Interaction Patterns in Computer-assisted Semantic Annotation of Text

An Empirical Evaluation

Jaroslav Dytrych and Pavel Smrz

Brno University of Technology, Faculty of Information Technology, IT4Innovations Centre of Excellence,

Bozetechova 2, 612 66 Brno, Czech Republic

Keywords:

Computer-assisted Tagging, Semantic Annotation, Event Extraction.

Abstract:

This paper examines user interface options and interaction patterns evinced in tools for computer-assisted se-

mantic enrichment of text. It focuses on advanced annotation tasks such as hierarchical annotation of complex

relations and linking entities with highly ambiguous names and explores how decisions on particular aspects

of annotation interfaces inﬂuence the speed and the quality of computer-assisted human annotation processes.

Reported experiments compare the 4A annotation system, designed and implemented by our team, to RDFaCE

and GATE tools that all provide advanced annotation functionality. Results show that users are able to reach

better consistency of event annotations in less time when using the 4A editor. A set of experiments is then

conducted that employ 4A’s high ﬂexibility and customizability to ﬁnd an optimal amount of displayed infor-

mation and its presentation form to reach best results in linking entities with highly ambiguous names. The

last set of experiments then proves that 4A’s particular way of implementing the concept of semantic ﬁltering

speeds up event annotation processes and brings higher consistency when compared to alternative approaches.

1 INTRODUCTION

Semantic annotation of text has become a popular

topic of the natural language processing in recent

years. Various tools have been developed that au-

tomatically enrich text with semantic annotations.

However, the quality of results achieved using fully

automatic approaches varies signiﬁcantly across an-

notation tasks and input data. It can be particularly

low for complex and highly ambiguous cases Moro

and Navigli (2015); Surdeanu and Heng (2014).

There is still a room for computer-assisted man-

ual annotation. Although it would not be wise to rely

on user tagging of extremely large amounts of tex-

tual data available on the current web, manual anno-

tation is still used in the preparation of training data

for supervised machine learning methods, for anno-

tation validation tasks, constructing meaning through

annotations, etc. To support the annotation process,

various semantic editors, crowdsourcing plugins for

existing tools and web browser annotation extensions

have been created Ciccarese et al. (2012); Grassi

et al. (2013); Handschuh et al. (2002); Heese et al.

(2010). Also, general linguistic annotation tools such

as BRAT Stenetorp et al. (2012) are frequently used

for manual creation of annotated data.

The high number of existing annotation systems

contrasts with the fact that there are very few stud-

ies comparing particular features of the tools and

discussing their suitability for speciﬁc tasks (some

of them are brieﬂy reviewed in Section 2 – Re-

lated work). To the best of our knowledge, no ex-

isting study compares design patterns employed in

such tools that are relevant for complex annotation of

events and disambiguation of highly ambiguous en-

tities. This is the main purpose of the set of experi-

ments conducted by our team.

People understand the term event intuitively as

who did what to whom when and where. However,

deﬁnitions of the term in papers on event extraction

vary according to the focus their authors give to par-

ticular aspects of the problem in hand. For exam-

ple, an event can mean “a change on the state of

a molecule or molecules” in biomedical text mining

systems Kim et al. (2009). We simply adopt the intu-

itive natural deﬁnition in our work and take events as

situations, actions or occurrences that happen or take

place at a certain location in a certain time. Having

the text mining focus in mind, events can be repre-

sented as a complex combination of relations linked

to a set of empirical observations from texts Hogen-

boom et al. (2011).

Initial experiments reported in this paper com-

pare three semantic annotation tools – GATE Cun-

Dytrych, J. and Smrz, P.

Interaction Patterns in Computer-assisted Semantic Annotation of Text - An Empirical Evaluation.

DOI: 10.5220/0005695900740084

In Proceedings of the 8th International Conference on Agents and Artiﬁcial Intelligence (ICAART 2016) - Volume 2, pages 74-84

ISBN: 978-989-758-172-4

ningham et al. (2011), RDFaCE Khalili et al. (2012),

and 4A Smrz and Dytrych (2011, 2015) on the task

of hierarchical annotation of complex relations in

text. The annotation process consisted of selecting

parts of a text corresponding to an event of a speciﬁc

type, ﬁlling its attributes (slots) by entities and values

mentioned in the text, and disambiguating the enti-

ties by linking them to a reference resource (mostly

DBPedia/Wikipedia). Results of the user study with

6 participants indicate that different approaches repre-

sented by the three tested tools lead to different qual-

ity of the annotation and different times to ﬁnish the

task.

Other two sets of experiments then employ the 4A

system in a study confronting various settings of the

annotation user interface and corresponding interac-

tion patterns. It is shown that the commonly used

practice of annotation tools asking people to disam-

biguate entities based just on a suggested type and a

displayed URL leads to a poor quality of results. The

opposite approach giving users immediately extensive

information on entities potentially corresponding to

an ambiguous name not only leads to longer annota-

tion times but, surprisingly, does not bring the best an-

notation accuracy either. A trade-off between the in-

sufﬁcient and the excessive is found and demonstrated

to provide the most efﬁcient setting. Experiments also

call attention to semantic ﬁltering and other enhance-

ments of advanced user interfaces by showing their

impact on annotation consistency and speed.

