Modelling Duqu 2.0 Malware using Attack Trees with Sequential

Conjunction

Peter Maynard, Kieran McLaughlin and Sakir Sezer

Centre for Secure Information Technologies, Queen’s University Belfast, BT3 9DT, Belfast, U.K.

Keywords:

Duqu 2.0, Attack Trees with Sequential Conjunction, SAND, Malware Analysis, Threat Modelling.

Abstract:

In this paper we identify requirements for choosing a threat modelling formalisation for modelling sophisti-

cated malware such as Duqu 2.0. We discuss the gaps in current formalisations and propose the use of Attack

Trees with Sequential Conjunction when it comes to analysing complex attacks. The paper models Duqu

2.0 based on the latest information sourced from formal and informal sources. This paper provides a well

structured model which can be used for future analysis of Duqu 2.0 and related attacks.

1 INTRODUCTION

Threat modelling is used to visualise threats to a sys-

tem or process and provide a method to identify vul-

nerable areas which otherwise might have gone unno-

ticed. Threat modelling can be applied to many differ-

ent circumstances ranging from computer networks,

software life cycle, malware analysis and physical se-

curity. Not only can it provide the analyst with a vi-

sual representation, it is also possible to apply quan-

tiﬁcation methods to each possible threat path, result-

ing in a ranking of the likelihood that a speciﬁc vul-

nerability could be exploited. In most cases threat

modelling will take the form of the abstracted high

level steps an adversary could take when attempting

to compromise a process. This is normally repre-

sented as a graph, a tree or a combination matrix, and,

quantiﬁcation methods are then applied on top of the

model.

Typically there are two main approaches to threat

modelling, there are formalisms which are derived

from, or extend, the original threat trees, and for-

malisms based on attack graphs. Threat tree based

approaches are designed with the perceived threat at

the top of the diagram, which is referred to as the root

node. Underneath are multiple paths and leaf nodes

which an adversary could take to exploit the preserved

threat. Attack graphs are based on graphs where all

nodes are connected to each other and the values of

the vertices are used to measure the quantitative val-

ues. There is an inherent problem when using a graph

to model attacks, they are typically not able to scale

well.

Duqu 2.0 was identiﬁed by Kaspersky Labs

(Kaspersky, 2015) in 2014 and have conﬁrmed that

it is the re-emergence of the Duqu malware which

was found in 2011 which was active for a few months

before it was deactivated apparently by its creators.

Duqu 2.0 was ﬁrst found to be active about three

weeks before the Iranian nuclear talks were to take

place in the same physical location, with speculation

(Schneier, 2015; Zetter, 2015) on Duqu being used

for espionage by a nation state. Duqu and Duqu 2.0

share large amounts of code with the exception that

Duqu 2.0 was compiled with newer tool chains, it also

has many similarities in the way in which the code is

structured. Duqu 2.0 uses a range of compression and

encryption algorithms to avoid being detected, it also

hijacks existing process’s security clearances to pre-

vent anti-virus software from terminating the process.

Contributions: In this paper we develop a model

of the Duqu 2.0 malware based on the latest analy-

sis of the malware. There is a lot of information re-

garding Duqu 2.0 but no single formal deﬁnition has

been published, which can be used to deeply analyse

Duqu’s behaviour in greater detail. Most of the in-

formation regarding Duqu 2.0 is only in news reports

and white papers, which detail only the technical de-

tails of how it works. Modelling Duqu 2.0 using a for-

malised threat model gives future researchers a base

to develop new detection techniques and allow for ap-

plication of quantiﬁcation methodologies.

The paper is organised as follows: Section 2

explores some implementations of threat modelling

within cyber-physical systems. Section 3 discusses

existing threat modelling formalisations, and we

Maynard, P., McLaughlin, K. and Sezer, S.

Modelling Duqu 2.0 Malware using Attack Trees with Sequential Conjunction.

DOI: 10.5220/0005745704650472

In Proceedings of the 2nd International Conference on Information Systems Security and Privacy (ICISSP 2016), pages 465-472

ISBN: 978-989-758-167-0

465

model Duqu 2.0 in section 4 before presenting some

conclusions.

2 BACKGROUND

In this section we discuss the use of threat modelling

in the analysis of recent attacks, and threat modelling

speciﬁc to cyber-physical systems.

