Collaborative Information Service

Privacy Algebra for User Defined Security

Asim Kumar Pal

, Subrata Bose

and Arpita Maitra

Management Information Systems Group, Indian Institute of Management Calcutta, Kolkata, India

Department of Computer Science and Engineering, Neotia Institute of Technology, Management & Science, Kolkata, India

Keywords: Privacy Template, Privacy Issue, Privacy Protection, Dominance Relation.

Abstract: With the increased activity over the internet and globalization of the market economy collaborative

computing becomes an important area of research. Security is an increasing concern because of chances of

malicious elements breaching the network of collaborating partners. Further the level of mutual belief

among the collaborators would not be identical and may change with experience. Thus the concept of user

defined flexible security requirements arose. The idea of user defined privacy template was brought in

IRaaS (Information Retrieval as a Service) (Pal and Bose 2013) which is a flexible system of information

services to customers who seek information from various sources through a service provider. The idea was

further extended to CIS (Collaborative Information Service) (Pal and Bose 2016) which provides a

framework for general information exchange activities (not restricted to retrievals only) for a set of

collaborating partners. The current work extends CIS by introducing privacy algebra to be applied on

templates to get a concise expression of privacy restrictions. CIS is a step towards a privacy aware

collaborative computing problem.

1 INTRODUCTION

Collaboration is often required by independent

organizations for their interlinked business, e.g.

partners in a supply chain. Many organizations find

that collaboration brings additional value to them.

Information exchange or information sharing plays a

major role in such joint activities. Consider a typical

example from e-commerce. An on-line purchase by

a buyer goes through a series of information

activities such as finding the products of interests,

checking their stocks in the warehouses, enquiring

delivery status of the items from warehouse to the

customer’s address, receiving payment through

some credit card company, waiting for return of

some goods, etc. In another situation, for a bulk

order involving different products and shipping

addresses all or most of the above tasks could be

performed without much of user interaction though

the purchase could be on-line or off-line. Such

applications can be designed as a sequence of

information exchange activities which are

collaborative in nature. We need efficiency as well

as security of the operations among separate and

independent organizations or organizational

components. This kind of computations comes under

what is known as collaborative computing.

Fundamentally such computation works on the

principles of distributed system (Zhu et al. 2006).

Security is a serious issue in collaborative

computing (Atallah 2006; Ahmed and Tripathi

2007). Security concerns are more serious when the

participants do not have much knowledge of each

other, e.g. a customer or a small business to a credit

card company. Collaboration is successful only

when the participants can keep trust in the system.

An important security concern in such collaborative

computation is at data level. All the data elements

belonging to a given participant need not be equally

sensitive with respect to specific opponents or its

security may need to be traded with efficiency of the

activity. This kind of security is known as attribute

oriented security (Zhang et al. 2006). Security in

collaboration can be user oriented or user defined

and role based. Pal and Dey (2014) proposed user

oriented policies for secure data storage and

computation of enterprise data in cloud collecting

varying perceptions of users about trustworthiness of

the Cloud Service Provider and also roles which the

users represent. The work of (Pearson, Shen and

Pal, A., Bose, S. and Maitra, A.

Collaborative Information Service - Privacy Algebra for User Deﬁned Security.

DOI: 10.5220/0005746304730481

In Proceedings of the 2nd International Conference on Information Systems Security and Privacy (ICISSP 2016), pages 473-481

ISBN: 978-989-758-167-0

473

Mowbray 2009) has close similarity in terms of

offering the user selection of privacy preferences

from a range of choices.

In an earlier work Pal and Bose (2013)

introduced a robust information retrieval service

(IRaaS) to its customer using a service provider

from a set of heterogeneous independent and

unknown data sources. IRaaS considered four types

of user selectable privacies – Identity, Data, Query

and Result. In a recent work Pal and Bose (2016)

introduced Collaborative Information Service (CIS)

for secure information exchange among the partners.

Like IRaaS, CIS uses privacy template to allow

users to express their security concerns against

inappropriate use of information by the opponents or

leakage of information to undesired parties. The

current work is an extension of CIS. It proposes

privacy algebra to represent user defined security

captured via privacy template, in a concise and

manageable form. CIS caters to seven privacy

aspects, namely, Identity, Schema, Data Read, Data

Write, Result, Query and Query Distribution. Each

of these privacies is looked at the granularity level of

each participant against all other resulting in a huge

number of combinations. It is not desirable or

practically feasible to handle such huge variations

which also mean providing a very large number of

security mechanisms or protocols. Idea of

simplification arose from this. Privacy algebra

basically helps simplify expressing the overall

privacy needs of a collaborative computing job using

dominance and join properties of privacies

(discussed in section 3).

