Recursive Reductions of Internal Dependencies in Multiagent Planning

Jan To

cka, Jan Jakub

uv and Anton

ın Komenda

Agent Technology Center, Department of Computer Science, Czech Technical University in Prague,

Karlovo namesti 13, 121 35, Prague, Czech Republic

Keywords:

Automated Planning, Multiagent Systems, Problem Reduction.

Abstract:

Problems of cooperative multiagent planning in deterministic environments can be efﬁciently solved both by

distributed search or coordination of local plans. In the current coordination approaches, behavior of other

agents is modeled as public external projections of their actions. The agent does not require any additional

information from the other agents, that is the planning process ignores any dependencies of the projected ac-

tions possibly caused by sequences of other agents’ private actions.

In this work, we formally deﬁne several types of internal dependencies of multiagent planning problems and

provide an algorithmic approach how to extract the internally dependent actions during multiagent planning.

We show how to take an advantage of the computed dependencies by means of reducing the multiagent plan-

ning problems. We experimentally show strong reduction of majority of standard multiagent benchmarks and

nearly doubling of solved problems in comparison to a variant of a planner without the reductions. The efﬁ-

ciency of the method is demonstrated by winning in a recent competition of distributed multiagent planners.

1 INTRODUCTION

Cooperative intelligent agents acting in a shared en-

vironment have to coordinate their steps in order to

achieve their goals. A well-established model for

multiagent planning in deterministic environments

was described by (Brafman and Domshlak, 2008)

as MA-STRIPS, which is a minimal extension of

classical planning model STRIPS (Fikes and Nilsson,

1971). MA-STRIPS provides problem partitioning in

form of separated sets of actions of particular agents,

and notion of local private information the agents are

not willing to share. By deﬁnition, private actions and

facts about the environment do not affect other agents

and cannot be affected by other agents. Shared facts

and actions which can inﬂuence more than one agent

are denoted as public.

In multiagent planning modeled as MA-STRIPS,

agents can either plan only with their own actions

and facts and inform the other agents about public

achieved facts, as for instance in the MAD-A* plan-

ner (Nissim and Brafman, 2012). Or, agents can also

use other agents’ public actions provided that the ac-

tions are stripped of the private facts in preconditions

and effects. Thus agents plan actions, in a sense, for

other agents and then coordinate the plans (To

cka

et al., 2014b).

Only a complete stripping of all private informa-

tion from public actions was used in literature so far.

Such approach can, however, lead to tangible loss of

information on causal dependencies of the actions de-

scribed by the private actions. A seeming remedy is

to borrow techniques from classical planning on prob-

lem reduction (e.g., in (Haslum, 2007; Chen and Yao,

2009; Coles and Coles, 2010)). As our motivation is

to “pack” sequences of public and private actions, the

most suitable are recursive macro actions as proposed

by (Jonsson, 2009; B

ackstr

om et al., 2012). A macro

action can represent a sound sequence of actions and,

provided that it allows for recursive reductions, it can

be used repeatedly with possibly radical downsizing

of the reduced planning problem.

In a motivation logistic problem, when an agent

transports a package from one city to another and

wants to keep its current load internal, it is not prac-

tical to publish two actions: load(package, fromC-

ity) and unload(package, toCity). Instead it should

publish action transport(package, fromCity, toCity),

which is capturing the hidden (private) relation be-

tween this pair of actions while it is not disclosing it

in an explicit way.

We propose to keep the pair of actions and to add

new public predicate that says that some action re-

quires another action to precede it (because it better

ﬁts the proposed coordination algorithm). In the sim-

Toži

cka, J., Jakub˚uv, J. and Komenda, A.

Recursive Reductions of Internal Dependencies in Multiagent Planning.

DOI: 10.5220/0005754901810191

In Proceedings of the 8th International Conference on Agents and Artiﬁcial Intelligence (ICAART 2016) - Volume 2, pages 181-191

ISBN: 978-989-758-172-4

181

plest case, the new public fact would directly corre-

spond to the internal fact isLoaded(package), but in

realistic cases, it could also capture more complex de-

pendencies, for example, the transshipment between

different vehicles belonging to the transport agent.

In this paper, we build on our previous

work (To

cka et al., 2015a) where internal depen-

dencies of public actions where studied with a restric-

tion that every action consumes all of its precondi-

tions. This restriction no longer applies here because

it can be very limiting in practice. Furthermore, we

demonstrate the effect of our approach on a bench-

mark set from the CoDMAP competition held on In-

ternational Conference on Automated Planning and

Scheduling (ICAPS’15). Our planner, employing the

theory from this paper, won the distributed track of

CoDMAP 2015.

2 MULTIAGENT PLANNING

This section provides condensed formal prerequisites

of multiagent planning based on the MA-STRIPS for-

malism (Brafman and Domshlak, 2008). Refer to

(To

cka et al., 2014a) for more details.

An MA-STRIPS planning problem Π is a quadru-

ple Π = hP,{α

}

i=1

,I, Gi, where P is a set of

facts, α

is the set of actions of i-th agent

I ⊆

P is an initial state, and G ⊆ P is a set of

goal facts. We deﬁne selector functions facts(Π),

agents(Π), init(Π), and goal(Π) such that Π =

hfacts(Π),agents(Π),init(Π),goal(Π)i. An action

a ∈ α, the agent α can perform, is a triple of subsets

of P called preconditions, add effects, delete effects.

Selector functions pre(a), add(a), and del(a) are de-

ﬁned so that a = hpre(a),add(a),del(a)i. Note that

an agent is identiﬁed with the actions the agent can

perform in an environment.

