IEEE C37.118-2 Synchrophasor Communication Framework

Overview, Cyber Vulnerabilities Analysis and Performance Evaluation

Raﬁullah Khan, Kieran McLaughlin, David Laverty and Sakir Sezer

Queen’s University Belfast, Belfast, U.K.

Keywords:

Smart Grid, Synchrophasor, Cyber Security, Vulnerability, IEEE C37.118.

Abstract:

Synchrophasors have become an important part of the modern power system and numerous applications have

been developed covering wide-area monitoring, protection and control. Most applications demand continuous

transmission of synchrophasor data across large geographical areas and require an efﬁcient communication

framework. IEEE C37.118-2 evolved as one of the most successful synchrophasor communication standards

and is widely adopted. However, it lacks a predeﬁned security mechanism and is highly vulnerable to cyber

attacks. This paper analyzes different types of cyber attacks on IEEE C37.118-2 communication system and

evaluates their possible impact on any developed synchrophasor application. Further, the paper also recom-

mends an efﬁcent security mechanism that can provide strong protection against cyber attacks. Although,

IEEE C37.118-2 has been widely adopted, there is no clear understanding of the requirements and limitations.

To this aim, the paper also presents detailed performance evaluation of IEEE C37.118-2 implementations

which could help determine required resources and network characteristics before designing any synchropha-

sor application.

1 INTRODUCTION

Synchrophasors are the measurements of electrical

quantities across different parts of the power system

synchronized using a common precise time source.

For higher accuracy and utilizing a universal time

source, synchrophasors are normally time-stamped

using Global Positioning System (GPS) time. With

the development of synchrophasor technology, nu-

merous applications have been proposed. Today, syn-

chrophasor technology is being used in Wide-Area

Monitoring System (WAMS), Wide-Area Protection

and Control System (WAPCS), islanding detection,

determining stability margins, system dynamics vi-

sualization and recording, enhancing operator situa-

tional awareness, etc (Schweitzer et al., 2008).

The aim of synchrophasor technology is to rep-

resent power system condition/status in real time.

This requires transmission of synchrophasor measure-

ments across large geographical areas in real-time

with very low latency. Using IP based communica-

tion is feasible where it utilizes already available high

speed infrastructure. To transmit synchrophasor mea-

surements over an IP network, a suitable communi-

cation framework is required. The IEEE C37.118-2

standard evolved as one of the most successful and

widely adopted communication framework for syn-

chrophasor applications. The IEEE C37.118-2 stan-

dard speciﬁes messaging format but does not put any

restriction on the choice of communication medium

or transport protocol. Further, IEEE C37.118-2 stan-

dard does not addressed security features. The syn-

chrophasor measurements are transmitted over inse-

cure IP network which make IEEE C37.118-2 com-

munication highly vulnerable to cyber attacks (Stew-

art et al., 2011).

This paper describes the IEEE C37.118-2 stan-

dard in details highlighting its main features and ca-

pabilities. It also explores how vulnerabilities can

be exploited to launch different types of attacks on

IEEE C37.118-2 communication system. In partic-

ular, reconnaissance, authentication/access, man-in-

the-middle, replay/reﬂection and denial of service at-

tacks are explored. These attacks alone or in com-

bination may severely impact the synchrophasor ap-

plications. They may leave different components of

the synchrophasor system not being able to commu-

nicate with each other or unintentionally performing

wrong decisions. For most critical synchrophasor ap-

plications, cyber attacks could potentially cause se-

vere damage to the physical equipment. Therefore, it

is vital to effectively analyze and mitigate cyber vul-

nerabilities in the synchrophasor system. Most often,

attackers try to exploit communication framework to

Khan, R., McLaughlin, K., Laverty, D. and Sezer, S.

IEEE C37.118-2 Synchrophasor Communication Framework - Overview, Cyber Vulnerabilities Analysis and Performance Evaluation.

DOI: 10.5220/0005745001670178

In Proceedings of the 2nd International Conference on Information Systems Security and Privacy (ICISSP 2016), pages 167-178

ISBN: 978-989-758-167-0

167

launch attacks. To protect IEEE C37.118-2 commu-

nication framework against attacks, this paper recom-

mends an effective security mechanism where secu-

rity policy and keying material periodically change.

Such refreshment of security credentials prevent at-

tacker never being able to discover a valid secret key.

Even if an attacker somehow discovers secret key

through analyzing captured packets, it will no longer

remain valid. In short, the main contributions of this

paper include:

1. Analysis of vulnerabilities in IEEE C37.118-2

standard through different cyber attacks and their

impact on the synchrophasor application.

2. Recommendation of an efﬁcient security mecha-

nism integrated in IEEE C37.118-2 standard and

evaluation of its effectiveness.

3. Detailed performance evaluation of IEEE

C37.118-2 standard to analyze requirements and

limitations in a practical environment.

The rest of the paper is organized as follows: Sec-

tion 2 addresses related work. Section 3 describes a

generic synchrophasor system and its basic building

blocks. Section 4 describes IEEE C37.118-2 stan-

dard, different types of deﬁned messages, and com-

munication modes and protocols. Section 5 analyzes

cyber vulnerabilities in IEEE C37.118-2 standard and

recommends a suitable security mechanism by ad-

dressing its unique features. Section 6 presents de-

tailed performance evaluation of IEEE C37.118-2 im-

plementations. Finally, Section 7 concludes the paper.

2 RELATED WORK

Synchrophasor technology got increasing popularity

since its development. Its applications quickly pro-

gressed from simple data visualization and archiv-

ing or postmortem analysis to several real-time pro-

tection, monitoring and control applications. This

is due to the capability of synchrophasors represent-

ing power system condition in real time and taking

prompt control actions. The authors in (Schweitzer

et al., 2008) described several advanced real-time syn-

chrophasor applications developed over time. Sev-

eral efforts were put to develop a suitable communi-

cation standard for synchrophasors. IEEE C37.118-2

evolved probably as the ﬁrst most successful commu-

nication standard. It was originally based on IEEE

1344 standard and its evolution is explained in (Mar-

tin et al., 2008). The authors have also highlighted

key differences between old and new versions and

introduced several applications for IEEE C37.118-2

standard.

Since, most synchrophasor applications involve

transmission of data across large geographic areas us-

ing non-reliable and insecure IP network, analysis of

potential cyber vulnerabilities and threats drawn more

and more research attention (Allgood et al., 2011).