Rest of the paper is organized as follows. Section

2 discusses CIS. Section 3 describes its privacy

model. Section 4 describes privacy algebra. Section

5 shows the applicability of privacy algebra on CIS.

Section 6 summarizes the paper and concludes with

future direction of the work.

2 CIS SYSTEM

CIS is an information service intended to bring

together a number of independent and autonomous

entities such as different organizations, departments

or units of an organization, individuals etc. for

collaborative information exchange among them to

perform a task or execute an application. These

entities form a network, each entity representing a

node of the network. The information service

processes users’ information request which involves

data read or write. For every action (query or

transaction) a subset of the entities participates. For

example, Amazon might have a number of sources

for a product, number of courier services for home

delivery etc. but for an order it will choose a

particular courier service and one or more of the

available sources of the products. An online

shopping transaction in Amazon also requires data

write (update) operations in cases such as change of

delivery status or shipment status or payment status,

etc. For simplicity, we assume that each entity owns

a single data source, e.g. a denormalized form of a

database. Our proposed model offers a framework

for secure processing of any general collaborative

application which involves data read or write We

introduce one independent entity called Service

Provider (SP) to facilitate the collaboration. Each

partner (entity) has a certain degree of trust on SP,

which may change over time. We assume that SP

knows the data definition of each entity. Similarly,

each entity has to know the identity of SP. CIS is

composed of three components namely the

adversarial model, security framework and

computational model.

2.1 Adversarial Model (AM)

The security assumptions regarding the adversaries

are expressed through the privacy constraints desired

by a player vis-à-vis his opponents (partners in

collaboration and the SP) through a privacy template

(section 3) built on privacy issues and protections

(Pal and Bose 2016).

2.2 Security Framework (SF)

Security framework of CIS is guided by three

phases. The initial phase which is the setup phase of

a specific service or an application chooses the

collaborating entities – the data sources (DS) and the

SP. This phase is also responsible for constructing

the global data dictionary coupled with the global

privacy template. Once the setup is done, the system

is ready to accept any transaction processing request

of a user. This is accomplished by a transaction

specific setup phase followed by the transaction

execution phase. The transaction setup phase allows

the user to specify its privacy restrictions through

local data dictionary and a local privacy template

which will supersede the global restrictions.

Generally, SP is positioned as the entity to carry out

the setup jobs. In the transaction execution phase a

sequence of sub processes involving a subset of data

sources is constructed. This is a distributed

processing scenario which may allow some sub

processes to execute in parallel (Pal and Bose 2016).

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

474

2.3 Computation Model (CM)

N entities (organizations) with their data sources,

... DS

collaborate to provide an information

service to their customers. The service provider SP

is chosen by the entities or SP chooses himself. SP

has full knowledge of the data definition of each DS.

The user or customer C obtains services from this set

of data owner entities. C hosted on one such entity

sends his request to the transaction related entities

either directly or through SP. The query formed to

service the request has three parts, <command,

target clause, predicate clause>. The command is

Retrieve, Insert, Delete or Update. The target clause

for retrieval is a set of expressions i.e. functions

defined on the attributes from DSs. Delete command

in its target list refers mainly to rows (occasionally

columns) in one or more database tables. Insert and

Update have an additional clause representing the

values to be put in for a new record or for replacing

the contents of an existing record. The predicate

clause is a logical expression involving the attributes

of different DSs.

SP builds global data dictionary by aggregating

individual data dictionaries of all DS. Privacy

template of each DS specifies its privacy

requirement against all other participants C, SP and

other DS for any read or write operation. This

includes privacy of any data element or attribute of

the DS, its identity, schema, data or any part of the

results. Similarly, it also includes the privacy of C

regarding its identity, the query raised by it and the

results or any part result. Note that query or

transaction could be an important thing to be

protected from being disclosed or misused when it is

an isolated or ad hoc query as in the case of IRaaS

(Pal and Bose 2013), but may not be so critical when

each such query is part of an application requiring

joint computation. For write operation the target DSs

need protection of intermediate results. These results

imply knowledge of the value used for write

operations like insert and update. More importantly

it can manipulate information wrongly. Other than

the DSs both C and SP also specify their privacies

required from other participants. In more general

case each data source may ask different privacy

requirements against different customers or different

types of customers. SP constructs global privacy

template from all these privacy templates. The

global template and schema are captured and

constructed for all the participants in the system.

