Software Evolution of Legacy Systems

A Case Study of Soft-migration

Andreas F

urnweger, Martin Auer and Stefan Bifﬂ

Vienna University of Technology, Inst. of Software Technology and Interactive Systems, Vienna, Austria

Keywords:

Software Evolution, Migration, Legacy Systems.

Abstract:

Software ages. It does so in relation to surrounding software components: as those are updated and modern-

ized, static software becomes evermore outdated relative to them. Such legacy systems are either tried to be

kept alive, or they are updated themselves, e.g., by re-factoring or porting—they evolve. Both approaches carry

risks as well as maintenance cost proﬁles. In this paper, we give an overview of software evolution types and

drivers; we outline costs and beneﬁts of various evolution approaches; and we present tools and frameworks

to facilitate so-called “soft” migration approaches. Finally, we describe a case study of an actual platform

migration, along with pitfalls and lessons learned. This paper thus aims to give software practitioners—both

resource-allocating managers and choice-weighing engineers—a general framework with which to tackle soft-

ware evolution and a speciﬁc evolution case study in a frequently-encountered Java-based setup.

1 INTRODUCTION

Software development is still a fast-changing environ-

ment, driven by new and evolving hardware, oper-

ating systems, frameworks, programming languages,

and user interfaces. While this seemingly constant

drive for modernization offers many beneﬁts, it also

requires dealing with legacy software that—while

working—slowly falls out of step with the surround-

ing components that are being updated—for example,

if a certain version of an operating system is no longer

supported by its vendor. There are various ways to

handle such “aging” software: one can try to keep

it up and running; to carefully refactor it to various

degrees to make it blend in better; to port its code;

to rewrite it from scratch. The main stakeholders in

deciding on a course of action are managers, which

must allocate resources to and consider the risks and

maintenance cost proﬁles of the various options (e.g.,

will affordable developers with speciﬁc skills still be

available?), as well as software developers, which

should be aware of the long-term implications of their

choices (e.g., will a certain programming language be

around in ﬁve years’ time?).

To provide some software evolution guidelines,

our paper ﬁrst gives an overview on software evolu-

tion types, covering maintenance, reengineering, and

whether to preserve or redesign legacy systems. We

address software aging and its connection with main-

tainability. We look into different aspects of software

maintenance and show that the classic meaning of

maintenance as some ﬁnal development phase after

software delivery is outdated—instead, it is best seen

as an ongoing effort. We also discuss program porta-

bility with a speciﬁc focus on porting source code.

We then outline costs and beneﬁts of various

evolution approaches. These approaches are either

legacy-based, essentially trying to preserve as much

as possible of the existing system, or migration-based,

where the software is transferred, to various degrees,

into a new setup.

After that, we focus on various methods for “soft”

migration approaches—those approaches aim to fa-

cilitate traditional migration methods like porting or

rewriting code via support tools and frameworks.

We especially concentrate on the Java programming

language and present a speciﬁc variant of a soft-

migration approach, which is using a Java-based pro-

gram core with several platform-speciﬁc branches.

Finally, we describe a case study of an actual soft

migration of the UML editor UMLet, which is cur-

rently available as a Swing-based Java program and

an SWT-based Eclipse plugin, and which is ported to

a web platform. We analyze some problems we en-

countered, and discuss the beneﬁts and drawbacks of

the suggested approach.

Fürnweger, A., Auer, M. and Bifﬂ, S.

Software Evolution of Legacy Systems - A Case Study of Soft-migration.

In Proceedings of the 18th International Conference on Enterprise Information Systems (ICEIS 2016) - Volume 1, pages 413-424

ISBN: 978-989-758-187-8

413

2 RELATED WORK

(Mens and Demeyer, 2008) give an overview of trends

in software evolution research and address the evo-

lution of other software artifacts like databases, soft-

ware design, and architectures. A general overview of

the related topics of maintenance and legacy software

is given by (Bennett and Rajlich, 2000), who also

identify key problems and potential solution strate-

gies.

Lehman classiﬁes programs in terms of software

evolution and also formulates laws of software evo-

lution (Lehman, 1980; Lehman et al., 1997), which

are, however, not considered universally valid (Her-

raiz et al., 2013). There are also many exploratory

studies that try to analyze and understand software

evolution based on speciﬁc software projects (Jo-

hari and Kaur, 2011; Businge et al., 2010; Zhang

et al., 2013; Ratzinger et al., 2007; Kim et al., 2011).

(Chaikalis and Chatzigeorgiou, 2015) develop a pre-

diction model for software evolution and evaluate it

against several open-source projects. (Benomar et al.,

2015) present a technology to identify software evo-

lution phases based on commits and releases.

The related topic of legacy systems is a bit am-

biguous, due to differing deﬁnitions. It can describe

a system that resists modiﬁcation (Brodie and Stone-

braker, 1995), a system without tests (Feathers, 2004),

or even all software as soon as it has been written

(Hunt and Thomas, 1999). A natural question regard-

ing legacy systems is whether to preserve or redesign

them. As this question is not easy to answer (Schnei-

dewind and Ebert, 1998), the pros and cons of reengi-

neering or preserving a system are to be compared

thoroughly before making a decision (Sneed, 1995).

In addition, it is possible to replace a system in stages

to minimize the operational disruption of the system

(Schneidewind and Ebert, 1998).

Even though the classic view of maintenance as

the ﬁnal life-cycle phase of software after delivery is

still prevalent, it is a much broader topic, especially

for programs which must constantly adapt to a chang-

ing environment. There are reports that the total main-

tenance costs are at least 40% of the initial develop-

ment costs (Brooks Jr., 1995), 70% of the software

budget (Harrison and Cook, 1990), and up to 90% of

the total costs of the system (Rashid et al., 2009). As

these numbers show, the topic of maintenance is cru-

cial. (Lientz and Swanson, 1980) categorize mainte-

nance activities into distinct classes. Several authors

(Sjøberg et al., 2012; Riaz et al., 2009) propose main-

tainability metrics.