It is worth to mention that IEEE C37.118-2 standard

does not include any security feature and making ap-

plications highly vulnerable to cyber attacks. Al-

though cyber security research in general is not new,

still implementation of experimental tools or strate-

gies to effectively mitigate vulnerabilities for syn-

chrophasor system is quite limited.

Authors in (Stewart et al., 2011) presented best

practice techniques (such as ﬁrewall, Virtual Private

Network (VPN)) and veriﬁed by experiments to over-

come cyber vulnerabilities. Their main focus was to

ensure information security between substation and

control center. However, security within the substa-

tion LAN or within the control center LAN has negli-

gible considerations. Authors in (Morris et al., 2011)

evaluated the resilience of Phasor Measurement Units

(PMUs) against denial of service attacks using IEEE

C37.118. They ﬂooded PMU with ARP request pack-

ets, IPv4 packets and PPPoE packets and monitored

its unresponsiveness. Further, the authors evaluated

resilience against malformed packets through proto-

col mutation tests. Several other efforts also tried to

protect synchrophasor network against cyber attacks

(Sikdar and Chow, 2011).

Along with information security, several research

efforts also focused on ensuring PMU and Phasor

Data Concentrator (PDC) security (D’Antonio et al.,

2011). A further work analyzing PMUs vulnerabili-

ties using IEEE C37.118 protocol was performed by

(Coppolino et al., 2014). Synchrophasor applications

require high time synchronization which is normally

achieved through GPS. GPS spooﬁng may leave se-

vere impact on any synchrophasor application. This

is analyzed by authors in (Shepard et al., 2012) that

GPS spooﬁng can cause intentional tripping of power

generators and may even cause physical damage to

equipment. A further work analyzing detection of

GPS spooﬁng attacks is presented in (Yu et al., 2014).

In short, cyber vulnerabilities analysis is a hot re-

search topic and numerous research articles are avail-

able in literature. There are also number of avail-

able surveys analyzing cyber threats relevant to smart

grid in general, PMU network, and/or synchrophasor

applications (Boyer and McBride, 2009), (Baumeis-

ter, 2010), (Yan et al., 2012), (Zargar et al., 2013),

(Beasley et al., 2014).

Most of the research in literature addresses cy-

ber vulnerabilities for power system in general with

few have little focus on synchrophasors network. No

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

168

much work is available on analyzing cyber vulnera-

bilities in IEEE C37.118-2 communication standard.

This paper analyzes cyber vulnerabilities in IEEE

C37.118-2 standard and evaluates possible impact on

the synchrophasor application. Further, this paper

also recommends a security mechanism to be used

with IEEE C37.118-2 standard to achieve protec-

tion against different cyber attacks. Although IEEE

C37.118-2 standard is being widely used, its require-

ments and limitations in practical environment have

never been addressed. To this aim, this paper also

presents detailed performance evaluation of IEEE

C37.118-2 standard.

3 OVERVIEW OF

SYNCHROPHASOR

MEASUREMENT SYSTEM

A synchrophasor system consists of several basic

building blocks including GPS receivers, PMUs,

PDCs, communication network and equipment and

visualization, monitoring or control software as

shown in Fig. 1. A PMU is the device that performs

measurements of synchrophasor data which represent

electrical quantities for current/voltage waveform at a

given time instant. The measurements performed by

PMU are normally time stamped to a common and

highly precise time source often GPS. Thus, PMU

devices are normally equipped with a GPS antenna.

The PMU can be a standalone device with dedicated

functionality or it may co-exist on a multi-functional

device. There are two possible modes of operations

of PMU; commanded and spontaneous. In com-

manded mode, PMU establishes bi-directional com-

munication with its peer (local or remote PDC or ap-

plication). The peer can send commands to PMU to

control its operations (e.g., stop/start or control syn-

chrophasors transmission). The communication be-

tween PMU and its peer is normally private unicast in

commanded mode. In spontaneous mode, PMU oper-

ations cannot be controlled by its peer. The commu-

nication is uni-directional (from PMU to its peer) and

PMU is not able to receive any commands. The com-

munication between PMU and its peers is normally

multicast in spontaneous mode of operation.

Another important element in a synchrophasor

system is PDC. PDC is a device which receives syn-

chrophasor data from more than 1 PMU and aggre-

gates and transmits as one output stream. A PDC may

be receiving data from multiple PMUs (i.e., substa-

tion PDC in Fig. 1) or multiple PDCs (i.e., Control

Center PDC in Fig. 1).

Substation 1

LAN

PDC

GPS Antenna

Substation N

LAN

PDC

GPS Antenna

Control Center

Monitoring /

Visualization

PDC

Control

Software

Archive

Network /

Internet

PMU

Figure 1: Generic synchrophasor communication system.

As illustrated in Fig. 1, the control center may be

receiving data from more than one substation and han-

dover to respective application. The application may

be designed for simply archiving data, performing vi-

sualization/monitoring or performing protection and

control functionalities. It can be observed in Fig. 1

that the synchrophasor data could be directly provided

by PMUs to respective application without needing

any PDC. However, such approach will result in a

lot of network trafﬁc overhead (analyzed in Section

6) and ambiguity for control application in interpret-

ing data from each PMU. Thus, the substation PDC

makes the transmission much more efﬁcient by send-

ing out only one stream of data instead of multiple

streams.

As depicted in Fig. 1, synchrophasor measure-

ments are transmitted in real-time over insecure pub-

lic Internet. Thus, a suitable communication proto-

col is required that can ensure security as well as low

transmission latency. IEEE C37.118-2 is most wide

used communication framework for synchrophasor

applications. Although it lacks security features and

is vulnerable to cyber attacks. Section 4 analyzes im-

portance of security and presents a suitable security

mechanism for IEEE C37.118-2 standard.

4 IEEE C37.118-2

COMMUNICATION STANDARD

Synchrophasor applications demand real-time trans-

mission of messages with very low latency. This sec-

tion brieﬂy addresses the IEEE C37.118-2 standard,

which evolved as one of the most suitable and well

tested standard for the transmission of synchrophasor

measurements. IEEE C37.118-2 standard effectively

addresses synchrophasor requirements, presents suit-

able format and structure for messages and ensures to

keep communication overhead to the minimum possi-

ble level.