However, the system may also create local schema

and template specific to any query or transaction

from the relevant subset of participants which helps

to redefine or override privacy constraint expressed

by each in a given situation. For example, one DS

(say a Bank) may be very cautious against any party

but if the requirement of query is from an

investigation agency it might behave differently.

During execution a query is broken down into a

set of sub-queries which are executed in stages to be

performed in sequence. A sub-query may have to be

further split into a set of query components one for

each DS. However, the query components within a

stage can work in parallel. The decomposition of

queries, query execution plan and results are

determined based on the local schema of the DSs.

Privacy template describes the privacy

constraints imposed by each party w.r.t. other

parties, in other words the privacy relationship that

should hold between any two parties. Enforcing the

privacy constraints will ensure trust in the

information service. Cryptographic protocols will be

brought in for this enforcement. The privacy and

security framework must ensure that SP cannot

interfere with data, query or results belonging to the

organizations except beyond the point where his

accesses are allowed. The sequences of accesses

may not be apparent during query decomposition

and result reconstruction phases. The actual access

patterns may be decided dynamically depending on,

which security protocols are available and designed

based on the privacy templates. Some examples are:

The most important development Homomorphic

encryption allows direct operation on encrypted data

(Gentry 2009; Olumofin and Goldberg 2010;

Shiyuan, Agrawal and Abbadi 2011; Shiyuan,

Agrawal and Abbadi 2012). Private information

retrieval (PIR) helps data anonymization encrypting

database index. Indexes are used to quickly access

records based on key values (Olumofin and

Goldberg 2010; Reardon, Pound and Goldberg

2007). Similarly, Commutative encryption is used to

exchange information between parties A and B via P

who knows the identities of both A and B, unknown

to each other, e.g. A could be a customer, B a data

source and P the SP (Agrawal, Evfimievsk and

Srikant 2003).

3 PRIVACY MODEL

The privacy model in (Pal and Bose 2016) safe

guards the privacy concerns of all participants, C, SP

and the DSs in CIS to prevent disclosure of sensitive

information. CIS has identified seven primary

privacy concerns of the participants, namely Identity

(I), Schema (S), Data Read (DR), Data Write (DW),

Collaborative Information Service - Privacy Algebra for User Deﬁned Security

475

Result (R), Query (Q) and Query Distribution (QD).

They are referred as privacy issues. The work of

Pearson (Pearson, Shen and Mowbray 2009) has

also looked into the user selection of privacy

preferences from a range of choices. The privacy

issues were first introduced in (Pal and Bose 2015).

3.1 Privacy Issues

The privacy issues are meant for different access

levels allowed by any party to any remote entity for

different kind of operations on the former’s data

sources. Note access to one’s data source is possible

only when the identity of that party as well as the

data definition (schema) is disclosed through the

schema definition. We briefly discuss these privacy

issues here.

a. Identity Privacy mainly involves knowledge

required to locate and identify a party to

communicate with it. To prevent on-line identity

discloser anonymous communication should be

employed. Off-line identity disclosure can be

avoided by adopting cryptographic measures

(Pearson, Shen and Mowbray 2009).

b. Schema Privacy refers to the protection of

individual schema of the data sources.

Cryptographic measures to prevent schema

disclosure are not known to exist though it appears

to be a serious privacy need in selective cases.

c. Data Read Privacy refers to the protection of

data contents (attribute values) of a DS for

controlling accesses from other DSs, and C as well

as SP. For solving a query often data need to be

shared with others. Data obfuscation is one possible

cryptographic technique to be applied here. There is

a distinction between schema and data privacy.

