Abstract Dialectical Frameworks for Text Exploration

Elena Cabrio

and Serena Villata

University of Nice Sophia Antipolis, Sophia Antipolis, France

CNRS, I3S Laboratory, Sophia Antipolis, France

Keywords:

Argumentation, Textual Entailment, Natural Language Processing.

Abstract:

Textual Entailment (TE) systems aim at recognizing the relations of entailment or non entailment holding

between two text fragments (i.e. a pair). The identiﬁed TE pairs are considered as independent one from

the others. However, in the latest years TE systems have been challenged against a number of real world ap-

plication scenarios like analyzing costumers interactions about a service, or analyzing online debates. These

applications have underlined the need to move from TE pairs to TE graphs where pairs are no more inde-

pendent. Moving from single pairs to graphs has the advantage of providing an overall view of the topic

discussed in the text. The challenge here is to deﬁne ways to exploit such graph-based representation for text

exploration. In the literature, some approaches apply abstract argumentation theory to compute the accepted

arguments of a debate, but they present a number of drawbacks, e.g., the non entailment relation and the attack

relation in abstract argumentation are assumed to be equivalent, but this is not always the case. In this paper,

we deﬁne bipolar entailment graphs, i.e., graphs whose nodes are text fragments and the edges represent the

entailment or non entailment relations. We adopt abstract dialectical frameworks to deﬁne acceptance condi-

tions for the nodes such that the resulting framework returns us relevant information for our text exploration

task. Experimental evaluation shows the feasibility of our approach.

1 INTRODUCTION

In the last ten years, the Textual Entailment (TE)

framework (Dagan et al., 2009) has gained popularity

in Natural Language Processing (NLP) applications

like information extraction and question answering,

providing a suitable model for capturing major se-

mantic inference needs at textual level, taking into ac-

count the language variability. Given a pair of textual

fragments, a TE system assigns an entailment or a non

entailment relation to the pair. However, in real world

scenarios as analyzing costumers’ interactions about

a service or a product, or online debates, these pairs

extracted from the interactions cannot be considered

as independent. This means that they need to be col-

lected together into a single graph, e.g., all the reviews

about a certain service are collected together to un-

derstand which are the overall problems/merits of the

service.

This combination of TE pairs into a unique

graph aims at supporting text exploration, whose goal

is the extraction of speciﬁc information from users in-

teractions evaluated as relevant in a particular domain

As discussed also in the keynote talk of the Joint Sym-

posium on Semantic Processing (http://jssp2013.fbk.eu/)

or task. The challenge is thus to propose an automated

framework able to compute such relevant information

starting from the TE pairs returned by the system and

collected into a graph.

In this paper, we answer the research question:

• How to guide text exploration by highlighting rel-

evant information?

Differently from standard entailment graphs (Be-

rant et al., 2010; Mehdad et al., 2013) where the nodes

are connected by entailment relations only, in this pa-

per we consider bipolar entailment graphs (BEG),

where the nodes are the text fragments of TE pairs,

and both relations returned by TE systems (i.e., entail-

ment and non entailment) are considered as the graph

links. A recent proposal by (Cabrio and Villata, 2012)

suggests that TE pairs can be collected together to

construct an abstract argumentation framework (Cay-

rol and Lagasquie-Schiex, 2013; Dung, 1995) where

the entailment relation is mapped with the support re-

lation in argumentation, and the non entailment rela-

tion is mapped with the attack relation. Argumenta-

tion theory (Dung, 1995) is used to compute the set

of accepted arguments in the online debates they an-

alyze. While we believe that strong connections hold

Cabrio, E. and Villata, S.

Abstract Dialectical Frameworks for Text Exploration.

DOI: 10.5220/0005699100850095

In Proceedings of the 8th International Conference on Agents and Artiﬁcial Intelligence (ICAART 2016) - Volume 2, pages 85-95

ISBN: 978-989-758-172-4

between TE and argumentation theory, we detect the

following drawbacks in their combined approach: i)

the non entailment relation is considered as equiva-

lent to a contradiction and directly translated into an

attack relation. This is not always the case: non en-

tailment means that the two text spans are either unre-

lated or contradicting each other; ii) the support rela-

tion affects arguments’ acceptability only if supported

arguments are also attacked (new attacks are intro-

duced when a support holds (Cayrol and Lagasquie-

Schiex, 2013)), making the resulting framework more

complex; and iii) applying standard acceptability se-

mantics (Dung, 1995) to TE graphs does not give the

possibility to express detailed task-dependent condi-

tions to be satisﬁed, in order to have the arguments

accepted.

Our research question breaks down into the fol-

lowing sub-questions:

• How to cast bipolar entailment graphs in the ar-

gumentation setting such that the semantics of the

relations is maintained?

• How to deﬁne speciﬁc arguments’ acceptance

conditions such that information we consider as

relevant in our task is extracted?

First, we answer the research questions by adopt-

ing abstract dialectical frameworks (ADF) (Brewka

and Woltran, 2010; Brewka et al., 2013), a general-

ization of Dung’s abstract argumentation frameworks

where different kinds of links among statements are

represented. We cast bipolar entailment graphs in ab-

stract dialectical frameworks where the links repre-

sent entailment and non entailment.

Second, considering positive (entailing) and nega-

tive (non entailing) links, and the weights assigned to

such links by the TE system, we deﬁne and evaluate

two acceptance conditions which allow us to extract

in an automated way the set of arguments, i.e., text

fragments, relevant for our text exploration task.

The goal of the proposed framework is to high-

light the information that is relevant to explore (i.e.

to understand, and in a certain sense, to summarize)

humans interactions in natural language (e.g. in a de-

bate, or in a reviewing service). Our proposal is a nat-

ural language based knowledge representation frame-

work grounded on natural language constructs rather

than on a formal pre-deﬁned terminology. On the

one side we provide an automated way to compute

relevant information, and on the other side we apply

abstract dialectical frameworks to a real application

where texts are the primary source of knowledge.

