starts choosing targets from

the reported ones. Similar to the seen targets of the

world model, civilians were also prioritized accord-

ing to distance and HP as well.

The introduced learning model now acts as an

intermediate level between what the agent perceives

from the world model and deciding which action to

do. The model takes as an input the parameters re-

ceived from the server for each civilian in the agent’s

line of sight and outputs the ETD of the civilian. Af-

ter comparison of civilians’ ETD, the agent starts pri-

oritizing the tasks accordingly, giving civilians with

low ETD a higher priority than the ones with a higher

ETD. Subsequently, if the agent is faced with two tar-

gets, one with a high priority but not in line of sight

and the other one with a lower priority and in line of

sight, then the agent will decide to move towards the

former target instead of the latter. The task priori-

tizing process does not intervene with the actions the

agent decides to do, as it takes place at the beginning

of each time step, when the thinking process of the

agent is just starting. By the time the agent is ready to

make a decision all tasks should have the appropriate

priority. Whenever the agent decides to rescue a civil-

ian, the estimated time of rescue would be calculated

and added to the current time step, if it exceeds the

ETD of the civilian then the agent would have to call

out for other agents to help.

Similar to the previous planner, in cases where the

agent has no decisions to make regarding all seen tar-

gets -if none of the targets are reachable- the agent

moves on to targets that are reported as buried by

other agents. However, some adjustments had to be

done to the communication model in order to be syn-

chronized with the new planner. One of which is that

all agents in the map either ambulance, police or ﬁre-

brigades were to use the new learning model before

reporting any buried civilians. With the use of the

new model, agents are able to predict the ETD of the

seen targets and add them to the reported message

delivered to other agents. This requires the learning

model to be generic enough to be used by any type of

agent. Upon receiving a reported message, the ambu-

lance team agents proceed with their task prioritizing.

However, in this case agents have only one decision

to make which is moving towards the target. Once a

target is reported to an agent, it means that this target

is outside the agent’s line of sight. Thus, the decision

making process here is different than the one of the

targets extracted from the world model.

2.2.2 Time Versus Distance

The message for reporting buried civilians previously

consisted of the target’s location, since the target is

not in the agent who is receiving the message line of

sight. Currently after the new approach, the ETD of

the target is added to the message along with the loca-

tion. For an agent to move from one point in the map

to another a path has to be provided for the agent to

follow. This path is a set of nodes, where each node

is an entity on the map. An entity could either be a

road or a building. For a more formal presentation,

the nodes of the map were structured in the form of

a graph. Some factors related to the rescue problem

had to be taken into consideration, one of which is

that blocked roads are constantly removed from the

graph. Similarly, cleared roads are restored once they

are reported to be clear. The search algorithm used in

previous work based on (Abouraya et al., 2014), for

searching the graph and constructing a path is Breadth

First Search (BFS). The aim of the algorithm is to ﬁnd

the shortest path to the target node. If the agent had no

way to reach any of the seen targets, the agent would

Harnessing Supervised Learning Techniques for the Task Planning of Ambulance Rescue Agents

161

search the graph for the closest reported target, fol-

lowed by a movement towards that target.

Initially, we followed the same approach for plan-

ning the task of rescuing reported targets the same

way as we did with seen targets. For any given agent,

all reported civilians are sorted and prioritized accord-

ing to their ETD. When the agent decides to rescue

targets that are reported to be buried, the agent starts

moving towards the reported civilian with the lowest

ETD using the shortest path constructed through BFS.

However, the time an agent takes to reach a certain

location on the map; namely the Estimated Time Of

Arrival(ETA) rapidly changes according to different

factors, e.g. the number of nodes in the path, along

with the speed of the agent, percentage of blockades

in each road and some other factors. This means that

the ETA of an agent might exceed the ETD of the

civilian with the highest priority, resulting in the civil-

ian’s death. Additionally, wasting time on a task that

was de-prioritized and overestimation of the cost to

reach a certain target, which happened to be the case

during evaluation.

In order to combine the two approaches together,

exploiting both the learning model and the shortest

path for reaching targets, a search algorithm inspired

by A

∗

search was the chosen search paradigm. A

∗

search is the best-ﬁrst search algorithm. It is also

known to be the only optimal algorithm for expanding

the minimum number of nodes in any search space,

besides being complete (Russell and Norvig, 1995).

The expansion of the nodes is dependant on the eval-

uation function f (n), which is an estimation of the

cheapest solution from node n. The function is de-

ﬁned as the following:

f (n) = g(n) + h(n) (3)

where

• g(n) is the path cost from node n to the goal.

• h(n) is the heuristic function.

