The PERICLES Process Compiler: Linking BPMN Processes into

Complex Workﬂows for Model-Driven Preservation in Evolving

Ecosystems

Noa Campos-L´opez

1,2

and Oliver Wannenwetsch

University of G¨ottingen, G¨ottingen, Germany

Gesellschaft f¨ur Wissenschaftliche Datenverarbeitung G¨ottingen mbH (GWDG), G¨ottingen, Germany

Keywords:

Digital Preservation, Model-Driven Preservation, Process Model, Digital Ecosystem, Digital Art, BPMN,

RDF.

Abstract:

Understanding and reusing archived digital information after a decade of technological advancements, constant

developments and changes to software and hardware is a very complex and time consuming task. Without a

clear documentation and records of changes, research on the creation and modiﬁcation of information systems

and its associated data is almost impossible. To ease these problems, the EU-funded project PERICLES

follows a model-driven preservation approach, where the digital ecosystem is modelled and updated constantly

to handle changes for generating a holistic record on information systems involvement. For realising this

approach, we present in this paper the PERICLES Process Compiler, which consumes descriptive models

of changing environments and evolving semantics to generate executable workﬂows that are capable of re-

enacting changes in information systems and mitigate their impact. By this, our contribution narrows the gap

between the theory of model-driven preservation and its application in real information system environments.

1 INTRODUCTION

Digital content and its associated metadata are gen-

erated and used across different phases of the infor-

mation lifecycle and in a continually evolving envi-

ronment. Therefore, the concept of a ﬁxed and sta-

ble ﬁnal version that needs to be preserved becomes

less appropriate. In order to deal with technologi-

cal change and obsolescence, long-term sustainabil-

ity requires to address changes in context, as well

as changes in semantics. These changes involve se-

mantic drift that arises from changes in language and

meaning or disciplinary and societal changes that af-

fect the practices, attitudes and interests of users and

stakeholders (Davenport and Cronin, 2000).

Capturing and maintaining this information

throughout the data lifecycle, together with the com-

plex relationships between the components of the dig-

ital ecosystem as a whole, is the key to an approach

based on preservation by design (Kowalczyk, 2008).

For this, models that capture intents and interpretive

contexts associated with digital content are subject of

current research on preservation, which enables con-

tent to remain relevant to new communities of users.

The EU-funded project PERICLES (Promoting

Figure 1: PERICLES Model-Driven Preservation with au-

tomatic process compilation.

and Enhancing Reuse of Information throughout the

Content Lifecycle taking account of Evolving Seman-

tics) follows the approach of modelling, capturing and

maintaining details of digital ecosystems for com-

plex information systems on digital artefacts (PERI-

CLES, 2015). For this, PERICLES follows the prin-

ciple of model-driven preservation (MDP) that in-

cludes a holistic capturing, analysing, and updating

of software environments with all applied changes,

Campos-López, N. and Wannenwetsch, O.

The PERICLES Process Compiler: Linking BPMN Processes into Complex Workﬂows for Model-Driven Preservation in Evolving Ecosystems.

In Proceedings of the 12th International Conference on Web Information Systems and Technologies (WEBIST 2016) - Volume 1, pages 76-83

ISBN: 978-989-758-186-1

involved processes and interactions with digital data

over evolving semantics (Vion-Dury, 2015). This

complete capturing is important, because change does

not only lead to a loss of functionality in software

systems but also to a loss of meaning, understanding

and reusing of digital information (Vion-Dury et al.,

2015).

In this paper, we give an overview on the

PERICLES Process Compiler, a core software

component that helps to realise and partially automate

the MDP approach by compiling linked RDF-based

processes into executable BPMN workﬂows. By this,

we deliver contributions on preservation action man-

agement by linking the domain of MDP to the exe-

cutable workﬂow domain.

The paper is structured in eight sections. First,

we provide an insight into existing preservation tech-

niques by process composition, and environment and

semantic modelling in Section 2. Then, we introduce

the MDP approach in PERICLES in Section 3, and

describe our contribution on linking RDF-based pro-

cesses by extending the ecosystem model with three

new concepts in Section 4. Latter, we illustrate this

approach with a case study on preserving digital art

in Section 5 and present the technical realisation of

the Process Compiler in Section 6. We conclude our

paper and provide an insight into future features of the

Process Compiler in Sections 7 and 8, respectively.