Schema privacy automatically implies data privacy,

but the reverse is not true. Even if there is no

requirement of confidentiality yet adequate

precautions have to be taken to prevent data from

being manipulated affecting availability and

integrity.

d. Data Write Privacy refers to an entity

protecting its data from being written over by others.

e. Result Privacy refers to protection of the

results which are provided to C by SP. As such C

can also combine the part results obtained from

different entities. C may not like to reveal the final

query result as well as part results to any third party.

f. Query Privacy (Transaction Privacy) refers to

the protection of the user query from SP and DSs. C

is particularly interested to protect the sensitive parts

of a query. A transaction text may be disclosed to

SP, but the semantics need not be disclosed. Though

the textual content of a query may not disclose the

complete intention of the user, the constants

supplied by the user at runtime are private and must

be protected (Olumofin and Goldberg 2010).

g. Query Distribution (Transaction Distribution)

Privacy refers to the protection of knowledge of

query distribution by SP from DSs and C. Note SP

distributes the query components to a set of DSs

based on their availability and suitability. This

protection works at two levels. At the first level

there are DSs who are not involved in the query

execution and hence need not have any idea about

the ongoing query. At the second level DSs who are

involved would not be informed about others’

participation. This information also may be kept

from the client. However in a good collaboration

many of these restrictions may not exist.

CIS has addressed seven privacy issues required

at the most basic level. For higher granularity of

privacy any issue may have to be split generating

more issues. Data Write privacy issue may be split

into Data Insert, Modify and Delete issues.

Similarly, the Schema privacy issue may be split

into Schema Read and Write issues, or even give

rise to Index privacy issue. Privacy can be defined

for each category or role of users. Another point of

interest could be that the privacy template is

minimized if local schema and even their subsets of

relevant attributes are used in place of the entire

global schema.

3.2 Privacy Types

A privacy type refers to a particular combination of

protections available in a privacy issue. It can be

compared to a tuple in a database table. However,

there is a fundamental difference here. Unlike

databases the protections are not unique or do not

require separate existence. For example, protection

of customer from service provider is applicable to

both identity and query privacy issue. A privacy

issue is represented as a matrix, each column

represents a privacy protection and row represents a

privacy type. A privacy protection refers to the

protection of one party (A) from another party (B)

i.e. A protected from B, or conversely, A open to B

with respect to the underlying privacy issue and

hence it has only two possible values “Yes” (y) or

“No” (n). A privacy protection can be compared to

an attribute of an entity.

3.2.1 Type and Type-Subset

Let P be a privacy type. The set of privacy

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

476

protections in P is denoted by protection (P).

Sometimes privacy types are labeled for easy

reference (e.g. Qd privacy). The set of types in P is

denoted by type(P). P1 is a type-subset of P if

type(P1) ⊆ type(P). Similarly, P2 is a protection-

subset of P if protection(P2) ⊆ protection(P).

3.2.2 Conditioned Privacy Issue

P(c) is obtained by applying certain selection

condition c onto the parent privacy issue P, or P(Q)

by imposing another privacy issue Q upon it. P(c) or

P(Q) could be a type-subset, protection-subset or

both of P. A privacy issue having m privacy

protections can have maximum of 2



privacy types.

Let us look at the privacy issues at greater

details. Consider the issue of identity privacy. It

concerns each and every party and it is the gateway

for accessing a party. In our model we have N+2

parties – N number of DSs, SP and C. So

(N+2)×(N+1) one way communications or access

rights are possible among these parties which result

in a maximum of 2

(N+2)(N+1)

privacy types for identity

privacy. If there are M categories of customers who

have the same identity privacy requirements, then

the total number of privacy options will be

M×2

(N+2)(N+1)

. Our objective is to find out

permissible communications between any two

parties.

3.3 Enumeration of Privacy Types

For determining the privacy types of different

privacy issues there is a common phenomenon:

symmetric vis-à-vis non-symmetric. Privacy

relationship, i.e. privacy constraints between any

two players A and B is of two types, e.g. A protected

from B = ‘Yes’ or ‘No’. Consider p players: B

…,

and A. Total number of privacy types between

players {A and B

}, …, and {A and B

} is 2

, p>2,

i.e. A protected from B

= ‘Yes’ or ‘No’, …, A

protected from B

= ‘Yes’ or ‘No’ etc. Here B

represents the players in the same category, e.g. data

sources, meaning that their privacy concerns may

remain identical. Again the total number of privacy

types between any B

and B

, i, j=1, ... , p is 2

p(p-1)

Combining this with the relationship of A with Bs

the number of privacy types rises to 2

+ 2

p(p-1).