The rest of the paper is organized as follows: Af-

ter Related work, Section 3 discusses high variability

of text annotation tools and various factors that can

inﬂuence comparison results. Research questions and

experiments run to answer them are presented in Sec-

tion 4. The last section concludes the study and sum-

marizes its results.

2 RELATED WORK

As mentioned above, studies comparing user experi-

ences with tools for semi-automatic text annotation

are rare. The Knowledge Web project benchmarked

6 textual annotation tools considering various crite-

ria including usability (installation, documentation,

aesthetics. . . ), accessibility (user interface features),

and interoperability (platforms and formats) Maynard

et al. (2007). Most of the parameters are out of scope

of our study but at least some of them are covered in

an open shared document

that we prepared to com-

https://docs.google.com/spreadsheets/d/14ionbRVYBQ

uD0cNLazKfRWYzrkax3qFCspm9SiaG5Aw

pare usage characteristics of annotation tools from the

perspective of complex annotation tasks.

Maynard (2008) compares annotation tools from

the perspective of a manual annotator, an annotation

consumer, a corpus developer, and a system devel-

oper. Although the study is already 7 years old, most

evaluation criteria are still valid. The study partially

inﬂuenced our work.

Yee (2002) motivates the implementation of

CritLink – a tool enabling users to attach annotations

to any location on any public web page – by a table

summarizing shortcomings of existing web tools. As

opposed to our approach, the comparison focuses on

basic annotation tasks only and stresses technical as-

pects rather than the user experience.

Similarly to other studies, Reeve and Han (2005)

compare semantic annotation platforms focusing on

the performance of background pre-annotation com-

ponents that generate annotation suggestions. As

modern user interaction tools can freely change the

back-ends and generate suggestions by a range of ex-

isting annotation systems, the work is relevant only

for a historical perspective.

3 COMPARING SEMANTIC

ANNOTATORS – APPLES AND

ORANGES?

When planning an experimental evaluation of seman-

tic annotation frameworks, one has to take into ac-

count features signiﬁcantly differing across the tools

as well as varying aspects of the annotation process

that can inﬂuence results. This is particularly true if

the comparison involves the annotation time and the

quality of created annotations. The following para-

graphs point out several risks that could negatively in-

ﬂuence reliability of such a comparison and strategies

to mitigate the risks followed in the reported experi-

mental work.

Three levels of potential problems can be distin-

guished:

• speciﬁcity of the annotation tasks performed in

the experiments;

• incommensurability of the tools themselves;

• varying experience and expertise of testers.

Computer-assisted semantic annotation refers to a

wide range of tasks. It can involve just a simple iden-

tiﬁcation of entity mentions of few speciﬁc types in

a text, but also full linking of potentially ambiguous

entity names to a background knowledge base, anno-

tation of complex hierarchical relations and their in-

Interaction Patterns in Computer-assisted Semantic Annotation of Text - An Empirical Evaluation

dividual attributes. Domain of the text being anno-

tated (e.g., biomedical v. general), its genre, register,

or source (for example, news articles v. tweets) may

also vary across annotation experiments – they can

require particular approaches to text pre-processing

and can imply different results of the automatic pre-

annotation.

Datasets to be annotated can correspond to a rep-

resentative subset of texts or they can focus on a

chosen phenomenon and mix data accordingly. This

variance can be demonstrated by differing nature of

datasets employed in previous annotation challenges.

For example, the short text track of the 2014 Entity

Recognition and Disambiguation (ERD) Challenge

stressed limited contexts that naturally appear in web

search queries from past TREC competitions. On the

other hand, the SemEval-2015 Task 10

particularly

deals with annotations relevant for sentiment analysis

in microblog (Twitter) messages. The Entity Discov-

ery and Linking (EDL) track at NIST TAC-KBP2015

then aims to extract named entity mentions, includ-

ing person nominal mentions, link them to an exist-

ing Knowledge Base (KB) and cluster mentions for

entities that do not have corresponding KB entries.

Obviously, the degree of ambiguity of entities men-

tioned in annotated texts as well as proportions of oc-

currences corresponding to particular meanings can

have a crucial impact on the speed and accuracy of

the annotation process.

Experiments reported in this paper involve anno-

tation of general web page texts (from the Common-

Crawl corpus

– see below). Initial ones take random

sentences based on trigger words (see Section 4.2 for

details). Remaining experiments focus on entity link-

ing tasks that are particularly difﬁcult for automatic

tools due to the ambiguity of names. We believe that

making people annotate occurrences for which auto-

matic tools often fail makes the scenario of the man-

ual annotation tasks more realistic. Sentences to be

annotated are particularly selected to guarantee that

there is at least one example of an occurrence cor-

responding to each potential meaning covered by the

knowledge base. To evaluate a realistic setting, a part

of the dataset is also formed by mentions not covered

by the reference resources used.

Various aspects of annotation interfaces also inﬂu-

ence experimental results. Some annotation tools aim

at general applicability for semantic processes. Oth-

ers are particularly tailored for paid-crowd annotation

scenarios Bontcheva et al. (2014) so that they can be

http://web-ngram.research.microsoft.com/erd2014/

http://alt.qcri.org/semeval2015/task10/

http://nlp.cs.rpi.edu/kbp/2015/index.html

http://blog.commoncrawl.org

unsuitable for collaborative environments. Also, tools

can be tied up with a particular annotation back-end

or they can be only loosely coupled with a (preferred)

annotator tool that can be easily changed or extended

for speciﬁc tasks. Other features of annotation tools,

especially those related to user interfaces and inter-

action patterns, are brieﬂy discussed in the following

section.