Finally, when migrating a system, a reengineer-

ing phase is almost always necessary. According

to (Feathers, 2004), this phase should be accompa-

nied by extensive testing to make sure the application

behavior stays the same. (Fowler and Beck, 1999)

list useful refactoring patterns, while (Feathers, 2004)

stresses how legacy code can be made testable.

3 SOFTWARE EVOLUTION

This section outlines relevant disciplines and nomen-

clature related to software evolution.

3.1 Overview

(Lehman et al., 2000) divide the view on software

evolution into two disciplines. The scientiﬁc dis-

cipline investigates the nature of software evolution

and its properties, while the engineering discipline

focuses on the practical aspects like “theories, ab-

stractions, languages, activities, methods and tools

required to effectively and reliably evolve a software

system.” (Lehman, 1980) classiﬁes programs based

on their relationship to the environment where they

are executed. Lehman also formulates the eight laws

of software evolution. Among those laws, two as-

pects are emphasized: continuing change (i.e., with-

out adaption, software can become progressively less

effective), and increasing complexity (i.e., as software

evolves, its complexity tends to increase unless effort

is spent to avoid that). According to (Herraiz et al.,

2013), these laws have been proven in many cases,

but they are not universally valid.

3.2 Legacy Systems

There are different deﬁnitions of what a legacy system

or legacy code is. (Brodie and Stonebraker, 1995) de-

scribe it as “a system which signiﬁcantly resists mod-

iﬁcation and evolution.” (Feathers, 2004) deﬁnes it as

code without tests, while (Hunt and Thomas, 1999)

state that “All software becomes legacy as soon as it’s

written.”

Preserve or Redesign Legacy Systems

According to (Schneidewind and Ebert, 1998), the

question whether to preserve or redesign a legacy sys-

tem is not easy to answer. In general, most organiza-

tions do not rush to replace legacy systems, because

the successful operation of these systems is vital. But

they must eventually take some action to update or re-

place their systems, otherwise they will not be able to

take advantage of new hardware, operating systems,

or applications.

ICEIS 2016 - 18th International Conference on Enterprise Information Systems

414

An important aspect of this decision is that one

does not have to choose an extreme solution like pre-

serving a system unaltered, or redesigning it from

scratch. Instead, the existing system can be main-

tained while the replacement system is developed,

which makes a ﬂuid transition from the old to the new

system possible. This minimizes the disruption to the

existing system and avoids replacing the existing sys-

tem as a whole while it is operational (Schneidewind

and Ebert, 1998).

(Sneed, 1995) remarks that reengineering is only

one of many solutions to the typical maintenance

problems with legacy systems. He also mentions that

there must be a signiﬁcant beneﬁt, like cost reduction

or added value, to justify the reengineering, and that it

is important to compare the maintenance costs of the

existing solution to the expected improvements intro-

duced by the reengineering.

3.3 Software Aging

“Programs, like people, get old. We can’t prevent ag-

ing, but we can understand its causes, take steps to

limits its effects . . . and prepare for the day when the

software is no longer viable.” (Parnas, 1994)

The maintenance costs of an aged application tend

to increase, because modiﬁcations to a software gen-

erally make future adaptions more difﬁcult. Therefore

it is important to invest time to keep software modules

simple, to clean up convoluted code, and to redesign

program logic if necessary (Monden et al., 2000).

3.4 Maintenance

Software maintenance is sometimes considered to be

the ﬁnal phase of the delivery life-cycle. Unfortu-

nately, this deﬁnition is outdated for many types of

software, which must constantly adapt to changing re-

quirements and circumstances in their environment.

Maintenance Effort and Costs

In large software codebases, the required maintenance

effort is high. (Basili et al., 1996) show how to build a

predictive effort model for software maintenance re-

leases, with the goal of getting a better understanding

of maintenance effort and costs. (Brooks Jr., 1995)

claims that the total maintenance costs of a widely

used program are typically at least 40% of the initial

development costs. (Rashid et al., 2009) show that

over the last few decades the costs of software mainte-

nance have increased from 35-40% to over 90% of the

total costs of the system. According to (Harrison and

Cook, 1990), more than 70% of the software budget is

spent on maintenance; 75% of software professionals

are involved with maintenance. According to (Cole-

man et al., 1994), HP has between 40 and 50 million

lines of code under maintenance, and 60% to 80% of

research and development personnel are involved in

maintenance activities.

Maintenance Classes

(Lientz and Swanson, 1980) categorize maintenance

activities into four classes: adaptive (keeping up

with changes in the software environment); perfective

(new functional or nonfunctional user requirements);

corrective (ﬁxing errors); and preventive (prevent fu-

ture problems). The most maintenance effort (around

51%) falls into the second category, while the ﬁrst cat-

egory (around 23%), and the third one (around 21%),

make up most of the remaining effort.

There are several metrics to evaluate how main-

tainable a system is. Unfortunately, these meth-

ods don’t always produce consistent results (Sjøberg

et al., 2012; Riaz et al., 2009). (Sjøberg et al., 2012)

consider the overall system size to be the best predic-

tor of maintainability.

3.5 Reengineering

“Reengineering (. . . ) is the examination and alter-

ation of a subject system to reconstitute it in a new

form and the subsequent implementation of the new

form. Reengineering generally includes some form of

reverse engineering (to achieve a more abstract de-

scription) followed by some form of forward engineer-

ing or restructuring.” (Chikofsky and Cross II, 1990)

Many times the existing software is a legacy sys-

tem, although “it is not age that turns a piece of soft-

ware into a legacy system, but the rate at which it

has been developed and adapted without having been

reengineered.” (Demeyer et al., 2002)

(Feathers, 2004) mentions that in the case of

legacy systems the necessary reengineering phase has

to be more elaborate and should be accompanied by

the introduction of automated tests, to make sure the

current application behaves the same before and after

the reengineering. (Gottschalk et al., 2012) describe

reengineering efforts to reduce the energy consump-

tion of mobile devices.

