Linear(hull) Cryptanalysis of Round-reduced Versions of KATAN

Danping Shi

1,2,3

, Lei Hu

1,2

, Siwei Sun

1,2

and Ling Song

1,2

State Key Laboratory of Information Security, Institute of Information Engineering,

Chinese Academy of Sciences, Beijing 100093, China

Data Assurance and Communication Security Research Center, Chinese Academy of Sciences, Beijing 100093, China

University of Chinese Academy of Sciences, Beijing 100093, China

Keywords:

KATAN, Mixed-integer Linear Programming, Linear Hull, Dependence.

Abstract:

KATAN is a family of block ciphers published at CHES 2009. Based on the Mixed-integer linear

programming(MILP) technique, we propose the ﬁrst third-party linear cryptanalysis on KATAN. Furthermore,

we evaluate the security of KATAN against the linear attack without ignoring the dependence of the input bits

of the 2 × 1 S-box(the AND operation). Note that in previous analysis, the dependence is not considered,

and therefore the previous results are not accurate. Furthermore, the mounted 131/120-round attack on

KATAN32/48 respectively by our 84/90-round linear hull is the best single-key known-plaintext attack. In

addition, a best 94-round linear hull attack is mounted on KATAN64 by our 76-round linear hull.

1 INTRODUCTION

Demands for lightweight ciphers used in resource-

constrained devices with low cost are increasing in

recent years. Many lightweight block ciphers are

published in recent years, such as LBlock (Wu and

Zhang, 2011), PRESENT (Bogdanov et al., 2007),

LED (Guo et al., 2011), PRIDE (Albrecht et al., 2014)

and SIMON (Beaulieu et al., 2013).

Related Works

KATAN is a family of lightweight block ciphers

published at CHES 2009 (Canni`ere et al., 2009). Af-

ter its publication, KATAN received extensive crypt-

analysis. For instance, the conditional differential

cryptanalysis by Knellwolf et al. (Knellwolf et al.,

2010) on 78/70/68-round KATAN32/48/64, differen-

tial cryptanalysis by Albrecht et al. (Albrecht and

Leander, 2012) on 115-round KATAN32, meet-in-

the-middle attack by Isobe et al. (Isobe and Shibu-

tani, 2012) on 110/100/94-round KATAN32/48/64,

match box meet-in-the-middle cryptanalysis by Fuhr

et al. (Fuhr and Minaud, 2014) on 153/129/119-

round KATAN32/48/64, and dynamic cube attack by

Ahmadian et al. (Ahmadian et al., 2015) on 118-round

or 155-round on KATAN32. All results are presented

in Table 1.

Linear cryptanalysis is an important cryptanalysis

technique on modern block ciphers (Matsui, 1993). It

corresponding author: Lei Hu

aims at ﬁnding a non-random linear expression on bits

of plaintext, ciphertext, and subkey, where the expres-

sion has non-zero correlation. The extended linear

hull cryptanalysis is presented by Nyberg (Nyberg,

1994) in 1995. No third-party linear cryptanalysis on

KATAN has been proposed. Furthermore, the security

evaluation of KATAN with respect to linear cryptanal-

ysis proposed by the designers is not accurate owing

to ignoring the dependence of the S-box, where the

dependence of S-box means that different S-boxes

share one same input.

Our Contribution

In this paper, we ﬁrst evaluate the linear security

cryptanalysis on KATAN32 without ignoring the de-

pendence of the S-box based on the Mixed-integer

linear programming(MILP) technique (Sun et al.,

2014a; Shi et al., 2014). Furthermore, 84/90/76-

round linear hulls on KATAN32/48/64 respectively

are proposed. Moreover, 131/120/94-round attack on

KATAN32/48/64 are mounted by these linear hulls. A

comparison between this paper and other single-key

attacks is listed in Table 1. Although, cryptanalysis

provided by paper (Fuhr and Minaud, 2014) can

attack more rounds, their cryptanalysis is based on

stricter chosen-plaintext model. As we know, the

131/120-round attacks on KATAN32/48 respectively

in this paper are the best single-key known-plaintext

attacks, and our 94-round attack on KATAN64 is the

ﬁrst linear attack on KATAN64.

The paper is organized as follows. Section 2

364

Shi, D., Hu, L., Sun, S. and Song, L.