This

describes the most general situation, referred to as

non-symmetric case. In the symmetric case there is

no behavioural difference between any two B

and B

w.r.t. A, i.e. the relationship between A and B

same as that between A and B

. The total number of

distinct types in this case reduces drastically to 2.

For example, when p = 2 number of types for the

non-symmetric case is 2

+ 2

2(2-1)

= 8 but the number

of types for the corresponding symmetric cases is 2

+ 2 = 4. In the template definition for different

privacy issues these will occur. In the remaining

discussion Data Privacy Issue has combined Data

Read and Data Write. The summarized version of all

the privacy issues and types is depicted in Table 1.

Table 1 shows Identity privacy for Customer and

Data Sources (symmetric case). It has three

protections, i) C protected from DS, ii) DS protected

from C, and iii) DS protected from other DSs. This

Table 1: Summarized version of all the privacy issues (excluding Data Write).

Privacy Issue

Protections

a→ b: a protected from b;

a↔ b: a protected from b

and b protected from a;

# Privacy Types (2

)

Symmetric

Case (z1)

Non-symmetric

Case (z2)

Identity Privacy C ↔ DS, DS ↔ DS 3 N(N+1)

Schema Privacy DS → C, DS ↔ DS 2 N

Data Privacy DS → C, DS → SP, DS ↔ DS 3 N(N+1)

Result

Privacy

Intermediate Result DS → C, DS → SP, DS ↔ DS 3 N(N+1)

Final Result C → SP, C → DS 2 N+1

Query

Privacy

Complete

Query

Syntax and

Semantics

SP → DS 1 N

Semantics-sensitive

constants only

C → SP 1 -

Part Query

Syntax and

Semantics

DS → C, DS ↔ DS 2 N

Semantics-sensitive

constants only

DS ↔ DS 1 N(N-1)

Query Distribution

Privacy

(Identities protected)

Open QD SP → C: No, SP → DS: No

0 -

C-Open QD SP → C: No, SP → DS: Yes

DS-Open QD SP → C: Yes, SP → DS: No

Closed QD SP → C: Yes, SP → DS: Yes

Collaborative Information Service - Privacy Algebra for User Deﬁned Security

477

protections, i) C protected from DS, ii) DS protected

from C, and iii) DS protected from other DSs. This

privacy has eight types. All or some of the types

could be labeled for convenience, e.g. the first type

has been called Open or Public – where each party is

accessible to other, the last one Closed or Private –

where none is accessible to other. Since we haven’t

put any condition on the issue, there are all 2

types. If all possible communications are allowed

between any two parties – C and DSs there will be

n(n+1) protections and 2

n(n+1)

privacy types. But note

that Identity privacy issue for C and DS (Symmetric

Case) is both a type-subset and protection-subset of

Identity privacy issue for C and DS (Non-symmetric

Case). The condition ‘symmetry among the DSs’

applied on the latter will reduce it to the former, in

other words, the former is a conditioned issue w.r.t.

the latter. Consider Closed Query Distribution,

where the customer and the data sources are

unknown to each other, the only privacy type

allowed for Identity privacy is (Yes, Yes, Yes) – the

Closed/Private type, whereas the Open Query

Distribution allows only (No, No, No) – the Open /

Public type. Table 2 shows restricted identity

privacy which allows identity sharing as guided by

Query distribution policy.



Table 2: Identity conditioned by Query distribution.

Privacy

Type

Identity Privacy Protection

from

from C

from

other

Corresponding

Qd Type

0 (public) No No No Open Qd

1 No No Yes C-Open Qd

6 Yes Yes No DS-Open Qd

7 (private) Yes Yes Yes Closed Qd

4 PRIVACY ALGEBRA

We denote the privacy issues by capital letter and

privacy protections by small letters in the following

discussions.

Join of Privacy Issues: Let privacy issue X has

p protections and Y has q protections of which r are

common.Then X.Y represents a new privacy issue

obtained by joining X and Y. Join is performed in

the same way as database relations are joined. We

can also define the joint privacy issue X.Y as X U Y

– X ∩ Y. Hence, X.Y will have p + q – r protections.

If X and Y are two independent privacy issues

having no common protections, then X.Y will have

p+q protections. For example, join of Identity

Privacy of C and DS which has 3 protections C →

DS, DS → C and DS → DS (Table 1) and Schema

Privacy of Data Source which has 2 protections DS

→ C and DS → DS (Table 1) results in Identity and

Schema Privacy having 3 protections (Table 3).