2 RELATED WORK

In literature, different aspects of preservation and cu-

ration of software environments have been discussed

in recent years. While the focus of recent literature

is on technical challenges of preservation or on high

level approaches, publications which link both do-

mains together that are usable for non-software ex-

perts are still underrepresented. For preserving soft-

ware environments, different approaches have been

introduced, such as performance model-based preser-

vation (Matthews et al., 2010). However, this ap-

proach coming from the area of libraries does not

reﬂect the changing nature of software environments

that has been recognized by the software development

community (Barateiro et al., 2012). As software is

just one essential part in complex scenarios, preserva-

tion processes aim on higher semantics of preserving

data, software environments and evolving semantics

(Neumann et al., 2011).

New approaches that link business process mod-

els with metamodels and ontologies have appeared in

recent years. These approaches cover semantic inter-

operability of process models by adding higher pre-

cision in modelling and enable semantic querying of

large process model repositories (H¨offerer, 2007) and

(Smith et al., 2012).

Other approaches cover the employment of se-

mantic process models by linking model elements

with concepts from formal ontologies. Linking those

domains together improves the representation of pro-

cess models, enables process validation at semantic

level, and simpliﬁes the process execution (Thomas

and Fellmann, 2007). As processes are also subject to

changes in evolving environments during their lifecy-

cle, approaches that manage these changes and allow

the reconﬁguration of process models are of great in-

terest. Gottschalk et al. propose conﬁgurable work-

ﬂow models by extending workﬂow modelling lan-

guages with conﬁguration elements and their conﬁg-

urations (Gottschalk et al., 2008), whereas Koliadis

et al. combine high-level conceptual models with

business process models to populate changes in both

context (Koliadis et al., 2006). However, these ap-

proaches do not consider changes in semantics and

this is the gap, where we provide a contribution with

MDP and process compiling. Many publications on

process composition based on compiling ontological

descriptions into executable process models can be

found in literature. These approaches allow process

reuse, and facilitates the process modelling, reason-

ing and matching. However, they are mostly focused

on speciﬁc domains, i.e. Web Service composition

(Rao et al., 2004), (Rao and Su, 2005), (Martin et al.,

2005), and (Sirin et al., 2002), or scientiﬁc workﬂow

compilation (Lud¨ascher et al., 2003).

From the side of modelling computation envi-

ronments for scientiﬁc applications, cloud computing

added new impulses of deploying infrastructure mod-

els into executable cloud environments. One essential

standard in this setting is Topology and Orchestra-

tion Speciﬁcation for Cloud Applications (TOSCA)

from the OASIS, which is used to describe topologies

of cloud based web services, their relations, compo-

nents, and processes used to manage them (Binz et al.,

2012). Similar to PERICLES, TOSCA is a current re-

search topic in the area of executable environments

for scientiﬁc applications in the cloud (Glaser, 2015).

3 MODEL-DRIVEN

PRESERVATION

In this line-up, the EU-funded project PERICLES

is looking at the whole picture from the different

angle of modelling and builds upon the results on

performing digital preservation. The research focus

of PERICLES is on understanding the implication

The PERICLES Process Compiler: Linking BPMN Processes into Complex Workﬂows for Model-Driven Preservation in Evolving

Ecosystems

of changing ecosystems in contrast to speciﬁc chal-

lenges on system changes over time, as it was formu-

lated ﬁve years ago (Brocks et al., 2010).

The model-driven preservation approach em-

ployed and extended in PERICLES consists of a set of

interrelated ontologies and models described as Re-

source Description Framework (RDF) triples. One

of these models is the ecosystem model, describ-

ing the digital ecosystem in which digital resources

are produced, stored, modiﬁed and processed. The

PERICLES project, as context where our work is con-

ducted, deﬁnes as digital ecosystem a set of interre-

lated entities that evolve on time (PERICLES, 2015).