Skills, a current state of mind and motivation of

users participating in experiments can also inﬂuence

results. Measured quality and the time always need to

be interpreted with respect to these aspects. It can

be expected that users with an experience in using

a particular tool will better understand its user inter-

face and will be able to achieve better results using

the tool. Also, expertise in a domain in question can

speed up the annotation process, especially the disam-

biguation of specialized entity mentions.

Experimental settings that can award quality over

quantity or vice versa can lead to dramatically dif-

ferent times and amounts of annotation errors. In-

deed, users in our experiments realized a trade-off be-

tween the time spent on each particular case and re-

sulting quality (e.g., users’ certainty that they consid-

ered enough context to correctly disambiguate an en-

tity mention). While our users asked for preferences

in this situation, this ﬁnding can be also expected in

the paid-for crowdsourcing settings that need to apply

sophisticated quality control mechanisms to prevent

annotators’ temptation to cheat Wang et al. (2013).

Research questions deﬁned in the following sec-

tion also relate to the amount of information neces-

sary for a correct (and fast) decision on entity disam-

biguation problems and the way to present potential

choices. The number of displayed suggestions and

their attributes as well as particular annotation steps

followed inﬂuence user’s attention paid to the task

and, consequently, the accuracy of results.

As detailed in Section 4.3, our experiments com-

paring features of annotation tools were conducted

with users that had no previous experience in using

the tools and no particular expertise in the ﬁeld. They

had 20 minutes to familiarise themselves with each

particular tool (the order in which they tested the tools

was unique for all users as there are 6 possible com-

binations for three tools). Task instructions stressed

that users should be as accurate as possible but that

time is limited. There was an informal competition

on who will deliver the fastest and the most accurate

results but no particular incentives (except for a beer

for the winner) were promised or given.

ICAART 2016 - 8th International Conference on Agents and Artiﬁcial Intelligence

4 ANNOTATION EXPERIMENTS

4.1 Research Questions

Reported experiments aim at answering the following

research questions:

1. How design choices of particular annotation tools

impact the quality of results and the annotation

time.

2. To what extent the amount of information shown

to disambiguators inﬂuences the results.

3. Whether users beneﬁt from knowledge of poten-

tial alternative annotations and conﬁdence levels

of provided suggestions.

4. What quality the concept of semantic ﬁltering

brings to the annotation process.

Initial annotation experiments address the ﬁrst

question. They compare different user interfaces and

interaction patterns as exempliﬁed by three speciﬁc

annotation systems. Various features that can inﬂu-

ence annotation performance need to be considered.

Some tools make no visible distinction between pre-

annotations generated by a back-end automatic sys-

tem and manual annotations entered by users. Other

tools explicitly distinguish the system suggestions

from the accepted or newly entered annotations. This

can have an impact on consistency of the annotation,

i. e. the number of cases users did not check or just

missed a suggestion.

Underlying annotation patterns for events and

other complex relations and their attributes vary

across tools too. Advanced tools enable deﬁning so-

phisticated templates and type constraints that control

ﬁlling of event slots. Of course, systems differ in their

actual application of the general approach and the way

they implement it inﬂuences annotation performance

aspects.

Various values entered by users often need to cor-

respond to an entry in a controlled vocabulary or a

list of potential items. An example of such a case

is a URL linking an entity mention to a reference

knowledge source. Tools support entering such val-

ues through autocomplete functions that can present

not only the value to be entered, but also additional

information that helps users to choose the right value.

For example, the 4A client shows not only an URL

link, but also full names and disambiguation contexts.

The RDFaCE, on the other hand, autocompletes just

URLs in this context. As shown in the next section,

this also impacts the results.

Other two questions mentioned above are covered

by the second set of experiments. It is clear that the

amount of information shown to the user and its form

can inﬂuence the speed and accuracy of the annotation

process. If the displayed information is not sufﬁcient

for a decision what a correct link for an entity is, the

user will have to search for additional information.

On the other hand, if a tool lets users read more than

necessary, the annotation speed can decrease.

Most of the explored systems show just a URL

and let the user explore it if she is not sure that the

linked information corresponds to an expected one.

This can speed up the annotation process but it can

also make it error-prone. The 4A system enables ﬁl-

tering displayed information and ﬁne-tuning the way

it is shown. Detailed entity attributes can be folded

and shown only if the user asks for them.

Without a system support, users are often unaware

of ambiguity of some names. It causes no harm for

frequent appearances of dominant senses. However,

if a user is not an expert in a ﬁeld where two or more

potential links to an underlying resource can appear,

she can easily conﬁrm an incorrectly suggested link

for an ambiguous name. The risk can be mitigated if

the tools let users know about alternatives. The ques-

tion is how an optimal setting for this function looks

like – whether this should be a default behaviour or

the system should notify the user only if an automati-

cally computed conﬁdence is smaller than a threshold

or the difference between a suggested option and the

second one is closer than a threshold. These aspects

are discussed in the second experiment too.