IEEE C37.118-2 Synchrophasor Communication Framework - Overview, Cyber Vulnerabilities Analysis and Performance Evaluation

169

4.1 Overview

With the development of synchrophasor technology

and its need for transmission over wide area net-

works, IEEE established a working group to develop

a suitable communication standard. The working

group developed IEEE 1344 in 1995, the ﬁrst standard

for transmission of synchrophasor measurements in

real-time. IEEE 1344 addresses data formats, struc-

tures and time synchronization of data from multiple

sources. However, it does not address measurement

accuracy, support for transmission hierarchy, hard-

ware and software requirements, process for calcu-

lating synchrophasors, security mechanism and trans-

port protocol. These considerations are left to the

users based on their needs and application require-

ments.

In 2005, IEEE 1344 was replaced by an improved

IEEE C37.118 standard which overcomes the limita-

tions of the previous standard and focuses on the re-

quirements for future power systems. The most obvi-

ous improvements include the introduction of meth-

ods for evaluating measurement performance, ac-

counting measurements from multiple PMUs and a

more complete messaging system. It introduced To-

tal Vector Error (TVE) criterion to check if the mea-

surements are compliant with the standard. It mainly

shifted focus from the measurement method to the

measurement results. Thus, any algorithm or tech-

nique can be used as long as it produces acceptable

results.

The IEEE C37.118 standard was limited to ad-

dress accuracy requirements only for steady state

conditions. Over time, the IEEE realized the need

to address requirements for synchrophasor measure-

ments also under dynamic conditions. Further, IEEE

C37.118 standard combined synchrophasor measure-

ment and communication functions. To overcome

the shortcomings and ﬁx some minor errors, IEEE

C37.118 split into two parts in 2011, IEEE C37.118-

1 and IEEE C37.118-2. IEEE C37.118-1 addresses

requirements for synchrophasor measurements under

dynamic conditions which makes it very suitable for

most of the applications where the phasor measure-

ments could be severely affected by system noise and

disturbances. Whereas, IEEE C37.118-2 addresses

only the communication framework and requirements

for transmission of synchrophasors. It is worth men-

tioning that IEEE C37.118-2 is an extended standard

with some new features but provides full backward

compatibility with original IEEE C37.118. Further, it

also does not put any restriction on the choice of com-

munication protocol, communication medium and the

mode of communication.

SYNC

SOC

CHK

2 Bytes

2 Bytes 4 Bytes 4 Bytes

Depending on Data Size

2 Bytes

MSB

LSB

IDCODE

FRAMESIZE

FRACSEC

DATA 1 DATA 2

DATA N

Figure 2: IEEE C37.118-2 standard message format.

4.2 Message Format and Types

IEEE C37.118-2 speciﬁed a standard format for dif-

ferent types of the messages as depicted in Fig. 2.

Each message begins with identiﬁcation and synchro-

nization word (SYNC), followed by FRAMESIZE

(total Bytes inside message), IDCODE (ID of the

synchrophasor data source), SOC (Second Of Cen-

tury count since epoch midnight 01.01.1970), FRAC-

SEC (FRACtion of SECond and time quality), DATA

(Depends on message type) and CHK (Cyclic Re-

dundancy Check (CRC)). The content and structure

of DATA ﬁeld is different for different types of

messages. IEEE C37.118-2 standard described four

types of messages: data, conﬁguration, command and

header. Header message carries descriptive informa-

tion in human readable format while all other types

of messages are in machine readable format. Com-

mand messages are sent by the control application to

data source (e.g., PMU, PDC) as instructions/orders

while data, conﬁguration and header are sent by the

data source.

4.2.1 Data Message

Data messages are sent by the data source which

include real-time measurements of synchrophasors.

The sending device can be a PMU (containing single

block of data) or PDC (containing multiple blocks of

data). Each block of data contains a complete struc-

ture according to IEEE C37.118-2 (phasors in polar

or rectangular format, analog and digital values, fre-

quency deviation, rate of change of frequency etc). In

the case of a PDC, data from multiple PMUs is cor-

related to a particular time stamp and transmitted in a

single message.

4.2.2 Conﬁguration Message

Conﬁguration messages contain information and pro-

cessing parameters (calibration factors, meta data,

data types, etc) for a synchrophasor data stream. It ba-

sically provides necessary information to the receiver

on how to decode data messages. IEEE C37.118-2

standard identiﬁed three types of conﬁguration mes-

sages: CFG-1, CFG-2 and CFG-3. CFG-1 and CFG-

2 were also present in the ﬁrst IEEE C37.118 stan-

dard published in 2005. CFG-1 represents data source

(PMU, PDC) capabilities and the data it will be re-

porting. CFG-2 represents measurements currently

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

170

being transmitted in data messages. CFG-3 is similar

to CFG-1 and CFG-2 but includes added information

and ﬂexible framing.

4.2.3 Header Message

Header messages carry human readable descriptive

information about the data source, scaling algorithms,

ﬁltering etc. It does not have a special format for

the DATA ﬁeld (in Fig. 2) but carries information in

ASCII format.

4.2.4 Command Message

Command messages are orders received by a data

source device. These orders include but are not lim-

ited to: start and stop transmission of data messages,

send header message, send CFG-1, CFG-2 or CFG-3

conﬁguration message etc.

Data Source Controller

Command: Send Configurations

Configuration: CFG-2

Command: Start Data Transmission

Data: Synchrophasors

Command: Stop Data Transmission

Figure 3: Generic IEEE C37.118-2 communication sce-

nario for data source operating in commanded mode.

Fig. 3 depicts a generic communication scenario

when the data source operates in commanded mode.

For simplicity header message is not shown which

may be requested by control application/controller

using command message. Upon receiving request,

data source sends a header message to the con-

troller. When a data source operates in spontaneous

mode (cannot receive commands), then communica-

tion should only contain data and conﬁguration mes-

sages. A data source will ensure to send conﬁguration

messages whenever necessary to enable the receiver

to correctly decode data messages.

4.3 Communication Modes and

Protocols

IEEE C37.118-2 only speciﬁes different types of mes-

sages and their structure, format and content. It does

not put any restriction on communication mode or

choice of transport protocol. Most industrial imple-

mentations targeted either RS232 serial or IP based

network communication depending on the applica-

tion. The possible communication modes include:

client-server/unicast (one device sends data which is

received by one other device), multicast (one device

sends data which is received by a group of device) and

broadcast (one device sends data which is received by

all available device in the network). The freedom on

the choice of transport protocol leads to several com-

bination: (i) TCP for all types of messages, (ii) UDP

for all types of messages, and (iii) data messages on

UDP while all other messages on TCP. Each combi-

nation will have its own pros and cons which we will

try to analyze in Section 6.