In MA-STRIPS, out of computational or privacy

concerns, each fact is classiﬁed either as public or as

internal. A fact is public when it is mentioned by

actions of at least two different agents. A fact is in-

ternal for agent α when it is not public but mentioned

by some action of α. A fact is relevant for α when it

is either public or internal for α. MA-STRIPS further

extends this classiﬁcation of facts to actions as fol-

lows. An action is public when it has a public (add-

or delete-) effect, otherwise it is internal. An action

from Π is relevant for α when it is either public or

owned by (contained in) α.

Whereas, in STRIPS, the second parameter is a set of

actions, in MA-STRIPS, the second parameter is actually a

set of sets of actions.

We use int-facts(α) and pub-facts(α) to denote in

turn the sets internal facts and the set of public facts

of agent α. Moreover, we write pub-facts(Π) to de-

note all the public facts of problem Π. We write

pub-actions(α) to denote the set of public actions of

agent α. Finally, we use pub-actions(Π) to denote all

the public actions of all the agents in problem Π.

In multiagent planning with external actions, a lo-

cal planning problem is constructed for every agent

α. Each local planning problem for α is a classical

STRIPS problem where α has its own internal copy

of the global state and where each agent is equipped

with information about public actions of other agents

called external actions. These local planning prob-

lems allow us to divide an MA-STRIPS problem into

several STRIPS problems which can be solved sepa-

rately by a classical planner.

The projection F .α of a set of facts F to agent

α is the restriction of F to the facts relevant for α,

representing F as seen by α. The public projection

a.? of action a is obtained by restricting the facts in

a to public facts. Public projection is extended to sets

of actions element-wise.

A local planning problem Π.α of agent α, also

called projection of Π to α, is a classical STRIPS

problem containing all the actions of agent α together

with external actions, that is, public projections of

other agents’ public actions. The local problem of α is

deﬁned only using the facts relevant for α. Formally,

Π.α = hP .α,α ∪ exts(α),I . α, Gi

where the set of external actions exts(α) is deﬁned as

follows.

exts(α) =

[

β6=α

(pub-actions(β).?)

In the above, β ranges over all the agents of Π. The set

exts(α) can be equivalently described as exts(α) =

(pub-actions(Π) \α) . ?. To simplify the presenta-

tion, we consider only problems with public goals and

hence there is no need to restrict goal G.

3 PLANNING WITH EXTERNAL

ACTIONS

The previous section allows us to divide an MA-

STRIPS problem into several classical STRIPS local

planning which can be solved separately by a classi-

cal planner. Recall that the local planning problem

of agent α contains all the actions of α together with

α’s external actions, that is, with projections of public

actions of other agents. This section describes con-

ditions which allow us to compute a solution of the

ICAART 2016 - 8th International Conference on Agents and Artiﬁcial Intelligence

182

Algorithm 1:Distributed MA planning algorithm.

1 Function MaPlanDistributed(Π . α) is

2 Φ

←

3 loop

4 generate new π

∈ sols(Π.α);

5 Φ

← Φ

∪ {π

.?};

6 exchange public plans Φ

with other

agents;

7 Φ ←

β∈agents(Π)

;

8 if Φ 6=

0 then

9 return Φ;

10 end

11 end

12 end

original MA-STRIPS problem from solutions of local

problems.

A plan π is a sequence of actions. A solution of Π

is a plan π whose execution transforms the initial state

to a subset of the goals. A local solution of agent α is

a solution of Π.α. Let sols(Π) denote the set of all

the solutions of MA-STRIPS or STRIPS problem Π.

A public plan σ is a sequence of public actions. The

public projection π.? of plan π is the restriction of π

to public actions.

A public plan σ is extensible when there is π ∈

sols(Π) such that π . ? = σ. Similarly, σ is α-

extensible when there is π ∈ sols(Π.α) such that

π.? = σ. Extensible public plans give us an order of

public actions which is acceptable for all the agents.

Thus extensible public plans are very close to solu-

tions of Π and it is relatively easy to construct a so-

lution of Π once we have an extensible public plan.

Hence our algorithms will aim at ﬁnding extensible

public plans.

The following theorem (To

cka et al., 2014a) es-

tablishes the relationship between extensible and α-

extensible plans. Its direct consequence is that to ﬁnd

a solution of Π it is enough to ﬁnd a local solution

∈ sols(Π.α) which is β-extensible for every agent

β.

Theorem 1. Public plan σ of Π is extensible if and

only if σ is α-extensible for every agent α.

The theorem above suggests the distributed mul-

tiagent planning algorithm described in Algorithm 1.

Every agent executes the loop from Algorithm 1, pos-

sibly on different machine. Every agent keeps gener-

ating new solutions of its local problem and stores so-

lution projections in set Φ

. These sets are exchanged

among all the agents so that every agent can com-

pute their intersection Φ. Once the intersection Φ is

non-empty, the algorithm terminates yielding Φ as the

result. Theorem 1 ensures that every public plan in

the resulting Φ is extensible. Consult (To

cka et al.,

2014a) for more details on the algorithm.

4 INTERNAL DEPENDENCIES

OF ACTIONS

One of the beneﬁts of planning with external ac-

tions is that every agent can plan separately its local

problem which involves planning of actions for other

agents (external actions). Other agents can then only

verify whether a plan generated by another agent is

α-extensible for them. A con of this approach is that

agents have only a limited knowledge about external

actions because internal facts are removed by projec-

tion. Thus it can happen that an agent plans exter-

nal actions inappropriately in a way that the resulting

public plan is not α-extensible for some agent α.

In the rest of this paper we try to overcome the

limitation of partial information about external ac-

tions. The idea is to equip agents with additional in-

formation about external actions without revealing in-

ternal facts. The rest of this section describes depen-

dency graphs which are used in the following sections

as a formal ground for our analysis of public and ex-

ternal actions.