The goal of the third set of experiments is then to

answer the last research question dealing with the role

of semantic ﬁltering. It is not easy to enter complex

annotations such as events. Advanced mechanisms

suggesting slot ﬁlling can make the process more con-

sistent and fast. The 4A tool supports hierarchical an-

notation which highlights potential nested annotations

if an upper-level type is known. As shown at the end

of this section, such an approach leads to speedups of

the annotation process.

4.2 Data Preparation

Texts to be annotated in the experiments reported in

the following subsections were chosen from general

web data contained in the CommonCrawl corpus from

December 2014.

First experiments comparing an-

notation frameworks dealt with general annotation of

events. Text selection did not address any speciﬁc ob-

jective (in contrast to next experiments) so that con-

texts containing mentions of named entities recog-

nized by all three tools and a trigger word (verb) cor-

responding to travels and visits of people to various

http://blog.commoncrawl.org/2014/12/

Interaction Patterns in Computer-assisted Semantic Annotation of Text - An Empirical Evaluation

places were pre-selected. The data was then manu-

ally annotated by two authors of this paper, annotation

disagreements were solved by choosing correct ones

in clear cases and excluding few cases considered un-

clear.

The second set of experiments, looking into an op-

timal amount of displayed information, needed data

containing ambiguous names with a proportional rep-

resentation of two or more alternatives. Inspired

by WikiLinks

, we searched the CommonCrawl data

for cases linking a name to two or more distinct

Wikipedia URLs. To ﬁlter out potential interdepen-

dencies among various options and enable focusing

on key attributes in the ﬁrst part of experiments, a

majority of the prepared dataset consists of pairs of

texts mentioning a name shared by two distinct en-

tities. For example, the following sentences are in-

cluded in the resulting data:

1. Charles Thomson was a Patriot leader in

Philadelphia during the American Revolution and

the secretary of the Continental Congress (1774–

1789) throughout its existence.

2. Charles Thomson’s best known work is a satire of

Sir Nicholas Serota, Director of the Tate gallery,

and Tracey Emin, with whom he was friends in the

1980s.

A smaller part (34 sets) of the data correspond to

sentences containing names that could refer to 5 or

more entities in the English Wikipedia. For 7 such

cases, the subset was further manually extended to in-

clude a text with the same ambiguous name referring

to an entity not covered by the Wikipedia. This data

was used in the second part of the experiments de-

scribed in Section 4.4.

The last set of experiments combine annotation of

events with disambiguation of entity mentions. Con-

sequently, paragraphs with sentences mentioning am-

biguous names linked to the Wikipedia that contain

a trigger verb indicating a particular type of an event

were retrieved from the CommonCrawl data and val-

idated by the authors. Similarly to the data for the

ﬁrst experiments, the dataset was formed from cases

in which the pre-annotation process had led to a clear

consensus between the annotators. Only 12 texts

mentioning events were ﬁnally used in the study.

4.3 Comparing Tools

The aim of initial experiments was to compare ad-

vanced annotation editors in terms of their interac-

tion patterns and user-interface features that can in-

ﬂuence user experience and annotation performance.

https://code.google.com/p/wiki-links/

We were interested whether annotation results ob-

tained by using particular tools will differ in the qual-

ity measured by their completeness and accuracy of

types of entities ﬁlling slots of complex relations and

their links to underlying resources (mostly DBPe-

dia/Wikipedia). In addition, times to ﬁnish each ex-

periment were measured for each user and then aver-

aged per attribute annotated.

Employed tools represent different approaches to

complex annotation tasks (see Figure 1 for examples

of event annotation views). The 4A system

, imple-

mented by our team, pays a special attention to hierar-

chical annotations and potentially overlapping textual

fragments. Users beneﬁt from advanced annotation

suggestions and an easy mechanism for entering cor-

rect attribute values by simply accepting or rejecting

provided suggestions.

The RDFaCE editor

is similar to 4A in the way

it annotates textual fragments and can be also de-

ployed as an plugin for JavaScript WYSIWYG editor

TinyMCE. It can pre-annotate texts too. On the other

hand, there is no visual distinction between a sug-

gestion and a user annotation. There is also no easy

way to annotate two overlapping parts of a text with

two separate events. Thus, testers were allowed to

simplify their job and select whole sentences or even

paragraphs as fragments corresponding to events.

Various existing GATE extensions and plugins

were considered for our annotation experiment. Un-

fortunately, GATE Teamware

– a web-based col-

laborative text annotation framework which would

be an obvious choice – does not currently pro-

vide good support for relation and co-reference an-

notation Bontcheva et al. (2013). Similarly, sim-

ple question-based user interfaces generated by the

GATE Crowdsourcing plugin

Bontcheva et al.

(2014) would not be efﬁcient for the complex hierar-

chical annotation tasks tested. Thus, our experiments

employed the standard GATE Developer

desktop

interface, able to cope with the task at hand. Pre-

annotations by back-end annotators were set the same

way as in the other two tools. Users were instructed

to perform an easier task of selecting event attributes

and linking them to a reference resource ﬁrst and then

just selecting a text including all identiﬁed arguments

and tagging it as an event.