Linear(hull) Cryptanalysis of Round-reduced Versions of KATAN.

DOI: 10.5220/0005739103640371

In Proceedings of the 2nd International Conference on Information Systems Security and Privacy (ICISSP 2016), pages 364-371

ISBN: 978-989-758-167-0

proposes the brief description of KATAN. Section 3

shows the searching method of linear masks. The re-

sults about the linear(hull) cryptanalysis are described

in Section 4. Section 5 is the conclusion.

2 BRIEF DESCRIPTION OF

KATAN

KATAN is a family of block ciphers with 32, 48,

or 64-bit block length, denoted by KATAN32,

KATAN48 or KATAN64 respectively. All versions

share the same 80-bit master key. For each version,

the plaintext is loaded in two registers L

and L

where the lengths of L

and L

for each version

are listed in Table 2. In the ﬁrst place, the round

function for KATAN32 is illustrated. For KATAN32,

the registers L

and L

are shifted to the left by

1 position, and two new computed bits by two

nonlinear functions f

(·) and f

(·) are loaded in the

least signiﬁcant bits of L

and L

, where the least

signiﬁcant(rightmost) bit for each register will be

denoted as 0-th bit. The ciphertext is obtained after

254 rounds. The f

and f

are deﬁned as follows

) = L

] ⊕ L

] ⊕ (L

] ∧ L

]) ⊕

] ∧ IR) ⊕ k

) = L

] ⊕ L

] ⊕ (L

] ∧ L

]) ⊕

] ∧ L

]) ⊕ k

where IR is round constant, k

and k

are two subkey

bits. The index x

and y

are listed in Table 2.

For KATAN48, the shift update of the registers

and the nonlinear function f

, f

are applied twice

with same round subkey in each round, while the

nonlinear functions and update of the register are

applied three times for KATAN64.

Since we only consider single-keycryptanalysis in

this paper, and therefore the key schedule is omitted

here. More details on KATAN can be found in

paper (Canni`ere et al., 2009).

3 THE LINEAR CRYPTANALYSIS

OF KATAN

3.1 Notations

[i]: the i-th bit of the register L

in r-th round

[i]: the i-th bit of the register L

in r-th round

: the r-th round subkey used in f

: the masks of the variable t

3.2 Deﬁnition of the Linear

Cryptanalysis

Let f be a boolean function, the correlation ε

of f is

deﬁned by

Pr( f(x) = 0) − Pr( f(x) = 1).

Suppose the encryption function is

F : F

→ F

x → y .

Then F

u,v

: u·x+v·y is the linear approximation of F

with input masks u ∈ F

and output masks v ∈ F

. The

linear cryptanalysis is evaluated by the correlation of

the approximation .

The potential introduced by Nyberg(Nyberg,

1994) is used to evaluate the linear hull cryptanalysis.

Given the input and output masks α and β for a

block cipher C = f(P,K), the potential ALH(α,β) is

deﬁned by

ALH(α,β) =

∑

(Pr(α· P+ β·C+ γ· K = 0) − 1/2)

3.3 Dependence of S-box

For simplicity, each AND operation ∧ is treated as a

2× 1 S-box. The S-box is active if the output mask is

non-zero. Since IR is constant, L

] ∧ IR is a linear

operation in each round, not an S-box. In this paper,

the dependence of two S-boxes illustrates that the two

S-boxes share one input. Owing to the fact that only

few bits are registered in each round, S-boxes for

KATAN are dependent.

Usually, the correlation of a linear characteristic

for a block cipher is obtained from the correlation

of the approximation of round function by pilling-

up lemma (Matsui, 1993). Whereas, the pilling-

up lemma is not suitable for KATAN due to the

dependence of the S-box.

For instance, suppose two approximations of two

S-boxes of L

in 0-th round and 3-th round, both with

zero input mask and non-zero output mask, are L

[5]∧

[8] and L

[5] ∧ L

[8]. Clearly, each approximation

has the same correlation(absolute) 2

−1

. The correla-

tion of XOR-ed function L

[5] ∧ L

[8] + L

[5] ∧ L

[8]

of the two approximations is 2

−2

if applying pilling-

up lemma. However, the correlation of L

[5]∧L

[8]+

[5] ∧ L

[8] = L

[5] ∧ (L

[8] + L

[5]) is 2

−1

due to

[8] = L

[5].