3.6 Portability of Programs

Older high-level languages like C always aimed to be

portable across systems, but often fall short, e.g., due

to different APIs or system word size. To solve these

problems, new languages were designed that run on

Software Evolution of Legacy Systems - A Case Study of Soft-migration

415

virtual machines. This was a huge step forward in

terms of portability, as programs are compiled into an

intermediate language that is runnable without modi-

ﬁcations on any system with an implementation of the

required virtual machine. Java is an example of such

a language.

A similar approach is taken by web applications,

which require a web browser instead of a virtual ma-

chine. The browser-based approach has other advan-

tages like easy distribution. Web applications run

on every platform with modern browser. Newer ap-

proaches based on system virtualization and contain-

ers (like Docker) address the need for better portabil-

ity of whole subsystems without any restrictions on

programming language or the used ecosystem.

Java Language and Platforms

Java is a programming language speciﬁcally designed

for portability, achieved via virtual machines. They

cover nearly all platforms, from smart cards and mo-

bile phones to desktop and server environments. The

most familiar non-ofﬁcial platform is probably An-

droid, which supports large portions of the JavaSE

API excluding graphical related portions such as

Swing and AWT.

Other uses of the language are based on compila-

tion of Java code to another programming language,

such as GWT (Google Web Toolkit), which compiles

from Java to JavaScript, or J2ObjC, which compiles

from Java to Objective-C. Although most transpilers

support a large part of the source language’s features

and API, certain features cannot be mapped to the tar-

get language (e.g., classes that are used for the Java

GUI Framework Swing are not supported in GWT).

The main advantage of such a source-to-source

compiler (also known as transpiler) is that there is

no need for a Java Virtual Machine. This is especially

important for the web platform, because even though

browser-plugin-based Java Applets are possible, the

plugin is based on the Netscape plugin API (NPAPI),

which is not supported by mobile browsers. Further-

more, desktop browsers have also started to remove

NPAPI support, e.g., the Chrome browser removed it

on September 1, 2015.

4 COSTS AND BENEFITS

This section discusses software evolution types and

costs and beneﬁts of migration/preservation.

support.google.com/chrome/answer/6213033

4.1 Types of Software Evolution

Simpliﬁed, software evolution comes in various ﬂa-

vors (in increasing order of perceived costs), and is

characterized by the following activities:

Legacy-based Evolution

1. Simple maintenance

• Keep the system running.

• Only apply bugﬁxes and required changes.

2. Maintenance with some reengineering

• Carefully adapt and overhaul program logic.

• Document application logic.

• Create automated tests if missing.

Migration-based Evolution

3. Soft migration

• Use tools to ease migration (e.g., virtual ma-

chines, transpilers, . . . ).

• Reuse as much as possible the core parts of the

legacy source.

• Only add minimal code in new languages (e.g.,

Java wrapper around existing COBOL applica-

tion; HTML pages for GWT transpiled code).

4. Hard migration or porting

• Re-program the application from scratch.

• Re-compile existing code on new target plat-

form.

At ﬁrst glance, the costs seem to increase in this

list of evolutionary steps. However, this need not be

the case:

• As for (1), legacy systems set up with old pro-

gramming languages (ADA, COBOL) might in-

cur increasing maintenance costs due to a lack of

available expertise.

• With respect to (4), well-programmed C-code, on

the other hand, can theoretically be ported to, i.e.,

re-compiled on, a new operating system at almost

zero cost. (In practice, this very rarely happens;

even supposedly platform-independent languages

like Java often cause portability problems.)

4.2 Software Evolution Criteria

After outlining some terminology and various aspects

of software evolution, we can now summarize costs,

risks, and beneﬁts involved in migrating software

to help determine the appropriate software evolution

type.

ICEIS 2016 - 18th International Conference on Enterprise Information Systems

416

Table 1: Comparison of costs/risks and beneﬁts of preservation.

Preservation Risks Preservation Beneﬁts

Legacy systems are hard to maintain and change. Stability (training, operations, . . . ) is preserved.

Underlying, external dependencies (e.g., hardware,

operating systems, virtual machines, software frame-

works) could become difﬁcult or impossible to ob-

tain, risking an inability to operate the software.

Better predictability of overall system costs (if no ma-

jor changes are required).

User acceptance for the software might wane, and the

user base might erode, as users ﬂock to other vendors

with more modern approaches, like updated GUIs, or

solutions running on new systems. For example, en-

dusers might choose to use windows-based GUIs over

their command-line-based ancestors.

Saved resources can be applied to keep the software

alive with minor, and less dangerous, software evo-

lution steps than outright migration, like partial re-

engineering, documentation via reverse-engineering,

or virtualization.

If the software components, languages, or frame-

works are becoming obsolete, it might get more dif-

ﬁcult and/or costlier to ﬁnd the required program-

ming expertise (witness the numerous COBOL sys-

tems still running in insurance and banking). Mainte-

nance efforts and costs will likely increase over time.

Table 2: Comparison of costs/risks and beneﬁts of migration.

Migration Risks Migration Beneﬁts

Obviously, setting up or re-writing software is expen-

sive and the costs are often difﬁcult to estimate. The

original software’s long-developed optimizations and

workarounds might not always be easy to reproduce

with completely new technology.

Modern languages and related tools, a larger pro-

grammer base, faster hardware, . . . , can reduce costs

of new feature development, maintenance, and error

ﬁxing.

Choosing new environments, setups, and languages

as migration target carries the risk of selecting wrong

candidates, like soon-to-be obsolete OSes or lan-

guage paradigms. New, buzz-word-rich platforms of-

ten fade and disappear quite unceremoniously.

Modern new software frameworks and libraries can

improve the user experience, maintainability, and

testability of the system.

There are considerable risks of introducing bugs or

unwanted software behavior. Even seemingly useful

bug ﬁxes can lead to problems, e.g., if other systems,

aware of the known bug, already compensate for it.

Better APIs can increase interoperability with mod-

ern software.

If parts of the system are not migrated, or if the old

software needs to be kept alive (e.g., due to con-

tractual obligations), duplicate code bases need to be

maintained, and changes propagated to both.