Bryes et.al (Byres et al., 2004) discuss the use

of attack trees in assessing vulnerabilities in SCADA

systems, the authors develop eleven models each with

there own speciﬁc attack goal. The models identify

vulnerabilities within SCADA protocols and in ex-

isting methods of ICS deployment. Although these

vulnerabilities are now well-known, they were not at

the time of publishing. Byres demonstrated that the

use of attack trees is suitable for use within the indus-

try and identify ﬂaws with the formalisation. It also

became evident that threat modelling was in need of

more exploration. Since the paper was published in

2004 there has been an uptake in threat modelling.

Ten et.al. (Ten et al., 2007) again used attack trees

to model threats to SCADA systems and have taken

it a step further than Bryes (Byres et al., 2004). They

have identiﬁed an analytical method to measure the

vulnerabilities. The analytical method allows for sys-

tematically evaluating threats and countermeasures.

One of the weaknesses which they identiﬁed by using

Attack Trees is there is no way to model the sequence

of the steps, which limits its usefulness. Though the

attack trees approach works well for pentesting and

studying security ﬂaws.

Tanu and Arreymbi (Tanu and Arreymbi, 2010)

model seven types of communication based attacks,

such as replay, DoS, man-in-the-middle and com-

mand injection. Augmented vulnerability tree was

able to model the communication based attacks,

and identify issues with the current SCADA proto-

cols. They recommended the use of message hashing

for authentication and encrypted communication be-

tween all devices. Though the mitigation results are

not novel, they were able to make use of threat mod-

elling within a SCADA environment with a successful

results.

Smith and Ma (Ma and Smith, 2013) have written

about risk assessment in which they model the con-

nections of the network based on the network trafﬁc.

This is done on a rule based system similar to ﬁre-

wall rules, once the network is modelled they iden-

tify what software and services are running on each

node and map vulnerabilities to any CVE and CVSS

found in a CVE database. They are then able to in-

fer the most likely multi attack path using that infor-

mation. This works well for mapping existing sys-

tems and performing a good audit of the network, and

could be a very good ﬁrst step for a penetration tester.

However, this does not help to identify future or exist-

ing attacks, how they may be performed or how they

can inﬁltrate the network.

Stuxnet is known as possibly the most advanced

persistent threat ever seen, and it was targeting cyber-

physical systems. Since then there has been more re-

search in the ﬁeld of SCADA and ICS security, than

in previous years. Duqu/Duqu2.0, Havex, BlackEn-

ergy, and the German steel mill attack are malicious

malware which have been seen to speciﬁcally target

critical infrastructure, without analysing these threats

we will not be able to defend against them in the fu-

ture. This is where threat modelling can help identify

features to be used for defending our critical infras-

tructures.

3 EXISTING THREAT

MODELLING APPROACHES

This section details four prominent threat modelling

formalisations designed for speciﬁcally modelling at-

tacks such as malware and network intrusions. To-

wards the end of this section we discuss the problems

with each of them.

3.1 Time-dependent Attack Trees

Time dependent attack trees evaluate the probability

of an attack as a function of time. The formalisation

has been formally described in (Arnold et al., 2014).

They make use of the sequential AND operator, as

described in section 3.4 which allows for sequential

operations. Due to the nature of the model, each node

needs to be given speciﬁc time values, which is the

expected length of time it would take for that step to

be achieved. It uses the bottom-up algorithm to quan-

tify the results. It is particularly difﬁcult to model an

attack and so the developers have used acyclic phase-

type distribution (APH) expressions to simplify de-

velopment of the models, they provide a prototype

web-based interface for generating the APH expres-

sions. It has been applied to a few test cases, and

appears to be able to handle complex attacks such as

Stuxnet.

3.2 Boolean Logic Driven Markov

Processes

Boolean Logic Driven Markov Processes (BDMP) is

a hybrid formalisation which is based on fault trees

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

466

combined with Markov graphs. Invented for use

within the safety and reliability area (Bouissou and

Bon, 2003) it was later applied to the security industry

by (Pietre-Cambacedes and Bouissou, 2010) in 2010.