This set comprises digital objects, user communities,

policies, processes, technical systems, and the rela-

tions and interactions between them. If changes in

the ecosystem are applied, i.e. an update of the oper-

ating system, an update of the ecosystem model is re-

quired. For managing the evolution and change of the

digital ecosystem, the ecosystem model is fundamen-

tally built on the Linked Resource Model (LRM),

which provides a framework to build the dependen-

cies between entities as a set of evolving linked re-

sources (Vion-Dury et al., 2015). The LRM allows to

deﬁne the semantics of a change in terms of its inten-

tion and manage its impact on the ecosystem, key to

long-term preservation, understanding and reusing of

digital information. While the LRM and ecosystem

model provide a domain-independent basis to model

digital resources in changing environmentsand evolv-

ing semantics, domain-speciﬁc ontologies are used

to describe speciﬁc ecosystems for the different use

cases.

Regular checks and analyses of models together

with a validation of the digital ecosystem against its

representation in the ecosystem model are necessary

to detect changes in data objects, technology, context,

semantics and user communities. When a change oc-

curs, preservation actions are applied on the ecosys-

tem to preserve the digital resources and mitigate the

impact of change (c.f. Figure 1). Hence, the set of

models and the derived preservation actions allow to

trace all changes in digital systems and information

processing and allow an (semi-) automatic reconstruc-

tion of digital ecosystems, capable of executing an-

cient software in their original environment. Preser-

vation actions operate over the digital ecosystem, and

change and evolve as it does. Therefore, we model

these preservation actions as a set of process entities

interrelated with other entities in the digital ecosys-

tem by extending the ecosystem model with new con-

cepts, namely aggregated process, atomic process and

implementation entities (c.f. Subsec. 4.1 and 4.2). A

process entity in the ecosystem model is a high-level

description of a process: which function it performs,

which data it consumes and produces, and which ser-

vices it runs, while delegating the low-level details to

be described in an associated ﬁle using a well suited

notation (e.g. Business Process Model and Notation

(BPMN)). This BPMN ﬁle can be then executed over

real information systems to perform the preservation

actions. This approach allows to use the same tech-

nology to reason, manage, query and store all models

and entities used in the preservation system, includ-

ing the LRM functionalities of change management

and semantic versioning. Thus, our preservation sys-

tem takes advantage of the beneﬁts provided by se-

mantic process models (c.f. Sec. 2) without having to

develop a complete new process ontology.

4 THEORETICAL APPROACH

The PERICLES Process Compiler that we describe

in this paper allows to transform and combine RDF-

based descriptions of preservation processes into ex-

ecutable BPMN workﬂows (c.f. Fig. 1). This can be

done because we have included three new concepts in

the ecosystem model: aggregated processes, atomic

processes and implementations. These entities can

be used to easily design new preservation actions by

process combination, while enabling process valida-

tion within the ecosystem model at semantic level and

within the process model speciﬁcation (e.g. BPMN)

at implementation level.

4.1 Aggregated and Atomic Process

Entities

An aggregated process is a process that can be de-

scribed as a combination of other process entities.

For this, both process ﬂow and data ﬂow are deﬁned.

They describe how processes, and produced and con-

sumed data are connected within each other.

In contrast, an atomic process is a process that

cannot be decomposed in other process entities, even

if its execution may include more than one task.

Atomic processes have information about the opera-

tors, namely the entities responsible of performing the

tasks involved in the execution of the workﬂow.

This differentiation in aggregated and atomic pro-

cesses provides more ﬂexibility to create new preser-

vation actions while enabling the reusability of reli-

able ecosystem processes. It facilitates a clearer vi-

sualization of dependencies between entities in the

ecosystem and allows us to keep track of which pro-

cesses are used by others. It also reduces the scope of

change. For example, if the technology of a service

WEBIST 2016 - 12th International Conference on Web Information Systems and Technologies

Figure 2: Process ﬂow and data ﬂow in an aggregated pro-

cess composed of three processes.

used by an atomic process changes, only the imple-

mentation ﬁles need to be recompiled, while aggre-

gated process descriptions and dependencies remain

valid.

