Toward a Guide Agent who Actively Intervene Inter-user

Conversation – Timing Deﬁnition and Trial of Automatic Detection using

Low-level Nonverbal Features

Hung-Hsuan Huang, Shochi Otogi, Ryo Hotta and Kyoji Kawagoe

College of Information Science and Engineering, Ritsumeikan University, Shiga, Japan

Keywords:

Multi-party conversation, Human-agent Interaction, Conversational Agent, Multi-modal Interface.

Abstract:

As the advance of embodied conversational agent (ECA) technologies, there are more and more real-world

deployed applications of ECA’s. The guides in museums or exhibitions are typical examples. However, in

these situations, the agent systems usually need to engage groups of visitors rather than individual ones. In

such a multi-user situation, which is much more complex than single user one, specialized additional features

are required. One of them is the ability for the agent to smoothly intervene user-user conversation. In order to

realize this, at ﬁrst, a Wizard-of-Oz (WOZ) experiment was conducted for collecting human interaction data.

By analyzing the collected data corpus, four kinds of timings that potentially allow the agent to do intervention

were found. The collected corpus was then annotated with these deﬁned timings by recruited evaluators with

a dedicated and intuitive tool. Finally, as the trial of the possibility of automatic detection on these timings,

the use of non-verbal low level features were able to achieve a moderate accuracy.

1 INTRODUCTION

As the advance of embodied conversational agent

(ECA) technology, there are more and more real-

world deployed applications of ECA’s (Kopp et al.,

2005; Traum et al., 2012). Various kinds of kiosk

information systems are used in public places, such

as shopping malls, museums, and visitor centers. The

typical situation in which such systems are used is that

a group of people stand in front of the kiosk and oper-

ate it in order to retrieve the information while talking

with another visitors in the same group. Therefore, in

order to implement an ECA that can serve as an in-

formation kiosk in public places, multi-party conver-

sation functionality for simultaneous interaction with

multiple users is indispensable.

In dyadic dialogs where only two participants are

involved, it can be assumed that when one partici-

pant is speaking then the other one is the addressee in

most cases. In multi-party dialogs, however, the dis-

tinction among conversation participants’ roles, ad-

dressee, overhearer, and speaker is necessary. Who

is talking to whom about what topic should be iden-

tiﬁed and traced, the obligation to answer a question

when being asked needs to be fulﬁlled, and whether

an utterance has been grounded (Clark and Schaefer,

1989) with the addressee(s), i.e. became a shared be-

lief between the speaker and the addressee(s), needs

to be identiﬁed. Since there are potentially more in-

terlocutors to acquire dialog turns from and transfer

dialog turns to, managing the communication ﬂow in

a multi-party conversationis much more sophisticated

than a dyadic one. Traum (Traum, 2003) provided

the principal literature identifying some of the gen-

eral issues in realizing multi-party human-agent in-

teractions.

The conversation style of most contemporary

ECA systems are either agent-initiative(e.g. the agent

always asks questions and the user answers) or user-

initiative (e.g. the user always ask questions and the

agent answers), because these interaction designs are

simpler and are easier to be implemented. However,

the natural conversation occurred between human and

human is mixed-initiative, i.e. both of the agent and

the user may take initiative during the conversation.

In this study, we are proceeding with a project that

aims to build an ECA capable of mixed-initiativecon-

versation with multiple users in a typical application,

information providing for users’ collaborative deci-

sion making.

Considering the case where a real estate agent is

serving a recently married couple who are planning

to buy a new house, the married couples consider the

Huang, H-H., Otogi, S., Hotta, R. and Kawagoe, K.

Toward a Guide Agent who Actively Intervene Inter-user Conversation – Timing Deﬁnition and Trial of Automatic Detection using Low-level Nonverbal Features.