Its goal is to ﬁnd a better trade off between readabil-

ity, modelling power and quantiﬁcation capabilities

with respect to the existing solutions particularly at-

tack trees. BDMP’s advantages over the traditional

attack trees are its ability to use what they call trig-

gers. Triggers allow modelling of sequences and sim-

ple dependencies by conditionally “activating” sub-

trees of the global structure. Because BDMP is based

on fault trees there is an array of connections avail-

able such as AND, OR and PAND gates, this also

gives the model the advantage that it is easy to un-

derstand and read. In (Kriaa et al., 2012) Kriaa mod-

els Stuxnet using BDMP. Quantiﬁcation for BDMP is

dependent on how the fault tree is modelled, and this

allows for a very versatile set of metrics. Typical met-

rics include: overall mean-time to success, probabil-

ity of success in a given time, ordered list of attack se-

quences leading to the objective, cost of attacks, han-

dling of boolean indicator and so on. It is also pos-

sible to model defence-centric attributes which reﬂect

the detection and prevention of the system already in

place, this allows for a more realistic prediction of at-

tack path. There is one tool (KB3-BDMP

) capable

of developing BDMP models and performing analy-

sis of the model, development and implementation of

the tool was detailed in (Pietre-Cambacedes and Def-

lesselle, 2011).

3.3 CoPNet

CoPNet is a hybrid threat model which combines at-

tack trees and coloured Petri nets. It was partially de-

ﬁned by (Bouchti and Haqiq, 2012), in this informal

speciﬁcation their case study is based on a SCADA

network. The case study is a simple SCADA network

with a 3-bus power grid which contains a HMI mon-

itoring the three generators, they model the network

and a range of possible threats then identify the most

likely attack path using their quantiﬁcation method. It

uses attack trees to model the attack to help in simpli-

fying the development and allow for importing exist-

ing models. Once an attack is modelled using attack

trees, CoPNet has detailed a method which can con-

vert attack trees into coloured Petri nets where they

can then perform the threat analysis. The authors

provide partially working tools available to develop

a CoPNet model. When testing we we’re unable to

generate a usable results from the tools.

http://researchers.edf.com/software/kb3-80060.html

3.4 Attack Trees with Sequential

Conjunction

Attack trees with sequential conjunction (SAND) is

an enhancement of attack trees, which were popular-

ized by Schneier (Schneier, 1999). SAND enhances

Attack Trees by deﬁning the use of a sequential AND

operator. This allows for the child nodes to be com-

pleted in sequence adding another level of complexity

without losing the simplicity of attack trees and main-

taining the advantages. SAND was deﬁned in 2015

and has formally been described in (Jhawar et al.,

2015), though this is the most formal deﬁnition of

the operator it has been used by other formalisations

previously. There is one primary tool which supports

SAND, called ATSyRA (Pinchinat et al., 2014), a tool

built on top of the Eclipse IDE.

3.5 Problems with Current Threat

Modelling Approaches

To effectively model the Duqu 2.0 malware it was

necessary to identify some requirements upon which

to chose a formalisation. It needs to be easy to un-

derstand in both the raw and visual form. An effec-

tive formalisation must be able to represent sequential

events or dependencies to be able to model a complex

process such as Duqu 2.0. A practical formalisation

also needs to support some form of quantiﬁcation so

the model can be used for analysis of the malware.

It is also desirable to have a formal speciﬁcation of

the formalisation to ensure that our model is built to a

correct standard.

Time Dependent attack trees upon ﬁrst glance ap-

pear to meet all the requirements. They have been

formally deﬁned, support sequential operations and

a working tool is available to help generate models.

Though as the name suggests, the only quantiﬁcation

which it supports is based on time, and that the model

has to be built using acyclic phase-type distribution

(APH) expressions which abstracts the model, thus

losing information, and reduces the readability of the

model. These two points make it unsuitable for our

application as we wish to develop a model which can

be easily understood and provide a base for further

quantiﬁcation metrics to be applied.

BDMP has a similar ability to represent sequen-

tial operations by using triggers. It has been formally

deﬁned, though it lacks the readability of traditional

attack trees. BDMP is a hybrid formalisation com-

bining attack trees and Markov graphs, this combina-

tion requires the model designer to have a solid under-

standing of BDMP before they can start working on

a model, as well as the modelling tool being depen-

Modelling Duqu 2.0 Malware using Attack Trees with Sequential Conjunction

467

dant on propitiatory software. Due to the high learn-

ing curve of BDMP over some of the other formalisa-

tions the authors feel that due to BDMP’s complexity

it reduces the likelihood of others continuing to use

and share the produced models.

Visually CoPNet is easy to understand and be-

cause it is based on attack trees, its raw form is also

easy to understand, but there is an extra step which

is needed to convert from attack trees into the model.

The conversion software is currently a prototype. This

extra requirement, along with an informal deﬁnition

of the formalisation, does not make it easy for other

analysts to continue working with a model. Further-

more the informal paper (Kriaa et al., 2012) says that

it can handle sequential operations but does not detail

how it can be modelled.