New platforms (mobile, web, . . . ) can open up new

markets and increase user acceptance.

Domain experts and the developers of the legacy sys-

tem are probably not available anymore, therefore it

can be hard to understand and re-implement the soft-

ware correctly.

New code can be made more modular using object

oriented design patterns, increasing its re-usability,

and introduce automated tests (unit tests, integration

tests, . . . ).

If the old system is not documented properly, knowl-

edge that exists only implicitly within the program

logic can get lost.

Vendor and platform dependency can be reduced

(e.g., by removing libraries).

5 SOFT MIGRATION

Tools and frameworks can greatly facilitate software

migrations; they allow for what we dub “soft” migra-

tions. The next subsection gives a general overview

on the variety of such migration assistance; the fol-

lowing one focuses on Java-based support.

Software Evolution of Legacy Systems - A Case Study of Soft-migration

417

5.1 Soft Migration Overview

System Virtual Machines

System VMs (also called Full Virtualization VMs)

virtualize the complete operating system to emulate

the underlying architecture required by a program.

Examples are VirtualBox or VMWare.

Application Virtual Machines

Application VMs (also called Process VMs) run as a

normal application inside an existing operating sys-

tem. They abstract away (most) platform and op-

erating system differences, and therefore allow the

creation of platform-independent programs that can

be executed using this VM. Examples are the Java

Virtual Machine, the Android Runtime (ART), or

the Common Language Runtime (used by the .NET

Framework).

Integrated Virtual Machines

Integrated VMs can be seen as a subtype of Applica-

tion VMs, because they are integrated and run within

another program (e.g., as a plugin). One popular ex-

ample are Java Applets, where the JVM is either part

of a browser, or added with a browser plugin. Today,

they are not very common anymore, because browsers

started to remove the support for such plugins for se-

curity reasons (see section 3.6 about the removal of

NPAPI support in browsers).

Transpilers

A transpiler is a source-to-source compiler. It com-

piles or translates one language to another and there-

fore enables code reuse between different program-

ming languages. Examples are GWT, which tran-

spiles from Java to JavaScript, or J2ObjC, which tran-

spiles from Java to Objective-C.

Delegates/Wrappers

Delegates or wrappers are tools that allow interaction

between system and programming language bound-

aries. There are several reasons to create a wrapper

(like security, or usage of a different programming

language), but the basic idea is to hide the underly-

ing program and instead provide a suitable interface

for the user. Examples are libraries that allow to call

from COBOL to Java

, or from Java to .NET.

supportline.microfocus.com/documentation/books/nx40/

dijint.htm

www.ikvm.net

Distribution Utilities/Platforms

These are tools to facilitate the installing and up-

dating of applications. One example is Java Web

Start, which is basically a protocol for a standardized

way to distribute Java applications and their updates.

Other examples are digital distribution platforms like

Google Play Store or the Apple App Store.

5.2 Java-based Soft Migration

This section describes soft-migration approaches in

the context of the Java platform in more detail. Java

has several properties that make it a good example

for software migration: it is designed for platform in-

dependence, which facilitates, e.g., mere migrations

to new operating systems; it is very popular and thus

there exist a wide variety of support tools; and sev-

eral of its language features make concurrent support

of different platforms easier than with other program-

ming languages.

Idea

As mentioned, the Java Programming language can

be run on nearly all commonly used platforms (any

platform with a Java Virtual Machine (JVM) support,

like Android, iOS, and GWT via transpilation). Un-

fortunately, not the full Java API is available on all of

these platforms—therefore core Java code that is to be

run on various platforms needs to be more restrictive

in terms of API usage than the rest of the code.

The idea of reusing program logic on several plat-

forms and programs, even if they do not use the same

programming language, is not new. Most client/server

applications already hide their internally used pro-

gramming language(s) by providing a standardized

type of API (e.g., CORBA, JAX-WS, or REST). This

enables several programs to reuse certain functional-

ity as if it were part of their own application code.

This soft-migration approach also encapsulates

the shared functionality behind a speciﬁc API and al-

lows different programs to reuse it. If these programs

use different programming languages, the language

barrier can be avoided by using transpilers (e.g., to

JavaScript with GWT, or to Objective-C with J2Objc).

Supporting Technology

As mentioned in section 4.1, soft-migration relies on

supporting tools. With Java, several such tools and

frameworks are available:

• GWT is a Java to JavaScript compiler to facilitate

migrations to web-based platforms.

ICEIS 2016 - 18th International Conference on Enterprise Information Systems

418

• J2Objc is a Java to Objective-C compiler to port

code to iOS.

• RoboVM is a Java ahead-of-time compiler and

runtime, for iOS and OS X.

An alternative way to run Java applications within

a web browser are Java Applets, but they depend on

browser plugins, which are often limited in function-

ality for security reasons.

Steps

1. Analyze the current application. The ﬁrst goal

must be to understand the legacy system in its cur-

rent form. The core concepts must be abstracted

and a high-level architectural model must be cre-

ated. Ideally, the system is amply documented;

in practice, some reverse-engineering is often in-

evitable.

2. Improve the architectural model. To support mi-

gration, or to extract reusable core components,

the high-level architectural model usually must be

improved. This typically leads to improved mod-

ularization of the application and to the creation

of a clearer, layered architectural model.

3. Reengineer the application. The next step is the

implementation of the improved model. This is

also typically the most complex step. Special care

must be taken not to break original functionality,

e.g., via—possibly newly introduced—unit tests.

Documentation must be updated and/or kept in

sync with the changes. Organically grown ex-

tensions and ad-hoc solutions or ﬁxes should be

ironed out. This is also an opportunity to clean up

naming conventions, as well as build processes.

4. Migrate to the new platform. After the necessary

reengineering steps are completed, the new plat-

form speciﬁc code must be implemented. If the

previous steps were successfully implemented,

there should be clear interfaces to the shared code-

base.