4.1 Dependency Graphs

Local planning problem Π . α of agent α contains in-

formation about external actions provided by the set

exts(α). The idea is to equip agent α with more in-

formation described by a suitable structure. A depen-

dency graphs is a structure we use to encapsulate in-

formation about public actions which an agent shares

with other agents.

Dependency graphs are known from litera-

ture (Jonsson and B

ackstr

om, 1998; Chrpa, 2010). In

our context, a dependency graph ∆ is a bipartite di-

rected graph deﬁned as follows.

Deﬁnition 1. A dependency graph ∆ is a bipartite di-

rected graph whose nodes are actions and facts. We

write actions(∆) and facts(∆) to denote action and

fact nodes respectively. Given the nodes, graph ∆

contains the following three kinds of edges.

(a → f ) ∈ ∆ iff f ∈ add(a) (a produces f )

( f → a) ∈ ∆ iff f ∈ pre(a) \ del(a) (a requires f )

( f 99K a) ∈ ∆ iff f ∈ pre(a) ∩ del(a) (a consumes f )

Additionally, a fact can be marked as initial in ∆. The

set of states marked as initial is denoted init(∆).

Hence edges of a dependency graph ∆ are

uniquely determined by the set of nodes. Note that

Recursive Reductions of Internal Dependencies in Multiagent Planning

183

action nodes are themselves actions, that is, triples of

fact sets. These action nodes can contain additional

facts other than fact nodes facts(∆). We use depen-

dency graphs to represent internal dependencies of

public actions. Dependencies determined by public

facts are known to other agents and thus we do not

need them in the graph as fact nodes. From now on

we suppose that facts(∆) contains no public facts as

fact nodes. Action nodes, however, can contain public

facts in their public actions.

Deﬁnition 2. Let an MA-STRIPS problem Π be

given. The minimal dependency graph MD(α)

of agent α ∈ agents(Π) is the dependency graph

uniquely determined by the following set of nodes.

actions(MD(α)) = pub-actions(α)

facts(MD(α)) =

init(MD(α)) =

Hence MD(α) has no edges as there are no fact

nodes. Thus the graph contains only separated public

action nodes. Furthermore, the set exts(α) of exter-

nal actions of agent α can be trivially expressed as

follows.

exts(α) =

[

β6=α

(actions(MD(β)).?)

Thus we see that dependency graphs can carry the

same information as provided by exts(α).

Deﬁnition 3. The full dependency graph FD(α) of

agent α contains all the actions of α and all the in-

ternal facts of α.

actions(FD(α)) = α

facts(FD(α)) = int-facts(α)

init(FD(α)) = init(Π) ∩ int-facts(α)

Hence FD(α) contains all the information known

by α. By publishing FD(α), an agent reveals all his

internal dependencies which might be a potential pri-

vacy risk. On the other hand, other agents are by

FD(α) provided the most precise information about

dependencies of public actions of α. Every plan of

another agent, computed with FD(α) in mind, is auto-

matically α-extensible. Thus we see that dependency

graphs can carry dependencies information with a var-

ied precision.

4.2 Dependency Graph Collections

A dependency graph represents information about

public actions of one agent. Every agent needs to

know information from all the other agents. We use

dependency graph collections to represent all the re-

quired information. A dependency graph collection

D of an MA-STRIPS problem Π is a set of depen-

dency graphs which contains exactly one dependency

graph for every agent of Π. We write D(α) to denote

the graph of α. We write actions(D ), facts(D), and

init(D ) to denote in turn all the action, fact, and initial

fact nodes from all the graphs in D.

Deﬁnition 4. Given problem Π, we can deﬁne the

minimal collection MD(Π) and the full collection

FD(Π) as follows.

MD(Π) = {MD(α) : α ∈ agents(Π)}

FD(Π) = {FD(α) : α ∈ agents(Π)}

Later we shall show some interesting properties of

the minimal and full collections.

4.3 Local Problems and Dependency

Collections

In order to deﬁne local problems informed by D, we

need to deﬁne facts and action projections which pre-

serve information from D . We use symbol .

to de-

note projections accordingly to D. Recall that the

public projection a.? of action a is the restriction of

the facts of a to pub-facts(Π). The public projection

? of action a accordingly to D is the restriction

of the facts of a to pub-facts(Π) ∪ facts(D). Pub-

lic projection is extended to sets of actions element-

wise. Furthermore, external actions of α according

to D, denoted exts

(α), contain public projections

(according to D) of actions of other agents. In other

words, exts

(α) carries all the information published

by other agents for agent α. It is computed as follows.

exts

(α) =

[

β6=α

(actions(D(β)).

This equation captures distributed computation

of exts

(α) where every agent β separately com-

putes published actions, applies public projection, and

sends the result to α.

In order to deﬁne a local planning problem of

agent α which would take information from D into

consideration, we need to extract from D facts and

initial facts of other agents. Below we deﬁne sets

facts

(α) and init

(α) which contain those facts and

initial facts published by other agents, that is, all the

facts from D except of the facts of α.

facts

(α) = facts(D) \ facts(D(α))

init

(α) = init(D )\ init(D (α))

Now we are ready to deﬁne local planning problems

according to D which extends local planning prob-

lems by the information contained in D.

ICAART 2016 - 8th International Conference on Agents and Artiﬁcial Intelligence

184

Deﬁnition 5. Let Π be MA-STRIPS problem. The

local problem Π.

α of agent α ∈ agents(Π) accord-

ingly to D is the classical STRIPS problem Π .