DOI: 10.5220/0005759704590464

In Proceedings of the 8th International Conference on Agents and Artiﬁcial Intelligence (ICAART 2016) - Volume 2, pages 459-464

ISBN: 978-989-758-172-4

459

location, layout, or the price of the houses suggested

by the agent, discuss with each other and collabora-

tively make the ﬁnal decision. In this task, the deci-

sion can be made efﬁciently if the agent can actively

intervene the discussion between the users to pro-

vide timely information while the agent is listening to

the users’ conversation as an overhearer. For exam-

ple, the agent may suggest new candidates as “how

about this apartment? It is only a ﬁve-minute walk

to the train station.” if it hears that the users are dis-

cussing about the transportation issue, or “how about

this apartment? There is a super market which is just

ﬁve-minute away from it.” if it hears that the users

are discussing about meal issue. This kind of interac-

tion is nature and frequently occurs in human-human

conversation. However, for a virtual agent to tackle

this, additional specialized functions have to been in-

corporated to the agent. The agent needs to reason

what information to provide from the users’ conver-

sation even their demands are not clearly described.

The agent also needs to identify the timings when the

user may be interested in the information being pro-

vided without making them feel disturbed. In order

to realize this, we focus on nonverbal information. It

has been known that nonverbal information is an im-

portant element in a conversation scene. In particular,

gaze has been found to have a major impact on multi-

party conversation (Subramanian et al., 2010) .

This paper describes the development of the

method dealing with the timing ﬁnding issue. In order

to realize the feature to ﬁnd the appropriate timings

for the agent, at ﬁrst, a Wizard-of-Oz (WOZ) exper-

iment was conducted for collecting a human interac-

tion data corpus. The experiment participants were

instructed to collaboratively make decisions in three

tasks: travel planning, lecture registration, and part-

time job hunting. They did the tasks with the infor-

mation provided by a virtual agent who is controlled

by one of the experimenters from remote (Section 3).

Then an analysis was conducted on the collected data

corpus to ﬁnd the eight possible timings and the cor-

responding user behaviors (Section 4). A method was

developed to automatically identify four of the four

kinds of timings only by using nonverbal cues, gaze,

body posture, and acoustic information (Section 5).

Finally, the paper is concluded with the evaluation of

the performance of the proposed method and the dis-

cussion on the results.

2 RELATED WORKS

Many studies on the processes of recognition and in-

terpretation in multi-party meetings have been done

in the AMI and AMIDA projects (Renals et al., 2007)

and in the projects of DARPA (Waibel et al., 1998;

Waibel et al., 2001). By applying speech and natural

language processing technologies, a number of useful

components were developed in these projects, such as

speech transcription, speaker diarization, and meeting

summarization.

The management of speaking turns in multi-party

dialogs is very related to the goal of this work. The in-

tervention for active information providing is a higher

level task that needs to consider the situation and the

context of conversation in addition. In the literature

of human communication, (Kendon, 1967; Duncan,

1972; Sacks et al., 1974), it has been reported that

in addition to explicit verbal utterances, people also

use nonverbal signals such as their gaze, nods, and

postures to regulate their conversation, e.g., to show

their intention to yield or the willingness to take next

speech turn. The speaker looks at the addressee to

monitor her/his understanding or attitude, and, the ad-

dressee looks at the speaker in order to be able to of-

fer positive feedbacks in return (Kendon, 1967; Ar-

gyle and Cook, 1976). When yielding his/her turns

for another participant to speak, the speaker looks

at the next speaker at the end of his/her utterances

(Duncan, 1972). Takemae (Takemae et al., 2003)

provided the evidence that the speaker’s gaze indi-

cates addressee-hood and plays a regulatory role in

turn management. The Japanese spoken dialog sys-

tem, DUG-1 (Nakano et al., 1999) realized rich turn-

taking with rules based on linguistics features. Jons-

dottir and Thorisson (Jonsdottir and Thorisson, 2009)

proposed a system that learns turn-taking behavior

on-line with an individual user in less 30 turns by

utilizing reinforcement learning techniques. Bohus

and Horvitz (Bohus and Horvitz, 2010) proposed a

turn management framework in the virtual reception-

ist application. They showed the verbal and non-

verbal cues used by the avatar can shape the dynam-

ics of multi-party conversation. However, the applica-

tion task was relatively simple, a question-answering

game with trivial questions.

3 INTERACTION CORPUS

COLLECTING WOZ

EXPERIMENT

To collect the video corpus for an analysis of the sit-

uations when the agent can potentially intervene the

users to provide timely information, a WOZ exper-

iment on three collaborative decision making tasks

was conducted. We expect that the subjects’ reactions

ICAART 2016 - 8th International Conference on Agents and Artiﬁcial Intelligence

460

toward the agent may differ to how they talk with a

human information provider. To observe the natu-

ral interaction with humans and agents, we chose the

WOZ experiment setting instead of a human-human

one.