5 SECURITY ANALYSIS &

RECOMMENDATIONS

IEEE C37.118-2 does not specify any kind of cryp-

tographic signature. Thus, packets are vulnerable to

spooﬁng, being modiﬁed in the network during trans-

mission or being transmitted by un-authorized peers.

This section ﬁrst analyzes how vulnerabilities in IEEE

C37.118-2 based communication system could be ex-

ploited in the form of different possible attacks. To

overcome the vulnerabilities, a security mechanism

based on Group Domain of Interpretation (GDOI) is

recommended that could be efﬁciently integrated in

IEEE C37.118-2 communication systems (Weis et al.,

2011). Finally, this section also analyzes the effec-

tiveness of the recommended security system.

5.1 Cyber Vulnerabilities Analysis

Cyber vulnerabilities in IEEE C37.118-2 could be ex-

ploited by unauthorized entities/attackers to extract,

modify or insert messages in the network. With the

knowledge of vulnerabilities, different types of at-

tacks could be launched which may impair the com-

munication and cause physical damage to the syn-

chrophasor system. The attacks described here are

based on the generic synchrophasor system depicted

in Fig. 1.

5.1.1 Reconnaissance Attack

In a reconnaissance attack, an adversary ﬁrst tries to

discover vulnerabilities in the network which could be

exploited for the actual attack. It is the unauthorized

learning process of the network devices or commu-

nication system to discover available services, open

ports, identify network stack daemons or the operat-

ing system, etc. Reconnaissance itself is not normally

a harmful action but provides necessary information

IEEE C37.118-2 Synchrophasor Communication Framework - Overview, Cyber Vulnerabilities Analysis and Performance Evaluation

171

for the adversary to plan and launch more severe at-

tacks such as Denial of Service (DoS) attack, access

attack etc.

Reconnaissance attack could be launched either

on the physical device or on the communication net-

work. The main focus here is the communication

network. Through eavesdropping on network traf-

ﬁc of IEEE C37.118-2, attackers could learn about

the substation name, names and locations of differ-

ent physical components (e.g., PMU, breakers) and

conﬁgurations of the device sending packets. Such

information is normally carried by IEEE C37.118-

2 conﬁguration messages. The attacker may be in-

terested in controlling the PMU operations (or the

whole substation depending on synchrophasor ap-

plication) through eavesdropping on command mes-

sages. Eavesdropping on data messages will enable

an attacker to know the current physical state of the

substation. The level of risk through eavesdropping

on header messages might be low or high depend-

ing on the synchrophasor application. In short, eaves-

dropping on different types of IEEE C37.118-2 mes-

sages can enable an attacker to launch high impact

attacks on the substation.

5.1.2 Authentication/Access Attack

Authentication is an access control mechanism which

ensures that only authorized users can get access to a

system or resources. It is the process in which cre-

dentials provided by the client devices are checked

and compared to the information on ﬁle/database and

access is granted only if the credentials match. Unau-

thorized access to a device or information is some-

times also referred to as access attack.

IEEE C37.118-2 does not specify any form of au-

thentication between communicating devices. Thus,

it is possible that the control application or the

PDC interprets messages being received from genuine

PMUs but it may not be the case. The messages may

be received from non-intended PMUs or from attack-

ers through packet injection or replay attacks.

Not only on the network trafﬁc, access attacks

may also take place on the physical device e.g.,

PMU/PDC or control center. Once attacker has con-

trol on the physical device, he can easily alter packets

being transmitted or injects packets on its own.

5.1.3 Man In The Middle Attack

In a Man In The Middle (MITM) attack, the at-

tacker impersonates two communicating devices and

makes them believe that they are directly communi-

cating with each other. Instead, the attacker lies in

the middle and is able to intercept each and every

packet exchanged between the two communicating

devices. The MITM attack may also involve connec-

tion/session hijacking. The attacker capabilities in a

successful MITM attack include hijacking packets, al-

tering or dropping them and injecting new packets.

The MITM attack can target any message type

in an IEEE C37.118-2 synchrophasor communication

system. However, its impact could be much more se-

vere on command, conﬁguration and data messages

compared to header messages. Targeting conﬁgu-

ration messages will enable an attacker to severely

disrupt the synchrophasor application. The attacker

can easily leave a receiver (applications at the con-

trol center) unable to decode/understand data mes-

sages. This makes attack on conﬁguration messages

the most attractive choice for an attacker. Command

messages control the whole communication and an

attacker may intentionally disrupt or start/stop the

transmission of data messages. Attacks on data mes-

sages may alter/modify the synchrophasor measure-

ments and make the receiver believe that the data is

genuine. This will leave receiver unintentionally per-

forming decisions based on incorrect data. The im-

pact of MITM attack on header messages is applica-

tion dependent.

5.1.4 Replay or Reﬂection Attack

Replay attacks rely on MITM attack to record com-

munication between two devices and replay it to hide

real system information. The replay packets might

lead to incorrect decisions by the receiving device.

Further, this attack does not require detailed knowl-

edge of the underlying system. The impact of replay

attacks on different types of IEEE C37.118-2 mes-

sages is similar to a MITM attack. Replaying data

messages may cause the receiver to carry out incorrect

actions. If conﬁgurations change, replaying old con-

ﬁguration messages could prevent the receiver from

decoding upcoming data messages.

5.1.5 Denial of Service Attack

The DoS attack is different from previous attacks as it

does not require unauthorized access to network traf-

ﬁc or the communicating devices but simply attempts

to disrupt or block communication between the com-

municating devices. The DoS attacks overwhelm

the target device with high data rate bulk packets so

that it becomes irresponsive due to lack of available

resources (bandwidth, CPU, memory etc) or buffer

overﬂow. Referring to Fig. 1, the DoS attack can be

on the communication link between PMUs and sub-

station PDC, substation PDC and control center PDC

or control center PDC and the control applications.

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

172

Group Controller / Key Server (GCKS)

Group Member Group Member Group Member

Internet

Phase 1

Phase 2

Phase 3

Figure 4: Generic GDOI-based communication scenario.

The most feasible choice for most of the attackers will

be targeting communication link between substation

PDC and control center PDC. This will lead to loss of

substations visibility for the control center.

Normally, DoS attacks will prevent all types of

IEEE C37.118-2 messages being processed by the re-

ceiver. However, if the DoS attack is weak, it may

result in less number of messages being lost at the

receiver. Depending on the type of message (that is

lost), the impact of DoS attack could be different.