α =

i where

(1) P

= facts (Π .α)∪ facts

(α),

(2) A

= α ∪ exts

(α),

(3) I

= init(Π . α) ∪ init

(α), and

(4) G

= goal(Π).

We can see that a local problem Π.

α according

to D extends the local problem Π.α by the facts and

actions published by D.

Let us consider two boundary cases of depen-

dency collections MD(Π) and FD(Π). Given an MA-

STRIPS problem Π, we can construct local problems

using the minimal dependency collection MD(Π). It is

easy to see that Π.

MD(Π)

α = Π . α for every agent α.

With the full dependency collection FD(Π) we obtain

equal projections, that is, Π .

FD(Π)

α = Π .

FD(Π)

β for

all agents α and β. Moreover, local solutions equal

MA-STRIPS solutions, that is, sols(Π .

FD(Π)

α) =

sols(Π) for every α.

4.4 Publicly Equivalent Problems

We have seen that dependency collections can pro-

vide information about internal dependencies with a

varied precision. Given two different collections, two

different local problems can be constructed for every

agent. However, when the two local problems of the

same agent equal on public solutions, we can say that

they are equivalent because their public solutions are

equally extensible.

In order to deﬁne equivalent collections, we ﬁrst

deﬁne public equivalence on problems. Two planning

problems Π

and Π

are publicly equivalent, denoted

'Π

, when they have equal public solutions. For-

mally as follows.

'Π

⇔ sols(Π

).? = sols(Π

).?

Public equivalence can be extended to dependency

graph collections as follows. Two collections D

and

of the same MA-STRIPS problem Π are equiva-

lent, written D

, when for any agent α, it holds

that the local problems Π.

α and Π.

α are pub-

licly equivalent. Formally as follows.

⇔ (Π.

α)'(Π.

α) (for all α)

Example 1. Given an MA-STRIPS problem Π, with

the full dependency collection FD(Π) we can see that

Π'Π.

FD(Π)

α holds for any agent. Hence to ﬁnd

a public solution of Π it is enough to solve the lo-

cal problem (accordingly to FD(Π)) of an arbitrary

agent. The same holds for any dependency collection

D such that D 'FD(Π). Note that D can be much

smaller and provide less private information than the

full dependency collection.

The above deﬁnitions allow us to recognize prob-

lems without any internal dependencies which we can

deﬁne as follow.

Deﬁnition 6. An MA-STRIPS problem Π is internally

independent when MD(Π)'FD(Π).

In order to solve an internally independent prob-

lem, it is enough to solve the local problem Π .α of

an arbitrary agent. Any local public solution is exten-

sible which makes internally independent problems

easier to solve because there is no need for interac-

tion and negotiation among the agents. Later we shall

show how to algorithmically recognize internally in-

dependent problems. The following formally captures

the above properties.

Lemma 2. Let Π be an internally independent MA-

STRIPS problem. Then (Π . α) ' Π.

Proof. (Π.α)'(Π.

MD(Π)

α)'(Π.

FD(Π)

α)'Π

5 SIMPLE ACTION

DEPENDENCIES

Let us consider dependency collections without inter-

nal actions, that is, collections D where actions(D )

contains no internal actions. When D is published,

then no agent publishes actions additional to exts(α)

which is desirable out of privacy concerns. Further-

more, the plan search space of Π.

α is not increased

when compared to Π . α. Even more, every addition-

ally published fact in D providing a valid dependency

prunes the search space. Action dependencies cap-

tured by collections without internal actions can be

expressed by requirements on the order of actions in a

plan. This further abstracts the published information

providing privacy protection. Thus it seems reason-

able to publish dependency collections without inter-

nal actions.

5.1 Simply Dependent Problems

The following deﬁnes simply dependent MA-STRIPS

problems, where internal dependencies of public ac-

tions can be expressed by a dependency collection

free of internal actions.

Deﬁnition 7. An MA-STRIPS problem Π is simply

dependent when there exists D such that actions(D )

contains no internal actions and D 'FD(Π).

Recursive Reductions of Internal Dependencies in Multiagent Planning

185

Suppose we have a simply dependent MA-

STRIPS problem and a dependency collection D

which proves the fact. In order to solve Π, once again,

it is enough to solve only one local problem Π.

(of an arbitrary agent α).

Lemma 3. Let Π be a simply dependent MA-

STRIPS problem. Let D be a dependency collec-

tion which proves that Π is simply dependent. Then

(Π.

α)'Π holds for any agent α ∈ agents(Π).

Proof. (Π.

α)'(Π.

FD(Π)

α)'Π

The above method requires all the agents to pub-

lish the information from D . However, the informa-

tion does not need to be published to all the agents as

it is enough to select one trusted agent and send the

information only to him. Hence it is enough for all

the agents to agree on a single trusted agent.

5.2 Dependency Graph Reductions

Recognizing simply dependent MA-STRIPS prob-

lems might be difﬁcult in general. That is why we

deﬁne an approximative method which can provably

recognize some simply dependent problems. We

deﬁne a set of reduction operations on dependency

graphs and we prove that the operations preserve rela-

tion '. Then we apply the reductions repeatedly start-

ing with FD(∆) obtaining a dependency graph which

can not be reduced any further. This is done by every

agent. When the resulting graphs contain no internal

actions, then we know that the problem is simply de-

pendent. Additionally, when the resulting graphs con-

tain no internal facts, then we know that the problem

is independent.

Our previous work (To

cka et al., 2015a) was re-

stricted to problems where pre(a) = del(a) holds for

every action a. This impractical limitation is removed

here. We still restrict our attention to problems where

del(a) ⊆ pre(a) holds for every action a. This is not

considered limiting because a problem not meeting

this requirement can be easily transformed to a per-

missible equivalent problem.