3.1 Experiment Settings

Pairs of experiment participants were instructed to in-

teract with a life-size female character projected on

a 100-inch screen. They had to retrieve information

from the character in order to make a decision regard-

ing the given tasks until the agreement between them

achieved. As shown in Figure 1, the subjects stood

about 1.8 m away from the screen where the char-

acter was projected. Two video cameras were used

to record the whole experiment, one from the front

to take the upper bodies of the participants and the

other one takes the whole scene including the partic-

ipants and the character from the rear. One Webcam

was used for the telecommunication software Skype

to connect the WOZ operator to the experiment room.

The microphone array of one Microsoft Kinect sensor

was to identify the voice source (left or right user) of

user utterances. The other Kinect sensor was used to

record body postures with depth images. The conver-

sation experiment was conducted with the following

premises:

• The participants want to make a decision based on

their agreement from multiple candidates with the

help of the agent who is knowledgeable about that

task domain.

• The participants have a rough image of what they

want, but they do not have idea about particular

candidates in advance.

• The participants discuss on their own and acquire

new information from the agent.

• The conversationends when the participants made

the ﬁnal decision.

A total of 15 pairs of college students were re-

cruited as the participants in the experiment, all of

whom were native Japanese speakers. The students

came from various departments ranging from eco-

nomics, life science to engineering at average age,

19.2. 11 of the all 15 pairs were male ones and the

other four were female ones. Each pair was instructed

to complete three decision-making tasks described as

the follows:

Travel Planning: the participants were instructed to

pretend to be in a situation where they had a

coupon from a travel agency that allows them to

visit three of 14 sightseeing spots in Kyushu for

!"#$%&'(')"*$+'%,-$.,('/$0%,-!

!"#$%&''

1)+"%$'2+3.%$4

5.+6$%&+.!

7".&3,8'93"*$!

Figure 1: Setup of the WOZ experiment to collect data for

the interaction corpus.

free. The information, which includes a brief his-

tory, highlights, nearby restaurants, for each lo-

cation was deﬁned in advance. The sightseeing

spots were selected from four of all seven pre-

fectures inside Kyushu. The participants were in-

structed to complete their task by freely retrieving

information from the travel agent, and to discuss

their decisions on their own.

Lecture Registration: the participants were in-

structed to choose three out of 12 lectures to

attend together in the next semester. The informa-

tion about the lecturer, textbook, course difﬁculty,

prerequisites, etc. for each lecture was deﬁned

in advance. The lectures were divided into four

categories: information science, engineering, lan-

guages and communication, and social science.

The subjects could freely ask the “tutor” agent for

any information about the lectures or the agent

itself, and then discuss this on their own in order

to make the ﬁnal decision.

Part-time Job Hunting: the participants were in-

structed to request help in choosing three out of

14 part-time jobs to work together near the univer-

sity. The information about the salary, location,

workload, work type, etc. for each job was de-

ﬁned in advance. The jobs were divided into four

categories: convenient stores, book shops, restau-

rants, and gas stations. The subjects could freely

ask the agent for any information about the part-

time jobs or the agent itself, and then discuss this

on their own in order to make the ﬁnal decision.

These tasks were chosen because the student par-

ticipants are supposed to be familiar with these issues.

In order to stimulate more active discussion, the par-

Toward a Guide Agent who Actively Intervene Inter-user Conversation – Timing Deﬁnition and Trial of Automatic Detection using

Low-level Nonverbal Features

461

ticipants were instructed to make the ranking of three

ﬁnal choices. All participant pairs were assigned to

take all of the three tasks in three separate sessions,

one task for one session. The sessions were conducted

in all possible orders to cancel order effects. One stu-

dent who major in computer science was recruited to

operate the WOZ agent. He was chosen due to his fa-

miliarity in operating a GUI-based WOZ application,

which ensured that there would be smooth interac-

tion. The operator was asked to practice on the WOZ

user interface for two hours prior to the experiment to

further ensure that the agent can response as soon as

possible. All the sentences that the agent could speak

during the experiment were listed in a menu where

relevant sentences were grouped for the WOZ opera-

tor to select from more easily. There was also a text

ﬁeld that allowed the operator to type arbitrary utter-

ances, in the cases when they were needed but were

not deﬁned. The WOZ operator was instructed to try

to end the interaction sessions in ten minutes, if pos-

sible.