As being part of the digital ecosystem, process

entities and their dependencies are described and

modelled in the ecosystem model (c.f. Sec. 3). The

ecosystem model assigns attributes to each entity

type, describing its instances with identiﬁers, hu-

man readable names, versions and other necessary at-

tributes. For modelling the behaviour and relation-

ships of a process in the digital ecosystem, the ecosys-

tem model provides a set of dependencies - which

inherits from the LRM dependency deﬁnition - be-

tween processes and other entities, i.e. isInputOf,

isOutputOf or isImplementationOf. In the following

subsections, a brief overview of the process type at-

tributes is given, to explain the input side of the PER-

ICLES Process Compiler.

4.1.1 Common Process Attributes

Originated from the same abstract process entity, both

process types of aggregated and atomic processes

share a common set of attributes. In the following,

we explain the most important attributes:

Identiﬁers are provided for machinery identiﬁcation

with a unique identiﬁer and a human-readable name.

Descriptions are provided for explaining the pro-

cess, its purpose, which operation/functionalityit per-

forms, over which entities and under which condi-

tions.

Inputs are describing the inputs that can be inserted

into a process. They are provided as a list of input

slots ∗(0..n), specifying for processes a set of vari-

ables with a unique ID, a human-readable name, an

input data type, and a ﬂag marking the input as re-

quired or optional.

Outputs are the entities generated by a process. Sim-

ilar to inputs, they are organized as a list of slots

∗(0..n), specifying for processes a set of variables

with a unique ID, a human-readablename, and an out-

put data type.

Implementations are containing the entities with

the low-level description of the process (c.f.

Subsec. 4.2.).

4.1.2 Atomic Process Attributes

Atomic processes as the smallest unit in the decom-

position for the Process Compiler consist of a list of

operators ∗(0..n), as well as the common attributes

shown in Subsec. 4.1.1.

Operators are entities responsible for performing a

speciﬁc task, which may invoke technical services

and other infrastructure components. They can be hu-

man agents performing human tasks, or software or

hardware agents performing automatic tasks.

Figure 3: Atomic process and its dependencies with other

entities in the ecosystem.

4.1.3 Aggregated Process Attributes

Aggregated processes are created as a combination of

other process entities.Thus, they have as additional at-

tributes the description of this combination:

Process ﬂow as an attribute consists of a list of pro-

cess identiﬁers that determines the order of execution

of sub-processes: a sequential process thread starting

with a start event followed by the sub-processes and

ﬁnishing with an end event.

Data ﬂow as an attribute consists of a map that deter-

mines the data connection between input and output

slots of process entities and the available digital re-

sources at that time.

4.2 Implementation Entity

An implementation entity contains the information

regarding the nature and location of a speciﬁc arte-

fact that performs changes on data and systems in the

ecosystem. The implementation entity as low-level

description of a process consists of a unique identiﬁer

and a version number that allows a co-existence of

different-aged implementations. Furthermore, it con-

sists of:

The PERICLES Process Compiler: Linking BPMN Processes into Complex Workﬂows for Model-Driven Preservation in Evolving

Ecosystems

Figure 4: Aggregated process and its dependencies with

other entities in the ecosystem.

Implementation Type is an attribute that speciﬁes

the identiﬁer of the execution environment, i.e.

BPMN

if the implementation is done as an executable BPMN

workﬂow.

Location speciﬁes where the artefacts containing the

implementation are stored. The location annotation is

done abstract from real path descriptions as Universal

Resource Identiﬁer (URI).

Checksum assures the integrity of the implementa-

tion artefact, by providing a cryptographic hash.

4.3 Process Aggregation

To allow a coherent process aggregation approach, we

assume the following:

Sequential Execution of the processes that conform

an aggregated process. This means that a process can

be executed only if the previous one has already ﬁn-

ished. Therefore, resources created by previous pro-

cesses (intermediate resources in Fig. 2) or input re-

sources of the aggregated process can be used as in-

puts for the current process. Parallel execution in

atomic processes is allowed.

Single Threading in aggregated processes. The ar-

rangement of processes is limited to a ﬂat sequence of

processes, understanding as a ﬂat sequence a unique

thread with a start event followed by speciﬁc pro-

cesses and an end event, (process ﬂow in Fig. 2). Mul-

tithreading in atomic processes is allowed.

Immutable Resources, therefore if a process mod-

iﬁes a resource, it has to create a new one. They

are represented by ﬁles on the ﬁle system or arbitrary

URIs.