Finally, to abstract from the set of initial facts of

a dependency graph ∆, we introduce to the graph a

special initial action h

0,init(∆),

0i. We suppose that

every dependency graph has exactly one initial action

and hence we do not need to remember the set of ini-

tial facts. The initial action is handled as public even

when it has no public effect. Both deﬁnitions of de-

pendency graphs are trivially equivalent but the one

with an initial action simpliﬁes the presentation of re-

duction operations.

We proceed by informal descriptions of depen-

dency graph reductions. The formal deﬁnition is

given below. The operations are depicted in Figure 1.

(R1) Remove Simple Action Dependency. If some

internal action has only one delete effect and one

add effect and there is no other action depending

on f

we can merge both facts into one and re-

move that action.

(R2) Remove Simple Fact Dependency. If some

fact is the only effect of some action and there is

only one action that consumes this effect without

any side effects, we can remove this fact and

merge both actions.

(R3) Remove Small Action Cycle. In many do-

mains, there are reversible internal actions that

allow transitions between two (or more) states.

All these states can be merged into a single state

and the actions changing them can be omitted.

(R4) Merge Equivalent Nodes. If two nodes (facts

or actions) equal on incoming and outgoing edges,

then we can merge these two nodes. Mostly this is

not directly in the domain but this structure might

appear when we simplify a dependency graph us-

ing the other reductions.

(R5) Remove Invariants. After several reduction

steps, it can happen that all the delete effects on

some fact are removed and the fact is always ful-

ﬁlled from the initial state. This happens, for

example, in Logistics, where the location of a

vehicle is internal knowledge and can be freely

changed as described by reduction (R3). Once

these cycles are removed, only one fact remains.

The remaining fact represents that the vehicle is

somewhere, which is always true. This fact can be

freely removed from the dependency graph.

In order to formally deﬁne the above reductions

we ﬁrst deﬁne operator [F]

→ f

which renames fact

to f

in the set of facts F ⊆ P.

[F]

→ f

(

F if f

6∈ F

(F \ { f

}) ∪ { f

} otherwise

Similarly, we deﬁne operator [F]

- f

= F \ { f } which

removes fact f from the set of facts F. These oper-

ators are extended to actions (applying the operator

to preconditions, add, and delete effects) and to ac-

tion sets (element-wise). The operators can be fur-

ther extended to dependency graphs, where [∆]

- f

the dependency graph determined by [actions(∆)]

- f

and [facts(∆)]

- f

. Finally, for two actions a

and a

we deﬁne the merged action a

⊕a

as the action ob-

tained by unifying separately preconditions, add, and

delete effects of both the actions.

ICAART 2016 - 8th International Conference on Agents and Artiﬁcial Intelligence

186

   

(R1) (R2) (R3) (R4)

Figure 1: Graphical illustration of reduction operations (R1)–(R4). Circles represent fact nodes and rectangles represent

action nodes. Rounded boxes in (R4) represent any node (either fact or action node).

The following formally deﬁnes reduction relation

∆

→ ∆

which holds when ∆

can be transformed to

∆

using one of the reduction operations.

Deﬁnition 8. The reduction relation ∆

→ ∆

dependency graphs is deﬁned by the following four

rules.

(R1) Rule (R1) is applicable to ∆

when

(1) ∆

contains edges ( f

99K a → f

(2) a is internal, and

(3) there are no other edges from/to a, and

(4) there are no other edges from f

Then ∆

→ ∆

where ∆

is deﬁned as ∆

[∆

]

→ f

. The initial action is preserved.

(R2) Rule (R2) is applicable to ∆

when

(1) ∆

contains edges (a

→ f 99K a

(2) there are no other edges from/to f , and

(3) there are no other edges from a

, and

(4) a

has no other delete effects, and

(5) a

is internal action.

Then ∆

→ ∆

where ∆

is given by the following.

actions(∆

) = {[a

⊕a

]

- f

} ∪ (actions(∆

) \ {a

})

facts (∆

) = [facts(∆

)]

- f

If a

is the initial action of ∆

then the new merged

action becomes the initial action of ∆

. Other-

wise, the initial action is preserved.

(R3) Rule (R3) is applicable to ∆

when

(1) ∆

contains edges ( f

99K a

→ f

), and

(2) ∆

contains edges ( f

99K a

→ f

), and

(3) a

and a

are both internal, and

(4) there are no other edges from/to a

or a

Then ∆

→ ∆

where ∆

is given by the following.

actions(∆

) = [actions(∆

) \ {a

}]

→ f

facts (∆

) = [facts(∆

)]

→ f

The initial action is preserved as it is public.

(R4) Rule (R4) is applicable to ∆

when ∆

contains

two nodes n

and n

(either action or fact nodes)

such that

(1) nodes n

and n

have equal sets of incoming

and outgoing edges, and

(2) n

and n

are not public actions.

Then ∆

→ ∆

where, in the case n

and n

are

actions, ∆

is given by the following.

actions(∆

) = {n

⊕n

} ∪ (actions(∆

) \ {n

})

facts (∆

) = facts(∆

)

When n

or n

is the initial action of ∆

then the

new merged action becomes the initial action of

∆

. Otherwise, the initial action is preserved.

In the case n

and n

are facts, ∆

= [∆

]

→n

(R5) Let a

init

be the initial action of ∆

. Rule (R5) is

applicable to ∆

when there exists fact f such that

(1) ∆

contains edge (a

init

→ f ), and

(2) ∆

contains no edge ( f 99K a) for any a.