4 TIMING EXPLORATION

The appropriate timings of when to intervene the

inter-user conversation for a guide agent is a subjec-

tive issue and has no correct answers. Therefore, hu-

man evaluation was used in this work. The video clips

of 12 sessions, which were randomly selected from

the corpus were evaluated by 20 recruited evaluators

(all male college students at average age, 20.2). Each

video clip was assigned to ﬁve evaluators. The evalu-

ators were instructed to annotate the video when they

want to provide additional on-time information for the

users, as if they were proactive and kind guides. Intu-

itive impression was considered essential for this task,

a dedicated annotation tool other than widely used

tools like Anvil or ELAN. The evaluators watched

the video and input four possible timings with a game

pad. The A, B, C, D button of the game pad were as-

signed to the following four possible timings respec-

tively.

Provide-topic (P-T): switch the topic and provide

new information to the users.

More-information (M-I): provide more detailed in-

formation in compensating the information pro-

vided previously.

Recall-support (R-S): remind the user about the in-

formation provided by the agent if they forgot it.

Discussion-support (D-S): sort out and conclude

the discussion up to now.

In the case when the evaluator wanted to use in-

tervene the inter-user conversation in another way,

he/she can pause the video and freely type “other”

types of timings.

4.1 Analysis of Annotation Data

Totally there were 436 timings labeled by the 20 eval-

uators upon the 12 video clips (ﬁve evaluators for one

clip, averagely 36.3 timings for one clip). In order to

analyze these timings, we segmented the video into

the following four types of periods.

After-agent: immediately after the utterances of the

agent

After-user: immediately after the utterances of the

user

Silent: silent period (at least three seconds)

During-user: during the user’s utterances

The periods during the agent’s utterances were ex-

cluded. In considering what kind of support is appro-

priate, the annotation results of four possible timings

were shown in Figure 2. The timing types did not

distribute evenly in the segments, especially the type

D-S (during the users’ utterances) had most instances.

This is considered that the evaluators most willing to

provide some kind of additional support during the

users’ conversation. The other timings like, “the reply

of the guide toward the question was too quick,”‘ ‘the

pronunciation of the agent should be clearer” were ex-

cluded.

From these results, the timing type M-I had most

instances (19.0 per group). This means that the users

were not satisﬁed with the amount of the information

provided by the agent, or the agent did not make a

right answer. In these cases, timing type R-S and D-S

had 4.2 and 4.8 instances averagely for each group.

Type D-S was annotated around every two minutes in

comparing with the average length of the video clips,

11:40. This implies that it’s important to sort the the

users’ conversation in a thread if the conversation di-

verges.

5 AUTOMATIC CLASSIFICATION

OF INTERVENING TIMINGS

5.1 Selected Features

In order to automatically classify the timing types,

verbal and non-verbal features are selected and anno-

tated if necessary. The details of the selected features

are described below:

ICAART 2016 - 8th International Conference on Agents and Artiﬁcial Intelligence

462

+,-" .,/" 0,1" 2,1" +,-" .,/" 0,1" 2,1" +,-" .,/" 0,1" 2,1" +,-" .,/" 0,1" 2,1"

34567895:;" 34567<=56" 1><:?@5==" 2<6A:97<=56"

Figure 2: Summary of annotation results regarding to tim-

ing types and periods.

Speaking State: When agent itself is speaking, it

can not intervene the user’s conversation, and while a

user is speaking, it is impolite to intervene. Among

the deﬁnition of time periods regarding to speaking

state in section 4.1, the three periods, After

agent, Af-

ter user, and Soundless where neither the users nor

the agent is speaking can be considered as the candi-

dates of intervening.

Speaker: In this work, in order to explore the full

capability of the model which classiﬁes the timing

types, 100% correct information of the speaker of

each utterance has to be prepared. In the WOZ ex-

periment, there are three possibilities of the speaker

of an individual utterance, the user standing at right

hand side, the user standing at the left hand side, and

the agent. During the experiment, the WOZ system

recorded the logs of the utterances when the speaker

is the agent. The microphone array of a Kinect sen-

sor was used to identify the speaker via the direction

of sound source. The mechanism used was so sim-

ple that the identiﬁcation was interfered by noise, and

the results was then manually corrected. When the

realtime system is developed, this aspect should be

improved with a more reliable method.