For the algorithm to be an A

∗

search h(n) has to be

an admissible heuristic h

∗

(n), which was not the case

in the chosen heuristic here. So an approximation

of the optimal heuristic function h(n) will be used

here to estimate the cost of the optimal function h

∗

(n)

(Bonet and Geffner, 2001). In our example, the g(n)

was deﬁned as the length of the shortest path from

the agent’s location to the desirable target. This path

was constructed using BFS algorithm, guaranteeing

that it would be the shortest available path to the tar-

get. The heuristic function h(n) is the ETD of the

target. The combination of these two functions led to

the following prioritization of the agent’s tasks: tar-

gets that are closest to the agent with a low ETD will

have higher priority than further targets with a higher

ETD. In other words, if an agent is faced with two tar-

gets t

and t

, the length of the path to both targets is l

and l

and the ETD is e

and e

respectively. First, in

the case of both targets being located at the same dis-

tance from the agent, then the evaluation function will

choose the target with a lower ETD. Additionally, the

case of one target with a closer location to the agent

than the other one, assuming that l

< l

, the agent

will be faced with one of two decisions:

1. if e

≤ e

then t

would be of higher priority than

2. if e

> e

, t

would be chosen, if and only if,

− e

> l

− l

. Meaning that if the agent de-

cided to move towards t

by the time it reaches t

it will most likely die before then. However, this

will not be the case using the evaluation function

presented above. Otherwise, t

will be of higher

priority as well.

3 EVALUATION

The goal of our solution for the rescue problem is to

maximize the number of rescued civilians by utiliz-

ing the task planning of the agents. Thus, the num-

ber of rescued civilians was chosen to be the evalua-

tion measurement of our approach. Another measure-

ment of the overall performance of the agents would

be the ﬁnal score, which is calculated by the simula-

tor kernel for each running scenario and map. How-

ever, we couldn’t highly depend on this score for test-

ing our approach, since the rescue simulation depends

on a number of components and factors as mentioned

in section 1. Meanwhile, our solution only targeted

the ambulance team. That’s why to ensure an accu-

rate evaluation of our approach, the same environment

mentioned in section 2.1.1 for obtaining the training

dataset was used for testing as well. The aim of the

evaluation is to test whether the introduced learning

model used for task prioritization and planning helped

enhance the performance of the ambulance team or

not. Moreover, we also wanted a conﬁrmation that it

is better than previous work such as (Abouraya et al.,

2014).

For achieving this goal, we ran multiple maps that

were released and used in the RoboCup 2015 world

ﬁnals

. Each map was tested using three different

strategies. The ﬁrst strategy was using the learning

model to predict the ETD of the targets and priori-

tize them accordingly. Another strategy was prioritiz-

ing civilians according to the shortest distance from

the agent. The ﬁnal approach used the targets HP to

http://goo.gl/IXI31O

ICAART 2016 - 8th International Conference on Agents and Artiﬁcial Intelligence

162

plan and prioritize the agent’s tasks. Even though, the

three strategies followed different methods for task

prioritization, they all used the same new planner in-

troduced in this paper for completing their tasks. At

the end of each run, the number of civilians rescued

was extracted and used to produce the statistics pre-

sented in Figure 3. The graph shows that in most

cases the presented new approach outperforms the

other two strategies in terms of how many civilians

were rescued. Moreover, given the average number

of civilians in each map, the presented statistics will

show that using the ﬁrst strategy 77% of the civil-

ians are rescued. In comparison to 56% in the case

of the second strategy and 64% in the third case. Cer-

tainly, different scenarios might lead to different out-

comes, as the simulation environment is highly non-

deterministic. Moreover, the initial distribution of

both agents and civilians in the map also contributes

to how the rest of the simulation proceeds. As was

the case in some of the maps used for testing such

as Istanbul1.However, given the presented statistics,

the performance of the new approach will out perform

any of the other two approaches if used alone by min-

imum 10%.

Figure 3: Graph showing number of civilians rescued per

map.

Another evaluation measure is to use the ﬁnal

score of the map. However, not all maps are fully de-

pendant on the ambulance team, so we had to pick

a map that would only test the performance of the

ambulance agents. In such maps the score will be

directly affected by the number of civilians rescued,

since no other factors have an equivalent high effect.

The Paris1 map that was presented in RoboCup 2014

world ﬁnal competition

was chosen for this task.

Formerly, during the competition, the new approach

was proposed but was not yet ﬁnalized or integrated

with the work. Task planning was still mainly depen-

dant on calculating the distance between the agent and

http://roborescue.sourceforge.net/2014/results/

the targets. After the new approach was ﬁnalized, the

new implementation was tested against the old one

using the mentioned map for score comparison.

Figure 4: Paris1 using 2014 approach.

Figure 5: Paris1 using 2015 approach.

Figures 4 and 5 are two screen shots after running

Paris1 map using both the old approach and the new

one respectively. The difference in scores between

the two maps is almost 70 points which is immense.