5. Optional: remove code for old platform. If the old

platform should be dropped, its platform-speciﬁc

code can be removed. This helps minimize main-

tenance efforts—even “dead” code causes obsta-

cles when browsing/understanding a code base.

Creating New Software

In addition to the use case of migrating an existing ap-

plication to a new platform, the idea of a shared Java

core component can also be used when writing new

software that should run on several platforms. Ray

Cromwell gave a presentation at the GWT.create con-

ference in January 2015 entitled Google Inbox: Multi

Platform Native Apps with GWT and J2ObjC

, where

he explained details about how Google approached

the development of their new product Inbox. He men-

tions that they share 60-70% of their code in a Java-

based core component, which is (a) used as a Java De-

pendency for the Android application, (b) compiled

to Objective-C (with J2Objc) for the iOS application,

and (c) compiled to JavaScript (with GWT) for the

web application.

Useful Tools

As mentioned, the Java platform offers many tools

that help in keeping the codebase maintainable and

modular. The following list presents some important

categories of tools, and lists some examples.

• Automated Tests. Typically, legacy codebases

have no automated tests, therefore it is risky to

refactor such code, because any change can eas-

ily break previously working features. Therefore

it is usually a good idea to write some tests before

refactoring the code. A useful tool to write and ex-

ecute tests for Java code is JUnit.

It can be com-

bined with Mockito

to create simple mocks of

dependencies. Combined with Powermock

, even

static ﬁelds, ﬁnal classes, and private methods can

be mocked for tests.

As legacy codebases often consist of tightly cou-

pled components, it might be necessary to break

those dependencies (see section 5.2) before writ-

ing tests (e.g., a tightly coupled database connec-

tion is typically a problem for tests, but a tightly

coupled utility class might not). Unfortunately,

breaking those dependencies also involves code

changes. (Feathers, 2004) describes this vicious

cycle of avoiding bugs by making code testable

through changes that can potentially introduce

new bugs.

• Dependency Injection. This implements the prin-

ciple of Inversion of Control for resolving the de-

pendencies of a class. It basically means that ob-

jects do not instantiate their dependencies them-

selves, but get them injected either manually us-

ing the constructor, or by a dependency injection

framework. Martin Fowler

describes the pattern

drive.google.com/ﬁle/d/0B3ktS-w9vr8IS2ZwQkw3WVR

VeXc

junit.org

code.google.com/p/mockito

www.powermock.org

www.martinfowler.com/articles/injection.html

Software Evolution of Legacy Systems - A Case Study of Soft-migration

419

in detail and compares it to some alternatives (like

the Service Locator pattern).

The advantages of using dependency injection be-

come apparent in this migration-approach, as the

shared code must not depend on the platform-

speciﬁc implementation of any dependency. Ex-

amples for frameworks supporting dependency in-

jection are Google Guice

or Spring.

• Static Code Analysis Tools. These tools can ﬁnd

potential bugs, dead or duplicate code, and they

can help to enforce a common code style. Exam-

ples: FindBugs,

PMD,

or Checkstyle.

• Build and Dependency Management. Tools like

Apache Maven

or Gradle

manage the depen-

dencies of an application and its submodules.

They also standardize several other aspects of an

application like the directory structure and the

build process. Their “convention over conﬁgu-

ration” approach

also helps to familiarize new

developers with a cade base, simply because of

familiar project structure conventions.

6 EXEMPLARY MIGRATION

UMLet (Auer et al., 2009; Auer et al., 2003) is a UML

tool in active development since 2001. It is referenced

in 200+ publications, as well as 16+ books on soft-

ware engineering. UMLet is the most favored plu-

gin on the Eclipse Marketplace (Eclipse is the world-

leading Java integrated development environment). In

the 12 months leading up to August 1st 2015, more

than 700.000 page views to UMLet’s main web site

have been recorded via Google Analytics.

UMLet uses a text-based approach of customiz-

ing UML elements (e.g., entering the line fg=red in

the elements properties text block will color the back-

ground of the element red). Text without a speciﬁc

meaning is simply printed, which is, e.g., a fast way

to declare class methods.

To provide an exemplary application of the sug-

gested soft-migration approach, UMLet gets migrated

to a modern GWT-based web application that runs

without browser plugins, while the Swing and Eclipse

plugin versions are retained.

github.com/google/guice

spring.io

ﬁndbugs.sourceforge.net

pmd.sourceforge.net

checkstyle.sourceforge.net

maven.apache.org

www.gradle.org

softwareengineering.vazexqi.com/ﬁles/pattern.html

6.1 Legacy/Migration Criteria

Section 4.2 suggests two main decision drivers with

the current UMLet codebase:

• The user base might move to new, web-based plat-

forms, e.g., yUML

, sketchboard

, js-sequence-

diagrams

or websequencediagrams

• The current two-level platform (Java virtual ma-

chine on top of an OS) is not very future-proof:

– Java often does not come pre-installed; it is not

unlikely that future closed-source OS iterations

further discourage Java deployments.

– OS vendors like Apple increasingly limit the in-

stallation of unsigned software, or try to coax

applications to be provided via custom app

stores. This gives vendors the inﬂuence to pro-

hibit ﬂexible, uncomplicated installs for casual

users, and also allows them to ban applications

outright (e.g., if an application does not com-

ply with some user interface guidelines, if the

vendor perceives its usability or uniqueness as

not adequate, or if tech specs like access right

handling are not to the vendor’s liking).

These two criteria are the main drivers to use a mi-

gration approach with the goal of increasing the plat-

form independence of UMLet.

6.2 Analysis

A ﬁrst analysis shows that most of the applications

code is tightly coupled with Swing classes. The

main building blocks of the diagram (UML-Classes, -

UseCases, -Relations, . . . ), which are called GridEle-

ment, all extend the Swing class JComponent.

The Eclipse plugin provides a small SWT-based

wrapper around the Swing-based code to make it

runnable in Eclipse. The parsing of the elements

text is done within an overwritten JComponent.print()

method, therefore there is no clear separation between

parsing and drawing.