As discussed in Section 3, it is very difﬁcult to ob-

jectively compare semantic annotation tools from the

user perspective. To minimize the danger of unfair

http://knot.ﬁt.vutbr.cz/annotations/

http://rdface.aksw.org/

https://gate.ac.uk/teamware

https://gate.ac.uk/wiki/crowdsourcing.html

https://gate.ac.uk/family/developer.html

ICAART 2016 - 8th International Conference on Agents and Artiﬁcial Intelligence

Figure 1: Event annotation screens in a) GATE, b) RDFaCE, and c) 4A.

comparison, six users that participated in the exper-

iments had been selected to have no previous expe-

rience with neither the tools explored, nor the tasks

that they used the tools for. They were 4 men and

2 women, PhD candidates or MSc. in computer sci-

ence, aged 26–34. Every user spent about 20 min-

utes prior to the measured session familiarizing her-

/himself with the tool to test while working on a spe-

ciﬁc part of the data, not included in the real testing

set, yet containing all cases that appeared later during

real testing (e.g., multiple values for attributes, two

distinct events expressed in one sentence, suggestions

that do not correspond to a correct sense, etc.) To

make the comparison as fair as possible, the order in

which users tested the tools was different for each user

too.

Each user had about 40 minutes for annotation

in each tool in the experiment. Three characteris-

tics were collected. As summarized in Table 1, they

included the amount of incorrect values entered, the

number of misses – entities that were mentioned in

the text but not associated with the event being an-

notated – and the average annotation time per event.

Incorrect attributes involve all kinds of errors – incor-

rect selection of a textual fragment, blank or incorrect

types, co-references or URLs linking entity mentions

to a wrong entry in reference resources.

Table 1: Results of experiments comparing annotation

tools.

tool incorrect missing time

values values per event

GATE 9.4 % 8.3 % 135 s

RDFaCE 8.7 % 8.8 % 193 s

4A 6.2 % 5.6 % 116 s

The overall high error rate (column “incorrect val-

ues”) can be explained by a rather strict comparison

with the gold standard. For example, users were sup-

posed to compute and enter the interval of years for an

event mentioning a woman in her 50s who travelled

around . . . Some of them entered values correspond-

ing to 1950s.

Results correspond to the fact that the way GATE

presents annotations of event attributes has often led

to inconsistent results. RDFaCE was only slightly

better in this respect.

A part of the problem of event slots left empty al-

though the annotated text contains information nec-

essary for their ﬁlling (column “missing values”) re-

lates to pronominal references that were supposed to

be linked to the referred entity. However, the differ-

ence between results of GATE and RDFaCE on one

side and 4A on the other one shows that it is useful

to visually distinguish system suggestions from user

validated data and that 4A’s way of conﬁrming sug-

gestions lead to more consistent data.

Finally, the average time needed to annotate an

event was higher when our testers used RDFaCE than

with the other two tools. This can be explained by a

rather austere user interface of the tool with a limited

way to easily correct previous mistakes.

4.4 Optimizing Displayed Information

The second set of experiments explored the impact of

varying amount of information presented to the user

in an initial annotation view and the way users get

additional information. It also asked whether users

beneﬁt from knowledge of potential alternative anno-

tations and conﬁdence levels of provided suggestions.

The experiments could not be done using a tool

that does not allow customization and just ﬁxes the

way information is presented. We took advantage of

4A’s ﬂexibility here and set its user interface accord-

ing to required features. In particular, the setting in-

volved limiting the set of attributes shown to users

in primary disambiguation views and those that are

shown when users ask for details.

Interaction Patterns in Computer-assisted Semantic Annotation of Text - An Empirical Evaluation

The experiments particularly focused on com-

plex entity disambiguation. As mentioned above,

the data extracted from the CommonCrawl corpus

was searched for links that correspond to ambiguous

names of people and places in the Wikipedia. A col-

lection of 186 excerpts used in the tests was manually

veriﬁed by one of the authors. The way it had been

prepared guaranteed that a random guess would lead

to a 50 % error (or more, in the case of entities with

more than 2 alternatives).

We primarily compared three settings of disam-

biguation views, differing by entity attributes shown,

and looked at the impact on the speed and accuracy

of the disambiguation. Users were instructed to an-

notate just the entity in question (highlighted in each

excerpt) and choose always one of the provided sug-

gestions. Users did not skip any disambiguation task

so that we can compare just the speed and accuracy of

results.

The ﬁrst setting showed users an extensive list of

attributes and values for the suggestion with a higher

conﬁdence. Displayed attributes involved entity type,

full name, description corresponding to the ﬁrst para-

graph from Wikipedia or Freebase, visual representa-

tion (the ﬁrst image from Wikipedia, if available), and

URL. Figure 2 shows such a view. If necessary, users

could follow the URL link, consult the full Wikipedia

page and decide based on the full information con-

tained there.

The second setting corresponded to the limited

view some tools offer for the disambiguation task. It

displayed only entity types and URLs and users were

supposed to either decide based on the URL alone, or

open the Wikipedia page if they felt it is necessary for

the disambiguation. Note that Wikipedia URLs can

help disambiguation with words in parentheses used

for articles discussing entities with the same name

as a primary (more famous) entity covered by the

Wikipedia.

The third setting took advantage of a special dis-

ambiguation attribute that is dynamically computed

from descriptions of available alternatives. It com-

bines the disambiguation word from the Wikipedia

URL and a selected part of the entity description. It is

generated by a function which can be easily adapted

to other data sources than Wikipedia or Freebase. The

disambiguation attribute was shown together with the

suggested entity type and URL so that users could

again click to get more information (see Figure 3).