Loss of conﬁguration message will leave receiver un-

able to decode upcoming data messages. Loss of few

data messages will make difﬁcult for the receiver to

take decisions due to not having enough information

about the synchrophasor system dynamics. Loss of

command message will prevent receiver from control-

ling data source. While the impact of DoS attack on

header message is application dependent.

5.2 Enabling Security based on GDOI

To secure the IEEE C37.118-2 based communica-

tion system against attacks, its inherent vulnerabilities

should be addressed. Further, a mechanism should

be introduced that can make attacker activities visi-

ble to the user. To this aim, this paper suggests the

use of GDOI to ensure secure communication of syn-

chrophasors using IEEE C37.118-2. GDOI is a group

key management protocol published by Cisco Sys-

tems & MIT (Weis et al., 2011). Since publication,

GDOI is getting increasing popularity. It has already

been adopted in IEC 61850-90-5, a real time commu-

nication system for the smart grid applications. GDOI

ensures that the communication remains highly se-

cure by constantly changing group Security Associ-

ations (SAs).

The generic GDOI-based communication sce-

nario is depicted in Fig. 4. The GDOI group

key management model consists of two types of de-

vices: Group Controller/Key Server (GCKS) and

Group Member (GM). GCKS is responsible to main-

tain group security policy and generation of keys. As

shown in Fig. 4, the GDOI mechanism consists of

three phases:

• Phase 1: The group members authenticate and

which are necessary to secure communication be-

tween the group members. The registration phase

is secured through encryption using Pairwise key.

It is possible that GCKS manages more than one

group and each group has different SAs. To re-

quest security policies and keys, group members

need to provide group ID to GCKS. After the

group ID is veriﬁed, GCKS sends group security

policy to the group member. The group member

checks if it can handle the policy and acknowl-

edges to the GCKS in order to download the Key

Encryption Key (KEK). The KEK is used to en-

crypt the message in which GCKS provides Traf-

ﬁc Encryption Key (TEK) to the group member.

• Phase 2: The group member uses TEK as an

IPsec SA to encrypt messages it exchanges with

other group members. In synchrophasor applica-

tions, TEK will be used to encrypt different types

of IEEE C37.118-2 messages.

• Phase 3: Remember, GCKS assigns both KEK

and TEK keys with certain validity period. The

keys should be refreshed periodically and pro-

vided to group members before the expiry of pre-

vious keys to enable uninterrupted secure commu-

nication between group members. This keys up-

date mechanism can be unicast to a single group

member or multicast to all group members. Mul-

ticast update messages have no delivery acknowl-

edgment and are transmitted multiple times to ac-

count for any packet loss.

The GDOI protocol is based on Internet Se-

curity Association and Key Management Proto-

col (ISAKMP) to protect the group members au-

thentication and registration in Phase 1. All the

group members and GCKS must have the same

ISAKMP policy acquired via an out of band method.

The ISAKMP policy should be strong enough as

the whole GDOI mechanism security depends on

it. Two new ISAKMP exchanges are deﬁned

in GDOI: GROUPKEY-PULL and GROUPKEY-

PUSH. GROUPKEY-PULL exchange is used in

Phase 1 as explained above. GROUPKEY-PULL ex-

change allows group members to request group pol-

icy and keying material (KEK, TEK) from GCKS.

GROUPKEY-PUSH exchange is Phase 3 in which

GCKS distributes the updated group policy and key-

ing material to all authorized group members before

the expiry of the previous keying material.

It is important that GCKS is explicitly a trusted

entity by all group members. If no authentication is

IEEE C37.118-2 Synchrophasor Communication Framework - Overview, Cyber Vulnerabilities Analysis and Performance Evaluation

173

performed, MITM attack between GCKS and group

member could be possible for a rogue GDOI partici-

pant. It is also important that GCKS explicitly authen-

ticates/authorizes each group member before sending

them group policy and keying material. The GCKS

should implement a method for authenticating mem-

bers (e.g., by maintaining an up to date authorization

list).

5.3 Beneﬁts of GDOI based Security

All the different types of attacks described in Sec-

tion 5.1 could be mitigated if the devices and IEEE

C37.118-2 communication are appropriately secured.

As explained before, the reconnaissance attack could

either take place on the network devices or the com-

munication network. The main focus here is only on

the communication network. If IEEE C37.118-2 mes-

sages are encrypted, eavesdropping on network traf-

ﬁc would not beneﬁt the attacker. Although IEEE

C37.118-2 does not include authentication, still the

authentication or access attacks could be prevented. It

is due to the fact that unauthorized users could not ac-

quire security policy and keying material from GCKS.

Without having valid TEK, devices are not be able to

communicate. Similarly to eavesdropping on network

trafﬁc, MITM attack could be easily prevented due to

encrypted messages.

The replay attacks replay the recorded communi-

cation between two devices. These attacks could also

be prevented due to periodic security policy and key-

ing material refreshment mechanism used in GDOI.

The replayed messages might be based on old key-

ing material which is no longer valid. This obviously

depends on the validity period of keys assigned by

GCKS. A shorter key validity period could effectively

prevent IEEE C37.118-2 based communication from

replay attacks. The DoS attacks overwhelm the target

device with high trafﬁc. The impact of DoS attacks

can be mitigated to a degree if the receiver simply

discard messages without processing them. This is

only possible if the receive knows that messages are

received from unauthorized device. The GDOI mech-

anism prevents any unauthorized device being able to

communication with authorized devices.

Thus, different types of attacks could be prevented

as long as key distribution mechanism is not com-

promised. GDOI assumes that the network is inse-

cure and could be exploited by attackers. However,

it assumes that GCKS and group members are all

trusted and secure. Any compromised group member

may enable attacker to reveal group policy and keying

material necessary to eavesdrop on network trafﬁc.

Therefore, group members must have proper security

in place preventing unauthorized access to them.

GDOI consists of three different phases as de-

scribed in Section 5.2. From a security point of view,

attackers will most probably look for vulnerabilities

in Phase 1 ISAKMP authentication, GROUPKEY-

PULL and GROUPKEY-PUSH exchanges of secret

keying material. The effectiveness of these exchanges

is brieﬂy described in the following.

5.3.1 Phase 1 ISAKMP Authentication

The authentication in Phase 1 is achieved via pre-

shared keys assuming secure GCKS and group mem-

bers. Any connection hijacking or MITM attack will

foil the authentication of one or more communicat-

ing peers during key establishment. An attacker may

launch replay or reﬂection attack between GCKS and

a group member and replays captured messages to a

group member. The replay of previous key manage-

ment messages could be detected as GDOI relies on

hash based message authentication along with Phase

1 nonce mechanism. Further, GDOI provides preven-

tion against DoS attacks by identifying spurious mes-

sages through a Phase 1 cookie mechanism prior to

processing cryptographic hash.