6.3 Reengineering

The goals of the UMLet reengineering are to:

• separate parsing and drawing of element proper-

ties;

• remove coupling between GridElement classes

and Swing-speciﬁc classes;

yuml.me/diagram/scruffy/class/draw

sketchboard.me

bramp.github.io/js-sequence-diagrams

www.websequencediagrams.com

ICEIS 2016 - 18th International Conference on Enterprise Information Systems

420

• introduce an abstraction layer with generic draw

methods instead of directly relying on Swing

Graphics objects;

• move GridElements to a separate module.

Even after the reengineering, there will be a rel-

atively large portion of platform-speciﬁc code. E.g.,

the composition of the graphical user interface will

still be platform-speciﬁc and must be implemented

separately for GWT and Swing.

Based on this analysis, the given high-level archi-

tectural model can be retained with only minor differ-

ences on each platform (e.g., ﬁle-IO handling). The

main restructuring of the model consists of a clear

deﬁnition on how the properties of GridElements get

parsed and drawn by each platform.

6.4 Implementation of Shared Codebase

As mentioned, the shared codebase mostly consists

of the GridElements and the appropriate parsing and

drawing logic.

New GridElements

The new GridElements have a uniﬁed syntax for the

commands and therefore break backwards compati-

bility with some old diagrams. They are also reduced

to a smaller set of customizable elements to avoid un-

necessary element duplication.

Reusable Commands on Properties

The concept of element properties (and functions trig-

gered by speciﬁc commands) is implemented using a

separate parsing procedure, which is executed every

time an element changes its properties or size. During

this procedure, all possible commands for the speciﬁc

element are checked and—if triggered—executed.

The main advantage of this approach is that these

functions can be shared between elements. If two ele-

ments need to implement, e.g., the command bg=red

to set the background color to red, they can refer to

the same generic function. Changes like new features

or bugﬁxes to such a function will therefore automat-

ically be applied to all elements relying on them.

Common Drawing API

Platform-speciﬁc drawing logic is hidden behind a

platform-independent API, which offers basic meth-

ods like drawLine(), drawRectangle(), printText(), as

well as styling methods like setBackgroundColor() or

setLineThickness(). Every platform has to implement

this API and redirect the calls to the underlying graph-

ical framework (e.g., Swing in JavaSE, or the HTML

Canvas drawing methods in GWT).

Missing Basic Classes in GWT

As UMLet makes heavy use of geometric function-

ality, it needs classes such as Point, Line, Rectan-

gle, . . . Unfortunately, those classes are located in the

AWT package and therefore not available on many

platforms like GWT

or Android.

To circumvent

this problem, alternative classes are created that are

converted to platform-speciﬁc ones directly before

drawing.

6.5 Web Implementation UMLetino

The web version of UMLet is called UMLetino and it

transfers UMLet’s minimalistic, text-based GUI ap-

proach to the web. The initial GUI mock was de-

signed to look exactly like UMLet, but after further

evaluation, it was apparent that a web application

needs several adaptions. One difference, e.g., is the

menu, which is a collapsible horizontal menu at the

top border in most desktop applications, but a simple

vertical menu on the left side for most web applica-

tions.

Another UI component that is different, because

it is already embedded in the browser, is the tab-bar.

An UMLetino-speciﬁc tab-bar below the browser tabs

can be confusing and it does not prevent the user from

opening multiple UMLetino tabs in the browser. It

was therefore removed; users who want to work in

parallel on several diagrams can rely on the native

browser tabs instead.

Figure 1 shows the ﬁnal, reengineered code struc-

ture in UML format.

Storing in Files or on the Web

UMLet stores diagrams in the ﬁle system. Web appli-

cations typically have limited access to it, therefore

we have implemented several alternatives. Diagrams

can be stored:

1. in the local storage of the browser (as a quick

save/load while working on a diagram);

2. on the ﬁle system, with drag-and-drop-based im-

port, and an export based on Data-URIs and the

browser’s save-as functionality;

3. on Dropbox

servers using the users’ accounts.

www.gwtproject.org/doc/latest/RefJreEmulation.html

developer.android.com/reference/packages.html

www.dropbox.com

Software Evolution of Legacy Systems - A Case Study of Soft-migration

421

The diagrams are stored using the XML-based

UXF ﬁle format, which is also used in UMLet.

Browser Local Storage

- used for persistent data

- store/load diagram uxfs

- clipboard simulation

- offers basic operations

-e.g. import, export,

save, restore

File Drop

- drag&drop uxf files

into the browser to

create diagram

Command

- represents a undoable

interaction with the diagram

- e.g. Add Element

- e.g. Move Element

Listener

- routes browser events to

Diagram

- e.g. MouseClickEvent

- e.g. KeyPressEvent

XML Parser

- transforms uxf into diagram with grid elements

- transforms diagram with grid elements into uxf

Palette

- represent predefined diagrams

for certain use case

- e.g. UML Class, UML Package

Selector

- holds selection state of diagram

- can manipulate selection state

Diagram

- contains diagram specifics (e.g. elements,

diagram properties, ...)

- consists of DrawPanel and DrawCanvas

GridElement

- represents one element and its properties (text,

color, ...)

- executable properties encapsulated in Commands

- drawn using a DrawHandler

Entry Point

- the point which starts the application

- html page with mostly javascript

uses ▲

interacts

with ▲

◄ interacts

with

sends uxf to ▲

executes on ▲

routes

events

uses

selection state

contains

0..*

0..1

initializes

serializes

contains

0..*

is a

Figure 1: Reengineered code structure in UML format.

6.6 Code Base Analysis

Before Migration:

• 22,688 total (all in one project)

After Migration:

• 21,419 in Baselet (Standalone/UMLet speciﬁc)

• 8,915 in BaseletElements (shared)

• 3,135 in BaseletGWT (Web/UMLetino speciﬁc)

• 33,469 total

These numbers show that the web version con-

sists of approx. 26% platform-speciﬁc code and 74%

shared code.