Class based-inheritance in the ecosystem. If an en-

tity, child entity, is a specialization of other entity,

parent entity, then all the attributes of the parent en-

tity are present and unmodiﬁed in the child entity.

Thus, we can use a child entity as input/output for a

process that takes the parent entity as the correspond-

ing input/output.

To facilitate the creation of new preservation ac-

tions by process aggregation, a set of generic pro-

cesses that perform common functionalities is pro-

vided when creating the preservation system. This set

will increase and become richer as new processes are

created.

An aggregated process can be described as a com-

bination of atomic and/or other aggregated processes,

which can be also described as a combination of

atomic and/or other aggregated processes and so on.

This aggregation hierarchy follows a tree structure in

the ecosystem model which always ends in atomic

processes with their corresponding operators. There-

fore, it is not necessary to explicitly link the list of op-

erators involve in an aggregated process, as they can

be inferred by unfolding the process ﬂow steps.

The unfolding step queries extensively the model

repository (c.f. Fig. 1), a triplestore which contains

the RDF-based descriptions of models and entities,

and also integrates a step of verifying data types of

input and output slots. Repetitive steps are inte-

grated as multiple occurrences in the process. Due

to these constraints of unfolding and assembling pro-

cesses, the Process Compiler for MDP constructed in

PERICLES does not feature a Turing-complete lan-

guage, but rather gain full explicit process step def-

initions, important for long-living workﬂow deﬁni-

tions in the context of data curation. However, pro-

cess implementations can contain Turing-complete

languages with loops and nested instructions. Hence,

each step of an aggregated process represents the ex-

ecution of a process with a well-deﬁned data set.

5 CASE STUDY: INGEST OF THE

DIGITAL COMPONENT OF A

SOFTWARE-BASED ARTWORK

In PERICLES, the ﬁrst project stream deals with

preservation strategies for digital artworks and me-

dia at TATE, as shown in (Falcao et al., 2014). The

second stream deals with experimental scientiﬁc data

originated from the European Space Agency and In-

ternational Space Station (Soille et al., 2014). Both

use case providers are working to understand the im-

pact of the MDP approach on their preservation prac-

tices.

In this case study, we focus on the ﬁrst project

stream and its goal is to create a process that ingests

an Artwork’s Software (AS) into a preservationpack-

age of a speciﬁc format. We assume that this pro-

cess can be described as a combination of three pro-

cesses: check the AS for viruses, extract its meta-

WEBIST 2016 - 12th International Conference on Web Information Systems and Technologies

data (MD), and encapsulate the AS together with its

MD in a preservation package, ready for storage (c.f.

Fig. 6). For the purpose of this paper, we have sim-

pliﬁed the ingest process as we only want to depict

the process aggregation and show how it facilitates

the change management in our MDP approach. A

real scenario should consider a more complex design,

i.e. the encapsulation process would require stringent

quality control to ensure that the performance of the

encapsulated software is the same as that of the non-

encapsulated version.

Let us consider the following situation: an organ-

isation has a collection of ASs and decides to intro-

duce them in its preservation system. For that, new

policies and preservation actions need to be created

and applied, i.e. the policy ”every AS needs to be in-

gested before storing”, which implies to execute the

process Ingest AS over each new AS. A data cura-

tor accesses to the preservation system to create the

new ingest process and realises that it can be done

as a combination of other processes already available

in the system. Therefore, the curator decides to cre-

ate an aggregated process with a process ﬂow com-

posed by: Virus Check, Extract MD and Encapsulate

DO and MD processes. These processes are modelled

in the ecosystem as atomic process entities with their

corresponding operators. The relationships between

these processes and other entities in the ecosystem are

shown in Fig. 5.

Figure 5: Entities and their dependencies in the ecosystem

for the aggregated process Ingest Artwork’s Software.

Then, the curator has to create the data ﬂow. The

Ingest AS process has two input resources, an AS and

a package format corresponding to the input slots x

and x

respectively and one output resource, a preser-

vation package corresponding to the output slot y

(c.f. Fig. 6).