In the remainder of the paper, Section 2 compares

the proposed approach to the related work. Section 3

presents the TE framework. Section 4 introduces

ADFs and the two acceptance conditions we deﬁne.

Experimental setting is described in Section 5. Con-

clusions end the paper.

2 RELATED WORK

The term entailment graph is not new in the literature,

and it has been ﬁrstly introduced by Berant et al. (Be-

rant et al., 2010) as a structure to model entailment re-

lations between propositional templates. The nodes of

an entailment graph are propositional templates, i.e.,

a path in a dependency tree between two arguments of

a common predicate (Lin and Pantel, 2001). In a de-

pendency parse, such a path passes through the predi-

cate; a variable must appear in at least one of the argu-

ment positions, and each sense of a polysemous pred-

icate corresponds to a separate template (and a sepa-

rate graph node): X

sub j

←−− treat#1

ob j

−−→ Y and X subj

sub j

←−−

treat#1

ob j

−−→ nausea are propositional templates for the

ﬁrst sense of the predicate treat. An edge (u,v) repre-

sents the fact that template u entails template v. (Be-

rant et al., 2010) assume a user interested in retriev-

ing information about a target concept (e.g., nausea).

The proposed approach automatically extracts from

a corpus the set of propositions where nausea is an

argument, and learns an entailment graph over propo-

sitional templates derived from the extracted proposi-

tions.

While (Berant et al., 2010; Berant et al., 2012)

model the problem of learning entailment relations

between predicates represented as propositional tem-

plates as a graph learning problem (to search for the

best graph under a global transitivity constraint), we

collect both entailment and non entailment relations

returned by the system to use both of them during the

computation of relevant information. In the context of

the topic labeling task, (Mehdad et al., 2013) propose

to build a multidirectional entailment graph over the

phrases extracted for a given set of sentences (cover-

ing the same topic). Since many of such phrases in-

clude redundant information which are semantically

equivalent but vary in lexical choices, they exploit the

entailment graphs to discover if the information in one

phrase is semantically equivalent, novel, or more/less

informative with respect to the content of the other

phrase.

Also the combination of argumentation theory and

NLP is not new, and some existing works combine

NLP and argumentation theory (Ches

nevar and Ma-

guitman, 2004; Carenini and Moore, 2006; Moens

et al., 2007; Wyner and van Engers, 2010; Feng and

Hirst, 2011; Amgoud and Prade, 2012) with different

purposes, ranging from policy making support up to

recommendations on language patterns using indices,

ICAART 2016 - 8th International Conference on Agents and Artiﬁcial Intelligence

to automated arguments generation. However, only

few of them (Carenini and Moore, 2006; Moens et al.,

2007; Feng and Hirst, 2011) actually process the tex-

tual content of the arguments, but their goals, i.e., ar-

guments generation (Carenini and Moore, 2006), and

arguments classiﬁcation in texts (Moens et al., 2007;

Feng and Hirst, 2011) differ from ours.

Moreover, systems like Avicenna (Rahwan et al.,

2011), Carneades (Gordon et al., 2007), Arau-

caria (Reed and Rowe, 2004) (based on argumen-

tation schemes (Walton et al., 2008)), and Ar-

guMed (Verheij, 1998) use natural language argu-

ments, but the text remains unanalyzed as users are

requested to indicate the kind of relationship hold-

ing between two arguments. Finally, approaches

like (Leite and Martins, 2011; Gabbriellini and Tor-

roni, 2013b; Heras et al., 2013) show the added value

of applying argumentation theory to understand on-

line discussions and user opinions in decision support

and business oriented websites. Again texts here are

not the source of knowledge, and the linguistic con-

tent is not analyzed. All these approaches show the

need to make the two communities communicate and

jointly address such kind of open issues.

Up to our knowledge, the only work which tries

to combine TE with argumentation theory is (Cabrio

and Villata, 2012). The drawbacks of this work have

been previously detailed. For sake of completeness,

we have to mention that they (Cabrio and Villata,

2012) are aware about the ﬁrst drawback we identi-

ﬁed in their approach, i.e., the fact that the non entail-

ment relation is mapped to the attack relation even if

the meaning of the two is different, and they present

a data-driven comparison of the meanings of entail-

ment/support and non entailment/attack in (Cabrio

and Villata, 2013). However, the drawback still holds,

and a more general framework is required to obtain a

proper combination of TE and argumentation.

The added value of using argumentation theory in

on-line discussions and user reviews to support deci-

sion making on business oriented websites has been

shown by (Gabbriellini and Santini, 2015), while an

interesting approach to support argumentative discus-

sions on social networks, and more precisely on Twit-

ter, has been explored by (Gabbriellini and Torroni,

2012; Gabbriellini and Torroni, 2013a). We share

with these approaches the adoption of argumentation

theory to support intelligent interactions with other

users or big amount of data.

Finally, in the last years, the argument mining re-

search topic has become more and more relevant in

the Artiﬁcial Intelligence and Natural Language Pro-

cessing communities, as witnessed by the success of

the ‘Argument Mining’ workshop

. An interesting

approach that is worth mentioning in particular has

been recently presented by (Lippi and Torroni, 2015).

The authors propose a method that exploits structured

parsing information to detect claims without resorting

to contextual information. Even if the goal of the two

approaches is different, they go in the same direction

of developing supporting systems for users who inter-

act with big amount of data and need to be guided to

achieve an intelligent exploration experience.

3 BIPOLAR ENTAILMENT

GRAPHS

This section introduces the Textual Entailment frame-

work (Section 3.1), and its extension into bipolar en-

tailment graphs (Section 3.2).