The standalone version in comparison only con-

sists of approx. 70% platform speciﬁc code and 30%

shared code, but this is mostly due to the legacy sup-

port for the now deprecated OldGridElements. The

old elements consist of roughly 5,600 LOC, so as

soon as they are removed, approx. 36% of code will

be shared.

Furthermore, there are some elements that have

not been migrated to the shared codebase until now,

due to their complexity (All in One Elements), or de-

pendency on a Java Compiler during runtime (Custom

Elements). They consist of roughly 4,000 LOC and

will reduce the standalone speciﬁc code even more,

while increasing the shared portion.

Although containing still much more speciﬁc code

than the web version, the standalone project supports

3 different sub-platforms (Eclipse plugin, Swing stan-

dalone, and batch-mode) and therefore requires more

code.

The overall duration of the migration was roughly

6 months; 2 developers in a remote-team setup spent

an overall effort of 400 man-hours.

6.7 Lessons Learned

During UMLet’s soft migration, we encountered sev-

eral generic and speciﬁc issues worth mentioning:

• Front-end code is often more platform-dependent

and should be de-coupled from business logic.

There are several graphical libraries for JavaSE

like AWT, Swing, or SWT. Android and GWT of-

fer their own APIs. One possible way of avoid-

ing this duplication is the usage of HTML (prob-

ably with some JavaScript generated by GWT),

because most modern GUI frameworks can dis-

play embedded HTML+JavaScript views. In case

of UMLet the code didn’t have a clear separation

between GUI and business logic; therefore a sig-

niﬁcant amount of time was necessary to modu-

larize and decouple the components of the appli-

cation in order to make the extraction of a shared

core component possible. Fortunately, large por-

tions of UMLet’s graphical output is drawn on a

Canvas where every platform offers its own im-

plementation with only minor differences.

• Choosing 3rd-party libraries creates dependen-

cies and impacts the overall portability. If a Java

program should run on several platforms it must

be veriﬁed that 3rd-party libraries work on all of

them. In general, such libraries are only allowed

to use Java classes that are supported by the plat-

form speciﬁc API. In addition, GWT compiles

Java source code to JavaScript, i.e., the library

must be available as source code and not only as

compiled classes.

• Special language features like reﬂection and reg-

ular expressions limit portability. GWT does not

support reﬂection out of the box, and the default

Java RegEx classes are only partially supported.

Complex Regular Expressions must use GWT

speciﬁc classes that work more like JavaScript

RegEx than Java RegEx. In general, if a speciﬁc

JVM feature like bytecode generation or just in

time compilation is used, it has to be veriﬁed if it

is supported by the target platform and the used

transpiler.

ICEIS 2016 - 18th International Conference on Enterprise Information Systems

422

• The documentation and tool support of GWT is

very good, but the future is uncertain. GWT

is well documented and an Eclipse plugin eases

development and testing. The GWT Dev Mode

makes debugging within the IDE very convenient.

Nevertheless, GWT Dev Mode is restricted to

older browser versions (e.g., Firefox 26), because

current browser versions have removed some re-

quired APIs (e.g., NPAPI). GWT offers the Super

Dev Mode as alternative, but the Eclipse integra-

tion is only possible by using 3rd-party plugins

like SDBG

, and is less convenient.

• Useful web applications require modern brow-

sers. In general, web applications that should

behave like standalone desktop applications typ-

ically require certain APIs to interact with the un-

derlying system. This is a minor inconvenience

for browsers like Chrome or Firefox, which get

constantly updated, but other browsers like the In-

ternet Explorer often lag behind. UMLetino also

requires some speciﬁc HTML 5 features like the

Web Storage API or the File Reader API, which

are only available in Internet Explorer 10+.

• Platforms have different constraints. Although

modern browsers offer several APIs to allow deep

system integration, the web platform still has

many constraints that do not exist for standalone

applications. One example is the interaction with

the ﬁle system. Standalone applications like UM-

Let have full access to the ﬁle system, but web

applications have only limited access. File can

be read by using the HTML 5 File Reader API,

but most browsers disallow write access to the

ﬁle system (only Chrome allows it to a sandboxed

section of the ﬁlesystem).

Find UMLetino at www.umletino.com.

7 CONCLUSION

Software maintenance, aging, and evolution are often

considered an afterthought. We hope to emphasize

with this paper that software will inevitably age, and

that this will surely have a non-trivial impact on its

use and cost proﬁle over time.

Within the general evolution process, planners and

programmers can use a simple framework to help

reach evolution decisions. A concrete instance of

one application’s soft migration hopefully helps to il-

lustrate this. This should also underline how mod-

ern tools make software migration much more fea-

github.com/sdbg/sdbg

sible. Future work should especially look a the re-

cent container-based software deployment tools, es-

pecially with regard to outside interface dependen-

cies. Of special interest are layers that interact with

persistent data storage (typically databases). Another

approach worth examining concerns GUI adaptabil-

ity for various screen/input environments, especially

as GUIs are notoriously tricky to migrate.

Finally, these considerations should not merely be

applied “down the road,” though this is still useful.

Instead, the foreseeable eventual software evolution

should be part of any decisions made during the soft-

ware’s initial design stages. Those are often crucial

in making sure the software will age gracefully—and,

ideally, never die.

REFERENCES

Auer, M., P

olz, J., and Bifﬂ, S. (2009). End-User Develop-

ment in a Graphical User Interface Setting. In Proc.

11th Int. Conf. on Enterprise Inf. Systems (ICEIS).

Auer, M., Tschurtschenthaler, T., and Bifﬂ, S. (2003). A

Flyweight UML Modelling Tool for Software Devel-

opment in Heterogeneous Environments. In Proc.

29th Conf. on EUROMICRO.

Basili, V., Briand, L., Condon, S., Kim, Y.-M., Melo, W. L.,

and Valett, J. D. (1996). Understanding and Predict-

ing the Process of Software Maintenance Releases. In

Proc. 18th Int. Conf. on Software Engineering (ICSE).

Bennett, K. H. and Rajlich, V. T. (2000). Software Mainte-

nance and Evolution: A Roadmap. In Proc. Conf. on

The Future of Software Engineering (ICSE).