The Virus Check process takes as input the digital

material to be checked and produces a ﬁle contain-

ing the result of this operation. Therefore, the curator

maps its input slot with the input slot of the Ingest

process related to the AS, that is (x

, a

). The result

of this check is then used as extra information to be

added to the MD of the AS, that is (b

, c

). The En-

capsulate digital object (DO) and MD process encap-

sulates the AS and its MD together into a package of a

speciﬁc format. Therefore, the curator maps their in-

put slots with the input slots of the Ingest process, and

with the output slot of the Extract MD process, that is

, e

), (x

, e

) and (x

, e

). The curator also maps

its output slot with the output slot of the Ingest pro-

cess, that is (f

, y

). Once the aggregated process is

deﬁned, it is compiled by the Process Compiler com-

piles to create the executable workﬂow (i.e. BPMN

ﬁle) to be executed when a new AS is introduced in

the preservation system.

Figure 6: Process ﬂow and data ﬂow for the aggregated pro-

cess Ingest Artwork’s Software.

In this example the preservation action is created

by hand, but the MDP approach in PERICLES is de-

signed to allow (semi-)automatic reconﬁguration of

preservation actions. For example, a new preservation

policy is applied: ”when checking for viruses, suspect

material has to be quarantined for 30 days”. There-

fore, the old process Virus Check is changed by a new

one Virus Check and Quarantine, and all aggregated

processes that perform virus checks are automatically

reconﬁgured with the new one.

The PERICLES Process Compiler: Linking BPMN Processes into Complex Workﬂows for Model-Driven Preservation in Evolving

Ecosystems

6 IMPLEMENTATION

The implementation of the PERICLES Process Com-

piler is done in Java. It currently supports MDP

process compilation for BPMN-based workﬂows, al-

though the design is intended to adapt to other work-

ﬂow languages. In PERICLES, entities and mod-

els are stored in the model repository (c.f. Fig. 1),

a triplestore used as database for storage and re-

trieval of triples through semantic queries. Digital re-

sources and bitstreams are stored in external data stor-

age systems, such as CDSTAR (Schmitt et al., 2014).

Communications are done via Representational State

Transfer (REST) APIs, allowing in the case of the

triplestore SPARQL requests.

The Process Compiler compiles an RDF-based de-

scription of an aggregated process to create an exe-

cutable BPMN ﬁle by doing the following:

Validation by validating the ﬁle structure against the

implementation speciﬁcation, rejecting input with un-

known or unsupported attributes and checking entity

compatibility, which may imply to check the inheri-

tance tree and dependencies in the ecosystem model.

For instance, the Virus Check process in Sec. 5 takes

as input an entity of class Artwork’s Software. As the

AS class is a subclass of Digital Object, this process

can be used to check an entity of class AS and the

previous mapping (x

, a

) is valid.

Process Flow Handling by linking the processes in

an appropriate order taking into account the services

used to perform the tasks and managing the corre-

sponding interfaces. It creates a single thread with

start-event the one of the ﬁrst sub-process and end-

event the one of the last sub-process.

Data Flow Handling by connecting input and out-

put process slots with external and temporary digi-

tal resources according to the map speciﬁed by the

data ﬂow of the aggregated process. Intermediate re-

sources are temporarily stored in a secure external

system (i.e. CDSTAR) and deleted when the process

compilation is ﬁnished.

Error Handling by generating appropriate errors and

linking them to external events.

7 CONCLUSION

The PERICLES project follows a model-driven

preservation approach, where the digital ecosystem is

modelled and updated to handle changes in digital in-

formation and mitigate their impact for preservation

purposes. The PERICLES Process Compiler supports

this model-driven approach by validating and linking

processes to perform preservation actions over evolv-

ing ecosystems.

For doing this, we introduce the concept of ag-

gregated and atomic processes as part of the ecosys-

tem model, which are used by the Process Compiler

to compile preservation processes into executable

BPMN workﬂows. Using these different process

types allows more ﬂexibility to create new preserva-

tion processes, increases process reusability, and re-

duces the scope of changes in the ecosystem. This

approach provides as well the advantages of semantic

annotation of processes, namely better process under-

standing and representation, and process query and

validation at semantic level, without developing an

entire complex process ontology. Also, the relation-

ships and dependencies between the entities in the

ecosystem become clearer as low-level descriptions

remain hidden in implementation entities linked to

process entities. Starting with a set of common pro-

cesses, preservation processes become more complex

and specialised as the ecosystem evolves. The Process

Compiler facilitates the creation and modiﬁcation of

these processes without a deep knowledge of the im-

plementation language or the ontologies and models

used for describing the ecosystem.