Attack Trees with Sequential AND (SAND) are

based on Attack Trees, which makes comprehending

the raw and visual representations of the formalisation

easier than the other formalisation. It is also a well

known and widely used approach which has been pre-

viously applied to cyber-physical systems. With the

addition of the Sequential AND operator, SAND al-

lows modelling of sequential operations and complex

systems. SAND has been formally deﬁned which al-

lows users to develop a model with reassurance that it

can be expanded in future works.

4 MODELLING DUQU 2.0

Based on the analysis of available threat modelling

techniques in the previous section, we have deter-

mined that SAND should be used to model the Duqu

2.0 malware. In this section we will introduce the ba-

sics of SAND and provide a detailed review of Duqu

2.0.

Attack trees are ordered to allow for systemati-

cally identifying different ways in which a system or

process can be attacked. Attack Trees are ordered

with the attacker’s goal at the top, called the root

node, and subsequent child nodes represent the at-

tacker’s sub-goals. The nodes are connected using

disjunctive (OR), conjunctive (AND) and sequential

conjunctive (SAND). The leaves of the tree represent

the attackers actions.

An example model based on the formalisation

(Jhawar et al., 2015) using SAND is shown in Fig-

ure 1, it details a ﬁle server offering ftp, ssh, and rsh

services. The Attack Tree shows the ways which an

attack can get root access. There are two ways ei-

ther without authenticating (no-auth) or by authenti-

cating (auth). The ﬁrst case (no-auth) the user must

gain privileges then perform a local buffer overﬂow

Figure 1: Example of the SAND formalisation.

attack (lobf). This is where the sequential AND oper-

ator is used, as the steps must be completed in order

for the attack to succeeded. To gain user privileges,

the attack must ﬁrst exploit the FTP service so that

they can upload a list of trusted hosts which rsh will

used to allow authentication to the server. In this ex-

ample SAND is executed in left to right order across

the nodes, (note that later this paper it is executed top

to bottom due to the size of the diagrams). The second

method of becoming root is to abuse a buffer over in

both the ssh daemon (ssh) and the RSAREF2 library

(rsa). These nodes are linked with AND, as each of

the steps can happen in any order.

Duqu 2.0 is primarily an information gathering

and exﬁltration malware, which has a lot of support

for remaining hidden from detection. It runs com-

pletely within RAM to avoid being detected and it

also leverages anti-virus detection system’s defences

to help remain hidden. It was ﬁrst found on the net-

work owned by Kaspersky spying on their activity.

It had used three highly complex zero-day exploits.

Not only is it able to hide from detection it has over

one hundred plugins, supporting various functions,

and the ability to encrypt and compress using a wide

range of algorithms. Duqu 2.0 comes in two versions,

full and light, full is around 18MB and contains all

the plugins needed, the light version contains just the

bare minimum with the ability to install plugins. One

of the key features is its ability to create an internal

proxy server for all the infected clients within the net-

work, the trafﬁc is then covertly transferred into and

out of the network without raising suspicion.

We have modelled Duqu using the SAND formal-

isation. The next three sections will discuss the model

in detail, which has been broken down into three man-

ageable parts as follows: Figure 2, Initial Compro-

mise and Lateral Movement, Figure 5, Execution of

the Payload, and Figure 4, Command and Control and

Plugin Operations.

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

468

4.1 Part A - Initial Compromise and

Lateral Movement

It is believed that Duqu was delivered by a targeted

spear-phishing campaign. When a victim received an

email and they downloaded and executed a word doc-

ument resulting in the, then zero-day, exploit CVE-

2014-4148, which is a vulnerability in the windows

TrueType font. The attacker crafts a custom TrueType

font which, when it gets parsed by the operating sys-

tem, allows the attacker to execute arbitrary code with

the security permissions of the kernel, virtually unre-

stricted.

Once the malware has kernel access it attempts

to propagate laterally through the network. Again,

it is able to take advantage of another zero-day ex-

ploit (CVE-2014-6324) to gain domain administrator

privileges using a ’pass the hash’ exploit. Essentially

Figure 2: Part A - Initial Compromise and Lateral Move-

ment.

it requests a token from the Kerberos authentication

server, decrypts it and forges the security groups so

that it looks as if the domain user is in the administra-

tors user group. This gives the malware unrestricted

administrative access to the domain controller and the

rest of the network.