Table 3: Join of Identity and Schema Privacy of C and DS.

Identity and Schema Privacy Protection of

C from

any DS

Any DS

from C

Any DS from

any other DS

Privacy

Type

* * * 0 – 7

4.1 Dominance Relations

Dominance of Privacy Protections: Let x and y be

two privacy protections of a privacy issue P. We say

x dominates y over P if, in P if x is protected then y

is also protected, i.e. protection pair (x,y) cannot

assume the value (Yes, No). This is denoted by x > y

over P.

Dominance of Privacy Issues over Protections:

Let p and q be two protections of privacy issue X

and Y respectively. We say p>q if p>q holds in the

privacy issue X.Y. We term this as dominance

between two privacy issues, i.e. X dominates Y,

denoted X > Y over protection p and q. If p and q

refer to the same protection, then we say X

dominates Y over p denoted by X > Y over p. By

applying dominance relations between privacy

issues or privacy protections one essentially

conditions the joint privacy issue or protections, i.e.

obtains conditioned privacy issues

Binary String Representation of Valid Privacy

Types: Let a and b be two privacy protections of a

privacy issue such that a>b. The set of valid privacy

types for (a,b) is {(1,1),(0,1),(0,0)}, i.e. (1,0) is not a

valid. In other words for a = “Yes” only value that is

allowed for b is “Yes”. We can also use binary

strings to represent the privacy types in more

compact form. The valid types are represented by

three binary strings, {11, 01, 00} is equivalent to

{11, 0*} or, {1

, 0*}, * represents either 0 or 1.

Therefore, 0*

represents four strings, namely,

000111, 001111, 010111 and 011111.

Transitivity of Dominance Relations:

Claim 1: The protection dominance is transitive, i.e.

if x > y and y > z then x > z, where x, y and z

protections belong to same or different privacy

issue.

Proof: Let x > y and y over P. The valid privacy

types of both (x, y) and (y, z) are {11, 01, 00}. By

joining these on common values of y we get {11, 01,

00} as the set of valid privacy types of (x, z), i.e. x >

z over P. Note, this logic holds even if x, y and z

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

478

belong to different privacy issues.

Claim 2: The privacy issue dominance is a

transitive relation, i.e. X > Y and Y > Z then X > Z,

where X, Y and Z are privacy issues over a common

privacy protection or over different protections.

Proof: Let p, q and r be three protections of privacy

issues X, Y and Z respectively. X > Y => p > q in

X.Y and Y > Z => q > r in Y.Z. By Claim 1, Y > Z

=> p > r in Y.Z. Again p and r are protections of

X.Z. By definition of privacy issue dominance we

can conclude X > Z.

Valid Privacy Types: Let b



,…,b



k 2, are k

privacy issues w.r.t. to a common privacy protection.

Alternatively, let b

, ..., b

be the k privacy

protections over the domain of one or more privacy

issues (which have been joined). For the joint

protection domain (b

, ..., b

) total number of

possible privacy type is 2

. We can represent these

types by binary strings of length k, i.e. k-bit strings

whose values range from 0 to 2

– 1.

Claim 3: Let b

> ... > b

hold for the joint

protection domain (b

, ..., b

). Then, there are only k

+ 1 valid privacy types {1

, 0

k-1

, ..., o

k-1

, 0

equivalently {2

– 1, 2

k-1

– 1, ..., 2

– 1} out of a total

possible 2

types.

Proof: We prove the claim by induction. If b

> b

the valid types are {11, 01, 00} or, {1

, 01, 0

}. This

proves that the claim holds for k=2. Let the claim

hold for k = i. We will show that it holds for k = i+1.

The case k = i indicates that b

> ... > b

. Assume, b

> b

i+1

. So, in the combined privacy (b

, ..., b

, b

i+1

)

obtained by joining (b

, ..., b

) and (b

, b

i+1

), we have

> .... b

> b

i+1

. For k = i, we get i+1 valid privacy

binary strings. For k = i + 1, only one bit will be

introduced in the right hand side of each string. We

call this bit parity bit. Thus, there are i+1 strings

with parity bit 0 and i+1 strings with parity bit 1.