The Process Compiler is still under development

and its functionality is subject of research in the

course of the PERICLES project. Current scenarios

in both use cases look at the Process Compiler as a

key component to perform the MDP approach, as it

allows the automatic reconﬁguration of preservation

actions when a change occurs. For instance, changes

in a policy imply the reconﬁguration of its associated

processes to be applied over the digital ecosystem to

assure its coherent state, or changes in technology, i.e.

obsolete software, imply the recompilation of the im-

plementation ﬁles to be linked to up-to-date services.

8 FUTURE WORK

Future lines of work of the PERICLES Process Com-

piler will allow more complex process aggregations,

not only sequential threads with input and output

mapping, but actual complete automata by leverag-

ing Petry nets. On the other hand, semantic valida-

tion will be added to type validation together with op-

timizations at some degree, i.e. verify that a ﬁle is

checked for viruses only once, to improve the perfor-

mance of the overall system where the Process Com-

piler is used. Although BPMN is a widely used pro-

cess modelling standard, another interesting feature

is to support other workﬂow description languages in

order to extend its usability and allow process models

interoperability.

WEBIST 2016 - 12th International Conference on Web Information Systems and Technologies

ACKNOWLEDGEMENTS

Parts of this work are founded in the PERICLES

project funded by the European Union under its Sev-

enth Framework Programme (ICT Call 9) under the

grant agreements No 6 01138. We thank Marcel Hel-

lkamp for his contribution on the Process Compiler

implementation and sharing his ideas and concepts

with us. Furthermore, we like to thank Patricia Falcao

from TATE for giving insights into their use cases.

REFERENCES

Barateiro, J., Draws, D., Neuman, M., and Strodl, S. (2012).

Digital Preservation Challenges on Software Life Cy-

cle. In Software Maintenance and Reengineering

(CSMR), 2012 16th European Conference on, pages

487–490, Szeged.

Binz, T., Breiter, G., Leyman, F., and Spatzier, T. (2012).

Portable Cloud Services Using TOSCA. IEEE Inter-

net Computing, 16(3):80–85.

Brocks, H., Kranstedt, A., J¨aschke, G., and Hemmje, M.

(2010). Modeling Context for Digital Preservation. In

Kacprzyk, J., Szczerbicki, E., and Nguyen, N. T., edi-

tors, Smart Information and Knowledge Management,

volume 260, pages 197–226. Springer, Berlin.

Davenport, E. and Cronin, B. (2000). Knowledge Man-

agement: Semantic Drift or Conceptual Shift? Jour-

nal of Education for Library and Information Science,

41(4):294.

Falcao, P., Ashe, A., and Jones, B. (2014). Virtualisation

as a Tool for the Conservation of Software-Based Art-

works - Presentation. In Proceedings of the 11th In-

ternational Conference on Digital Preservation, pages

83–90, Melbourne. State Library of Victoria.

Glaser, F. (2015). Towards Domain Model Optimized De-

ployment and Execution of Scientiﬁc Applications in

Cloud Environments. In Doctoral Consortium, pages

20–25, Lisbon, Portugal.

Gottschalk, F., Van Der Aalst, W. M., Jansen-Vullers,

M. H., and La Rosa, M. (2008). Conﬁgurable work-

ﬂow models. International Journal of Cooperative In-

formation Systems, 17(02):177–221.

H¨offerer, P. (2007). Achieving Business Process Model In-

teroperability Using Metamodels and Ontologies. In

ECIS, pages 1620–1631, Geneva, Switzerland.

Koliadis, G., Vranesevic, A., Bhuiyan, M., Krishna, A.,

and Ghose, A. (2006). Combining i* and BPMN for

Business Process Model Lifecycle Management. In

Hutchison, D. and Eder, J., editors, Business Process

Management Workshops, volume 4103, pages 416–

427. Springer, Berlin.

Kowalczyk, S. (2008). Digital Preservation by Design.