The above example shows that the dependence of

the S-box should be taken into consideration when

computing the correlation. Consequently, the corre-

lation of the linear characteristic will be computed

Linear(hull) Cryptanalysis of Round-reduced Versions of KATAN

365

Table 1: The analysis results of KATAN based on single-key.

Version Cryptanalysis method Model Rounds Data Time Reference

Differential CP 78 2

(Knellwolf et al., 2010)

Differental CP 115 2

(Albrecht and Leander, 2012)

Match box MITM CP 153 2

78.5

(Fuhr and Minaud, 2014)

KATAN32 Dynamic cube attack CP 118/155 2

78.3

(Ahmadian et al., 2015)

MITM KP 110 138 2

(Isobe and Shibutani, 2012)

Match box MITM KP 121 4 2

77.5

(Fuhr and Minaud, 2014)

Linear hull KP 131 2

28.93

78.93

Section 4.2

Differential CP 70 2

(Knellwolf et al., 2010)

Match box MITM CP 129 2

(Fuhr and Minaud, 2014)

KATAN48 MITM KP 100 128 2

(Isobe and Shibutani, 2012)

Match box MITM KP 110 4 2

77.5

(Fuhr and Minaud, 2014)

Linear hull KP 120 2

47.22

75.22

Section 4.2

Differential CP 68 2

(Knellwolf et al., 2010)

Match box MITM CP 119 2

78.5

(Fuhr and Minaud, 2014)

KATAN64 MITM KP 94 116 2

77.68

(Isobe and Shibutani, 2012)

Match box MITM KP 102 4 2

77.5

(Fuhr and Minaud, 2014)

Linear hull KP 94 2

Section 4.2

CP: chosen-plaintext attack; KP: known-plaintext attack

Table 2: The parameters for KATAN.

version |L

| |L

| x

KATAN32 13 19 12 7 8 5 3 18 7 12 10 8 3

KATAN48 19 29 18 12 15 7 6 28 19 21 13 15 6

KATAN64 25 39 24 15 20 11 9 38 25 33 21 14 9

directly instead of applying the pilling-up lemma in

this paper. The computing method in the following is

similar to paper(Sun et al., 2014a; Shi et al., 2014).

Obviously, the XOR-ed function of all

approximations for active S-box is a quadratic

function. Denote quadratic boolean function

f(t) = Q(t)+L(t), wheret = (t[1],t[2],··· ,t[n]) ∈ F

Q(t) = t[i

] ∧ t[i

] + t[i

] ∧ t[i

] + ·· · + t[i

m−1

] ∧ t[i

]

is the sum of quadratic term t[i] ∧ t[ j], and

L(t) = t[ j

] + t[ j

] + ·· · + t[ j

n−1

] + t[ j

] is linear

combination of t[i]. This kind of function satisfying

the property that i

,·· · ,i

m−1

are not

coincident is called the standard quadratic function

in the following. Most important, the correlation ε

of the standard function can be obtained directly as

follow:

• { j

, j

,·· · , j

} ⊆ {i

,·· · ,i

}: ε

= 2

−m/2

• others: ε

= 0.

In other words, if the correlation of the standard

function is non-zero, there is a negative correlation

between the correlation and the amount of the vari-

ables existing in the quadratic terms. Moreover, for

any quadratic function, there exists a non-singular

transform s = A·t such that g(s) = f(A

−1

·s) = Q(s)+

L(s) is the standard form of f. What is more, the

correlation of the standard function g equals to that of

For instance, f(t) = t[1] ∧ t[2] + t[1] ∧

t[3] + t[2] ∧ t[4] + t[2]. Suppose non-singular

transform s[1] = t[1] + t[4],s[2] = t[2] + t[3],s[3] =

t[3],s[4] = t[4], therefore the standard form

g(s) = s[1] ∧ s[2] + s[3] ∧ s[4] + s[2] + s[3]. Hence,

the correlation of f is obtained from g by the above

method, which is 2

−2

, due to {2, 3} ⊆ {1,2,3, 4}.

In brief, three steps for computing the correlation

of a linear characteristic are applied. Firstly, obtain

the XOR-ed function of all approximations of each

active S-box. Secondly, derive the standard form of

the XOR-ed function. Finally, calculate the correla-

tion of the standard form by the above method. The

calculating method is also suitable for other ciphers

with the similar S-box of KATAN, such as SIMON.