3.1 Textual Entailment

In the NLP ﬁeld, the notion of Textual Entailment

(Dagan et al., 2009) refers to a directional relation

between two textual fragments, termed Text (T) and

Hypothesis (H), respectively. The relation holds (i.e.

T ⇒ H) whenever the truth of one text fragment fol-

lows from another text, as interpreted by a typical

language user. The TE relation is directional, since

the meaning of one expression may usually entail the

other, while entailment in the other direction is much

less certain. Consider the pairs in Examples 1, 2, and

Example 1.

T (id=3): People should be at liberty to treat their

bodies how they want to. Indeed, people are allowed

to eat and drink to their detriment and even death, so

why shouldn’t they be able to harm themselves with

marijuana use? This is, of course, assuming that their

use does not harm anyone else.

H (id=1): Individuals should be free to use mari-

juana. If individuals want to harm themselves, they

should be free to do so.

Example 2 (Continued).

T (id=2): Even if marijuana’s effects were isolated to

the individual, there is room for the state to protect

individuals from harming themselves.

H (id=1): Individuals should be free to use mari-

juana. If individuals want to harm themselves, they

should be free to do so.

https://www.cs.cornell.edu/home/cardie/naacl-2nd-

arg-mining/

Abstract Dialectical Frameworks for Text Exploration

Example 3 (Continued).

T (id=4): Individuals should be at liberty to experi-

ence the punishment of a poor choice.

H (id=2): Even if marijuana’s effects were isolated to

the individual, there is room for the state to protect

individuals from harming themselves.

In Example 1, we can identify an entailment re-

lation between T and H (i.e. the meaning of H can

be derived from the meaning of T), in Example 2, T

contradicts H, while in Example 3, even if the topic

is the same, the truth of H cannot be veriﬁed on the

bases of the information present in T (i.e. the relation

is said to be unknown).

The notion of TE has been

proposed as an applied framework to capture major

semantic inference needs across applications in NLP

(e.g. information extraction, text summarization, and

reading comprehension systems) (Dagan et al., 2009).

The task of recognizing TE is therefore carried out by

automatic systems, mainly implemented using Ma-

chine Learning techniques (typically SVM), logical

inference, cross-pair similarity measures between T

and H, and word alignment.

While entailment in its

logical deﬁnition pertains to the meaning of language

expressions, the TE model does not represent mean-

ings explicitly, avoiding any semantic interpretation

into a meaning representation level. Instead, in this

applied model inferences are performed directly over

lexical-syntactic representations of the texts. TE al-

lows to overcome the main limitations showed by for-

mal approaches (where the inference task is carried

out by logical theorem provers), i.e. (i) the computa-

tional costs of dealing with huge amounts of available

but noisy data present in the Web; (ii) the fact that for-

mal approaches address forms of deductive reasoning,

exhibiting a too high level of precision and strictness

as compared to human judgments, that allow for un-

certainties typical of inductive reasoning. But while

methods for automated deduction assume that the ar-

guments in input are already expressed in some for-

mal representation (e.g. ﬁrst order logic), addressing

the inference task at a textual level opens different and

new challenges from those encountered in formal de-

duction. Indeed, more emphasis is put on informal

reasoning, lexical semantic knowledge, and variabil-

ity of linguistic expressions.

In the two-way classiﬁcation task, contradiction and

unknown relations are collapsed into a unique relation, i.e.

non entailment.

(Dagan et al., 2009) provides an overview of the recent

advances in TE.

3.2 From Pairs to Graphs

As deﬁned in the previous section, TE is a directional

relation between two textual fragments. However,

in various real world scenarios, these pairs cannot

be considered as independent. This means that they

need to be collected together into a single graph. A

new framework involving entailment graphs is there-

fore needed, where the semantic relations are not only

identiﬁed between pairs of textual fragments, but such

pairs are also part of a graph that provides an over-

all view of the statements’ interactions, such that the

inﬂuences of some statements on the others emerge.

Therefore, we introduce the notion of bipolar entail-

ment graphs (BEG), where two kinds of edges are

considered, i.e., entailment and non entailment, and

nodes are the text fragments of TE pairs.

Deﬁnition 1 (Bipolar Entailment Graph). A bipolar

entailment graph is a tuple BEG = hT, E,NEi where

• T is a set of text fragments;

• E ⊆ T × T is an entailment relation between text

fragments;

• NE ⊆ T × T is a non entailment relation between

text fragments.

This opens new challenges for TE, that in the

original deﬁnition considers the T-H pairs as “self-

contained” (i.e., the meaning of H has to be derived

from the meaning of T). On the contrary, in arguments

extracted from human linguistic interactions a lot is

left implicit (following Grice’s conversational Maxim

of Quantity), and anaphoric expressions should be

solved to correctly assign semantic relations among

arguments.

4 TEXT EXPLORATION

THROUGH ARGUMENTATION

In this section, we ﬁrst introduce abstract dialecti-

cal frameworks (Section 4.1), and then we describe

which acceptability measures we choose for our text

exploration task (Section 4.2).

4.1 Abstract Dialectical Frameworks

Abstract dialectical frameworks (Brewka and

Woltran, 2010) have been introduced as a gen-

eralization of Dung-style abstract argumentation

frameworks (Dung, 1995) where each node is asso-

ciated with an acceptance condition. The slogan of

abstract dialectical frameworks is: ADF = depen-

dency graphs + acceptance conditions, meaning that,

ICAART 2016 - 8th International Conference on Agents and Artiﬁcial Intelligence

in contrast with Dung frameworks where links be-

tween nodes represent the type of relationship called

attack, in this framework different dependencies can

be represented in a ﬂexible way.