Since, b

> b

i+1

we can discard the strings having

parity bit 1 except the strings of all 1s. Thus, the

number of valid privacy strings will be i + 1 number

of strings having parity bit 0 plus the string with all

1s. Clearly, the combined privacy has i + 2 privacy

types {2

i+1

– 1, 2

– 1, ..., 2

– 1, 2

– 1}. This

completes the proof.

5 PRIVACY ALGEBRA AND CIS

In this section we demonstrate how privacy algebra

can be used to simplify and consolidate the privacy

issues of CIS. First we notice that successive

applications of join of elementary privacy issues are

not affected by the sequence in which the operands

are selected for the join operation. For example,

A.(B.C) = (A.C).B = C.(A.B) = B.(C.A). We will

detect the interdependencies in the form of

dominance relations between privacy issues over

privacy protections or vice versa. Let us allow all

possible communications between any two parties

out of n+2 parties, C, SP, DS

, ..., DS

, i.e. no

symmetry among DSs are assumed. We consider

five privacy issues: I (identity), S (schema), D

(data), Q (query) and R (result). The query

distribution (Qd) issue is fixed at (No, No), i.e.

Open-Qd issue (Table 2). For each of the five

privacy issues there are (n+2)(n+1) one way

accesses. Therefore, total number of possible

privacy types for all five issues is 2

5(n+2)(n+1)

. With

increasing number of participants or large value of n

it may not be practical to implement so many

privacy types. We therefore look into reduction of

allowable privacy types considering dominance

relations of different privacies (Section 4).

Let us consider the privacy protection between

any two DS across different privacy issues. Note, for

this protection, the following dominance holds: I > S

> D, I > R and I > S > Q because without access to

identity one cannot have access to schema. In other

words, when identity is protected schema cannot

remain unprotected. But when identity is

unprotected schema can be protected or unprotected.

Similarly, without learning the respective schema

learning data would not be possible, but for learning

the result part the knowledge of schema need not be

essential. However, the query part would require the

knowledge of the respective schema. Coming to the

privacy types, for I > S we have 3 valid privacy

types {11, 01, 00}. Similarly, for S > D we also have

3 valid privacy types {11, 01, 00}. By Claim 3,

joining I > S with S > D we have 4 valid privacy

types {111, 011, 001, 000} = {2

– 1, 2

– 1,

– 1} for the dominance I > S > D shown in Table

4. Similarly, for I > S > Q, we also have 4 valid

privacy types {111, 011, 001, 000}. By joining

privacy types of I > S > D with those of I > S >

Q the set of valid privacy types for I, S, Q, and D are

shown in Table 5. Joining I > R having 3 privacy

types {11, 01, 00} with (I>S>D).(I>S>Q) with 11

types (Table 6).

Thus by applying the dominance relations we

have been able to reduce the number of privacy

options between two data sources from 2

= 32 to

11. Similarly, considering the protection of DS from

C, given relations I > S > D and I > R we get 7

privacy types (Table 7). Protection C from a DS

involves only identity privacy, and has two types:

“*”. Protection DS from SP involves data and result

privacies which are independent of each other, hence

Collaborative Information Service - Privacy Algebra for User Deﬁned Security

479

all four types (*,*) are valid.

Table 4: Protection of DS from DS: I > S > D.

I S D Type #types

No No No 000 1

No No Yes 001 1

* Yes Yes *11 2

Table 5: Joint Protection of DS from DS I>S>D & I>S>Q.

I S D Q Type #types

No No * * 00** 4

* Yes Yes Yes *111 2

Table 6: Protection of DS from DS for the join

(I>S>D).(I>S>Q).(I>R).

I S D Q R Type #types

No No * * * 00*** 8

No Yes Yes Yes No 01110 1

* Yes Yes Yes Yes *1111 2

Table 7: Protection of DS from C for I > S > D and I > R.

I S D R Type # of types

No No * * 00** 4

No Yes Yes * 011* 2

Yes Yes Yes Yes 1111 1

5 CONCLUSIONS

Pal and Bose (2013; 2015) proposed IRaaS, a user

defined security model for the information retrieval

services from different data sources for customers

with help of a service provider. CIS (Pal and Bose,

2016) has added write operation beyond read and

also considered the problem as a collaborative model

for any arbitrary joint information exchange

activities. It extends CIS privacy model further by

introducing the concept of privacy algebra which

incorporates privacy constraints of different

partners. It has used the idea of dominance between

the privacy issues and obtained results for concise

expressions of the user privacy requirement, a more

compact privacy template. Further depth in privacy

template can be achieved by restricting accesses to

attributes rather than relations. Optimizing the

privacy template by relaxing or restricting some

constraints is another point of study. Developing

general collaborative applications along the same

line while taking care of user or role concern for the

security of the owner and remote sites and a

language development (high level and low level)

with a compilation process needs to be looked at. As

next generation systems will be highly collaborative

and will have to share information based on a

planned privacy model, interoperability via open

communication and standardized data exchange is

needed (Karnouskos et al. 2012).