Benomar, O., Abdeen, H., Sahraoui, H., Poulin, P., and

Saied, M. A. (2015). Detection of Software Evo-

lution Phases Based on Development Activities. In

Proc. 23rd IEEE Int. Conf. on Program Comprehen-

sion (ICPC).

Brodie, M. L. and Stonebraker, M. (1995). Migrating

Legacy Systems: Gateways, Interfaces, and the Incre-

mental Approach. Morgan Kaufmann.

Brooks Jr., F. P. (1995). The Mythical Man-Month. Addi-

son-Wesley.

Businge, J., Serebrenik, A., Brand, M. V. D., and van den

Brand, M. (2010). An Empirical Study of the Evo-

lution of Eclipse Third-party Plug-ins. In Proc. Joint

ERCIM WS on Software Evolution (EVOL) and Int.

WS on Principles of Software Evolution (IWPSE).

Chaikalis, T. and Chatzigeorgiou, A. (2015). Forecasting

Java Software Evolution Trends Employing Network

Models. IEEE Transactions on Software Engineering,

41(6):582–602.

Chikofsky, E. J. and Cross II, J. H. (1990). Reverse En-

gineering and Design Recovery: A Taxonomy. IEEE

Software, 7(1):13–17.

Coleman, D., Ash, D., Lowther, B., and Oman, P. (1994).

Using Metrics to Evaluate Software System Maintain-

ability. IEEE Computer, 27(8):44–49.

Software Evolution of Legacy Systems - A Case Study of Soft-migration

423

Demeyer, S., Ducasse, S., and Nierstrasz, O. (2002). Object

Oriented Reengineering Patterns. Morgan Kaufmann.

Feathers, M. (2004). Working Effectively with Legacy Code.

Prentice Hall.

Fowler, M. and Beck, K. (1999). Refactoring: Improving

the Design of Existing Code. Addison-Wesley.

Gottschalk, M., Joseﬁok, M., Jelschen, J., and Winter, A.

(2012). Removing Energy Code Smells with Reengi-

neering Services. In Beitragsband der 42. Jahresta-

gung der Gesellschaft f

ur Informatik e.V. (GI).

Harrison, W. and Cook, C. (1990). Insights on Improving

the Maintenance Process Through Software Measure-

ment. In Proc. Int. Conf. on Software Maintenance

(ICSME).

Herraiz, I., Rodriguez, D., Robles, G., and Gonzalez-

Barahona, J. M. (2013). The Evolution of the Laws

of Software Evolution: A Discussion Based on a Sys-

tematic Literature Review. ACM Computing Surveys,

46(2):1–28.

Hunt, A. and Thomas, D. (1999). The Pragmatic Program-

mer: From Journeyman to Master. Addison-Wesley.

Johari, K. and Kaur, A. (2011). Effect of Software Evolu-

tion on Software Metrics. ACM SIGSOFT Software

Engineering Notes, 36(5):1–8.

Kim, M., Cai, D., and Kim, S. (2011). An Empirical In-

vestigation into the Role of API-Level Refactorings

during Software Evolution. In Proc. 33rd Int. Conf.

on Software Engineering (ICSE).

Lehman, M. M. (1980). Programs, Life Cycles, and Laws

of Software Evolution. In Proc. IEEE.

Lehman, M. M., Ramil, J. F., and Kahen, G. (2000). Evolu-

tion as a Noun and Evolution as a Verb. In Proc. WS

on Software and Organisation Co-evolution (SOCE).

Lehman, M. M., Ramil, J. F., Wernick, P. D., Perry, D. E.,

and Turski, W. M. (1997). Metrics and Laws of Soft-

ware Evolution - The Nineties View. In Proc. 4th Int.

Symposium on Software Metrics (METRICS).

Lientz, B. P. and Swanson, E. B. (1980). Software Mainte-

nance Management. Addison-Wesley.

Mens, T. and Demeyer, S. (2008). Software Evolution.

Springer.

Monden, A., Sato, S.-i., Matsumoto, K.-i., and Inoue, K.

(2000). Modeling and Analysis of Software Aging

Process. In Product Focused Software Process Im-

provement SE - 15, volume 1840 of Lecture Notes in

Computer Science, pages 140–153. Springer.

Parnas, D. L. (1994). Software Aging. In Proc. 16th Int.

Conf. on Software Engineering (ICSE).

Rashid, A., Wang, W. Y. C., and Dorner, D. (2009). Gaug-

ing the Differences between Expectation and Systems

Support: the Managerial Approach of Adaptive and

Perfective Software Maintenance. In Proc. 4th Int.

Conf. on Cooperation and Promotion of Inf. Resources

in Science and Techn. (COINFO).

Ratzinger, J., Sigmund, T., Vorburger, P., and Gall, H.

(2007). Mining Software Evolution to Predict Refac-

toring. In Proc. 1st Int. Symposium on Empirical Soft-

ware Engineering and Measurement (ESEM).

Riaz, M., Mendes, E., and Tempero, E. (2009). A Sys-

tematic Review of Software Maintainability Predic-

tion and Metrics. In Proc. 3rd Int. Symp. on Empirical

Software Engineering and Measurement (ESEM).

Schneidewind, N. F. and Ebert, C. (1998). Preserve or Re-

design Legacy Systems. IEEE Software, 15(4):14–17.

Sjøberg, D. I. K., Anda, B., and Mockus, A. (2012). Ques-

tioning Software Maintenance Metrics: A Compar-

ative Case Study. In Proc. 6th Int. Symposium on

Empirical Software Engineering and Measurement

(ESEM).

Sneed, H. M. (1995). Planning the Reengineering of Legacy

Systems. IEEE Software, 12(1):24–34.

Zhang, J., Sagar, S., and Shihab, E. (2013). The Evolu-

tion of Mobile Apps: An Exploratory Study. In Proc.

Int. WS on Software Development Lifecycle for Mobile

(DeMobile).

ICEIS 2016 - 18th International Conference on Enterprise Information Systems

424