An ADF is a directed graph whose nodes represent

statements which can be accepted or not. The links

between the nodes represent dependencies: the status

(i.e., accepted, not accepted) of a node s depends only

on the status of its parents par(s), i.e., those nodes

connected to s by a direct link. Each node s is then

associated to an acceptance condition C

which spec-

iﬁes the exact conditions under which argument s is

accepted. C

is a function assigning to each subset of

par(s) one of the values in or out, where in means

that these arguments are accepted and out means that

they are rejected. Roughly, if for R ⊆ par(s) we have

(R) = in, this means that s will be accepted if the

nodes in R are accepted and those in par(s) \ R are

rejected.

Deﬁnition 2 (Abstract Dialectical Frame-

work (Brewka and Woltran, 2010)). An abstract

dialectical framework is a tuple D = hS,L,Ci where

• S is a set of statements (i.e., nodes);

• L ⊆ S ×S is a set of links;

• C = {C

}

s∈S

is a set of total functions C

par(s)

→ {in, out}, one for each statement s. C

called the acceptance condition of s.

For instance, Dung-style argumenta-

tion frameworks are associated to the ADF

Dung

= hArgs,att,Ci where the acceptance condi-

tions for all nodes s ∈ S is C

(R) = in if and only if

R =

0, and C

(R) = out otherwise. An example of

an abstract dialectical framework from (Brewka and

Woltran, 2010) is visualized in Figure 1, where grey

nodes are the accepted arguments, and acceptance

conditions are expressed as propositional formulas

over the nodes. For more details see (Brewka and

Woltran, 2010).

(Brewka and Woltran, 2010) underline that ADF

acceptance conditions can be deﬁned also through

positive and negative weights associated to links. In

particular, they introduce weighted ADFs presenting

their usefulness in the speciﬁc context of legal argu-

mentation, i.e., modeling ﬁve standards of proof. In

this paper, we start from weighted ADFs presented

in (Brewka and Woltran, 2010), and we adapt them

to represent our bipolar entailment graphs. Note that

weighted argumentation frameworks have been stud-

ied also by (Dunne et al., 2011), where weights are

used for handling inconsistencies, but there weights

are not exploited to compute the acceptance or rejec-

tion of the arguments. The advantage of using ADFs

to model bipolar entailment graphs, in contrast with

the approach proposed in (Cabrio and Villata, 2012),

is that the resulting “bipolar” argumentation graphs

are not forced to interpret the negative weighted links

as being attacks and therefore leading to a misconcep-

tion about the meaning of the non entailment relation

in TE.

4.2 Extracting Meaningful Information

using ADF

To explore texts searching for information which

satisﬁes speciﬁc constraints and shows certain fea-

tures, we adopt weighted abstract dialectical frame-

works (Brewka and Woltran, 2010), and we deﬁne

two acceptance conditions such that they allow us to

select, starting from a bipolar entailment graph, only

the information we are looking for. First, we deﬁne

a general weighted ADF (to which we map BEGs)

where an additional function is introduced to asso-

ciate each link to a weight, similarly to what was pro-

posed in (Brewka and Woltran, 2010).

Deﬁnition 3 (Weighted Abstract Dialectical Frame-

works). A weighted abstract dialectical framework is

a tuple D = hS,L,C,vi where

• S is a set of nodes;

• L ⊆ S × S is a set of links;

• C = {C

}

s∈S

is a set of total functions C

par(s)

→ {in, out}, one for each statement s. C

called the acceptance condition of s;

• v : L → W is a function associating weights to the

links, where W is a set of weights.

Mapping a BEG into a weighted ADF, we can

highlight two kinds of possible weights in bipolar

entailment graphs: i) qualitative weights, where we

distinguish between positive vs. negative weights

W = {+,−}, i.e., we consider the entailment links

as associated to a positive weight and non entailment

links as associated to a negative weight, and ii) nu-

merical weights, where we exploit the weights the TE

system assigns to each link as its conﬁdence, i.e., we

consider a range W ∈ [−1,1] such that the more the

link weight approaches -1, the more the system is con-

ﬁdent it is a non entailment relation and the more the

link weight approaches 1, the more the system is con-

ﬁdent it is an entailment relation. Figure 1 shows an

example of a weighted ADF, where C

is described.

Starting from the deﬁned weighted ADFs, we

have now to deﬁne the acceptance conditions we want

to adopt to guide the selection of the nodes in the

graph that we consider as relevant in our task. We

consider two use cases for text exploration: (a) a huge

online debate composed by several arguments, and we

Abstract Dialectical Frameworks for Text Exploration

⊤

¬b

b∨c

ADF

no negative links and

all positive links active

¬c ∧ (a ∧ b)

Cs(R):

Weighted ADF

Figure 1: Examples of ADF and weighted ADF together with the acceptance conditions deﬁned for nodes.

want to retrieve the arguments that are entailed by

at least one accepted statement and no negative link

is directed against them from accepted statements;

and (b) a set of users’ interactions about a service

have to be explored in order to retrieve those state-

ments which are highly entailed by other statements

in the BEG, and not much non entailed by other state-

ments (i.e., if the difference of their weights is above

a certain threshold). These two domain independent

acceptance conditions represent our heuristics to re-

trieve inside huge bipolar entailment graphs, the set

of information satisfying the goal of our text explo-

ration task.

The two acceptance conditions are formalized as

follows:

1. C

(R) = in if and only if

∃r ∈ R : v((r,s)) ∈ {+} ∧ ∀t ∈ R : v((t, s)) /∈ {−}

(1)

2. C

(R) = in if and only if, given r,t ∈ R,

maxv

((r, s)) − | maxv

−

((t,s))| > k (2)

where k is a certain threshold.