5.3.2 GROUPKEY-PULL Exchange

GROUPKEY-PULL exchange is used by group mem-

bers to request security policy and keying material

from GCKS. It is assumed that GCKS and group

members are secure and properly authenticated in

Phase 1. The GROUPKEY-PULL exchange is pro-

tected against connection hijacking and MITM at-

tacks as the authentication involves a secret known

only to GCKS and group members when construct-

ing HASH payload. Thus, the attacker could not alter

a message that goes undetected by GCKS or group

members. GCKS also keeps track of previously pro-

cessed GROUPKEY-PULL messages (e.g., message

HASH) and directly rejects messages previously pro-

cessed in order to not overload the computational re-

sources. This contributes to preventing against replay

and DoS attacks.

5.3.3 GROUPKEY-PUSH Exchange

GROUPKEY-PUSH exchange is used by GCKS to

update group members about new security policy and

keying material prior to the expiry of previous SAs.

The message is encrypted by KEK which is only

known to group members and distributed in previ-

ous GROUPKEY-PUSH exchange or GROUPKEY-

PULL exchange. The KEK is only known to GCKS

and group members (both are assumed secure) and

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

174

this provides protection against connection hijacking

and MITM attacks. The GROUPKEY-PUSH mes-

sages carry an increasing sequence number which

provides protection against reﬂection/replay attacks.

A group member will simply discard a GROUPKEY-

PUSH message if it contains sequence number the

same or lower than a previously received message.

Further, cookies provide protection against DoS at-

tacks for GROUPKEY-PUSH message.

6 PERFORMANCE EVALUATION

The implementation of the IEEE C37.118-2 library

was carried out in Linux OS using Python program-

ming language. A number of experiments were per-

formed to analyze the requirements, effectiveness and

limitations of IEEE C37.118-2 using different trans-

port protocols. Currently, research focuses on the ef-

ﬁcient design of PMUs/PDCs on compact hardware.

To this aim, all the experimental results reported in

this section were performed on a low power pocket

PC i.e., Raspberry Pi v2 (CPU: ARMv6 700 MHz,

Memory 512 MB, Power consumption: 3.6 W (idle)

& 3.8 W (full load)).

It is worth noting that any synchrophasor applica-

tion based on IEEE C37.118-2 will have its own re-

source requirements and performance metrics based

on its size, complexity and capabilities. The re-

ported results in this section are performance metrics

only ascribable to IEEE C37.118-2 library in any de-

veloped application. For all the reported results, it

is assumed that the PMU/PDC sends data messages

each carrying 2 phasors, 2 analog values and 1 dig-

ital word, all expressed in integer format except fre-

quency deviation (FREQ) and rate of change of fre-

quency (DFREQ) in ﬂoating point format. The same

settings are also reﬂected in Conﬁguration (Conﬁg)

messages.

6.1 Communication Overhead

The communication overhead is a signiﬁcant perfor-

mance metric for any protocol. It indirectly reﬂects

the maximum size of data that can be included inside

any packet. Further, it is also a factor affecting chan-

nel bandwidth requirements for transmission of mes-

sages. Normally, synchrophasor systems involve high

data transmission rates. This in turn requires more

channel bandwidth especially if the protocols com-

munication overhead is high.

The overhead for IEEE C37.118-2 is reported in

Table 1 considering different types of messages sent

Table 1: Size of real information and message formatting as

percentage of overall communication overhead (including

headers and protocol scemantics).

Using UDP Using TCP

RealInfo Formatting RealInfo Formatting

Data 26.83 % 21.95 % 3.77 % 3.08 %

Conﬁg 86.70 % 3.67 % 40.30 % 1.71 %

Command 3.33 % 26.67 % 0.36 % 2.85 %

Header 21.62 % 21.62 % 2.78 % 2.78 %

over UDP or TCP. It can be observed that the com-

munication overhead is signiﬁcantly low for Data and

Conﬁg messages; the two most frequently exchanged

messages in IEEE C37.118-2 based communication

systems. Compared to UDP, TCP has quite high com-

munication overhead due to exchange of several ad-

ditional packets during connection establishment and

termination.

Fig. 5 depicts how the communication overhead

is affecting with the increasing size of data messages.

The size of real information inside the packet in-

creases when a PDC aggregates data from multiple

PMUs which in turn results in lower communication

overhead. The number of PMUs data inside a PDC

depends on its location. A local/substation PDC may

aggregate data from 10 PMUs whereas regional con-

trol center or super PDC may carry data from up to

1000 PMUs (Grigsby, 2012). Fig. 5 illustrates that

UDP is the most favorable choice to transmit small

size packets. Choosing a low communication over-

head option (i.e., UDP) could signiﬁcantly reduce

channel bandwidth requirement. However, UDP is a

non-reliable protocol. The TCP could be a suitable

choice for transmission of large size packets (when its

overhead is not signiﬁcantly high compared to UDP)

to achieve reliability and other beneﬁts offered by

TCP in general.

100

120

140

5 10 15 20 25 30 35 40 45 50

Overhead Analysis (%)

Number of PMUs

Data + Formatting (UDP)

Communication (UDP)

Data + Formatting (TCP)

Communication (TCP)

Figure 5: Overhead analysis when PDC aggregates data

from multiple PMUs.

IEEE C37.118-2 Synchrophasor Communication Framework - Overview, Cyber Vulnerabilities Analysis and Performance Evaluation

175

6.2 Impact of Latencies

Latency is the critical factor that can impair the per-

formance of real-time applications in three ways: (i)

application latency which is ascribable to encoding

and decoding of different types of messages, (ii) net-

work latency which is time taken by packets to tra-

verse the network, and (iii) transport latency which

is time taken by transport protocol e.g., TCP to ac-

knowledge or retransmit data. Network and transport

latencies are linked with available bandwidth (low

latencies are observed on high bandwidth channels

and vice versa) whereas application latency depends

on the processing power of a given device. Table

2 presents the sum of all three latencies for differ-

ent types of IEEE C37.118-2 messages averaged over

100 transmissions. To avoid clock synchronization is-

sues between sender and receiver, latency measure-

ments were calculated from two-way time measure-

ments. The observed latencies are comparatively low

for UDP than TCP but the difference is not too signif-

icant. It is due to the fact that most of the latency is

ascribable to encoding and decoding of messages on

a low power device i.e., Raspberry Pi. Based on the

values reported in Table 2, there should be ideally no

packet loss if messages are transmitted at appropriate

rate (roughly 90 and 97 data messages per second for

TCP and UDP, respectively). Practically, high data

rates can be easily supported (especially for UDP) us-

ing parallel processing and large size socket buffer.