3.4 Automatic Enumeration of

Characteristic with MILP

Similar with paper (Sun et al., 2014a; Shi et al., 2014;

Sun et al., 2014b), we obtain the linear characteristic

by the automatic enumeration with Mixed-integer

linear Programming Modelling(MILP). The method

denotes each mask bit by a 0-1 variable, then

describes the propagation of the masks by linear

constraints and optimizes an objective function.

Constrains for linear operations are similar to

paper (Sun et al., 2014a; Shi et al., 2014; Sun

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

366

et al., 2014b). Following is the MILP modelling for

searching the linear characteristic, where α

denotes

the mask for variable t.

Constraints for Linear Operations

Constraints for bitwise XOR and branching structure

are same with paper (Sun et al., 2014a; Bogdanov and

Rijmen, 2014) in the following.

1. For XOR operation z = x ⊕ y, their masks satisfy

= α

2. For three branching structure z = x = y, their

masks satisfy











τ ≥ α

,τ ≥ α

+ α

≥ 2τ,

+ α

≤ 2,

where τ is the introduced new dummy variable.

Constraints for S-box

For S-box z = x∧y, their masks satisfy 2α

≥ α

+α

Constraints Dealing with Dependence of S-box

In order to consider the dependence of the S-box, the

| + |L

| initial variables of registers and the two

newregistered variableseach round loaded in the LSB

of registers are treated as original variables. In this

case, the XOR-ed function of approximationsfor each

active S-box can be expressed as a quadratic function

of these original 0-1 variables. Furthermore, there

is a negative correlation between the correlation(non-

zero) of the standard form and the number of the

variables existing in the quadratic terms as shown

in Section 3.3. Usually, the more variables exist

in the quadratic terms of a boolean function, the

more variables exist in that of its standard form. As

a consequence, the amount of the variables in the

quadratic terms is chosen as the preliminary measure

of the correlation. On the other hand, the fact that

one original variable exists in the quadratic terms is

equivalent to the thing that this variable is the input

of active S-box. Accordingly, the amount of all

original variables as inputs of active S-boxes are the

our preliminary measure of the correlation.

For each original variable t, denote a new 0-1

variable V

to indicate whether the variable t is the

input of one active S-box, where V

= 1 if it is. In

this case,

∑

t∈A

is our preliminary measure, where

A denotes the set consists of all original variables.

Furthermore, each variable t may be one input of

several S-boxes(suppose n

), which means these n

S-

box are dependent as previous shows. For instance,

the original variable L

[5] for KATAN32 affects 2 S-

box, 0-th and 4-th round S-box of L

. What is more,

if all the n

S-box are not active, V

= 0; otherwise

= 1. This property for each original variable can

be described by following constraints:

·V

≥ β

+ β

+ ··· + β

+ β

+ ··· + β

≥ V

where β

,i ∈ 1,··· ,n

, are output masks of the n

S-box, and also express whether these S-box are

active.

Objective Function

As previous shows,

∑

t∈A

is chosen as our prelim-

inary measure of the correlation. Usually, the more

variables exist in the quadratic terms, the smaller the

correlation is. Therefore the objective function is to

minimize

∑

t∈A

3.5 The Computation of potential

For each version, we will obtain the linear hull by

previous methods. In the ﬁrst place, obtain a lin-

ear characteristic with high correlation by Gurobi

software, with MILP modeling presented in above

Section 3.4. Secondly, search again to obtain as many

as possible suitable characteristics with additional

constraints of ﬁxing the input and output masks equal-

ing to that of the obtained linear characteristic with

high correlation. Finally, obtain the correlation for

each characteristic by the computing method shown

in previous Section 3.3, then give the potential.

4 RESULTS

The linear cryptanalysis shown by the designers

(Canni`ere et al., 2009) did not consider the

dependence of the S-box. The 126-round linear

characteristic eliminated by 42-round linear

approximation is not accurate, due to the dependence

of the S-box. With taking the dependence of S-box

into consideration, we obtain some new results for

the security cryptanalysis. Furthermore, some linear

hulls with high potential are obtained by the MILP

modelling shown in Section 3.4. What is more, we

mount some best attacks by these linear hulls.