REFERENCES

Agrawal, R., Evfimievski, A. and Srikant, R. (2003).

Information sharing across private databases.

Proceedings of the 2003 ACM SIGMOD international

conference on Management of data.

Ahmed, T. and Tripathi, A. (2007). Specification and

verification of security requirements in a programming

model for decentralized CSCW systems. ACM

Transactions on Information and System Security

(TISSEC) 10.2 (2007): 7.

Karnouskos, S., Colombo, A., Bangemann, T., Manninen,

K., Camp, R., Tilly, M., Stluka, P., Jammes, F.,

Delsing, J. and Eliasson, J. (2012). A SOA-based

architecture for empowering future collaborative

cloud-based industrial automation. IECON 2012 - 38th

Annual Conference on IEEE Industrial Electronics

Society.

Olumofin, F. and Goldberg, I. (2010). Privacy-preserving

queries over relational databases. Proceedings of the

10th international conference on Privacy enhancing

technologies. Springer Berlin Heidelberg, 2010.

Pal, A. and Bose, S. (2013). Information Retrieval as a

Service for Multiple Heterogeneous Data-Privacy

Model. Proceedings of the Third International

Conference on Parallel, Distributed, Grid and Cloud

Computing for Engineering, Stirlingshire, Paper 31.

Pearson, S., Shen, Y. and Mowbray, M. (2009). A Privacy

Manager for Cloud Computing. Lecture Notes in

Computer Science, Cloud Computing. Springer, 2009,

pp.90-106.

Zhang, X., Nakae, M., Covington, M. J., & Sandhu, R.

(2006, June). A usage-based authorization framework

for collaborative computing systems. In Proceedings

of the eleventh ACM symposium on Access control

models and technologies (pp. 180-189). ACM.

Reardon, J., Pound, J. and Goldberg, I. (2007). Relational-

complete private information retrieval. University of

Waterloo, Tech. Rep. CACR 34 (2007).

Shiyuan, W., Agrawal, D. and Abbadi, A. (2011).

Towards practical private processing of database

queries over public data with homomorphic

encryption, Technical Report 2011-06, Univ.

California at Santa Barbara, 2011.

Shiyuan, W., Agrawal, D. and Abbadi, A. (2012). Is

homomorphic encryption the holy grail for database

queries on encrypted data. Technical report,

Department of Computer Science, UCSB, 2012.

Gentry, C. (2009) A fully homomorphic encryption

scheme, Diss. Stanford University, 2009.

Pal, A. and Bose, S. (2015). Information Retrieval as a

Service - IRaaS: A Concept Paper on Privacy

ICISSP 2016 - 2nd International Conference on Information Systems Security and Privacy

480

Analysis, WPS 763, Indian Institute Management

Calcutta, June 2015. https://facultylive.iimcal.ac.in/

sites/facultylive.iimcal.ac.in/files/WPS%20763.pdf.

Pal, A. and Dey, S. (2014). A Policy-based Security

Framework for Storage and Computation on

Enterprise Data in the Cloud, Proc. 47th Hawaii

International Conference on System Sciences 2014

(HICSS), 6-9 January 2014, Hawaii. IEEE.

Pal, A. and Bose, S. (2016). Collaborative Information

Service: The Security Question, Proc. 49th Hawaii

International Conference on System Sciences 2016

(HICSS), January 2016, Hawaii. IEEE (to be

appeared).

Atallah, M. (2006). Security issues in collaborative

computing." Lecture Notes in Computer Science 4112

(2006): 2.

Zhu, M., Shen, J., Yan, S., & Zhao, B. (2006). U.S. Patent

No. 7,069,298. Washington, DC: U.S. Patent and

Trademark Office.

Collaborative Information Service - Privacy Algebra for User Deﬁned Security

481