Once Duqu 2.0 has administrator access to the do-

main controller it begins to propagate itself across the

network by remotely installing malicious a MSI ﬁle

on domain clients. An MSI ﬁle is an executable in-

stallation ﬁle used by windows, Duqu 2.0 can create

these executables which contain the necessaries to de-

ploy itself on client machines, Figure 3 shows the MSI

structure. It can install the MSI ﬁle remotely with

’msiexec.exe’ or using the task scheduler. There are

two versions of the MSI; one basic in-memory remote

backdoor, and another larger version (18MB) which

contains many of the advanced plugins. The MSI ﬁle

is encrypted and compressed using a unique combina-

tion of algorithms, making it hard to apply signature

detection upon the ﬁles.

4.2 Part B - Execution of the Payload

This section discusses Figure 5 which is focused on

the payload of the malware.

The MSI’s ﬁle structure, as shown in Figure 3,

contains two executable blocks, one is ’Custom ac-

tion dll’ which is used to decrypt and decompress the

payload called ’ActionData0’. ActionData0 also con-

tains encrypted and compressed executable code used

to deploy and manage the malware. Duqu is able to

adapt to its environment by using different payloads,

it can dynamically target CPU architectures as well

as a speciﬁc process. Kaspersky was able to identify

ﬁve payload containers each with similar conﬁgura-

tion. In this paper we have gone into detail on the

variation payload Type L with a focus on the Kasper-

sky anti-virus process as this has been the only pro-

cess covered in such detail. The other payloads are

similar to Type L, we have included the differences in

the model, and brieﬂy discuss them towards the end

of this section.

It ﬁrst attempts to locate and execute ’api-ms-win-

shell-XXXX.dll’, with ’X’ being a decimal, the num-

ber is based on the machine/boot time. If it can ﬁnd

that it will generate a PRNG kernel object, this allows

for the value to be unique and easily identiﬁed by an-

other process if it uses the same number generator.

If it already exists it will load the value located in it,

and if not it will open a device driver and issue some

IOCTL codes to the driver. This is used by another

module further on.

It starts to search though all the running processes

Modelling Duqu 2.0 Malware using Attack Trees with Sequential Conjunction

469

Figure 3: Kaspersky’s breakdown of Duqu’s MSI structure.

(Kaspersky, 2015).

on the host for a matching string, in our model it

speciﬁcally looks for ’avp.exe’. Which is the Kasper-

sky anti-virus process. Once it is located, it will at-

tempt to gain kernel access using CVE-2015-2360,

with the intention of loading the ’KMART.dll’ driver

with kernel level permissions. Loading ’KMART.dll’

with high permissions is done so as to allow hijacking

of the anti-virus’ security tokens.

Now it iterates over a list of hard coded registry

keys, with the intention of ﬁnding the location of in-

stalled security software, again in this instance we

are speciﬁcally looking for ’avp.exe’. Once the loca-

tion is found, it conﬁrms that the ﬁle is executable by

checking the environmental values resolve correctly,

the ﬁle will open, and it begins with 0x5A4D (MZ).

With the executable correctly identiﬁed it will map

it to memory and patch it to jump back to ’kilf.dll’

where it communicates with ’KMART.dll’, which is

a signed driver with kernel level permissions. Once

all this is done, it now appears to the operating sys-

tem and other processes that, Duqu is actually a pro-

cess owned by ’avp.exe’, the anti-virus. This effec-

tively means that it will be ignored by the anti-virus

software as it believes it is secure, and the defences

which Kaspersky have built into their application will

also be hijacked.

The four alternative payloads, G, I, K, and Q are

very similar to L but with some slight differences.

Figure 4: Part C - Command and Control and Plugin Oper-

ations.

Type G, is almost identical to L, but it skips hijack-

ing the processes’ security tokens and automatically

selects a process with a known conﬁguration. Type I,

is the same a G, but it searches for the processes us-

ing a hashed value. Type K, runs from the context of

the current process and blocks the threat until its com-

plete and Q does the same but runs asynchronously.

4.3 Part C - Command and Control and

Plugin Operations

This section will discuss Figure 4, which is focused

on the command and control and plugins. Command

and control instructions are handled with an array of

possible protocols, HTTP and HTTPs, which covertly

transmits the data as a JPEG/GIF to reduce the likeli-

hood of being detected. Duqu can also use SMB net-

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

470

Figure 5: Part B - Execution of the Payload.

work pipes and generic TCP connections. It forwards

remote desktop connections and controls all aspects

of the malware remotely using these methods.