4.1 Results for Linear Characteristic

For KATAN32, the correlation for the best 42-round

linear approximationis 2

−5

accordingto the designers

(Canni`ere et al., 2009), with ignoring the effect of

the dependence of S-box. In the case of taking the

dependence of S-box into consideration, we evaluate

the security of the linear cryptanalysis again. The

Linear(hull) Cryptanalysis of Round-reduced Versions of KATAN

367

Table 3: The input and output masks for linear hull.

version Input masks of register L

Input masks of register L

KATAN32 1000010001000 0000000000000010000

KATAN48 0000000000000000000 00000000000000000100000000100

KATAN64 0100000000100000100000000 000000000000000000100000000100010000000

version output masks of register L

output masks of register L

KATAN32 0010000000000 1000000000000000000

KATAN48 1000000001000000001 00000000100000000000000000000

KATAN64 1000001001001000100000000 100010000100000100101000100100000100100

Table 4: The involved subkey bits in the attack process.

version round of guessed-key for k

KATAN32 13, 9, 8, 6, 4, 3, 2, 1, 0, 111, 114, 115, 116, 118, 119, 120, 121, 122, 123, 124, 125, 126, 127, 128, 129, 130

KATAN48 7, 4, 3, 2, 1, 0, 107, 109, 110, 111, 112, 113, 114, 115, 116, 117, 118, 119,

KATAN64 5, 4, 3, 2, 1, 0, 89, 90, 91, 92,93

version round of guessed-key for k

KATAN32 10, 7, 5, 4, 3, 2, 1, 0, 111, 113, 115, 117, 119, 120, 121, 122, 123, 124, 125, 126, 127, 128, 129, 130

KATAN48 10, 6, 3, 2, 1, 0, 113, 116, 117, 118

KATAN64 5, 4, 2, 1, 0, 89, 91, 92, 93

version non-guessed key

KATAN32 k

107

112

117

105

116

KATAN48 k

106

110

114

119

KATAN64 k

Table 5: The involved bits of the registers for KATAN32.

Round bits of register L

bits of register L

0 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16, 17, 18

1 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 14, 15, 16, 17, 18

... ... ...

19 1, 10, 5 2

20 2, 11, 6 3

21 3, 12, 7 4

105 10 18

106 0, 11 8, 9, 11, 4, 13

107 1, 12 9, 10, 12, 5, 14

108 8, 9, 2, 6 0, 6, 10, 11, 13, 15

... ... ...

129 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16, 17, 18

130 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16, 17, 18

131 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16, 17, 18

correlation of the best 42-round linear approximation

is still 2

−5

by our method. At the same time, a

best 84-round linear characteristic with correlation

−15

is presented in Appendix, while the previous 84-

round linear characteristic is directly eliminated as no

more than 2

−5×2

by pilling-up lemma according to

the designers. The obtained 84-round linear charac-

teristic demonstrates that KATAN32 is secure against

linear cryptanalysis based on one linear characteristic,

however we can mount linear hull attack on KATAN

in the following.

For KATAN48/64, a best 43/37-round respec-

tively linear characteristic with correlation 2

−8

−10

is also obtained in this paper under the consideration

of the dependence of the S-box, while the previous

43/37-round linear characteristic for KATAN48/64

provided by designers has correlation 2

−9

−10

. Due

to the limitation of computing resources, the more

accurate security analysis for KATAN48/64 are not

obtained. The masks are listed in Appendix.

4.2 Results for Linear Hull

By setting the input and output masks presented in Ta-

ble 3, linear hulls for some versions are obtained with

some additional constraints owing to the limitation of

computing resource. Moreover, some best attacks are

mounted by these linear hulls.

For KATAN32, a 84-round linear hull consisting

of 98264 linear characteristics with potential 2

−27.93

is obtained with additional constraints

∑

t∈A

≤ 44.

In addition, a 131-roundattack with 21-round forward

and 26-round backward is mounted by this linear

hull. In the attack process, 50-bit subkey require

to be guessed, while another 10-bit subkey with

linear effect to the linear approximation do not. The

involved subkey bits in the attack process are listed in

Table 4, and the involved bits of the registers are listed

in Table 5.