While the sequence of testing cases (40 for each

setting) was ﬁxed, each of 6 testers had a different

order of the 3 settings (similarly as order of tools in

ﬁrst set of experiments). Each user had 30 minutes for

each setting. Table 2 compares times and error rates

Figure 2: An example of detailed information for a sug-

gested annotation.

Figure 3: An example of a disambiguation attribute for a

suggested annotation.

and shows how many times users clicked on the URL

link to read further information.

Though there were some differences among in-

dividual testers, the overall ﬁgure (the best and the

worst performing setting in terms of the average time

and the error rate) remained the same for all the

testers. The number of cases in which individual users

consulted Wikipedia pages was always the highest in

the second setting but users differed in the level they

believed that seeing just a URL is enough to decide

Table 2: Results of experiments comparing three settings of

the disambiguation view.

setting average error URL

time rate clicked

detailed information 33.92 s 6.2 % 1.3 %

only type and URL 37.26 s 27.9 % 41.7 %

disambiguation attr. 32.98 s 2.1 % 1.5 %

ICAART 2016 - 8th International Conference on Agents and Artiﬁcial Intelligence

(which then resulted in an increased number of er-

rors).

The relatively high number of errors is also due

to the complexity of the disambiguation task. This

was one of the feedback answers provided by users

after all 3 sessions in a collected questionnaire. Al-

though users tried to make as few mistakes as pos-

sible, 20+ minute sessions were felt demanding and

users (not knowing how many errors they had made

yet) pointed out that they could be faster if the fo-

cus would be on the speed rather than on the quality.

Being confronted with the number of errors in their

results, they realized the trade-off between the time

and the quality and proposed context-sensitive fea-

tures that would help them in particular disambigua-

tion cases (images in the case of ambiguity between a

ship name and a person, dates of deaths in the case of

two persons living in different centuries, etc.).

The fact that users did not originally realize the

complexity of the disambiguation task also proba-

bly explains the surprisingly high error in the case of

presenting full information immediately (the ﬁrst set-

ting). Too much information that does not highlight

key differences between alternatives seems to lead to

a less focused work. Our future research will explore

whether this can be changed when users are more ex-

perienced. On the other hand, the average time per

decision and the connected low number of cases users

had to consult Wikipedia pages correspond to the fact

that users often skimmed full texts and images and

felt they have enough information for their decisions.

The setting showing just the type and the URL

proved to be the most diverse among users. Some

of them opened more than 2/3 of all links and read

the information on the Wikipedia page, others decided

much faster but also made more errors. Although the

latter could be prohibited by a penalization of errors,

the second setting is clearly the worst for the task

at hand. The tools that offer only this information

in the disambiguation context could improve signif-

icantly by considering more informative views.

A clear winner of this part is the setting with the

disambiguation attribute and the option to click on the

provided URL to ﬁnd details. Users made less mis-

takes than in other settings and the average time was

the lowest. They needed to consult Wikipedia rarely.

Five out of six users also indicated in the question-

naire that this setting was the most comfortable one

in their eyes.

As opposed to the simpliﬁed situation prepared for

the above-mentioned tested settings, the data for the

next reported experiment corresponds to more realis-

tic conditions when a name can belong to an entity

that is not covered by a background knowledge base

(Wikipedia, in our case) so that neither of the pro-

vided suggestions is correct. The focus on highly am-

biguous names that have 5 or more alternative mean-

ings in Wikipedia also prevents the simple selection

strategy applicable in the previous settings. Users

could not beneﬁt from excluding the wrong alterna-

tive and thoughtlessly conﬁrming the other one this

time.

Two sets per 15 entity mentions were prepared

while 3 of them (20 %) in each set did not correspond

to neither of the alternatives. The ﬁrst suggestion was

correct in 9 out of 15 cases (60 %) in each set which

corresponds to empirical measurement of accuracy of

background suggestion service for selected texts. No

threshold on the conﬁdence level was applied so that

the background suggestion service provided the best

ﬁtting alternative even in the cases when the mention

did not correspond to any of the options.

One tested setting generally corresponded to the

presentation of the best alternative with the disam-

biguation attribute shown for the most probable sug-

gestion. Users were able to unfold and explore

detailed information and visit the linked Wikipedia

page.

The other setting directly showed 5 most probable

suggestions and the conﬁdence level for the best one

(for technical reasons, the second to the ﬁfth alter-

natives were ranked just by a global score reﬂecting

mainly the number of visits of particular Wikipedia

pages; computing real context-dependent score for

each alternative would take too much time). Figure 4

shows such a case.

Three users started with the former, other three

with the latter setting and continued with the other

one. For the cases where none of the suggestions was

correct, refusing all alternatives was taken as correct.

Results are summarized in Table 3.

Table 3: One suggestion v. all alternatives.

setting average error URL

time rate clicked

one pre-selected 41.2 s 14.4 % 3.3 %

all alternatives 42.9 s 12.2 % 2.2 %

The average time of selection grew to more than

40 seconds. It reﬂects increased complexity of the

task compared to the one in Section 4.3. It took

slightly more time to consider all alternative sugges-

tions (the last row of the table) but it resulted in a

higher accuracy. Although the results are not fully

conclusive and they generally depend on the qual-

ity of the suggestion-generation process and the fre-

quency of cases where an entity is not covered by

the background resource, showing alternative sugges-

Interaction Patterns in Computer-assisted Semantic Annotation of Text - An Empirical Evaluation

Figure 4: Alternatives shown in an initial disambiguation

view.

tions seems to be the preferable option when one val-

ues quality over time. On the other hand, users’ an-

swers in the questionnaire do not indicate that know-

ing the conﬁdence level of the suggestion service

helped them consider less clear suggestions more

carefully. Our future research will investigate this

ﬁnding to a more detail.