The ﬁrst acceptance condition models use case

(a): statement s is accepted if and only if R contains

no node with a negative link towards s and at least one

node with a positive link towards s, i.e., no node not

entailing s and at least one node entailing s. The sec-

ond acceptance condition models use case (b): state-

ment s is accepted if and only if the difference be-

tween the maximal positive weight and the absolute

value of the maximal negative weight is above a given

threshold k. Concerning those nodes which have no

incident links (i.e., par(s) =

0), we apply the follow-

ing acceptance condition: C

is in (constant function).

Note that we do not claim that these are the only pos-

sible acceptance conditions for identifying relevant

information during text exploration in BEGs. We de-

ﬁne such acceptance conditions because they provide

us with the information satisfying our text exploration

features. However, weighted ADFs applied to text ex-

ploration based on bipolar entailment graphs provide

a ﬂexible framework such that more complex accep-

tance conditions can be deﬁned depending on the kind

of information to be retrieved.

5 EXPERIMENTAL SETTING

This section evaluates the automated framework we

propose to support text exploration. As a ﬁrst step, we

run a TE system to assign the entailment and the non

entailment relations to the pairs of arguments. Then, a

bipolar entailment graph is built, where the arguments

are the nodes of the graph, and the automatically as-

signed relations correspond to the links of the graphs.

Finally, we adopt the abstract dialectical frameworks

to deﬁne acceptance conditions for the nodes of the

bipolar entailment graph. The dataset of argument

pairs on which we run the experiments is described

in Section 5.1, while the framework evaluation is re-

ported in Section 5.2.

5.1 Dataset

We experiment our framework on the Debatepedia

dataset

(described in (Cabrio and Villata, 2012)). It

is composed of 200 pairs, balanced between entail-

ment and non entailment pairs, and split into a train-

ing set (100 pairs), and a test set (100 pairs). The

pairs are extracted from a sample of Debatepedia

de-

bates, an encyclopedia of pro and con arguments on

critical issues (e.g. China one-child policy, vegetari-

anism, gay marriages). To the best of our knowledge,

it is the only available dataset of T-H pairs that can be

represented as bipolar entailment graphs.

Since (Cabrio and Villata, 2012) show on a learn-

ing curve that augmenting the number of training

pairs actually improves the TE system performances

The Recognizing Textual Entailment (RTE) data are

not suitable for our goal, since the pairs are not intercon-

nected (i.e. they cannot be transformed into argumentation

graphs)

http://idebate.org/

ICAART 2016 - 8th International Conference on Agents and Artiﬁcial Intelligence

on the test set, we decided to contribute to the exten-

sion of the Debatepedia data set manually annotating

60 more pairs (30 entailment and 30 non entailment

pairs). We followed the methodology described in

(Cabrio and Villata, 2012) for the annotation phase,

and we added the newly created pairs to the original

training set. We consider this enriched dataset of 260

pairs as the goldstandard in our experiments (where

entailment/non entailment relations are correctly as-

signed), against which we will compare the TE sys-

tem performances.

Starting from the pairs in the Debatepedia dataset,

we then build a bipolar entailment graph for each of

the topic in the dataset (12 topics in the training set

and 10 topics in the test set, listed in (Cabrio and

Villata, 2012)). The arguments are the nodes of the

graph, and the relations among the arguments corre-

spond to the links of the graphs.

To create the goldstandards to check the validity

of the two proposed acceptance conditions, we sep-

arately applied both conditions on the bipolar entail-

ment graphs built using manually annotated relations.

In particular, for the second acceptance condition that

consider the weights assigned on the links (see Sec-

tion 4), we consider the max weight of 1 to be at-

tributed to the entailment link (maximal conﬁdence

on the entailment relation assignment), and the max

weight of -1 to be attributed to the non entailment link

(maximal conﬁdence on the non entailment relation

assignment).

We are aware that the dataset we used is smaller

than the datasets provided in RTE challenges

, but we

consider it as a representative test set to prove the va-

lidity of our approach.

5.2 Evaluation

We carry out a two-step evaluation of our framework:

ﬁrst, we assess the TE system accuracy in correctly

assigning the entailment and the non entailment rela-

tions to the pairs of arguments in the dataset. Then,

we evaluate how much such accuracy impacts on

ADF graphs, i.e. how much a wrong assignment of

a relation to a pair of arguments is propagated in the

ADF by the acceptance conditions.

To detect which kind of relation underlies each

couple of arguments, we experiment the EXCITE-

MENT Open Platform (EOP)

, that provides a

generic architecture for a multilingual textual infer-

ence platform. We tested the three state-of-the-art en-

tailment algorithms in the EOP (i.e., BIUTEE (Stern

and Dagan, 2012), TIE and EDITS (Kouylekov and

http://bit.ly/RTE-challenge

http://hltfbk.github.io/Excitement-Open-Platform/

Negri, 2010)) on Debatepedia dataset, experimenting

several different conﬁgurations, and adding knowl-

edge resources.

The best results for the ﬁrst evaluation step on De-

batepedia are obtained with BIUTEE, adopting the

conﬁguration that exploits all available knowledge re-

sources (e.g. WordNet, Wikipedia, FrameNet) (see

Table 1). BIUTEE follows the transformation-based

paradigm, which recognizes TE by converting the text

into the hypothesis via a sequence of transformations.

Such sequence is referred to as a proof, and is per-

formed over the syntactic representation of the text

(i.e. the text parse tree). A transformation modiﬁes

a given parse tree, resulting in a generation of a new

parse tree, which can be further modiﬁed by subse-

quent transformations. The main type of transforma-

tions is the application of entailment-rules (Bar-Haim

et al., 2007) (e.g. lexical rules, active/passive rules,

coreference).