For KATAN48, a 90-round linear hull consisting

of 99434 linear characteristics with potential 2

−46.22

is obtained with additional constraints

∑

t∈A

≤ 65.

Furthermore, we mount a 120-round attack with 16-

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

368

Table 6: The involved bits of the registers for KATAN48.

Round bits of register L

0 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16, 17, 18

1 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 17, 18

2 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16, 17

·· · ·· ·

14 17, 11, 6, 14

15 -

16 -

106 0, 9, 18

107 17, 2, 11, 14, 9

108 16, 8, 11, 4, 13

·· · ·· ·

118 0, 1, 2, 6, 8, 9, 10, 11, 12, 13, 14, 15, 16, 17, 18

119 1, 2, 3, 4, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16, 17, 18

120 1, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16, 17, 18

Round bits of register L

0 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 11, 12, 13, 14, 15, 16, 17, 18, 19, 20, 21, 22, 24, 26, 27, 28

1 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 13, 14, 15, 16, 17, 18, 19, 20, 21, 23, 24, 26, 28

2 0, 1, 2, 3, 4, 5, 6, 7, 9, 10, 11, 12, 13, 15, 16, 17, 18, 19, 20, 21, 22, 25, 26, 28

·· · ·· ·

14 7

15 0, 9

16 2, 11

106 20

107 1, 22

108 0, 24, 3

... ...

118 0, 1, 2, 3, 5, 6, 7, 8, 9, 11, 12, 13, 14, 15, 16, 17, 18, 20, 21, 22, 23, 24, 26, 28

119 0, 1, 2, 3, 4, 5, 7, 8, 9, 10, 11, 13, 14, 15, 16, 17, 18, 19, 20, 21, 22, 23, 24, 25, 26, 28

120 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 15, 16, 17, 18, 19, 20, 21, 22, 23, 24, 25, 26, 27, 28

Table 7: The involved bits of the registers L

for KATAN64.

Round bits of register L

0 0, 3, 4, 5, 6, 7, 8, 9, 10, 12, 13, 14, 15, 18, 19, 22, 23

1 0, 1, 2, 3, 6, 7, 8, 9, 10, 11, 12, 13, 15, 16, 17, 18, 21, 22

2 0, 2, 3, 4, 5, 6, 9, 10, 11, 13, 14, 15, 18, 19, 20, 24

·· · ·· ·

10 8, 17, 2

11 11, 20, 5

12 8, 14, 23

88 8, 24, 18, 12, 15

89 2, 21, 23, 11, 18, 14, 15

90 0, 1, 5, 13, 14, 17, 18, 21, 22, 24

91 3, 4, 8, 12, 14, 16, 17, 18, 20, 21, 23, 24

92 1, 2, 6, 7, 11, 12, 13, 14, 15, 17, 18, 19, 20, 21, 22, 23, 24

93 0, 1, 4, 5, 9, 10, 12, 13, 14, 15, 16, 17, 18, 20, 21, 22, 23, 24

94 0, 2, 3, 4, 7, 8, 10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 20, 21, 22, 23, 24

Round bits of register L

0 0, 1, 2, 4, 5, 6, 7, 8, 9, 11, 12, 13, 14, 16, 17, 18, 19, 20, 21, 22, 23, 24, 25, 26, 28, 30, 31, 32, 33, 35, 36, 37, 38

1 0, 1, 3, 4, 5, 7, 8, 9, 10, 12, 14, 15, 16, 17, 19, 20, 21, 23, 24, 25, 28, 29, 31, 33, 34, 36, 38

2 0, 3, 4, 6, 7, 8, 10, 11, 12, 13, 15, 17, 18, 19, 20, 23, 24, 27, 28, 31, 32, 36, 37

·· · ·· ·

10 1, 5, 14

11 8, 17, 4

12 11, 20, 7

·· · ·· ·

92 1, 2, 3, 5, 7, 11, 12, 14, 16, 17, 21, 22, 23, 24, 26, 27, 28, 29, 30, 32, 33, 35, 36, 37

93 0, 1, 2, 4, 5, 6, 8, 10, 11, 14, 15, 16, 17, 19, 20, 22, 23, 24, 25, 26, 27, 29, 30, 31, 32, 33, 34, 35, 36, 38

94 0, 1, 2, 3, 4, 5, 7, 8, 9, 10, 11, 12, 13, 14, 15, 17, 18, 19, 20, 22, 23, 24, 25, 26, 27, 28, 29, 30, 32, 33, 34, 35, 36, 37, 38

round forward and 14-round backward by this linear

hull. In the attack process, 28-bit subkey require to

be guessed, while another 8-bit subkey do not. The

involved subkey bits in the attack process are listed in

Table 4, and the involved bits of the registers are listed

in Table 6.