The plugins are separated into two groups, attack

and reconnaissance. The attack section details some

of Duqu’s offensive plugins which range from re-

motely controlling a desktop, to responding to WPAD

requests, and running a fake SMB server to steal lo-

gin credentials. The reconnaissance describes fea-

tures which can be used to collect information, and is

divided into Network and System features. It is able

to detect when a packet capture tool is being run and

take precautions, it can also enumerate though the net-

work identify machines. It can steal passwords from

web browsers, email clients and the operating system.

It also targets speciﬁc ﬁle types which are related to

the operation of critical infrastructure.

5 CONCLUSION

In this paper we have modelled the fundamental

mechanisms of the Duqu 2.0 malware in a robust

and formally deﬁned model. The model was built

using the latest information on Duqu 2.0 gathered

from various formal and informal sources. The pa-

per has provided the security community with a com-

plex model, which can be expanded to perform quan-

tiﬁcation analysis of malware. This paper has iden-

tiﬁed features which can potentially be used to de-

tect and prevent such malware from appearing in the

wild. The paper has identiﬁed a suitable formalisa-

tion which can be used for future research into mal-

ware analysis as well as network threat modelling. By

using Sequential AND to model Duqu we were able

to generate a model which is easy to work with and

allows us to extract common features for future use.

The advantage of using SAND over existing formali-

Modelling Duqu 2.0 Malware using Attack Trees with Sequential Conjunction

471

sations is it’s simplistic modelling of complex attacks.

The textual representation allows for analysis of the

model without specialist tools or complex syntax.

REFERENCES

Arnold, F., Hermanns, H., Pulungan, R., and Stoelinga, M.

(2014). Time-Dependent Analysis of Attacks. In Prin-

ciples of Security and Trust (POST). Springer.

Bouchti, A. and Haqiq, A. (2012). Modeling cyber-attack

for SCADA systems using CoPNet approach. In

2012 International Conference on Complex Systems

(ICCS), pages 1–6.

Bouissou, M. and Bon, J.-L. (2003). A new formalism that

combines advantages of fault-trees and Markov mod-

els: Boolean logic driven Markov processes. Reliabil-

ity Engineering & System Safety, 82(2):149–163.

Byres, E. J., Franz, M., and Miller, D. (2004). The use of

attack trees in assessing vulnerabilities in scada sys-

tems. In in IEEE Conf. International Infrastructure

Survivability Workshop (IISW 04). Institute for Elec-

trical and Electronics Engineers.

Jhawar, R., Kordy, B., Mauw, S., Radomirovi, S., and

Trujillo-Rasua, R. (2015). Attack Trees with Sequen-

tial Conjunction. In ICT Systems Security and Privacy

Protection, number 455 in IFIP Advances in Informa-

tion and Communication Technology, pages 339–353.

Kaspersky (2015). The Mystery of Duqu 2.0: a sophisti-

cated cyberespionage actor returns.

Kriaa, S., Bouissou, M., and Pietre-Cambacedes, L. (2012).

Modeling the Stuxnet attack with BDMP: Towards

more formal risk assessments. In 2012 7th Interna-

tional Conference on Risk and Security of Internet and

Systems (CRiSIS), pages 1–8.

Ma, Z. and Smith, P. (2013). Determining Risks from Ad-

vanced Multi-step Attacks to Critical Information In-

frastructures. In Critical Information Infrastructures

Security, number 8328, pages 142–154. Springer.

Pietre-Cambacedes, L. and Bouissou, M. (2010). Attack

and Defense Modeling with BDMP. In Kotenko, I.

and Skormin, V., editors, Computer Network Security,

number 6258, pages 86–101. Springer.

Pietre-Cambacedes, L. and Deﬂesselle, Y. (2011). Security

Modeling with BDMP: From Theory to Implementa-

tion. pages 1 – 8.

Pinchinat, S., Acher, M., and Vojtisek, D. (2014). Towards

Synthesis of Attack Trees for Supporting Computer-

Aided Risk Analysis.

Schneier, B. (1999). Attack Trees. Dr. Dobb’s.

Schneier, B. (2015). Duqu 2.0. Schneier on Security.

Tanu, E. and Arreymbi, J. (2010). An examination of the se-

curity implications of the supervisory control and data

acquisition (SCADA) system in a mobile networked

environment. Proceedings of Advances in Computing

and Technology, (AC&T).

Ten, C.-W., Liu, C.-C., and Govindarasu, M. (2007). Vul-

nerability Assessment of Cybersecurity for SCADA

Systems Using Attack Trees. In IEEE Power Engi-

neering Society General Meeting, 2007, pages 1–8.

Zetter, K. (2015). Kaspersky Finds New Nation-State At-

tackIn Its Own Network.

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

472