4.5 Semantic Filtering

The third set of experiments compared two ways of

annotating complex events and their attributes. It

aimed at measuring what speedups can be expected

when advanced semantic ﬁltering is applied. Users

were instructed to select and annotate just parts of

presented paragraphs mentioning travels of a person

abroad. The data was as realistic as possible – it

contained sentences corresponding to other kinds of

events and mentions of entities that did not play a role

in the event in question.

Two sets of texts, each containing 6 events of the

correct type were prepared. Users had to identify

event attributes manually in the ﬁrst set while the sec-

ond setting involved automatic pre-annotation of at-

tributes of each speciﬁc type and applying 4A’s se-

mantic ﬁltering that highlights potential attribute can-

Table 4: Manually entered v. suggested annotations of enti-

ties that can ﬁll event slots.

slot incorrect missing time

ﬁlled values values per event

manually 11.7 % 6.6 % 303.5 s

suggested 4.5 % 3.4 % 109.3 s

didates concurring to the type of the attribute being

ﬁlled. The latter simpliﬁes the role of users to as-

sembling suggested entity annotations, adding miss-

ing ones and assembling the parts into events.

Table 4 compares the two settings. The manual

process without any pre-annotation is tedious, users

spend more than 5 minutes annotating one event and

results contain a lot of noise. On the other hand, the

4A’s semantic ﬁltering switched on in the second set-

ting leads to high-quality results that can be achieved

relatively fast. The concept of advanced semantic ﬁl-

tering of suggestions will be also explored in our fu-

ture work.

5 CONCLUSIONS AND FUTURE

DIRECTIONS

The presented empirical study of semi-automatic tex-

tual annotation tools and their interaction components

proves that user interface factors as well as involved

interaction patterns have an impact on the speed of

the annotation process and its results. We showed that

tool developers need to pay a special attention to vari-

ous aspects of the annotation interfaces, including the

amount of information displayed for entity linking,

the way users are notiﬁed about annotation alterna-

tives and mechanisms of semantic templates and ﬁl-

tering. When done properly, the tools have a great po-

tential to speed up computer-assisted semi-automatic

annotation that is still necessary in complex relation

annotation tasks.

In particular, the comparison of user interfaces

and interaction patterns represented by three differ-

ent annotation tools proved that the annotation con-

sistency beneﬁts from clear visual distinction be-

tween system suggestions and annotations validated

by users. The 4A system also excelled in its compre-

hensible presentation of event attributes which has led

to less incorrect values entered in annotations. The vi-

sually compelling interface with images representing

known entities and the clear hierarchy of nested an-

notations allowed users to ﬁnish their tasks in shortest

times using the 4A tool too.

The experiments comparing various settings of the

entity disambiguation interface in the 4A tool showed

ICAART 2016 - 8th International Conference on Agents and Artiﬁcial Intelligence

that it is beneﬁcial to pay a special attention to the

amount of information presented to users in the case

of entity name ambiguity. A brief context-dependent

disambiguation text supplemented by the link to a

Wikipedia page or another resource providing more

details helped users to make fast and accurate deci-

sions on the entity links. 4A’s intuitive semantic ﬁl-

tering also showed to be beneﬁcial in terms of anno-

tation quality and speed.

Our future work will extend the reported results

towards other kinds of complex annotation tasks in-

cluding data preparation for aspect-oriented sentiment

analysis and annotation of textual contexts suggest-

ing emotional states of authors. We will also support

newly available entity recognition tools and frame-

works, such as WAT Piccinno and Ferragina (2014)

or Gerbil R

oder et al. (2015), that will be employed

as back-end pre-annotation components.

ACKNOWLEDGEMENTS

This work was supported by the H2020 project

MixedEmotions, grant agreement No. 644632, and

by the IT4IXS – IT4Innovations Excellence in Sci-

ence project (LQ1602).

REFERENCES

Bontcheva, K., Cunningham, H., Roberts, I., Roberts, A.,

Tablan, V., Aswani, N., and Gorrell, G. (2013). GATE

Teamware: A web-based, collaborative text annota-

tion framework. Lang. Resour. Eval., 47(4):1007–

1029.

Bontcheva, K., Roberts, I., Derczynski, L., and Rout, D.

(2014). The GATE Crowdsourcing Plugin: Crowd-

sourcing annotated corpora made easy. In Proceed-

ings of Demonstrations at the 14th Conference of the

European Chapter of the Association for Computa-

tional Linguistics (EACL), pages 97–100. Association

for Computational Linguistics.

Ciccarese, P., Ocana, M., and Clark, T. (2012). Open

semantic annotation of scientiﬁc publications using

DOMEO. Journal of Biomedical Semantics, 3(Suppl

1).

Cunningham, H., Maynard, D., Bontcheva, K., Tablan,

V., Aswani, N., Roberts, I., Gorrell, G., Funk, A.,

Roberts, A., Damljanovic, D., Heitz, T., Greenwood,

M. A., Saggion, H., Petrak, J., Li, Y., and Peters,

W. (2011). Text Processing with GATE (Version 6).

GATE.