It can be observed in Table 2 that latencies are dif-

ferent for different types of messages. This is due to

different message size, format and structure. The la-

tencies are expected to increase with increase in mes-

sage size and complexity. Which will in turn affect

the maximum possible data transmission rate. Fig.

6 divides latencies into two parts: (i) time required

to encode the message and send it to receiver de-

vice, and (ii) time required to receive a message, an-

alyze/decode it and extract data. It is apparent from

Fig. 6 that encoding latencies are quite low compared

to decoding latencies. It is due to the fact that PDC

simply aggregates data from multiple PMUs during

the encoding process whereas control application in

decoding process performs deep inspection of re-

ceived packet to separate data of each PMU and ana-

lyze each and every bit according to Conﬁg. message.

This obviously depends on the processing power of

the devices performing PDC and control application

functionalities (Raspberry Pi in this case).

Compared to UDP, TCP provides several beneﬁts

such as ﬂow and error control, reliability and guaran-

teed delivery of data. However, TCP is normally not

suggested for high rate real-time transmission of mes-

100

150

200

250

300

350

400

10 20 30 40 50 60 70 80 90 100

Latency (ms)

Number of PMUs

Transmission & encoding latency

Transmission & decoding latency

Figure 6: Transmission & encoding/decoding latencies

when PDC aggregates data from multiple PMUs.

sages. To analyze the suitability of TCP for real-time

transmissions, Fig. 7 reports packet loss with increas-

ing data rate. For each data rate, 10,000 packets were

transmitted and number of lost packets were counted.

It can be observed in Fig. 7 that the packet loss in-

creases rapidly with increase in the data transmission

rate. This is due to the fact that each lost packet causes

an interval of packets loss. If TCP waits for the re-

covery of lost packets, data transmission rate will be

affected leaving worst effects on the performance of

real-time applications as well as throughput. Another

limitation of TCP is its incapability to support multi-

cast instead of establishing 1-1 connection which also

increases the network bandwidth requirements.

100

120

100 200 300 400 500 600 700 800 900 1000

Number of Lost Packets

Data Messages per second

Figure 7: Packet loss with increase in data transmission rate

using TCP as transport protocol.

6.3 Resource Requirements

This section analyzes the resource requirements in

terms of CPU and bandwidth. For applications to per-

form well, the minimum required processing power

and bandwidth should be available. Fig. 8 presents

the minimum required resources with increase in data

transmission rate. It can be observed in Fig. 8(a)

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

176

Table 2: Latencies for different types of messages.

Using UDP Using TCP

Min Average Max Std. Dev. Min Average Max Std. Dev.

Data 4.83 ms 10.28 ms 19.71 ms 1.96 ms 9.62 ms 11.07 ms 15.03 ms 1.13 ms

Conﬁg 7 ms 8.74 ms 17.26 ms 1.42 ms 7.82 ms 9.57 ms 13.57 ms 1.19 ms

Command 4.07 ms 5.89 ms 9.75 ms 1.39 ms 4.79 ms 6.44 ms 11 ms 1.21 ms

Header 4.17 ms 6.28 ms 13.83 ms 1.54 ms 5.98 ms 7.03 ms 11.89 ms 1.34 ms

that CPU usage of the application increases with in-

crease in data transmission rate. Fig. 8(a) depicts re-

sults obtained on Raspberry Pi and will be different

for other types of devices depending on the available

CPU power. The device processing power also affects

the message encoding/decoding latencies as reported

in Section 6.3.

The bandwidth requirement is the most critical

factor for any communication protocol. High data rate

on low bandwidth links can cause trafﬁc congestion

which will in turn result in packet loss. In computing,

bandwidth is the bit rate or maximum throughput that

can be supported by a given communication medium.

It can be observed in Fig. 8(b) and Fig. 8(c) that band-

width requirement increases linearly with increase in

data transmission rate. Further, the bandwidth re-

quirement depends on the message size. Large size

messages (e.g, including more phasors) have signif-

icant high bandwidth requirement especially at high

data transmission rates. Further, the bandwidth re-

quirement also has strong connection with the com-

munication overhead. TCP communication overhead

is higher than UDP resulting in 3-4 times increase

in bandwidth requirement at a given data rate. With

TCP, IEEE C37.118-2 based communication requires

roughly 500 kbps at 100 data messages per second

transmission rate which is lower than the maximum

bandwidth of most Internet access technologies ex-

cept the dialup (dialup/modem: 56 kbps, ADSL lite:

1.5 Mbps, ADSL1: 8 Mbps, ADSL2+: 24 Mbps,

wireless 802.11b: 11 Mbps, wireless 802.11g: 54

Mbps, wireless 802.11n: 600 Mbps, Gigabit Ethernet:

1 Gbps, etc). Some Internet access technologies may

not provide enough bandwidth for high synchropha-

sor data transmission rates (especially for PDC that

aggregates data from multiple PMUs).

6.4 Remarks

Based on the latencies, observed packet loss and

bandwidth requirement, TCP is an ideal choice only

for low data rate reliable transmissions. Its perfor-

mance gets worse under high data rates and low avail-

able channel bandwidth. On the other hand, UDP has

low bandwidth requirements, has low communication

overhead and does not cause incremental latency in

case of packet loss. This makes it suitable for high

data rate and real-time transmissions. However, it

is unreliable and does not guarantee the delivery of

data. Due to pros and cons of each transport proto-

col, the mixed approach will be ideal choice for IEEE

C37.118-2 based communication system. The mixed

approach will use reliable TCP for infrequent mes-

sages (Conﬁg, Command, Header) and non-reliable

UDP for frequent Data messages. The beneﬁts of

mixed approach include reliable transmission of crit-

ical information (e.g., Conﬁg message is very impor-

tant for receiver to understand how to decode received

Data messages, Command messages which control

whole communication between two peers, etc) and

minimum latency and low packet loss for real-time

streaming (Data messages). Another advantage of

mixed approach is its suitability for both client-server

as well as multicast mode of transmission.