Moreover, the ﬁgures show a big gap between the two

approaches in terms of rescued civilians. Similar to

the previous evaluation phase, this comparison lead to

the conclusion that when faced with a scenario fully

dependant on the ambulance team, the new approach

clearly outperforms the old one. Furthermore, in Fig-

ure 4 the resulting map shows that some of the previ-

ously rescued civilians died in the refuge. As civilians

then were chosen according to their distance from the

rescuing agents, so the possibility of a civilian to die

Harnessing Supervised Learning Techniques for the Task Planning of Ambulance Rescue Agents

163

while or even after rescuing is high. Whereas, us-

ing the new approach in Figure 5 this is not the case.

Since civilians were chosen and prioritized according

to their ETD, decreasing the possibility of their death

after they have been rescued.

4 CONCLUSION

Including a new learning model in the ambulance

team agents thinking process helped utilize the agents

time while carrying out with their rescuing duties.

This model was the outcome of a training data set that

was trained using linear regression algorithm. Subse-

quently, the model was used for serving the planner

by allowing agents to predict the ETD of the civil-

ians. The planner then uses the ETD for task prior-

itizing and planning. Moreover, the ETD was also

used for optimizing the search algorithm that con-

structs paths for the agents to move from one location

on the map to another. This was done by replacing

the old traditional breadth ﬁrst search by a heuristic

search, which includes the ETD as a heuristic for the

evaluation function of expanding nodes. According to

the exhaustive evaluation performed as mentioned in

section 3, both the learning model and the new plan-

ning helped increase the number of rescued civilians

by more than 10% compared with other strategies,

such as depending on the HP of the civilians or the

distance for tasks planning.

However, during evaluation there were some sce-

narios where the new approach performed almost

similar to the other two approaches. This is likely

to happen since the two parameters used for the other

two approaches are practically a part of the new learn-

ing model and planner, especially, the one with the

civilians sorted according to their HP. In future work,

we are planning to use a more weighted classiﬁcation

for further enhancements of the results. For exam-

ple, the HP in the used training dataset could have a

larger weight than the other parameters in both the

training and prediction phases. Additionally, when

the approach was tested against previous approach us-

ing a map highly dependent on the ambulance perfor-

mance, better scores were achieved.

The new proposed solution did not only help op-

timize the task planning of the agents and achieve

better results. It also helped overcome the obstacles

enforced by the inaccurate values retrieved from the

simulator regarding civilians. In other words, having

the training dataset was the reason the relation be-

tween these parameters was ﬁnally revealed and un-

derstood. As mentioned in Section 2.1.3, the pre-

sented graphs showed that neither the HP nor the

damage can determine the ETD of the civilian if used

alone. This strategy was previously used for rescuing

civilians. This explains why having a training dataset

that consists of multiple parameters was highly effec-

tive to determine and predict the ETD. Moreover, this

helped clarifying what are the parameters that mostly

affect the state of the civilian at each time step.

REFERENCES

Abouraya, A., Helal, D., Sakr, F., Khater, N., Osama, S.,

and Abdennadher, S. (2014). Clustering and planning

for rescue agent simulation. In RoboCup 2013: Robot

World Cup XVII, pages 125–134. Springer.

Afzal, A., Alizadeh, P., Nezhad, M. A., Ghaffari, K., Hasan-

pour, G., Jahedi, K., Kaviani, P., and Omidvar, G.

(2013). Poseidon team description paper robocup

2013, eindhoven.

Bonet, B. and Geffner, H. (2001). Planning as heuristic

search. Artiﬁcial Intelligence, 129(1):5–33.

Guan, D.-q., Chen, N., and Jiang, Y.-h. (2010). Robocupres-

cue 2010-rescue simulation league team description.

In RoboCup 2010 Symposium Proceeding CD. Singa-

pore: RoboCup Foundation.

Hesam, A., Taheri, P., Ameri, M., Al-Bouye, M., and

FaghaniLemraski, M. (2015). Robocup rescue 2015

rescue simulation league team description paper.

Hussein, A., Gervet, C., and Abdennadher, S. (2012).

Multi-agent planning for the robocup rescue

simulation-applying clustering into task alloca-

tion and coordination. In ICAART (2), pages

339–342.

Kitano, H. and Tadokoro, S. (2001). Robocup rescue: A

grand challenge for multiagent and intelligent sys-

tems. AI magazine, 22(1):39.

Lane, D. M. (2015). Online statistics education: An inter-

active multimedia course of study.

Murphy, K. P. (2012). Machine learning: a probabilistic

perspective. MIT press.

Russell, S. and Norvig, P. (1995). Intelligent agents. Artiﬁ-

cial intelligence: A modern approach, pages 46–47.

ICAART 2016 - 8th International Conference on Agents and Artiﬁcial Intelligence

164