For KATAN64, a 76-round linear hull consisting

of 82908 linear characteristics with potential 2

−57

is obtained with additional constraints

∑

t∈A

≤ 77.

What is more, we mount a 94-round attack with 12-

round forward and 6-round backward by this linear

hull. In the attack process, 20-bit subkey require to

be guessed, while another 13-bit subkey do not. The

involved subkey bits in the attack process are listed in

Table 4, and the involved bits of the registers are listed

in Table 7.

The constraints

∑

t∈A

≤ 44/65/77 for

KATAN32/48/64 respectively is added due to

the limitation of computing resource. The data

complexity N of the linear hull attack is set by

2· ALH

−1

. Suppose the length of the guessed-key is

, thus the time complexity is N ·2

. The complexity

is summarized in Table 1.

5 CONCLUSION

We ﬁrst propose a third-party linear cryptanalysis on

KATAN in this paper. What is more, we ﬁrst take

the dependence of the S-box into the analysis for

Linear(hull) Cryptanalysis of Round-reduced Versions of KATAN

369

KATAN. At the same time, we evaluate the security

analysis on KATAN32 in the case of taking the depen-

dence of the S-box into consideration. Furthermore,

the 131/120-round attack mounted by our linear hull

on KATAN32/48 respectively is the best single-key

known-plaintext attack for KATAN.

ACKNOWLEDGEMENT

The authors would like to thank anonymous reviewers

for their helpful comments and suggestions. The

work of this paper was supported by the National Key

Basic Research Program of China (2013CB834203),

the National Natural Science Foundation of China

(Grants 61472417, 61472415 and 61402469), the

Strategic Priority Research Program of Chinese

Academy of Sciences under Grant XDA06010702,

and the State Key Laboratory of Information Security,

Chinese Academy of Sciences.

REFERENCES

Ahmadian, Z., Rasoolzadeh, S., Salmasizadeh, M., and

Aref, M. R. (2015). Automated dynamic cube attack

on block ciphers: Cryptanalysis of simon and katan.

IACR Cryptology ePrint Archive, 2015, page 040.

Albrecht, M. R., Driessen, B., Kavun, E. B., Leander, G.,

Paar, C., and Yalc¸in, T. (2014). Block ciphers - focus

on the linear layer (feat. PRIDE). In Advances in

Cryptology - CRYPTO 2014 - 34th Annual Cryptology

Conference, Santa Barbara, CA, USA, August 17-21,

2014, Proceedings, Part I, pages 57–76.

Albrecht, M. R. and Leander, G. (2012). An all-in-

one approach to differential cryptanalysis for small

block ciphers. In Selected Areas in Cryptography,

19th International Conference, SAC 2012, Windsor,

ON, Canada, August 15-16, 2012, Revised Selected

Papers, pages 1–15.

Beaulieu, R., Shors, D., Smith, J., Treatman-Clark, S.,

Weeks, B., and Wingers, L. (2013). The simon and

speck families of lightweight block ciphers. IACR

Cryptology ePrint Archive, 2013, 2013:404.

Bogdanov, A., Knudsen, L., Leander, G., Paar, C.,

Poschmann, A., Robshaw, M., Seurin, Y., and

Vikkelsoe, C. (2007). Present: An ultra-lightweight

block cipher. In Paillier, P. and Verbauwhede,

I., editors, Cryptographic Hardware and Embedded

Systems - CHES 2007, volume 4727 of Lecture Notes

in Computer Science, pages 450–466. Springer Berlin

Heidelberg.

Bogdanov, A. and Rijmen, V. (2014). Linear hulls with

correlation zero and linear cryptanalysis of block

ciphers. Designs, Codes and Cryptography, 2014,

70(3):369–383.

Canni`ere, C. D., Dunkelman, O., and Knezevic, M.