Addressee: Previous works (Huang et al., 2011;

Baba et al., 2012) have shown that the addressee of

a user utterance can be identiﬁed via non-verbal fea-

tures at the accuracy as high as 80%. In this work,

because of the requirement of correct feature values

for training the classiﬁcation model, the addressee of

each utterance was manually labeled to the values, left

user, right user, and the agent.

Face Direction: During the WOZ experiment, the

face movement of each subject was logged with a We-

bCam and the face recognition software, FaceAPI

Logged face movement information includes three

dimensional positions and rotation as well as a con-

ﬁdence value. These raw values were then used to

train a decision tree (J48 in Weka(Hall et al., 2009))

for automatically classifying face directions to front,

partner, and otherwise.

5.2 Results and Discussion

Due to the fact that the evaluators in the timing an-

notation experiment (Section 4) might label the video

clips at arbitrary positions, labels were explained as

being associated with speaking state segments rather

than their absolute positions. If there were multi-

ple labels labeled by multiple evaluators at the same

speaking state segments, only one was counted (i.e.

multiple labels were not weighted). In addition to

the four proposed intervening timing types, the class,

“False” that means “not a timing” was added to the

targets of automatic classiﬁcation. Because there was

a variety of instance numbers across timing types,

the number of each timing types was balanced in the

training dataset.

The classiﬁcation results using random-forest al-

gorithm are shown in Table 1. The overall accuracy

was 58% (F measure: 0.53). The result was only mod-

erate but was higher than the chance level of ﬁve-class

classiﬁcation (20%).

Table 1: Results of automatic classiﬁcation of intervening

timing types. “N” denotes the number of data instances.

Types N Precision Recall F measure

P-T 60 0.64 0.23 0.34

M-I 60 0.55 0.52 0.53

R-S 60 0.66 0.68 0.66

D-S 60 0.60 0.57 0.58

False 60 0.43 0.75 0.55

Overall 300 0.58 0.55 0.53

6 CONCLUSION AND FUTURE

WORKS

This paper presents the results of the ﬁrst step of an

ongoing project that aims to build an information pro-

viding agent for collaborative decision making tasks,

ﬁnding the timings for the agent to intervene user-user

conversation to provide active support. In order to re-

alize this, at ﬁrst, a WOZ experiment was conducted

for collecting human interaction data. From the col-

lected corpus, four kinds of timings were found prob-

http://www.faceapi.com/download/register.php

Toward a Guide Agent who Actively Intervene Inter-user Conversation – Timing Deﬁnition and Trial of Automatic Detection using

Low-level Nonverbal Features

463

ably allowing the agent to do intervention in the tar-

get task. The deﬁnitions of the timings were validated

with Web based questionnaires. Second, an automatic

timing identifying method was developed to identify

four of the timings only by using nonverbal cues in-

cluding face direction and speaking state. The perfor-

mance of the method is moderate (F-measure 0.53).

The current automatic estimation method is still

relatively ad hoc due to the small corpus, we would

like to increase the corpus size and would like to

explore machine learning techniques to improve its

performance. The performance should be able to be

improved with additional context information. We

would like to introduce the mechanism of context

management and understanding in the future, this

should help to estimate the four remaining timings as

well. Finally, we would like to incorporate the inter-

vention timing estimation feature into an ECA system

and test it in a real-world application.

ACKNOWLEDGEMENTS

This work is partially funded by JSPS under a Grant-

in-Aid for Scientiﬁc Research (B) (24300039) and

(25280076).

REFERENCES

Argyle, M. and Cook, M. (1976). Gaze and Mutual Gaze.

Cambridge University Press.

Baba, N., Huang, H.-H., and Nakano, Y. (2012). Addressee

identiﬁcation for human-human-agent multiparty con-

versations in different proxemics. In 4th Workshop on

Eye Gaze in Intelligent Human Machine Interaction:

Eye Gaze and Multimodality,14th International Con-

ference on Multimodal Interaction (ICMI 2012).