Then ∆

→ ∆

where ∆

is deﬁned as ∆

= [∆

]

- f

The initial action of ∆

is [a

init

]

- f

The following deﬁnes reduction equivalence re-

lation ∆

∼∆

as a reﬂexive, symmetric, and transi-

tive closure of →. In other words, ∆

and ∆

are re-

duction equivalent when one can be transformed to

another using the reduction operations. Dependency

collections D

and D

are reduction equivalent when

graphs of corresponding agents are reduction equiva-

lent.

Deﬁnition 9. Dependency graphs reduction equiva-

lence relation, denoted ∆

∼∆

, is the least reﬂexive,

symmetric, and transitive closure generated by the re-

lation →.

Given MA-STRIPS problem Π, dependency col-

lections D

and D

of Π are reduction equivalent,

written D

∼D

, when D

(α)∼D

(α) for any agent

α ∈ agents(Π).

The following theorem formally states that reduc-

tion operations preserves public equivalence.

Theorem 4. Let Π be an MA-STRIPS problem and

let pre(a) ⊆ del(a) hold for any internal action. Let

and D

be dependency collections of problem Π.

Then D

∼D

implies D

Proof sketch. It can be shown that none of the re-

duction operations changes the set of public plans

sols(D

(α)).? of any agent α ∈ agents(Π). There-

fore repetitive application of reductions assures that

Recursive Reductions of Internal Dependencies in Multiagent Planning

187

Algorithm 2: Compute the dependency graph to

be published by agent α.

1 Function ComputeSharedDG(α) is

2 ∆

← FD(α);

3 loop

4 if ∃∆

: ∆

→ ∆

then

5 ∆

← ∆

;

6 else

7 break;

8 end

9 end

10 if ∆

contains only public actions then

11 return ∆

;

12 else

13 return MD(α);

14 end

15 end

To avoid possible action confusion caused by

value renaming, we suppose that actions are assigned

unique ids which are preserved by the reduction, and

that plans are sequences of these ids.

The consequences of the theorem are discussed in

the following section.

5.3 Recognizing Simply Dependent

Problems

Let us have an MA-STRIPS problem Π where

pre(a) ⊆ del(a) holds for every internal action a. Sup-

pose that every agent α can reduce its full dependency

collection FD(α) to a state where it contains no inter-

nal action. Then there is D such that D ∼FD(Π) and

hence D 'FD(Π) by Theorem 4. Hence Π is sim-

ply dependent and its public solution can be found

without agent interaction, provided all the agents al-

low to publish D . Important idea here is that publicly

equivalent dependency graphs do not need to reveal

the same amount of sensitive information. Moreover

when D ∼MD(α) then Π is independent and can be

solved without any interaction and without revealing

other than public information. This gives us an algo-

rithmic approach to recognize some independent and

simply dependent problems.

6 PLANNING WITH

DEPENDENCY GRAPHS

This section describes how agents use dependency

graphs in order to solve MA-STRIPS problem Π (Al-

gorithm 3). At ﬁrst, every agent computes the de-

Algorithm 3: Distributed planning with depen-

dency graphs.

1 Function DgPlanDistributed(α) is

2 ∆ ← ComputeSharedDG(α);

3 send ∆ to other agents;

4 construct D from other agent’s graphs;

5 compute local problem Π.

α;

6 return MaPlanDistributed(Π.

α);

7 end

pendency graph it is willing to share using function

ComputeSharedDG described by Algorithm 2. Ev-

ery agent α starts with the full dependency graph

FD(α) and tries to apply reduction operations repeat-

edly as long as it is possible. When the resulting re-

duced dependency graph ∆

contains only public ac-

tions, then the agent publishes ∆

. Otherwise, the

agent publishes only the minimal dependency graph

MD(α). Algorithm 2 clearly terminates for every in-

put because every reduction decreases the number of

nodes in the dependency graph. Hence the algorithm

loop (lines 3–9 in Algorithm 2) can not be iterated

more than n times when n is the count of nodes in

FD(α). Moreover, every reduction operation can be

performed in a time polynomial to the size of the

problem, and thus the whole algorithm is polynomial-

time.

Once the shared dependency graph ∆ is computed,

Algorithm 3 continues by sending ∆ to other agents.

Then shared dependency graphs of other agents are

received. This allows every agent to complete the

dependency collection D , and to construct the local

problem Π.

α. The rest of the planning procedure

is the same as in the case of Algorithm 1.

The algorithm can be further simpliﬁed when all

the agents succeeds in reducing FD(α) to an equiva-

lent dependency graph without internal actions, that

is, when Π is provably simply dependent. Then it is

enough to select one agent to compute public solu-

tion of Π. When at least one agent α fails to share

dependency collection equivalent to the full depen-

dency collection FD(α) then iterated negotiation is re-

quired. When some agent α (but not all the agents)

succeeds in reducing FD(α) then every plan created

by any other agent will be automatically α-extensible.

7 EXPERIMENTS

For experimental evaluation we use benchmark prob-

lems from the CoDMAP’15 competition

. The

See http://agents.fel.cvut.cz/codmap

ICAART 2016 - 8th International Conference on Agents and Artiﬁcial Intelligence

188

Table 1: Results of the analysis of internal dependencies of public actions in benchmark domains.

Domain Facts Public facts Merge facts Fact disclosure Actions Public actions Success

Blocksworld 787 733 53 100 % 1368 1368 100 %

Depots 1203 1139 56 85 % 2007 2007 100 %

Driverlog 1532 1419 16 25 % 7682 7426 100 %

Elevators 509 343 43 29 % 2060 1767 70 %

Logitics 240 154 56 63 % 342 298 100 %

Rovers 2113 1251 31 3 % 3662 1555 13 %

Satellite 846 578 0 0 % 8839 914 1 %

Taxi 177 173 0 0 % 107 107 100 %

Woodworing 1448 1425 7 27 % 4126 4126 100 %

Zenotravel 1349 1204 0 0 % 13516 2364 0 %

benchmark set contains 12 domains with 20 problems

per domain. Each agent has its own domain and prob-

lem ﬁles containing description of known facts and

actions. Additionally, some facts/predicates are spec-

iﬁed as private and thus should not be communicated

to other agents. The privacy classiﬁcation roughly

corresponds to MA-STRIPS.