7 CONCLUSIONS

Synchrophasors have become an integral part of the

modern power system and their applications are con-

tinuously evolving. Many synchrophasor applica-

tions involve transmission of messages over the In-

ternet. IEEE C37.118-2 is the well tested and most

widely used communication standard for transmis-

sion of synchrophasors data. This paper presented

an overview of IEEE C37.118-2 standard highlighting

its main features and capabilities. IEEE C37.118-2

standard does not have any embedded security mech-

anism which makes it highly vulnerable to cyber at-

tacks. This paper analyzed how different types of cy-

ber attacks can exploit vulnerabilities and impact the

operations of any synchrophasor application based on

IEEE C37.118-2.

To overcome IEEE C37.118-2 vulnerabilities, this

paper recommended a GDOI based security mech-

anism and addressed its effectiveness. GDOI pro-

vides enhanced security and protection against man-

in-the-middle, connection hijacking, replay, reﬂec-

tion and denial-of-service attacks. Finally, the paper

presented detailed performance evaluation of IEEE

C37.118-2 and analyzed network overhead, resource

requirements (e.g., bandwidth, CPU), communication

IEEE C37.118-2 Synchrophasor Communication Framework - Overview, Cyber Vulnerabilities Analysis and Performance Evaluation

177

100

100 200 300 400 500 600 700 800 900 1000

CPU usage (%)

Data Messages per second

(a) CPU usage

100

120

140

160

10 20 30 40 50 60 70 80 90 100

Min required capacity (kbps)

Data Messages per second

1 phasor, all integers

1 phasor, all floats

10 phasors, all integers

10 phasors, all floats

(b) Bandwidth (using UDP)

100

200

300

400

500

600

10 20 30 40 50 60 70 80 90 100

Min required capacity (kbps)

Data Messages per second

1 phasor, all integers

1 phasor, all floats

10 phasors, all integers

10 phasors, all floats

Figure 8: Resource requirements with increase in data transmission rate.

latencies and their impact on the data transmission

rate. The reported results provide enough information

about the required resources and network characteris-

tics before designing any synchrophasor application

based on IEEE C37.118-2 standard.

ACKNOWLEDGEMENTS

This work was funded by the EPSRC CAPRICA

project (EP/M002837/1).

REFERENCES

Allgood, G., Bass, L., Brown, B., Brown, K., Grifﬁn, S.,

Ivers, J., Kuruganti, T., Lake, J., Lipson, H., Nutaro,

J., Searle, J., and Smith, B. (2011). Security proﬁle

for wide-area monitoring, protection, and control. In

The UCAIug SG Security Working Group.

Baumeister, T. (2010). Literature review on smart grid cyber

security. In University of Hawaii, Technical Report.

Beasley, C., Zhong, X., Deng, J., Brooks, R., and Ve-

nayagamoorthy, G. K. (2014). A survey of electric

power synchrophasor network cyber security. In 5th

IEEE PES Innovative Smart Grid Technologies Eu-

rope (ISGT Europe). IEEE.

Boyer, W. F. and McBride, S. A. (2009). Study of secu-

rity attributes of smart grid systemscurrent cyber secu-

rity issues. In INL, USDOE, Battelle Energy Alliance

LLC., Rep INL/EXT-09-15500.

Coppolino, L., DAntonio, S., and Romano, L. (2014). Ex-

posing vulnerabilities in electric power grids: An ex-

perimental approach. In International Journal of Crit-

ical Infrastructure Protection vol:7(1), pp:51-60. EL-

SEVIER.

D’Antonio, S., Coppolino, L., Elia, I., and Formicola, V.

(2011). Security issues of a phasor data concentrator

for smart grid infrastructure. In 13th European Work-

shop on Dependable Computing. ACM.

Grigsby, L. L. (2012). Wide-area monitoring and situational

awareness. In Power System Stability and Control -

Third Edition, Volume 5. CRC Press.

Martin, K. E., Hamai, D., Adamiak, M. G., Anderson, S.,

Begovic, M., Benmouyal, G., Brunello, G., Burger,

J., Cai, J. Y., Dickerson, B., Gharpure, V., Kennedy,

B., Karlsson, D., Phadke, A. G., Salj, J., Skendzic,

V., Sperr, J., Song, Y., Huntley, C., Kasztenny,

B., and Price, E. (2008). Exploring the ieee stan-

dard c37.1182005 synchrophasors for power systems.

In IEEE TRANSACTIONS ON POWER DELIVERY,

VOL. 23, NO. 4. IEEE.

Morris, T., Pan, S., Lewis, J., Moorhead, J., Younan, N.,

King, R., Freund, M., and Madani, V. (2011). Cy-

ber security risk testing of substation phasor measure-

ment units and phasor data concentrators. In Seventh

Annual Workshop on Cyber Security and Information

Intelligence Research (CSIIRW ’11). ACM.

Schweitzer, E., Gong, Y., and Donolo, M. (2008). Ad-

vanced real-time synchrophasor applications. In 35th

Annual Western Protective Relay Conference.

Shepard, D., Humphreys, T., and Fansler, A. (2012). Evalu-

ation of the vulnerability of phasor measurement units

to gps spooﬁng attacks. In International Journal of

Critical Infrastructure Protection.

Sikdar, B. and Chow, J. (2011). Defending synchrophasor

data networks against trafﬁc analysis attacks. In IEEE

Transactions on Smart Grid, Vol:2, Issue: 4. IEEE.

Stewart, J., Maufer, T., Smith, R., Anderson, C., and Er-

sonmez, E. (2011). Synchrophasor security practices.

In 14th Annual Georgia Tech Fault and Disturbance

Analysis Conference.

Weis, B., Rowles, S., and Hardjono, T. (Oct. 2011). The

group domain of interpretation. In Internet Engineer-

ing Task Force (IETF) Request For Comments (RFC):

6407.

Yan, Y., Qian, Y., Sharif, H., and Tipper, D. (2012). A

survey on cyber security for smart grid communi-

cations. In Communications Surveys and Tutorials,

vol.14, no.4, pp.998-1010. IEEE.

Yu, D.-Y., Ranganathan, A., Locher, T., Capkun, S., and

Basin, D. (2014). Short paper: detection of gps spoof-

ing attacks in power grids. In Int. conference on Secu-

rity and privacy in wireless & mobile networks. ACM.

Zargar, S., Joshi, J., and Tipper, D. (2013). A survey of de-

fense mechanisms against distributed denial of service

(ddos) ﬂooding attacks. In Communications Surveys

and Tutorials, vol. 15, no. 4, pp. 2046-2069. IEEE.

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

178