Grassi, M., Morbidoni, C., Nucci, M., Fonda, S., and Do-

nato, F. D. (2013). Pundit: Creating, exploring and

consuming semantic annotations. In Proceedings of

the 3nd International Workshop on Semantic Digital

Archives, Valletta, Malta.

Handschuh, S., Staab, S., and Ciravegna, F. (2002). S-

CREAM – Semi-automatic CREAtion of Metadata

Knowledge Engineering and Knowledge Manage-

ment: Ontologies and the Semantic Web. In G

omez-

erez, A. and Benjamins, V., editors, Knowledge En-

gineering and Knowledge Management: Ontologies

and the Semantic Web, volume 2473 of Lecture Notes

in Computer Science, chapter 32, pages 165–184.

Springer, Berlin, Heidelberg.

Heese, R., Luczak-Rsch, M., Paschke, A., Oldakowski, R.,

and Streibel, O. (2010). One click annotation. In Pro-

ceedings of the 6th Workshop on Scripting and Devel-

opment for the Semantic Web, collocated with ESWC.

Ruzica Piskac, Redaktion Sun SITE, Informatik V,

RWTH Aachen, Ahornstr. 55, 52056 Aachen, Ger-

many.

Hogenboom, F., Frasincar, F., Kaymak, U., and de Jong, F.

(2011). An Overview of Event Extraction from Text.

DeRiVE.

Khalili, A., Auer, S., and Hladky, D. (2012). The RDFa

Content Editor – From WYSIWYG to WYSIWYM.

In Proceedings of COMPSAC 2012 – Trustworthy

Software Systems for the Digital Society.

Kim, J., Ohta, T., Pyysalo, S., Kano, Y., and Tsujii, J.

(2009). Overview of BioNLP’09 shared task on event

extraction. In Proceedings of the Workshop on Cur-

rent Trends in Biomedical Natural Language Process-

ing: Shared Task, pages 1–9. Association for Compu-

tational Linguistics.

Maynard, D. (2008). Benchmarking textual annotation tools

for the semantic web. In 6th International Conference

on Language Resources and Evaluation, Marrakech,

Morocco. European Language Resources Association

(ELRA).

Maynard, D., Dasiopoulou, S., Costache, S., Eckert, K.,

Stuckenschmidt, H., Dzbor, M., and Handschuh,

S. (2007). Knowledge web project: Deliverable

D1.2.2.1.3 – Benchmarking of annotation tools.

Moro, A. and Navigli, R. (2015). SemEval-2015 Task 13:

Multilingual all-words sense disambiguation and en-

tity linking. In Proceedings of the 9th International

Workshop on Semantic Evaluation, pages 288–297,

Denver, Colorado.

Piccinno, F. and Ferragina, P. (2014). From TagME to WAT:

a new entity annotator. In Proceedings of the ﬁrst in-

ternational workshop on Entity recognition & disam-

biguation, pages 55–62. ACM.

Reeve, L. and Han, H. (2005). Survey of semantic anno-

tation platforms. In Proceedings of the 2005 ACM

Symposium on Applied Computing, SAC ’05, pages

1634–1638, New York, NY, USA. ACM.

oder, M., Usbeck, R., and Ngonga Ngomo, A.-C. (2015).

Developing a sustainable platform for entity annota-

tion benchmarks. In ESWC Developers Workshop

2015. http://svn.aksw.org/papers/2015/ESWC_

GERBIL_semdev/public.pdf.

Smrz, P. and Dytrych, J. (2011). Towards new scholarly

communication: A case study of the 4a framework. In

SePublica, volume 721 of CEUR Workshop Proceed-

ings. Ruzica Piskac, Redaktion Sun SITE, Informatik

V, RWTH Aachen, Ahornstr. 55, 52056 Aachen, Ger-

many.

Interaction Patterns in Computer-assisted Semantic Annotation of Text - An Empirical Evaluation

Smrz, P. and Dytrych, J. (2015). Advanced features of col-

laborative semantic annotators – the 4a system. In

Proceedings of the 28th International FLAIRS Con-

ference, Hollywood, Florida, USA. AAAI Press.

Stenetorp, P., Pyysalo, S., Topi

c, G., Ohta, T., Ananiadou,

S., and Tsujii, J. (2012). BRAT: A web-based tool

for nlp-assisted text annotation. In Proceedings of the

Demonstrations at the 13th Conference of the Euro-

pean Chapter of the Association for Computational

Linguistics, EACL ’12, pages 102–107, Stroudsburg,

PA, USA. Association for Computational Linguistics.

Surdeanu, M. and Heng, J. (2014). Overview of the English

slot ﬁlling track at the TAC2014 knowledge base pop-

ulation evaluation. In Proceedings of the TAC-KBP

2014 Workshop.

Wang, A., Hoang, C., and Kan, M.-Y. (2013). Perspec-

tives on crowdsourcing annotations for natural lan-

guage processing. Language Resources and Evalu-

ation, 47(1):9–31.

Yee, K. P. (2002). Critlink: Advanced hyper-

links enable public annotation on the web.

http://zesty.ca/pubs/cscw-2002-crit.pdf.

ICAART 2016 - 8th International Conference on Agents and Artiﬁcial Intelligence