As baseline in this ﬁrst experiment we use a token-

based version of the Levenshtein distance algorithm,

i.e. EditDistanceEDA in the EOP, as shown in Table

1. In this table, we do not report the results of the

TIE system as it is not relevant with respect to the

present evaluation, as we ﬁxed EditDistanceEDA as

our baseline and the best performing system for our

task in the EOP is BIUTEE. The obtained results are

in line with the average systems performances at RTE

(∼0.65 F-measure

As a second step of our evaluation, we consider

the impact of the best TE conﬁguration on the accept-

ability of the arguments, i.e. how much a wrong as-

signment of a relation to a pair of arguments affects

the acceptability of the arguments in the ADF. We

use the acceptance conditions we deﬁned in Section

4 to identify the accepted arguments both on i) the

goldstandard entailment graphs of Debatepedia topics

(described in Section 5.1), and ii) on the graphs gen-

erated using the relations and the weights assigned by

BIUTEE on Debatepedia (since it is the system that

obtained the best performances, see Table 1).

BIUTEE allows many types of transformations,

by which an hypothesis can be proven from any text.

Given a T-H pair, the system ﬁnds a proof which

generates H from T, and estimates the proof validity

(Stern and Dagan, 2012). Finding such a proof is a se-

quential process, conducted by a search algorithm. In

each step of the proof construction the system exam-

ines all the possible transformations that can be ap-

plied, generates new trees by applying the selected

transformations, and calculates their costs by con-

The F-measure is a measure of accuracy. It considers

both the precision and the recall of the test to compute the

score.

Abstract Dialectical Frameworks for Text Exploration

Table 1: First step evaluation (results on Debatepedia test set, i.e. 100 pairs). Systems are trained on Debatepedia training set

(160 pairs).

EOP conﬁguration Accuracy Recall Precision F-measure

BIUTEE 0.71 0.94 0.66 0.78

EditDistanceEDA 0.58 0.61 0.59 0.59

structing appropriate feature-vectors for them. Even-

tually, the search algorithm ﬁnds the (approximately)

lowest cost proof. If the proof cost is below a thresh-

old (automatically learned on the training set, for de-

tails see (Stern and Dagan, 2011)), then the system

concludes that T entails H. The inverse of this cost

is normalized as a score between 0 (where T and H

are completely different) and 1 (where T and H are

identical), and returned as output. In other words, the

score returned by the system indicates how likely it

is that the obtained proof is valid, i.e., the transfor-

mations along the proof preserve entailment from the

meaning of T.

In order to apply the second acceptance condition

described in Section 4 using the scores returned by

BIUTEE as the weights on the links between nodes,

we need to have positive values (from 0 to 1) corre-

sponding to the conﬁdence of BIUTEE in assigning

the entailment relation to the pair, and negative val-

ues (from 0 to -1) corresponding to the conﬁdence of

BIUTEE in assigning a non entailment relation to the

pair. Since the scores that BIUTEE returns are nor-

malized between 0 and 1, where the threshold learned

on the Debatepedia training set is set to 0.5, we need

to shift such scores on the scale demanded by such

acceptance condition, setting the threshold to 0 and

normalizing the scores produced by BIUTEE accord-

ingly. In this new scale, i) the more the system is

conﬁdent that there is a non entailment relation be-

tween two arguments, the more its score (i.e. the link

weight) approaches -1; ii) the more the system is con-

ﬁdent that there is an entailment relation, the more

its score (i.e. the link weight) approaches 1; iii) the

more the system is uncertain about the assigned rela-

tion, the more the system score (i.e. the link weight)

approaches 0 (both on the negative and on the positive

scale).

Table 2 reports on the results of this second eval-

uation phase, where we evaluate the impact of BIU-

TEE on the arguments acceptability, adopting admis-

sible based semantics, with respect to a goldstandard

where the relations on the links have been assigned

by human annotators (Section 5.1). In general, the

TE system mistakes in relation assignment propagate

in the argumentation framework, but results are still

satisfying.

We are aware that in Debatepedia entailment

graphs the error propagation is also limited by i) their

size (see Table 2, column avg # links per graph);

and ii) the heuristic we applied in computing the ar-

guments acceptability, according to which the argu-

ments that have no negative incident links are ac-

cepted, augmenting the number of the accepted nodes

in the graphs. Concerning time complexity, the

weighted ADF module takes ∼1 second to analyze a

weighted ADF of 100 pairs, returning the relevant ar-

guments with respect to the selected acceptance con-

dition.

The results reported in Table 2 cannot be

strictly compared with the results shown in (Cabrio

and Villata, 2012), since the underlying role of the

entailment relation in the selection of the accepted ar-

gument is different. In this paper, we do not address

a comparison with the existing ADF software, such

as DIAMOND and QADF

, as the purpose of the

present paper is not to evaluate the performances in

computing ADFs, but the goodness of our system in

retrieving natural language arguments for topics ex-

ploration. However, we plan as future research to

adopt such systems for computing the acceptability

of the arguments, and to evaluate their performances

with respect to our speciﬁc task. Note that this evalu-

ation is not intended to evaluate the performances of

argumentation systems to compute the acceptability

of the arguments

, but it is meant to show the accu-

racy of the combined system (i.e., TE plus ADFs) in

detecting the arguments satisfying the speciﬁed fea-

tures, so that it can be exploited for a text exploration

task.

In general, we consider the results we obtained

experimenting our framework on the Debatepedia

dataset as promising, fostering further research in this

direction. An analysis of arguments returned by the

acceptability conditions has been addressed, and re-

sults show that the selected arguments contain rele-

vant information for the topics exploration.