Bohus, D. and Horvitz, E. (2010). Facilitating multiparty

dialog with gaze, gesture, and speech. In In Interna-

tional Conference on Multimodal Interfaces and the

Workshop on Machine Learning for Multimodal In-

teraction.

Clark, H. H. and Schaefer, E. F. (1989). Contributing to

discourse. Cognitive Science, 13:259–294.

Duncan, S. (1972). Some signals and rules for taking speak-

ing turns in conversations. Journal of Personality and

Psychology, 23(2):283–292.

Hall, M., Frank, E., Holmes, G., Pfahringer, B., Reutemann,

P., and Witten, I. H. (2009). The weka data mining

software: An update. ACM SIGKDD Explorations,

11(1):11–18.

Huang, H.-H., Baba, N., and Nakano, Y. (2011). Making

virtual conversational agent aware of the addressee

of users’ utterances in multi-user conversation from

nonverbal information. In 13th International Con-

ference on Multimodal Interaction (ICMI’11), pages

401–408.

Jonsdottir, G. R. and Thorisson, K. (2009). Teaching com-

puters to conduct spoken interviews: Breaking the re-

altime barrier with learning. In Ruttkay, Z., Kipp, M.,

Nijholt, A., Hogni, H., and Vilhjalmsson, editors, 9th

International Conference on Intelligent Virtual Agents

(IVA’09), volume 5773/2009 of LNCS, pages 446–

459, Amsterdam, Netherlands. Springer Berlin.

Kendon, A. (1967). some functions of gaze direction in

social interaction. Acta Psychologica, 26:22–63.

Kopp, S., Gesellensetter, L., Kramer, N. C., and

Wachsmuth, I. (2005). A conversational agent as mu-

seum guide - design and evaluation of a real-world ap-

plication. In Proceedings of the 5th International Con-

ference on Intelligent Virtual Agents (IVA’05), Kos,

Greece.

Nakano, M., Dohsaka, K., Miyazaki, N., ichi Hirasawa,

J., Tamoto, M., Kawamori, M., Sugiyama, A., and

Kawabata, T. (1999). Handling rich turn-taking

in spoken dialogue systems. In European Confer-

ence on Speech Communication and Technology (EU-

ROSPEECH’99).

Renals, S., Hain, T., and Bourlard, H. (2007). Recogni-

tion and understanding of meetings the ami and amida

projects. In IEEE Workhshop on Automatic Speech

Recognition and Understanding (ASRU’07).

Sacks, H., Schegloff, E. A., and Jefferson, G. (1974). a sim-

plest systematics for the organization of turn-taking

for conversation. language, 50(4):696–735.

Subramanian, R., Staiano, J., Kalimeri, K., Sebe, N., and

Pianesi, F. (2010). Putting the pieces together: Mul-

timodal analysis of social attention in meetings. In

Proceedings of the International Conference on Mul-

timedia, pages 659–662.

Takemae, Y., Otsuka, K., and Mukawa, N. (2003). Videocut

editing rule based on participants’ gaze in multiparty

conversation. In 11th ACM International Conference

on Multimedia.

Traum, D. (2003). Issues in multiparty dialogues. In Ad-

vances in Agent Communication, International Work-

shop on Agent Communication Languages (ACL’03),

pages 201–211.

Traum, D., Aggarwal, P., Artstein, R., Foutz, S., Gerten, J.,

Katsamanis, A., Leuski, A., Noren, D., and Swartout,

W. (2012). Ada and grace: Direct interaction with

museum visitors. In 12th International Conference on

Intelligent Virtual Agents (IVA 2012), pages 245–251.

Waibel, A., Bett, M., Finke, M., and Stiefelhagen, R.

(1998). Meeting browser: Tracking and summarizing

meetings. In DARPA Broadcast News Transcription

and Understanding Workshop, pages 281–286.

Waibel, A., Bett, M., Metze, F., Ries, K., Schaaf, T.,

Schultz, T., Soltau, H., Yu, H., and Zechner, K.

(2001). Advances in automatic meeting record cre-

ation and access. In Proceedings of the International

Conference on Acoustics, Speech, and Signal Process-

ing 2001 (ICASSP’01), Seattle, USA.

ICAART 2016 - 8th International Conference on Agents and Artiﬁcial Intelligence

464