(2009). KATAN and KTANTAN - A family of small

and efﬁcient hardware-oriented block ciphers. In

Cryptographic Hardware and Embedded Systems -

CHES 2009, 11th International Workshop, Lausanne,

Switzerland, September 6-9, 2009, Proceedings,

pages 272–288.

Fuhr, T. and Minaud, B. (2014). Match box meet-in-

the-middle attack against KATAN. In Fast Software

Encryption - 21st International Workshop, FSE 2014,

London, UK, March 3-5, 2014. Revised Selected

Papers, pages 61–81.

Guo, J., Peyrin, T., Poschmann, A., and Robshaw, M.

(2011). The led block cipher. In Preneel, B. and

Takagi, T., editors, Cryptographic Hardware and

Embedded Systems, CHES 2011, volume 6917 of

Lecture Notes in Computer Science, pages 326–341.

Springer Berlin Heidelberg.

Isobe, T. and Shibutani, K. (2012). All subkeys recovery

attack on block ciphers: Extending meet-in-the-

middle approach. In Selected Areas in Cryptography,

19th International Conference, SAC 2012, Windsor,

ON, Canada, August 15-16, 2012, Revised Selected

Papers, pages 202–221.

Knellwolf, S., Meier, W., and Naya-Plasencia, M.

(2010). Conditional differential cryptanalysis of nlfsr-

based cryptosystems. In Advances in Cryptology -

ASIACRYPT 2010 - 16th International Conference

on the Theory and Application of Cryptology and

Information Security, Singapore, December 5-9,

2010. Proceedings, pages 130–145.

Matsui, M. (1993). Linear cryptanalysis method for

des cipher. In Helleseth, T., editor, Advances

in Cryptology, EUROCRYPT 1993, volume 765 of

Lecture Notes in Computer Science, pages 386–397.

Springer Berlin Heidelberg.

Nyberg, K. (1994). Linear approximation of block ciphers.

In Advances in CryptologyłEUROCRYPT’94, pages

439–444. Springer.

Shi, D., Hu, L., Sun, S., Song, L., Qiao, K., and Ma, X.

(2014). Improved linear (hull) cryptanalysis of round-

reduced versions of SIMON. volume 2014, page 973.

Sun, S., Hu, L., Wang, M., Wang, P., Qiao, K., Ma, X., Shi,

D., Song, L., and Fu, K. (2014a). Towards ﬁnding

the best characteristics of some bit-oriented block

ciphers and automatic enumeration of (related-key)

differential and linear characteristics with predeﬁned

properties. IACR Cryptology ePrint Archive, 2014,

2014:747.

Sun, S., Hu, L., Wang, P., Qiao, K., Ma, X., and Song, L.

(2014b). Automatic security evaluation and (related-

key) differential characteristic search: Application to

simon, present, lblock, des(l) and other bit-oriented

block ciphers. In Sarkar, P. and Iwata, T., editors,

Advances in Cryptology, ASIACRYPT 2014, volume

8873 of Lecture Notes in Computer Science, pages

158–178. Springer Berlin Heidelberg.

Wu, W. and Zhang, L. (2011). Lblock: A lightweight

block cipher. In Lopez, J. and Tsudik, G., editors,

Applied Cryptography and Network Security,2011,

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

370

volume 6715 of Lecture Notes in Computer Science,

pages 327–344. Springer Berlin Heidelberg.

APPENDIX

Table 8: The 84-round linear characteristic for KATAN32.

Round input masks of register L

input masks of register L

0 1000010001000 0000000000000010000

1 0000000000000 0000000000000100001

·· · ·· · · · ·

5 0000000000000 0000000001000010000

·· · ·· · · · ·

21 0000001000010 0000100001000000000

·· · ·· · · · ·

50 0000100001000 0000000000000000000

·· · ·· · · · ·

84 0010000000000 1000000000000000000

Table 9: The 43-round linear characteristic for KATAN48.

Round input masks of register L

input masks of register L

0 0000000001000001001 00000100000000100000000000000

·· · ·· · ·· ·

5 0000000010010010000 00000000000000000000000000001

·· · ·· · ·· ·

30 0001000001000000000 00000000000000000000000000100

·· · ·· · ·· ·

43 0000000000000000000 10000010000000000000000000000

Linear(hull) Cryptanalysis of Round-reduced Versions of KATAN

371