In Figure 2, ADF

shows the weighted ADF result-

ing from the BEG whose text fragments are presented

in Section 3, together with the nodes selected through

the ﬁrst acceptance condition. Note that statement

“Individuals should be free to use marijuana. If in-

Complexity results for ADFs have been studied

by (Brewka and Woltran, 2010).

http://www.dbai.tuwien.ac.at/research/project/adf/

We refer the interested reader to the results of the First

International Competition on Computational Models of Ar-

gumentation (Thimm and Villata, 2015).

ICAART 2016 - 8th International Conference on Agents and Artiﬁcial Intelligence

Table 2: Results of the second evaluation (Debatepedia test set). Precision (avg): arguments accepted by the automatic

system and by the goldstandard with respect to an entailment graph; recall (avg): arguments accepted in the goldstandard and

retrieved as accepted by the automatic system.

Acceptance condition # graphs avg # links per graph Precision Recall F-measure

First 10 9.1 0.89 0.98 0.93

Second 10 9.1 0.894 0.98 0.95

ADF1

5 4

ADF2

0.60

-0.76

-0.73

0.58

-0.76

0.56

-0.64

0.57

0.58

Figure 2: Two examples from our dataset (ADF

- positive/negative weights, ADF

- numerical weights).

dividuals want to harm themselves, they should be

free to do so” is selected as it has an incident nega-

tive link but coming from a rejected argument, and it

is entailed by “People should be at liberty to treat their

bodies how they want to. Indeed, people are allowed

to eat and drink to their detriment and even death, so

why shouldn’t they be able to harm themselves with

marijuana use? [...]”. In Figure 2, ADF

shows the

weighted ADF we obtain for the whole ADF about

the topic “Gas Vehicles” from our dataset, where the

links are weighted with the conﬁdence the TE system

associates to the assigned relations. In this case, we

ﬁrst assign to the arguments the acceptability degree

computed following the formula of the second accep-

tance condition, and if the computed value is above

the threshold the argument is selected, i.e., it is evalu-

ated as in, otherwise it is discarded.

6 CONCLUSIONS

We have introduced the notion of bipolar entailment

graph where the pairs identiﬁed by the classical TE

framework are collected together into a single graph.

The advantage of moving from pairs to a graph lies in

the fact that the graph provides a structured view of

the text supporting text exploration tasks. In particu-

lar, we propose to exploit abstract dialectical frame-

works to perform such tasks: we deﬁne acceptance

conditions for the nodes such that the framework re-

turns us relevant information for our text exploration

task. Relying on ADFs ensures to our framework

high ﬂexibility in deﬁning the kind of nodes we look

for, i.e., the acceptance conditions, and allows us to

overcome some drawbacks highlighted in similar ap-

proaches in the literature (Cabrio and Villata, 2012).

Experiments on the Debatepedia dataset using state

of the art TE systems to automatically assign the in-

ference relations between the statements are promis-

ing, fostering further research in this direction. Both

the enriched Debatepedia dataset (260 pairs), and the

generated ADF are available for research purposes.

As for future work, we will test our framework on

a dataset built of customer interactions, where further

acceptance conditions may become necessary to re-

trieve other information in the texts. Moreover, we

will study how to modify the acceptance condition to

consider the fact that the relations assigned to a pair

by the system with a low conﬁdence (around 0) are

more uncertain than those assigned with a higher con-

ﬁdence. More speciﬁcally, we will consider to asso-

ciate to the conﬁdence values (from -1 to 1) a prob-

ability distribution, to improve the system ability in

assigning the semantic relation to the pair, depend-

ing on the presence of the entailment relation. An in

depth user evaluation of the arguments returned after

applying the acceptance conditions for the text explo-

ration task is an ongoing work. Finally, we plan to ex-

plore the adoption of GRAPPA (Brewka and Woltran,

2014), a semantical framework that allows to deﬁne

Dung-style semantics for arbitrary labelled graphs,

proposing acceptance functions based on multisets of

labels. This framework could allow to simplify the

deﬁnition of the acceptance functions thanks to the in-

troduced pattern language, enhancing the automated

evaluation of our framework.

http://bit.ly/DebatepediaExtended

Abstract Dialectical Frameworks for Text Exploration

REFERENCES

Amgoud, L. and Prade, H. (2012). Can AI models capture

natural language argumentation? IJCINI, 6(3):19–32.

Bar-Haim, R., Dagan, I., Greental, I., and Shnarch, E.

(2007). Semantic inference at the lexical-syntactic

level. In AAAI, pages 871–876.

Berant, J., Dagan, I., Adler, M., and Goldberger, J.

(2012). Efﬁcient tree-based approximation for entail-

ment graph learning. In ACL (1), pages 117–125.

Berant, J., Dagan, I., and Goldberger, J. (2010). Global

learning of focused entailment graphs. In ACL, pages

1220–1229.

Brewka, G., Strass, H., Ellmauthaler, S., Wallner, J. P., and

Woltran, S. (2013). Abstract dialectical frameworks

revisited. In IJCAI.

Brewka, G. and Woltran, S. (2010). Abstract dialectical

frameworks. In KR.

Brewka, G. and Woltran, S. (2014). GRAPPA: A semanti-

cal framework for graph-based argument processing.

In Schaub, T., Friedrich, G., and O’Sullivan, B., edi-

tors, ECAI 2014 - 21st European Conference on Arti-

ﬁcial Intelligence, 18-22 August 2014, Prague, Czech

Republic - Including Prestigious Applications of Intel-

ligent Systems (PAIS 2014), volume 263 of Frontiers

in Artiﬁcial Intelligence and Applications, pages 153–

158. IOS Press.

Cabrio, E. and Villata, S. (2012). Natural language argu-

ments: A combined approach. In ECAI, pages 205–

210.

Cabrio, E. and Villata, S. (2013). A natural language bipo-

lar argumentation approach to support users in on-

line debate interactions. Argument & Computation,

4(3):209–230.