In Raisinghani, M. S., editor, Handbook of research

on global information technology management in the

digital economy, pages 405–431. Information Science

Reference, Hershey.

Lud¨ascher, B., Altintas, I., and Gupta, A. (2003). Com-

piling abstract scientiﬁc workﬂows into web service

workﬂows. In Scientiﬁc and Statistical Database

Management, 2003. 15th International Conference

on, pages 251–254, San Diego. IEEE.

Martin, D., Paolucci, M., McIlraith, S., Burstein, M., Mc-

Dermott, D., McGuinness, D., Parsia, B., Payne, T.,

Sabou, M., Solanki, M., Srinivasan, N., and Sycara,

K. (2005). Bringing Semantics to Web Services: The

OWL-S Approach. In Hutchison, D., editor, Semantic

Web Services and Web Process Composition, volume

3387, pages 26–42. Springer, Berlin.

Matthews, B., Shaon, A., Bicarregui, J., and Jones, C.

(2010). A Framework for Software Preservation. In-

ternational Journal of Digital Curation, 5(1):91–105.

Neumann, M. A., Riedel, T., Taylor, P., Schmidtke, H. R.,

and Beigl, M. (2011). Monitoring for Digital Preser-

vation of Processes. pages 214–220, Berlin. Springer

Berlin Heidelberg. Last accessed on Oct 27, 2015.

PERICLES, P. (2015). About the project. Last accessed on

Oct 27, 2015.

Rao, J., Kungas, P., and Matskin, M. (2004). Logic-based

web services composition: From service description

to process model. In Web Services, 2004. Proceed-

ings. IEEE International Conference on, pages 446–

453, San Diego. IEEE.

Rao, J. and Su, X. (2005). A Survey of Automated Web

Service Composition Methods. In Hutchison, D., edi-

tor, Semantic Web Services and Web Process Compo-

sition, volume 3387, pages 43–54. Springer, Berlin.

Schmitt, O., Siemon, A., Schwardmann, U., and Hellkamp,

M. (2014). GWDG Object Storage and Solution for

Research - Common Data Storage Architecture (CD-

STAR). GWDG Berichte, (78):64. Last accessed on

Oct 27, 2015.

Sirin, E., Hendler, J., and Parsia, B. (2002). Semi-automatic

Composition of Web Services using Semantic De-

scriptions. In In Web Services: Modeling, Architecture

and Infrastructure workshop in ICEIS 2003, pages

17–24, Angers, France.

Smith, F., Missikoff, M., and Proietti, M. (2012). Ontology-

Based Querying of Composite Services. In Hutchi-

son, D., editor, Business System Management and En-

gineering, volume 7350, pages 159–180. Springer,

Berlin.

Soille, P., Marchetti, P. G., European Commission, Joint

Research Centre, Institute for the Protection and the

Security of the Citizen, ESA, SatCen, and Conference

on Big Data from Space (2014). Proceedings of the

2014 conference on Big Data from Space (BiDS’14).

Publications Ofﬁce, Luxembourg.

Thomas, O. and Fellmann, M. (2007). Semantic EPC:

Enhancing Process Modeling Using Ontology Lan-

guages. In Hepp, M., Hinkelmann, K., Karagiannis,

D., Klein, R., and Stojanovic, N., editors, Proceed-

ings of the Workshop on Semantic Business Process

and Product Lifecycle Management (SBPM 2007),

Aachen. RWTH Aachen.

Vion-Dury, J.-Y. (2015). Towards model-driven preserva-

tion. Colmar, France.

Vion-Dury, J.-Y., Lagos, N., Kontopoulos, E., Riga, M.,

Mitzias, P., Meditskos, G., Waddington, S., Lau-

renson, P., and Kompatsiaris, I. (2015). Designing

for Inconsistency – The Dependency-Based PERI-

CLES Approach. In Morzy, T., editor, New Trends

in Databases and Information Systems, volume 539,

pages 458–467. Springer International Publishing,

Cham. Last accessed on Oct 27, 2015.

The PERICLES Process Compiler: Linking BPMN Processes into Complex Workﬂows for Model-Driven Preservation in Evolving

Ecosystems