We ﬁrstly present analysis of internal dependen-

cies and their reductions in Section 7.1. In Sec-

tion 7.2, we present results independently evaluated

by organizers of the CoDMAP’15 competition.

7.1 Domain Analysis

In this section we present analysis of internal depen-

dencies of public action in the benchmark problems.

We have evaluated internal dependencies of pub-

lic actions within benchmark problems by construct-

ing full dependency graph for every agent in every

benchmark problem. We have applied Algorithm 2 to

reduce full dependency graphs to an irreducible pub-

licly equivalent dependency graph. The results of the

analysis are presented in Table 1. The table columns

have the following meaning. Column (Facts) repre-

sents an average number of all facts in a domain prob-

lem. Column (Public facts) represents an average

number of public facts in a domain problem. Column

(Merge facts represents an average size of facts(∆)

in the resulting irreducible dependency graph. Col-

umn (Fact disclosure) represents the percentage of

published merge facts with respect to all the internal

facts. Column (Actions) represents an average num-

ber of all actions in a domain problem. Column (Pub-

lic actions) represents an average number of public

actions in a domain problem. Column (Success) rep-

resents the percentage of agents capable of reducing

their full dependency graph to to a publicly equivalent

graph without internal actions.

We can see that ﬁve of the benchmark domains,

namely Blocksworld, Depots, Driverlog, Logistics,

Taxi, Wireless, and Woodworking were found simply

dependent. All the problems in these domains can be

Figure 2: Comparison of planning times (in seconds) of

PSM-VR algorithm without (X axis) and with (Y axis) in-

ternal problem reduction.

solved by solving a local problem of a single agent.

On the contrary, in most problems of domains Rovers,

Satellite, and Zenotravel, none of the agents were able

to reduce its full dependency graph so that it con-

tains no internal actions. Hence the agents in these

domain publish only the minimal dependency graphs

and hence the analysis does not help in solving them.

Finally, in Elevators domain, some of the agents suc-

ceeded in reducing their full dependency graphs and

thus the analysis can partially help to solve them.

7.2 Experimental Results

To evaluate the impact of dependency analysis, we

use our PSM-based planners (To

cka et al., 2014b)

submitted to the CoDMAP’15 competition. Namely,

we use planner PSM-VR (To

cka et al., 2015b) and

its extension with dependency analysis PSM-VRD.

Figure 2 evaluates the impact of the dependency

analysis on CoDMAP benchmark problems. For each

Recursive Reductions of Internal Dependencies in Multiagent Planning

189

Table 2: Results at CoDMAP competition (http://agents.fel.cvut.cz/codmap/results/). Top table shows overall

coverage of solved problem instances. Middle table shows IPC score over the plan quality Q (a sum of Q

∗

/Q over all

problems, where Q

∗

is the cost of an optimal plan, or of the best plan found by any of the planners for the given problem

during the competition). Bottom table shows IPC Agile score over the planning time T (a sum of 1/(1 + log

(T /T

∗

)) over

all problems, where T

∗

is the runtime of the fastest planner for the given problem during the competition).

‡

This is optimal

planner.

†

This post-submission domain was not supported by the planner parser. These results are presented with the consent

of CoDMAP organizers.