Carenini, G. and Moore, J. D. (2006). Generating

and evaluating evaluative arguments. Artif. Intell.,

170(11):925–952.

Cayrol, C. and Lagasquie-Schiex, M.-C. (2013). Bipolar-

ity in argumentation graphs: Towards a better under-

standing. Int. J. Approx. Reasoning, 54(7):876–899.

Ches

nevar, C. I. and Maguitman, A. (2004). An argumen-

tative approach to assessing natural language usage

based on the web corpus. In ECAI, pages 581–585.

Dagan, I., Dolan, B., Magnini, B., and Roth, D. (2009).

Recognizing textual entailment: Rational, evalua-

tion and approaches. Natural Language Engineering

(JNLE), 15(Special Issue 04):i–xvii.

Dung, P. (1995). On the acceptability of arguments and

its fundamental role in nonmonotonic reasoning, logic

programming and n-person games. Artif. Intell.,

77(2):321–358.

Dunne, P. E., Hunter, A., McBurney, P., Parsons, S., and

Wooldridge, M. (2011). Weighted argument systems:

Basic deﬁnitions, algorithms, and complexity results.

Artif. Intell., 175(2):457–486.

Feng, V. W. and Hirst, G. (2011). Classifying arguments by

scheme. In ACL, pages 987–996.

Gabbriellini, S. and Santini, F. (2015). A micro study on

the evolution of arguments in amazon.com’s reviews.

In Chen, Q., Torroni, P., Villata, S., Hsu, J. Y., and

Omicini, A., editors, PRIMA 2015: Principles and

Practice of Multi-Agent Systems - 18th International

Conference, Bertinoro, Italy, October 26-30, 2015,

Proceedings, volume 9387 of Lecture Notes in Com-

puter Science, pages 284–300. Springer.

Gabbriellini, S. and Torroni, P. (2012). Large scale agree-

ments via microdebates. In Ossowski, S., Toni, F., and

Vouros, G. A., editors, Proceedings of the First Inter-

national Conference on Agreement Technologies, AT

2012, Dubrovnik, Croatia, October 15-16, 2012, vol-

ume 918 of CEUR Workshop Proceedings, pages 366–

377. CEUR-WS.org.

Gabbriellini, S. and Torroni, P. (2013a). Arguments in so-

cial networks. In Gini, M. L., Shehory, O., Ito, T.,

and Jonker, C. M., editors, International conference

on Autonomous Agents and Multi-Agent Systems, AA-

MAS ’13, Saint Paul, MN, USA, May 6-10, 2013,

pages 1119–1120. IFAAMAS.

Gabbriellini, S. and Torroni, P. (2013b). Netarg: an agent-

based social simulator with argumentative agents. In

AAMAS, pages 1365–1366.

Gordon, T., Prakken, H., and Walton, D. (2007). The

carneades model of argument and burden of proof. Ar-

tif. Intell., 171(10-15):875–896.

Heras, S., Atkinson, K., Botti, V. J., Grasso, F., Juli

an, V.,

and McBurney, P. (2013). Research opportunities for

argumentation in social networks. Artif. Intell. Rev.,

39(1):39–62.

Kouylekov, M. and Negri, M. (2010). An open-source pack-

age for recognizing textual entailment. In ACL (Sys-

tem Demonstrations), pages 42–47.

Leite, J. and Martins, J. (2011). Social abstract argumenta-

tion. In IJCAI, pages 2287–2292.

Lin, D. and Pantel, P. (2001). Discovery of inference rules

for question answering. Natural Language Engineer-

ing, 7:343–360.

Lippi, M. and Torroni, P. (2015). Context-independent

claim detection for argument mining. In Yang, Q. and

Wooldridge, M., editors, Proceedings of the Twenty-

Fourth International Joint Conference on Artiﬁcial In-

telligence, IJCAI 2015, Buenos Aires, Argentina, July

25-31, 2015, pages 185–191. AAAI Press.

Mehdad, Y., Carenini, G., Ng, R. T., and Joty, S. R. (2013).

Towards topic labeling with phrase entailment and ag-

gregation. In HLT-NAACL, pages 179–189.

Moens, M.-F., Boiy, E., Palau, R. M., and Reed, C. (2007).

Automatic detection of arguments in legal texts. In

ICAIL, pages 225–230.

Rahwan, I., Banihashemi, B., Reed, C., Walton, D., and Ab-

dallah, S. (2011). Representing and classifying argu-

ments on the semantic web. Knowledge Eng. Review,

26(4):487–511.

Reed, C. and Rowe, G. (2004). Araucaria: Software for

argument analysis, diagramming and representation.

International Journal on Artiﬁcial Intelligence Tools,

13(4):961–980.

Stern, A. and Dagan, I. (2011). A conﬁdence model for

syntactically-motivated entailment proofs. In RANLP,

pages 455–462.

ICAART 2016 - 8th International Conference on Agents and Artiﬁcial Intelligence

Stern, A. and Dagan, I. (2012). Biutee: A modular open-

source system for recognizing textual entailment. In

ACL (Demo), pages 73–78.

Thimm, M. and Villata, S. (2015). System descriptions

of the ﬁrst international competition on computa-

tional models of argumentation (iccma’15). CoRR,

abs/1510.05373.

Verheij, B. (1998). Argumed - a template-based argument

mediation system for lawyers and legal knowledge

based systems. In JURIX, pages 113–130.

Walton, D., Reed, C., and Macagno, F. (2008). Argumenta-

tion Schemes. Cambridge University Press.

Wyner, A. and van Engers, T. (2010). A framework for

enriched, controlled on-line discussion forums for e-

government policy-making. In eGov.

Abstract Dialectical Frameworks for Text Exploration