Domain #

MAPlan

LM-Cut

‡

MAPlan

MA-LM-Cut

‡

MH-FMAP

MAPlan

FF+DTG

PSM-VR PSM-VRD

Blocksworld 20 2 1 0 14 12 20

Depots 20 5 2 2 10 1 16

Driverlog 20 15 9 18 18 16 20

Elevators 20 2 0 9 9 2 5

Logitics 20 4 5 4 16 0 16

Openstacks 20 1 1 8 18 14 18

Rovers 20 2 4 18 19 13 13

Satellite 20 13 4 4 14 7 17

Taxi 20 19 14 20 19 9 20

Wireless 20 3 2 0 4 0

†

Woodworing 20 3 4 8 14 9 19

Zenotravel 20 6 6 16 19 16 16

Total Coverage 240 75 52 107 174 99 180

Domain #

MAPlan

LM-Cut

‡

MAPlan

MA-LM-Cut

‡

MH-FMAP

MAPlan

FF+DTG

PSM-VR PSM-VRD

Blocksworld 20 2 1 0 7 11 17

Depots 20 5 2 2 6 1 15

Driverlog 20 15 9 17 12 14 16

Elevators 20 2 0 8 6 1 4

Logitics 20 4 5 4 13 0 15

Openstacks 20 1 1 8 18 9 12

Rovers 20 2 4 18 16 5 5

Satellite 20 13 4 4 10 6 13

Taxi 20 19 14 17 15 6 16

Wireless 20 3 2 0 4 0

†

Woodworing 20 3 4 7 13 8 17

Zenotravel 20 6 6 15 15 10 10

IPC Score 240 75 52 100 135 72 140

Domain #

MAPlan

LM-Cut

‡

MAPlan

MA-LM-Cut

‡

MH-FMAP

MAPlan

FF+DTG

PSM-VR PSM-VRD

Blocksworld 20 1 0 0 14 5 14

Depots 20 3 1 1 9 0 14

Driverlog 20 10 4 11 17 7 14

Elevators 20 1 0 4 8 1 4

Logitics 20 3 2 2 13 0 14

Openstacks 20 0 0 3 18 7 8

Rovers 20 1 1 7 19 6 6

Satellite 20 10 2 1 13 3 12

Taxi 20 14 7 10 19 3 15

Wireless 20 3 2 0 2 0

†

Woodworing 20 2 3 4 9 5 18

Zenotravel 20 5 4 10 18 8 8

IPC Agile Score 240 52 27 52 159 45 127

ICAART 2016 - 8th International Conference on Agents and Artiﬁcial Intelligence

190

problem, a point is drawn at the position correspond-

ing to the runtime without dependency analysis (x-

coordinate) and the runtime with dependency analy-

sis (y-coordinate). Hence the points below the diag-

onal constitute improvements. Results show that the

dependency analysis decreases overall planning time

of PSM algorithm. We can see that in few cases the

time increases which is caused by the time consumed

by reduction process. Also, by publishing additional

facts, the problem size can grow and thus it can be-

come harder to solve.

Table 2 shows ofﬁcial results of the CoDMAP

competition. We can see that the dependency anal-

ysis signiﬁcantly improved the performance of PSM-

VR planner. Moreover, PSM-VRD achieved the over-

all best coverage in 8 out of 12 domains. As expected,

the highest coverage directly corresponds to the suc-

cess of dependency analysis. The table also shows

results of two additional criteria comparing the qual-

ity (IPC Score) of solutions and the time (IPC Agile

Score) need to ﬁnd the solution. In both criteria PSM-

VRD performed very well even though it was outper-

formed by MAPlan-FF+DTG planner in the IPC Ag-

ile Score.

8 CONCLUSIONS

We have formally and semantically deﬁned inter-

nally independent and simply dependent MA-STRIPS

problems and proposed a set of reduction rules utiliz-

ing the underlying dependency graph. To identify in-

ternally independent and simply dependent problems,

we have proposed technique which can build a full de-

pendency graph and try to reduce it to an irreducible

publicly equivalent dependency graph. This provides

an algorithmic procedure for recognizing provably in-

ternally independent and simply dependent problems.

We have shown that provably independent and sim-

ply dependent problems can be solved easily without

agent interaction. The proposed reduction rules were

deﬁned over structural information of the dependency

graph and provided possibly recursive removal of su-

perﬂuous facts and actions by analysis of simple de-

pendency, cycles, equivalency, and state invariants.

We experimentally showed that reduction of the

standard multiagent planning benchmarks using the

dependencies provides overall 71% downsizing and

nearly doubled the number of solved problems in

comparison to the same algorithm used without the

reductions. Finally, in comparison with the latest dis-

tributed multiagent planners the proposed approach

outperformed all and won the distributed track of the

recent multiagent planning competition CoDMAP.

ACKNOWLEDGEMENTS

This research was supported by the Czech Sci-

ence Foundation (no. 13-22125S and 15-20433Y)

and by the Czech Ministry of Education (no.

SGS13/211/OHK3/3T/13). Access to computing and

storage facilities owned by parties and projects con-

tributing to the National Grid Infrastructure MetaCen-

trum, provided under the program ”Projects of Large

Infrastructure for Research, Development, and Inno-

vations” (LM2010005), is greatly appreciated.

REFERENCES

ackstr

om, C., Jonsson, A., and Jonsson, P. (2012).

Macros, reactive plans and compact representations.

In ECAI 2012, pages 85–90.

Brafman, R. I. and Domshlak, C. (2008). From one to

many: Planning for loosely coupled multi-agent sys-

tems. In ICAPS’08, pages 28–35.

Chen, Y. and Yao, G. (2009). Completeness and optimal-

ity preserving reduction for planning. Proceedings of

21st IJCAI, pages 1659–1664.

Chrpa, L. (2010). Generation of macro-operators via inves-

tigation of action dependencies in plans. Knowledge

Eng. Review, 25(3):281–297.

Coles, A. and Coles, A. (2010). Completeness-preserving

pruning for optimal planning. In Proceedings of 19th

ECAI, pages 965–966.

Fikes, R. and Nilsson, N. (1971). STRIPS: A new approach

to the application of theorem proving to problem solv-

ing. In IJCAI’71, pages 608–620.

Haslum, P. (2007). Reducing Accidental Complexity in

Planning Problems. In Proceedings of 20th IJCAI,

pages 1898–1903.

Jonsson, A. (2009). The role of macros in tractable plan-

ning. Journal of Artiﬁcial Intelligence Research,

36:471–511.

Jonsson, P. and B

ackstr

om, C. (1998). Tractable plan exis-

tence does not imply tractable plan generation. Annals

of Mathematics and Artiﬁcial Intelligence, 22:281–

296.

Nissim, R. and Brafman, R. I. (2012). Multi-agent A* for

parallel and distributed systems. In Proceedings of

AAMAS’12, pages 1265–1266.

cka, J., Jakub

uv, J., Durkota, K., Komenda, A., and

echou

cek, M. (2014a). Multiagent Planning Sup-

ported by Plan Diversity Metrics and Landmark Ac-

tions. In Proceedings ICAART’14.

cka, J., Jakub

uv, J., and Komenda, A. (2014b). Gener-

ating multi-agent plans by distributed intersection of

ﬁnite state machines. In ECAI2014, pages 1111–1112.

cka, J., Jakub

uv, J., and Komenda, A. (2015a). On

internally dependent public actions in multiagent

planning. In Proceedings of DMAP Workshop of

ICAPS’15.

cka, J., Jakub

uv, J., and Komenda, A. (2015b). PSM-

based Planners Description for CoDMAP 2015 Com-

petition. In CoDMAP-15.

Recursive Reductions of Internal Dependencies in Multiagent Planning

191
